DS-2CD2T83G0-I5/I8
8 MP IR Fixed Bullet Network Camera
BLC/3D DNR/ROI/HLC
IP67
Built-in micro SD/SDHC/SDXC card slot,
up to 128 GB
1/2.5" Progressive Scan CMOS
3840 × 2160 @15 fps
2.8/4/6/8 mm fixed lens
Color: 0.01 lux @(F1.2, AGC ON), 0.028
lux @(F2.0, AGC ON), 0 lux with IR
H.265+, H.265, H.264+, H.264
2 Behavior analyses
120dB WDR
Key Features
Specifications
Camera
Image Sensor
1/2.5" Progressive Scan CMOS
Min. Illumination
Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
Lens
Focal Length
2.8/4/6/8 mm
Aperture
F2.0
Focus
Fixed
FOV
2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124°
4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95°
6 mm, horizontal FOV: 50°, vertical FOV: 28°, diagonal FOV: 59°
8 mm, horizontal FOV: 40°, vertical FOV: 25°, diagonal FOV: 53°
Lens Mount
M12
IR
IR Range
I5: up to 50 m
I8: up to 80 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
256 Kbps to 16 Mbps
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection
Face Detection
Yes
Region of Interest
Support 1 fixed region for main stream and sub-stream
Max. Resolution
3840 × 2160
Main Stream
50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR/HLC
Image Settings
Saturation, brightness, contrast, sharpness adjustable by client software or web browser
Target Cropping
No
Day/Night Switch
Day/Night/Auto/Schedule
Network
Network Storage
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour
General Function
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filter
Firmware Version
V5.5.52
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Video Output
No
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
SVC
H.264 and H.265 encoding support
Reset Button
Yes
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5mm coaxial power plug
PoE(802.3af, class 3)
Power Consumption and
Current
I5:
12 VDC, 0.7 A, max. 7.5W
PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 9W
I8:
12 VDC, 0.9 A, max. 11W
PoE: (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.9W
Protection Level
IP67
Material
Metal
Dimensions
Camera: Φ 104.8 × 299.7 mm (Φ 4.1" × 11.8")
Package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1")
Weight
Camera: 1200 g (2.7 lb.)
Available Models:
DS-2CD2T83G0-I5(2.8/4/6/8 mm), DS-2CD2T83G0-I8(2.8/4/6/8 mm)
62.6(2.5″)
62.6(2.5″)
4-
Φ
4.2
162.5(6.4″)
268.9(10.6″)
299.7(11.8″)
Φ104.8(4.1″)
86.5(3.4″)
85.1(3.4″)
Unit: mm
DS-1260ZJ
Junction Box
Accessories
05055220180619
