HP Designjet 4520 Printer series
Ideal for color production and unattended printing
(1 Serif PosterDesigner Pro for HP is an
optional feature. Not included, sold separately.
(2 SCP reprocontrol for HP is an optional
feature. Not included, sold separately.
(3 +/-0.1% of the specified vector length
or +/-0.1 mm (whichever greater) at 73° F (23° C), 50-60% relative humidity, on E/A0 printing material in Best or Normal mode with HP Matte Film.
(4 The HP Designjet 4520 Scanner comes
standard on the HP Designjet 4520 HD-MFP. It is an optional (not included, sold separately) accessory on the HP Designjet 4520 and 4520ps printers.
(5 IPsec and IPv6 support requires the
purchase of the HP Jetdirect 630n or HP Jetdirect 635n.
(6 Available on the HP Designjet 4520ps
Printer and HP Designjet 4520 HD-MFP only. Support in English only.
Unattended color production at low cost
• Take advantage of unattended color printing with two long media rolls up to 575 ft (175 meters) and reliable 775-ml black, 400-ml color Original HP ink cartridges.
• Double your print capacity and truly maximize productivity with HP Double Swath technology and 160 GB hard disk.
• Experience greater cost efficiency with free HP support, HP supplies that deliver a better value, and finishing options that save time and money.
Provides great possibilities to grow your business
• Experience more possibilities to increase your personal productivity with the HP Instant Printing Utility 2.0, HP Embedded Web Server, and the optional Serif PosterDesigner Pro for HP
• Turn your HP Designjet into a print workflow management system with optional stacker and SCP reprocontrol for HP
• Produce excellent lines and images with patented HP inks, printheads enabling 0.1% line accuracy Color technologies.
• Expand your business with high performance copy and scan capabilities
• Choose from a broad portfolio of over 35 Original HP media for high-quality results from CAD drawings and renders to presentations and posters.
For High
(4
.
100
Production
environment
prints per hour
D/A1
(1
.
775-ml black,
400-ml color
cartridges
(3
, and HP Professional
160 GB
hard disk
(2
Trusted integration in your IT environment
• Trusted connectivity and security-with built-in Gigabit Ethernet networking, advanced access control and optional HP Jetdirect support for secure IPsec and IPv6 driver offers additional support for Linux users
• Manage your HP Designjet, fleet of devices, and your costs with HP Web Jetadmin and the embedded Web server.
• Experience true peace of mind with a printer and printing supplies you know you can trust—from a company with years of experience and expertise.
.
Optional
PostScript
SCP
reprocontrol
for HP
2
rolls
(5
. A Linux PS
(6
.
Scanning/
Copying
capabilities
HP Designjet 4520 Printer series
1. Ink cartridge of 225 and 400-ml for
CMY, and 400 and 775-ml for K.
2. Accommodates 2 media rolls with
long roll support up to 575 ft (175 m)
3. Front panel with user-friendly
animations.
4. Color consistency and screen-to-print
matching with HP Professional Color technologies.
5. Pairs of staggered printheads in the
carriage mean the HP Designjet 4520 Printer series has double the print capacity of earlier models
6. HP Embedded Web Server for
driverless file submission, queue management, preview, supplies and printer status, and error notification.
7. HP Embedded Jetdirect Gigabit
Ethernet print server (1000Base-T) + 2 FireWire (IEEE-1394a compliant) ports.
8. EIO port for optional Jetdirect
cards.
9. Embedded processor for
simultaneous printing and processing. 160 GB hard disk and 608 MB standard memory—upgradeable to 1120 MB.
10. Equipped with a standard bin
that holds 25 D (A1) prints. An optional stacker is capable of flattening and stacking up to 200 plots.
(7
.
1.
4.
2.
5.
3.
7.
8. 9.
6.
10.
(7 Compared to any HP Designjet 600/700/800/1000 Printer
HP large black ink cartridge HP long media roll
0.2 in (5 mm) margins
HP Designjet 4520 Printer series at a glance
HP Designjet 4520 Printer
• Up to 42 in (1067 mm) wide
• 2400 x1200 dpi maximum resolution
• Two media rolls with long roll support up to 575 ft (175 m)
• Ink supplies of 225 and 400-ml for CMY, 400 and 775-ml for K
• Embedded processor and 608 MB memory upgradeable up to 1120 MB. 160 GB hard disk
• Support for HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4
HP Designjet 4520ps Printer
All the features of the 4520 model, plus:
• Embedded RIP for Adobe PostScript 3, Adobe PDF 1.5
HP Designjet 4520 HD-MFP
All the features of the 4520 model, plus:
• Embedded RIP for Adobe PostScript 3, Adobe PDF 1.5
• HP Designjet 4520 Scanner
Optional accessories
• HP Designjet 4500 Stacker
• HP Designjet 4520 Scanner
• HP Designjet 42 in (1067 mm) Roll Feed Spindle
• HP Designjet 512 MB Memory Upgrade
• HP Designjet High Speed USB 2.0 Card
• HP Jetdirect 630n IPv6 Gigabit Print Server
• HP Jetdirect 635n IPv6/IPsec Print Server
• Serif PosterDesigner Pro for HP
• SCP reprocontrol for HP
Optional service and support
• HP Installation Services with Network Setup (1 unit)
• HP Next Business Day Onsite Hardware Support, 3 years
• HP Same Day 9x5 Onsite Hardware Support, 3 years
• HP Same Day 13x5 Onsite Hardware Support, 3 years
HP Double Swath Technology
(4
2
Ideal for unattended printing of high-quality large-format drawings, graphics, maps, presentations, renders, and
posters
1
.
Full flexibility from the HP Designjet 4520 Printer series
More functionality with the HP Designjet 4520 HD-MFP
With scan speeds of 3 inches per second color and 10 inches per second black-and-white, 2 D (A1)-size prints in less than 1
(8
minute
, and excellent image quality (508 dpi optical resolution and up to 9600 dpi enhanced resolution), the HP Designjet 4520 HD-MFP delivers outstanding copy and scan performance.
The integrated copy system of this Designjet features real-time printer, media, and queue info in the scanner user interface, copy accounting in the printer, and copy job priority capability.
Integration with the printer enables excellent copy quality and performance.
An easy-to-use touchscreen, easy color calibration, and easy print settings for printing sets make scanning and copying exceptionally user-friendly.
It is easy to integrate with a wide variety of industry-leading third-party applications such as scan, raster-to-vector conversion, or document management.
This MFP is fully compatible. Easily print scanned documents directly to almost any HP Designjet printer network capabilities foster productivity with fewer steps. Easily save scanned files in PDF, TIFF, JPEG2000, and DWF file formats.
(9
. Built-in scan-to-
HP Designjet 4500 Stacker (optional)
The HP Designjet 4500 Stacker collects up to 200 D (A1) or E (A0) size plots and automatically flattens them, keeping them organized until you can gather them. Print unattended runs during business hours—and get more done—or overnight.
Free up production staff to work on multiple projects at once. The HP Designjet 4500 Stacker handles large black-and-white or color jobs without intervention. Unattended printing allows users to get more done.
Save time and collect your valuable, high-impact output as it prints with the HP Designjet 4500 Stacker. When you’re ready to gather your output, it will be organized and waiting for you. Neatly and cleanly collects all sizes and weights of printable media supported by the HP Designjet 4520 Printer series Original HP printing materials from new HP Cockle-free Coated Paper available in 100 g/m HP Recycled Bond Paper made of 100% recycled base paper, to versatile HP Everyday Adhesive Matte Polypropylene and HP Durable Banner with DuPont
(8 Mechanical printing time. Line drawing printed in Fast mode on HP Bright White Inkjet Paper (Bond).Speed indicated is maximum printer speed.
(9 Fully compatible with HP Designjet 510, 4020, 4520, 5000, 5500, T610, T1120, Z2100, Z3200, Z6100 series products.
(10 Stacker performance may vary depending on the media used.
2
and 170 g/m2, to new chlorine-free
Tyvek®.
(10
, including over 35
3
HP Designjet 4520 Printer series
Technical specifications
Print speed Print
Print resolution Margins
(top x bottom x left x right)
Technology Ink cartridge colors Ink types Ink drop Line accuracy Line Width
Printer media
Thickness We ight S ize
(4
Scan
Scan speed
Scan/copy resolution
Maximum scan width Maximum scan thickness
Memory
Printer
(4
Scanner
Media Handling
Printers
(4
Scanner
Media Types
Printers
(4
Scanner
Sta cker
Connectivity Interfaces (standard): Printers
Interfaces (standard): Scanner Drivers (included)
Print languages (standard) 452 0
4520ps & 4520 HD-MFP
Dimensions (h x d x w)
Printer
(4
Scanner Sta cker Shipping Printer
Shipping Scanner Shipping Stacker
Weight
Printer Scanner Sta cker Shipping Printer Shipping Scanner Shipping Stacker
What's in the box
HP Designjet 4520/4520ps
HP Designjet 4520 HD-MFP
(11 Color image (100% color coverage) printed in Fast mode on HP Bright White Inkjet Paper (Bond). Speed indicated is maximum printer speed. (12 Multi-copy printing; total printing time. Line drawings printed in Fast mode on HP Bright White Inkjet Paper (Bond). Speed indicated is maximum printer speed. (13 The HP Designjet 4520 Stacker does not support films, including HP Clear Film and HP Matte Film or other media with long drying times.
Environmental ranges Operating temperature
Recommended operating temperature Storage temperature Operating humidity Recommended humidity
Acoustic Sound pressure, active
Sound pressure, standby Sound power, active Sound power, standby
Power consumption Maximum Power requirements Printers
Scanner
Certification Safety
Environmental Electromagnetic
ENERGY STAR
Warranty
HP Care Pack Services
(4
®
(4
(4
qualified models
25 sec/page on D/A1
Up to 2400 x 1200 optimized dpi
0.2 x 0.2 x 0.2 x 0.2 in (5 x 5 x 5 x 5 mm) HP Thermal Inkjet Black, cyan, magenta, yellow Dye-based (cyan, magenta, yellow), pigment-based (black) 5 pl (cyan, magenta, yellow), 15 pl (black)
(3
+/- 0.1%
Minimum line width (HP-GL/2 addressable): 0.0007 in (0.02 mm) Guaranteed minimum line thickness (ISO/IEC 13660:2001(E))*: 0.0027 in (0.07 mm)
Up to 15.7 mil (0.4 mm)
0.11 to 0.72 lb (50 to 328 g/m²) Rolls up to 42 in (1067 mm) wide
Color (200 dpi/400 dpi Turbo): 3 in/sec (76 mm/sec) Black-and-white (200 dpi/400 dpi Turbo): 10 in/sec (254 mm/sec) Enhanced mode: 9600 x 9600 dpi, with variable resolution settings from
50 dpi in increments of 1 dpi
Best mode: 300 x 300 dpi Normal mode: 200 x 200 dpi Draft mode: 150 x 150 dpi
42 in (1067 mm)
0.6 in (15 mm)
608 MB memory (upgradeable to 1120 MB), 160 GB hard disk 1 GB memory, 40 GB hard disk
Two automatic rolls, automatic roll-switching, automatic cutter Straight-through scan paper path for sheet and cardboard originals
Bond and coated paper, technical paper, film, photographic paper, proofing paper, self-adhesive, banner and sign material Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard.
(No plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies)
Paper (plain, inkjet, coated, heavyweight coated, super heavyweight coated, semi-gloss, translucent bond, natural tracing, photo, vellum)
1 Gigabit Ethernet (1000Base-T) port, 2 FireWire (IEEE-1394a compliant) ports, 1 EIO Jetdirect accessory slot
(4
1 Gigabit Ethernet (1000Base-T) port, 1 FireWire (IEEE-1394a compliant) port HP-GL/2, HP-RTL, PostScript support for Citrix XenApp and Citrix XenServer environments
HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4 Adobe PostScript 3, Adobe PDF 1.5, HP-GL/2, HP-RTL,TIFF, JPEG, CALS G4
76 x 31.5 x 53.2 in (1930 x 800 x 1350 mm)
70.8 x 40.2 x 54.3 in (1800 x 1020 x 1380 mm)
50.63 x 61.77 x 44.69 in (1286 x 1569 x 1135 mm)
83.9 x 30.5 x 74.4 in (2130 x 775 x 1890 mm)
75.2 x 26.8 x 24.2 in (1910 x 680 x 615 mm)
55.1 x 31.9 x 23.6 in (1400 x 810 x 23.6 mm)
408 lb (185 kg) 204 lb (92.5 kg) 116 lb (53 kg)
599.1 lb (272.3 kg) 269 lb (122 kg)
143.3 lb (65 kg)
Printer, 42-in printer stand and bin, printheads (x8), printhead cleaners (x8), introductory ink cartridges, roll module, user maintenance kit, quick reference guide, setup poster, Serif PosterDesigner Pro poster, documentation and drivers CD,
power cord
All the features mentioned above, plus HP Designjet 4520 Scanner, scanner stand, touchscreen (panel PC), keyboard, quick reference guide, setup poster, documentation CD, system recovery DVD, customer service guide, FireWire cables (x2), Ethernet cable, power cord
41 to 104° F (5 to 40° C) 59 to 86° F (15 to 30° C)
- 4 to 131° F (-20 to 55° C) 20 to 80% RH 25 to 75% RH
53 dB(A) 38 dB(A)
7.0 B(A)
5.9 B(A)
500 watts, 800 watts
Input voltage (auto ranging): 100 to 127 VAC (+/- 10%), 6 A; 220 to 240 VAC (+/- 10%), 3 A; 50/60 Hz (+/- 3 Hz); 100 to 240 VAC (+/- 10%), 50/60 Hz, 5 A maximum
USA and Canada (CSA certified), EU (LVD and EN60950-1 compliant), Russia (GOST), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE)
EU & China RoHS, WEEE, REACH, EuP Compliance for Class A ITE products: EU (EMC Directive), USA (FCC Rules), Canada (ICES), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI); Certified as Class A product: Korea (MIC), Taiwan (BSMI) see: www.hp.com/go/energystar
One -year limited hardware warranty
UN397E HP 3-Year Next Business Day Onsite H4518E HP Installation Service with Network Setup UN394E HP 3-Year Same Day Onsite Service (9x5) UN390E HP 3-Year Same Day Onsite Service (13x5)
(8
, 1000 ft²/hr (93 m²/hr)
(11
, 100 D/A1 prints per hour
(13
(6
drivers for Windows; HP PCL 3 GUI, PostScript
(4
(12
(6
drivers for Mac OS X 10.4/10.5;
Ordering information
Product
CM767A HP Designjet 4520 42-in Printer CM768A HP Designjet 4520ps 42-in Printer CM769A HP Designjet 4520 HD-MFP
Accessories
Q5676A HP Designjet 42-in Roll Feed Spindle Q5680A HP Designjet High Speed USB 2.0 Card CM973A HP Designjet 512 MB Memory Upgrade Q5677B HP Designjet 4500 Stacker 110V J7997G HP Jetdirect 630n IPv6 Gigabit Print Server J7961G HP Jetdirect 635n IPv6/IPsec Print Server CN088A Serif PosterDesigner Pro for HP CN454A SCP reprocontrol for HP (1 printer) CN455A SCP reprocontrol for HP (2 printers) CM770A HP Designjet 4520 Scanner (comes as standard with HP Designjet 4520 HD-MFP)
Original HP ink cartridges
C5054A HP 90 Black Printhead and Cleaner C5055A HP 90 Cyan Printhead and Cleaner C5056A HP 90 Magenta Printhead and Cleaner C5057A HP 90 Yellow Printhead and Cleaner C5060A HP 90 225-ml Cyan Ink Cartridge C5062A HP 90 225-ml Magenta Ink Cartridge C5064A HP 90 225-ml Yellow Ink Cartridge C5061A HP 90 400-ml Cyan Ink Cartridge C5063A HP 90 400-ml Magenta Ink Cartridge C5065A HP 90 400-ml Yellow Ink Cartridge C5058A HP 90 400-ml Black Ink Cartridge C5059A HP 90 775-ml Black Ink Cartridge C5078A HP 90 Black Printhead/Cleaner & Ink Cartridge, 400-ml, Value Pack C5079A HP 90 Cyan Printhead/Cleaner & Ink Cartridge, 400-ml, Value Pack C5080A HP 90 Magenta Printhead/Cleaner & Ink Cartridge, 400-ml, Value Pack C5081A HP 90 Yellow Printhead/Cleaner & Ink Cartridge, 400-ml, Value Pack C5082A HP 90 Black Ink Cartridges, 400-ml, 3-ink Multipack C5083A HP 90 Cyan Ink Cartridges, 400-ml, 3-ink Multipack C5084A HP 90 Magenta Ink Cartridges, 400-ml, 3-ink Multipack C5085A HP 90 Yellow Ink Cartridges, 400-ml, 3-ink Multipack C5095A HP 90 Black Ink Cartridges, 775-ml, 3-ink Multipack C5096A HP 90 Black Printhead Cleaner
Original HP large-format printing materials
Q1397A HP Universal Bond Paper 80 g/m², 36 in. x 150 ft/914 mm x 45.7 m Q8751A HP Universal Bond Paper 80 g/m², 36 in. x 574 f t/914 mm x 175 m C6810A HP Bright White Inkjet Paper 90 g/m2, 36 in. x 300 ft/914 mm x 91.4 m C6020B HP Coated Paper 90 g/m², 36 in. x 150 ft/914 mm x 45.7 m C6980A HP Coated Paper 90 g/m², 36 in. x 300 ft/914 mm x 91.4 m C6030C HP Heavyweight Coated Paper 131 g/m², 36 in. x 100 ft/914 mm x 30.5 m Q1956A HP Heavyweight Coated Paper 131 g/m², 42 in. x 225 ft/1067 mm x 67.5 m C3868A HP Natural Tracing Paper 90g/m², 36 in. x 150 ft/914 mm x 45.7 m C3875A HP Clear Film 174 g/m², 36 in. x 75 ft/914 mm x 22.9 m 51642B HP Matte Film 160 g/m², 36 in. x 125 ft/914 mm x 38.1 m Q1427A HP Universal High-gloss Photo Paper 190 g/m², 36 in. x 100 ft/914 mm x 30.5 m Q1421A HP Universal Semi-gloss Photo Paper 190 g/m², 36 in. x 100 ft/914 mm x 30.5 m CG886A HP Cockle-free Heavyweight Coated Paper 170 g/m², 24 in. x 100 ft/610 mm x 30.5 m CG887A HP Cockle-free Heavyweight Coated Paper 170 g/m², 36 in. x 100 ft/914 mm x 30.5 m CG888A HP Cockle-free Heavyweight Coated Paper 170 g/m², 42 in. x 100 ft/1067 mm x 30.5 m CG883A HP Cockle-free Coated Paper 100 g/m², 24 in. x 150 ft/610 mm x 45.7 m CG884A HP Cockle-free Coated Paper 100 g/m², 36 in. x 150 ft/914 mm x 45.7 m CG885A HP Cockle-free Coated Paper 100 g/m², 42 in. x 150 ft/1067 mm x 45.7 m CG889A HP Recycled Bond Paper 80 g/m², 24 in. x 150 ft/610 mm x 45.7 m CG890A HP Recycled Bond Paper 80 g/m², 36 in x 150 ft/914 mm x 45.7 m CG891A HP Recycled Bond Paper 80 g/m², 42 in. x 150 ft./1067 mm x 45.7 m CG892A HP Recycled Bond Paper 80 g/m², (A2) 16.5 in. x 150 ft./420 mm x 45.7 m CG824A HP Everyday Adhesive Matte Polypropylene 180 g/m², 36 in. x 75 ft/914 mm x 22.9 m CG825A HP Everyday Adhesive Matte Polypropylene 180 g/m², 42 in. x 75 ft/1067 mm x 22.9 m CG843A HP Everyday Adhesive Matte Polypropylene 180 g/m², 24 in. x 75 ft/610 mm x 22.9 m CG821A HP Durable Banner with DuPont™ Tyvek CG822A HP Durable Banner with DuPont™ Tyvek CG823A HP Durable Banner with DuPont™ Tyvek
More HP large-format printing material sizes and weights available at:
www.hp.com/go/designjet/supplies
HP DESIGNJET 4520 PRINTER
ECO INFORMAT ION
• Save paper and avoid printing mistakes with HP Instant Printing Utility 2.0
• Less ink wasted thanks to effici ent installation and maintenance routine.
Free, convenient cartridge recycling
• Supports 100% recycled media
®
140 g/m², 36 in. x 75 ft/914 mm x 22.9 m
®
140 g/m², 42 in. x 75 ft/1067 mm x 22.9 m
®
140 g/m², 60 in. x 75 ft/1524 mm x 22.9 m
1
2
• ENERGY ST AR® Qualified Product
1. Does not apply to 4520 HD-MFP
2. In countries where the HP’s Planet Partner Program operates
www.hp.com/ecosolutions
Please recycle your printing hardwa re and supplies.
Find out how at our website.
© 2004, 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. PANTONE is the property of Pantone, Inc. Adobe and PostScript 3 are trademarks of Adobe Systems Incorporated. FireWire is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. Windows is a U.S. registered trademark of Microsoft Corporation.
For more information, visit our website at:
www.hp.com/go/designjet4520
4AA2-4845ENUC, March 2009
