Page 1
USB Port
1
Page 2
Table of Contents
Get To Know Your Gear 2-4
Frequently Asked Questions 5
Technical Specifications 6-7
1
Page 3
GET TO KNOW YOUR GEAR
Integrated Charging Cable
No more lost cables. Charge the
Torch in 7 hours from any USB port.
Hand Crank
1 Minute Crank =
2 Minutes of Light
WHAT IT POWERS THREE WAYS TO CHARGE
Headlamp
2-5 Recharges
2 3
POV Camera
3 Recharges
2 Recharges
Phone
Laptop
50% Boost
Built-in Solar Panel
Charge up the Torch in 24 Hrs (full sun). Add
additional solar panels for quicker charge time.
70 Lumens
Flood Light
48 Hrs on Low
22 Hrs on High
180 Lumens
Spot Light
15 Hrs on Low
7 Hrs on High
Hand CrankBuilt-in SolarAny USB Port
Page 4
GET TO KNOW YOUR GEAR
Flood Light: 70 Lumens
Push once for high; twice for low.
Runs 48 hours on low, 22 hours on high.
Spot Light: 180 Lumens
Push once for high; twice for low.
Runs 15 hours on low; 7 hours on high.
Red Light
Push once for steady light twice for flashing.
Integrated Hanger
Hang it
LED Battery
Indicator
Will flash when
charging.
Built-in USB Port
Charge phones, boost
tablets, stay connected
4 5
FREQUENTLY ASKED QUESTIONS
Q: Does it matter which direction I turn the
hand crank?
A: Nope, you can turn the hand crank in either
direction for power. Remember, 1 minute of
cranking is about 2 minutes of light.
Q: How do I know if the solar panel is working?
A: You’ll know the solar panel is working when
the blue LED indicator lights turn on and start
blinking. Angle the solar panel toward the sun
for the best charging experience.
PRO TIP: Leave your Torch 250 in a windowsill
so it’s always charged and ready to go.
Page 5
TECHNICAL SPECIFICATIONS
Torch 250 Flashlight and USB Power Hub
Goal Zero Nomad 3.5 10-20 hrs
Goal Zero Nomad 7 7-14 hrs
Built-in Solar 23-46 hrs
USB Source 7 hrs
Run Time
Spot Light (low power) 15 hrs
Spot Light (high power) 7 hrs
Flood Light (low power) 48 hrs
Flood Light (high power) 22 hrs
Battery
Cell Chemistry Li-NMC
Cell Capacity 16.3Wh (3.7V, 4400mAh)
Lifecycles Hundreds of cycles
Shelf-life Charge every 3-6 months
Fuses None
Management System Charging and low-battery
Light
LED (Output) 250 Lumens, 4000K warm
protection built-in
white LEDs
6 7
Spot Light 180 Lumens
Flood Light 70 Lumens
Hand crank
Hand Crank 2.2 W (cranking at120 RPM)
1 Minute of Crank 2 minutes of light
Solar
Rated Power: 0.8W
Cell Type Monocrystalline
Ports
USB Port (Output) 5V, up to 1A (7.5W max),
USB Port (Input) 5V, up to 1A (5W max)
General
Chainable No
Weight 14.4 oz (408 g)
Dimensions 10 x 3.5 x 1.75 in
Operating Usage Temperature 32-104 F (0-40 C)
Certs
Warranty 12 Months
Be sure to activate your warranty at
goalzero.com/warranty
regulated
(25.4 x 8.9 x 4.5 cm)
Page 6
GOAL ZERO HEADQUARTERS
675 West 14600 South
Bluffdale, UT 84065
1-888-794-6250
Designed in the U.S.A.
Made in China
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
8
