Epson TM-U200D series Operator's Manual

TM-U200D Series

Operator’s Manual

Using this online operator’s guide

The words on the left side of this screen are
topics in this guide.

Use the
want. Click a bookmark to instantly jump to its topic. (If you wish,
you can increase the size of the bookmark area by dragging the
dividing bar to the right.)

Use the
the text.

Use the

Click the
(However, using the bookmarks is usually quicker.)

Complete online documentation for Acrobat Reader is located in the Help directory for Acrobat Reader.

scroll bar

scroll bar

zoom

Find

next to the bookmarks to find any topic you

on the right side of this screen to move through

tools to magnify or reduce the page display.

button if you want to search for a particular term.

bookmarks

for all the

1 Station Printer

TM-U200D Series

Operator’s Manual

401238900

Printer parts

Single-color type

Interface

connector

Drawer kick-out

connector

Power
connector

For serial interface mod el

For parallel interface mod el

DIP switches

Two-color type

Control panel

Interface

connector

Drawer kick-out

connector

Power
connector

For serial interface model

For parallel interface model

DIP switches

PAPER FEED

button

ERROR light POWER light

PAPER OUT ligh t

All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, mechanical,
photocopying, recording, or otherwise, without the prior written permission of Seiko
Epson Corporation. No patent liability is assumed with respect to the use of the
information contained herein. While every precaution has been taken in the
preparation of this book, Seiko Epson Corporation assumes no responsibility for
errors or omissions. Neither is any liability assumed for damages resulting from the
use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of
this product or third parties for damages, losses, costs, or expenses incurred by
purchaser or third parties as a result of: accident, misuse, or abuse of this product or
unauthorized modifications, repairs, or alterations to this product, or (excluding the
U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and
maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising
from the use of any options or any consumable products other than those designated
as Original Epson Products or Epson Approved Products by Seiko Epson
Corporation.

EPSON and ESC/POS are registered trademarks of Seiko Epson Corporation.

NOTICE:

The contents of this manual are subject to change without notice.

Copyright © 1997, 1998 by Seiko Epson Corporation, Nagano, Japan.

i

EMC and Safety Standards Applied

Printer

Product Name: TM-U200D/U200PD
Model Name: M119D

The following standards are applied only to the printers that are so labeled.
(EMC is tested using the packaged AC adapter and the EPSON PS-170 power
supply.)

Europe: CE Marking

Safety: EN60950

North America: EMI: FCC/ICES-003 Class A

Safety: UL 1950/CSA C22.2 No. 950

Japan: EMI: VCCI Class A

Oceania: EMC: AS/NZS 3548

Taiwan: EMI: Class B

AC Adapter

Product Name: PA-6511/6513, PB-6509/6510
Model Name: M34PA, M34PB

The following standards are applied only to the AC adapters that are so
labeled. (The printer and the AC adapter together are applied to the EMC
standards.)

Europe: CE Marking

Safety: EN60950

North America: Safety: UL 1950/CSA C22.2 No. 950

Japan: Safety: Electrical Appliance and Material Control

Law of Japan

Oceania: Safety: AS 3260

WARNING

The connection of a non-shielded printer interface cable to this printer will invalidate
the EMC standards of this device.

You are cautioned that changes or modifications not expressly approved by SEIKO
EPSON Corporation could void your authority to operate the equipment.

ii

CE Marking

The printer conforms to the following Directives and Norms

Directive 89/336/EEC EN 55022 Class B

EN 50082-1

IEC 801-2
IEC 801-3
IEC 801-4

Directive 90/384/EEC EN45501

FCC Compliance Statement

For American Users

This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to
correct the interference at his own expense.

FOR CANADIAN USERS

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme

la norme NMB-003 du Canada.

à

iii

GERÄUSCHPEGEL

Gemäß der Dritten Verordnung zum Gerätesicherheitsgesetz
(Maschinenlärminformations- Verordnung-3. GSGV) ist der arbeitsplatzbezogene
Geräusch-Emissionswert kleiner als 70 dB(A) (basierend auf ISO 7779).

iv

Introduction

Features

The TM-U200 Series printers are one-station printers for ECR and POS use which
can be used for printing the results of weighing or measuring.

TM-U200 Series (Type D) has the following 4 types.

• Single-color type with a serial interface

• Single-color type with a parallel interface

• Two-color type with a serial interface

• Two-color type with a parallel interface

The main features of the TM-U200 Series (Type D) printers are the following:

High-speed printing through logic-seeking control

❏

Excellent reliability and long life due to use of two stepping motors, one for

❏

moving the carriage and one for paper feeding

Flexible paper feed setting permits printing in accordance with any user-defined

❏

format

Command protocol based on ESC/POS, a widely used standard

❏

Built-in drawer kick-out interface provides capability to drive two drawers

❏

Selectable character fonts (7 x 9, 9 x 9)

❏

Semi-automatic paper loading capability

❏

AC adapter provides compact power supply (the AC adapter may not be

❏

enclosed for some models).

Compact and light in weight

❏

Automatic Status Back (ASB) function to automatically send printer status

❏

changes

Bidirectional parallel interface in accordance with the IEEE 1284 Nibble/Byte

❏

Modes.

Two-color printing (black and red); (two-color type only)

❏

v

About This Manual

Setting Up and Using

❏ Chapter 1

the self test, and setting the DIP switches.

❏ Chapter 2
❏ Chapter 3

contains information on unpacking the printer, setting it up, running

contains information on using the printer.

contains troubleshooting information.

Reference

❏ Chapter 4

contains specifications.

Notes, Cautions, and Warnings

Note:

Notes have important information and useful tips on the operation of your
printer.

CAUTION:

Cautions must be observed to avoid minor injury to yourself or
damage to your equipment.

vi

WARNING:

Warnings must be followed carefully to avoid serious bodily
injury.

Contents

Chapter 1 Setting Up the Printer

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Selecting the Place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Attaching the Paper Roll Near-End Detector (Option) . . . . . . . . . . . . . . . . . . . . . . . 1-2

Connecting the Printer to the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Model with serial interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Model with parallel interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Connecting the Printer to the Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Grounding the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

Connecting the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

Installing the Ribbon Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

Installing the Paper Roll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13

Running the Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17

Setting the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18

Using the Power Switch Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21

Affixing the Fastening Tape (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22

Chapter 2 Using the Printer

Operating the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Chapter 3 Troubleshooting

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

General problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Printing problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Removing jammed paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Hexadecimal Dump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Chapter 4 Reference Information

Printing Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Character Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Paper Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

vii

viii

Chapter 1

Setting Up the Printer

Unpacking

The illustration below shows the items included for the standard
specification printer.

Printer

Power supply

Hexagonal lock screws (2 pcs)
(only for the serial interface)

Ribbon cassette

Roll paper

Power switch cover

If any item is damaged, please contact your dealer for assistance.

Note:

See the Note on page 1-5 for information on the screws.

Setting Up the Printer 1–1

Selecting the Place

Place the printer on a surface that is as horizontal as possible.

The printer should be installed so that it does not move or vibrate
during paper cutting or the drawer kick-out operation.

Fastening tape is available as an option.

Attaching the Paper Roll Near-End Detector (Option)

If you do not have a paper roll near-end detector or do not want to
attach it, skip this section.

Note:

If you use this detector, use paper rolls with a core diameter 10.5
to 12.5 mm so that the detector detects the remaining paper
correctly.

1. Make sure that the power supply is disconnected from the
printer.

2. Remove four screws from the bottom of the printer; then
remove the cover.

1–2 Setting Up the Printer

3. Two spacers are included with the near-end detector. See the
illustration below and decide whether or not you want to use
them. Use them if you want the near-end detector to be
triggered when distance A is 3 to 4 mm; otherwise it will be
triggered when distance A is approximately 6 mm.

distance A

4. Secure the paper roll near-end detector (and spacers) with two
screws. When you insert the spacers, be sure you set the
spacers in the direction shown in the illustration.

Spacer

Setting Up the Printer 1–3

5. Connect the connector of the detector to CN11 of the printer.
Position the cable as shown in the illustration.

6. Replace the cover and fasten it with the four screws.

Connecting the Printer to the Computer

You need an appropriate serial interface or parallel interface cable
to connect your computer to the printer.

Model with serial interface

1. Make sure that the printer and the computer are turned off.
Then plug the cable into the connector on the printer, as shown.

1–4 Setting Up the Printer

Note:

Your printer comes with inch-type hexagonal lock screws installed.
If you plan to use an interface cable that requires millimeter-type
lock screws, replace the inch-type screws with the enclosed
millimeter-type screws by using a hex screwdriver (5 mm). To
distinguish the two types of screws, see the illustration below .

Notch (one or more lines )

Inch-type

2. Connect the other end of the cable to the connector on your
computer.

Model with parallel interface

1. Make sure that the printer and the computer are turned off.
Then plug the cable into the connector on the printer, as shown.

Millimeter-type

Note:

Squeeze the wire clips on the printer together until they lock in
place on both sides of the connector.

2. Connect the other end of the cable to the connector on your
computer.

Setting Up the Printer 1–5

Connecting the Printer to the Drawer

WARNING:

Use a drawer that matches the printer specification. Using an
improper drawer may damage the drawer as well as the
printer.

Plug the drawer cable into the drawer kick-out connector on the
bottom of the printer next to the computer interface connector.

Model with
serial interface

Model with
parallel interrface

CAUTION:

Do not connect a telephone line to the drawer kick-out
connector; otherwise the printer and the telephone line may
be damaged.

1–6 Setting Up the Printer

Den Drucker an die Schublade anschließen

Das Kabel der Schublade an die Schnappsteckerbuchse (neben der
Schnittstellenbuchse) an der Unterseite des Druckers anschließen.

Model with
serial interface

Model with
parallel interface

ACHTUNG:

Kein Telefonkabel an die Schnappsteckerbuchse
anschließen.

Setting Up the Printer 1–7

Grounding the Printer

You need a ground wire to ground your printer. Make sure that
the wire meets the specification below.

Thickness of wire: AWG 18 or equivalent
Diameter of terminal to be attached: 3.2

1. Make sure that the printer is turned off.

2. Connect the ground wire to the printer using the FG screw on
the bottom of the printer, as shown.

1–8 Setting Up the Printer

Connecting the Power Supply

This printer requires an external power supply. Be sure to use a
power supply that matches the specifications.

WARNING:

Using an incorrect power supply may cause fire or electrical
shock.

CAUTION:

When connecting or disconnecting the power supply from
the printer, make sure that the power supply is not plugged
into an electrical outlet; otherwise you may damage the
power supply or the printer.

CAUTION:

Do not connect the enclosed power supply to the EPSON
customer display DM-D101 or DM-D202. This can damage the
customer display and the power supply. However, you can
connect this power supply to the EPSON customer display
DM-D101 II or DM-D202 II.

Note:

The power supply may not be included for some models.

1. Make sure that the printer and the power supply are turned off.

Setting Up the Printer 1–9

2. Plug the power supply’s cable into the printer’s connector as
shown below. Note that the flat side of the connector faces
down.

Model with serial
interface

Model with
parallel interface

3. Plug the power supply’s cord into an outlet.

❏

If you ever need to remove the cable, unplug the power
supply’s cord from an outlet and then grasp the connector
firmly at the arrow mark and pull it straight out.

1–10 Setting Up the Printer

Installing the Ribbon Cassette

CAUTIONS:

Never turn the ribbon cassette’s feed knob in the opposite
direction of the arrow marked on the cassette; otherwise the
ribbon cassette may be damaged.

Be sure the printer is not receiving data when you replace a
ribbon cassette; otherwise data may be lost.

Note:

Use the EPSON ERC-38 (B),ERC-38(P), or ERC-38(B/P) ribbon
cassette for your printer.

The illustrations used in this section are for the single-color type
printer. However, the procedure is the same for the two-color type
printer.

1. Open the printer cover.

2. Turn the ribbon cassette’s knob in the direction of the arrow, to
take up any slack in the ribbon. Then lift up the left side with
your fingers and remove it.

3. Insert the ribbon in the position shown in the illustration on the
next page and push the ribbon cassette until it clicks.

Setting Up the Printer 1–11

Note:

Make sure that the ribbon is installed between the print head
and the platen without wrinkles or creases.

* The shape of the

print head may be
different from the
illustration.

4. Turn the ribbon cassette’s knob 5 or 6 times in the direction of
the arrow again, to take up any slack in the ribbon.

1–12 Setting Up the Printer

Installing the Paper Roll

Notes:

Be sure to use roll paper that meets the specifications.

Do not use paper rolls which have the paper glued to the core
because the printer cannot detect the paper end correctly.
However, if you will stop the printing using the optional paper
roll near-end detector, you can use glued type paper rolls.

The illustrations used in this section are for the single-color type
printer. However, the procedure is the same for the two-color type
printer.

1. Using scissors, cut the leading edge of the paper roll as shown
below.

2. Turn on the printer and open the printer cover.

3. Insert the paper roll.

Setting Up the Printer 1–13

Note:

Be sure to note the correct direction that the paper comes off the
roll as shown below.

4. Hold both edges of the paper and insert it straight into the
paper slot. The printer feeds the paper automatically.

1–14 Setting Up the Printer

5. Cut the paper, then close the cover.

6. When the

PAPER OUT

light blinks, press the

button to set the printer on line.

To remove the paper roll, follow the steps below.

1. Open the printer cover.

PAPER FEED

Setting Up the Printer 1–15

2. Pull up the paper and cut the paper at the dotted line shown in
the illustration below.

Cut here

3. Remove the paper roll from the printer.

4. Remove the remaining paper.

Note:

Do not pull the remaining paper in the opposite direction of
paper feeding.

1–16 Setting Up the Printer

Running the Self Test

Any time that you want to check the performance of your printer
you can run the self test described below. This shows whether your
printer is working correctly. It is independent of any other
equipment or software.

Note:

Be sure to install the ribbon cassette and the paper roll before
you run the self test.

1. To perform the self test, hold down the

PAPER FEED

button

while you turn on the printer with the power switch.

2. The printer prints the current printer settings and then the

PAPER OUT

light blinks to indicate that the printer is in the test

printing standby state.

3. Press the

PAPER FEED

button to start the second part of the test,
in which the printer prints a pattern using the built-in character
set.

4. After the printer completes a certain number of lines, it prints
the following:

*** completed ***

Then it enters the normal mode.

Note:

If you want to pause the self test manually, press the PAPER
FEED button. Press the PAPER FEED button again to continue

the self test.

Setting Up the Printer 1–17

Setting the DIP Switches

CAUTION:

Turn off the printer while removing the DIP switch cover to
prevent an electrical short, which can damage the printer.

You can change your serial interface and print column settings by
changing the DIP switch settings.

1. Make sure that the printer is off.

2. Turn the printer over and remove the DIP switch access cover,
as shown below.

SW 1

SW 2

3. There are two sets of switches. Notice that ON is marked on
each set of switches. Use tweezers or another narrow tool to
move the switches.

1–18 Setting Up the Printer

4. Use the following tables to set the DIP switches. Numbers
starting with 1 are in the first set, and numbers starting with 2
are in the second.

Model with serial interface DIP-Switch Functions

DIP Switch Set 1

Switch Function ON OFF

1-1 Data reception error Ignored Prints”?”

1-2

1-3 Handshaking XON/XOFF DTR/DSR
1-4 Word length 7 bits 8 bits
1-5 Parity check Yes No
1-6 Parity selec tion Even Odd
1-7 Baud rate 4800 BPS 9600 BPS

1-8 Busy condition

Receive buffer
capacity

40 bytes Approx. 1K

bytes

Sets the printer to go
BUSY when the
receive buffer is full

Sets the printer to
go BUSY when it is
offline or the
receive buffer i s fu ll

DIP Switch Set 2

Switch Function ON OFF

2-1 Print column selection

7 × 9 font/9 × 9 font

42/35 40/33

2-2 Internal use. Setting must not be changed. (Fixed to Off).
2-3 I/F pin 6 reset signal Enabled Disabled
2-4 I/F pin 25 reset signal Enabled D isabled
2-5 Internal use. Setting must not be changed. (Fixed to Off).
2-6 Internal use. Setting must not be changed. (Fixed to Off).
2-7 Internal use. Setting must not be changed. (Fixed to Off).
2-8 Undefined.

Setting Up the Printer 1–19

CAUTION:

Do not change the settings of switches 2-2, 2-5, 2-6, and 2-7.
Changing these settings may cause inferior print quality.

Model with parallel interface DIP-Switch Functions

DIP Switch Set 1

Switch Function ON OFF

1-1 Auto-li ne feed Enabled Disabled

1-2

1-3 Undefined
1-4 Undefined
1-5 Undefined
1-6 Undefined
1-7 Undefined
1-8 Handshaking

Receive buffer
capacity

(BUSY condition)

40 bytes Approx. 1K

Sets the printer to go
BUSY when the
receive buffer is full

DIP Switch Set 2

Switch Function ON OFF

2-1 Print column selection

7 × 9 font/9 × 9 font

42/35 40/33

bytes

Sets the printer to
go BUSY when it is
offline or the
receive buffer i s fu ll

2-2 Internal use. Setting must not be changed. (Fixed to Off).
2-3 Undefined
2-4 Internal use. Setting must not be changed. (Fixed to On).
2-5 Internal use. Setting must not be changed. (Fixed to Off).
2-6 Internal use. Setting must not be changed. (Fixed to Off).

1–20 Setting Up the Printer

DIP Switch Set 2

Switch Function ON OFF

2-7 Internal use. Setting must not be changed. (Fixed to Off),
2-8 Undefined.

CAUTION:

Do not change the settings of switches 2-2, 2-4, 2-5, 2-6, and
2-7. Changing these settings may cause inferior print quality.

5. Replace the DIP switch cover and secure it with the screw.

Using the Power Switch Cover

You can use the provided power switch cover to protect the power
switch from accidental or improper operation. Attach the cover as
shown in the illustration below.You can turn the power on or off
with the switch cover attached by inserting a pointed object (like a
ball point pen) through either of the two small holes on the switch
cover.

Setting Up the Printer 1–21

WARNING:

If an accident occurs when the power switch cover is
attached, unplug the power supply cord from the outlet
immediately.

Affixing the Fastening Tape (Option)

Two sets of tape are included as an option to fasten your printer to
a countertop or other surface. Follow the steps below:

1. Clean the countertop or other surface where the printer will be
installed.

2. Peel the green backing paper off of one side of each of the two
sets of tapes and affix them to the bottom of the printer, as
shown below.

3. Peel the green backing paper off of the other side of the tapes.

4. Press the printer onto the countertop; it will be held firmly in
place by the fastening tape.

1–22 Setting Up the Printer

Chapter 2

Using the Printer

Operating the Control Panel

You can feed paper with the button on the control panel. The
indicator lights help you monitor the printer’s status.

Switch

The power switch on the front of the printer turns the printer on
and off.

Button

PAPER FEED

Press the
You can also hold down
continuously.

This button is also used while replacing the paper roll. The

OUT

state after paper loading. When the
the

PAPER FEED

light blinks and printer enters the on-line recovery standby

PAPER FEED

button to set the printer on line.

button once to advance roll paper one line.

PAPER FEED

to feed the paper

PAPER OUT

light blinks, press

PAPER

Using the Printer 2-1

Note:

This button can be disabled by the ESC c 5 command, but depending
on the setting of GS z 0 command, it can work while replacing the
paper roll even if it has been disabled.

Indicator lights

The control panel lights provide information on printer conditions.

POWER

PAPER OUT

(Green)

The

POWER

(Red)

This light is on when the paper roll is at the end or near the end.

This light blinks in the following cases. When it blinks, press the

PAPER FEED

❏

In the self-test standby mode

❏

In the on-line recovery standby state after semi-auto loading

Note:

The paper near-end detector is an option.

ERROR (Red)

light is on when the printer power is on.

button.

This light is on when the printer is off line. It blinks to indicate an
error condition.

The blinking pattern shown below indicates that the temperature
of the print head is too high. The printer recovers automatically
and resumes printing when the head cools.

2-2 Using the Printer

Approximately 160 ms

If the printer stops working and the
the printer off, check for jammed paper, and remove it by following
the instructions on page 3-3, if necessary. Then turn the printer
back on. If the printer still does not work, unplug the power supply
cord from the outlet immediately; then contact a qualified service
person.

CAUTION:

The print head becomes very hot during printing. Allow it to
cool before you reach into the printer.

Note:

The power switch and
start the self test.

PAPER FEED

ERROR

light is blinking, turn

button can also be used to

Using the Printer 2-3

2-4 Using the Printer

Chapter 3

Troubleshooting

Troubleshooting

This chapter gives solutions to some of the more common printer
problems.

General problems

The lights on the control panel do not come on.

Make sure that the power supply cables are correctly plugged into
the printer, the power unit, and to the power outlet.

Make sure that power is supplied to the power outlet. If the outlet
is controlled by a switch or timer, use another outlet.

Printing problems

ERROR

The

First, turn off the printer and check for a paper jam. (See the paper
jam description on page 3-3.)

If there is no paper jam and the printer has been printing for quite a
while, the print head may be overheated. If the print head is
overheated, the printer will resume printing when the head has
cooled (usually within two or three minutes).

If there is no paper jam and the print head is not overheated, turn
off the printer and turn it back on after about 10 seconds. If the
printer still does not work, unplug the power supply cord from the
outlet immediately. Then contact a qualified service person.

light is blinking and the printer does not print.

Troubleshooting 3-1

The

ERROR

light is off, but nothing is printed.

Try to run the self test to check that the printer works properly. See
the self test instructions in Chapter 1 to run the self test. If the self
test does not work, contact your dealer or a qualified service
person.

If the self test works properly, check the following:

1. Check the connection at both ends of the interface cable
between the printer and the computer. Also make sure that this
cable meets the specifications for both the printer and the
computer.

2. The data transmission settings may be different between the
printer and computer. Make sure that the printer’s DIP switch
settings for data transmission are the same as the computer’s.
You can print the printer’s interface settings using the self test.

If the printer still does not print, contact your dealer or a qualified
service person.

The printer sounds like it is printing, but nothing is printed.

The ribbon cassette may not be installed properly. See the
instructions in Chapter 1.

The ribbon may be worn out. Replace the ribbon cassette as
described in Chapter 1.

The printout is faint.

The ribbon may be worn out. Replace the ribbon cassette as
described in Chapter 1.

3-2 Troubleshooting

A line of dots is missing in the printout.

The print head may be damaged. Stop printing and contact your
dealer or a qualified service person.

Removing jammed paper

Follow these steps to clear a paper jam:

CAUTION:

The print head becomes very hot during printing. Allow it to
cool before you reach into the printer.

1. Open the printer cover.

2. Pull up the paper and cut the paper at the dotted line shown in
the illustration below.

Cut here

Cut here

(Single-color type)

3. Remove the paper roll from the printer.

4. Remove the ribbon cassette.

(Two-color type)

Troubleshooting 3-3

5. Loosen the screw securing the print head cover. Turn the screw
only until you can tilt it as shown in the illustration.

(Single-color Type)

(Two-color Type)

Note:

Do not remove the screw from the print head cover.

6. Slide the print head cover to the left about 5 mm (1/5 inch).
(Single-color type only)

3-4 Troubleshooting

(Single-color Type)

7. Lift up the print head cover.

(Single-color Type)

8. Remove all the jammed paper.

Note:

Do not pull the jammed paper in the opposite direction of paper
feeding.

9. Replace the print head cover and secure it with the screw.

10. Replace the ribbon cassette and paper roll; then close the
printer cover.

Hexadecimal Dump

This feature allows experienced users to see exactly what data is
coming to the printer. This can be useful in finding software
problems. When you turn on the hex dump function, the printer
prints all commands and other data in hexadecimal format along
with a guide section to help you find specific commands.

(Two-color Type)

Troubleshooting 3-5

To use the hex dump feature, follow these steps:

1. After you make sure that the printer is off, set DIP switch 1-2 to

.

ON

2. Turn on the printer while you hold down the
button; then release and press the

PAPER FEED

PAPER FEED

button quickly.

Note:

Releasing and pressing the PAPER FEED button should be

performed before the printer finishes initializing; otherwise the
printer begins the self test.

3. When the printer enters the hex dump mode, it prints
“Hexadecimal Dump.”

4. Run any software program that sends data to the printer. The
printer prints all the codes it receives in a two-column format.
The first column contains the hexadecimal codes and the
second column gives the ASCII characters that correspond to
the codes.

Hexadecimal Dump
1B 21 00 1B 26 02 40 40 : . ! . . & . @ @
1B 25 01 1B 63 34 00 1B : . % . . c4 . .

41 42 43 44 45 46 47 48 : ABCDEFGH

❏

A period (.) is printed for each code that has no ASCII
equivalent.

❏

During the hex dump all commands except

DLE ENQ

5. When the printing finishes, turn off the printer or reset it to
turn off the hex dump mode.

6. If you changed the DIP switch 1-2, set it back to

3-6 Troubleshooting

are disabled.

DLE EOT

.

OFF

and

Chapter 4

Reference Information

Printing Specifications

Printing Method:

Head wire
configuration:

Printing Direction:

Characters/line
(default):

Character spacing
(default)
Fonts A and B:

Printing speed:

Serial impact dot-matrix

9-pin serial configuration

Bi-directional, logic-seeking

See table on page 4-2.

See table on page 4-2.

Approx. 3.5 LPS (40 columns, 16 CPI)
Approx. 6.4 LPS (16 columns, 16 CPI)
(excluding data transmission time and
processing time)

LPS: Lines Per Second
CPI: Characters Per Inch (number of characters per 25.4 mm)

Note:

When printing exceeds the allowable print duty cycle, the printer automatically
stops printing. In this case, the printing speed described above is not
guaranteed.

Reference Information 4-1

Character Specifications

Number of
characters

Alphanumeric characters: 95
Extended graphics: 128 x 8 pages,
International characters: 32

Character structure:

7 x 9 (the total number of dots in
horizontal: 400 in half dot units)
9 x 9 (the total number of dots in
horizontal: 400 in half dot units)

Character size:

See table below.

Character Sizes, Character Spacing, Character Columns

Character structure

Horiz x Vert Character

ANK 1.2 x 3.1 3 half dots 40 16

7 x 9

Graphics 1.7 x 3.1 0 40 16

Character size
W x H (mm)

Character
spacing
Dot space

CPL

CPI

ANK 1.6 x 3.1 3 half dots 33 13.3

9 x 9

Graphics 2.0 x 3.1 0 33 13.3
ANK 1.2 x 3.1 2 half dots 42 17.8

7 x 9

Graphics 1.6 x 3.1 0 42 17.8
ANK 1.6 x 3.1 2 half dots 35 14.5

9 x 9

Graphics 1.9 x 3.1 0 35 14.5

CPL:Characters Per Line
CPI : Characters Per Inch (number of characters per 25.4 mm)
LPS : Lines Per Second (number of charac ters per secon d)

Notes:

• Th e default is

• 7 x 9 with 2 -dot spacing in half dot units and 9 x 9 with 2 -dot spacing in half

dot units depend on the DIP switch setting.

7 x 9 with 3 -dot spacing in half dot units.

4-2 Reference Information

Paper Specifications

Paper feed method:

Paper feed pitch:

Friction feed

Default 4.23 mm {1/6"}

Can be set in units of 0.176 mm {1/
144"} by the

ESC 3

and

ESC J

commands.

Paper feed speed:

Approx. 105.92 mm/second {approx.

4.17 inches/second (25 LPS)
(continuous feeding)}

Paper size and weight: Normal paper (single-ply)

Size: Width 76 mm ± 0.5 mm

{3.0" ± 0.02"}

Maximum

83 mm {3.27"}

outside dia:

Thickness: 0.06 to 0.085 mm {.0024 to

.0033"}

Mass: 52.3 to 64.0 g/m

17 lbs} (45 to 55 Kg {20.41
to 24.94 lbs}/1000 sheets/
1091 mm ✕ 788mm
{43.00" ✕ 31.02"}

LPS : Lines Per Second (number of charac ters per secon d)

2

{13.9 to

Reference Information 4-3

Pressure sensitive paper

Maximum 1 original + 2 copies

Size: Width 76 mm ± 0.5 mm

{3.0" ± 0.02"}

Maximum

83 mm {3.27"}

outside dia:

Thickness: 0.05 to 0.08 mm {.0020 to

.0031"}
(Total thickness should
be a 0.2 mm or less
combination of 0.05 to

0.08 mm sheet.)

Recommend

-ed paper:

MITSUBISHI PAPER
MILLS, LTD.

Non-carbon paper
(blue color)

Top and middle sheets:
N40Hi
(thickness: 0.06 mm,

2

mass: 47.2 g/m

)

Note:

When using original + 2 copies ( the total is 3), the edges of papers might
be folded at 34°C, 90% in the operating tem pera ture an d hum idit y rang e.

4-4 Reference Information

Bottom sheet: N60
(thickness: 0.08 mm,

2

mass: 68.0 g/m

)

Copy capability

Relationship between ambient temperature and number of
copie

Number of copies Ambient temperature

Original + 2 copies 10° to 40°C {50° to 104°F}
Original + 1 copy 5° to 50°C {41° to 122°F}

s

Electrical Specifications

Operating voltage: Packaged AC adapter

Copy capability is greatly influenced
by the ambient temperature, so
printing must be performed under the
conditions described in the table
below.

One of the following 4 AC adapters is
selected, depending on the local power:

Factory setting Voltage

North America 120 V ± 10 %, 60 Hz PB--6509
Europe

(Germany)
Europe (England) 230 V ± 10 %, 50 Hz PA-6511
Australia 240 V ± 10 %, 50 Hz PA-6513

230 V ± 10 %, 50 Hz PB-6510

Manufacture
Number

Note:

The power supply may not be included with the printer with serial
interface.

Current consumption

(excluding driving

Operating :
Mean-approx. 43 W

drawer kickout)

Standby:
Mean-approx. 6 W

Reference Information 4-5

Reliability

Life:

MTBF:

MCBF:

Mechanism: 7,500,000 lines

Print head: 150 million characters
(using an average of 2 dots/wire per
character)

❏

End of Life is defined as the point
at which the printer reaches the
beginning of the Wearout Period.

180,000 hours

❏

Failure is defined as Random
Failure occurring at the time of the
Random Failure Period.

18,000,000 lines

❏

This is an average failure interval
based on failures relating to
wearout and random failures up to
the life of 7.5 million lines.

4-6 Reference Information

Environmental Conditions

Temperature

Operating

Storage

Humidity

Operating

Storage

0 to 50° C {32 to 122° F}
(when the temperature is 30° C or more,
there is a limitation for the humidity.
Refer to the figure below.)

–10 to 50° C {14 to 122° F}

(except for paper, and a ribbon)

10 to 90% RH

10 to 90% RH
(except for paper and a ribbon)

Operating environment range

Relative humidity

90

60

80

40

20
10

34° C, 90%

40° C, 65%

50° C, 35%

0

0

10

20

40

30

Environment temperature [° C]

50

Reference Information 4-7

Interface Specifications

Serial interface:

Parallel interface:

Note:

The interface is a factory installed option. One of the interfaces (RS­232, RS-485, or parallel) is already installed.

Note:

Refer to the EPSON TM-U200 Series (Type D) Specification for
details.

RS-232 compatible or RS-485 compatible

IEEE 1284 compatible (Nibble/Byte
Modes)

4-8 Reference Information

Printed in Philippines

1999.12
