DS-2CD2H45FWD-IZS
4 MP IR Varifocal Network Turret Camera
BLC/3D DNR/ROI/HLC
IP66, IK10
IR range: up to 30 m
Built-in microSD/SDHC/SDXC card slot, up
to 128 GB
Color: 0.008 lux @(F1.2, AGC ON), 0.011
lux @(F1.4, AGC ON), 0 lux with IR
1/2.5" Progressive Scan CMOS
2688 × 1520@30 fps
2.8 to 12 mm motorized varifocal lens
H.265+, H.265, H.264+, H.264
4 Behavior analyses
120dB WDR
Powered by Darkfighter
Key Features
Specifications
Camera
Image Sensor
1/2.5" Progressive Scan CMOS
Min. Illumination
Color: 0.008 lux @(F1.2, AGC ON), 0.011 lux @(F1.4, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Focal Length
2.8 to 12 mm
Lens Type
Motorized
Aperture
F1.4
Focus
Auto
FOV
Horizontal field of view: 114° to 32°
Vertical field of view: 59° to 18°
Diagonal field of view: 141° to 36.5°
Lens Mount
Φ14
IR
IR Range
Up to 30 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection, object removal detection, unattended baggage
detection
Exception Detection
Scene change detection
Face Detection
Yes
Region of Interest
Support 1 fixed region for main stream and sub-stream
Max. Resolution
2688 × 1520
Main Stream
50Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
60Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
Sub-Stream
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR/HLC
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client
software or web browser
SVC
H.264 and H.265 encoding support
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In
Network
Network Storage
Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour
General Function
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filter
Firmware Version
V5.5.80
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Interface
Audio
1 input (line in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound
Alarm
1 input, 1 output (max. 12 VDC, 30 mA)
Video Output
No
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Reset Button
Yes
Audio
Environment Noise Filtering
Yes
Audio Sampling Rate
8kHz/16kHz/32kHz/44.1kHZ/48kHz
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, terminal block for DC input
PoE (802.3af, class 3)
Power Consumption and
Current
12 VDC, 1 A, max. 11 W
PoE (802.3af, 36V to 57V), 0.4 A to 0.3 A, max. 12.5 W
Protection Level
IP66, IK10
Material
Metal
Dimensions
Φ 135.8 mm × 145.5 mm (Φ 5.4" × 5.7")
Weight
With Package: approx. 1220 g (2.7 lb.)
Camera: approx. 1060 g (2.3 lb.)
Available Model:
DS-2CD2H45FWD-IZS (2.8 to 12 mm)
Φ135.8 mm
(5.4")
145.5 mm
(5.7")
46 mm (1.8")
35 mm (1.4")
83.5 mm
(3.3")
Φ 36 mm (1.4")
Φ 4.5 mm
(0.2")
DS-1473ZJ-135
Wall Mount
DS-1471ZJ-135
Pendant Mount
DS-1281ZJ-DM23
Inclined Ceiling Mount
DS-1475ZJ-SUS
Vertical Pole Mount
DS-1476ZJ-SUS
Corner Mount
DS-1473ZJ-135B
Wall Mount
with Junction Box
DS-1473ZJ-135(Black)
Wall mount
DS-1471ZJ-135(BLack)
Pendant mount
DS-1281ZJ-DM23(Black)
Inclined ceiling mount
DS-1475ZJ-SUS(Black)
Vertical pole mount
Accessories
Dimensions
05058020190429
