Page 1
HP recommends Windows® 7.
HP EliteBook 8470w Mobile Workstation
HP’s most travel-friendly workstation features ISV-certied, workstation-caliber graphics and
powerful processing with a business rugged design and a 14-inch diagonal display.
Workstation Power. Notebook Mobility.
Develop intense visuals and jaw-dropping animations with workstation-
caliber graphics. The HP EliteBook 8470w is ISV-certied so your mobile
workstation runs smoothly and reliably.
Expand your view to see multiple screens at once or enlarge your
content across ve displays for ne-tuning designs. AMD Eyenity
Technology1 makes it possible. Enjoy sharper, deeper images when
you plug your mobile workstation into your additional, independent
displays through the DisplayPort connector.
Demanding projects require faster data access. Boot up quickly with
the solid state drive (SSD). Replace the integrated optical drive with a
second hard drive for data-hungry applications or RAID backup.
Withstands the rigors of mobile business.
When you invest in a computer this powerful, you want it to last. The
HP EliteBook 8470w meets tough military standards (MIL-STD-810G) for
drop, vibration, dust, temperature and altitude.
With a 14-inch diagonal HD3 display, HP’s most travel-friendly mobile
workstation is easy to carry to project sites and meetings.
2
Rely on a notebook truly built
for business.
Save time by quickly accessing your favorite les with Intel Smart
Response Technology.4 You’ll also gain fast response times for things
like system boot and application startup.
Engage in video conferences,5 web-based trainings6 or streaming videos
with smooth audio quality that’ll surprise you. SRS Premium Sound PRO
also allows you to share crisp, powerful sound directly from your mobile
workstation. Forget the extra speakers during your presentations.
It’s nice to have options. Choose a lightweight conguration or add
extended battery life with multiple battery options. In fact, combining
the HP Ultra Extended Life Notebook Battery7 with the 9-cell primary
battery on a properly congured HP EliteBook 8470w oers the longest
battery life of any 2012 HP mobile workstation.
hp.com/zworkstations
Page 2
EliteBook 8470w Mobile Workstation
Form Factor
HP recommends Windows
®
7.
Operating system
Processor
Chipset
Memory
Internal Storage
Flash Cache
Upgrade Bay
Display
Graphics
Audio/Visual
Wireless Support
14
7,18,19
Preinstalled:
Genuine® Windows 7 Professional 32
Genuine Windows 7 Professional 64
Genuine Windows 7 Home Premium 64
8
8,9
8,9
FreeDOS
Supported:
Genuine Windows 7 Enterprise
Genuine Windows 7 Ultimate
8
8
Genuine Windows XP Professional
SUSE Linux Enterprise Desktop 11 SP2
Red Hat Enterprise Linux 6.x
Certied:
SUSE Linux Enterprise Desktop 11 SP2
Red Hat Enterprise Linux 6.x
10
3rd Generation Intel® Core™ i7
Mobile Intel® QM77 Express (vPro™ support
DDR3 SDRAM, 1600 MHz, two slots supporting dual-channel memory, 2/4/8 GB SODIMMs, up to 16 GB total
320/500/750 GB 7200 rpm SMART SATA II HDD, 500 GB 7200 rpm SED (Self Encrypting Drive) HDD, 128/180 GB SATA 6 GB/s SSD, or 256 GB SATA 6 GB/s
SED SSD, HP 3D DriveGuard
Optional 24 GB mSATA Flash cache module;
12.7 mm SATA optical drive or secondary hard drive: Blu-ray R/RE DVD+/-RW SuperMulti DL Drive,
DVD+/–RW SuperMulti DL Drive,
14.0" diagonal LED-backlit HD
TM
AMD FirePro
M2000 with 1 GB dedicated GDDR5 video memory; AMD Eyenity Technology for advanced multi-monitor support
with Turbo Boost Technology;11 3rd Generation Intel® Core™ i510 with Turbo Boost Technology
12
)
13
15
7,16
Support Intel Smart Response Technology
7,17
7,17
DVD-ROM Drive,7 500 GB 7200 rpm secondary HDD;
3
anti-glare (1366 x 768), 14.0" diagonal LED-backlit HD+3 anti-glare (1600 x 900)
7,14
or weight saver
Blu-ray ROM DVD+/-RW SuperMulti DL Drive,
High Denition Audio (SRS Premium Sound Pro), stereo speakers, stereo headphone/line out, stereo microphone in, optional HD
11
1
3
Webcam,7 integrated
7,17
dual-microphone array
Optional HP hs2350 HSPA+ Mobile Broadband;
Centrino 802.11a/b/g/n 2x2;
19
Broadcom 802.11a/b/g/n 2x2;19 HP Integrated Module with Bluetooth® v4.0; HP Connection Manager
7,18
Optional HP un2430 EV-DO/HSPA Mobile Broadband;
7,18
Intel® Centrino 802.11a/b/g/n 3x3;19 Intel®
Communications
Ports and Connectors
Expansion Slots
Input Devices
Software (Windows OS only)
Security
Dimensions (w x d x h)
Weight
20
Power
Expansion Solutions
7
Warranty
2
Integrated Intel® 82579LM Gigabit Network Connection (vPro™ support
11
); 56K v.92 modem
7
2 USB 3.0 ports, 1 USB 2.0 charging port, eSATA/USB 2.0 combo, VGA, DisplayPort, stereo microphone in, stereo headphone/line out, 1394a, power
connector, RJ-11(optional modem), RJ-45(Ethernet), docking connector, secondary battery connector
1 ExpressCard/54, 1 SD/MMC slot
Full-sized spill-resistant keyboard with bottom case drain, touchpad with scroll and gestures support, point stick, launch buttons (Web browser, WLAN
on/o, mute)
HP Power Assistant,
Business 2010 (select models), Adobe® Flash Player, PDF Complete Corporate Edition, WinZip Basic, HP Performance Advisor, HP GPS and Location
(select models), Microsoft® Oce Starter: reduced-functionality Word and Excel® only, with advertising. No PowerPoint® or Outlook®. Buy Oce 2010
to use the full-featured software.
Standard: Microsoft Security Essentials, HP ProtectTools,
Sensor, Pre-Boot Security, HP SpareKey,
Recognition for HP ProtectTools,
28
Models),
Password Manager for HP ProtectTools, Privacy Manager for HP ProtectTools, security lock slot Optional: Computrace,
20
HP Recovery Manager, HP Support Assistant, Corel WinDVD (select model), Roxio Secure Burn21 (select models), Roxio MyDVD
23
Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs.
15
25
HP Disk Sanitizer,26 Drive Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, Face
27
File Sanitizer for HP ProtectTools,26 Smart Card Reader, Intel® AT (requires a Computrace subscription)(select
Device Access Manager with Just in Time Authentication or One Time Password7 (DigitalPass), Secure Erase, DriveLock, Automatic DriveLock,
Central Management for HP ProtectTools,24 TPM Embedded Security Chip 1.2, HP Fingerprint
7,29
HP Privacy Filter
22
7
13.31 x 9.11 x 1.25 in (at front); 33.8 x 23.1 x 3.2 cm (at front)
Starting at 4.96 lb (2.25 kg) with SSD and weight saver; 5.27 lb (2.39 kg) with SSD and optical drive (weight will vary by conguration)
9-cell (100 WHr) Lithium-Ion battery,30 6-cell (62 WHr) Lithium-Ion battery,30 6-cell (55 WHr) HP Long Life Battery (3-year),30 optional HP ST09
Extended Life Notebook Battery (73 WHr),
31
Charge
7,30
optional HP BB09 Ultra Extended Life Notebook Battery (100 WHr),
7,30
90W HP Smart AC Adapter, HP Fast
HP 90W Docking Station, HP 120W Advanced Docking Station, HP USB Docking Station 2.0, HP Essential USB 2.0 Port Replicator, HP Dual Hinge
Notebook Stand, HP Display & Notebook Stand, HP Adjustable Display Stand, HP Adjustable Dual Display Stand
Limited 3-year, 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on primary battery. Optional
HP Care Pack Services
7
are extended service contracts which go beyond your standard warranties.32
For more details, visit hp.com/go/lookuptool.
Page 3
EliteBook 8470w Mobile Workstation
HP recommends Windows® 7.
1
2
3
6
45
1. Genuine Windows® 7 Professional
2. Optional HD Webcam
3,7
3. 14.0" diagonal HD3 anti-glare display
4. Full-size keyboard
5. Point stick
6. USB 3.0 ports
8
3
Page 4
EliteBook 8470w Mobile Workstation
Screen image courtesy of PTC
1. Requires AMD discrete graphics conguration. HP EliteBook 8470w supports up to ve total displays when using with the HP Advanced docking station. The advanced docking station is sold separately.
2. Testing was not intended to demonstrate tness for DOD contracts requirements or for military use. Test results are not a guarantee of future per formance under these test conditions.
3. HD content required to view HD images.
4. Requires a compatible Intel
®
Smart Response Technology is only available on select 2012 HP systems. Depending on system conguration, results may vary.
Intel
5. Video conferencing is available on congurations with the optional 720p HD webcam.
6. Internet access required.
7. Sold separately or as an optional feature.
8. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Not all features are available in all editions of Windows 7.
See microsoft.com/windows/windows-7/ for details.
9. Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benet from use of this technolog y. 64-bit computing on Intel
architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not operate (including
32-bit operation) without an Intel
performance.
®
Turbo Boost 2.0 technology requires a PC with a processor with Intel Turbo Boost 2.0 capability. Intel Turbo Boost 2.0 performance varies depending on hardware, software and overall system
10. Intel
conguration. See intel.com/technology/turboboost for more information.
11. Some functionality of this technology, such as Intel
“virtual appliances” applications for Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required.
12. Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource requirements.
13. 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors will
not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations.
See intel.com/info/em64t for more information. Quad Core is designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may
require appropriate operating system software for full benet. Not all customers or software applications will necessarily benet from use of this technology. Intel’s numbering is not a measurement
of higher performance.
14. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 15 GB (Windows 7) of system disk is reserved for the system recovery software.
15. Requires Microsoft Windows.
16. Not available with SSD or Self-Encrypting Drive or Wireless WAN Broadband module.
17. Blu-ray contains new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems
is not guaranteed. In order for some Blu-ray titles to play, they may require an HDMI digital connection and your display may require HDCP support. HD DVD disks cannot be played on this drive. Note
that DVD-ROM cannot read or write to 2.6 GB Single Sided/5.2 GB Double Sided – Version 1.0 media. Actual speeds may vary. Don’t copy copyright-protected materials. Double Layer discs can store
more data than single layer discs; discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.
18. Wireless use requires separately purchased service contract. Check with your local vendor for coverage area and availability in your area. Connection and speeds will vary due to location,
environment, network conditions, and other factors.
19. Wireless access point and Internet service required. Availability of public wireless access points limited.
20. Power calculations and cost calculations are estimates. Results will vary based on variables, which include information provided by the user, time PC is in dierent power states (on, standby, hibernate,
o), time PC is on battery or AC, hardware conguration, variable electricity rates and utilities provider. HP advises customers to use information reported by HP Power Assistant for reference only
and to validate impact in their environment. Environmental calculations were based on U.S. EPA eGrid 2007 data found at epa.gov/egrid/. Regional results will vary. Microsoft Windows required.
Requires discrete graphics conguration.
21. Do not copy copyright-protected materials.
22. GPS access requires an unobstructed path to multiple satellites. Performance may be aected if/when used inside of buildings, bridges or heavily congested metropolitan areas. Requires separately
purchased GPS navigation software available from multiple GPS applications. Internet access required.
23. Includes reduced functionality versions of Word and Excel. Purchase of Product Key required to activate full Oce 2010 suite available at participating resellers/retailers and oce.com .
24. In order to deploy and receive updated policies, the client needs to be connected to the network server and requires separately purchased DigitalPersona Pro software. System access may not
prevent users from logging into the system on the rst attempt if policy updates haven’t yet been received and applied. Requires Microsoft Windows.
25. Requires initial user set up.
26. For the use cases outlined in the DOD 5220.22-M Supplement. Does not support Solid State Drives (SSDs). Initial setup required. Web histor y deleted only in Internet Explorer and Firefox browsers
and must be user enabled.
27. Microsof t Windows and webcam required.
®
AT security requires a separately purchased Absolute Computrace service subscription and must be activated and congured. Check with Absolute for availability in your country. Intel and
28. Intel
HP assume no liability for lost or stolen data and/or systems or any other damages resulting therefrom. See absolute.com/en/partners/alliances/intel.
29. The Computrace agent is shipped turned o, and must be activated by customers when they purchase a subscription. Subscriptions can be purchased for terms ranging multiple years. Service is
limited, check with Absolute for availability outside the U.S.
30. Battery life will vary depending on the product model, conguration, loaded applications, features, use, wireless functionality and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See MobileMark07 battery benchmark bapco.com/products/mobilemark2007 for additional details.
31. Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is o. Fast Charge Technology does not apply to the HP Ultra Extended Life or 9-cell batteries. When the
PC is powered on, charge time may increase and will vary based on the workload of the notebook PC.
32. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply.
For details, visit hp.com/go/lookuptool.
®
Core processor, enabled chipset, Intel® Rapid Storage technology software and non-SED HDD + optional mSATA SSD ash cache module and non-WWAN conguration.
®
64 architecture-enabled BIOS. Performance will vary depending on your hardware and sof tware congurations. Intel’s numbering is not a measurement of higher
®
Active management technology and Intel Virtualization technology, requires additional 3rd part y sof tware in order to run. Availability of future
HP recommends Windows® 7.
®
Learn more
hp.com/zworkstations
© 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein.
Bluetooth is a trademark of its proprietor and used by Hewlett-Packard Company under license. Microsoft and Windows are U.S. registered
trademarks of Microsoft Corporation. Intel and Core and are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries. AMD is a trademark of Advanced Micro Devices, Inc. Adobe is a trademark of Adobe Systems Incorporated.
4AA 4-1808EN W, June 2012
