arranty and Service:

Elna's superior reputation was established in 194

0 with the

production of its first sewing machine. Ever since, Elna has continued to be a leading

brand of home sewing and related equipment especially designed with the innovative

sewer in mind. T

housands of prof

essionals worldwide provide expert service. Millions of

people have c

hosen Elna for its quality, performance and reliability.

LABEL - 398012-02 - Pr

nted i

n Switz

land / Subjec

t to change without notice

www

.elna.com

CARRYING

S Y STEM

A sturdy, two part

wheeled storage

system transports and

stores the Xquisit I

and its components.

The upper case holds

the embroidery unit,

while the lower case

holds the Xquisit II.

The pockets are great

for books, foot control,

cords, supplies.

Everything all in

one place !

4 HOOPS –

WHICH TO USE

Based on the size

of the design, use the

mallest hoop possible.

The Xquisit II lets you

know if you choose a

hoop that's too small

or if you attach the

wrong hoop.

Xquisit II

achine features

• Fully automated threading – from spool through needle eye

• Full-color LCD screen

• Updatability via www.elna.com

• On-screen instruction manual

• Hint messages

• Personalized machine function settings

• Adjustable sewing speed up to 850 spm

• Multiple languages

• Automatic thread tension – computer system automatically releases correct

thread amount for ultimate stitch performance

• Needle thread and bobbin thread sensors

• Presser foot lever sensor

• Automatic thread cutter key – programmable

• Start/stop key – for embroidery and traditional sewing

• Up/down needle key

• Dual lights – eliminate shadows

• Extra presser foot lift

•

Serial port for direct PC hookup

•

Extensive selection of standard accessories

•

3 accessory storage areas

• Foot control with retractable cord

•

Storage bag – two-part, wheeled

Embroidery •

Fully automated bobbin winding – free embroidery bobbin thread spool included

features

• Extra large embroidery area (24 x 14 cm / 9 1/2 " x 5 1/2")

• Feed dog automatically lowers when embroidery unit is attached

• Multiple hooping – plots points on-screen for alignment of 2 or more large hoopings

• Wide array of built-in designs including Continuous Hoop designs

• On-screen layout, alignment grid turns on and off

• 6 alphabets – resize in 1 mm increments

• Rotate (in 1

° increments), mirror image, change size and spacing

• Easy embroidery editing

• 32 permanent memories – up to 120 characters and letters in each

• Temporary embroidery memory restarts where left off

• Power failure function for embroidery

• Hoops included

- 3 standard hoops – large, medium, small

- Continuous Hoop – embroider borders with special quick-clamp hoop

• Embroidery Cards (optional)

•

Continuous Hoop Border Embroidery Card included

• Xpressive software (optional)

raditional sewing

•

320+ stitc

hes, including 12 buttonholes

features • Choice heirloom and quilt stitches

• Directional feed patterns – larger than 7 mm with no hoop

• Directional sewing – forward, backward, left, right without pivoting

•

5 alphabets, 7 mm – 25 mm

• Lockstitch – programmable

• Maximum stitch width 7 mm

• Maximum stitch length 5 mm (basting – 20 mm)

• Elongation – satin stitches up to 5 times original length

•

2 color – certain stitc

hes alternate needle and b

obbin threads on right side of fabric

• Size – change from small to medium to large

• Mirror image and face to face

•

Cascade – 6 c

hoices arrange stitc

hes in steps rather than in a straight line

• Direct editing – edit any stitch within a sequence

• 20 permanent memories – up to 120 characters and letters in each

• Strong needle penetration on all fabrics

• Free arm

• Adjustable foot pressure

•

nee lifter

Exhilarating, extraordinary,

ever-expanding

o matter where you are in your journey through life, the versatile Xquisit II is there by your side. As you've experi-

enced, sewing renews your spirit and lets you express yourself in many ways, whether it's embroidery, wearable art,

quilting, couture, bridal, heirloom, western wear, carnival, home decor. Just start with a length of fabric or purchase

something and add your own special touch. Let your creativity take over; the machine will do the rest.

otally automated threading, automatic bobbin winding, hoop sensors, hint messages, plan-ahead thread color

organizer, updatable software – these are just a few of the numerous benefits when you choose Elna. In a world filled

with choices when it comes to sewing and embroidery, there's only one choice – the Elna Xquisit II.

on't be left behind.

Things are changing so quickly that updatability

is a must in today's world. Simply go to

www.elna.com to locate the latest upgrades.

et's be honest

–

threading can be a chore, especially

because of that tiny needle eye.

Not anymore! One touch threads

the machine from spool

through needle.

Oh, no - the bobbin thread

ran out during embroidery!

Watch - the Xquisit II stops, winds

the bobbin automatically and

begins sewing again exactly

where it stopped.

Have you heard?

Use Elna's continuous hoop

and continuous designs to create

beautiful borders effortlessly.

The V-shaped mark gives you

a precise st

art point for each

design repeat.

Ever lose your embroidery data?

If the X

quisit II is shut off during

embroidery, either deliberately

or accidentally, the data is saved

and you can resume sewing

exactly where you left off.

Where are those scissors?

Don't bother searching –

when embroidering, the Xquisit II automatically

cuts the thread for color c

hanges. And when

sewing traditionally

, the threads are cut leaving

the ends the proper length to start again.

Need a little reminder?

The on-screen manual gives you

sewing hints and instructions,

troubleshooting tips,

machine us

age

information, all right

at your fingertips.

Hidden in plain sight.

The top accessory storage gives you quick

access to the most often used

feet and the foot holder.
