HIT HA13159 Datasheet

HA13159

37 W × 4-Channel BTL Power IC

ADE-207-264A (Z)

2nd Edition

Jul. 1999

Description

The HA13159 is four-channel BTL amplifier IC designed for car audio, featuring high output and low
distortion, and applicable to digital audio equipment. It provides 37 W output per channel, with a 13.7 V
power supply and at Max distortion.

Functions

• 4 ch BTL power amplifiers

• Built-in standby circuit

• Built-in muting circuit

• Built-in protection circuit (surge, T.S.D and ASO)

Features

• Low power dissipation

• Soft thermal limiter

• Requires few external parts (C:3, R:1)

• Popping noise minimized

• Low output noise

• Built-in high reliability protectio n circuit

• Pin to pin with HA13153A/HA13154A/HA13155/HA13157/HA13158/HA13158A

HA13159

Block Diagram

11

13

C2

0.1 µ/16 V

14

IN V

STBY

2

IN-1

1

IN-2

IN-3

CC

Buffer & Mute-1

Buffer & Mute-2

Buffer & Mute-3

PV

18

CC

PVCC1

2

Amp-1

Amp-2

Amp-3

4400 µ/16 V

6

C1

3

4

5

7

8

9

15

16

V

CC

13.2 V

R1

7.5 k

Notes: Standby

1.
Power is turned on when a signal of

3.5 V or 0.05 mA is impressed at pin 2.
When pin 2 is open or connected to
GND, standby is turned on (output off).

Muting

2.

Muting is turned off (output on) when
a signal of 3.5 V or 0.2 mA is impressed
at pin 10.
When pin 10 is open or connected to
GND, muting is turned on (output off).

TAB (header of IC) connected to GND.3.

10

23

IN-4

MUTE

C3

5 V

5 V

Amp-4

2

10

Buffer & Mute-4

Protector
(ASO, Surge, TSD)

12 22 TAB

10 µ/10 V

37.5 k

23.5 k

25 k

17

19

20

21

Unit R: Ω

Q1 ON

↓

BIAS ON

Q2 ON

↓

MUTE ON

C: F

Rev.2, Jul. 1999, page 2 of 15

Absolute Maximum Ratings

Item Symbol Rating Unit

Operating supply voltage V
Supply voltage when no signal*
Peak supply voltage*
Output current*
Power dissipation*

2

3

4

1

CC

VCC (DC) 26 V
VCC (PEAK) 50 V
IO (PEAK) 4 A
P

T

Junction temperature Tj 150 °C
Operating temperature Topr –30 to +85 °C
Storage temperature Tstg –55 to +125 °C
Note: 1. Tolerance within 30 seconds.

2. Tolerance in surge pulse waveform.

3. Value per 1 channel.

4. Value when attached on the infinite heat sink plate at Ta = 25 °C.
The derating carve is as shown in the graph below.

100

18 V

83 W

HA13159

83 W

(W)

T

50

28 W

Power dissipation P

0

25

A: When heat sink is infinite (θj-a = 1.5°C/W)
B: When θf (thermal resistance of heat sink) = 3°C/W
(θj-a = 4.5°C/W)

A

B

50

85

100

Ambient temperature Ta (°C)

150

Rev.2, Jul. 1999, page 3 of 15

HA13159

Electrical Characteristics (VCC = 13.2 V, f = 1 kHz, RL = 4 Ω, Rg = 600 Ω, Ta = 25°C)

Item Symbol Min Typ Max Unit Test Conditions

Quiescent current I
Output offset voltage ∆V
Gain G
Gain difference between

Q1

∆G

Q

V

V

channels
Rated output power P

Max output power P

O

OMAX

Total harmonic distortion T.H.D. — 0.03 — % Po = 3 W
Output noise voltage WBN — 0.15 — mVrms Rg = 0 Ω,

Ripple rejection SVR — 55 — dB f = 120 Hz
Channel cross talk C.T. — 70 — dB Vout = 0 dBm
Input impedance Rin — 25 — kΩ
Standby current I
Standby control voltage (high) V
Standby control voltage (low) V
Muting control voltage (high) V
Muting control voltage (low) V

Q2

STH

STL

MH

ML

Muting attenuation ATTM — 70 — dB Vout = 0 dBm

— 220 — mA Vin = 0
–180 0 +180 mV

30.5 32 33.5 dB
–1.0 0 +1.0 dB

—22—W V

= 13.2 V,

CC

THD = 10%, R

—37—W V

= 13.7 V, RL = 4 Ω

CC

BW = 20 to 20 kHz

——10µA

3.5 — V

CC

V

0—1.5V

3.5 — V

CC

V

0—1.5V

= 4 Ω

L

Rev.2, Jul. 1999, page 4 of 15

Pin Explanation

HA13159

Pin
No. Symbol Functions

1 IN1 CH1 INPUT 25 kΩ (Typ) 0 V

11 IN2 CH2 INPUT
13 IN3 CH3 INPUT
23 IN4 CH4 INPUT
2 STBY Standby control 90 kΩ

3 OUT1 (+) CH1 OUTPUT — VCC/2

5OUT1 (–)
7 OUT2 (+) CH2 OUTPUT
9OUT2 (–)
15 OUT3 (+) CH3 OUTPUT
17 OUT3 (–)
19 OUT4 (+) CH4 OUTPUT
21 OUT4 (–)
10 MUTE Muting control 25 kΩ (Typ) —

Input
Impedance

(at Trs. cutoff)

DC
Voltage Equivalence Circuit

—

1

25 k

37.5 k

2

23.5 k

3

10

25 k

22 RIPPLE Bias stability — VCC/2

22

Rev.2, Jul. 1999, page 5 of 15

HA13159

Pin Explanation (cont)

Pin
No. Symbol Functions

6PV

1 Power of

CC

Input
Impedance

DC
Voltage Equivalence Circuit

—VCC—

output stage
18 PVCC2
14 INV

CC

Power of

—VCC—

input stage
4 CH1 GND CH1 power GND — — —
8 CH2 GND CH2 power GND
16 CH3 GND CH3 power GND
20 CH4 GND CH4 power GND
12 IN GND Input signal GND — — —

Rev.2, Jul. 1999, page 6 of 15

HA13159

Point of Application Board Design

1. Notes on Application Board’s Pattern Design

• For increasing stability, the connected line of V

impedance.

• For increasing stability, it is better to place the capacitor between V

• It is better to place the grounding of resistor (Rg), between input line and ground, close to INGND (Pin

12) because if OUTGND is connected to the line between Rg and INGND, THD will become worse due
to current from OUTGND.

and OUTGND is better to be made wider and lower

CC

and GND (0.1 µF) close to IC.

CC

Rg

0.1 µFV

6

1

12

3
4
5

CC

Figure 1 Notes on Application Board’s Pattern Design

2. How to Reduce the Popping Noise by Muting Circuit

At normal operating circuit, Muting circuit operates at high speed under 1 µs.
In case popping noise becomes a problem, it is possible to reduce the popping noise by connecting

capacitor, which determines the switching time constant, between pin 10 and GND. (Following figure

2)
We recommend value of capacitor greater then 1 µF.
Also transitional popping noise can be reduced sharply by muting before V

5 V

0 V

7.5 kΩ

4.7 µF

10

Muting
control

and Standby are ON/OFF.

CC

Figure 2 How to use Muting Circuit

Table 1 Muting ON/OFF Time

C (µµµµF) ON Time OFF Time

nothing under 1 µs under 1 µs

0.47 2 ms 2 ms

4.7 19 ms 19 ms

Rev.2, Jul. 1999, page 7 of 15

HA13159

Characteristic Curves

(mA)

Q

Quiescent current I

400

300

200

100

Quiescent current vs. Supply Voltage

RL = ∞

0

8 101214161820

0

Supply Voltage V

Output Power vs. Supply Voltage

60

RL = 4 Ω, f = 1 kHz, 4ch operation

50

40

30

20

Output Power Po, Pomax (W)

10

0

8 1012141618200

(V)

CC

Pomax (Vin = 4 Vrms)

Po (THD = 10 %)

Rev.2, Jul. 1999, page 8 of 15

Supply Voltage V

CC

(V)

Total Harmonic Distortion vs. Frequency

VCC = 13.2 V, RL = 4 Ω, 80 kHz L.P.F ON

2
1

0.5

0.2

0.1

0.05

Total Harmonic Distortion THD (%)

0.02

0.01
20 50 100 200 500 1k 2k 5k510k 20k

Po = 1.5 W
Po = 8 W

Frequency f (Hz)

HA13159

Total Harmonic Distortion vs. Output Power

10

VCC = 13.2 V, RL = 4 Ω, 80 kHz L.P.F ON

5

2
1

0.5

0.2

0.1

0.05

Total Harmonic Distortion THD (%)

0.02

0.01

0.01

f = 100 Hz
f = 1 kHz
f = 10 kHz

0.02 0.05 0.1 0.2 0.5 1 2 5
Output Power Po (W)

10 20 30

Rev.2, Jul. 1999, page 9 of 15

HA13159

Crosstalk vs. Frequency (1)

70

60

50

(dB)

T

40

30

Crosstalk C

VCC = 13.2 V, Vout = 0 dBm,

20

80 kHz L.P.F, Input Ch1

10

0

20 50 100 200 500 1k 2k 5k8010k 20k

Ch2
Ch3
Ch4

Frequency f (Hz)

Crosstalk vs. Frequency (2)

70

60

50

(dB)

T

40

30

Crosstalk C

VCC = 13.2 V, Vout = 0 dBm,

20

80 kHz L.P.F, Input Ch2

10

0

20 50 100 200 500 1k 2k 5k8010k 20k

Ch1
Ch3
Ch4

Frequency f (Hz)

Rev.2, Jul. 1999, page 10 of 15

Crosstalk vs. Frequency (3)

70

60

50

(dB)

T

40

30

Crosstalk C

VCC = 13.2 V, Vout = 0 dBm,

20

80 kHz L.P.F, Input Ch3

10

0

20 50 100 200 500 1k 2k 5k8010k 20k

Ch1
Ch2
Ch4

Frequency f (Hz)

HA13159

Crosstalk vs. Frequency (4)

70

60

50

(dB)

T

40

30

Crosstalk C

VCC = 13.2 V, Vout = 0 dBm,

20

80 kHz L.P.F, Input Ch4

10

0

20 50 100 200 500 1k 2k 5k8010k 20k

Ch1
Ch2
Ch3

Frequency f (Hz)

Rev.2, Jul. 1999, page 11 of 15

HA13159

Supply Voltage Rejection Ratio vs. Frequency

70

60

50

40

30

VCC = 13.2 V, RL = 4 Ω,
Vripple = 0 dBm, 80 kHz L.P.F ON

20

10

Supply Voltage Rejection Ratio SVR (dB)

0

20 50 100 200 500 1k 2k 5k8010k 20k

Ch1
Ch2
Ch3
Ch4

Frequency f (Hz)

Wide Band Noise vs. Signal Source Resistance

VCC = 13.2 V, RL = 4 Ω,
Vin = 0

2
1

0.5

0.2

0.1

0.05

Wide Band Noise WBN (mV)

0.02

0.01
20 50 100 200 500 1k 2k 5k510k 20k

Mute OFF (Ch1–Ch4)

Mute ON (Ch1–Ch4)

Signal Source Resistance Rg (Ω)

50k

Rev.2, Jul. 1999, page 12 of 15

Power Dissipation vs. Output Power

100

RL = 4 Ω, f = 1 kHz, 1ch operation

50

VCC = 13.2 V

= 14.4 V

V

CC

VCC = 16 V

(W)

T

20

10

5

Power Dissipation P

2

1

0.02 0.05 0.1 0.2 0.5 1 2 5 10 20 30
Output Power Po (W)

HA13159

Power Dissipation vs. Frequency

(W)

T

10

5

Power Dissipation P

VCC = 13.2 V, RL = 4 Ω, Po = 10 W, 1ch operation

0

20 50 100 200 500 1k 2k 5k1510k 20k

Frequency f (Hz)

Rev.2, Jul. 1999, page 13 of 15

HA13159

Package Dimensions

3.80 ± 0.05

17.50 ± 0.13

30.18 ± 0.25

19.81

4.32 ± 0.05

φ

3.80 ± 0.05

2.79

2 – R1.84 ± 0.19

10.70 ± 0.12

4.50 ± 0.12

+ 0.05

1.55

– 0.1

17.78 ± 0.254.14 ± 0.33

Unit: mm

1.12

0.70

+0.09
–0.1

0.25

27.94

231

M

1.27

+ 0.06

0.40

– 0.04

Hitachi Code
JEDEC
EIAJ

(reference value)

Weight

5.08

4.29

SP-23TE
Conforms

—

8.5 g

Rev.2, Jul. 1999, page 14 of 15

HA13159

Disclaimer

1. Hitachi neither warrants nor grants licenses of any rights of Hitachi’s or any third party’s patent,
copyright, trademark, or other intellectual property rights for information contained in this document.
Hitachi bears no responsibility for problems that may arise with third party’s rights, in cluding
intellectual property rights, in connection with u se of the information contained in this document.

2. Products and product specifications may be subject to change without notice. Confirm that you have
received the latest product standards or specifications before final design, purchase or use.

3. Hitachi makes every attempt to ensure that its products are of high quality and reliability. However,
contact Hitachi’s sales office before using the product in an application that demands especially high
quality and reliability or where its failure or malfunction may directly threaten human life or cause risk
of bodily injury, such as aerospace, aeronautics, nuclear power, combustion control, transportation,
traffic, safety equipment or medical equipment for life support.

4. Design your application so that the product is used within the ranges guaranteed by Hitachi particularly
for maximum rating, operating supply voltage range, heat radiation characteristics, installation
conditions and other characteristics. Hitachi bears no responsibility for failure or damage when used
beyond the guaranteed ranges. Even within the guaranteed ranges, consider normally foreseeable
failure rates or failure modes in semiconductor devices and employ systemic measures such as fail­safes, so that the equipment incorporating Hitachi product does not cause bodily injury, fire or other
consequential damage due to operation of the Hitachi product.

5. This product is not designed to be radiation resistant.

6. No one is permitted to reproduce or duplicate, in any form, the whole or part of this document without
written approval from Hitachi.

7. Contact Hitachi’s sales office for any questions regarding this document or Hitachi semiconductor
products.

Sales Offices

Hitachi, Ltd.

Semiconductor & Integrated Circuits.
Nippon Bldg., 2-6-2, Ohte-machi, Chiyoda-ku, Tokyo 100-0004, Japan
Tel: Tokyo [phone] Fax: [phone]

URL NorthAmerica : http://semiconductor.hitachi.com/

For further information write to:

Hitachi Semiconductor
(America) Inc.
179 East Tasman Drive,
San Jose,CA 95134
Tel: <1> [phone]
Fax: <1>[phone]

Europe : http://www.hitachi-eu.com/hel/ecg
Asia : http://sicapac.hitachi-asia.com
Japan : http://www.hitachi.co.jp/Sicd/indx.htm

Hitachi Europe GmbH
Electronic Components Group
Dornacher Straße 3
D-85622 Feldkirchen, Munich
Germany
Tel: <49> (89) 9 9180-0
Fax: <49> (89) 9 29 30 00

Hitachi Europe Ltd.
Electronic Components Group.
Whitebrook Park
Lower Cookham Road
Maidenhead
Berkshire SL6 8YA, United Kingdom
Tel: <44> (1628) 585000
Fax: <44> (1628) 585160

Hitachi Asia Ltd.
Hitachi Tower
16 Collyer Quay #20-00,
Singapore 049318
Tel : <65>-538-6533/538-8577
Fax : <65>-538-6933/538-3877
URL : http://www.hitachi.com.sg

Hitachi Asia Ltd.
(Taipei Branch Office)
4/F, No. 167, Tun Hwa North Road,
Hung-Kuo Building,
Taipei (105), Taiwan
Tel : <886>-(2)-2718-3666
Fax : <886>-(2)-2718-8180
Telex : 23222 HAS-TP
URL : http://www.hitachi.com.tw

Copyright  Hitachi, Ltd., 2000. All rights reserved. Printed in Japan.

Hitachi Asia (Hong Kong) Ltd.
Group III (Electronic Components)
7/F., North Tower,
World Finance Centre,
Harbour City, Canton Road
Tsim Sha Tsui, Kowloon,
Hong Kong
Tel : <852>-(2)-735-9218
Fax : <852>-(2)-730-0281
URL : http://www.hitachi.com.hk

Colophon 2.0

Rev.2, Jul. 1999, page 15 of 15
