D-Link DMC-300SC operation manual
10/100BASE-TX to
100BASE-FX
Media Converter
User’s Guide
Rev. 01 (JUN. 2002)
1907M110MM16003
RECYCLABLE
TABLE
OF CONTENTS
TABLE OF CONTENTS ... 2
INTRODUCTION ............. 3
A
BOUT MEDIA CONVERTER
P
RODUCT FEATURES
.....................................3
...............................................3
INSTALLATION............... 4
S
ELECTING A SITE FOR THE EQUIPMENT
C
ONNECTING TO POWER
S
LIDING SWITCH
C
ONNECTING TO POWER
I
NSTALLING IN A CHASSIS
LED I
NDICATOR
.......................................................5
.......................................................7
.........................................5
.........................................6
........................................6
...................4
SPECIFICATIONS ........... 8
2
RECYCLABLE
Rev. 01 (Jan. 2002)
6012-9600128
1907M110MM16001
Printed In Taiwan
I
NTRODUCTION
Thank you for choosing the 10/100BASE Fast Ethernet
Media Converter, The Converter introduced here
provides one channel media conversion between
10/100BASE-TX and 100BASE-FX.
About Media Converter
The Media Converter is a network technology specified
by IEEE 802.3 10BASE-T, IEEE802.3u 100BASE-TX,
100BASE-FX standards.
Product Features
One-channel media conversion between
10/100BASE-TX and 100BASE-FX
Fiber media allows: multi-mode fiber using SC,
LC or MT-RJ connector; single-mode fiber using
SC connector
Auto negotiation of speed and duplex mode on TX
port
Auto MDI-X on TX port
One slide switch for configuring fixed half/full
duplex modes
Store-and-forward mechanism
Back-pressure & IEEE802.3x compliant flow
control
Full wire-speed forwarding rate
Front panel status LEDs
Used as a stand-alone device or with a chassis
Hot-swappable when used with a chassis
3
