QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 1

HP EliteOne 1000 G2 All-in-One Business PC

Front

1.

Webcam (optional)

4.

Collaboration keys

2.

On-screen display (OSD) buttons

5.

Power button

3.

Volume slider

6.

Speakers (optional)

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 2

HP EliteOne 1000 G2 All-in-One Business PC

Collaboration keys

1.

Volume slider

5.

Microphone mute button

2.

Speaker mute button

6.

Call button

3.

Hang up button

7.

Power button

4.

Webcam mute button

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 3

Infrared (IR) and Dual-facing Full High Definition (FHD) webcam (optional)

1.

Webcam light

5.

Rear webcam adjustment wheel

2.

IR light

6.

Digital microphones

3.

Full High Definition (FHD) webcam

7.

Webcam light

4.

IR webcam

8.

FHD webcam

Full High Definition (FHD) webcam (optional)

1.

Webcam light

3.

Digital microphones

2.

FHD webcam

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 4

HP EliteOne G2 All-in-One Business PC (rear)

Rear

1.

Security lock slot

5.

DisplayPort™ 1.2 out

2.

RJ-45 (network) jack

6.

HDMI 2.0a out connector

3.

Power connector

7.

USB 3.1 Gen2 ports

4.

DisplayPort™ 1.2 in

8.

USB 3.1 Gen2 ports (wake capable)

Not Shown

Slots

Bays

(1) internal M.2 2230 connector for optional wireless NIC

(1) 2.5" internal storage drive bay

(1) internal M.2 SSD storage (2230 or 2280 connector)

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 5

HP EliteOne 1000 G2 All-in-One Business PC (side)

Side

1.

USB 3.1 Gen1 Type-A (charging) port

5.

Universal Audio Jack with CTIA headset support

2.

USB 3.1 Gen2 Type-C™ Thunderbolt port (DP Alt mode and 15W)

6.

Fingerprint sensor (optional)

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 6

HP EliteOne 1000 Display

Additional optional displays include: HP EliteOne 1000 23.8-in FHD Display, HP EliteOne 1000 23.8-in FHD Touch Display, HP EliteOne 1000 27-in 4K UHD Display, and HP EliteOne 1000 34-in WQHD Curved Display

5

Front

1.

Webcam (optional)

3.

Power indicator LED

2.

On-screen display (OSD) buttons

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 7

HP EliteOne 1000 Display

Rear

1.

Power button

4.

Power connector

2.

DisplayPort™ 1.2 in

5.

USB Type-B out (webcam, mics, and touch)

3.

HDMI connector

6.

Security lock slot

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Overview

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 8

At a Glance

• Unique All-in-One form factor with interchangeable and upgradeable display options

• Four display options: 23.8" diagonal FHD touch and non-touch, 27" diagonal 4K UHD, and 34"diagonal WQHD Curved

5

• Ability to redeploy displays or purchase additional displays with a matching standalone display base

• Tool-less accessibility to easily reach upgradeable components or swap displays

• Creates a rich video conferencing solution with immersive video and audio engagement, capacitive touch collaboration keys, and a built-

in pop-up privacy camera

• Integrated collaboration keys keep conferencing controls (call answer, microphone mute, webcam disable, call hang up, and volume

controls) within reach

• Intel Unite (optional)

• Intel® Q370 chipset supporting Intel® 8th generation Core™ processors, featuring integrated Intel® UHD Graphics and Intel® vPro™

Technology (available with Core i5 and Core i7 processors)

• 35W and 65W processor support

• Windows 10

• Intel® UHD graphics

• Optional AMD discrete graphics

• USB 3.1 Type-C™ Thunderbolt port

• Intel® Ethernet Connection I219LM GbE LOM integrated network connection

• DDR4 Synchronous Dynamic Random Access Memory (SDRAM)

• Support for up to 2 additional monitors via DisplayPort™ 1.2 or HDMI connectors

• HP Sure Start Gen4

1

• HP Manageability Integration Kit Gen2

2

• HP Sure Click

4

• HP Sure Run

6

• HP Sure Recover

7

• HP WorkWise

8

• HP PhoneWise

1

; A phone integration solution that allows you to route phone calls and answer texts on your PC

• 23.8” and 27” screen sizes are ENERGY STAR® certified and EPEAT® Gold registered where applicable/supported. Registration may vary by

country. See http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party option store for solar generator accessories at http://www.hp.com/go/options

• CCC Certified

• TCO Edge for AiO

• PC chassis and all internal components and modules are manufactured with low halogen content

3

• Protected by HP Services, including limited warranties up to 3-3-3 (terms and conditions vary by country; certain restrictions and

exclusions apply); Care Packs available with up to 5 years ext Business Day Onsite Hardware Support

1. HP Sure Start G4 requires Intel® 8th generation processors

2. HP Management Integration Kit Gen2 for Microsoft System Center Configuration Manager: HP Management Integration Kit Gen2 can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html

3. External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase may not be low halogen.

4. HP Sure Click is available on select HP platforms and supports Microsoft® Internet Explorer, Google Chrome, and Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode. Check

http://h20195.www2.hp.com/v2/GetDocument.aspx?docname=4AA7-0922ENW for all compatible platforms as they become available.

5. Configurable at purchase with choice of display sizes. Additional displays sold separately.

6. HP Sure Run is available on HP Elite products equipped with 8th generation Intel® or AMD® processors.

7. HP Sure Recover is available on HP Elite PCs with 8th generation Intel® or AMD processors and requires an open, wired network connection. Not available on platforms with multiple internal storage drives, Intel® Optane™. You must back up important files, data, photos, videos, etc. before use to avoid loss of data.

8. HP WorkWise smartphone app is available as a free download on the Google Play. As of September 2017, HP WorkWise will no longer support iOS or iPhone® devices

NOTE: See important legal disclosures for all listed specs in their respective features sections.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 9

PRODUCT NAME

HP EliteOne 1000 G2 All-in-One Business PC HP EliteOne 1000 G2 23.8-in All-in-One Business PC HP EliteOne 1000 G2 23.8-in Touch All-in-One Business PC HP EliteOne 1000 G2 27-in 4K UHD All-in-One Business PC HP EliteOne 1000 G2 34-in Curved All-in-One Business PC HP EliteOne 1000 G2 Base PC

OPERATING SYSTEMS

Preinstalled

Windows® 10 Pro 641 Windows® 10 Pro 64 (National Academic License)2 Windows® 10 Home 641 Windows® 10 Home Single Language 641 FreeDos 2.0

Web-supported only

Windows® 10 Enterprise 641

1. Not all features are avilable in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.

2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information. NOTE: Your product does not support Windows 8 or Windows 7 In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows® 8 or Windows 7 drivers on http://www.support.hp.com

PROCESSORS

Intel® 8th Generation Core™ Processors

NOTE: Multi-core is designed to improve performance of certain software products. Not all customers or software

applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on

application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a

measurement of higher performance.

GRAPHICS

Integrated Intel® Graphics

Optional Discrete Graphics

AMD Radeon™ RX 560 Graphics with 4GB GDDR5 dedicated memory*

*Optional discrete graphics card can only be configured with 35W CPUs and PCIe NVMe storage drives

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 10

DISPLAY FEATURES

HP EliteOne 1000 23.8-in FHD Display9

23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080)10 Non-Touch Tilt: 5 degrees forward and 25 degrees back Height Adjustment: 40mm

HP EliteOne 1000 23.8-in FHD Touch Display9

23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080)10 Touch; Projected capacitive touch supports up to 10 touch-points Tilt: 5 degrees forward and 25 degrees back Height Adjustment: 40mm

HP EliteOne 1000 27-in 4K UHD Display9

27" diagonal IPS widescreen WLED backlit anti-glare 4K UHD LCD (3840 x 2160)10 Non-Touch Tilt: 5 degrees forward and 25 degrees back

HP EliteOne 1000 34-in WQHD Curved Display9

34" diagonal IPS widescreen WLED backlit anti-glare WQHD LCD (3440 x 1440)

5,10

Non-Touch Tilt: 0 degrees forward and 20 degrees back

9. HD and 4K content required to view HD and 4K images.

10. Resolutions are dependent upon monitor capability, and resolution and color depth settings.

DISPLAY PANEL SPECIFICATIONS

23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080)

Type

IPS WLED Backlit LCD

Active area (mm)

527.04 x 296.46

Native Resolution (HxV)

1920 x 1080

Aspect ratio

16:09

Pixel pitch (HxV)(mm)

0.2745 x 0.2745

Contrast ratio (typical)

1000:01:00

Brightness (typical)

250 nits11

Viewing angle (typical) (HxV)

178° x 178°

Backlight lamp life (to half brightness)

30,000 hours minimum

Color support

Over 16 million colors

Color gamut (typical)

NTSC 72%

Anti-glare

Yes

Default color temperature

Warm (6500K)

11. All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 11

27" diagonal IPS widescreen WLED backlit anti-glare 4K UHD LCD (3840 x 2160)

Type

IPS WLED Backlit LCD

Active area (mm)

596.74 x 335.66

Native Resolution (HxV)

3840 x 2160

Aspect ratio

16:09

Pixel pitch (HxV)(mm)

0.1554 x 0.1554

Contrast ratio (typical)

1000:01:00

Brightness (typical)

350 nits11

Viewing angle (typical) (HxV)

178° x 178°

Backlight lamp life (to half brightness)

30,000 hours minimum

Color support

Over 1 billion colors

Color gamut (typical)

sRGB 99%

Anti-glare

Yes

Default color temperature

Warm (6500K)

11. All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.

34" diagonal IPS widescreen WLED backlit anti-glare WQHD LCD (3440 x 1440)

Type

IPS WLED Backlit LCD

Active area (mm)

799.80 x 334.8

Native Resolution (HxV)

3440 x 1440

Aspect ratio

21:09

Pixel pitch (HxV)(mm)

0.2325 x 0.2325

Contrast ratio (typical)

1000:01:00

Brightness (typical)

300 nits

11

Viewing angle (typical) (HxV)

178° x 178°

Backlight lamp life (to half brightness)

30,000 hours minimum

Color support

Over 1 billion colors

Color gamut (typical)

sRGB 99%

Anti-glare

Yes

Default color temperature

Warm (6500K)

11. All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 12

STORAGE AND DRIVES

12

2.5 inch 7.2k RPM 2.5 inch 7.2k RPM Hard Disk Drives

500GB SATA 1TB SATA

2.5 inch Solid State Hybrid Drives (SSHD)

500GB 5400RPM 2.5in 8GB Hybrid 1TB 5400RPM 2.5in 8GB Hybrid 2TB 5400RPM 2.5in 8GB Hybrid

2.5 inch 5.4k RPM Hard Disk Drives

2TB SATA

2.5 inch Self-encrypting Drives (SED HDD)

500GB 7200RPM 2.5in SED OPAL 2 500GB 5400RPM 2.5in Federal Information Processing Standard (FIPS) SED

2.5 SATA SSD Drives 128GB SATA TLC SSD 256GB SATA TLC SSD 512GB SATA TLC SSD

2.5 inch Self-encrypting Drives (SED SSD)

256GB TLC SED SSD OPAL 2 Drive 512GB TLC SED SSD OPAL 2 Drive 256GB TLC SED SSD 2.5in Federal Information Processing Standard (FIPS) SED 512GB TLC SED SSD 2.5in Federal Information Processing Standard (FIPS) SED

PCIe NMVe SSD Drives

128GB PCIe NVMe TLC SSD 256GB PCIe NVMe TLC SSD 512GB PCIe NVMe TLC SSD 1TB PCIe NVMe TLC SSD 128GB PCIe NVMe SSD 256GB PCIe NVMe SSD 512GB PCIe NVMe SSD

PCIe NMVe Self-encrypting Drives (PCIe NVMe SED SSD)

256GB PCIe NVMe TLC SED SSD OPAL 2 Drive 512GB PCIe NVMe TLC SED SSD OPAL 2 Drive

12. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) is reserved for system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 13

MEMORY

13

Maximum

32GB (16GB/slot)

Memory Slots

2 SODIMM DDR4-2666 (Transfer rates up to 2666 MT/s)

Double channel support

Customer accessible/upgradeable

Configurations

4 GB (1 x 4 GB) 8 GB (2 x 4 GB) 8 GB (1 x 8 GB) 16 GB (2 x 8 GB) 16 GB (1 x 16 GB) 32 GB (2 x 16 GB) Intel® Optane Memory 16GB SSD (cache)

13. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system and requires configuration with an optional Intel® Core™ i(5or 7)+ processor.

NETWORKING

Wireless LAN

Intel® 9560 802.11b/g/n/a/ac 2x2 Wi-Fi +Bluetooth® M.2 Combo Card non-vPro™ Intel® 9560 802.11b/g/n/a/ac 2x2 Wi-Fi +Bluetooth® M.2 Combo Card vPro™

Realtek RTL8822BE ac 2x2 Wi-Fi +Bluetooth® M.2 Combo Card Realtek ac 1x1 +Bluetooth® M.2 Combo Card (2230 PCI-e+USB)

Ethernet (RJ-45) Integrated

Intel® I219LM Gigabit Network Connection LOM (standard)

14. Wireless LAN is optional and must be bought at purchase

15. Wireless access point and Internet service required and not included. Availability of public wireless access points limited.

16. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 14

AUDIO/MULTIMEDIA

Audio

Integrated Conexant CX5001 codec - up to 24-bit PCM High performance integrated stereo speakers (2W) Headset side port (3.5mm) Multi-streaming capable17

Webcam & Mic

Pop-up webcam - 2MP FHD webcam, Up to 30 frames/sec, discrete dual array microphone (Fixed 2MP FHD 1080p)(maximum resolution of 1920 x1080)(optional) Pop-up webcam - 2MP FHD webcam with IR camera front-facing and 2nd rear-facing 2MP webcam, discrete dual array microphone (Dual Camera 480P IR+1080P RGB Fixed/2MP FHD 1080P Fixed)(maximum resolution of 1920 x1080)(optional) IR camera (optional) supports Win10 Hello

Collaboration Keys

Integrated, capacitive touch collaboration keys functions include: Call answer, microphone mute, webcam mute, hang up, speaker mute, and volume slider

Collaboration Keys

Call answer Microphone mute

NOTE: All HP devices which carry the Bang & Olufsen brand are custom-tuned with Bang & Olufsen’s acoustical engineers for precise sound experience in business use.

17.The side headset connector supports CTIA style headsets and is re-taskable as a Line-in, Microphone-in or Headphone-out port. External speakers must be powered externally. Multi-streaming can be enabled in the audio control panel to allow independent audio streams to be sent to/from the side headset jack or internal speakers. This allows for different audio applications to use separate audio ports on the system. For example, the side audio jack could be used with a headset for a communications application while the internal speakers can be used with a multimedia application.

AUDIO SPECIFICATIONS

High Definition Audio

Type

Integrated

HD Audio Codec

Conexant CX5001

Audio I/O Ports

Universal Audio Jack with CTIA headset support (re-taskable for headphone/line out/microphone in/line in)

Wavetable Syntheses

Yes - Uses OS soft wavetable

Analog Audio

Yes

Internal Speaker

Yes - two speakers

DAC Sampling Rates

44.1kHz/48kHz/96kHz/192kHz

ADC Sampling Rates

44.1kHz/48kHz/96kHz

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 15

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

Keyboard and Mouse Combos

HP Premium Wireless Keyboard and Mouse HP Premium USB Wired Keyboard and Mouse HP USB Keyboard and Mouse Healthcare Edition HP Wireless Business Slim Keyboard and Mouse

Keyboards

HP Premium USB Wired Keyboard HP USB Business Slim Keyboard HP USB Business Slim Grey Keyboard HP USB Business Slim CCID SmartCard Keyboard HP USB Business Slim Antimicrobial Keyboard18 HP USB Wired Keyboard HP Wired Keyboard EPEAT®

Mice

HP USB 1000dpi Laser Mouse HP Grey V2 Mouse HP USB Mouse HP USB Antimicrobial Mouse18 HP USB Hardened Mouse HP USB PS/2 Wired Washable Mouse

Other

HP Mouse Pad

Adapters and Cables

DisplayPort™ 1.2 Cable DisplayPort™ 1.2 to DVI-D Adapter DisplayPort™ 1.2 to HDMI 4K Adapter DisplayPort™ 1.2 to VGA Adapter

HP DVI Cable HP USB Type-C™ to Type-A Hub HP USB to Serial Port Adapter HP USB-C™ to USB 3.0 Adapter

Headsets

HP Business Headset v2 HP UC Bluetooth® Headset

18. China Only

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 16

SOFTWARE AND SECURITY

BIOS

HP BIOSphere Gen417 HP DriveLock & Automatic DriveLock BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase18 Absolute Persistence Module19 Pre-boot Authentication HP Wireless Wakeup

Software

HP Native Miracast Support15 HP Velocity HP ePrint Driver + JetAdvantage20 HP Hotkey Support - CMIT HP Recovery Manager HP Jumpstart HP Support Assistant21 HP Noise Cancellation Software HP WorkWise37 HP PhoneWise29 Buy Office (sold separately) Intel Unite (optional)}

Manageability Features

HP Driver Packs22 HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP Manageability Integration Kit Gen223 Ivanti Management Suite24

Client Security Software

HP Client Security Suite Gen425 including: HP Client Security Manager26 (including Credential Manager, Password Manager, Spare Key) Synaptics Fingerprint Sensor31 HP Device Access Manager HP Power On Authentication Microsoft Defender27

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 17

Security Management

Secure Erase18 TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified) (FIPS 140-2 Level 2 Certified)32 SATA 0,1 port disablement (viaBIOS) Serial, USB enable/disable (viaBIOS) Power-on password (viaBIOS) Setup password (viaBIOS) Support for chassis padlocks and cable lock devices Integrated hood sensor HP Sure Start Gen430 HP Sure Run35 HP Sure Recover36 HP Sure Click38

15. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming

17. HP BIOSphere Gen4 features may vary depending on the PC platform and configurations requires 8th Gen Intel® processors.

18. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method.

19. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:

http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided

by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.

20. HP ePrint Driver requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see

http://www.hp.com/go/eprintcenter). Print times and connection speeds may vary.

21. HP Support Assistant requires Windows and Internet access.

22. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.

23. HP Manageability Integration Kit can be downloaded from

http://www8.hp.com/us/en/ads/clientmanagement/overview.html

24. Ivanti Management Suite subscription required.

25. HP Client Security Suite Gen 4 requires Windows and Intel® or AMD 8th generation processors.

26. HP Password Manager requires Internet Explorer or Chrome or FireFox. Some websites and applications may not be supported. User may need to enable or allow the add-on / extension in the internet browser.

27. Microsoft Defender Opt in and internet connection required for updates.

29. HP PhoneWise Client is only available on select platforms. For supported platforms and HP PhoneWise system requirements see www.hp.com/go/HPPhoneWise.

30. HP Sure Start Gen4 is available on HP Elite and HP Pro 600 products equipped with 8th generation Intel® or AMD processors.

31. HP Fingerprint Sensor sold separately or as an optional feature.

32. Firmware TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM 2.0 specification version v0.89 as implemented by Intel Platform Trust Technology (PTT).

35. HP Sure Run is available on HP Elite products equipped with 8th generation Intel® or AMD® processors.

36. HP Sure Recover is available on HP Elite PCs with 8th generation Intel® or AMD processors and requires an open, wired network connection. Not available on platforms with multiple internal storage drives, Intel® Optane™. You must back up important files, data, photos, videos, etc. before use to avoid loss of data.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 18

37. HP WorkWise smartphone app is available as a free download on the Google Play. As of September 2017, HP WorkWise will no longer support iOS or iPhone® devices

38. HP Sure Click is available on select HP platforms and supports Microsoft® Internet Explorer, Google Chrome, and

Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode.

Check http://h20195.www2.hp.com/v2/GetDocument.aspx?docname=4AA7-0922ENW for all compatible platforms as they become available.

POWER

Power Supply

External 180W

Standard efficiency 87%

Power cord length: 6.0 ft. (1.83 m)

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 19

WEIGHTS & DIMENSIONS

Weight

23.8 Non-Touch Product Weight (Unboxed)

Without Arm: 4.71kg, 10.3lb Without Base: 5.19kg, 11.4lb Whole system with Base: 8.21kg, 18.1lb

23.8 Touch Product Weight (Unboxed)

Without Arm: 4.71kg, 10.3lb Without Base: 5.26 kg, 11.6lb Whole system with Base: 8.28kg, 18.25lb

23.8 Shipping Weight (Boxed)

System with package weight: 12.42kg , 27.38 lb

23.8 Shipping Weight (Pallet)

Total Weight including pallet: 247 kg, 544.54 lb

Dimensions (W x D x H)

23.8 System Dimensions (including Touch, NonTouch )

Without Base: 539.5 x 33 x 324.9 mm, 21.2 x 1.3 x 12.8 in Base only: 400 x 190 x 37 mm, 15.7 x 7.5 x 1.5 in With Base: 539.5 x 190 x 419.2 mm, 21.2 x 7.5 x 16.5 in

23.8 Shipping Dimensions (Pallet)

Shipping pallet size : 1153 x 905 x 1728 mm, 45.39 x 35.63 x 68.03 in

23.8 Pallet Quantity (including Touch, NonTouch)

18 units per pallet Weight

27 Product Weight (Unboxed)

Without Arm: 6.78 kg, 14.9 lb Without Base: 7.26 kg, 16.0lb Whole system with Base: 10.2kg, 22.5lb

27 Shipping Weight (Boxed)

System with package weight: 14.62 kg, 32.23lb (maximum config.)

27 Shipping Weight (Pallet)

Total Weight including pallet: 243 kgf, 535.72 lb

Dimension

27 System Dimensions

Without Base: 613.3 x 30.5 x 366.7 mm, 24.15 x 1.19 x 14.44 in Base only: 400 x 190 x 37 mm, 15.7 x 7.5 x 1.5 in With Base: 613.3 x 190 x 457.3 mm, 24.15 x 7.5 x 18 in

27 Shipping Dimensions (Boxed)

Package: 741 x 243 x 572 mm, 29.71 x 9.57 x 22.52 in

27 Shipping Dimensions (Pallet)

Shipping pallet size : 1102 x 984 x 1851 mm, 43.39 x 38.74 x 62.87 in

27 Pallet Quantity

15 units per pallet

Weight

34 Product Weight (Unboxed)

Without Arm: 6.8 kg, 15.0 lb Without Base: 7.28 kg, 16 lb Whole system with Base: 10.3 kg, 22.8 lb

34 Shipping Weight (Boxed)

System with package weight: 17.32 kg , 38.14 lb

34 Shipping Weight (Pallet)

Total Weight including pallet: 228 kg, 502.65 lb

Dimension

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 20

34 System Dimensions

Without Base: 815.8 x 73.8 x 366.7 mm, 32.1 x 2.9 x 14.44 in Base only: 400 x 190 x 37 mm, 15.7 x 7.5 x 1.5 in With Base: 815.8 x 190 x 457.3 mm, 32.1 x 7.5 x 18 in

34 Shipping Dimensions (Boxed)

Package: 985 x 292 x 608 mm, 38.78 x 11.5 x 23.94 in

34 Shipping Dimensions (Pallet)

Shipping pallet size : 1168 x 984 x 1959 mm, 45.98 x 38.74 x 77.13 in

34 Pallet Quantity

12 units per pallet

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 21

ENVIRONMENTAL AND INDUSTRY

UNIT ENVORINMENT AND OPERATIING CONDITIONS

General Unit Operating Guidelines

• Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit

is operated within the specified operating range.

• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.

• Never restrict airflow into the computer by blocking any vents or air intakes.

• Do not stack computers on top of each other or place computers so near each other that they are subject to each other's

re-circulated or preheated air.

• Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign matter can block the vents and limit the airflow.

• If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure, and the same operating guidelines listed above will still apply.

Temperature Range

Operating: 50° to 95° F (10° to 35° C)* Non-operating: -22° to 140° F(-30° to 60° C)

Relative Humidity

Operating: 10% to 90% (non-condensing at ambient) Non-operating: 5% to 95% (non-condensing at ambient)

Maximum Altitude (unpressurized)

Operating: 5000m Non-operating: 50000ft (15240 m)

NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.

PORTS/SLOTS

Rear I/O Connectors

(2) Type A USB 3.1 Gen2 (KB wake capable) (2) Type A USB 3.1 Gen2

(1) DisplayPort™ 1.2 1.2 (out) (1) DisplayPort™ 1.2 1.2 (in)

(1) HDMI 2.0a (out) (1) RJ45 network interface

Side I/O Connectors

(1) Type C USB 3.1 Gen2 with Thunderbolt (DP Alt mode and 15W)

39

(1) Type A USB 3.1 Gen1 (fast charging port) (1) Headset side port (3.5mm)

Slots

(1) M.2 2230 for WLAN (1) M.2 2280 for NVMe SSD storage

Bays

(1) 2.5” HDD

39. Thunderbolt DP Alt mode functionality is shared with the DiplayPort™ out port; DiplayPort™ out is prioritized and automatically selected over Thunderbolt DP Alt mode

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 22

STORAGE AND DRIVES

500GB 7200 RPM SATA Hard Drive

Capacity

500 GB

Rotational Speed

7,200 rpm

Interface

SATA 6 Gb/s

Buffer Size

16 MB

Logical Blocks

976,773,168

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

1TB 7200 RPM SATA Hard Drive

Capacity

1 TB

Rotational Speed

7,200 rpm

Interface

SATA 6 Gb/s

Buffer Size

32 MB

Logical Blocks

1,953,525,168

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

500GB 5400 RPM Solid State Hybrid Drive

Capacity

500 GB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

64 MB

NAND Flash

8GB

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 23

1TB 5400 RPM Solid State Hybrid Drive

Capacity

1 TB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

64 MB

NAND Flash

8 GB

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

2TB 5400 RPM Solid State Hybrid Drive

Capacity

2 TB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

128 MB

NAND Flash

8GB

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 24

2TB 5400 RPM SATA Hard Drive

Capacity

2 TB

Rotational Speed

5,400 rpm

Interface

SATA 6 Gb/s

Buffer Size

128MB

Logical Blocks

3,907,050,336

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

Capacity

2TB

Rotational Speed

5,400 rpm

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

500GB SED Solid State Drive

Capacity

500 GB

Rotational Speed

Self-Encrypting (SED) Solid State Drive with SATA interface

Interface

SATA 6 Gb/s

Buffer Size

32 MB

Logical Blocks

976,773,168

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 25

128GB SATA TLC Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

128 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 530MB/s

Maximum Sequential Write

Up to 450MB/s

Logical Blocks

250,069,680

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM;

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

256GB SATA TLC Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

256GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

500,118,192

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM;

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 26

512GB SATA TLC Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

512 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

1,000,215,216

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM;

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

256GB SATA TLC SED OPAL2 Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

256 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

500,118,192

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM; Self Encrypting Drive with OPAL2.0

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

512GB SATA TLC SED OPAL2 Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

512 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

1,000,215,216

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM; Self Encrypting Drive with OPAL2.0

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 27

256 GB SATA TLC FIPS 140-2 SED Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

256 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

500,118,192

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM; FIPS 140-2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

512GB 2.5" SATA-3 TLC FIPS 140-2 SED Solid State Drive

Drive Weight

up to 50g (0.11lb)

Capacity

512 GB

Height

7mm (0.276in)

Width

70mm (2.756 in)

Interface

SATA 3.0 (6Gb/s)

Maximum Sequential Read

Up to 540MB/s

Maximum Sequential Write

Up to 500MB/s

Logical Blocks

1,000,215,216

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

DIPM; TRIM; FIPS 140-2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 28

256GB M.2 PCIE NVME Solid State Drive

Drive Weight

up to 10g (0.022lb)

Capacity

256GB

Height

2.38mm (0.093in)

Width

22mm (0.87in)

Length

80mm (3.15in)

Interface

PCIE Gen3

Maximum Sequential Read

Up to 1600MB/s

Maximum Sequential Write

Up to 550MB/s

Logical Blocks

500,118,192

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

APST; ASPM L1.2; NVME spec 1.2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

512GB M.2 PCIE NVME Solid State Drive

Drive Weight

up to 10g (0.022lb)

Capacity

512 GB

Height

2.38mm (0.093in)

Width

22mm (0.87in)

Length

80mm (3.15in)

Interface

PCIE Gen3

Maximum Sequential Read

Up to 1800MB/s

Maximum Sequential Write

Up to 550MB/s

Logical Blocks

1,000,215,216

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

APST; ASPM L1.2; NVME spec 1.2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 29

256GB M.2 PCIE NVME TLC Solid State Drive

Drive Weight

up to 10g (0.022lb)

Capacity

256GB

Height

2.38mm (0.093in)

Width

22mm (0.87in)

Length

80mm (3.15in)

Interface

PCIE Gen3 x 4

Performance

Up to 2700MB/s

Maximum Sequential Read

Up to 1100MB/s

Maximum Sequential Write

500,118,192

Logical Blocks

0° to 70°C (32° to 158°F) [ambient temp]

Operating Temperature

APST; ASPM L1.2; NVME spec 1.2

Features

Up to 2700MB/s

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

512GB M.2 PCIE NVME TLC Solid State Drive

Drive Weight

up to 10g (0.022lb)

Capacity

512GB

Height

2.38mm (0.093in)

Width

22mm (0.87in)

Length

80mm (3.15in)

Interface

PCIE Gen3 x 4

Maximum Sequential Read

Up to 2700MB/s

Maximum Sequential Write

Up to 1400MB/s

Logical Blocks

1,000,215,216

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

APST; ASPM L1.2; NVME spec 1.2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 30

1TB M.2 PCIE NVME TLC Solid State Drive

Drive Weight

up to 10g (0.022lb)

Capacity

1 TB

Height

2.38mm (0.093in)

Width

22mm (0.87in)

Length

80mm (3.15in)

Interface

PCIE Gen3 x 4

Maximum Sequential Read

Up to 2700MB/s

Maximum Sequential Write

Up to 1500MB/s

Logical Blocks

2,000,409,264

Operating Temperature

0° to 70°C (32° to 158°F) [ambient temp]

Features

APST; ASPM L1.2; NVME spec 1.2

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 31

GRAPHICS

Intel® UHD Graphics (integrated)

DisplayPort™

Multimode capable; supports HDCP 2.2, Display Port Audio (2 streams), HBR2 link rates and Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)

HDMI

Supports HDMI 2.0a features

Optional

Memory

The actual amount of maximum graphics memory can be >4GB. System memory is allocated for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an optimal balance between graphics and system memory use.

Maximum Color Depth

Up to 10 bits/color

Graphics/Video API Support

HEVC 10b Enc/Dec HW VP9 10b Dec HW HDR Rec. 2020 DX12"

AMD Radeon™ RX 560 Graphics

Architecture

Discrete hybrid graphics configuration

Memory

4GB GDDR5 on a x128 bit bus

Outputs

Since this is a hybrid design, the AMD graphics' output capabilities are the same as listed for Intel Graphics

System Bus Connection

PCIEx8

API support

DirectX 12 OpenCL 2.0 OpenGL 4.5

Display Output chart.

Resolution

Refresh

Rate

VGA

(Using HP DP to

VGA adapter)

DVI-D

(Using HP DP to

DVI-D adapter)

DisplayPort™

HDMI

Standard

640 x 480

60, 75, 85

X X X X VESA DMT, CVT 0.31M3

720 x 400

70 X X X X

IBM VGA

800 x 600

60, 75, 85

X X X X VESA DMT, CVT0.48M3

1024 x 768

60, 75, 85

X X X X VESA DMT, CVT 0.79M3

1152 x 864

60, 75, 85

X X X X VESA DMT, CVT 0.83MA

1280 x 720

60, 75, 85

X X X X VESA DMT, CVT 0.92M9, CEA-

770.3

1280 x 768

60, 60RB, 75, 85

X X X X VESA DMT, CVT 0.98M9/0.98M9R

1280 x 800

60, 75, 85

X X X X VESA DMT

1280 x 960

60, 75, 85

X X X X VESA DMT

1280 x 1024

60, 75, 85

X X X X VESA DMT, CVT 1.31M4

1366 x 768

60, 60RB

X X X X VESA DMT

1440 x 900

60, 60RB

X X X X VESA DMT

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 32

1600 x 900

60, 60RB, 75, 85

X X X X VESA DMT

1680 x 1050

60, 60RB

X X X X VESA DMT, CVT 1.76MA/1.76MAR

1920 x 1080

60 X X X X

VESA DMT, CVT 2.07M9, SMPTE 274M

1920 x 1080

75 X X

CVT-RBv2 (2.07M-R)

1920 x 1080

100

X X CVT-RBv2 (6.14M-R)

1920 x 1080

120

X X SMPTE 274M

1920 x 1080

144

X X SMPTE 274M

1920 x 1200

60, 60RB

X1 X X X DMT, CVT 2.30MA/2.30MA-R

1600 x 1200

60 X X X X

VESA DMT, 1.92M3

1920 x 1440

60, 75, 85

X X VESA DMT, CVT 2.76M3

1920 X 1600

59.95

X X CVT-RBv2 (Not CVT Standard Aspect Ratio)

2048 x 1536

60 X X

CVT 3.15M3

2560 x 1440

59.951

X X CVT 3.69M9-R

2560 x 1600

60, 60RB

X X VESA DMT, CVT 4.10MA/4.10MAR

3440 x 1200

60 X X

CVT-4.61M-R

3440 x 1440

49.987

X X CVT-RB v1

3440 x 1440

59.973

X X CVT-RB v1

3440 x 1440

60 X X

Samsung Custom

3440 x 1440

100

X X CVT-RBv2 (4.95M-R)

3440 x 1440

120

X X CVT-RBv2 (4.95M-R)

3840 x 1600

30 X X

CVT-RBv2 (6.14M-R)

3840 x 1600

59.994

X X CVT-RBv2

3840 x 2160

24 X X

SMPTE 274M

3840 x 2160

25 X X

SMPTE 274M

3840 x 2160

30 X X

SMPTE 274M

3840 x 2160

29.981

X X CVT-RB v1

3840 x 2160

50 X X

SMPTE 274M

3840 x 2160

59.997

X X CVT-RBv1 (8.29M9-R)

3840 x 2160

60 X X

SMPTE 274M

4096 x 2160

24 X X

SMPTE 274M

4096 x 2160

25 X X

SMPTE 274M

4096 x 2160

30 X X

SMPTE 274M

4096 x 2160

50 X X

SMPTE 274M

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 33

4096 x 2160

59.94

X X CVT-RBv2

4096 x 2160

60 X X

CVT-RBv2

1920 x 1080

60 X X X

VESA (SMPTE 274M)

1920 x 1080

50 X X X

SMPTE 274M

1920 x 1080

30 X X X

SMPTE 274M

1920 x 1080

24 X X X

SMPTE 274M

1280 x 720

60 X X X

VESA (CEA-770.3)

1280 x 720

50 X X X

SMPTE 296M

720 x 480

59.94

X X X MHL (CEA-770.2)

720 x 576

50 X X X

ITU-R BT.1358

640 x 480

59.94

X X X CEA (VESA DMT)

NOTE: Other refresh rates and resolutions may also work, but have not been validated. >60Hz refresh rates only for analog (VGA) signaling

1. 60Hz Reduced Blanking only

INPUT/OUTPUT DEVICES

HP Conferencing Keyboard

1.

Function Keys

6.

End/Decline a Call

2.

F11 Lync or Skype for Business Contact list 1

7.

Answer a Call

3.

F12 Lync or Skype for Business Calendar2

8.

Microphone Mute

4.

Share Screen

9.

Volume Up/Down

5.

Stop Webcam

10.

Audio Mute

1. Microsoft Lync 2013, or Skype for Business Contact list

2. Microsoft Lync 2013, or Skype for Business Calendar

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 34

HP USB Premium Keyboard

Physical Characteristics

Keys

104, 105 layout (depending upon country)

Dimensions (L x W x H)

17.04 x 5.55 x 0.52 in (433 x 141 x13.2 mm) Weight

1.54 lb (698g)

Electrical

Operating voltage

5 VDC, +/-5%

Power consumption

35mA (All LED on)

System interface

USB Type A plug connector

ESD

Contact Discharge: 8 KV Air Discharge: 15 KV

EMI - RFI

Conforms to FCC rules for a Class B computing device

Microsoft® PC 99 - 2001

Mechanically compliant

Mechanical

Keycaps

Low-profile design

Switch actuation

60±10g nominal peak force with tactile feedback

Switch life

10 million keystrokes (Life tester)

Switch type

Contamination-resistant switch membrane

Key-leveling mechanisms

For all double-wide and greater-length keys

Cable length

6 ft (1.8 m)

Microsoft PC 99 - 2001

Mechanically compliant

Environmental

Acoustics

43-dBA maximum sound pressure level

Operating temperature

50° to 122° F (10° to 50° C)

Non-operating temperature

-22° to 140° F (-30° to 60° C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

40 g, six surfaces

Non-operating shock

80 g, six surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Drop (out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop (in box)

30 in (76.2 cm) on concrete, 16-drop sequence

Approvals

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

Ergonomic compliance

TUVGS

Kit contents

Keyboard, QSP

Warranty Card

Product Notice

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 35

Skylab USB wired Keyboard

Physical Characteristics

Keys

104, 105, 106, 107, 109 layout (depending upon country)

Dimensions (L x W x H)

171.97 x 68.35 x 8.27 in (436.8± 1.5 x 137.6± 1.0 x 21.0±

1.0 cm)

Weight

1.32 lb (0.6± 0.08 kg)

Electrical

Operating voltage

4.4-5.25VDC

Power consumption

50-mA maximum (with 5 VDC power supplied and three LEDs ON)

System interface

USB

ESD

Contact Discharge: 2, 4,6,8KV Air Discharge: 2, 4, 8,10,12.5KV

EMI - RFI

Conforms to FCC rules for a Class B computing device

Mechanical

Keycaps

Low-profile design

Switch actuation

60±15g nominal peak force with tactile feedback

Switch life

10 million keystrokes (Life tester)

Switch type

Silicon rubber switch membrane

Cable length

6 ft (1.8 m)

Environmental

Acoustics

43-dBA maximum sound pressure level

Temperature

50° to 122° F (10° to 50° C)

Humidity

20% to 80% (non-condensing at ambient)

Vibration

2-g peak acceleration

Drop (out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop (in box)

30 in (76.2 cm) on concrete, 16-drop sequence

Approvals

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

Ergonomic compliance

ANSI HFS 100, ISO 9241-4, and TUVGS

Kit contents

Keyboard, Installation Guide, Warranty card, Safety and Comfort Guide

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 36

HP USB Premium Mouse

Physical characteristics

Dimensions (L x W x H)

4.21 x 2.64 x 1.52 in (107 x 67 x 38.7 mmm) Weight w/o cable

0.19lb (90g)

Environmental

Operating temperature

50° to 122° F (10° to 50° C)

Non-operating temperature

-22° to 140° F (-30° to 60° C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

50 g, 6 surfaces

Non-operating shock

80 g, 6 surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Electrical

Operating voltage

5 VDC, +/-5%

Power consumption (typical)

12mA

Mechanical

Connector

USB 2.0

Type

3D mouse (3 keys and wheel)

Resolution

800, 1200, 1600 DPI

Sensor

Pixart PAN3606DL

Tracking speed

30 inch/sec (max)

Tracking acceleration

8G(max), 1G=9.8m/s2

Cable length

6 ft (1.8 m)

Color

Jack Black

Regulatory Approvals

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

Apollo wired USB MS

Physical characteristics

Dimensions (H x L x W)"

2.5 x 4.5 x 1.5 in (63.5 x 114.3 x 38.1 mm) Weight

0.22 lb (99.79 g)

Color

Black

Connector

USB

Resolution

799 DPI sensitivity

Buttons

Two primary buttons and clickable scroll wheel

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 37

AUDIO

Audio by Bang & Olufsen*

Internal 2watt stereo speaker

3.5mm Combo Jack

High Definition Audio

Type

Integrated

HD Audio Codec

Conexant CX5001

Audio I/O Ports

Universal Audio Jack with CTIA headset support (re-taskable for headphone/line out/microphone in/line in)

Wavetable Syntheses

Yes - Uses OS soft wavetable

Analog Audio

Yes Internal Speaker

Yes - two speakers

DAC Sampling Rates

44.1kHz/48kHz/96kHz/192kHz

ADC Sampling Rates

44.1kHz/48kHz/96kHz

NOTE: All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.

WEBCAM & MICROPHONE

Integrated microphones and FHD (1920X1080) RGB webcam

No support for RealSense

Integrated dual discrete microphone modules

For Windows Hello

NOTE: All HP devices which carry the Bang & Olufsen brand are custom-tuned with Bang & Olufsen’s acoustical engineers for precise sound experience in business use.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 38

POWER SUPPLY

Operating Voltage Range

90 – 264 VAC

Rated Voltage Range

100-240V AC

Rated Line Frequency

50/60 HZ

Operating Line Frequency

47 – 63 Hz

Rated Input Current

180W: 2.5A

Rated Input Current with Energy Efficient* Power Supply

180W: 2.5A 180W active PFC 87/90/87% efficient at 20/50/100% load (115V) 88/91/88% efficient at 20/50/100% load (230V)

DC Output

+19.5V

Current Leakage (NFPA 99:

2102)

Less than 500 microamps of leakage current at 120 Vac with the ground wire disconnected, as required for Non-patient Electrical Appliances and Equipment used in a patient care facility or that contact patients in normal use. Per section 10.3.5.1. Less than 100 microamps of leakage current at 120 Vac with the ground wire intact with normal polarity, as required for Non-patient Electrical Appliances and Equipment used in a patient care facility or that contact patients in normal use. Per section 10.3.5.1.

Power cord length

6.0 ft. (1.83 m)

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 39

NETWORKING

Intel i219LM 10/100/1000 Integrated NIC

Connector

RJ-45

System Interface

PCI (Intel proprietary) + SMBus

Data rates supported

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

IEEE Compliance

IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE (Energy Efficient Ethernet)

Performance

TCP/IP/UDP Checksum Offload (configurable) Protocol Offload (ARP & NS) Large send offload and Giant send offload Receiving Side Scaling Jumbo Frame 9K

Power Consumption

Cable Disconnetion: 25mW 100Mbps Full Run: 450mW 1000bp Full Run: 1000mW WoL Enable(S3/S4/S5): 50mW WoL Disable(S3/S4/S5): 25mW

Power Management

ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption Advanced link down power saving for reducing link down power consumption

Management Interface

Auto MDI/MDIX Crossover cable detection

IT Manageability

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status

Security & Manageability

Intel® vPro™ support with appropriate Intel® chipset components

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 40

Intel® Jefferson Peak 9560 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 5.0 Combo [1] vPro

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

•2.402 – 2.482 GHz

802.11a/n

•4.9 – 4.95 GHz (Japan)

•5.15 – 5.25 GHz

•5.25 – 5.35 GHz

•5.47 – 5.725 GHz

•5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•Cisco Certified Extensions, all versions through CCX4 and CCX Lite

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

• 802.11ac VHT160(5GHz) : +11.5dBm minimum

Power Consumption

•Transmit mode2.0 W

•Receive mode1.6 W

•Idle mode (PSP)180 mW(WLAN Associated)

•Idle mode50 mW(WLAN unassociated)

•Connected Standby 10mW

•Radio disabled8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 41

Receiver Sensitivity

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature Operating

14° to 158° F (–10° to 70° C)

Non-operating

–40° to 176° F (–40° to 80° C

Humidity Operating

10% to 90% (non-condensing)

Non-operating

5% to 95% (non-condensing)

Altitude Operating

0 to 10,000 ft (3,048 m)

Non-operating

0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology Bluetooth Specification

4.0/4.1/4.2/5.0 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH) BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps BLE : 1 Mbps data rate; throughput up to 0.2 Mbps Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Bluetooth Software Supported Link Topology

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 42

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

Security & Manageability

Intel® vPro™ support with appropriate Intel® chipset components

NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices

Intel® Jefferson Peak 9560 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 5.0 Combo [1] non-vPro

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

•2.402 – 2.482 GHz

802.11a/n

•4.9 – 4.95 GHz (Japan)

•5.15 – 5.25 GHz

•5.25 – 5.35 GHz

•5.47 – 5.725 GHz

•5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•Cisco Certified Extensions, all versions through CCX4 and CCX Lite

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 43

Output Power2

• 802.11b : +14dBm minimum

• 802.11g : +12dBm minimum

• 802.11a : +12dBm minimum

• 802.11n HT20(2.4GHz) : +12dBm minimum

• 802.11n HT40(2.4GHz) : +12dBm minimum

• 802.11n HT20(5GHz) : +10dBm minimum

• 802.11n HT40(5GHz) : +10dBm minimum

• 802.11ac VHT80(5GHz) : +10dBm minimum

Power Consumption

•Transmit mode2.0 W

•Receive mode1.6 W

•Idle mode (PSP)180 mW(WLAN Associated)

•Idle mode50 mW(WLAN unassociated)

•Connected Standby 10mW

•Radio disabled8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature Operating

14° to 158° F (–10° to 70° C)

Non-operating

–40° to 176° F (–40° to 80° C

Humidity Operating

10% to 90% (non-condensing)

Non-operating

5% to 95% (non-condensing)

Altitude Operating

0 to 10,000 ft (3,048 m)

Non-operating

0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps BLE : 1 Mbps data rate; throughput up to 0.2 Mbps Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 44

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Bluetooth Software Supported Link Topology

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249 ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices

Realtek 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo [1]

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

•2.402 – 2.482 GHz

802.11a/n

•4.9 – 4.95 GHz (Japan)

•5.15 – 5.25 GHz

•5.25 – 5.35 GHz

•5.47 – 5.725 GHz

•5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 45

Security

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•Cisco Certified Extensions, all versions through CCX4 and CCX Lite

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

• 802.11b : +14dBm minimum

• 802.11g : +12dBm minimum

• 802.11a : +12dBm minimum

• 802.11n HT20(2.4GHz) : +12dBm minimum

• 802.11n HT40(2.4GHz) : +12dBm minimum

• 802.11n HT20(5GHz) : +10dBm minimum

• 802.11n HT40(5GHz) : +10dBm minimum

• 802.11ac VHT80(5GHz) : +10dBm minimum

Power Consumption

•Transmit mode2.0 W

•Receive mode1.6 W

•Idle mode (PSP)180 mW(WLAN Associated)

•Idle mode50 mW(WLAN unassociated)

•Connected Standby 10mW

•Radio disabled8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature Operating

14° to 158° F (–10° to 70° C)

Non-operating

–40° to 176° F (–40° to 80° C

Humidity Operating

10% to 90% (non-condensing)

Non-operating

5% to 95% (non-condensing)

Altitude Operating

0 to 10,000 ft (3,048 m)

Non-operating

0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 46

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy : 0~79 (1 MHz/CH) BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps BLE : 1 Mbps data rate; throughput up to 0.2 Mbps Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported Link Topology

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 47

Realtek 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo 1

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

•2.402 – 2.482 GHz

802.11a/n

•4.9 – 4.95 GHz (Japan)

•5.15 – 5.25 GHz

•5.25 – 5.35 GHz

•5.47 – 5.725 GHz

•5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•Cisco Certified Extensions, all versions through CCX4 and CCX Lite

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

• 802.11b : +14dBm minimum

• 802.11g : +12dBm minimum

• 802.11a : +12dBm minimum

• 802.11n HT20(2.4GHz) : +12dBm minimum

• 802.11n HT40(2.4GHz) : +12dBm minimum

• 802.11n HT20(5GHz) : +10dBm minimum

• 802.11n HT40(5GHz) : +10dBm minimum

• 802.11ac VHT80(5GHz) : +10dBm minimum

Power Consumption

•Transmit mode2.0 W

•Receive mode1.6 W

•Idle mode (PSP)180 mW(WLAN Associated)

•Idle mode50 mW(WLAN unassociated)

•Connected Standby 10mW

•Radio disabled8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 48

Receiver Sensitivity

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna. One embedded dual band 2.4/5 GHz antenna is provided to the card to support WLAN communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature Operating

14° to 158° F (–10° to 70° C)

Non-operating

–40° to 176° F (–40° to 80° C

Humidity Operating

10% to 90% (non-condensing)

Non-operating

5% to 95% (non-condensing)

Altitude Operating

0 to 10,000 ft (3,048 m)

Non-operating

0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH) BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps BLE : 1 Mbps data rate; throughput up to 0.2 Mbps Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported Link Topology

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Features

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 49

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

NOTE: Wireless access point and Internet service is required. Availability of public wireless access point is limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices

QuickSpecs

HP EliteOne 1000 G2 All-in-One Business PC

Options and Accessories (sold separately and availability may vary by country)

Not all configuration components are available in all regions/countries. c05966669 — DA16234 — Worldwide — Version 4 — August 27, 2018

Page 50

HP EliteOne 1000 G2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
