GE 475 User Manual

Part No. 175D1807P294 Pub. No. 49-90027

9–99 JR

500A277P027

Models Type: 333

453 473 475 4500

Owner’s Manual

GE Appliances

Dryers

GE Answer Center ®800.626.2000

Congratulations! You Are Now Part of the GE Family.

Welcome to the GE family. We’re proud of our quality products and we are committed to providing dependable service. You’ll see it in this easy-to-use Owner’s Manual and you’ll hear it in the friendly voices of our customer service department.

Best of all, you’ll experience these values each time you use your dryer. That’s important, because your new dryer will be part of your family for many years. And we hope you will be part of ours for a long time to come.

We thank you for buying GE. We appreciate your purchase, and hope you will continue to rely on us whenever you need quality appliances for your home.

GE & You, A Service Partnership.

Safety Information

. . .3–5

Operating Instructions

Controls . . . . . . . . . . . . . . . . . .6, 7

Features . . . . . . . . . . . . . . . . . . . . .8

Reversing The Door . . . . . . . . . . . .9

Loading and Using The Dryer . . .10

Venting The Dryer . . . . . . . . . . . .11

Troubleshooting Tips

Before You Call For Service

. .12, 13

Customer Service

Warranty . . . . . . . . . . . . . . . . . . .15

Service Telephone

Numbers . . . . . . . . . . . .Back Cover

FOR YOUR RECORDS

Write the model and serial numbers here:

They are on the label on the front of the dryer behind the door.

Inside you will find many helpful hints on how to use and maintain your dryer properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your dryer.

READ THIS MANUAL

PROPER VENTING

For the best drying performance the dryer needs to be properly vented. The dryer will use more energy and run longer if it is not vented to the specifications outlined in the

Venting the Dryer

section in

this manual and the

Exhausting

section in the Installation Instructions.

IF YOU NEED SERVICE

You’ll find many answers to common problems in the

Before You

Call For Service

section. If you review our chart of

Troubleshooting Tips

first, you may not need to call for service at all.

If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back section. Or,

in the U.S.,

you can always call the GE Answer

Center®at 800.626.2000, 24 hours a day, 7 days a week.

In Canada,

call 1-800-361-3400.

IMPORTANT!

Staple sales slip or cancelled check here.

Proof of the original purchase date is needed to obtain service under the warranty.

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips

■Properly ground dryer to conform with all

governing codes and ordinances. Follow details in Installation Instructions.

■Install or store where it will not be exposed to

temperatures below freezing or exposed to the weather.

■Connect to a properly rated, protected and sized

power supply circuit to avoid electrical overload.

■Remove all sharp packing items and dispose of all

shipping materials properly.

Exhaust/Ducting:

Gas dryers

MUST

be exhausted to the outside.

Exhausting electric dryers to the outside is

strongly recommended

to prevent large amounts of moisture and lint from being blown into the room.

Use only rigid metal or flexible metal 4″

diameter ductwork inside the dryer cabinet or for exhausting to the outside.

USE OF PLASTIC OR OTHER COMBUSTIBLE DUCTWORK CAN CAUSE A FIRE. PUNCTURED DUCTWORK CAN CAUSE A FIRE IF IT COLLAPSES OR BECOMES OTHERWISE RESTRICTED IN USE OR DURING INSTALLATION.

For complete details, follow the Installation Instructions.

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death.

WHAT TO DO IF YOU SMELL GAS:

Do not try to light a match, or cigarette, or

turn on any gas or electrical appliance.

Do not touch any electrical switch; do not

use any phone in your building.

Clear the room, building or area of all

occupants.

Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s instructions carefully.

If you cannot reach your gas supplier, call

the fire department.

California Safe Drinking Water and Toxic Enforcement Act

This act requires the governor of California to publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm and requires businesses to warn customers of potential exposure to such substances.

Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or LP fuels.

Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be minimized further by properly venting the dryer to the outdoors.

PROPER INSTALLATION

This dryer must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet, you can receive one by calling, toll-free, in the United States the

GE Answer Center®, 800.626.2000. In Canada, call, 1-800-361-3400.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions

■

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

■

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

YOUR LAUNDRY AREA

■ Keep the area underneath and around your

appliances free of combustible materials, (lint, paper, rags, etc.), gasoline, chemicals and other flammable vapors and liquids.

■ Keep the floor around your appliances clean and

dry to reduce the possibility of slipping.

■ Close supervision is necessary if this appliance is

used by or near children. Do not allow children to play on, with, or inside this or any other appliance

■ Keep all laundry aids (such as detergents,

bleaches, etc.) out of the reach of children, preferably in a locked cabinet. Observe all warnings on container labels to avoid injury.

■ Never climb on or stand on the dryer top.

WHEN USING YOUR DRYER

■ Never reach into the dryer while the drum is

moving. Before loading, unloading or adding clothes, wait until the drum has completely stopped.

■ Clean the lint filter before each load to prevent

lint accumulation inside the dryer or in the room.

DO NOT OPERATE THE DRYER WITHOUT THE LINT FILTER IN PLACE.

■ Do not wash or dry articles that have been

cleaned in, washed in, soaked in, or spotted with combustible or explosive substances (such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) which may ignite or explode. Do not add these substances to the wash water. Do not use or place these substances around your washer or dryer during operation.

■ Do not place items exposed to cooking oils in

your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a clothes load to catch fire

■ Any article on which you have used a cleaning

solvent or that contains flammable materials (such as cleaning cloths, mops, towels used in beauty salons, restaurants, or barber shops, etc.) must not be placed in or near the dryer until solvents or flammable materials have been removed. There are many highly flammable items used in homes such as acetone, denatured alcohol, gasoline, kerosene, some household cleaners, some spot removers, turpentines, waxes, wax removers and products containing petroleum distillates.

■ The laundry process can reduce the flame

retardancy of fabrics. To avoid such a result, carefully follow the garment manufacturer’s care instructions.

■ Do not dry articles containing rubber, plastic,

or similar materials such as padded bras, tennis shoes, galoshes, bath mats, rugs, bibs, baby pants, plastic bags, pillows, etc. that may melt or burn. Some rubber materials, when heated, can under certain circumstances produce fire by spontaneous combustion.

■ Do not store plastic, paper or clothing that may

burn or melt on top of the dryer during operation.

■ Garments labeled

Dry Away from Heat orDo

Not Tumble Dry

(such as life jackets containing

Kapok) must not be put in your dryer.

■ Do not dry fiberglass articles in your dryer.

Skin irritation could result from the remaining particles that may be picked up by clothing during subsequent dryer uses.

■ To minimize the possibility of electric shock,

unplug this appliance from the power supply or disconnect the dryer at the household distribution panel by removing the fuse or switching off the circuit breaker before attempting any maintenance or cleaning (except the removal and cleaning of the lint filter).

NOTE:

Turning the Cycle Selector knob

to an

OFF

position does

NOT

disconnect the

appliance from the power supply.

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips

WHEN NOT USING YOUR DRYER

■ Grasp the plug firmly when disconnecting this

appliance to avoid damage to the cord while pulling. Place the cord away from traffic areas so it will not be stepped on, tripped over or subjected to damage.

■

Do not attempt to repair or replace any part of this appliance or attempt any servicing unless specifically recommended in this Owner’s Manual or in published user-repair instructions that you understand and have the skills to carry out.

■ Before discarding a dryer, or removing it from

service, remove the dryer door to prevent children from hiding inside.

■ Do not tamper with controls.

■ Never attempt to operate this appliance if it is

damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.

■ The interior of the machine and the exhaust duct

connection inside the dryer should be cleaned at least once a year by a qualified technician. See the

Loading and Using the Dryer

section.

■ If yours is a gas dryer, it is equipped with an

automatic electric ignition and does not have a pilot light.

DO NOT ATTEMPT TO LIGHT WITH A

MATCH.

Burns may result from having your hand in the vicinity of the burner when the automatic ignition turns on.

■ You may wish to soften your laundered fabrics

or reduce the static electricity in them, by using a dryer-applied fabric softener or an anti-static conditioner. We recommend you use either a fabric softener in the wash cycle, according to the manufacturer’s instructions for those products, or try a dryer-added product for which the manufacturer gives written assurance on the package that their product can be safely used in your dryer. Service or performance problems caused by use of these products are the responsibility of the manufacturers of those products and are not covered under the warranty to this appliance.

Read and follow this Safety Information carefully.

SAVE THESE INSTRUCTIONS

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
