Goal Zero Sherpa 40 User Guide [ml]
Table of Contents
Get to Know Your Gear 2
What it Charges 3
FAQ 4
Technical Specifications 5
Français 6-9
日本語
10-13
Deutsch 14-17
Español 18-21
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
1
GET TO KNOW YOUR GEAR
Micro-USB cable
For charging
the Sherpa
Battery Indicator
Lights/On Button
Press it to check the
battery level or to
begin charging
1: 25% charge
2: 50% charge
3: 75% charge
4: 100% charge
2.4A USB Output
Included Cables +
Built-in Storage
Lightning®
USB-C
Micro-USB
2 3
WHAT IT CHARGES
Sherpa 40 is designed to give multiple recharges on most
phones and up to one full recharge on most tablets. With
4.8A shared between the two USB ports, you can even
recharge two devices at once.
WHAT IT POWERS
7”
POV Camera
5 Recharges
Phone
3-4 Recharges
Tablet
1-2 Recharges
HOW IT WORKS
Nomad 14 Plus
Solar Panel
(Sold Separately)
8 Hrs
Full Sun
USB Port
8 Hrs
Goal Zero
Sherpa 40
FREQUENTLY ASKED QUESTIONS
What can I charge with Sherpa 40?
Sherpa 40 is designed to give multiple recharges on most
phones and up to one full recharge on most tablets. With 4.8A
shared between the two USB ports, you can even recharge
two devices at once.
How do I charge my gear?
Plug in and turn it on. Simply select the cable that works
with your device, plug in, and push the Battery Indicator to
power up. Sherpa 40 senses when the device is full and will
automatically shut off.
How long will Sherpa 40 take to charge a phone?
It really depends on your device. On average you’re looking at
2 hours or so for a full recharge on a phone.
How long will a charged Sherpa 40 last?
At least 3 months just sitting around. That being said, the
best thing to do to keep any battery healthy is to use it.
Sherpa 40 is meant to go with you everywhere, be that friend
you can always count on to help you out of a situation. If
you plan on storing Sherpa 40 for long periods of time, we
recommend charging it every 3-6 months.
4 5
TECHNICAL SPECIFICATIONS
Sherpa 40
Ports
Center USB Port
(output)
Side USB port
(output)
Micro USB port (input) 5V, up to 2.4A (12W max)
General
Weight 13.4oz (380g)
Dimensions 7.5 x 4.2 x 0.45in (19 x 10.67 x
Operating usage
temp.
Certs
Warranty 12 months
Be sure to activate your warranty at goalzero.com/warranty
5V, up to 2.4A (12W max), regulated
5V, up to 2.4A (12W max), regulated
1.1cm)
32-104 F (0-40 C)
APPRENDRE À CONNAÎTRE VOTRE ÉQUIPEMENT
Câble Micro USB
Pour recharger
le Sherpa
Lumières indicatrices
du niveau de charge de
la batterie /Bouton On
Appuyez sur le
bouton indicateur de
batterie pour vérifier
le niveau de charge ou
commencer à charger
1 : 25% chargé
2 : 50% chargé
3 : 75% chargé
4 : 100% chargé
Sortie USB 2,4A
Câbles inclus +
Stockage intégré
Lightning®
USB-C
Micro USB
6 7
