ORIGINAL OPERATING INSTRUCTIONS
PS 30 ferrodetector
It is essential that the operating instructions
are read before the tool is operated for the
first time.
Always keep these operating instructions
together with the tool.
Ensure that the operating instructions are
with the tool when it is given to other
persons.
Contents Page
1. General information 11
2. Description 12
3. Technical data 14
4. Safety instructions 14
5. Before use 16
6. Operation 16
7. Care and maintenance 17
8. Troubleshooting 18
9. FCC statement (applicable in US) / ICES
statement (applicable in Canada) 19
10. Disposal 19
11. Manufacturer’s warranty 19
12. EC declaration of conformity 20
1 These numbers refer to the corresponding illustrations. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
tool” always refers to the PS 30 Ferrodetector.
Parts, operating controls and indicators 1
On/off button
@
Display
;
Status LEDs (red / green)
=
Marking opening
%
Battery compartment
&
en
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
11
Symbols
Location of identification data on the tool
The type designation and serial number can be found
on the type identification plate on the tool. Make a
note of this data in your operating instructions and
always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
en
Read the
operating
instructions
before use.
Return waste
material for
recycling.
Serial no.:
2. Description
2.1 Use of the product as directed
The Hilti PS 30 Ferrodetector is designed to detect ferrous metals (steel rebars) and non-ferrous metals
(copper and aluminium).
The tool is not suitable for locating tensioning cables.
The tool and its ancillary equipment may present hazards when used incorrectly by untrained personnel or
when used not as directed.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
Take the influences of the surrounding area into account. Do not use the appliance where there is a risk of fire
or explosion.
Modification of the tool is not permissible.
2.2 Display
The settings and tool status are shown in the display.
2.3 Display illumination
The display illumination switches on automatically in conditions of low ambient light.
2.4 Display
Areas of the display 1 Status area
1
2
2 Detection area
Shows the two areas of the display.
2.5 Status indicator
Status area
1 Ferrous metal object
2 Non-ferrous metal object
3 Audible signal off
4 Battery status
1 2 3 4
Shows which status is active
12
