Page 1
Item # _____________________________________
Quantity ___________________________________
C.S.I. Section 11400
HS7/HS7N
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
STANDARD FEATURES
KNIFE
■ 13" CleanCut™ Knife
■ Removable Ring Guard Cover
■ Zero Knife Exposure
■ Heavy-Gauge Stainless Steel Knife Cover
■ Top-Mounted Borazon Stone Sharpener
OPERATION
■ 1⁄2 H.P. Knife Drive Motor
■ Timing Belt for Automatic Drive System
■ Variable Four-Speed Automatic Carriage with
Front Mounted Controls
■ Three Stroke Lengths
INTERLOCKS
SLICER
MODELS
❑ HS7 – Automatic Slicer/Burnished Finish
❑ HS7N – Automatic Slicer/Burnished Finish with
Non-Removable Knife Feature
ACCESSORIES
❑ Full Fence
❑ Food Chute
❑ Debris Deector
Specications, Details and Dimensions on Inside and Back.
■ Home-Start Position
■ No-Volt Release
HOUSING AND BASE
■ Burnished Aluminum Base
■ Machine Grooves on Gauge Plate and Knife
Cover
■ Exclusive Tilting, Removable Carriage System
■ Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport
■ Double-Action Indexing Cam
■ Lift Assist Cleaning Leg
■ Ergonomic-Style Handle
■ Rear-Mounted, Removable Meat/Vegetable Grip
Arm
HS7/HS7N SLICER
F40334 – HS7/HS7N Slicer Page 1 of 4
Page 2
HS7/HS7N
SLICER
SOLUTIONS / BENEFITS
PRECISION SLICING
13” CleanCut™ Knife
■ Super alloy edge stays sharp longer
■ Lasts two to three times longer than carbon coated
or stainless steel knives
Top Mounted Borazon Stone Sharpener
■ Single-action sharpens and hones in just 15 seconds
■ Removable and warewasher safe for easy cleaning
and sanitation – can be used wet or dry
■ Lifetime guaranteed Borazon sharpening stones
provide maximum performance with reduced
maintenance costs
Machined Grooves on Gauge Plate and Knife Cover
■ Reduces drag for smoother slicing motion
Double-Action Indexing Cam
■ The rst full revolution of the indexing knob provides
precise control of shaving, chipping and thin slicing
■ The second revolution opens the gauge plate quickly
for thicker slicing
■ Gauge plate holds position for consistent, precision
slicing
EASY TO USE
1
⁄2 H.P. Knife Drive Motor
■ Reserve power runs at 430 rpm for optimum results
Timing Belt Automatic Drive System
■ Extends belt life while producing optimum slicing
results
■ Quieter operating slicer
■ Four carriage speeds including 28, 38, 48 and 58
strokes per minute
Three Stroke Lengths
■ Three stroke lengths ideal for a variety of products
Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport
■ Smooth operation with continuous lubrication of
carriage rod
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
Zero Knife Exposure*
■ Knife edge is covered when sharpener is both
mounted and removed, making cleaning easier
■ Gauge plate remains closed during operation of
sharpener
Home Start Position
■ Carriage must be in ‘home position’ before the slicer
will start
No Volt Release
■ Slicer must be restarted if power fails or slicer is
unplugged
EASY TO CLEAN
Removable Knife Option* – HS7
■ Knife easily removes with patented removal tool
■ Area within ring guard is open for faster cleaning
■ Knife and tool are warewasher safe for easy cleaning
and sanitation
Removable Ring Guard Cover*
■ Catches product debris around the knife for easy
removal during cleaning
■ Reduces time to ‘oss’ during cleaning
Exclusive Tilting, Removable Carriage System*
■ Tilt design allows for ease of mid-day cleaning
■ Removable for complete cleaning and sanitation
Rear-Mounted, Removable Meat Grip Arm
■ Opens up front of product tray for unobstructed
loading
■ Removable meat grip allows for easy cleaning
Lift Assist Cleaning Leg
■ Gas assisted leg helps operator easily lift machine
for cleaning underneath
Sanitary Burnished Aluminum Base
■ Limited cracks/crevices or bolt holes where product
can lodge and bacteria may grow
■ Easy clean up and durable nish
*Feature unique to Hobart
Page 2 of 4 F40334 – HS7/HS7N Slicer
Page 3
HS7/HS7N
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
SPECIFICATIONS
KNIFE
13" CleanCut Knife: The knife is approximately 13 inches,
constructed of 304L stainless steel and high performance
Stellite alloy. Knife cover is retained magnetically, and is
quickly removed by pulling straight back on the top cover
knob.
Removable Knife Option HS7: The patented knife
removal tool covers the knife edge and safely removes
knife from gauge plate to allow for thorough cleaning.
Removable Ring Guard Cover: Fits on top of ring guard
to catch food debris. When removed, reveals a 0.12"
space between knife and guard for easier ossing. Ring
guard is made with Zytel™ plastic and can be washed in
warewasher or three compartment sink.
Zero Knife Exposure: Knife edge is not exposed during
cleaning or sharpening procedures.
Top Mounted Borazon Stone Sharpener: Single action
operation utilizing two Borazon stones to sharpen and
hone in ve seconds. Removable, top mounted and
warewasher safe. When sharpener is removed for cleaning,
knife edge is completely shielded. Borazon stones have a
lifetime guarantee.
MOTOR
Poly V-Belt Knife Drive System: Knife is driven by
a Hobart Poly V belt and runs at 430 rpm for optimal
performance.
Four Stroke Speeds: Stroke speed can be set to 28, 38,
48 and 58 strokes per minute.
1
⁄2 H.P. Knife Drive Motor: 1⁄2 H.P. permanently lubricated
ball bearings. Single phase capacitor-start, induction run.
INTERLOCKS
Home Start Position: Home-start ensures carriage is in a
convenient position before starting the slicer.
No Volt Release: In the event of a power loss, slicer must
be restarted before operation can continue.
SLICER
HOUSING AND BASE
Sanitary Burnished Aluminum Base: One-piece base
has fewer places to harbor soil and is easier to clean.
Limits holes or crevices in which food can lodge.
Finish: Stainless steel top cover, anodized aluminum
product tray and gauge plate.
Exclusive Tilting, Removable Carriage System:
Aluminum product tray tilts easily for mid-day cleaning
and is removable for thorough cleaning and sanitation
procedures. The carriage has 12.5" manual travel.
Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport: Transport slide rod is
E-Nickel electroless plated. Slide rod bearings feature an
oil reservoir/oil wick.
Double-Action Indexing Cam: A solid construction index
knob moves the gauge plate via a barrel cam ensuring
consistent slice thickness across machine and over time.
First revolution of index cam for precision slicing; second
revolution for thicker slicing selection.
Lift Assist Cleaning Leg: Gas assisted leg helps operator
easily lift machine for cleaning underneath.
Ergonomic Style Handle: Specially shaped and
positioned for ease of use during manual operation.
Rear Mounted, Removable Meat Grip Arm: Rear
mounted grip is high strength thermoplastic. Swings out of
way when not in use.
Electrical Specification: 120/60/1; 5.6 Amps.
Switch: Moisture protected push button switch.
Cord & Plug: 6-foot, three-wire power supply cord and
plug. Plug not furnished on export models.
Capacity: The carriage will take food up to 53⁄4" x 103⁄4"
rectangle or 7.5" in diameter.
Gauge Plate: Gauge plate is a heavy aluminum extrusion
with machined grooves for smooth feeding. Adjustable to
cut any thickness of slice up to 1".
Warranty: All parts and service coverage for one year
including knife. Lifetime guarantee on Borazon stones in
the sharpening system.
Shipping Weight: 138 lbs .
F40334 – HS7/HS7N Slicer Page 3 of 4
Page 4
HS7/HS7N
19 1/8"
26 3/8"
SLICER
DETAILS AND DIMENSIONS
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
E1
30 5/16"
ELECTRICAL AND GROUNDING CONNECTIONS MUST
COMPLY WITH THE APPLICABLE PORTIONS OF THE
NATIONAL ELECTRICAL CODE AND/OR OTHER LOCAL
ELECTRICAL CODES.
E1 - ELECTRICAL CONNECTIONS
24 5/8"
27 1/4"
5 1/2"
As continued product improvement is a policy of Hobart, specications are subject to change without notice.
Page 4 of 4 F40334 – HS7/HS7N Slicer
F40334 (REV. 08/17) LITHO IN U.S.A. (H-01)
