Power - red (+), black (-)

Alimentation - rouge (+), noir (-)

Accensione - rosso (+), nero (-)

Video

Stromversorgung: Rot (+), Schwarz (-)

Alimentación: rojo (+), negro (-)

Strøm - rød (+), sort (-)

Av/på – rød (+), svart (–)

Ström – röd (+), svart (-)

Mounting screws (included)
Vis de montage (fournies)
Viti di montaggio (in dotazione)
Befestigungsschrauben (inbegriffen)

Tornillos de montaje (incluidos)

Monteringsskruer (medfølger)
Monteringsskruer (følger med)
Monteringsskruvar (inkluderade)

Loosen the set screw to rotate the camera.

Desserrez la vis de réglage pour faire pivoter la caméra.

Svitare il set di viti per ruotare la fotocamera.

Lockern Sie die Feststellschraube, um die Kamera zu drehen.

Aoje el tornillo de presión para girar la cámara.

Løsn sætskruen for at rotere kameraet.

Løsne justeringsskruen for å rotere kameraet.

Lossa på den inställda skruven för att rotera kameran.

Garmin GC 10 Marine Camera Instructions 1

GC™ 10 Marine Camera

Specications

Image Sensor Device: ⅓ in. (8.5 mm)

Sony Super HAD CCD camera

Effective Pixels: 768 × 494 (NTSC),

WARNING: Do not attempt to operate

or watch video input while operating
or navigating your boat. Operating or
watching the video input while the boat
is moving could cause an accident or
collision resulting in property damage,
serious injury, or death.

752 × 582 (PAL)

Scanning System: 2:1 Interlaced, 525 lines

(NTSC), 625 lines (PAL)

Sync System: Internal
Resolution: 480 TV lines
Video Output: VBS, 1.0 V peak-to-peak,

composite, 75 ohms

S/N Ratio: More than 48 dB (AGC off)
Operating Temperature: From -4°F to

140°F (from -20°C to 60°C)

Power Consumption: 80 mA at 12 Vdc

(with LED on, 120 mA, maximum)

Weight: 11.3 oz. (320 g)
Dimensions: Diameter, 2⅜ in.; Height, 2¼

in. (Diameter, 60 mm; Height, 57 mm)

Compass Safe Distance: 6⅛ in. (155 mm)
Waterproof rating: IP66
Input Voltage: 12 Vdc, ± 2V, regulated

power supply
