See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Not all features are available on all models.
Device Overview
À
Á
Â
Ã
Ä
Power key
Knob
Device keys
Arrow keys
Shortcut keys
• Turn the knob to highlight options.
• Turn the knob to zoom in or out of a screen.
• Hold a numbered key to create a shortcut to a screen.
Getting More Information
If you have any questions about your device, you can contact
®
Garmin
The website,
troubleshooting tips to help resolve most issues and answer
most questions.
• Frequently-asked questions (FAQs)
• Software updates
• Owner's and installation manuals
• Service alerts
• Video
• Contact numbers and addresses
Product Support.
www.garmin.com/support, offers many different
Inserting Memory Cards
You can use optional memory cards in the chartplotter. Map
cards allow you to view high-resolution satellite imagery and
aerial reference photos of ports, harbors, marinas, and other
points of interest. You can use blank memory cards to record
sonar data and transfer data such as waypoints, routes, and
tracks to another compatible Garmin
Open the access flap or door on the front of the chartplotter.
1
Insert the memory card.
2
Press the card in until it clicks.
3
chartplotter or a computer.
Keys
HOMESelect to return to the home screen.
Hold to turn on and off the device.
Press to adjust the backlight.
Tap to open autopilot standby.
Turn/Select
Knob
FOCUSPress to move a highlight to a different section of a
SELECTSelect to acknowledge messages and select options.
MARK/SOSSelect to save the present location as a waypoint.
Shortcut keys Hold to create shortcuts to selected functions.
NAV INFOSelect to display navigation information such as points
BACKSelect to return to the previous screen.
MENUSelect to open or close a menu of options for a page.
Turn to zoom in or out of a view.
Turn to highlight options in menus.
Press to select a highlighted option.
page.
Press to move a highlight to a different function or
window on a combination page.
Press to highlight options in menus.
Select to pan on a chart or sonar screen.
Hold for one second to mark an SOS location when
connected to a VHF radio, and begin a route back to
the location.
Select to open a shortcut to a selected function.
of interest, user data, and tides and celestial
information.
Tips and Shortcuts
• Hold to turn the chartplotter on.
• Select HOME from any screen to return to the Home screen.
• Select MENU from any main screen to access additional
settings about that screen.
• Select MENU to close the menu when finished.
• Select to adjust the backlight.
• Select and select Power Off to turn the chartplotter off.
Close the door.
4
Software Update
You may need to update the device software when you install
the device or add an accessory to the device.
Loading the New Software on a Memory Card
Insert a memory card into the card slot on the computer.
1
www.garmin.com/support/software/marine.html.
Go to
2
Select Download next to GPSMAP Series with SD Card.
3
Read and agree to the terms.
4
Select Download.
5
Select Run.
6
Select the drive associated with the memory card, and select
7
Next > Finish.
Updating the Device Software
Before you can update the software, you must obtain a
software-update memory card or load the latest software onto a
memory card.
Turn on the chartplotter.
1
After the home screen appears, insert the memory card into
2
the card slot.
Introduction1
NOTE: In order for the software update instructions to
appear, the device must be fully booted before the card is
inserted.
Follow the on-screen instructions.
3
Wait several minutes while the software update process
4
completes.
When prompted, leave the memory card in place and restart
5
the chartplotter manually.
Remove the memory card.
6
NOTE: If the memory card is removed before the device
restarts fully, the software update is not complete.
GPS Satellite Signals
When you turn on the chartplotter, the GPS receiver must collect
satellite data and establish the current location. When the
chartplotter acquires satellite signals, appears at the top of
the Home screen. When the chartplotter loses satellite signals,
disappears and a flashing question mark appears over on
the chart.
For more information about GPS, go to www.garmin.com
/aboutGPS.
Selecting the GPS Source
You can select your preferred source for GPS data, if you have
more than one GPS source.
Select Settings > System > GPS > Source.
1
Select the source for GPS data.
2
Customizing the Chartplotter
Home Screen
The chartplotter home screen provides access to all of the
features in the chartplotter. The features are dependant on the
accessories you have connected to the chartplotter. You may
not have all of the options and features discussed in this
manual.
The categories along the right of the screen provide quick
access to the main features of your chartplotter. For example,
the Sonar category displays the views and pages related to the
sonar feature. You can save items you commonly access to the
Favorites category.
All of the options along the bottom of the home screen are
visible on all other screens, except for the Settings button. The
Settings button is accessible only from the home screen.
When viewing another screen, you can return to the home
screen by selecting HOME.
When multiple displays are installed on the Garmin Marine
Network, you can group them together into a station. A station
enables the displays to work together, instead of as several
separate displays. When you select HOME on one display, each
display in the station returns to the home screen. You can
customize the layout of the pages on each display, making each
page different on each display. When you change the layout of a
page in one display, the changes appear on only that display.
When you change the name and symbol of the layout, those
changes appear on all displays in the station, to maintain a
consistent appearance.
The SmartMode™ items are geared toward an activity, such as
cruising or docking. When a SmartMode button is selected from
the home screen, each display in the station can show unique
information. For example, when Cruising is selected from the
home screen, one display can show the navigation chart and
another display can show the radar screen.
Adding an Item to the Favorites Screen
You can add items such as a chart, combo screen, or gauge to
your favorites screen.
Highlight an item, and hold SELECT.
The selected item appears on your favorites screen.
Customizing Pages
Customizing the Favorites Screen
You can add items to and rearrange items on the Favorites
screen.
From the Favorites screen, select MENU
1
Select an option:
2
• To rearrange an item, select Rearrange and use the
arrow keys to select the new location.
• To remove an item you have added to the Favorites
screen, select Remove Favorite, highlight the item, and
select SELECT.
Customizing the Layout of a SmartMode or
Combination Page
You can customize the layout and data shown in the
combination pages and SmartMode layouts. When you change
the layout of a page in a display you are interacting with, the
change appears only on that display, except for the SmartMode
name and symbol. When you change the SmartMode name or
symbol for the layout, the new name or symbol appears on all
displays in the station.
Open a page to customize.
1
Select MENU.
2
Select Edit Layout or Edit Combo.
3
Select an option:
4
• To change the name, select Name or Name & Symbol >
Name, enter a new name, and select Done.
• To change the SmartMode symbol, select Name &
Symbol > Symbol, and select a new symbol.
• To change the number of functions shown and the layout
of the screen, select Layout, and select an option.
• To change the function of a portion of the screen, select
the area to change, and select a function from the list on
the right.
• To change how the screens are split, drag the arrows to a
new location.
• To change the data shown on the page and additional
data bars, select Edit Overlays, and select an option.
• To assign a preset to a portion of the SmartMode screen,
select Presets > Include, and select a preset from the list
on the right.
Customizing a Combination Screen
Open a page to customize.
1
Select MENU > Edit Combo.
2
Select an option:
3
• To change the name, select Name, and enter a new
name.
• To change the arrangement of the information on the
screen, select Layout, and select a new layout.
• To customize the data shown on the screen, select
Overlays, and select an option.
• To resize the information areas shown on the screen, use
the arrow keys, and select FOCUS to exit.
2Customizing the Chartplotter
Adding a SmartMode Layout
You can add SmartMode layouts to suit your needs. Each
customization made to one SmartMode layout for the home
screen in a station appears on all displays in the station.
From the home screen, select SmartMode > MENU > Add
1
Layout.
Select an option:
2
• To change the name, select Name & SymbolName, enter
a new name, and select Done.
• To change the SmartMode symbol, select Name & Symbol > Symbol, and select a new symbol.
• To change the number of functions shown and the layout
of the screen, select Layout, and select an option.
• To change the function of a portion of the screen, select
the area to change, and select a function from the list on
the right.
• To change how the screens are split, drag the arrows to a
new location.
• To change the data shown on the page and additional
data bars, select Edit Overlays, and select an option.
• To assign a preset to a portion of the SmartMode screen,
select Presets > Include, and select a preset from the list
on the right.
Adding a Custom Combination Screen
You can create a custom combination screen to suit your needs.
Select Combos > MENU > Add Combo.
1
Follow the on-screen instructions.
2
Deleting a Combination Screen
From the combination screen, select MENU > Delete
1
Combo.
Highlight a combination, and select SELECT.
2
Customizing the Data Overlays
You can customize the data shown on a screen.
Select an option based on the type of screen you are
1
viewing:
• From a full screen view, select MENU > Edit Overlays.
• From a combination screen, select MENU > Edit Combo
> Edit Overlays.
• From a SmartMode screen, select MENU > Edit Layout >
Edit Overlays.
TIP: To quickly change the data shown in an overlay box,
hold the overlay box.
Select an item to customize the data and data bar:
2
• To change the data shown in an overlay box, select the
overlay box, select the new data to show, and select
BACK.
• To select the location and layout of the data overlay bar,
select Data, and select an option.
• To customize the information shown when navigating,
select Navigation, and select an option.
• To turn on other data bars, like the media controls, select
Top Bar or Bottom Bar, and select the necessary
options.
Select Done.
3
Resetting the Station Layouts
You can restore the factory default layouts for all stations.
Select Settings > System > Station Information > Reset
Stations.
Creating a Shortcut with a Shortcut Key
You can quickly open commonly used screens by creating a
shortcut. You can create a shortcut to screens such as radar
and sonar screens, charts, gauges, and the media player.
Open a screen.
1
Hold a shortcut key, and select OK.
2
TIP: The shortcut is also saved to your favorites page with
the shortcut key number.
Presets
A preset is a collection of settings that optimize the screen or
view. You can use particular presets to optimize groups of
settings for your activity. For example, some settings might be
optimal for when you are fishing, and others might be optimal for
when you are cruising. Presets are available on some screens,
such as charts, sonar views, and radar views.
To select a preset for a compatible screen, select MENU > ,
and select the preset.
When you are using a preset and you make changes to the
settings or view, you can save the changes to the preset or
create a new preset based on the new customizations.
Saving a New Preset
After you have customized the settings and view of a screen,
you can save the customization as a new preset.
From a compatible screen, change the settings and view.
1
Select MENU >
2
Enter a name, and select Done.
3
> Save > New.
Managing Presets
You can customize the pre-loaded presets and edit presets you
created.
From a compatible screen, select MENU >
1
Select a preset.
2
Select an option:
3
• To rename the preset, select Rename, enter a name, and
select Done.
• To edit the preset, select Edit, and update the preset.
• To delete the preset, select Delete.
• To reset all presets to factory settings, select Reset All.
> Manage.
Setting the Vessel Type
You can select your boat type to configure the chartplotter
settings and to use features customized for your boat type.
Select Settings > My Vessel > Vessel Type.
1
Select an option.
2
Adjusting the Backlight
Select Settings > System > Sounds and Display >
1
Backlight.
TIP: Select
backlight settings.
Select an option:
2
• Adjust the backlight level.
• Select Auto.
> Backlight from any screen to open the
Adjusting the Color Mode
Select Settings > System > Sounds and Display > Color
1
Mode.
TIP: Select
any screen to access the color settings.
Select an option.
2
> Sounds and Display > Color Mode from
Customizing the Chartplotter3
Charts and 3D Chart Views
The charts and 3D chart views that are available depend on the
map data and accessories used.
You can access the charts and 3D chart views by selecting
Charts.
Navigation Chart: Shows navigation data available on your pre-
loaded maps and from supplemental maps, if available. The
data includes buoys, lights, cables, depth soundings,
marinas, and tide stations in an overhead view.
Perspective 3D: Provides a view from above and behind the
boat (according to your course) and provides a visual
navigation aid. This view is helpful when navigating tricky
shoals, reefs, bridges, or channels, and is beneficial when
trying to identify entry and exit routes in unfamiliar harbors or
anchorages.
Mariner’s Eye 3D: Shows a detailed, three-dimensional view
from above and behind the boat (according to your course)
and provides a visual navigation aid. This view is helpful
when navigating tricky shoals, reefs, bridges, or channels,
and when trying to identify entry and exit routes in unfamiliar
harbors or anchorages.
NOTE: Mariner's Eye 3D and Fish Eye 3D chart views are
available with premium charts, in some areas.
Fish Eye 3D: Provides an underwater view that visually
represents the sea floor according to the chart information.
When a sonar transducer is connected, suspended targets
(such as fish) are indicated by red, green, and yellow
spheres. Red indicates the largest targets and green
indicates the smallest.
Fishing Chart: Provides a detailed view of the bottom contours
and depth soundings on the chart. This chart removes
navigational data from the chart, provides detailed
bathymetric data, and enhances bottom contours for depth
recognition. This chart is best for offshore deep-sea fishing.
NOTE: The offshore Fishing chart is available with premium
charts, in some areas.
Radar Overlay: Superimposes radar information on the
Navigation chart or the Fishing chart, when the chartplotter is
connected to a radar. This feature is not available with all
models.
Navigation Chart and Offshore Fishing Chart
NOTE: The offshore Fishing chart is available with premium
charts, in some areas.
The Navigation and Fishing charts allow you to plan your
course, view map information, and follow a route. The Fishing
chart is for offshore fishing.
To open the Navigation chart, select Charts > Nav. Chart.
To open the Fishing chart, select Charts > Fishing.
Selecting an Item on the Map Using the Device Keys
From a chart or 3D chart view, select
1
the cursor.
Select SELECT.
2
, , , or to move
Selecting a Map
If your product has both BlueChart® g2 and Garmin LakeVü™ HD
built-in maps, you can select which map to use. Not all models
have both types of built-in maps.
From the Navigation chart, select MENU > Built-in Map.
1
Select an option:
2
• When you are on an inland lake, select LakeVü™ HD.
• When you are offshore, select BlueChart® g2.
Measuring a Distance on the Chart
From a chart or the Radar overlay, select a location.
1
Select Measure Distance.
2
A push pin appears on the screen at your present location.
The distance and angle from the pin is listed in the corner.
TIP: To reset the pin and measure from the current location of
the cursor, select SELECT.
Chart Symbols
This table contains some of the common symbols you might see
on the detailed charts.
IconDescription
Buoy
Information
Marine services
Tide station
Current station
Overhead photo available
Perspective photo available
Other features common to most charts include depth contour
lines, intertidal zones, spot soundings (as depicted on the
original paper chart), navigational aids and symbols,
obstructions, and cable areas.
Showing a Different Chart
From a combination screen or SmartMode layout with a
1
chart, select MENU > Navigation Chart Menu > Change
Chart.
Select a chart or 3D chart view.
2
Creating a Waypoint on the Chart
From a chart or a 3D chart view, select a location or object,
1
and select SELECT.
A list of options appears along the right side of the chart. The
options that appear vary based on the location or object you
selected.
Select New Waypoint.
2
Navigating to a Point on the Chart
From the Navigation chart or Fishing chart, select a location.
1
Select SELECT > Navigate To.
2
Viewing Location and Object Information on a Chart
You can view information about a location or an object on the
Navigation chart or the Fishing chart.
NOTE: The offshore Fishing chart is available with premium
charts, in some areas.
From the Navigation chart or Fishing chart, select a location
1
or object.
A list of options appears along the right side of the chart. The
options that appear vary based on the location or object you
selected.
4Charts and 3D Chart Views
Select an option:
2
• To navigate to the selected location, select Navigate To.
• To mark a waypoint at the cursor location, select New Waypoint.
• To view the distance and bearing of the object from your
current location, select Measure Distance.
The distance and bearing appear on the screen. Select
SELECT to measure from a location other than your
current location.
• To view tide, current, celestial, chart notes, or local
services information near the cursor, select Information.
Viewing Details about Navaids
From the Navigation chart, Fishing chart, Perspective 3D chart
view, or Mariner’s Eye 3D chart view, you can view details about
various types of navigation aids, including beacons, lights, and
obstructions.
NOTE: The offshore Fishing chart is available with premium
charts, in some areas.
NOTE: Mariner's Eye 3D and Fish Eye 3D chart views are
available with premium charts, in some areas.
From a chart or 3D chart view, select a navaid.
1
Select the name of the navaid.
2
Heading Line and Angle Markers
The heading line is an extension drawn on the map from the
bow of the boat in the direction of travel. Angle markers indicate
relative position from the heading or course over ground, which
are helpful for casting or finding reference points.
Setting the Heading and Course Over Ground Lines
You can show the heading line and the course over ground
(COG) line on the chart.
COG is your direction of movement. Heading is the direction the
bow of the boat is pointed, when a heading sensor is connected.
From a chart view, select MENU > Chart Setup > Chart
1
Appearance > Heading Line.
If necessary, select Source, and select an option:
2
• To automatically use the source available, select Auto.
• To use the GPS antenna heading for COG, select GPS Heading (COG).
• To use data from a connected heading sensor, select
Heading.
• To use data from both a connected heading sensor and
the GPS antenna, select COG and Heading.
This displays both the heading line and the COG line on
the chart.
Select Display, and select an option:
3
• Select Distance > Distance, and enter the length of the
line shown on the chart.
• Select Time > Time, and enter the time used to calculate
the distance your boat will travel in the specified time at
your present speed.
Turning on Angle Markers
You can add angle markers to the map along the heading line.
Angle markers can be helpful for casting when fishing.
Set the heading line (
1
Ground Lines, page 5).
Select Angle Markers.
2
Setting the Heading and Course Over
Premium Charts
CAUTION
The Auto Guidance feature is based on electronic chart
information. That data does not ensure obstacle and bottom
clearance. Carefully compare the course to all visual sightings,
and avoid any land, shallow water, or other obstacles that may
be in your path.
NOTE: Not all models support all charts.
Optional premium charts, such as BlueChart g2 Vision®, allow
you to get the most out of your chartplotter. In addition to
detailed marine charting, premium charts may contain these
features, which are available in some areas.
Mariner’s Eye 3D: Provides a view from above and behind the
boat for a three-dimensional navigation aid.
Fish Eye 3D: Provides an underwater, three-dimensional view
that visually represents the sea floor according to the
information on the chart.
Fishing Charts: Shows the chart with enhanced bottom
contours and without navigational data. This chart works well
for offshore deep-sea fishing.
High Resolution Satellite Imagery: Provides high-resolution
satellite images for a realistic view of the land and water on
the Navigation chartShowing Satellite Imagery on the
Navigation Chart, page 6.
Aerial Photos: Shows marinas and other navigationally
significant aerial photos to help you visualize your
surroundingsViewing Aerial Photos of Landmarks, page 6.
Detailed Roads and POI data: Shows detailed road and point
of interest (POI) data, which includes highly detailed coastal
roads and POIs such as restaurants, lodging, and local
attractions.
Auto Guidance: Uses specified information about your vessel
and chart data to determine the best path to your destination.
Viewing Tide Station Information
on the chart indicates a tide station. You can view a detailed
graph for a tide station to help predict the tide level at different
times or on different days.
NOTE: This feature is available with premium charts, in some
areas.
From the Navigation chart or Fishing chart, select a tide
1
station.
Tide direction and tide level information appear near
Select the station name.
2
Animated Tide and Current Indicators
NOTE: This feature is available with premium charts, in some
areas.
You can view indicators for animated tide station and current
direction on the Navigation chart or the Fishing chart. You must
also enable animated icons in the chart settings (Showing Tides
and Current Indicators, page 6).
An indicator for a tide station appears on the chart as a vertical
bar graph with an arrow. A red arrow pointing downward
indicates a falling tide, and a blue arrow pointing upward
indicates a rising tide. When you move the cursor over the tide
station indicator, the height of the tide at the station appears
above the station indicator.
Current direction indicators appear as arrows on the chart. The
direction of each arrow indicates the direction of the current at a
specific location on the chart. The color of the current arrow
indicates the range of speed for the current at that location.
When you move the cursor over the current direction indicator,
the specific current speed at the location appears above the
direction indicator.
ColorCurrent Speed Range
Yellow0 to 1 knot
Orange1 to 2 knots
Red2 or more knots
.
Charts and 3D Chart Views5
Showing Tides and Current Indicators
NOTE: This feature is available with premium charts, in some
areas.
You can show static or animated tide and current station
indicators on the Navigation chart or Fishing chart.
From the Navigation or Fishing chart, select MENU > Chart
1
Setup > Tides & Currents.
Select an option:
2
• To show current station indicators and tide station
indicators on the chart, select On.
• To show animated tide station indicators and animated
current direction indicators on the chart, select Animated.
Showing Satellite Imagery on the Navigation Chart
NOTE: This feature is available with premium charts, in some
areas.
You can overlay high-resolution satellite images on the land or
on both land and sea portions of the Navigation chart.
NOTE: When enabled, high-resolution satellite images are
present only at lower zoom levels. If you cannot see highresolution images in your optional chart region, you can select
to zoom in. You also can set the detail level higher by changing
the map zoom detail.
From the Navigation chart, select MENU > Chart Setup >
1
Photos.
Select an option:
2
• Select Land Only to show standard chart information on
the water, with photos overlaying the land.
• Select Photo Map Blend to show photos on both the
water and the land at a specified opacity. Use the slider
bar to adjust the photo opacity. The higher you set the
percentage, the more the satellite photos cover both land
and water.
Viewing Aerial Photos of Landmarks
Before you can view aerial photos on the Navigation chart, you
must turn on the Photo setting in the chart setup.
NOTE: This feature is available with premium charts, in some
areas.
You can use aerial photographs of landmarks, marinas, and
harbors to help orient yourself to your surroundings or to
acquaint yourself with a marina or a harbor prior to arrival.
From the Navigation chart, select a camera icon:
1
• To view an overhead photo, select
.
• To view a perspective photo, select . The photo was
taken from the location of the camera, pointed in the
direction of the cone.
Select Aerial Photo.
2
Automatic Identification System
The Automatic Identification System (AIS) enables you to
identify and track other vessels, and alerts you to area traffic.
When connected to an external AIS device, the chartplotter can
show some AIS information about other vessels that are within
range, that are equipped with a transponder, and that are
actively transmitting AIS information.
The information reported for each vessel includes the Maritime
Mobile Service Identity (MMSI), location, GPS speed, GPS
heading, time that has elapsed since the last position of the
vessel was reported, nearest approach, and time to the nearest
approach.
Some chartplotter models also support Blue Force Tracking.
Vessels being tracked with Blue Force Tracking are indicated on
the chartplotter with a blue-green color.
AIS Targeting Symbols
Symbol Description
AIS vessel. The vessel is reporting AIS information. The
direction in which the triangle is pointing indicates the
direction in which the AIS vessel is moving.
Target is selected.
Target is activated. The target appears larger on the chart. A
green line attached to the target indicates the heading of the
target. The MMSI, speed, and direction of the vessel appear
beneath the target, if the details setting has been set to Show.
If the AIS transmission from the vessel is lost, a message
banner appears.
Target is lost. A green X indicates that the AIS transmission
from the vessel is lost, and the chartplotter displays a
message banner asking whether the vessel should continue
to be tracked. If you discontinue vessel tracking, the lost
target symbol disappears from the chart or the 3D chart view.
Dangerous target in range. The target flashes while an alarm
sounds and a message banner appears. After the alarm has
been acknowledged, a solid red triangle with a red line
attached to it indicates the location and the heading of the
target. If the safe-zone collision alarm has been set to Off, the
target flashes, but the audible alarm does not sound and the
alarm banner does not appear. If the AIS transmission from
the vessel is lost, a message banner appears.
Dangerous target is lost. A red X indicates that the AIS
transmission from the vessel is lost, and the chartplotter
displays a message banner asking whether the vessel should
continue to be tracked. If you discontinue vessel tracking, the
lost dangerous target symbol disappears from the chart or the
3D chart view.
The location of this symbol indicates the closest point of
approach to a dangerous target, and the numbers near the
symbol indicate the time to the closest point of approach to
that target.
NOTE: Vessels being tracked with the Blue Force Tracking
feature are indicated with a blue-green color regardless of their
status.
Heading and Projected Course of Activated AIS
Targets
When heading and course over ground information are provided
by an activated AIS target, the heading of the target appears on
a chart as a solid line attached to the AIS target symbol. A
heading line does not appear on a 3D chart view.
The projected course of an activated AIS target appears as a
dashed line on a chart or a 3D chart view. The length of the
projected course line is based on the value of the projected
heading setting. If an activated AIS target is not transmitting
speed information, or if the vessel is not moving, a projected
course line does not appear. Changes in the speed, course over
ground, or rate of turn information transmitted by the vessel can
impact the calculation of the projected course line.
When course over ground, heading, and rate of turn information
are provided by an activated AIS target, the projected course of
the target is calculated based on the course over ground and the
rate of turn information. The direction in which the target is
turning, which is also based on the rate of turn information, is
indicated by the direction of the barb at the end of the heading
line. The length of the barb does not change.
When course over ground and heading information are provided
by an activated AIS target, but rate of turn information is not
provided, the projected course of the target is calculated based
on the course over ground information.
6Charts and 3D Chart Views
Showing AIS and MARPA Vessels on a Chart or on a
3D Chart View
Before you can show AIS vessels on a chart, you must have an
external AIS device and active transponder signals from other
vessels. Mini Automatic Radar Plotting Aid (MARPA)
functionality works with radar.
You can configure how other vessels appear on a chart or on a
3D chart view. The display range and MARPA settings
configured for one chart or one 3D chart view are applied only to
that chart or to that 3D chart view. The details, projected
heading, and trails settings configured for one chart or one 3D
chart view are applied to all charts and to all 3D chart views.
From a chart or a 3D chart view, select MENU > Other
1
Vessels > Display Setup.
Select an option:
2
• To indicate the distance from your location in which AIS
vessels appear, select Display Range, and select a
distance.
• To show MARPA-tagged vessels, select MARPA > Show.
• To show details about AIS-activated and MARPA-tagged
vessels, select MARPA > Show.
• To set the projected heading time for AIS-activated and
MARPA-tagged vessels, select Proj. Heading, and enter
the time.
• To show the tracks of AIS vessels, select the length of the
track that appears using a trail, select Trails, and select
the length.
Activating a Target for an AIS Vessel
From a chart or a 3D chart view, select an AIS vessel.
1
Select AIS Vessel > Activate Target.
2
Viewing Information about a Targeted AIS Vessel
You can view the AIS signal status, MMSI, GPS speed, GPS
heading, and other information that is reported about a targeted
AIS vessel.
From a chart or a 3D chart view, select an AIS vessel.
1
Select AIS Vessel.
2
Deactivating a Target for an AIS Vessel
From a chart or a 3D chart view, select an AIS vessel.
1
Select AIS Vessel > Deactivate.
2
Viewing a List of AIS Threats
From a chart or 3D chart view, select MENU > Other
Vessels > List.
Setting the Safe-Zone Collision Alarm
Before you can set a collision alarm, you must have a
compatible chartplotter connected to an AIS device or radar.
The safe-zone collision alarm is used only with AIS and MARPA.
MARPA functionality works with radar. The safe zone is used for
collision avoidance and can be customized.
Select Settings > Alarms > Collision Alarm > On.
1
A message banner appears and an alarm sounds when a
MARPA-tagged object or an AIS-activated vessel enters the
safe-zone area around your boat. The object is also labeled
as dangerous on the screen. When the alarm is off, the
message banner and audible alarm are disabled, but the
object is still labeled as dangerous on the screen.
Select Range.
2
Select a distance for the safe-zone radius around your
3
vessel.
Select Time To.
4
Select a time at which the alarm will sound if a target is
5
determined to intersect the safe zone.
For example, to be notified of a pending intersection 10
minutes before it will likely occur, set Time To to 10, and the
alarm will sound 10 minutes before the vessel intersects the
safe zone.
AIS Distress Signals
Self-contained AIS distress signal devices transmit emergency
position reports when activated. The chartplotter can receive
signals from Search and Rescue Transmitters (SART),
Emergency Position Indicating Radio Beacons (EPIRB), and
other man overboard signals. Distress signal transmissions are
different than standard AIS transmissions, so they appear
differently on the chartplotter. Instead of tracking a distress
signal transmission for collision avoidance, you track a distress
signal transmission to locate and assist a vessel or person.
Navigating to a Distress Signal Transmission
When you receive a distress signal transmission, a distress
signal alarm appears.
Select Review > Go To to begin navigation to the
transmission.
AIS Distress Signal Device Targeting Symbols
Symbol Description
AIS distress signal device transmission. Select to see more
information about the transmission and begin navigation.
Transmission lost.
Transmission test. Appears when a vessel initiates a test of
their distress signal device, and does not represent a true
emergency.
Transmission test lost.
Enabling AIS Transmission Test Alerts
To avoid a large number of test alerts and symbols in crowded
areas such as marinas, you can select to receive or ignore AIS
test messages. To test an AIS emergency device, you must
enable the chartplotter to receive test alerts.
Select Settings > Alarms > AIS.
1
Select an option:
2
• To receive or ignore Emergency Position Indicating Radio
Beacon (EPRIB) test signals, select AIS-EPIRB Test.
• To receive or ignore Man Overboard (MOB) test signals,
select AIS-MOB Test.
• To receive or ignore Search and Rescue Transponder
(SART) test signals, select AIS-SART Test.
Turning Off AIS Reception
AIS signal reception is turned on by default.
Select Settings > Other Vessels > AIS > Off.
All AIS functionality on all charts and 3D chart views is
disabled. This includes AIS vessel targeting and tracking,
collision alarms that result from AIS vessel targeting and
tracking, and the display of information about AIS vessels.
AIS Display Settings
NOTE: AIS requires the use of an external AIS device and
active transponder signals from other vessels.
From a chart or 3D chart view, select MENU > Other Vessels >
Display Setup.
Display Range: Indicates the distance from your location within
which AIS vessels appear.
MARPA: Shows details about AIS-activated vessels.
Proj. Heading: Sets the projected heading time for AIS-
activated vessels.
Trails: Shows the tracks of AIS vessels, and select the length of
the track that appears using a trail.
Charts and 3D Chart Views7
Chart and 3D Chart View Settings
NOTE: Not all settings apply to all charts and 3D chart views.
Some options require premium maps or connected accessories,
such as radar.
These settings apply to the charts and 3D chart views, except
the radar overlay and Fish Eye 3D (Fish Eye 3D Settings,
page 9).
From a chart or a 3D chart view, select MENU.
Waypoints and Tracks: See Waypoints and Tracks Settings on
the Charts and Chart Views, page 8.
Other Vessels: See Other Vessels Settings on the Charts and
Chart Views, page 9.
Quickdraw Contours: Turns on bottom contour drawing, and
allows you to create fishing map labels.
Surface Radar: Shows surface radar details on the Perspective
3D or Mariner's Eye 3D chart views.
Weather Radar: Shows weather radar imaging on the
Perspective 3D or Mariner's Eye 3D chart views.
Navaids: Shows navigational aids on the Fishing chart.
Sailing: When in sailing mode, adjusts the laylines (Laylines
Settings, page 9) and starting line guidance.
Chart Setup: See Navigation and Fishing Chart Setup,
page 8.
Chart Appearance: See Chart Appearance Settings, page 8.
This might appear in the Chart Setup menu.
Edit Overlays: See Customizing the Data Overlays, page 3.
This might appear in the Chart Setup menu.
Navigation and Fishing Chart Setup
NOTE: Not all settings apply to all charts and 3D chart views.
Some settings require external accessories or applicable
premium charts.
From the Navigation chart or Fishing chart, select MENU >
Chart Setup.
Photos: Shows high-resolution satellite images on the land or
on both land and sea portions of the Navigation chart, when
certain premium maps are used Showing Satellite Imagery
on the Navigation Chart, page 6.
Water Overlay: Enables relief shading, which shows the
gradient of the bottom with shading, or sonar imagery, which
helps identify the density of the bottom. This feature is
available only with some premium maps.
Tides & Currents: Shows current station indicators and tide
station indicators on the chart Showing Tides and Current
Indicators, page 6 and enables the tides and current slider,
which sets the time for which tides and currents are reported
on the map.
Roses: Shows a compass rose around your boat, indicating
compass direction oriented to the heading of the boat. A true
wind direction or apparent wind direction indicator appears if
the chartplotter is connected to a compatible marine wind
sensor. When in sailing mode, true and apparent wind are
shown on the wind rose.
Lake Level: Sets the present water level of the lake. This
feature is available only with some premium maps.
Inset Map: Shows a small map centered on your present
location.
Weather: Sets which weather items are shown on the chart,
when the chartplotter is connected to a compatible weather
receiver with an active subscription. Requires a compatible,
connected antenna and an active subscription.
Chart Appearance: See
Chart Appearance Settings, page 8.
Waypoints and Tracks Settings on the Charts and
Chart Views
From a chart or a 3D chart view, select MENU > Waypoints
and Tracks.
Tracks: Shows tracks on the chart or 3D chart view.
Waypoints: Shows the list of waypoints (Viewing a List of all
Waypoints, page 11).
New Waypoint: Creates a new waypoint.
Waypoint Display: Sets how to display waypoints on the chart.
Active Tracks: Shows the active track options menu.
Saved Tracks: Shows the list of saved tracks (Viewing a List of
Saved Tracks, page 14).
Tracks Display: Sets which tracks to display on the chart based
on track color.
Chart Appearance Settings
You can adjust the appearance of the different charts and 3D
chart views. Each setting is specific to the chart or chart view
being used.
NOTE: Not all settings apply to all charts and 3D chart views
and chartplotter models. Some options require premium maps or
connected accessories.
From a chart or 3D chart view, select MENU > Chart Setup >
Chart Appearance.
Orientation: Sets the perspective of the map.
Detail: Adjusts the amount of detail shown on the map, at
different zoom levels.
Heading Line: Shows and adjusts the heading line, which is a
line drawn on the map from the bow of the boat in the
direction of travel, and sets the data source for the heading
line.
Panoptix Area: Shows and hides the area being scanned by
the Panoptix™ transducer. The attitude and heading reference
system (AHRS) must be calibrated use this feature
(Calibrating the Compass, page 22).
World Map: Uses either a basic world map or a shaded relief
map on the chart. These differences are visible only when
zoomed out too far to see the detailed charts.
Spot Depths: Turns on spot soundings and sets a dangerous
depth. Spot depths that are equal to or more shallow than the
dangerous depth are indicated by red text.
Shallow Shading: Sets the shades from the shoreline to the
specified depth.
Depth Shading: Specifies an upper and lower depth to shade
between.
Symbols: Shows and configures the appearance of various
symbols on the chart, such as the vessel icon, navaid
symbols, land POIs, and light sectors.
Inset Map: Shows a map zoomed in on the vessel's location in
the corner of the main map.
Style: Sets how the chart appears over 3D terrain.
Hazard Colors: Shows shallow water and land with a color
scale. Blue indicates deep water, yellow is shallow water, and
red is very shallow water.
Preferred Depth: Sets the appearance of a safe depth for the
Mariner’s Eye 3D chart view.
NOTE: This setting affects only the appearance of hazard
colors for the Mariner’s Eye 3D chart view. It does not affect
the safe water depth Auto Guidance setting or the sonar
shallow water alarm setting.
Range Rings: Shows and configures the appearance of range
rings, which help you to visualize distances in some chart
views.
8Charts and 3D Chart Views
Lane Width: Specifies the width of the navigation lane, which is
the magenta line in some chart views that indicates the
course to your destination.
Other Vessels Settings on the Charts and Chart Views
NOTE: These options require connected accessories, such as
an AIS receiver or VHF radio.
From a chart or a 3D chart view, select MENU > Other Vessels.
List: Shows a list of AIS and MARPA vessels.
DSC: Shows the DSC list and sets the DSC trails on the chart.
Collision Alarm: Sets the safe-zone collision alarm (Setting the
Safe-Zone Collision Alarm, page 7).
Display Setup: See Showing AIS and MARPA Vessels on a
Chart or on a 3D Chart View, page 7.
Laylines Settings
To use the laylines features, you must connect a wind sensor to
the chartplotter.
When in sailing mode (Setting the Vessel Type, page 3), you
can display laylines on the navigation chart. Laylines can be
very helpful when racing.
From the navigation chart, select MENU > Sailing > Laylines.
Display: Sets how the laylines and vessel appear on the chart,
and sets the length of the laylines.
Sailing Ang.: Allows you to select how the device calculates
laylines. The Actual option calculates the laylines using the
measured wind angle from the wind sensor. The Manual
option calculates the laylines using manually entered
windward and leeward angles.
Windward Ang.: Allows you to set a layline based on the
windward sailing angle.
Leeward Ang.: Allows you to set a layline based on the leeward
sailing angle.
Tide Correction: Corrects the laylines based on the tide.
Layline Filter: Filters the layline data based on the time interval
entered. For a smoother layline that filters out some of the
changes in the boat's heading or true wind angle, enter a
higher number. For laylines that display a higher sensitivity to
changes in the boat's heading or true wind angle, enter a
lower number.
Fish Eye 3D Settings
NOTE: This feature is available with premium charts, in some
areas.
From the Fish Eye 3D chart view, select MENU.
Fisheye View: Sets the perspective of the 3D chart view.
Tracks: Shows tracks.
Sonar Cone: Shows a cone that indicates the area covered by
the transducer.
Fish Symbols: Shows suspended targets.
When Garmin Quickdraw Contours records data, a colored
circle surrounds the vessel icon. This circle represents the
approximate area of the map that is scanned by each pass.
A green circle indicates good depth and GPS position, and a
speed under 16 km/h (10 mph). A yellow circle indicates good
depth and GPS position, and a speed between 16 and 32 km/h
(10 and 20 mph). A red circle indicates poor depth or GPS
position, and a speed above 32 km/h (20 mph).
You can view Garmin Quickdraw Contours in a combination
screen or as a single view on the map.
The amount of saved data depends on the size of your memory
card, your sonar source, and the speed of your boat as you
record data. You can record longer when you use a single-beam
sonar. It is estimated that you might be able to record about
1,500 hours of data onto a 2 GB memory card.
When you record data on a memory card in your chartplotter,
the new data is added to your existing Garmin Quickdraw
Contours map, and is saved on the memory card. When you
insert a new memory card, the existing data does not transfer
onto the new card.
Mapping a Body of Water Using the Garmin
Quickdraw Contours Feature
Before you can use the Garmin Quickdraw Contours feature,
you must have a supported chartplotter with upgraded software,
sonar depth, your GPS position, and a memory card with free
space.
NOTE: This feature is not available on all models.
From a chart view, select MENU > Quickdraw Contours >
1
Start Recording.
When recording is complete, select Stop Recording.
2
Select Manage > Name, and enter a name for the map.
3
Adding a Label to a Garmin Quickdraw
Contours Map
You can add labels to a Garmin Quickdraw Contours map to
mark hazards or points of interest.
From the Navigation chart, select a location.
1
Select Add Quickdraw Label.
2
Enter text for the label, and select Done.
3
Garmin Quickdraw Community
Garmin Quickdraw™ Contours
Mapping
WARNING
The Garmin Quickdraw Contours mapping feature allows users
to generate maps. Garmin makes no representations about the
accuracy, reliability, completeness or timeliness of the maps
generated by third parties. Any use or reliance on the maps
generated by third parties is at your own risk.
The Garmin Quickdraw Contours mapping feature allows you to
instantly create maps with contours and depth labels for any
body of water.
Garmin Quickdraw™ Contours Mapping9
The Garmin Quickdraw Community is a free, public, online
community that enables you to share your Garmin Quickdraw
Contours maps with others. You can also download maps other
users have created.
To access the Garmin Quickdraw Community, sign in to your
Garmin Connect™ account, and then you can upload and
download maps using a memory card.
Accessing the Garmin Quickdraw Community
You can access the Garmin Quickdraw Community using
Garmin Connect website.
connect.garmin.com.
Go to
1
Select Get Started > Quickdraw Community > Get Started.
2
If you do not have a Garmin Connect account, create one.
3
Sign in to your Garmin Connect account.
4
Select Marine in the upper-right to open the Garmin
5
Quickdraw widget.
TIP: Make sure you have a memory card in your computer to
share Garmin Quickdraw Contours maps.
Sharing Your Garmin Quickdraw Contours Maps with
the Garmin Quickdraw Community
You can share Garmin Quickdraw Contours maps that you have
created with others in the Garmin Quickdraw Community.
When you share a contour map, only the contour map is shared.
Your waypoints are not shared.
Remove the memory card from the chartplotter.
1
Insert the memory card into your computer.
2
Access the Garmin Quickdraw Community (
3
Garmin Quickdraw Community, page 9).
Select Share Your Contours.
4
Browse to your memory card, and select the /Garmin folder.
5
Open the Quickdraw folder, and select the file named
6
ContoursLog.svy.
After the file is uploaded, delete the ContoursLog.svy file from
your memory card to avoid issues with future uploads. Your data
will not be lost.
Accessing the
Downloading Garmin Quickdraw Community Maps
You can download Garmin Quickdraw Contours maps that other
users have created and shared with the Garmin Quickdraw
Community.
Insert the memory card into your computer.
1
Access the Garmin Quickdraw Community (
2
Garmin Quickdraw Community, page 9).
Select Search for Contours.
3
Use the map and search features to locate an area to
4
download.
The red dots represent Garmin Quickdraw Contours maps
that have been shared for that region.
Select Select an Area to Download.
5
Drag the edges of the box to select the area to download.
6
Select Start Download.
7
Save the file to your memory card.
8
TIP: If you cannot find the file, look in the "Downloads" folder.
The browser may have saved the file there.
Remove the memory card from your computer.
9
Insert the memory card in the chartplotter.
10
The chartplotter automatically recognizes the contours maps.
The chartplotter may take a few minutes to load the maps.
Accessing the
Garmin Quickdraw Contours Settings
From a chart, select MENU > Quickdraw Contours > Settings.
Display: Displays Garmin Quickdraw Contours. The User
Contours option shows your own Garmin Quickdraw
Contours maps. The Community Contours option shows the
maps you have downloaded from the Garmin Quickdraw
Community.
Recording Offset: Sets the distance between the sonar depth
and the contour recording depth. If the water level has
changed since your last recording, adjust this setting so the
recording depth is the same for both recordings.
For example, if the last time you recorded had a sonar depth
of 3.1 m (10.5 ft.), and today's sonar depth is 3.6 m (12 ft.),
enter -0.5 m (-1.5 ft.) for the a Recording Offset value.
User Display Offset: Sets differences in contour depths and
depth labels on your own contours maps to compensate for
changes in the water level of a body of water, or for depth
errors in recorded maps.
Comm. Display Offset: Sets differences in contour depths and
depth labels on the community contours maps to compensate
for changes in the water level of a body of water, or for depth
errors in recorded maps.
Survey Coloring: Sets the color of the Garmin Quickdraw
Contours display. When this setting is turned on, the colors
indicate the quality of the recording. When this setting is
turned off, the contour areas use standard map colors.
Green indicates good depth and GPS position, and a speed
under 16 km/h (10 mph). Yellow indicates good depth and
GPS position, and a speed between 16 and 32 km/h (10 and
20 mph). Red indicates poor depth or GPS position, and a
speed above 32 km/h (20 mph).
Depth Shading: Specifies the upper and lower limits of a depth
range and a color for that depth range.
Navigation with a Chartplotter
CAUTION
If your vessel has an autopilot system, a dedicated autopilot
control display must be installed at each steering helm in order
to disable the autopilot system.
The Auto Guidance feature is based on electronic chart
information. That data does not ensure obstacle and bottom
clearance. Carefully compare the course to all visual sightings,
and avoid any land, shallow water, or other obstacles that may
be in your path.
When using Go To, a direct course and a corrected course may
pass over land or shallow water. Use visual sightings, and steer
to avoid land, shallow water, and other dangerous objects.
NOTE: Some chart views are available with premium charts, in
some areas.
To navigate, you must choose a destination, set a course or
create a route, and follow the course or route. You can follow
the course or the route on the Navigation chart, Fishing chart,
Perspective 3D chart view, or Mariner’s Eye 3D chart view.
You can set and follow a course to a destination using one of
three methods: Go To, Route To, or Auto Guidance.
Go To: Takes you directly to the destination. This is the
standard option for navigating to a destination. The
chartplotter creates a straight-line course or navigation line to
the destination. The path may run over land and other
obstacles.
Route To: Creates a route from your location to a destination,
allowing you to add turns along the way. This option provides
a straight-line course to the destination, but allows you to add
turns into the route to avoid land and other obstacles.
Auto Guidance: Uses the specified information about your
vessel and chart data to determine the best path to your
destination. This option is available only when using a
compatible premium chart in a compatible chartplotter. It
provides a turn-by-turn navigation path to the destination,
avoiding land and other obstaclesAuto Guidance, page 13.
When you are using a compatible Garmin autopilot
connected to the chartplotter using NMEA 2000®, the
autopilot follows the Auto Guidance route.
NOTE: Auto Guidance is available with premium charts, in
some areas.
10Navigation with a Chartplotter
Loading...
+ 42 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
