Epson TM-L90, TM-L60II, TM-U210, TM-U230, TM-P60 User Manual

ESC/POS

CONFIDENTIAL

Printers & Commands

What’s New in This Version?

About This Guide

Character Code Tables

How to Use This Guide

ESC/POS Information

EPSON

404394101

Confidentiality Agreement

Paper Roll Printers

ESC/POS®Application

Programming Guide

Version 10.01

ESC/POS

EPSON

•

Commands in Alphanumeric Order

•

Commands Arranged by Function

•

Commands Arranged by Printer

CONFIDENTIAL

TM-T88III

TM-T90

TM-L60II

TM-L90

TM-J2000/J2100

TM-U210

TM-U220

TM-U230

TM-U300A/U300B

TM-P60

printers & commands

ESC/POS

EPSON

CONFIDENTIAL

how to use this guide

Text

Any text colored blue is a link to another screen. Click the text to go to that topic.

Printer information

Most information applies to all printers in a category. If there is information specific to one printer, you see its name in colored text, with a different color for each printer. The model dependent information appears if you click on the name of the printer or look at the bottom of the screen for text in the appropriate color.

blue

text

PRINTER

name

ESC/POS

EPSON

CONFIDENTIAL

what’s new in this version?

Version 10.00

TM-U220 added.

This guide (Paper Roll Printers) is now separate from the guides for other types of printers.

Version 10.01

TM-P60 added.

ESC/POS

CONFIDENTIAL

ESC/POS®Application Programming Guide for Paper Roll Printers Version 10.01 Seiko Epson Corporation, System Device Division

Notice: The contents of this manual are subject to change without notice

EPSON and ESC/POS are registered trademarks of Seiko Epson Corporation. Acrobat

®

EPSON

about this guide

ESC/POS

EPSON

CONFIDENTIAL

confidentiality agreement

BY USING THIS DOCUMENT, YOU AGREE TO ABIDE BY THE TERMS OF THIS AGREEMENT. PLEASE RETURN THIS DOCUMENT IMMEDIATELY IF YOU DO NOT AGREE TO THESE TERMS.

This document contains confidential, proprietary information of Seiko Epson Corporation or its affiliates. You must keep such information confidential. If the user is a business entity or organization, you must limit disclosure to those of your employees, agents and contractors who have a need to know and who are also bound by obligations of confidentiality.

On the earlier of (a) termination of your relationship with Seiko Epson, or (b) Seiko Epson's request, you must stop using the confidential information. You must then return or destroy the information, as directed by Seiko Epson.

If a court, arbitrator, government agency or the like orders you to disclose any confidential information, you must immediately notify Seiko Epson. You agree to give Seiko Epson reasonable cooperation and assistance in resisting disclosure.

You may use confidential information only for the purpose of facilitating authorized sales and service of, or developing software and similar products for authorized use with, EPSON products. Any other use requires the prior written consent of Seiko Epson.

THE INFORMATION IN THIS DOCUMENT IS PROVIDED “AS IS,” WITHOUT WARRANTY OF ANY KIND, INCLUDING ANY WARRANTY OF TITLE OR NONINFRINGEMENT. Seiko Epson has no liability for loss or damage arising from or relating to your use of or reliance on the information in the document.

You may not reproduce, store or transmit the confidential information in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise) without the prior written permission of Seiko Epson.

Your obligations under this Agreement are in addition to any other legal obligations. Seiko Epson does not waive any right under this Agreement by failing to exercise it. The laws of Japan apply to this Agreement.

CONFIDENTIAL

ESC/POS proprietary command system

ESC/POS

The market for store automation equipment is changing rapidly with the widespread introduction of POS (point of sale) terminals. These terminals are now appearing even in small retail stores and specialty shops.

As personal computers begin to be used as POS terminals, the demand for matching uniform peripheral devices is expected to rise. At present, however, many of the competing POS terminal printers on the market employ mutually incompatible command sets. This imposes limits on the expandability and range of applications possible with PC-based systems. There is a need for a new command set designed to provide the expandability and universal applicability demanded by the market.

ESC/POS

EPSON took the initiative by introducing ESC/POS, a proprietary POS printer command system, which includes patented or patent pending commands and enables versatile POS system construction with high scalability. Compatible with all types of EPSON POS printers and displays, this proprietary control system also offers the flexibility to easily make future upgrades. Its popularity is worldwide.

®

PROPRIETARY COMMAND SYSTEM

ESC/POS is designed to reduce the processing load on the host computer in POS environments. It comprises a set of highly functional and efficient commands that enables the full realization of the potential of printers.

A command set designed for universal applicability

The commands that are supported by all EPSON POS printers and those that are specific to individual models are clearly described. This means that ESC/POS compatible software will work with any system and be suitable for a wide range of applications.

Superb expandability allowing the addition of new functions

New functions can be added and accommodated by the categories already provided in the command system.

Allows more effective use of software

Once a software application has been created for one printer in the TM series, it can be used as the basis for versions for the other printers in the series. Only a small portion of the program source code needs to be modified.

Paper roll ESC/POS proprietary command system

Ver. 10.01 p. 7

CONFIDENTIAL

Command classification

COMMAND CLASSIFICATION

ESC/POS printer commands are classified by functions such as print, character, print position, printing paper, line spacing, panel button, paper sensor, mechanism control, status, bar code, bit-image, macro function, control option, and miscellaneous functions. The classification is called function classification.

ESC/POS printer commands are also classified by sheet and grade. The sheet and grade classification is called matrix classification.

The sheet classification is divided into single sheet commands and multiple sheet commands. The grade classification is separated into basic commands and extension commands.

Basic commands are defined as fundamental printer controls, including print commands and character type selection commands. Extension commands are defined as control codes for functions specific to individual printers. These commands are further divided into mechanical extension commands that relate to additional mechanical functions such as stamp and autocutter units, hardware extension commands that relate to additional hardware functions such as panel button and status transmission controls, and software extension commands that relate to additional software functions such as user-defined and bar code controls. The next screen is an overview diagram of the matrix classification of ESC/POS.

Paper roll Command classification

Ver. 10.01 p. 8

CONFIDENTIAL

Sheet

Multiple sheet

Single sheet

Multiple sheet commands

Single sheet commands

Basic commands

Mechanical extension commands

Extension commands

Hardware extension commands

Software extension commands

Paper roll Command classification

Grade

Ver. 10.01 p. 9

CONFIDENTIAL

Overview of data processing

OVERVIEW OF DATA PROCESSING

Character Data and Normal Commands

The printer stores data sent from the host computer in the receive buffer temporarily, and then the printer interprets the data and classifies them into commands or character data sequentially. If the data from the receive buffer is a normal command, the printer processes the command corresponding to its function; for example, if the data interpreted is ESC 3, the printer changes a setting value for the line spacing, and if it is LF, the printer prints the data in the print buffer and feeds the paper one line.

If the data from the receive buffer is character data, the printer reads the appropriate font data from the resident character generator and writes image data to the print buffer.

Real-time Commands

The printer stores data sent from the host computer in the receive buffer, interprets the data, and processes the commands corresponding to their function one line at a time. The real-time commands are the commands that consist of a DLE extension, such as DLE EOT or DLE ENQ. They are processed immediately. The real-time commands are ignored as undefined codes in the main processing.

Paper roll Overview of data processing

Ver. 10.01 p. 10

CONFIDENTIAL

Data processing diagram

Real-time

Interface

Host

computer

Character generator

(Font data)

[Data analysis/processing]

(Character data/normal command)

command

processing

Receive buffer

Main processing

Print buffer

Paper roll Overview of data processing

Mechanism

Ver. 10.01 p. 11

CONFIDENTIAL

Definitions

DEFINITIONS

Normal commands

Normal commands are all the commands except real-time commands. The normal commands are stored in the receive buffer temporarily and then processed sequentially.

Real-time commands

Real-time commands are the commands that consist of a DLE extension (such as DLE EOT or DLE ENQ). The realtime commands execute processing when received. After executing, they are stored in the receive buffer and then discarded as undefined codes when the normal commands are processed.

Receive buffer

The receive buffer is used to store data from the host computer. All received data is stored in this buffer and processed in the order received. Buffer capacity depends on the printer model used.

Obsolete commands

These are commands that will not be supported by future printer models. The command descriptions give a better command to use for the same function.

Print buffer

The print buffer is used to store image data for printing.

Print buffer-full

This state occurs when the print buffer becomes full.

Print buffer-full printing

If new print data (such as characters or bit images) or horizontal tabs are processed in standard mode when the print buffer is full, the image data already stored in the print buffer is printed, and a line feed is executed. This is the same operation as LF. The data (print data or horizontal tab) that causes the print buffer-full is processed from the beginning of the next line.

If new print data (such as characters or bit images) or horizontal tabs are processed in page mode when the print buffer is full, the printer moves the print position to the beginning of the next line (the same operation as LF) and processes the data (print data or horizontal tabs) that causes the print buffer-full.

Paper roll Definitions

Ver. 10.01 p. 12

CONFIDENTIAL

Beginning of the line

The beginning of the line meets all of the following conditions:

• No data exists in the print buffer.

• No spaces are skipped by HT in the print buffer.

• The print position has not been specified by ESC $ or ESC \.

In standard mode, the beginning of the line is the left margin.

Printable area

This is the maximum printable area specified for each printer model. This can be changed by setting the paper width with GS ( E fn = 5 or DIP switch or setting of paper layout that is supported by the label printer model.

Printing area

This is the printing range set by a command. The printing area should be equal to or smaller than the printable area. In standard mode, the printing area is set by GS L and GS W, and in page mode, it is set by ESC W.

Ignoring a command

This is the printer state in which the printer does nothing after receiving all codes, including parameters.

Horizontal/vertical direction

Horizontal direction is the direction that is perpendicular to the paper feed direction. Vertical direction is the paper feed direction. In page mode, however, horizontal/vertical direction differs, depending on the print direction of a character, not the paper feed direction.

Baseline

The baseline for character sets that are 9 dots high (for example, 7 × 9 and 9 × 9) is the invisible line marking the bottom of the character matrix (the bottom of the lowest dot possible). For other character sets, the baseline is the bottom of all characters, excluding descenders, such as the bottom parts of “g” and “y”, which are below the baseline.

Setting commands

Setting commands change printer status by processing a command and affect printer operation and print results thereafter. The commands that can specify enhanced characters, set paper feed amount, and select a character are setting commands as are some of the normal commands.

Paper roll Definitions

Ver. 10.01 p. 13

CONFIDENTIAL

Executing commands

Executing commands affect printer operation and change the printer status temporarily but do not affect the following printer operation. Functions of printing, paper cutting, and status transmission are executing commands and the real-time commands and some of the normal commands are executing commands.

MSB

Most Significant Bit

LSB

Least Significant Bit

Obsolete commands

These are commands that will not be supported by future printer models. The description of each of these commands gives a better command to use for the same function.

“Reserved” bit

“Reserved” bits are as follows:

• Bit that will be used for an extended function in the future.

• Bit that has a function in the ESC/POS specification; however, the printer does not support the function.

Use a bit with a value indicated in a table.

“Fixed” bit

Use a bit only with a value indicated in a table.

Paper roll Definitions

Ver. 10.01 p. 14

CONFIDENTIAL

TM-U375 supported commands

TM-T88III SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

CR

CAN

DLE EOT

DLE ENQ

DLE DC4 (fn = 1)

DLE DC4 (fn = 8)

ESC FF

ESC SP

ESC !

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Real-time request to printer

Generate pulse at real-time

Clear buffer

Print data in page mode

Set right-side character spacing

Select print mode(s)

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

ESC $

ESC %

ESC &

ESC ✻

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Set absolute print position

Select/cancel user-defined character set

Define user-defined characters

Select bit-image mode

Paper roll TM-T88III supported commands

PRINT POSITION COMMANDS

CHARACTER COMMANDS

BIT-IMAGE COMMANDS

Ver. 10.01 p. 15

CONFIDENTIAL

Command Classification Name Function type

ESC –

ESC 2

ESC 3

ESC =

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC L

ESC M

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Turn underline mode on/off

Select default line spacing

Set line spacing

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Select page mode

Select character font

CHARACTER COMMANDS

LINE SPACING COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

ESC R

ESC S

ESC T

ESC V

ESC W

ESC \

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Select an international character set

Select standard mode

Select print direction in page mode

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Set relative print position

Paper roll TM-T88III supported commands

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 16

CONFIDENTIAL

Command Classification Name Function type

ESC a

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC p

ESC t

ESC {

GS !

GS $

GS ( A

GS :

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Generate pulse

Select character code table

Turn upside-down printing mode on/off

Select character size

Set absolute vertical print position in page mode

Execute test print

Start/end macro definition

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

MACRO FUNCTION COMMANDS

GS B

GS H

GS I

GS L

GS P

GS V

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Turn white/black reverse printing mode on/off

Select printing position of HRI characters

Transmit printer ID

Set left margin

Set horizontal and vertical motion units

Select cut mode and cut paper

Paper roll TM-T88III supported commands

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

MECHANISM CONTROL COMMANDS

Ver. 10.01 p. 17

CONFIDENTIAL

Command Classification Name Function type

GS W

GS \

GS ^

GS a

GS b

GS f

GS h

GS k

GS r

GS w

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Set printing area width

Set relative vertical print position in page mode

Execute macro

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Set bar code height

Print bar code

Transmit status

Set bar code width

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-T88III supported commands

Ver. 10.01 p. 18

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-T88III supported commands

Ver. 10.01 p. 19

CONFIDENTIAL

TM-U375 supported commands

TM-T90 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

CR

CAN

DLE EOT

DLE ENQ

DLE DC4 (fn = 1)

DLE DC4 (fn = 2)

DLE DC4 (fn = 8)

ESC FF

ESC SP

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Real-time request to printer

Generate pulse at real-time

Turn off the power

Clear buffer

Print data in page mode

Set right-side character spacing

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

ESC !

ESC $

ESC %

ESC &

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select print mode(s)

Set absolute print position

Select/cancel user-defined character set

Define user-defined characters

Paper roll TM-T90 supported commands

CHARACTER COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 20

CONFIDENTIAL

Command Classification Name Function type

ESC ✻

ESC –

ESC 2

ESC 3

ESC =

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC L

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

Select bit-image mode

Turn underline mode on/off

Select default line spacing

Set line spacing

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Select page mode

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

ESC M

ESC R

ESC S

ESC T

ESC V

ESC W

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select character font

Select an international character set

Select standard mode

Select print direction in page mode

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Paper roll TM-T90 supported commands

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 21

CONFIDENTIAL

Command Classification Name Function type

ESC \

ESC a

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC p

ESC t

ESC {

GS !

GS $

GS ( A

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Set relative print position

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Generate pulse

Select character code table

Turn upside-down printing mode on/off

Select character size

Set absolute vertical print position in page mode

Execute test print

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

GS ( C

GS ( D

GS ( E

GS ( K

GS ( L GS 8 L

EXECUTING + SETTING

EXECUTING COMMAND

EXECUTING + SETTING

Edit NV user memory

Enable/disable real-time command

User setup commands

Select printing control

Specify graphics data

Paper roll TM-T90 supported commands

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

Ver. 10.01 p. 22

CONFIDENTIAL

Command Classification Name Function type

GS ( M

GS ( N

GS ( k

GS :

GS B

GS H

GS I

GS L

GS P

GS T

GS V

GS W

EXECUTING + SETTING

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Customize printer control value(s)

Select character effects

Specify and print the symbol

Start/end macro definition

Turn white/black reverse printing mode on/off

Select printing position of HRI characters

Transmit printer ID

Set left margin

Set horizontal and vertical motion units

Set print position to the beginning of print line

Select cut mode and cut paper

Set printing area width

CUSTOMIZE COMMANDS

CHARACTER COMMANDS

TWO DIMENSION CODE COMMANDS

MACRO FUNCTION COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

GS \

GS ^

GS a

GS b

GS f

GS g 0

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

Set relative vertical print position in page mode

Execute macro

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Initialize maintenance counter

Paper roll TM-T90 supported commands

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

Ver. 10.01 p. 23

CONFIDENTIAL

Command Classification Name Function type

GS g 2

GS h

GS k

GS r

GS w

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Transmit maintenance counter

Set bar code height

Print bar code

Transmit status

Set bar code width

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-T90 supported commands

Ver. 10.01 p. 24

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-T90 supported commands

Ver. 10.01 p. 25

CONFIDENTIAL

TM-U375 supported commands

TM-L60II SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

FF (on label)

CR

CAN

DLE EOT

ESC FF

ESC SP

ESC !

ESC $

ESC %

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode

Print and feed label to print starting position (on label)

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Print data in page mode

Set right-side character spacing

Select print mode(s)

Set absolute print position

Select/cancel user-defined character set

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

ESC &

ESC ✻

ESC –

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Define user-defined characters

Select bit-image mode

Turn underline mode on/off

Paper roll TM-L60II supported commands

CHARACTER COMMANDS

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 26

CONFIDENTIAL

Command Classification Name Function type

ESC 2

ESC 3

ESC =

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC L

ESC R

ESC S

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Select default line spacing

Set line spacing

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Select page mode

Select an international character set

Select standard mode

LINE SPACING COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

ESC T

ESC V

ESC W

ESC \

ESC a

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select print direction in page mode

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Set relative print position

Select justification

Paper roll TM-L60II supported commands

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 27

CONFIDENTIAL

Command Classification Name Function type

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC p

ESC t

ESC {

GS FF

GS !

GS $

GS :

GS B

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Generate pulse

Select character code table

Turn upside-down printing mode on/off

Print and eject label

Select character size

Set absolute vertical print position in page mode

Start/end macro definition

Turn white/black reverse printing mode on/off

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

CHARACTER COMMANDS

GS H

GS I

GS L

GS P

GS W

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select printing position of HRI characters

Transmit printer ID

Set left margin

Set horizontal and vertical motion units

Set printing area width

Paper roll TM-L60II supported commands

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 28

CONFIDENTIAL

Command Classification Name Function type

GS \

GS ^

GS a

GS b

GS f

GS h

GS k

GS r

GS w

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Set relative vertical print position in page mode

Execute macro

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Set bar code height

Print bar code

Transmit status

Set bar code width

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-L60II supported commands

Ver. 10.01 p. 29

CONFIDENTIAL

TM-U375 supported commands

TM-L90 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

CR

CAN

DLE EOT

DLE ENQ

DLE DC4 (fn = 1)

DLE DC4 (fn = 2)

DLE DC4 (fn = 8)

ESC FF

ESC SP

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Real-time request to printer

Generate pulse at real-time

Turn off the power

Clear buffer

Print data in page mode

Set right-side character spacing

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

ESC !

ESC $

ESC %

ESC &

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select print mode(s)

Set absolute print position

Select/cancel user-defined character set

Define user-defined characters

Paper roll TM-L90 supported commands

CHARACTER COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 30

CONFIDENTIAL

Command Classification Name Function type

ESC ✻

ESC –

ESC 2

ESC 3

ESC =

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC L

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

Select bit-image mode

Turn underline mode on/off

Select default line spacing

Set line spacing

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Select page mode

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

ESC M

ESC R

ESC S

ESC T

ESC V

ESC W

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select character font

Select an international character set

Select standard mode

Select print direction in page mode

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Paper roll TM-L90 supported commands

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 31

CONFIDENTIAL

Command Classification Name Function type

ESC \

ESC a

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC p

ESC t

ESC {

FS ( L

GS !

GS $

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

Set relative print position

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Generate pulse

Select character code table

Turn upside-down printing mode on/off

Control of the label paper / black mark paper

Select character size

Set absolute vertical print position in page mode

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

PRINTING PAPER COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

GS ( A

GS ( C

GS ( D

GS ( E

GS ( K

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

Execute test print

Edit NV user memory

Enable/disable real-time command

User setup commands

Select printing control

Paper roll TM-L90 supported commands

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

Ver. 10.01 p. 32

CONFIDENTIAL

Command Classification Name Function type

GS ( L GS 8 L

GS ( M

GS ( N

GS ( k

GS :

GS B

GS H

GS I

GS L

GS P

GS T

GS V

EXECUTING + SETTING

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Specify graphics data

Customize printer control value(s)

Select character effects

Specify and print the symbol

Start/end macro definition

Turn white/black reverse printing mode on/off

Select printing position of HRI characters

Transmit printer ID

Set left margin

Set horizontal and vertical motion units

Set print position to the beginning of print line

Select cut mode and cut paper

BIT-IMAGE COMMANDS

CUSTOMIZE COMMANDS

CHARACTER COMMANDS

TWO DIMENSION CODE COMMANDS

MACRO FUNCTION COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MECHANISM CONTROL COMMANDS

GS W

GS \

GS ^

GS a

GS b

GS f

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

Set printing area width

Set relative vertical print position in page mode

Execute macro

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Paper roll TM-L90 supported commands

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

Ver. 10.01 p. 33

CONFIDENTIAL

Command Classification Name Function type

GS g 0

GS g 2

GS h

GS k

GS r

GS w

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Initialize maintenance counter

Transmit maintenance counter

Set bar code height

Print bar code

Transmit status

Set bar code width

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-L90 supported commands

Ver. 10.01 p. 34

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-L90 supported commands

Ver. 10.01 p. 35

CONFIDENTIAL

TM-U375 supported commands

TM-J2000/J2100 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

CR

CAN

DLE EOT

DLE EOT BEL

DLE ENQ

DLE DC4 (fn = 1)

DLE DC4 (fn = 2)

DLE DC4 (fn = 8)

ESC FF

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Real-time status transmission for ink (The call name is changed.)

Real-time request to printer

Generate pulse at real-time

Turn off the power

Clear buffer

Print data in page mode

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

PRINT COMMANDS

ESC SP

ESC !

ESC $

SETTING COMMAND

EXECUTING COMMAND

Set right-side character spacing

Select print mode(s)

Set absolute print position

Paper roll TM-J2000/J2100 supported commands

CHARACTER COMMANDS

PRINT POSITION COMMANDS

Ver. 10.01 p. 36

CONFIDENTIAL

Command Classification Name Function type

ESC %

ESC &

ESC ✻

ESC –

ESC 2

ESC 3

ESC <

ESC =

ESC ?

ESC @

ESC D

ESC E

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

Select/cancel user-defined character set

Define user-defined characters

Select bit-image mode

Turn underline mode on/off

Select default line spacing

Set line spacing

Return home

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

CHARACTER COMMANDS

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

ESC G

ESC J

ESC L

ESC M

ESC R

ESC S

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Turn double-strike mode on/off

Print and feed paper

Select page mode

Select character font

Select an international character set

Select standard mode

Paper roll TM-J2000/J2100 supported commands

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

Ver. 10.01 p. 37

CONFIDENTIAL

Command Classification Name Function type

ESC T

ESC U

ESC V

ESC W

ESC \

ESC a

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC p

ESC r

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select print direction in page mode

Turn unidirectional printing mode on/off

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Set relative print position

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Generate pulse

Select print color

PRINT POSITION COMMANDS

MECHANISM CONTROL COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

ESC t

ESC {

GS !

GS $

GS ( A

SETTING COMMAND

EXECUTING COMMAND

Select character code table

Turn upside-down printing mode on/off

Select character size

Set absolute vertical print position in page mode

Execute test print

Paper roll TM-J2000/J2100 supported commands

CHARACTER COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

Ver. 10.01 p. 38

CONFIDENTIAL

Command Classification Name Function type

GS ( C

GS ( D

GS ( E

GS ( K

GS ( L GS 8 L

GS ( M

GS ( N

GS :

GS B

GS H

GS I

GS L

EXECUTING + SETTING

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Edit NV user memory

Enable/disable real-time command

User setup commands

Select printing control

Specify graphics data

Customize printer control value(s)

Select character effects

Start/end macro definition

Turn white/black reverse printing mode on/off

Select printing position of HRI characters

Transmit printer ID

Set left margin

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

CUSTOMIZE COMMANDS

CHARACTER COMMANDS

MACRO FUNCTION COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

GS P

GS T

GS V

GS W

GS \

GS ^

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Set horizontal and vertical motion units

Set print position to the beginning of print line

Select cut mode and cut paper

Set printing area width

Set relative vertical print position in page mode

Execute macro

Paper roll TM-J2000/J2100 supported commands

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

Ver. 10.01 p. 39

CONFIDENTIAL

Command Classification Name Function type

GS a

GS b

GS f

GS g 0

GS g 2

GS h

GS j

GS k

GS r

GS w

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Initialize maintenance counter

Transmit maintenance counter

Set bar code height

Enable/disable Ink Automatic Status Back (ASB)

Print bar code

Transmit status

Set bar code width

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-J2000/J2100 supported commands

Ver. 10.01 p. 40

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-J2000/J2100 supported commands

Ver. 10.01 p. 41

CONFIDENTIAL

TM-U375 supported commands

TM-U210 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

CR

DLE EOT

DLE ENQ

ESC SP

ESC !

ESC %

ESC &

ESC ✻

ESC –

ESC 2

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and carriage return

Real-time status transmission

Real-time request to printer

Set right-side character spacing

Select print mode(s)

Select/cancel user-defined character set

Define user-defined characters

Select bit-image mode

Turn underline mode on/off

Select default line spacing

PRINT POSITION COMMANDS

PRINT COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

ESC 3

ESC <

ESC =

ESC ?

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Set line spacing

Return home

Select peripheral device

Cancel user-defined characters

Paper roll TM-U210 supported commands

LINE SPACING COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 42

CONFIDENTIAL

Command Classification Name Function type

ESC @

ESC D

ESC E

ESC G

ESC J

ESC K

ESC R

ESC U

ESC a

ESC c 3

ESC c 4

ESC c 5

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Print and reverse feed

Select an international character set

Turn unidirectional printing mode on/off

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

ESC d

ESC e

ESC p

ESC r

ESC t

EXECUTING COMMAND

SETTING COMMAND

Print and feed n lines

Print and reverse feed n lines

Generate pulse

Select print color

Select character code table

Paper roll TM-U210 supported commands

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 43

CONFIDENTIAL

Command Classification Name Function type

ESC {

GS ( A

GS I

GS V

GS a

GS r

GS z 0

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Turn upside-down printing mode on/off

Execute test print

Transmit printer ID

Select cut mode and cut paper

Enable/disable Automatic Status Back (ASB)

Transmit status

Set online recovery wait time

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

MECHANISM CONTROL COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

Paper roll TM-U210 supported commands

Ver. 10.01 p. 44

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-U210 supported commands

Ver. 10.01 p. 45

CONFIDENTIAL

TM-U220 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

CR

DLE EOT

DLE ENQ

DLE DC4 (fn = 1)

ESC SP

ESC !

ESC %

ESC &

ESC ( A

ESC ✻

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

Horizontal tab

Print and line feed

Print and carriage return

Real-time status transmission

Real-time request to printer

Generate pulse at real-time

Set right-side character spacing

Select print mode(s)

Select/cancel user-defined character set

Define user-defined characters

Control of the beeper

Select bit-image mode

PRINT POSITION COMMANDS

PRINT COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

ESC –

ESC 2

ESC 3

SETTING COMMAND

Turn underline mode on/off

Select default line spacing

Set line spacing

Paper roll TM-U220 supported commands

CHARACTER COMMANDS

LINE SPACING COMMANDS

Ver. 10.01 p. 46

CONFIDENTIAL

Command Classification Name Function type

ESC <

ESC =

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC K

ESC M

ESC R

ESC U

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Return home

Select peripheral device

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Print and reverse feed

Select character font

Select an international character set

Turn unidirectional printing mode on/off

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

MECHANISM CONTROL COMMANDS

ESC a

ESC c 3

SETTING COMMAND

Select justification

Select paper sensor(s) to output paper-end signals

ESC c 4

ESC c 5

ESC d

SETTING COMMAND

EXECUTING COMMAND

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Paper roll TM-U220 supported commands

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

Ver. 10.01 p. 47

CONFIDENTIAL

Command Classification Name Function type

ESC e

ESC i

ESC m

ESC p

ESC r

ESC t

ESC u

ESC v

ESC {

FS !

FS &

FS –

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Print and reverse feed n lines

Partial cut (one point left uncut)

Partial cut (three points left uncut)

Generate pulse

Select print color

Select character code table

Transmit peripheral device status

Transmit paper sensor status

Turn upside-down printing mode on/off

Set print mode(s) for Kanji characters

Select Kanji character mode

Turn underline mode on/off for Kanji characters

PRINT COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

KANJI COMMANDS

FS .

FS 2

FS C

FS S

FS W

SETTING COMMAND

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Paper roll TM-U220 supported commands

KANJI COMMANDS

Ver. 10.01 p. 48

CONFIDENTIAL

Command Classification Name Function type

FS ?

FS p

FS q

GS ( A

GS ( C

GS ( D

GS ( E

GS I

GS V

GS a

GS r

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

Cancel user-defined Kanji characters

Print NV bit image

Define NV bit image

Execute test print

Edit NV user memory

Enable/disable real-time command

User setup commands

Transmit printer ID

Select cut mode and cut paper

Enable/disable Automatic Status Back (ASB)

Transmit status

KANJI COMMANDS

BIT-IMAGE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

MECHANISM CONTROL COMMANDS

STATUS COMMANDS

Paper roll TM-U220 supported commands

Ver. 10.01 p. 49

CONFIDENTIAL

TM-U375 supported commands

TM-U230 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

CR

DLE EOT

DLE ENQ

ESC SP

ESC !

ESC %

ESC &

ESC ( A

ESC ✻

ESC –

EXECUTING COMMAND

SETTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Horizontal tab

Print and line feed

Print and carriage return

Real-time status transmission

Real-time request to printer

Set right-side character spacing

Select print mode(s)

Select/cancel user-defined character set

Define user-defined characters

Control of the beeper

Select bit-image mode

Turn underline mode on/off

PRINT POSITION COMMANDS

PRINT COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

ESC 2

ESC 3

ESC <

ESC =

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select default line spacing

Set line spacing

Return home

Select peripheral device

Paper roll TM-U230 supported commands

LINE SPACING COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

Ver. 10.01 p. 50

CONFIDENTIAL

Command Classification Name Function type

ESC ?

ESC @

ESC D

ESC E

ESC G

ESC J

ESC K

ESC R

ESC U

ESC a

ESC c 3

ESC c 4

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Cancel user-defined characters

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Print and reverse feed

Select an international character set

Turn unidirectional printing mode on/off

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

ESC c 5

ESC d

ESC e

ESC p

ESC r

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Enable/disable panel buttons

Print and feed n lines

Print and reverse feed n lines

Generate pulse

Select print color

Paper roll TM-U230 supported commands

PANEL BUTTON COMMAND

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 51

CONFIDENTIAL

Command Classification Name Function type

ESC t

ESC {

GS ( A

GS I

GS V

GS a

GS r

GS z 0

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

SETTING COMMAND

Select character code table

Turn upside-down printing mode on/off

Execute test print

Transmit printer ID

Select cut mode and cut paper

Enable/disable Automatic Status Back (ASB)

Transmit status

Set online recovery wait time

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

MECHANISM CONTROL COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

Paper roll TM-U230 supported commands

Ver. 10.01 p. 52

CONFIDENTIAL

TM-U375 supported commands

TM-U300A/B SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

CR

ESC SP

ESC !

ESC %

ESC &

ESC ✻

ESC 2

ESC 3

ESC <

ESC @

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

Horizontal tab

Print and line feed

Print and carriage return

Set right-side character spacing

Select print mode(s)

Select/cancel user-defined character set

Define user-defined characters

Select bit-image mode

Select default line spacing

Set line spacing

Return home

Initialize printer

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

BIT-IMAGE COMMANDS

LINE SPACING COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

ESC D

ESC E

ESC G

ESC J

SETTING COMMAND

EXECUTING COMMAND

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Paper roll TM-U300A/B supported commands

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

Ver. 10.01 p. 53

CONFIDENTIAL

Command Classification Name Function type

ESC K

ESC R

ESC U

ESC c 3

ESC c 4

ESC c 5

ESC d

ESC e

ESC i

ESC m

ESC p

ESC r

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Print and reverse feed

Select an international character set

Turn unidirectional printing mode on/off

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

Enable/disable panel buttons

Print and feed n lines

Print and reverse feed n lines

Partial cut (one point left uncut)

Partial cut (three points left uncut)

Generate pulse

Select print color

PRINT COMMANDS

CHARACTER COMMANDS

MECHANISM CONTROL COMMANDS

PAPER SENSOR COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

ESC t

ESC u

ESC v

ESC {

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select character code table

Transmit peripheral device status

Transmit paper sensor status

Turn upside-down printing mode on/off

Paper roll TM-U300A/B supported commands

CHARACTER COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 54

CONFIDENTIAL

The following commands are supported only by Japanese/Simplified Chinese/Traditional Chinese/Korean supporting models.

Command Classification Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

SETTING COMMAND

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll TM-U300A/B supported commands

Ver. 10.01 p. 55

CONFIDENTIAL

TM-P60 supported commands

TM-P60 SUPPORTED COMMANDS

Command Classification Name Function type

HT

LF

FF (in page mode)

CAN

DLE EOT

DLE ENQ

DLE DC4 (fn = 2)

DLE DC4 (fn = 7)

DLE DC4 (fn = 8)

ESC FF

ESC SP

ESC $

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Horizontal tab

Print and line feed

Print and return to standard mode (in page mode)

Cancel print data in page mode

Transmit real-time status

Send real-time request to printer

Execute power-off sequence

Transmit specified status in real-time

Clear buffer (s)

Print data in page mode

Set right-side character spacing

Set absolute print position

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

ESC ( A

ESC –

EXECUTING + SETTING

SETTING COMMAND

Control beeper tones

Turn underline mode on/off

ESC 3

SETTING COMMAND

Set line spacing

Paper roll TM-P60 supported commands

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

Ver. 10.01 p. 56

CONFIDENTIAL

Command Classification Name Function type

ESC =

ESC @

ESC D

ESC E

ESC J

ESC L

ESC M

ESC R

ESC S

ESC T

ESC W

ESC \

SETTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

Select peripheral device

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Print and feed paper

Select page mode

Select character font

Select an international character set

Select standard mode

Select print direction in page mode

Set print area in page mode

Set relative print position

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

ESC a

ESC c 5

ESC d

ESC t

ESC {

GS !

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Select justification

Enable/disable panel buttons

Print and feed n lines

Select character code table

Turn upside-down print mode on/off

Select character size

Paper roll TM-P60 supported commands

PRINT POSITION COMMANDS

PANEL BUTTON COMMAND

PRINT COMMANDS

CHARACTER COMMANDS

Ver. 10.01 p. 57

CONFIDENTIAL

Command Classification Name Function type

GS $

GS ( C

GS ( D

GS ( E

GS ( H

GS ( L GS 8 L

GS ( M

GS ( K

GS B

GS H

GS I

GS L

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING + SETTING

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Set absolute vertical print position in page mode

Edit NV user memory

Enable/disable real-time command

Set user setup commands

Require response transmission

Set graphics data

Customize printer control value(s)

Select print control method(s)

Turn white/black reverse print mode on/off

Select print position of HRI characters

Transmit printer ID

Set left margin

PRINT POSITION COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

GS V

GS W

GS \

GS a

GS b

GS f

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

EXECUTING + SETTING

SETTING COMMAND

Select cut mode and cut paper

Set print area width

Set relative vertical print position in page mode

Enable/disable Automatic Status Back (ASB)

Turn smoothing mode on/off

Select font for HRI characters

Paper roll TM-P60 supported commands

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

BAR CODE COMMANDS

Ver. 10.01 p. 58

CONFIDENTIAL

Command Classification Name Function type

GS g 0

GS g 2

GS h

GS k

GS r

GS w

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

EXECUTING COMMAND

SETTING COMMAND

Initialize maintenance counter

Transmit maintenance counter

Set bar code height

Print bar code

Transmit status

Set bar code width

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

Paper roll TM-P60 supported commands

Ver. 10.01 p. 59

CONFIDENTIAL

Commands in alphanumeric order

COMMANDS IN ALPHANUMERIC ORDER

In this table, click any name to see the command description with program examples and print samples.

The print samples are images of the printing results of the program examples; they do not represent actual printing.

Command Name Function type

HT

LF

FF (in page mode)

FF (on label)

*

CR

CAN

DLE EOT

DLE ENQ

DLE DC4 (fn = 1)

DLE DC4 (fn = 2)

DLE DC4 (fn = 7)

DLE DC4 (fn = 8)

Horizontal tab

Print and line feed

Print and return to standard mode

Print and feed label to print starting position (on label)

Print and carriage return

Cancel print data in page mode

Real-time status transmission

Real-time request to printer

Generate pulse at real-time

Turn off the power

Transmit specified status in real time

Clear buffer

PRINT POSITION COMMANDS

PRINT COMMANDS

CHARACTER COMMANDS

STATUS COMMANDS

MISCELLANEOUS COMMANDS

ESC FF

ESC SP

Print data in page mode

Set right-side character spacing

Paper roll Commands in alphanumeric order

PRINT COMMANDS

CHARACTER COMMANDS

* obsolete command

Ver. 10.01 p. 60

CONFIDENTIAL

Command Name Function type

ESC !

ESC $

ESC %

ESC &

ESC ( A

ESC

*

ESC –

ESC 2

ESC 3

ESC <

ESC =

ESC ?

Select print mode(s)

Set absolute print position

Select/cancel user-defined character set

Define user-defined characters

Control of the beeper

Select bit-image mode

Turn underline mode on/off

Select default line spacing

Set line spacing

Return home

Select peripheral device

Cancel user-defined characters

CHARACTER COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

CHARACTER COMMANDS

LINE SPACING COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

ESC @

ESC D

ESC E

ESC G

ESC J

ESC K

Initialize printer

Set horizontal tab positions

Turn emphasized mode on/off

Turn double-strike mode on/off

Print and feed paper

Print and reverse feed

Paper roll Commands in alphanumeric order

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

CHARACTER COMMANDS

PRINT COMMANDS

Ver. 10.01 p. 61

CONFIDENTIAL

Command Name Function type

ESC L

ESC M

ESC R

ESC S

ESC T

ESC U

ESC V

ESC W

ESC \

ESC a

ESC c 3

ESC c 4

Select page mode

Select character font

Select an international character set

Select standard mode

Select print direction in page mode

Turn unidirectional printing mode on/off

Turn 90° clockwise rotation mode on/off

Set printing area in page mode

Set relative print position

Select justification

Select paper sensor(s) to output paper-end signals

Select paper sensor(s) to stop printing

MISCELLANEOUS COMMANDS

CHARACTER COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MECHANISM CONTROL COMMANDS

CHARACTER COMMANDS

PRINT POSITION COMMANDS

PAPER SENSOR COMMANDS

ESC c 5

ESC d

ESC e

ESC i

*

ESC m

*

ESC p

Enable/disable panel buttons

Print and feed n lines

Print and reverse feed n lines

Partial cut (one point left uncut)

Partial cut (three points left uncut)

Generate pulse

Paper roll Commands in alphanumeric order

PANEL BUTTON COMMAND

PRINT COMMANDS

MECHANISM CONTROL COMMANDS

MISCELLANEOUS COMMANDS

* obsolete command

Ver. 10.01 p. 62

CONFIDENTIAL

Command Name Function type

ESC r

ESC t

ESC u

*

ESC v

*

ESC {

FS !

FS &

FS ( A

FS ( L

FS –

FS .

FS 2

Select print color

Select character code table

Transmit peripheral device status

Transmit paper sensor status

Turn upside-down printing mode on/off

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters.

Control of the label paper / black mark paper

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

CHARACTER COMMANDS

STATUS COMMANDS

CHARACTER COMMANDS

KANJI COMMANDS

PRINTING PAPER COMMANDS

KANJI COMMANDS

FS C

FS S

FS W

FS ?

FS g 1

*

FS g 2

*

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

Write to NV user memory

Read from NV user memory

Paper roll Commands in alphanumeric order

KANJI COMMANDS

CUSTOMIZE COMMANDS

* obsolete command

Ver. 10.01 p. 63

CONFIDENTIAL

Command Name Function type

FS p

*

FS q

*

GS FF

*

Print NV bit image

Define NV bit image

Print and eject label

BIT-IMAGE COMMANDS

PRINT COMMANDS

GS !

GS $

GS ( A

GS ( C

GS ( D

GS ( E

GS ( H

GS ( K

GS ( L GS 8 L

GS ( M

GS ( N

GS ( k

Select character size

Set absolute vertical print position in page mode

Execute test print

Edit NV user memory

Enable/disable real-time command

User setup commands

Require response transmission

Select printing control

Specify graphics data

Customize printer control value(s)

Select character effects

Specify and print the symbol

CHARACTER COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

CUSTOMIZE COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

CUSTOMIZE COMMANDS

CHARACTER COMMANDS

TWO DIMENSION CODE COMMANDS

GS

*

GS /

*

GS :

GS <

*

Define downloaded bit image

Print downloaded bit image

Start/end macro definition

Initialize printer mechanism

Paper roll Commands in alphanumeric order

BIT-IMAGE COMMANDS

MACRO FUNCTION COMMANDS

MISCELLANEOUS COMMANDS

* obsolete command

Ver. 10.01 p. 64

CONFIDENTIAL

Command Name Function type

GS A

*

Adjust label print starting position

MISCELLANEOUS COMMANDS

GS B

GS C 0

*

GS C 1

*

GS C 2

*

GS C ;

*

GS E

*

GS H

GS I

GS L

GS P

GS Q 0

*

GS T

Turn white/black reverse printing mode on/off

Select counter print mode

Select count mode (A)

Select counter print mode

Select counter mode (B)

Select head control method

Select printing position of HRI characters

Transmit printer ID

Set left margin

Set horizontal and vertical motion units

Print variable vertical size bit image

Set print position to the beginning of print line

CHARACTER COMMANDS

COUNTER PRINTING COMMANDS

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

PRINT POSITION COMMANDS

MISCELLANEOUS COMMANDS

BIT-IMAGE COMMANDS

PRINT POSITION COMMANDS

GS V

GS W

GS \

GS ^

GS a

Select cut mode and cut paper

Set printing area width

Set relative vertical print position in page mode

Execute macro

Enable/disable Automatic Status Back (ASB)

Paper roll Commands in alphanumeric order

MECHANISM CONTROL COMMANDS

PRINT POSITION COMMANDS

MACRO FUNCTION COMMANDS

STATUS COMMANDS

* obsolete command

Ver. 10.01 p. 65

CONFIDENTIAL

Command Name Function type

GS b

GS c

*

GS f

GS g 0

GS g 2

GS h

GS j

GS k

GS r

GS v 0

*

GS w

GS z 0

Turn smoothing mode on/off

Print counter

Select font for HRI characters

Initialize maintenance counter

Transmit maintenance counter

Set bar code height

Enable/disable Ink Automatic Status Back (ASB)

Print bar code

Transmit status

Print raster bit image

Set bar code width

Set online recovery wait time

CHARACTER COMMANDS

COUNTER PRINTING COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BAR CODE COMMANDS

STATUS COMMANDS

BIT-IMAGE COMMANDS

BAR CODE COMMANDS

MISCELLANEOUS COMMANDS

Paper roll Commands in alphanumeric order

* obsolete command

Ver. 10.01 p. 66

CONFIDENTIAL

The following commands are supported only by Simplified Chinese/Traditional Chinese/Korean/Japanese models.

Command Name Function type

FS !

FS &

FS ( A

FS –

FS .

FS 2

FS C

FS S

FS W

FS ?

Set print mode(s) for Kanji characters

Select Kanji character mode

Define character effects of Kanji characters

Turn underline mode on/off for Kanji characters

Cancel Kanji character mode

Define user-defined Kanji characters

Select Kanji character code system

Set Kanji character spacing

Turn quadruple-size mode on/off for Kanji characters

Cancel user-defined Kanji characters

KANJI COMMANDS

Paper roll Commands in alphanumeric order

Ver. 10.01 p. 67

CONFIDENTIAL

The following commands are obsolete commands and will not be supported by future printer models. More suitable substitute commands are listed to the right.

Command Name Function type Substitute command

FF (on label)

ESC i

ESC m

ESC u

ESC v

FS g 1

FS g 2

FS p

Print and feed label to print starting position (on label)

Partial cut (one point left uncut)

Partial cut (three points left uncut)

Transmit peripheral device status

Transmit paper sensor status

Write to NV user memory

Read from NV user memory

Print NV bit image

PRINT COMMANDS FS ( L

MECHANISM CONTROL COMMANDS GS V

STATUS COMMANDS GS r

CUSTOMIZE COMMANDS GS ( C

BIT-IMAGE COMMANDS GS ( L GS 8 L

obsolete commands

FS q

GS FF

GS

*

GS /

GS <

GS A

GS C 0

GS C 1

Define NV bit image

Print and eject label

Define downloaded bit image

Print downloaded bit image

Initialize printer mechanism

Adjust label print starting position

Select counter print mode

Select count mode (A)

Paper roll Commands in alphanumeric order

BIT-IMAGE COMMANDS GS ( L GS 8 L

PRINT COMMANDS FS ( L

BIT-IMAGE COMMANDS GS ( L GS 8 L

MISCELLANEOUS COMMANDS GS ( A

MISCELLANEOUS COMMANDS GS ( E

COUNTER PRINTING COMMANDS NONE

Ver. 10.01 p. 68

CONFIDENTIAL

Command Name Function type Substitute commands

GS C 2

GS C ;

GS E

GS Q 0

GS c

GS v 0

Select counter print mode

Select counter mode (B)

Select head control method

Print variable vertical size bit image

Print counter

Print raster bit image

COUNTER PRINTING COMMANDS NONE

MISCELLANEOUS COMMANDS GS ( K

BIT-IMAGE COMMANDS GS ( L

COUNTER PRINTING COMMANDS NONE

BIT-IMAGE COMMANDS GS ( L

obsolete commands

Paper roll Commands in alphanumeric order

Ver. 10.01 p. 69

CONFIDENTIAL

Commands arranged by function

COMMANDS ARRANGED BY FUNCTION

Click any item to see the commands in that category.

Print commands

Line spacing commands

Character commands

Panel button command

Paper sensor commands

Print position commands

Bit-image commands

Status commands

Bar code commands

Macro function commands

Mechanism control commands

Miscellaneous commands

Kanji commands

Two dimension code commands

Customize commands

Counter printing commands

Printing paper commands

Paper roll Commands arranged by function

Ver. 10.01 p. 70

CONFIDENTIAL

Print commands

PRINT COMMANDS

Command Name

LF Print and line feed

FF (in page mode) Print and return to standard mode (in page mode)

FF (on label) Print and feed label to print starting position (on label)

CR Print and carriage return

ESC FF Print data in page mode

ESC J Print and feed paper

ESC K Print and reverse feed

ESC d Print and feed n lines

ESC e Print and reverse feed n lines

GS FF Print and eject label

Paper roll Print commands

Ver. 10.01 p. 71

CONFIDENTIAL

Print commands

LF

[Name] Print and line feed [Format] ASCII LF

Hex 0A

Decimal 10 [Range] None [Default] None [Printers not featuring this command] None [Description] Prints the data in the print buffer and feeds one line, based on the current line spacing. [Notes]

■ The amount of paper fed per line is based on the value set using the line spacing command (ESC 2 or ESC 3).

■ After printing, the print position moves to the beginning of the line. When a left margin is set in standard mode, the position of the left margin is the beginning of the line.

■ When this command is processed in page mode, only the print position moves, and the printer does not perform actual printing.

EXECUTING COMMAND

[Model-dependent variations] TM-L90, TM-L60II

Program Example for all printers Print Sample

PRINT #1, "AAAAA"; CHR$(&HA); AAAAA PRINT #1, "BBBBB"; CHR$(&HA); BBBBB

Paper roll Print commands LF

Ver. 10.01 p. 72

CONFIDENTIAL

TM-L90

When the origin of layout is selected to bottom of label or top of black mark in standard mode and a paper feed amount that exceeds the remaining printable area of the label is sent, the printer executes one of the following:

■ If the printer will print a line that is higher than the remaining printable area of the label, the printer feeds the label to the next print starting position and the printer executes this command.

■ If the printer will print in the remaining printable area of the label, but the feed amount exceeds the remaining printable area of the label, the printer prints the label and feeds to bottom of the label.

TM-L60II

When label paper is selected in standard mode and a paper feed amount that exceeds the remaining print area of the label is sent, the printer feeds the label to the next print starting position.

Paper roll Print commands LF

Ver. 10.01 p. 73

CONFIDENTIAL

Print commands

FF (in page mode)

[Name] Print and return to standard mode (in page mode) [Format] ASCII FF

Hex 0C

Decimal 12 [Default] None [Range] None [Printers not featuring this command] TM-U230, TM-U220, TM-U210, TM-U300A/B [Description] In page mode, prints all the data in the print buffer collectively and switches from page mode to standard

mode. [Notes]

■ This command is enabled only in page mode. See FF (in standard mode) to use this command in standard mode. Page mode can be selected by ESC L or FS L.

■ The data is deleted in the print area after being printed.

■ This command returns the values set by ESC W to the default values.

EXECUTING COMMAND

■ The value set by ESC T is maintained.

■ After printing, the print position moves to the beginning of the line. When a left margin is set, the

position of the left margin is the beginning of the line.

Paper roll Print commands FF (in page mode)

Ver. 10.01 p. 74

CONFIDENTIAL

[Model-dependent variations] None

Program Example for all printers Print Sample

PRINT #1, CHR$(&H1B);"L"; ←Select page mode PRINT #1, CHR$(&H1D);"P";CHR$(180);CHR$(180); PRINT #1, CHR$(&H1B);"W";CHR$(0);CHR$(0);CHR$(0);

CHR$(0);CHR$(60);CHR$(0);CHR$(90);CHR$(0); PRINT #1, CHR$(&H1B);"T";CHR$(0); PRINT #1, "AAAAA"; CHR$(&HA); ←Store characters for printing PRINT #1, "BBBBB"; CHR$(&HA); ←Store characters for printing PRINT #1, "CCCCC"; CHR$(&HC); ←Batch print

AAAAA BBBBB CCCCC

Paper roll Print commands FF (in page mode)

Ver. 10.01 p. 75

CONFIDENTIAL

Print commands

obsolete command

FF (on label)

EXECUTING COMMAND

[Name] Print and feed label to print starting position (on label) [Format] ASCII FF

Hex 0C

Decimal 12 [Default] None [Range] None [Printers not featuring this command] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-P60, TM-U230, TM-U220,

TM-U210, TM-U300A/B

[Description] Prints the data in the print buffer and feeds paper to the print starting position on the next label. [Recommended Functions]

This command is an obsolete command that is supported only by some printer models and may not be

supported by future models.

FS ( L is recommended for controlling labels. With the following procedure, that command can perform the

same as this command.

1. Using LF, the printer prints the last line of a label.

2. Using FS ( L <Function 67, (m = 49)>, execute the paper feed to the print start position of the next label.

[Notes]

■ This command is enabled only when a label is selected in standard mode. Printer operation differs when page mode is selected.

■ After printing, the print position moves to the beginning of the line. When a left margin is set, the position of the left margin is the beginning of the line.

■ Method of specifying label paper differs, depending on the printer models.

Paper roll Print commands FF (on label)

Ver. 10.01 p. 76

CONFIDENTIAL

[Model-dependent variations] TM-L60II

Program Example for all printers Print Sample

TM-L60II

A thermal label is selected when DIP switch 2-6 is ON with a serial interface.

A thermal label is selected when DIP switch 1-7 is ON with a parallel interface.

PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&HC);

AAAAA BBBBB

Paper roll Print commands FF (on label)

Ver. 10.01 p. 77

CONFIDENTIAL

Print commands

CR

[Name] Print and carriage return [Format] ASCII CR

Hex 0D

Decimal 13 [Range] None [Default] None [Printers not featuring this command] TM-P60 [Description] Executes one of the following operations.

Print head When auto line feed is enabled When auto line feed is disabled

Line thermal Executes printing and one line feed as LF This command is ignored

Serial dot head Executes printing and one line feed as LF In standard mode, prints the data in the

EXECUTING COMMAND

print buffer and moves the print position to the beginning of the print line.

In page mode, moves the print position to the beginning of the print line.

[Notes]

■ With a serial interface, the command performs as if auto line feed is disabled.

■ With a parallel interface, enabling or disabling the auto line feed can be selected by the DIP switch or the

memory switch. Memory switch can be changed with GS (E <Function3>.

■ After printing, the print position moves to the beginning of the line. When a left margin is set in standard mode, the position of the left margin is the beginning of the line.

■ When this command is processed in page mode, only the print position moves, and the printer does not perform actual printing.

Paper roll Print commands CR

Ver. 10.01 p. 78

CONFIDENTIAL

[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-L60II, TM-U230, TM-U220,

TM-U210, TM-U300A/B

Program Example (Line thermal) Print Sample (Line thermal)

AAAAA ←Auto line feed enabled

PRINT #1, "AAAAA";CHR$(&HD); BBBBB PRINT #1, " BBBBB";CHR$(&HA); AAAAA BBBBB ←Auto line feed disabled

Program Example (Serial dot head) Print Sample (Serial dot head)

AAAAA

PRINT #1, "AAAAA";CHR$(&HD); BBBBB ←Auto line feed enabled PRINT #1, " BBBBB";CHR$(&HA); AAAAABBBBB ←Auto line feed disabled

TM-J2000/J2100

Auto line feed for a parallel interface is selected by Memory switch 1-5.

This printer has only a serial dot head.

TM-T90

Auto line feed for a parallel interface is selected by Memory switch 1-5.

This printer has only a line thermal head.

TM-T88III

Auto line feed for a parallel interface is selected by DIP switch 1-1.

This printer has only a line thermal head.

Paper roll Print commands CR

Ver. 10.01 p. 79

CONFIDENTIAL

TM-L90

Auto line feed for a parallel interface is selected by Memory switch 1-5.

This printer has only a line thermal head.

TM-L60II

Auto line feed for a parallel interface is selected by DIP switch 1-1.

This printer has only a line thermal head.

TM-U230

Auto line feed for a parallel interface is selected by DIP switch 1-1.

This printer has only a serial dot head.

TM-U210, TM-U220

Auto line feed for a parallel interface is selected by DIP switch 1-1.

This printer has only a serial dot head.

TM-U300A/B

Auto line feed for a parallel interface is selected by DIP switch 1-1.

This printer has only a serial dot head.

Paper roll Print commands CR

Ver. 10.01 p. 80

CONFIDENTIAL

Print commands

ESC FF

[Name] Print data in page mode [Format] ASCII ESC FF

Hex 1B 0C

Decimal 27 12 [Range] None [Default] None [Printers not featuring this command] TM-U230, TM-U220, TM-U210, TM-U300A/B [Description] In page mode, prints the data in the print buffer collectively. [Notes]

■ This command is enabled only in page mode. Page mode can be selected by ESC L.

■ After printing, the printer does not clear the buffered data, the print position, or values set by other

commands.

■ The printer returns to standard mode with FF, ESC S, and ESC @. When it returns to standard mode by ESC @, all settings are canceled.

EXECUTING COMMAND

■ This command is used when the data in page mode is printed repeatedly.

[Model-dependent variations] None

Program Example for all printers Print Sample

PRINT #1, CHR$(&H1B);"L"; ← Select page mode PRINT #1, CHR$(&H1D);"P";CHR$(180);CHR$(180); PRINT #1, CHR$(&H1B);"W";CHR$(0);CHR$(0);CHR$(0);

CHR$(0);CHR$(120);CHR$(0);CHR$(170);CHR$(0); PRINT #1, CHR$(&H1B);"T";CHR$(0); ← Select print direction PRINT #1, "AAAAA"; CHR$(&HA); ← Store characters for printing PRINT #1, "BBBBB"; CHR$(&HA); ← PRINT #1, "CCCCC"; CHR$(&H1B);CHR$(&HC); ← PRINT #1, CHR$(&HC); ←

Batch print and return to standard mode

Store characters for printing

Batch print

Paper roll Print commands ESC FF

AAAAA BBBBB CCCCC

Ver. 10.01 p. 81

CONFIDENTIAL

Print commands

ESC J

[Name] Print and feed paper [Format] ASCII ESC J

Hex 1B 4A Decimal 27 74

[Range] 0 ≤ n ≤ 255 [Default] None [Printers not featuring this command] None [Description] Prints the data in the print buffer and feeds the paper n × (vertical or horizontal motion unit). [Notes]

■ The maximum paper feed amount is 1016 mm {40 inches}. If the specified amount exceeds 1016 mm {40 inches}, the paper feed amount is automatically set to 1016 mm {40 inches}.

■ When standard mode is selected, the vertical motion unit is used.

■ When page mode is selected, the vertical or horizontal motion unit is used for the print direction set by

ESC T.

n n n

EXECUTING COMMAND

• When the starting position is set to the upper left or lower right of the print area using ESC T, the

vertical motion unit is used.

• When the starting position is set to the upper right or lower left of the print area using ESC T, the

horizontal motion unit is used.

■ After printing, the print position moves to the beginning of the line. When a left margin is set in standard mode, the position of the left margin is the beginning of the line.

■ When this command is processed in page mode, only the print position moves; the printer does not perform actual printing.

■ This command is used to temporarily feed a specific length without changing the line spacing set by other commands.

Paper roll Print commands ESC J

Ver. 10.01 p. 82

CONFIDENTIAL

[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-P60, TM-L60II, TM-U230,

TM-U220, TM-U210, TM-U300A/B

Program Example for all printers Print Sample

PRINT #1, CHR$(&H1D);"P";CHR$(180);CHR$(180); PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&H1B);"J";CHR$(100); PRINT #1, "CCCCC"; CHR$(&HA); PRINT #1, "DDDDD"; CHR$(&HA);

TM-J2000/J2100

The vertical or horizontal motion unit is specified by GS P.

TM-T90

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the specified paper feed amount, the paper is fed the amount of the character height. For example, if a paper feed of 30 dots is specified with ESC J, but the character height is 48 dots, the paper is fed 48 dots.

The amount of paper feed of the Japanese model can be specified up to 900 mm {35.4 inches}. When an amount of paper feed that exceeds the maximum value is specified, the paper feed of the maximum amount is executed.

TM-T88III

The vertical or horizontal motion unit is specified by GS P.

AAAAA BBBBB

CCCCC

DDDDD

ESC J used to print one line and advance the paper by 100/180 inch

In standard mode, if the character height is greater than the specified paper feed amount, the paper is fed the amount of the character height. For example, if a paper feed of 30 dots is specified with ESC J, but the character height is 48 dots, the paper is fed 48 dots.

Paper roll Print commands ESC J

Ver. 10.01 p. 83

CONFIDENTIAL

TM-L90

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the specified paper feed amount, the paper is fed the amount of the character height. For example, if a paper feed of 30 dots is specified with ESC J, but the character height is 48 dots, the paper is fed 48 dots.

When the origin of layout is selected to bottom of label or top of black mark in standard mode and a paper feed amount that exceeds the remaining printable area of the label is sent, the printer executes one of the following:

■ If the printer will print a line that is higher than the remaining printable area of the label, the printer feeds the label to the next print starting position and the printer executes this command.

■ If the printer will print in the remaining printable area of the label, but a feed amount that exceeds the remaining printable area of the labels is sent, the printer prints on the label and feeds to bottom of the label.

The amount of paper feed of the Japanese Kanji model can be up to 900 mm {35.4 inches}. When the amount of paper feed exceeding the maximum is specified, the maximum paper feed is executed.

TM-L60II

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the specified paper feed amount, the paper is fed the amount of the character height. For example, if a paper feed of 30 dots is specified with ESC J, but the character height is 48 dots, the paper is fed 48 dots.

When label paper is selected in standard mode and a paper feed amount that exceeds the length of one label is sent, the printer feeds the label to the next print starting position.

Paper roll Print commands ESC J

Ver. 10.01 p. 84

CONFIDENTIAL

TM-P60

The vertical or horizontal motion unit is approximately 0.125 mm {1/203 inches}. This value equals one dot pitch.

In standard mode, if the character height is greater than the specified paper feed amount, the paper is fed the amount of the character height. For example, if a paper feed of 30 dots is specified with ESC J, but the character height is 48 dots, the paper is fed 48 dots.

TM-U230

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because the printer does not support page mode.

TM-U220, TM-U210

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because the printer does not support page mode.

TM-U300A/B

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because the printer does not support page mode.

Paper roll Print commands ESC J

Ver. 10.01 p. 85

CONFIDENTIAL

Print commands

ESC K

[Name] Print and reverse feed [Format] ASCII ESC K

Hex 1B 4B Decimal 27 75

[Range] TM-U230, TM-U220, TM-U210: 0 ≤ n ≤ 48 [Default] None [Printers not featuring this command] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-P60, TM-L60II,

[Description] Prints the data in the print buffer and feeds the paper n × (vertical motion unit) in the reverse direction. [Notes]

■ The maximum paper feed amount depends on the printer model.

■ After printing, the print position moves to the beginning of the line. When a left margin is set, the

position of the left margin is the beginning of the line.

■ When standard mode is selected, the vertical motion unit is used.

n n n

TM-U300A/B

EXECUTING COMMAND

■ When page mode is selected, the vertical or horizontal motion unit is used for the print direction set by ESC T.

• When the starting position is set to the upper left or lower right of the print area using ESC T, the

vertical motion unit is used.

• When the starting position is set to the upper right or lower left of the print area using ESC T, the

horizontal motion unit is used.

■ When this command is processed in page mode, only the print position moves; the printer does not perform actual printing.

■ This command is used to temporarily feed a specific length without changing the line spacing set by other commands.

Paper roll Print commands ESC K

Ver. 10.01 p. 86

CONFIDENTIAL

[Model-dependent variations] TM-U230, TM-U210

Program Example for all printers Print Sample

PRINT #1, CHR$(&H1D);"P";CHR$(180);CHR$(180); PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&H1B);"K";CHR$(30); PRINT #1, " CCCCC"; CHR$(&HA);

TM-U230

This command must not be executed consecutively more than two times. The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. In the reverse direction, the maximum paper feed amount is 8.467 mm {48/144 inch}. If the specified amount exceeds 8.467 mm {48/144 inch}, the printer only prints the data and does not feed the paper.

TM-U220, TM-U210

This command must not be executed consecutively more than two times.

Reverse direction paper feeding causes the following problems:

■ Paper feed pitch is incorrect.

■ Printer noise is louder than normal.

■ The paper may rub against the ribbon and become dirty.

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. In the reverse direction, the maximum paper feed amount is 8.467 mm {48/144 inch}. If the specified amount exceeds 8.467 mm {48/144 inch}, the printer only prints the data and does not feed the paper.

AAAAACCCCC BBBBB

ESC K used to print one line and then reverse feed the paper by 30/180 inch

Paper roll Print commands ESC K

Ver. 10.01 p. 87

CONFIDENTIAL

Print commands

ESC d

[Name] Print and feed n lines [Format] ASCII ESC d

Hex 1B 64 Decimal 27 100

[Range] 0 ≤ n ≤ 255 [Default] None [Printers not featuring this command] None [Description] Prints the data in the print buffer and feeds n lines. [Notes]

■ The amount of paper fed per line is based on the value set using the line spacing command (ESC 2 or ESC 3).

■ The maximum paper feed amount is 1016 mm {40 inches}. If the specified amount exceeds 1016 mm {40 inches}, the paper feed amount is automatically set to 1016 mm {40 inches}.

■ After printing, the print position moves to the beginning of the line. When a left margin is set in standard mode, the position of the left margin is the beginning of the line.

n n n

EXECUTING COMMAND

■ When this command is processed in page mode, only the print position moves, and the printer does not perform actual printing.

■ This command is used to temporarily feed a specific line without changing the line spacing set by other commands.

Paper roll Print commands ESC d

Ver. 10.01 p. 88

CONFIDENTIAL

[Model-dependent variations] TM-T90, TM-L90, TM-L60II

Program Example for all printers Print Sample

TM-T90

The amount of paper feed of the Japanese Kanji model can specify even 900 mm or less {35.4 inches}. When the amount of paper feed which exceeds the maximum value is specified, the paper feed of the maximum amount is executed.

TM-L90

When the label paper or the black mark paper is selected in standard mode and a paper feed amount that exceeds the remainder print area of the label, the printer feeds the label to the next print starting position.

The amount of paper feed can specify up to 900 mm {35.4 inches}. When the amount of paper feed which exceeds the maximum value is specified, the paper feed of the maximum amount is executed.

PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&H1B);"d";CHR$(6); PRINT #1, "CCCCC"; CHR$(&HA);

AAAAA BBBBB

ESC d used to print one line and advance the paper by six lines

CCCCC

TM-L60II

When the label paper or the black mark paper is selected in standard mode and a paper feed amount that exceeds the remainder print area of the label, the printer feeds the label to the next print starting position.

Paper roll Print commands ESC d

Ver. 10.01 p. 89

CONFIDENTIAL

Print commands

ESC e

[Name] Print and reverse feed n lines [Format] ASCII ESC e

Hex 1B 65 Decimal 27 101

[Range] TM-U230: 0 ≤ n ≤ 2

TM-U220, TM-U210: 0 ≤ n ≤ 2

[Default] None [Printers not featuring this command] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-L60II, TM-P60,

[Description] Prints the data in the print buffer and feeds n lines in the reverse direction. [Notes]

■ The amount of paper fed per line is based on the value set using the line spacing command (ESC 2 or ESC 3).

■ The maximum paper feed amount depends on the printer model.

■ After printing, the print position moves to the beginning of the line. When a left margin is set, the

position of the left margin is the beginning of the line.

n n n

TM-U300A/B

EXECUTING COMMAND

■ When this command is processed in page mode, only the print position moves, and the printer does not perform actual printing.

■ This command is used to temporarily feed a specific line without changing the line spacing set by other commands.

[Model-dependent variations] TM-U230, TM-U220, TM-U210

Program Example for all printers Print Sample

PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&H1B);"e";CHR$(1); PRINT #1, " CCCCC"; CHR$(&HA);

AAAAACCCCC BBBBB

Paper roll Print commands ESC e

Paper reverse fed one line after printing the line of Bs

Ver. 10.01 p. 90

CONFIDENTIAL

TM-U230

This command must not be executed consecutively more than two times. In the reverse direction, the maximum paper feed amount is 8.467 mm {48/144 inch}. If the specified amount exceeds

8.467 mm {48/144 inch}, the printer only prints the data and does not feed the paper.

TM-U220, TM-U210

This command must not be executed consecutively more than two times. Reverse direction paper feeding causes the following problems:

■ Paper feed pitch is incorrect.

■ Printer noise is louder than normal.

■ The paper may rub against the ribbon and become dirty.

In the reverse direction, the maximum paper feed amount is 8.467 mm {48/144 inch}. If the specified amount exceeds 8.467 mm {48/144 inch}, the printer only prints the data and does not feed the paper.

Paper roll Print commands ESC e

Ver. 10.01 p. 91

CONFIDENTIAL

Print commands

obsolete command

GS FF

EXECUTING COMMAND

[Name] Print and eject label [Format] ASCII GS FF

Hex 1D 0C

Decimal 29 12 [Default] None [Range] None [Printers not featuring this command] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-P60, TM-U230, TM-U220,

TM-U210, TM-U300A/B

[Description] Prints the data in the print buffer, and ejects the label and feeds paper to the print starting position on the

next label. [Recommended Functions]

This command is an obsolete command that is supported only by some printer models and may not be

supported by future models.

FS(L is recommended for controlling labels. With the following procedure, that command can perform the

same as this command.

1. Using LF, the printer prints the last line of a label.

2. Using FS(L <function 65, (m = 49)>, execute the paper feed to the peeling position of the next label.

3. After label peeling, using FS(L <function 67, (m = 50)> feeds the paper to the print start position of the current label.

[Notes]

■ This command is enabled only when a label is selected.

■ This command is enabled only when standard mode is selected.

■ When the label is advanced, the following processes are performed:

• After printing, the label is advanced so that it can be peeled off.

• The paper LED blinks waiting for the paper feed button to be pressed (press the button after peeling

the label off).

Paper roll Print commands GS FF

Ver. 10.01 p. 92

CONFIDENTIAL

• When the paper feed button is pressed, the next label is fed in reverse direction to the print starting

position. When a left margin is set, the print position is set to the left margin.

■ When panel buttons are disabled by ESC c 5, the paper feed button is enabled temporarily when the paper LED blinks to indicate that the printer is waiting for the paper feed button to be pressed (but a label cannot be fed).

■ Methods of specifying label paper differ, depending on the printer models.

[Model-dependent variations] TM-L60II

Program Example for all printers Print Sample

TM-L60II

The paper LED blinks while the printer is waiting for a label to be peeled off. The paper feed button is used for feeding a label.

A thermal label is selected when DIP switch 2-6 is ON with a serial interface.

A thermal label is selected when DIP switch 1-7 is ON with a parallel interface.

PRINT #1, "AAAAA"; CHR$(&HA); PRINT #1, "BBBBB"; CHR$(&H1D);CHR$(&HC); PRINT #1, "CCCCC"; CHR$(&HA);

AAAAA BBBBB

CCCCC

Paper roll Print commands GS FF

Ver. 10.01 p. 93

CONFIDENTIAL

Line spacing commands

LINE SPACING COMMANDS

Command Name

ESC 2 Select default line spacing ESC 3 Set line spacing

Paper roll Line spacing commands

Ver. 10.01 p. 94

CONFIDENTIAL

Line spacing commands

ESC 2

[Name] Select default line spacing [Format] ASCII ESC 2

Hex 1B 32

Decimal 27 50 [Range] None [Default] None [Printers not featuring this command] TM-P60 [Description] Sets the line spacing to the “default line spacing.” [Notes]

■ The line spacing can be set independently in standard mode and in page mode.

• In standard mode this command sets the line spacing of standard mode.

• In page mode this command sets the line spacing of page mode.

■ Selected line spacing is effective until ESC 3 is executed, ESC @ is executed, the printer is reset, or the power is turned off.

SETTING COMMAND

[Model-dependent variations] TM-U230, TM-T88III, TM-L60II, TM-L90, TM-J2000/J2100, TM-T90, TM-U210,

TM-U220, TM-U300A/B

See program example and print sample for ESC 2 and ESC 3.

TM-J2000/J2100

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 30 dots.

TM-T90

The default line spacing except Japanese characters is about 4.23 mm {1/6 inch}, which is equivalent to 30 dots.

The default line spacing for Japanese characters is about 3.75 mm {30/203 inch}, which is equivalent to 30 dots.

Paper roll Line spacing commands ESC 2

Ver. 10.01 p. 95

CONFIDENTIAL

When the maximum character height exceeds 30 dots in one line, printer feeds the paper amount of height of the character when changing lines in the standard mode.

TM-T88III

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 30 dots.

When the maximum character height exceeds 30 dots in one line, the printer will feed the amount of paper equal to the height of the character when changing lines in standard mode.

TM-L60II

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 30 dots.

When the maximum character height exceeds 30 dots in one line, the printer will feed the amount of paper equal to the height of the character when changing lines in standard mode.

TM-L90

The default line spacing is about 3.75 mm (30/203 inch), which is equivalent to 30 dots.

When the maximum character height exceeds 30 dots in one line, the printer will feed the amount of paper equal to the height of the character when changing lines in standard mode.

TM-U230

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 12 dots.

TM-U210, TM-U220

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 12 dots.

TM-U300A/B

The default line spacing is about 4.23 mm {1/6 inch}, which is equivalent to 12 dots.

Paper roll Line spacing commands ESC 2

Ver. 10.01 p. 96

CONFIDENTIAL

Line spacing commands

ESC 3

[Name] Set line spacing [Format] ASCII ESC 3

Hex 1B 33 Decimal 27 51

[Range] 0 ≤ n ≤ 255 [Default] TM-P60: n = 30

Printers other than the above: Amount of line spacing which corresponds to “default line spacing.” (See

ESC 2 for the default line spacing.) [Printers not featuring this command] None [Description] Sets the line spacing to n × (vertical or horizontal motion unit). [Notes]

■ The maximum line spacing is 1016 mm {40 inches}. If the specified amount exceeds 1016 mm {40 inches}, the line spacing is automatically set to 1016 mm {40 inches}.

■ When standard mode is selected, the vertical motion unit is used.

■ When page mode is selected, the vertical or horizontal motion unit is used for the print direction set by

ESC T.

n n n

SETTING COMMAND

• When the starting position is set to the upper left or lower right of the print area using ESC T, the

vertical motion unit is used.

• When the starting position is set to the upper right or lower left of the print area using ESC T, the

horizontal motion unit is used.

■ The line spacing can be set independently in standard mode and in page mode.

• In standard mode this command sets the line spacing of standard mode.

• In page mode this command sets the line spacing of page mode.

■ When the motion unit is changed after the line spacing is set, the line spacing setting does not change.

■ Selected line spacing is effective until ESC 2 is executed, ESC @ is executed, the printer is reset, or the

power is turned off.

Paper roll Line spacing commands ESC 3

Ver. 10.01 p. 97

CONFIDENTIAL

[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-T88III, TM-L60II, TM-L90, TM-P60, TM-U230,

TM-U220, TM-U210, TM-U300A/B

Program example for ESC 2 and ESC 3

Program Example Print Sample

PRINT #1, CHR$(&H1D);"P";CHR$(180);CHR$(180); FOR n=25 TO 50 STEP 5 PRINT #1, CHR$(&H1B);"3";CHR$(n); ← Set line spacing PRINT #1, "AAAAA"; CHR$(&HA); NEXT n

PRINT #1, CHR$(&H1B);"2"; ← Set the default PRINT #1, "BBBBB"; CHR$(&HA); PRINT #1, "CCCCC"; CHR$(&HA);

TM-J2000/J2100

The vertical or horizontal motion unit is specified by GS P.

TM-T90

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the line spacing specified by this command, the paper is fed the amount of the character height. For example, if a line spacing of 30 dots is specified with this command, but the characters used are double height Font A (48 dots), the paper is fed 48 dots.

AAAAA AAAAA

AAAAA

BBBBB CCCCC

25/180-inch line spacing 30/180-inch line spacing 35/180-inch line spacing

40/180-inch line spacing 45/180-inch line spacing

50/180-inch line spacing

1/6-inch line spacing

The amount of paper feed that the Japanese model can specify is up to 900 mm {35.4 inches}. When an amount of paper feed exceeding the maximum value is specified, the maximum paper feed is executed.

Paper roll Line spacing commands ESC 3

Ver. 10.01 p. 98

CONFIDENTIAL

TM-T88III

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the line spacing specified by this command, the paper is fed the amount of the character height. For example, if a line spacing of 30 dots is specified with this command, but the characters used are double height Font A (48 dots), the paper is fed 48 dots.

The amount of paper feed of the Japanese Kanji model can specify up to 900 mm {35.4 inches}. When the amount of paper feed which exceeds the maximum value is specified, the paper feed of the maximum amount is executed.

TM-L60II

The vertical or horizontal motion unit is specified by GS P.

TM-L90

The vertical or horizontal motion unit is specified by GS P.

In standard mode, if the character height is greater than the line spacing specified by this command, the paper is fed the amount of the character height. For example, if a line spacing of 30 dots is specified with this command, but the characters used are double height Font A (48 dots), the paper is fed 48 dots.

The amount of paper feed can specify up to 900 mm {35.4 inches}. When the amount of paper feed which exceeds the maximum value is specified, the paper feed of the maximum amount is executed.

TM-P60

The vertical or horizontal motion unit is approximately 0.125 mm {1/203 inches}. This value equals one dot pitch.

In standard mode, if the character height is greater than the line spacing specified by this command, the paper is fed the amount of the character height. For example, if a line spacing of 30 dots is specified with this command, but the characters used are double height Font A (48 dots), the paper is fed 48 dots.

Paper roll Line spacing commands ESC 3

Ver. 10.01 p. 99

CONFIDENTIAL

TM-U230

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because this printer does not support page mode.

The default value is (n = 24).

TM-U220, TM-U210

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because this printer does not support page mode.

The default value is (n = 24).

TM-U300A/B

The vertical motion unit is 0.176 mm {1/144 inch}. This value equals a half dot pitch. This command does not use the horizontal motion unit because this printer does not support page mode.

The default value is (n = 24).

Paper roll Line spacing commands ESC 3

Ver. 10.01 p. 100

Epson TM-L90, TM-L60II, TM-U210, TM-U230, TM-P60 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Commands arranged by function
