Hikvision DS-2CD2T25FHWD-I5-12mm, DS-2CD2T25FHWD-I5-2-8MM, DS-2CD2T25FHWD-I5-4MM, DS-2CD2T25FHWD-I5-6MM, DS-2CD2T25FHWD-I5-8MM Specsheet

DS-2CD2T25FHWD-I5/I8
2 MP IR Fixed Bullet Network Camera

Key Features

 Up to 2 megapixel high resolution
 Max. 1920 × 1080 @60fps
 2.8 mm/4mm/6mm/8 mm/12mm fixed lens,

optional

 Powered by Darkfighter
 H.265, H.265+, H.264+, H.264
 120dB Wide Dynamic Range
 3D Digital Noise Reduction

 12 VDC & PoE (802.3af)
 IR range: 50m, 80m, optional
 Support on-board storage, up to 128 GB
 IP67
 BLC/3D DNR/HLC/ROI
 Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR,

Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR

Specification

Camera

Image Sensor

1/2.8" Progressive Scan CMOS

Min. Illumination

Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Focal length

2.8/4/6/8/12 mm

Focus

Fixed

FOV

2.8 mm, horizontal field of view: 108°
4 mm, horizontal field of view: 86.4°
6 mm, horizontal field of view: 52°
8 mm, horizontal field of view: 41°
12 mm, horizontal field of view: 25°

Lens Mount

M12

Iris

F1.6

Day &Night

IR cut filter

DNR

3D DNR

Wide Dynamic Range

120dB

3-Axis Adjustment (bracket)

Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°

Compression Standard

Video Compression

Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 16 Mbps


Max. Resolution

1920 × 1080

Main Stream

50Hz: 50fps (1920 × 1080, 1280 × 960, 1280×720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280×720)

Sub-Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream

50Hz: 25fps (1920 × 1080, 1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 ×720, 640 × 360, 352 × 240)

Image Enhancement

BLC/3D DNR/HLC

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client
software or web browser

ROI (Region of Interest)

Support 1 fixed region for main stream and sub-stream

Day/Night Switch

Day/Night/Auto/Schedule

Network

Network Storage

Support microSD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR

Alarm Trigger

Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login,
HDD full, HDD error

Protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6

Standard

ONVIF (PROFILE S, PROFILE G), ISAPI

General Function

One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark,
IP Address Filter

Firmware Version

V5.5.80

API

ONVIF (PROFILE S, PROFILE G), ISAPI

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users
3 levels: Administrator, Operator and User

Client

iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500

Web Browser

Plug-in required live view:
IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view:
Chrome 45.0+, Firefox 52.0+

Interface

Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

On-board Storage

Built-in microSD/SDHC/SDXC slot, up to 128G

Reset Button

Yes

Smart Feature-set

Behavior Analysis

Line crossing detection, intrusion detection, unattended baggage detection, object removal
detection

Exception Detection

Scene change detection

Face Detection

Yes

General

Operating Conditions

-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, PoE(802.3af 36 to 57 V, class 3)

Power Consumption

-I5: 12 VDC ± 25%, 7 W; PoE, 9 W

-I8: 12 VDC ± 25%, 10 W; PoE, 12.5 W

IR Range

-I5: up to 50 m

-I8: up to 80 m

Material

Metal

Protection Level

IP67

Dimensions

Camera: Φ105 × 299.7 mm (Φ4.13″ × 11.80″)
Package: 386 × 156 × 155 mm (15.2″ × 6.14″ × 6.1″)

Weight

1200 g (2.65 lb.)

Available Models

DS-2CD2T25FHWD-I5(2.8 mm), DS-2CD2T25FHWD-I5(4 mm), DS-2CD2T25FHWD-I5(6 mm), DS-2CD2T25FHWD-I5(8 mm),
DS-2CD2T25FHWD-I5(12 mm)
DS-2CD2T25FHWD-I8(2.8 mm), DS-2CD2T25FHWD-I8(4 mm), DS-2CD2T25FHWD-I8(6 mm), DS-2CD2T25FHWD-I8(8 mm),
DS-2CD2T25FHWD-I8(12 mm)

299.7(11.80″)

268.9(10.59″)

62.58(2.46″)

62.58(2.46″)

Φ

105

(

4

.

13

″

)

93(3.66″)

88.9(3.5″)

Unit: mm

DS-1260ZJ

Junction Box

DS-1275ZJ-S-SUS

Vertical Pole Mount

DS-1276ZJ-SUS

Corner Mount

Dimensions

Accessory

05058020181207
