Table of Contents
Get To Know Your Gear 2
Control Deck 4
Rock Out 4
Inside 5
Power Up 6
Bigger Sound 7
Troubleshooting 8
Technical Specifications 9-10
Français 12-20
日本語
22-30
Deutsch 32-40
Español 42-50
2 3
GET TO KNOW YOUR GEAR
Adventure Ready
Use the elastic cord to attach the
speaker to your pack or ride.
Big Sound
DarkBass™ chamber allows massive
airflow for deep, precise sound
without the bulk.
Daisy Chain
Chainable with other Rock Outs for a
bigger, louder party. Use the AUX cable
and port to connect speakers.
4 5
CONTROL DECK
Power Back Play /
Pause
Next Decrease
Volume
Increase
Volume
INSIDE
Protect it
Audio device and cable
fit neatly inside the
internal pocket.
Charge It
Recharge directly from
any USB power source
with the included cable.
Chain It
Chain multiple
speakers together
for even more boom.
Audio Controls and Power Button
Press to turn on. Blue light indicates power on.
Red light indicates charging.
*Optimized for use with Apple
®
products.
Audio Input Cord
Plug your audio device
into the built-in AUX
audio input.
6 7
POWER UP
Solar Ready™
Connect RO2 to any Nomad Solar Panel and
charge up from the power of the sun.
USB Juice
Use the built-in charging cable with any USB
port and juice up in 2 hours. You’ll know you’re
charging when turns red.
Cool Feature: Auto-Shut Off
RO2 will save its battery after 20 minutes
of no sound. Your battery is getting low when
begins flashing red.
Chain RO2 with other Rock Out Speakers for
even more sound – perfect for partying. Use
the aux cable and port to connect speakers.
BIGGER SOUND
FREQUENTLY ASKED QUESTIONS
Why does my Android phone make a phone call when I
use the external controls?
Although we really wanted the external controls of
the Rock Out 2 to work with all phones and operating
systems, the vast combinations of Android phones and
software make it difficult to ensure full functionality for all
devices. The Rock Out 2 external controls are optimized
for Windows and iPhone phones currently.
Does it need to be plugged in for power?
Nope. The Rock Out 2 has a built-in battery that will last
up to 20+ hours depending on how loud you crank the
volume. Recharge from any USB power source.
8 9
TECHNICAL SPECIFICATIONS
Charge times:
GOAL ZERO Nomad
®
7 2-4 hrs
USB source 2 hrs
Run time: 20+ hrs
Battery:
Cell chemistry Li-ion
Cell capacity 3Wh (3.7V, 800mAh)
Lifecycles hundreds of cycles
Shelf-life Keep plugged in, or charge
every 3-6 months
Fuses none
Management system Charging and low-battery
protection built-in
Ports:
Audio output cord 3.5mm female audio jack,
(chaining)
Audio input port 3.5mm, male plug, (built in)
USB cord (input) 5V, up to 0.3A (1.5W max)
Rock Out 2
Audio:
Speakers 2x 40mm, 3W drivers
Amplifier Stereo, 3W max, 70dB SNR,
100Hz-20kHz
General:
Chainable yes
Weight 0.75 lbs (340 g)
Dimensions 7 x 3.75 x 2.5 in (17.8 x 9.5
x 6.4 cm)
Operating usage temp. 32-104 F (0-40 C)
Certs
Warranty 6 months
Be sure to ACTIVATE YOUR WARRANTY at goalzero.com/warranty
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
10 11
DÉCOUVREZ VOTRE APPAREIL
Prêt pour l'aventure
Utiliser le cordon élastique pour fixer l'enceinte
à votre sac ou votre vélo.
Gros son
La chambre DarkBass™ permet un afflux d’air
massif pour un son profond et précis sans
encombrement sonore.
Chaînage en série
Chaîner avec d'autres Rock Out pour une fête
encore plus grande et plus bruyante. Utilisez le
câble et le port AUX pour connecter les haut-parleur s.
