Page 1
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Overview
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 1
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Front
1.
Camera (optional)
3.
RFID reader (optional)
2.
HP Sure View Gen3 Integrated Privacy Screen
(optional)
Page 2
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Overview
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 2
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Side
1.
Optical disc drive (optional)
4.
Universal audio jack with CTIA headset support
2.
Optical disc drive eject button (optional)
5.
Headphone connector
3.
Standard lock slot (10 mm)
Page 3
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Overview
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 3
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Bottom components and rear ports (behind security cover)
1.
USB 3.1 Gen 2 Type-A port
7.
USB 3.1 Gen 2 Type-A ports (2) wake capable
2.
USB 3.1 Gen 2 Type-A port (charge support up to
5V/1.5A)
8.
HDMI 2.0a connector
9.
Dual-Mode DisplayPort™1.2 (DP++)
3.
Audio line-out connector
10.
SD card reader 4.0 (optional)
4.
USB 3.1 Gen 1 Type-A ports (2)
11.
USB 3.1 Type-C™ Gen 2 port (charge support up to 5V/3A)
5.
RJ-45 (network) jack
12.
Dual-state power button
6.
Power connector
13.
HP Sure View Button (optional)
Page 4
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Overview
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 4
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Infrared (IR) and dual facing camera (optional)
1.
Camera light
5.
Rear camera adjustment wheel
2.
IR camera light
6.
Digital microphones
3.
Full High Definition (FHD) camera
7.
Camera light
4.
IR camera
8.
FHD camera
Full High Definition (FHD) camera (optional)
1.
Camera light
3.
Digital microphones
2.
FHD camera
Page 5
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 5
AT A GLANCE
• All-in-One form factor (touch)
• Sanitizable with germicidal wipes every shift, every day
1
• Optional HP Sure View Gen3 Integrated Privacy Screen
• Optional, integrated dual-band RFID reader and and biometrics for integrated single sign-on support
• Optional, integrated RFID Asset Tag for Inventory tracking
• Intel® Q370 chipset
• Intel® 9
th
generation and select 8th Core™ processors
• Intel® vPro™ Technology available with Intel® Core™ i3, i5, i7 and i9 processors
• Processor support – 54W/65W
• Integrated Intel® UHD Graphics
• Windows 10
• Intel® Ethernet Connection I219LM GbE LOM integrated network connection
• EN/EN 60601-1-2:2015 compliant
• Skype for Business® certified
• Vidyo Ready for telemedicine
2
• Optional dual-facing and IR camera supports Windows Hello
• Available Stand Options: Adjustable Height Stand or No Stand (VESA mountable)
• DDR4 Synchronous Dynamic Random Access Memory (SDRAM)
• HP Sure Start Gen5
3
• HP Sure Sense
6
• HP Manageability Integration Kit Gen3
4
• ENERGY STAR® certified. EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country7
• TCO Edge for AiO
• PC chassis and all internal components and modules are manufactured with low halogen content
5
• Protected by HP Services, including warranties up to 3-3-3 (terms and conditions vary by country; certain restrictions and
exclusions apply)
1. Based on HP’s internal analysis as of Nov. 1, 2017 of AiOs tested to simulate up to 10,000 wipes with germicidal towelettes over a 3-year
period. See user guide for cleaning instructions. The HP EliteOne 800 G5 23.8-in Healthcare Edition AiO is not intended for use in diagnosis, cure,
treatment or prevention of disease or other medical conditions.
2. Vidyo not included sold separately
3. HP Sure Start Gen5 is available on HP Elite and HP Pro 600 products equipped with Intel® 8th generation processors.
4. HP Manageability Integration Kit Gen3 can be downloaded from http://www.hp.com/go/clientmanagement.
5. External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase may not be low
halogen.
6. Requires Windows 10. See product specifications for availability
7. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
Page 6
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 6
OPERATING SYSTEMS
Preinstalled
Microsoft Windows® 10 Pro
1
Microsoft Windows® 10 Pro (National Academic License)
2
Microsoft Windows® 10 Home
1
Microsoft Windows® 10 Home Single Language
1
Windows® 10 IoT Enterprise LTSC 2018
FreeDos 3.0
Web-supported only
Microsoft Windows® 10 Enterprise 64
1
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased
hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is
always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update.
Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
NOTE: Your product does not support Windows 8 or Windows 7
In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or Windows 7 operating system on products configured
with Intel and AMD 7th generation and forward processors or provide any Windows® 8 or Windows 7 drivers on
http://www.support.hp.com
Page 7
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 7
CHIPSET
Intel® Q370
PROCESSORS
Intel® 9th Generation Core™ Processors
*Intel® Core™ i9 9900 processor with Intel® UHD Graphics 630 (3.1GHz, up to 4.9 GHz with Intel® Turbo Boost,16MB cache, 8
cores) 65W1 Supports Intel® vPro™Technology
*Intel® Core™ i7 9700 processor with Intel® UHD Graphics 630 (3.0 GHz, up to 4.8 GHz with Intel® Turbo Boost, 12 MB cache, 8
cores) 65W
1,2
Supports Intel® vPro™ Technology
*Intel® Core™ i5 9600 processor with Intel® UHD Graphics 630 (3.1 GHz, up to 4.6 GHz with Intel® Turbo Boost, 9 MB cache, 6
cores)
1, 2
Supports Intel® vPro™Technology3
*Intel® Core™ i5 9500 processor with Intel® UHD Graphics 630 (3.0 GHz, up to 4.4 GHz with Intel® Turbo Boost, 9 MB cache, 6
cores)
1, 2
Supports Intel® vPro™Technology3
*Intel® Core™ i3 9300 processor with Intel® UHD Graphics 630 (3.7 GHz, 8 MB cache, 4 cores)1
*Intel® Core™ i3 9100 processor with Intel® UHD Graphics 630 (3.6 GHz, 6 MB cache, 4 cores)1
*Intel® Pentium® Gold G5620 processor with Intel® UHD Graphics 630 (4.0 GHz, 4 MB cache, 2 cores)1
*Intel® Pentium® Gold G5600 processor with Intel® UHD Graphics 630 (3.9 GHz, 4 MB cache, 2 cores)1
*Intel® Pentium® Gold G5420 processor with Intel® UHD Graphics 610 (3.8 GHz, 4 MB cache, 2 cores)1
*Intel® Celeron® G4930 processor with Intel® UHD Graphics 610 (3.2 GHz, 2 MB cache, 2 cores)
Intel® 8th Generation Core™ Processors
*Intel® Core™ i7 8700 vPro™ processor with Intel® UHD Graphics 630 (3.2 GHz, up to 4.6 GHz with Intel® Turbo Boost, 12 MB
cache, 6 cores) 65W
1,2
Supports Intel® vPro™Technology3
***Intel® Core™ i5 8500 vPro™ processor with Intel® UHD Graphics 630 (3.2 GHz, up to 4.6 GHz with Intel® Turbo Boost, 12 MB
cache, 6 cores) 65W
1,2
Supports Intel® vPro™Technology3
*Intel® Core™ i3 8100 processor with Intel® UHD Graphics 630 (3.6 GHz, 6 MB cache, 4 cores)1
1: Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily
benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and
software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
2. Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies
depending on hardware, software and overall system configuration. See http://www.intel.com/technology/turboboost for more
information.
3. Some functionality of vPro technology, such as Intel Active management technology and Intel Virtualization technology, requires
additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependant
on 3rd party software providers. Compatibility of this generation of Intel vPro technology-based hardware with with future "virtual
appliances" is yet to be determined.
NOTE: In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products
configured with Intel® and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on
http://www.support.hp.com.
NOTE: Multicore is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your
hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
NOTE: Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system.
Page 8
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 8
GRAPHICS
Integrated Intel® Graphics
Intel® UHD Graphics 630 (integrated on 9th gen Core i9/i7/i5/i3, Pentium® Gold G5600, G5500)
Intel® UHD Graphics 610 (integrated on 9th Pentium® Gold G5400, Celeron® G4900)
STORAGE AND DRIVES1
2.5 inch 7200 RPM Hard Disk Drives
500GB SATA
1TB SATA
2.5 inch 5400 RPM Hard Disk Drives
500GB SATA
2TB SATA
2.5 inch Self-encrypting Drives (SED HDD)
500GB 7200RPM 2.5in SED OPAL 2
500GB 7200RPM 2.5in Federal Information Processing Standard (FIPS) SED
2.5 SATA SSD Drives
256GB SATA TLC SSD
512GB SATA TLC SSD
2.5 inch Self-encrypting Drives (SED SSD)
256GB TLC SED SSD OPAL 2 Drive
256GB TLC SED SSD OPAL 2 Drive 2nd
512GB TLC SED SSD OPAL 2 Drive
512GB TLC SED SSD OPAL 2 Drive 2nd
256GB TLC SED SSD 2.5in Federal Information Processing Standard (FIPS) SED
512GB TLC SED SSD 2.5in Federal Information Processing Standard (FIPS) SED
PCIe NMVe SSD Drives
128GB PCIe NVMe TLC SSD
128GB PCIe NVMe TLC SSD 2nd
256GB PCIe NVMe TLC SSD
256GB PCIe NVMe TLC SSD 2nd
512GB PCIe NVMe TLC SSD
512GB PCIe NVMe TLC SSD 2nd
2TB PCIe NVMe TLC SSD
2TB PCIe NVMe TLC SSD 2nd
1TB PCIe NVMe TLC SSD
1TB PCIe NVMe TLC SSD 2nd
128GB PCIe NVMe SSD
128GB PCIe NVMe SSD 2nd
256GB PCIe NVMe SSD
256GB PCIe NVMe SSD 2nd
512GB PCIe NVMe SSD
512GB PCIe NVMe SSD 2nd
PCIe NMVe Self-encrypting Drives (PCIe NVMe SED SSD)
256GB PCIe NVMe TLC SED SSD OPAL 2 Drive
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to
36GB (for Windows 10) of system disk is reserved for the system recovery software.
Page 9
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 9
DISPLAY FEATURES
HP EliteOne 800 G5 Healthcare Edition 23.8-in FHD Display
23.8" diagonal IPS widescreen WLED backlit LCD (1920 x 1080)
Discrete Touch
Glass covered display
HP Sure View Gen 3 (optional)
MEMORY
Maximum
64GB (32GB/slot)
Memory Slots
2 SODIMMs
DDR4-2666 (Transfer rates up to 2666 MT/s)
Dual channel support
Customer accessible/upgradeable
Configurations
4 GB (1 x 4 GB)
8 GB (2 x 4 GB)
8 GB (1 x 8 GB)
16 GB (2 x 8 GB)
16 GB (1 x 16 GB)
32 GB (2 x 16 GB)
32 GB (1 x 32 GB)
64 GB (2 x 32 GB)
512 GB Intel® PCIe® NVMe™ QLC + 32 GB Intel® Optane™
NOTE: Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system.
NETWORKING
Wireless LAN
Intel® Wi-Fi 6 AX200 ax 2x2 Wi-Fi® +Bluetooth® M.2 Combo Card non-vPro™
Intel® Wi-Fi 6 AX200 ax 2x2 Wi-Fi® +Bluetooth® M.2 Combo Card vPro™
Intel® 9560 802.11b/g/n/a/ac 2x2 Wi-Fi® Bluetooth® M.2 Combo Card non-vPro™
Intel® 9560 802.11b/g/n/a/ac 2x2 Wi-Fi® +Bluetooth® M.2 Combo Card vPro™
Realtek RTL8822BE ac 2x2 Wi-Fi®+Bluetooth® M.2 Combo Card
Ethernet (RJ-45) Integrated
Intel® I219LM Gigabit Network Connection LOM (standard)
NOTE: Wireless LAN is optional and must be bought at purchase
NOTE: Wireless access point and Internet service required and not included. Availability of public wireless access points limited.
NOTE: The specifications for the 802.11ax WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the device to communicate with other 802.11ax WLAN devices.
Page 10
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 10
AUDIO/MULTIMEDIA
Audio
Integrated Conexant CX5001 codec - up to 24-bit PCM
High performance integrated stereo speakers(2.5watt)
High Definition Audio
Integrated
Conexant CX5001
Blu-Ray / DVD
Blu-ray Writer 9.5mm EliteOne AiO*
DVD-ROM 9.5mm EliteOne AiO (DVD-Rom)**
DVD-Writer 9.5mm EliteOne AiO (DVD-Writer)***
HP 9.5mm EliteOne 800 Slim DVD-Writer Drive***
Media Card Reader
SD 4.0 with 5-in-1 Interface (Supports SD, SDXC, SDHC, UHS-I, UHS-II)
Webcams & Mic
Pop-up camera - 2MP FHD camera, up to 30 frames/sec, discrete dual array microphone (Fixed 2MP FHD 1080p)(maximum
resolution of 1920 x1080)(optional)
Pop-up camera - 2MP FHD camera with IR camera front-facing and 2nd rear-facing 2MP camera discrete dual array
microphone (Dual Camera 480P IR+1080P RGB Fixed/2MP FHD 1080P Fixed)(maximum resolution of 1920x1080)(optional)
IR camera (optional) supports Win10 Hello
NOTE: Universal Audio Jack with CTIA headset support (re-taskable for headphone/line out/microphone in/line in)
*NOTE: With Blu-Ray, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in
the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI
digital connection and your display may require HDCP support.
**NOTE: HD-DVD disks cannot be played on this drive. No support for DVD-RAM. Actual speeds may vary. Don’t copy copyright-protected
materials. Double Layer discs can store more data than single layer discs. Discs burned with this drive may not be compatible with many
existing single-layer DVD drives and players.
***NOTE: Don’t copy copyright protected material.
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard and Mouse Combos
HP USB Keyboard and Mouse Healthcare Edition
HP Premium Wireless Keyboard and Mouse
HP Wireless Business Slim Keyboard and Mouse
HP USB Keyboard and Mouse
Keyboards
HP USB Collaboration Wired Keyboard
HP Collaboration Wireless Keyboard
HP USB Business Slim Keyboard
HP USB Business Slim Grey Keyboard
HP USB Business Slim CCID SmartCard Keyboard
HP USB Business Slim Antimicrobial Keyboard*
HP USB Wired Keyboard
HP Wired Keyboard EPEAT®
HP USB PS/2 Washable Standalone Wired Keyboard
HP USB Conferencing Wired Keyboard
Page 11
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 11
Mice
HP USB 1000dpi Laser Mouse
HP Grey V2 Mouse
HP USB Mouse
HP USB Antimicrobial Mouse*
HP USB Hardened Mouse
HP Washable Wired Mouse USB PS/2
HP Optical USB Mouse
Other
HP Mouse Pad
HP EliteOne G5 AiO Dust Filter
Adapters and Cables
HP DisplayPort Cable
HP DisplayPort to DVI-D Adapter
HP DisplayPort to HDMI True 4K Adapter
HP DisplayPort to VGA Adapter
HP DVI Cable
HP USB Type-C to Type-A Hub
HP USB to Serial Port Adapter
HP USB-C to USB 3.0 Adapter
HP Type-C to DisplayPort Adapter
Headsets
HP Business Headset v2
*China Only
HP BIOSPHERE
HP BIOS
Key features of the HP BIOS include:
• Deployment and manageability – HP BIOS provides several technologies that help integrate the HP EliteOne 800
Healthcare PC into the enterprise, such as PXE, remote configuration, remote control, and BIOS (F10) Setup support
for 15 languages.
• Network firmware updates – Update your BIOS via hp.com, Windows Update or standardize on a BIOS version hosted
on an Enterprise network.
• Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and
advanced change notification.
• UEFI specification version 2.6
• Absolute Persistence agent – For tracking and tracing services, available in select countries, separate software and
purchase of a subscription is required.
• Thermal and power management – The HP BIOS provides and enables thermal and power management technologies
so component temperatures are managed for high reliability and to assist in operating the HP Business Desktop
computer in any enterprise environment.
• Acoustic performance – Industry leading acoustic emissions across the range of operating conditions.
• Serviceability – HP BIOS provides diagnostic and detailed service information.
• Upgrades and recovery – HP BIOS provides numerous ways to upgrade HP Business Desktop computers, including
BIOS updates from within Windows (HP FirmwareUpdRec utility), HP Client Manager, and fail-safe recovery. In
addition, the HP BIOS Configuration Utility enables replication of BIOS settings within Windows while the Replicated
Setup feature provides the same capability within BIOS (F10) Setup. The BIOS Configuration Utility is available from
the HP support website.
• HP BIOS uses PKI signing of the BIOS for trusted BIOS upgrades and recovery.
Page 12
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 12
Additional HP BIOS Features:
• Power-On password – Helps prevent an unauthorized user from powering on the system.
• Administrator password – Also known as the setup password, this helps prevent unauthorized changes to the system
configuration. If the administrator password is not known, the BIOS cannot be updated and changes cannot be made
to BIOS settings using BIOS Setup or under the OS.
• S5 Maximum Power Savings setting supports EU Lot6 requirement and allows the computer to power down below
0.5W in S5 (when turned off). When S5 Maximum Power Savings feature is enabled below features are turned off:
- Power to expansion connectors / slots
- Wake events other than power buttons (such as wake on LAN)
- USB charging ports
• HP SureStart Gen5
• BIOS Integrity checking – Sure Start protection ensures that only trusted BIOS code is executed and not rootkits,
viruses and malware. Verification is done upon boot up, shutdown and while On.
• SureStart Gen5 is set by default to automatically repair the BIOS if corrupted or compromised but is policy driven for
better manageability.
• Protecting beyond BIOS – Integrity checking and repair is extended to other data that should be protected such as
network configuration parameters (network name), platform specific information (i.e. system IDs) and other code
the system needs to boot.
• Audit enabled – System Audit via Sure Start Event Logs capture data such as incident, repair date and time for
troubleshooting and investigating.
PORTS/SLOTS
Rear I/O Connectors
(2) USB 3.1 Gen 1 Type A w/ S4/S5 Wake
(3) USB 3.1 Gen 2 Type A
(1) USB 3.1 Gen 2 Type A w/ BC 1.2
(1) USB 3.1 Gen 2 Type-C DFP w/ 3.0A w/ BC1.2
(1) LAN RJ45
(1) DisplayPort 1.2
(1) HDMI 2.0a
(1) Audio Line-Out
(1) SD Card Reader 4.0
Left I/O Connectors
(1) Headphone
(1) Headset - CTIA UAJ Headset w/o Virtual OMTP
M.2 Socket
(1) M.2 Socket 1 Type 2230-E
(1) M.2 Socket 3 Type 2230/80-M
(1) M.2 Socket 3 Type 2230/42/80-M
Storage
(2) SATA Power/Data Combo
Page 13
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 13
SOFTWARE AND SECURITY
BIOS
HP BIOSphere Gen5 17
HP DriveLock & Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase 18
Absolute Persistence Module
19
RAID configurations 33
Pre-boot Authentication
HP Wireless Wakeup
Software
HP Native Miracast Support 15
HP LAN-Wireless Protection
HP Hotkey Support - CMIT
HP Recovery Manager
HP Jumpstart
HP Support Assistant 21
HP Noise Cancellation Software
HP Easy Clean 2.0
Buy Office
Manageability Features
HP Driver Packs 22
HP System Software Manager (SSM)
HP BIOS Config Utility (BCU)
HP Client Catalog
HP Manageability Integration Kit Gen3 23
Ivanti Management Suite 24
HP Collaboration Keyboard
Client Security Software
HP Client Security Suite Gen5 including: 25
HP Security Manager 26 (including Credential Manager, HP Password Manager, HP Spare Key)
Power On Authentication
HP Fingerprint Sensor 31
HP Device Access Manager
HP Power On Authentication
Windows Defender
27
HP Sure Run Gen 2
HP Sure View Gen 3
HP Sure Sense35
Page 14
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 14
Security Management
HP BIOSphere Gen5 17
HP DriveLock & Automatic DriveLock
BIOS Update via Network
Secure Erase 18
Pre-boot Authentication
TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified) 32
SATA 0,1 port disablement (via BIOS)
Serial, USB enable/disable (via BIOS)
Power-on password (via BIOS)
Setup password (via BIOS)
Support for chassis padlocks and cable lock devices
Integrated hood sensor
HP Sure Click
34
HP Sure Recover Gen 2
HP Sure Start Gen5 30
15. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming
17. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details. Features may vary depending on
the platform and configurations.
18. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method.
HP Secure Erase does not support platforms with Intel® Optane™.
19. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be
purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery
Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided by
Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a
Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software
21. HP Support Assistant requires Windows and Internet access.
22. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.
23. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html
24. Ivanti Management Suite subscription required.
25. HP Client Security Manager Gen5 requires Windows and is available on select HP Pro and Elite PCs. See product specifications for
details.
26. HP Password Manager requires Internet Explorer or Chrome or FireFox. Some websites and applications may not be supported. User
may need to enable or allow the add-on / extension in the internet browser.
27. Windows Defender Opt In, Windows 10, and internet connection required for updates..
30. HP Sure Start Gen5 is available on HP EliteBook products equipped with Intel® 9th generation processors
32. Firmware TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM 2.0 specification version v0.89 as implemented by
Intel Platform Trust Technology (PTT).
33. RAID configuration is optional and requires 2 equivalent hard drives.
34. HP Sure Click is available on most HP PCs and supports Microsoft® Internet Explorer, Google Chrome, and Chromium™. Supported
attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe Acrobat
are installed.
35. HP Sure Sense requires Windows 10. See product specifications for availability.
36. HP Sure View must be ordered at purchase, functions in landscape orientation and is planned to be available in July 2019.
37. HP Sure Recover Gen2: See product specifications for availability. Requires an open, wired network connection. Not available on
platforms with multiple internal storage drives. You must back up important files, data, photos, videos, etc. before using HP Sure Recover
to avoid loss of data. HP Sure Recover (Gen1) does not support platforms with Intel® Optane™.
38. HP Sure Run Gen2: See product specifications for availability.
Page 15
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 15
POWER
Power Supply
Internal
Internal 180W
ENVIRONMENTAL AND INDUSTRY
UNIT ENVIRONMENTAL AND OPERATING CONDITIONS
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit
is operated within the specified operating range.
• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that they are subject to each other's
re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range
Operating: 50° to 95° F (10° to 35° C)*
Non-operating: -22° to 140° F(-30° to 60° C)
Relative Humidity
Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude (unpressurized)
Operating: 5000m
Non-operating: 50000ft (15240 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight.
Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country*. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short
idle)
24.408 W
24.48 W
24.225 W
Page 16
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 16
Normal Operation (Long
idle)
4.861 W
4.951 W
4.723 W
Sleep
1.467 W
1.486 W
1.411 W
Off
0.73 W
0.788 W
0.707 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short
idle)
83.231 BTU/hr
83.477 BTU/hr
82.607 BTU/hr
Normal Operation (Long
idle)
16.576 BTU/hr
16.883 BTU/hr
16.105 BTU/hr
Sleep
5.0025 BTU/hr
5.067 BTU/hr
4.812 BTU/hr
Off
2.489 BTU/hr
2.687 BTU/hr
2.411 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
2.7
17.3
Fixed Disk – Random
writes
3.2
20.4
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680.1-2018 EPEAT® Status varies by country. Visit
www.epeat.net for more information. Search keyword generator on HP’s 3rd party option store for
solar generator accessories at http://www.hp.com/go/options
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
1419 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
694 g
PLASTIC/Polyethylene low density
94 g
Page 17
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 17
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers.
These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
HP Inc. Corporate
Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
Page 18
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Features
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 18
SERVICE AND SUPPORT
On-site Warranty 16: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day 17 service for
parts and labor and complimentary limited technical support. Three-year onsite and labor are not available in all countries.
Service offers terms up to 5 years by choosing an optional HP Care Pack.
18
To choose the right level of service for your HP
product, visit HP Care Pack Central: http://www.hp.com/go/cpc
16.Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.
17. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable
HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory
rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP
Limited Warranty provided with your HP Product.
CERTIFICATION AND COMPLIANCE
ENERGY STAR® certified; EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
www.epeat.net for registration status by country
NOTE: Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net for more
information.
Page 19
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications - RFID CARD READER
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 19
RFID CARD READER
Operating Frequencies
125 kHz, 13.56 MHz
Read Height
1in (Typical)
Device Class
HID
Protocol
USB HID
NFC RF Standards (in
reading CSN)
ISO/IEC 14443 A, ISO/IEC 14443 B
ISO/IEC 15693
NFC Forum Support
Tag Type 1, Type 2, Type 3, and Type 4 in reading CSN
Raw RF Data Rates
Low-frequency Cards: 1,2050 to 7,812 bps
High-frequency Cards: 106 to 848 bps
Card Types Supported –
125 kHz
AWID (RDR-698x Compatible)
Cardax UID (RDR-6C8x Compatible)
CASI-RUSCO (GE Security, UTC) (RDR-628x Compatible)
CDVI
COTAG
Deister UID
DIGITAG
Dimpna UID
EM 410x (RDR-6E8x Compatible)
EM 410x Alternate
Farpointe Data (Pyramid) PSC-1 26 Bit (RDR-647x Compatible)
Farpointe Data (Pyramid) UID
GProx-II ID
GProx-II UID (IRDR-6G8x Compatible)
HID Prox (RDR-608x Compatible)
HID Prox UID
Hitag 1 & S (RDR-6H8x Compatible)
Hitag 1 & S Alternate
Hitag 2 (RDR-6H8x Compatible)
Hitag 2 Alternate
ID Teck (RDR-6A8x Compatible)
ID Teck Alternate (128 bits)
Indala ASP 26 bit (Motorola) (RDR-638x Compatible)
Indala ASP UID (Motorola)
Indala ASP+ UID (Motorola)
IO Prox (Kantech) (RDR-678x Compatible)
Isonas
Keri NXT UID
Keri PSC-1 26 Bit: (RDR-647x Compatible)
Keri UID (RDR-6K8x Compatible)
Nedap
NexKey, Quadrakey, KeyMate, 2SmartKey (Honeywell)
Nexwatch (Honeywell) (RDR-6N8x Compatible)
Paradox
Postech
Pyramid (Farpointe Data) PSC-1 26 Bit
Pyramid (Farpointe Data) UID
Radio Key (Secura Key -02) RKCx-02 (RDR-6Z8x Compatible)
ReadyKey Pro UID RDR-6R8x Compatible)
Rosslare
Russwin UID
Secura Key -01 RKCx-01
Page 20
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications - RFID CARD READER
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 20
Card Types Supported –
13.56 MHz
CEPAS
e-TAG
Felica (NFC Type 3)
HID iCLASS
I-Code
ISO 14443B
I-tag
Legic Advant
MIFARE Classic (32 bits)
MIFARE DESFire
MIFARE DESFire EV1
MIFARE Plus
MIFARE Ultralight
my-d CSN (Infinion)
NFC Type 1
NFC Type 2
NFC Type 4
NTWare
Oyster
RDR-758x Equivalent (iCLASS, ISO 14443A, ISO 15693)
Tag-It (Texas instruments)
Card Types Supported –
13.56 MHz ID (with HID SE
Processor SIM)
HID iCLASS ID
HID iCLASS SE
HID iCLASS Seos
NOTE: Dual-band RFID reader and Asset Tracking sold as configurable options. SE Security Access Module (SE SAM) is a separate hardware SIM
inserted into the RFID reader and is required to support SE, SEOS, and iClass credentials for reading HID/iClass card types
Page 21
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Cleaning Care Guide
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 21
CLEANING CARE GUIDE
Please refer to the HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One Business PC user guide for instructions on cleaning this
computer. Here are additional instructions for cleaning with specific germicidal wipes.
First turn off the computer to prevent electric shock or damage to components.
o Disconnect AC power
o Disconnect all powered external devices
Examine the computer for any visible soiling and then wipe the exterior of the computer with a soft, water-dampened cloth to
remove the soil as needed.
o The cloth should be moist but not wet. Water dripping into the ventilation or other points of ingress can cause damage.
o The cloth should be of dry microfiber or a chamois (static-free cloth without oil), or static-free cloth wipes.
o Please do not use fibrous materials, such as paper towels, as these can scratch the computer. Over time, dirt and cleaning
agents can get trapped in the scratches.
Next, clean the computer using any of the ready-to-use germicidal wipes that contain the below chemical solutions.
o Remember to start with the display, then wipe the rest of the computer and finish with any flexible cables
o Allow the unit to air-dry before use
(Refer to the directions for use provided by the manufacturer of the wipes)
Ready-to-use cleaning wipe solutions include:
• Solution 1
o Benzyl-C12-18-alkyldimethyl ammonium chlorides: <0.1%
o Quaternary ammonium compounds, C12-14-alkyl[(ethylphenyl)methyl]di methyl, chlorides: <0.1%
• Solution 2
o Isopropanol: 10-20%
o 2-Butoxyethanol: <5%
o Quaternary ammonium compounds, C12-18-alkyl [(ethylphenyl) methyl] dimethyl, chlorides: <0.5%
o Benzyl-C12-18-alkyldimethyl ammonium chlorides: <0.5%
• Solution 3
o Quaternary ammonium compounds, C12-18-alkyl [(ethylphenyl) methyl] dimethyl, chlorides: <0.5%
o Benzyl-C12-18-alkyldimethyl ammonium chlorides: <0.5%
• Solution 4
o Isopropyl alcohol: 55.000%
o Alkyl dimethyl benzyl ammonium chlorides: 0.250%
o Alkyl (68% C12, 32% C14) dimethyl ethylbenzyl ammonium chloride: 0.250%
• Solution 5
o Isopropanol: 10-20%
o Ethylene Glycol Monobutyl Ether (2-Butoxyethanol): 1-5%
o Diisobutylphenoxyethoxyethyl dimethyl benzyl ammonium chloride: 0.1-0.5%
• Solution 6
o Sodium hypochlorite 0.1%–1.0%
• Solution 7
o Cellulose: 10-30%
o Ethyl alcohol: 0.10-1.00%
• Solution 8
o Isopropyl alcohol: 60-70%
Water: 30-40%
Do not use cleaners that contain any petroleum based materials such as benzene, thinner, or any volatile substance to clean the
screen or cabinet. These chemicals may damage the computer.
Occasionally clean air vents on all vented sides of the computer. Lint and dust can block the vents and limit the airflow.
Page 22
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Cleaning Care Guide
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 22
Compatible Gloves
Touch on the screen and clickpad is tuned for support with bare hands and with Latex, Nitrile, and Vinyl exam gloves.
*Solutions tested as of December 4, 2017; chemical composition is subject to change.
Page 23
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Display Panel
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 23
DISPLAY PANEL SPECIFICATIONS
23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080)
Discrete Projected Capacitive Touch supports up to 10 touch-points
Type
IPS WLED Backlit LCD
Active area (mm)
527.04 x 296.46
Native Resolution (HxV)
1920 x 1080
Aspect ratio
16:09
Pixel pitch (HxV)(mm)
0.2745 x 0.2745
Contrast ratio (typical)
1000:1
Brightness (typical)
215 nits
Viewing angle (typical) (HxV)
178 ° x 178 °
Backlight lamp life (to half brightness)
30,000 hours minimum
Color support
Over 16 million colors*
Color gamut (typical)
NTSC 72%
Anti-glare
Yes
Default color temperature
Warm (6500K)
NOTE: All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance
may vary either higher or lower.
*NOTE: Up to 16 million colors through A-FRC technology.
23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080) with optional switchable privacy display
Discrete Projected Capacitive Touch supports up to 10 touch-points
Type
IPS WLED Backlit LCD
Active area (mm)
527.04 x 296.46
Native Resolution (HxV)
1920 x 1080
Aspect ratio
16:09
Pixel pitch (HxV)(mm)
0.2745 x 0.2745
Contrast ratio (typical)
1000:1
Brightness (typical)
245 nits (non-Privacy); 170 nits (Privacy)
Viewing angle (typical) (HxV)
178 ° x 178 °(non-Privacy); 80 ° x 178 ° (Privacy)
Backlight lamp life (to half brightness)
30,000 hours minimum
Color support
Over 16 million colors
Color gamut (typical)
NTSC 72%
Anti-glare
Yes
Default color temperature
Warm (6500K)
NOTE: All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may
vary either higher or lower.
*NOTE: Up to 16 million colors through A-FRC technology.
Page 24
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 24
GRAPHICS
Intel® UHD Graphics (integrated)
DisplayPort™
Multimode capable; supports HDCP 2.2, Display Port Audio (2 streams), HBR2 link rates and
Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)
HDMI
Supports HDMI 2.0a features
Memory
The actual amount of maximum graphics memory can be >4GB. System memory is allocated
for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide
an optimal balance between graphics and system memory use.
Maximum Color Depth
Up to 10 bits/color
Graphics/Video API Support
HEVC 10b Enc/Dec HW
VP9 10b Dec HW
HDR
Rec. 2020
DX12
Display Output chart.
Resolution
Refresh
Rate
VGA
(Using HP DP to
VGA adapter)
DVI-D
(Using HP DP to
DVI-D adapter)
DisplayPort™
HDMI
Standard
640 x 480
60, 75, 85
X
X X X
VESA DMT, CVT 0.31M3
720 x 400
70 X X X X
IBM VGA
800 x 600
60, 75, 85
X
X X X
VESA DMT, CVT0.48M3
1024 x 768
60, 75, 85
X
X X X
VESA DMT, CVT 0.79M3
1152 x 864
60, 75, 85
X
X X X
VESA DMT, CVT 0.83MA
1280 x 720
60, 75, 85
X
X X X
VESA DMT, CVT 0.92M9, CEA-
770.3
1280 x 768
60, 60RB,
75, 85 X X X X
VESA DMT, CVT 0.98M9/0.98M9R
1280 x 800
60, 75, 85
X
X X X
VESA DMT
1280 x 960
60, 75, 85
X
X X X
VESA DMT
1280 x 1024
60, 75, 85
X
X X X
VESA DMT, CVT 1.31M4
1366 x 768
60, 60RB
X
X X X
VESA DMT
1440 x 900
60, 60RB
X
X X X
VESA DMT
1600 x 900
60, 60RB,
75, 85 X X X X
VESA DMT
1680 x 1050
60, 60RB
X
X X X
VESA DMT, CVT 1.76MA/1.76MAR
1920 x 1080
60 X X X X
VESA DMT, CVT 2.07M9, SMPTE
274M
1920 x 1080
75 X X
CVT-RBv2 (2.07M-R)
1920 x 1080
100 X X
CVT-RBv2 (6.14M-R)
1920 x 1080
120 X X
SMPTE 274M
Page 25
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 25
1920 x 1080
144 X X
SMPTE 274M
1920 x 1200
60, 60RB
X1
X X X
DMT, CVT 2.30MA/2.30MA-R
1600 x 1200
60 X X X X
VESA DMT, 1.92M3
1920 x 1440
60, 75, 85
X X
VESA DMT, CVT 2.76M3
1920 X 1600
59.95 X X
CVT-RBv2 (Not CVT Standard
Aspect Ratio)
2048 x 1536
60 X X
CVT 3.15M3
2560 x 1440
59.951 X X
CVT 3.69M9-R
2560 x 1600
60, 60RB
X X
VESA DMT, CVT 4.10MA/4.10MAR
3440 x 1200
60 X X
CVT-4.61M-R
3440 x 1440
49.987 X X
CVT-RB v1
3440 x 1440
59.973 X X
CVT-RB v1
3440 x 1440
60 X X
Samsung Custom
3440 x 1440
100 X X
CVT-RBv2 (4.95M-R)
3440 x 1440
120 X X
CVT-RBv2 (4.95M-R)
3840 x 1600
30 X X
CVT-RBv2 (6.14M-R)
3840 x 1600
59.994 X X
CVT-RBv2
3840 x 2160
24 X X
SMPTE 274M
3840 x 2160
25 X X
SMPTE 274M
3840 x 2160
30 X X
SMPTE 274M
3840 x 2160
29.981 X X
CVT-RB v1
3840 x 2160
50 X X
SMPTE 274M
3840 x 2160
59.997 X X
CVT-RBv1 (8.29M9-R)
3840 x 2160
60 X X
SMPTE 274M
4096 x 2160
24 X X
SMPTE 274M
4096 x 2160
25 X X
SMPTE 274M
4096 x 2160
30 X X
SMPTE 274M
4096 x 2160
50 X X
SMPTE 274M
4096 x 2160
59.94 X X
CVT-RBv2
4096 x 2160
60 X X
CVT-RBv2
1920 x 1080
60 X X X
VESA (SMPTE 274M)
NOTE: Other rerfresh rates and resolutions may also work, but have not been validated.
>60Hz refresh rates only for analog (VGA) signaling
1 - 60Hz Reduced Blanking only.
Page 26
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 26
STORAGE AND DRIVES
500 GB 7200RPM 2.5in SATA HDD
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB 7200RPM 2.5in SATA HDD
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
2 TB 5400RPM 2.5in SATA HDD
Capacity
2 TB
Rotational Speed
5,400 rpm
Interface
SATA 6 Gb/s
Buffer Size
128 MB
Logical Blocks
3,907,050,336
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
Page 27
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 27
500 GB 7200RPM 2.5in Self Encrypted OPAL2 SATA HDD
Capacity
500 GB
Architecture
Self-Encrypting (SED) Solid State Drive with SATA interface
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
500 GB 7200RPM 2.5in Self Encrypted Federal Information Processing Standard SATA HDD
Capacity
500 GB
Architecture
Self-Encrypting (SED) Solid State Drive with SATA interface
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<50g
Capacity
128 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 380MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
Page 28
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 28
256 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<62g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 450MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<50g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
<50g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; TCG-OPAL2.0 security
Page 29
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 29
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
<50g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; TCG-OPAL2.0 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB 2.5in SATA Self Encrypted Federal Information Processing Standard SSD
Drive Weight
<40g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; FIPS 140-2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
Page 30
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 30
512 GB 2.5in SATA Self Encrypted Federal Information Processing Standard SSD
Drive Weight
<45g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; FIPS 140-2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
128GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1400MB/s
Maximum Sequential Write
Up to 395MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 780MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
Page 31
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 31
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 860MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
1 TB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1800MB/s
Maximum Sequential Write
Up to 1800MB/s
Logical Blocks
2,000,409,264
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
128 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2800MB/s
Maximum Sequential Write
Up to 600MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Page 32
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 32
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
1 TB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 3480MB/s
Maximum Sequential Write
Up to 3037MB/s
Page 33
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 33
Logical Blocks
2,000,409,264
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2; TCG-OPAL2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2; TCG-OPAL2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
Page 34
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 34
512GB Intel® Optane™ Memory H10 with Solid State Storage
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2400MB/s
Maximum Sequential Write
Up to 1300MB/s
Logical Blocks
1,000,215,215
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
HP 9.5mm Slim DVD-ROM Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
Up to 0.31 lb (140g) without bezel
Read Speeds
DVD+R/-R/+RW/
-RW/+R DL /-R DL Up to 8X
DVD-ROM Up to 8X
CD-ROM, CD-R Up to 24X
CD-RW Up to 24X
Access time
(typical reads, including
settling)
Random: DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full stroke: DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Slim DVD Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Write Speeds
DVD-R DL - Up to 6X
DVD+R - Up to 8X
DVD+RW - Up to 8X
DVD+R DL - Up to 6X
Page 35
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 35
DVD-R - Up to 8X
DVD-RW - Up to 6X
CD-R - Up to 24X
CD-RW - Up to 10X
Read Speeds
DVD-RW, DVD+RW - Up to 8X
DVD-R DL, DVD+R DL - Up to 8X
DVD+R, DVD-R - Up to 8X
DVD-ROM DL, DVD-ROM - Up to 8X
CD-ROM, CD-R - Up to 24X
CD-RW - Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Slim Blu-Ray Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 128 GB QL, 100 GB TL, 50 GB DL or 25 GB standard SL
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.29 lb (132 g)
Write Speeds
BD-R SL/DL Up to 6X
BD-R TL/QL Up to 4X
BD-RE Up to 2X
DVD-R Up to 8X
DVD-RW Up to 6X
DVD+R Up to 8X
DVD+RW Up to 8X
DVD-RAM Up to 5X
CD-R Up to 24X
CD-RW Up to 10X
Read Speeds
BD-ROM Up to 6X
BD-R Up to 6X
BD-RE SL/DL Up to 6X
BD-RE TL Up to 4X
DVD-ROM Up to 8X
DVD-R Up to 8X
DVD-RW Up to 8X
DVD+R Up to 8X
DVD+RW Up to 8X
BDMV (AACS Compliant
Disc)
Up to 6x/2x (Read/Play)
DVD-RAM Up to 5x
DVD-Video (CSS
Compliant Disc)
Page 36
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 36
Up to 8x/4x (Read/Play)
CD-R/RW/ROM Up to 24x
CD-DA (DAE) Up to 24X/10X (Read/Play)
Access time
(typical reads, including
settling)
Random BD-ROM: 205 ms (typical), DVD-ROM: 185 ms (typical),
CD-ROM: 165 ms (typical)
Full Stroke BD-ROM: 350 ms (typical), DVD-ROM: 345 ms (typical),
CD-ROM: 340 ms (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC -1200 mA typical, 2000 mA maximum
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
Page 37
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 37
NETWORKING AND COMMUNICATIONS
Intel i219LM 10/100/1000 Integrated NIC
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K
Power Consumption
Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW
Power Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The
specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices
Intel 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5.0 Combo vPro™
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
•2.402 – 2.482 GHz
802.11a/n
•4.9 – 4.95 GHz (Japan)
•5.15 – 5.25 GHz
•5.25 – 5.35 GHz
•5.47 – 5.725 GHz
•5.825 – 5.850 GHz
Page 38
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 38
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +18.5dBm minimum
• 802.11g : +17.5dBm minimum
• 802.11a : +18.5dBm minimum
• 802.11n HT20(2.4GHz) : +15.5dBm minimum
• 802.11n HT40(2.4GHz) : +14.5dBm minimum
• 802.11n HT20(5GHz) : +15.5dBm minimum
• 802.11n HT40(5GHz) : +14.5dBm minimum
• 802.11ac VHT80(5GHz) : +11.5dBm minimum
• 802.11ac VHT160(5GHz) : +11.5dBm minimum
Power Consumption
•Transmit mode2.0 W
•Receive mode1.6 W
•Idle mode (PSP)180 mW(WLAN Associated)
•Idle mode50 mW(WLAN unassociated)
•Connected Standby 10mW
•Radio disabled8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
14° to 158° F (–10° to 70° C)
Non-operating
–40° to 176° F (–40° to 80° C
Humidity
Operating
10% to 90% (non-condensing)
Non-operating
5% to 95% (non-condensing)
Page 39
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 39
Altitude
Operating
0 to 10,000 ft (3,048 m)
Non-operating
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The
specifications for the 802.11ax WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11ax WLAN devices
Page 40
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 40
Intel 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5.0 Combo non-vPro™
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
•2.402 – 2.482 GHz
802.11a/n
•4.9 – 4.95 GHz (Japan)
•5.15 – 5.25 GHz
•5.25 – 5.35 GHz
•5.47 – 5.725 GHz
•5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +18.5dBm minimum
• 802.11g : +17.5dBm minimum
• 802.11a : +18.5dBm minimum
• 802.11n HT20(2.4GHz) : +15.5dBm minimum
• 802.11n HT40(2.4GHz) : +14.5dBm minimum
• 802.11n HT20(5GHz) : +15.5dBm minimum
• 802.11n HT40(5GHz) : +14.5dBm minimum
• 802.11ac VHT80(5GHz) : +11.5dBm minimum
• 802.11ac VHT160(5GHz) : +11.5dBm minimum
Power Consumption
•Transmit mode2.0 W
•Receive mode1.6 W
•Idle mode (PSP)180 mW(WLAN Associated)
•Idle mode50 mW(WLAN unassociated)
•Connected Standby 10mW
•Radio disabled8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Page 41
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 41
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
14° to 158° F (–10° to 70° C)
Non-operating
–40° to 176° F (–40° to 80° C
Humidity
Operating
10% to 90% (non-condensing)
Non-operating
5% to 95% (non-condensing)
Altitude
Operating
0 to 10,000 ft (3,048 m)
Non-operating
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Page 42
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 42
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The
specifications for the 802.11ax WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11ax WLAN devices
Realtek 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
•2.402 – 2.482 GHz
802.11a/n
•4.9 – 4.95 GHz (Japan)
•5.15 – 5.25 GHz
•5.25 – 5.35 GHz
•5.47 – 5.725 GHz
•5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Page 43
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 43
Output Power2
• 802.11b : +14dBm minimum
• 802.11g : +12dBm minimum
• 802.11a : +12dBm minimum
• 802.11n HT20(2.4GHz) : +12dBm minimum
• 802.11n HT40(2.4GHz) : +12dBm minimum
• 802.11n HT20(5GHz) : +10dBm minimum
• 802.11n HT40(5GHz) : +10dBm minimum
• 802.11ac VHT80(5GHz) : +10dBm minimum
Power Consumption
•Transmit mode2.0 W
•Receive mode1.6 W
•Idle mode (PSP)180 mW(WLAN Associated)
•Idle mode50 mW(WLAN unassociated)
•Connected Standby 10mW
•Radio disabled8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
14° to 158° F (–10° to 70° C)
Non-operating
–40° to 176° F (–40° to 80° C
Humidity
Operating
10% to 90% (non-condensing)
Non-operating
5% to 95% (non-condensing)
Altitude
Operating
0 to 10,000 ft (3,048 m)
Non-operating
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Page 44
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 44
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software Supported
Link Topology
USB 2.0 compliant
Power Management
Microsoft Windows Bluetooth Software
Certifications
Microsoft Windows ACPI, and USB Bus Support
Power Management
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Bluetooth Profiles Supported
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Realtek 802.11a/b/g/n/ac (1x1) Wi Fi® and Bluetooth® 4.2 Combo 1
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
•2.402 – 2.482 GHz
802.11a/n
•4.9 – 4.95 GHz (Japan)
•5.15 – 5.25 GHz
•5.25 – 5.35 GHz
•5.47 – 5.725 GHz
•5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Page 45
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 45
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +14dBm minimum
• 802.11g : +12dBm minimum
• 802.11a : +12dBm minimum
• 802.11n HT20(2.4GHz) : +12dBm minimum
• 802.11n HT40(2.4GHz) : +12dBm minimum
• 802.11n HT20(5GHz) : +10dBm minimum
• 802.11n HT40(5GHz) : +10dBm minimum
• 802.11ac VHT80(5GHz) : +10dBm minimum
Power Consumption
•Transmit mode2.0 W
•Receive mode1.6 W
•Idle mode (PSP)180 mW(WLAN Associated)
•Idle mode50 mW(WLAN unassociated)
•Connected Standby 10mW
•Radio disabled8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna.
One embedded dual band 2.4/5 GHz antenna is provided to the card to support WLAN
communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
14° to 158° F (–10° to 70° C)
Non-operating
–40° to 176° F (–40° to 80° C
Humidity
Operating
10% to 90% (non-condensing)
Non-operating
5% to 95% (non-condensing)
Altitude
Operating
0 to 10,000 ft (3,048 m)
Non-operating
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Page 46
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 46
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Page 47
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 47
INPUT/OUTPUT DEVICES
HP Conferencing Keyboard
1.
Function Keys
6.
End/Decline a Call
2.
F11 Lync or Skype for Business Contact list 1
7.
Answer a Call
3.
F12 Lync or Skype for Business Calendar2
8.
Microphone Mute
4.
Share Screen
9.
Volume Up/Down
5.
Stop Webcam
10.
Audio Mute
1. Microsoft Lync 2013, or Skype for Business Contact list
2. Microsoft Lync 2013, or Skype for Business Calendar
HP USB Premium Keyboard
Physical Characteristics
Keys
104, 105 layout (depending upon country)
Dimensions
(L x W x H)
17.04 x 5.55 x 0.52 in (433 x 141 x13.2 mm)
Weight
1.54 lb (698g)
Electrical
Operating voltage
5 VDC, +/-5%
Power consumption
35mA (All LED on)
System interface
USB Type A plug connector
ESD
Contact Discharge: 8 KV Air Discharge: 15 KV
EMI - RFI
Conforms to FCC rules for a Class B computing device
Microsoft® PC 99 - 2001
Mechanically compliant
Mechanical
Keycaps
Low-profile design
Switch actuation
60±10g nominal peak force with tactile feedback
Switch life
10 million keystrokes (Life tester)
Switch type
Contamination-resistant switch membrane
Key-leveling mechanisms
For all double-wide and greater-length keys
Cable length
6 ft (1.8 m)
Page 48
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 48
Microsoft PC 99 - 2001
Mechanically compliant
Environmental
Acoustics
43-dBA maximum sound pressure level
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating temperature
-22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Approvals
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance
TUVGS
Kit contents
Keyboard, QSP
Warranty Card
Product Notice
Skylab USB wired Keyboard
Physical Characteristics
Keys
104, 105, 106, 107, 109 layout (depending upon country)
Dimensions
(L x W x H)
436.9*137.7*20.4mm
Weight
615g
Electrical
Operating voltage
4.4-5.25VDC
Power consumption
50-mA maximum (with 5 VDC power supplied and three LEDs ON)
System interface
USB
ESD
Contact Discharge: 2, 4,6,8KV
Air Discharge: 2, 4, 8,10,12.5KV
EMI - RFI
Conforms to FCC rules for a Class B computing device
Mechanical
Keycaps
Low-profile design
Switch actuation
60±15g nominal peak force with tactile feedback
Switch life
10 million keystrokes (Life tester)
Switch type
Silicon rubber switch membrane
Cable length
6 ft (1.8 m)
Environmental
Acoustics
43-dBA maximum sound pressure level
Temperature
Minus 20 degress to 60 degress Celsius
Humidity
90%RH+-2%, 24Hours
Vibration
3mm amplitude oscillation, 60Hz
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Page 49
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 49
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Approvals
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, RCM, KC, EAC
Ergonomic compliance
ISO 9241-410, TUVGS
Kit contents
HP USB Premium Mouse
Physical characteristics
Dimensions
(L x W x H)
4.21 x 2.64 x 1.52 in (107 x 67 x 38.7 mmm)
Weight w/o cable
0.19lb (90g)
Environmental
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating temperature
-22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Electrical
Operating voltage
5 VDC, +/-5%
Power consumption (typical)
12mA
Mechanical
Connector
USB 2.0
Type
3D mouse (3 keys and wheel)
Resolution
800, 1200, 1600 DPI
Sensor
Pixart PAN3606DL
Tracking speed
30 inch/sec (max)
Tracking acceleration
8G(max), 1G=9.8m/s2
Cable length
6 ft (1.8 m)
Color
Jack Black
Regulatory Approvals
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC
HP USB Wired Keyboard
Physical characteristics
Dimensions
(H x L x W)"
37mm*115mm*62.9mm
Weight
90 +10g/- 5 g
Color
Black
Connector
USB
Resolution
800 DPI sensitivity
Buttons
Two primary buttons and clickable scroll wheel
Page 50
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Audio
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 50
AUDIO
Audio by HP Audio
Internal 2.5watt stereo speaker
3.5mm Combo Jack
High Definition Audio
Type
Integrated
HD Audio Codec
Conexant CX5001
Audio I/O Ports
Universal Audio Jack with CTIA headset support
(re-taskable for headphone/line out/microphone in/line in)
Wavetable Syntheses
Yes - Uses OS soft wavetable
Analog Audio
Yes Internal Speaker
Yes - two speakers
DAC Sampling Rates
44.1kHz/48kHz/96kHz/192kHz
ADC Sampling Rates
44.1kHz/48kHz/96kHz
NOTE: All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may
vary either higher or lower.
Page 51
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Power Supply
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 51
POWER SUPPLY
Operating Voltage Range
90 – 264 VAC
Rated Voltage Range
100-240V AC
Rated Line Frequency
50 / 60 HZ
Operating Line Frequency
47 – 63 Hz
Rated Input Current
180 W : 2.5A
Energy Efficient* Power
Supply
180 W active PFC
87/90/87% efficient at 20/50/100% load (115V)
88/91/88% efficient at 20/50/100% load (230V)
DC Output
12.1V/14.88A
Current Leakage (NFPA 99:
2102)
Less than 300 microamps of leakage current at 120 Vac with the ground wire disconnected, as
required for Non-patient Electrical Appliances and Equipment used in a patient care facility or that
contact patients in normal use. Per section 10.3.5.1.
Less than 100 microamps of leakage current at 120 Vac with the ground wire intact with normal
polarity, as required for Non-patient Electrical Appliances and Equipment used in a patient care
facility or that contact patients in normal use. Per section 10.3.5.1.
Power cord length
6.0 ft. (1.83 m)
Page 52
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 52
WEIGHTS & DIMENSIONS
Weight
Product Weight Unboxed
Without Stand
6.4 – 7.4 kg, 14.1 – 16.3 lbs
Adjustable height stand:
9.1 – 10.4kg, 20.06 – 22.93 lbs
Dimensions (W x D x H)
Products Dimensions
Without Stand
540.4 x 54 x 341.96 mm
21.24 x 2.1 x 13.5 in
Adjustable height stand (0 degress)
540.4 x 220.16 x 468 mm
21.24 x 8.67 x 18.43 in
DIMENSIONS
Page 53
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 53
Adjustable Height Stand Dimensions
Height - Vertical/Landscape
Adjustment
101mm (±2 mm)
Portrait Adjustment
54mm (±2 mm)
Tilt Angle
5° to +20° (±3°) in landscape and portrait
Rotation (Swivel)
90° (±1°)
Pivot
Clockwise 90°
Page 54
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 54
AFTER MARKET OPTIONS
Description
Part #
HP 16GB DDR4-2666 SODIMM
3TK84AA
HP 4GB DDR4-2666 SODIMM
3TK86AA
HP 8GB DDR4-2666 SODIMM
3TK88AA
HP 256GB SATA TLC Non-SED Solid State Drive
P1N68AA
HP PCIe NVME TLC 512GB SSD M.2 Drive
X8U75AA
HP PCIe NVME TLC 256GB SSD M.2 Drive
1CA51AA
Intel Optane Memory 16GB (cache) ****
1WV97AA
HP 9.5mm Slim Removable SATA 500GB
T7G14AA
HP 9.5mm AIO 800 G3 Slim DVD Writer
Z9H62AA
HP Type-C to USB3 Adapter
N2Z63AA
HP USB-C to USB-A HUB***
Z6A00AA
HP Single Monitor Arm **
BT861AA
HP EliteOne G3 800 AIO Recline Stand (optional)
Z9H67AA
HP EliteOne G3 800 AIO Adjustable Height Stand (optional)
Z9H66AA
HP Keyed Cable Lock 10mm Kit
T1A62AA
HP DVI Cable Kit
DC198A
HP DisplayPort To DVI-D Adapter
FH973AA
HP DisplayPort To VGA Adapter
AS615AA
HP DisplayPort Cable Kit
VN567AA
HP DisplayPort To HDMI 4k Adapter
K2K92AA
HP DisplayPort to Dual Link DVI Adapter
NR078AA
HP DisplayPort To HDMI True 4k Adapter
2JA63AA
HP HDMI Standard Cable Kit
T6F94AA
HP Business Headset v2
T4E61AA
HP UC Wireless Duo Headset
W3K09AA
HP USB Grey v2 Mouse
Z9H74AA
HP USB Mouse
QY777AA
HP (Bulk) USB Mouse
QY777A6
HP USB Grey Mouse
K7W54AA
HP USB 1000dpi Laser Mouse
QY778AA
HP (Bulk) USB 1000dpi Laser Mouse
QY778A6
HP PS/2 Mouse
QY775AA
HP (Bulk) PS/2 Mouse
QY775A6
HP Mouse Pad
AT485AA
HP (Bulk) Mouse Pad
AT485A6
HP USB PS/2 Washable Scroll Mouse
BM866AA
HP USB Hardened Mouse
P1N77AA
HP USB Collaboration Keyboard
Z9N38AA
HP WLess Collaboration Keyboard
Z9N39AA
HP USB Premium Keyboard
Z9N40AA
HP WLess Premium Keyboard
Z9N41AA
Page 55
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 55
HP Bus Slim Wirles Localize Kit Nordic
2MY27AA
HP Bus Slim Localize Kit - Nordic USB
2MY28AA
HP USB Keyboard and Mouse Healthcare Edition
1VD81AA
HP Business Slim Smartcard Keyboard
Z9H48AA
HP USB (Grey) Business Slim Keyboard
Z9H49AA
HP USB Antimicrobial Slim Kybd and Mouse
Z9H50AA
HP Conferencing Keyboard
K8P74AA
HP USB Conferencing Keyboard
N8N57AA
HP Wireless Keyboard & Mouse
QY449AA
HP USB Keyboard
QY776AA
HP USB Keyboard/Mouse/Mousepad Kit
B1T09AA
HP (Bulk Pack) USB Keyobard
QY776AT
HP USB (Grey) Keyboard
B6B64AA
HP (Bulk Pack) USB (Grey) Keyboard
B6B64A6
HP PS/2 Keyboard
QY774AA
HP (Bulk Pack) PS/2 Keyboard
QY774A6
HP (Bulk Pack) USB Smart Card Keyboard
ED707A6#xxx
HP USB CCID Smartcard Keyboard
BV813AA#xxx
HP (Bulk Pack) USB CCID Smart Card Keyboard
BT824A6#xxx
HP USB PS2 Washable Keyboard
VF097AA#xxx
HP USB PS2 Washable Keyboard & Mouse
BU207AA#xxx
HP USB Smartcard CCID Keyboard
E6D77AA#xxx
HP (Bulk) USB Smartcard CCID Keyboard
E6D77A6#xxx
HP USB Grey Smartcard CCID Keyboard
J7H70AA#xxx
HP (Bulk) PS/2 Business Slim Keyboard
N3R86A6
HP USB Business Slim Keyboard
N3R87AA
HP (Bulk) USB Business Slim Keyboard
N3R87A6
HP Wireless Business Slim Keyboard and Mouse
N3R88AA
HP (Bulk) Wireless Business Slim Keyboard and Mouse
N3R88A6
HP USB Business Slim Keyboard and Mouse and MousePad
T4E63AA
HP (Bulk) USB Bus Slim Keyboard/Mouse/Mousepad
T4E63A6
Page 56
QuickSpecs
HP EliteOne 800 G5 23.8-in Healthcare Edition All-in-One
Summary of Changes
Not all configuration components are available in all regions/countries.
c06314690 — DA 16475 — Worldwide — Version 4 — November 11, 2019
Page 56
Date of change:
Version History:
Description of change:
June 17, 2019
V1
Launch
October 18, 2019
V1 to V2
Update
Call outs re-arranged in side view image, adding Standard lock slot
November 11, 2019
V2 to V3
Update
EPEAT references updated
Copyright © 2019 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited
warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP
shall not be liable for technical or editorial errors or omissions contained herein.
Bluetooth is a trademark of its proprietor and used by HP Inc. under license. Intel, Core and Intel vPro are trademarks of Intel
Corporation or its subsidiaries in the U.S. and/or other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers
Forum. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the
United States and other countries.
Loading...
