Goal Zero Lighthouse 400 User Guide [ml]
1
Table of Contents
Frequently Asked Questions 1
Get To Know Your Gear 2-3
How It Works 4-5
Technical Specifications 6-7
Français 8-15
日本語
Deutsch 24-31
Español 32-39
Take the Lighthouse 400 out of the current demo
mode by quickly turning the hand crank three times,
enough for the blue battery indicator to illuminate.
DEMO MODE
16-23
FREQUENTLY ASKED QUESTIONS
How often do I need to charge the Lighthouse 400?
It is recommended to charge your Lighthouse 400
lantern every 3 months. The blue LED lights indicate
the current battery level.
Does it matter what direction I turn the hand crank?
Nope. You can turn the hand crank in either direction
for power. Remember, 1 minute of crank time equals
about 10 minutes of light on low.
CHARGE FROM
Goal Zero products:
Nomad Solar Panels
Sherpa Power Packs
Goal Zero Yeti Solar Generators
1
GET TO KNOW YOUR GEAR
HANG IT
Put the Lighthouse 400 anywhere
with the built-in hanger.
CHARGE IT
Charge through any USB port, with the
dynamo crank, or with Goal Zero solar panels.
POWER IT
Use the USB port to recharge a
phone or boost a tablet.
LIGHT IT
Multiple brightness and directional lighting
options. Red light for emergencies.
STAND IT
Convenient foldaway legs for easy
transport and hassle-free storage.
2 3
HOW IT WORKS
Dynamo Crank
Recharge by dynamo crank function: flip the
crank handle up from the top of the lantern
and rotate. One minute of cranking will provide
approximately ten minutes of light on low power.
USB Rechargeable Light
Power up the Lighthouse 400 from any USB
port with the built-in cord. Blue LED lights
indicate battery level.
Dualite™ Directional Lighting
Turn the knob right or left for different
directional lighting and brightness options.
Emergency Light
Push the triangle button for red, emergency
alert mode.
Power Your Gear
Recharge smartphones, and boost tablets
through the USB port.
4 5
TECHNICAL SPECIFICATIONS
Charge times:
Nomad 7 7-14 hrs
USB Source 5 hrs
Run time:
One Side Lit (low power) 48 hrs
One Side Lit (high power) 6 hrs
Both Sides Lit (low power) 24 hrs
Both Sides Lit (high power) 2.5 hrs
Battery:
Cell Chemistry Li-ion NMC
Cell Capacity 16.3Wh (3.7V, 4400mAh)
Lifecycles Hundreds of cycles
Shelf-life Charge every 3-6 months
Fuses None
Management System Charging and low-battery
Light:
LED (output) 2x3W warm white LED 400
Color Temperature 3,500 Kelvin
6 7
protection built-in
Lumens
Hand Crank:
Hand Crank 1 W (cranking at 130 RPM)
Ports:
USB Port (output) 5V, up to 1.5A (7.5W max),
USB Port (input) 5V, up to 1A (5W max)
General:
Chainable No
Weight 1.1 lbs (498 g)
Dimensions 4.5 x 5 x 6.5 in
Operating Usage Temp. 32-104 F (0-40 C)
Certs
Warranty 12 months
1 minute of crank =
10 minutes of light on low
regulated
(11.4 x 12.7 x 16.5 cm)
Be sure to register your product at goalzero.com/support
FRANÇAIS FOIRE AUX QUESTIONS
Table des matières
Foire aux questions 9
Découvrez votre appareil 10-11
Comment ça marche 12-13
Spécifications Techniques 14-15
Français 8-15
日本語
16-23
Deutsch 24-31
Español 32-39
À quelle fréquence dois-je recharger le Lighthouse400?
Nous recommandons de recharger la lanterne
Lighthouse400 tous les 3mois. La lumière DEL bleue
indique le niveau de charge actuel de la batterie.
La direction dans laquelle je tourne la manivelle
est-elle importante?
Non. Vous pouvez tourner la manivelle dans n'importe quelle
direction. Rappelez-vous: tourner la manivelle pendant
1minute peut générer environ 10minutes de lumière.
CHARGER DEPUIS
Produits de Goal Zero:
Panneaux solaires Nomad
Fare sortir le Lighthouse400 du mode démo en
tournant rapidement la manivelle trois fois, de façon
à ce que le voyant bleu de batterie s’allume.
8 9
MODE DÉMO
Blocs d’alimentation Sherpa
Générateurs solaires Goal Zero Yeti
DÉCOUVREZ VOTRE APPAREIL
SUSPENDEZ-LA
Placez la lanterne Lighthouse400
n'importe où grâce à son crochet intégré.
RECHARGEZ-LA
Rechargez-la par portUSB avec la
manivelle-dynamo ou les panneaux solaires
de Goal Zero.
ALIMENTEZ-LA
Utilisez le portUSB pour recharger un
téléphone ou une tablette.
ALLUMEZ-LA
Choisissez parmi plusieurs options de luminosité
et d'éclairage directionnel. Lumière rouge pour
les urgences.
POSEZ-LA
Transportez-la et rangez-la facilement
grâce à ses pieds escamotables pratiques.
10 11
