D-Link DCS-930-A2 User Manual
USER MANUAL
DCS-930
VERSION 1.0
2D-Link DCS-930 User Manual
Table of Contents
Product Overview ........................................................ 4
Package Contents ...................................................4
System Requirements .............................................4
Introduction ..............................................................5
Features ..................................................................6
Hardware Overview ................................................. 7
Front View ..........................................................7
Rear View ..........................................................8
Installation ....................................................................9
Hardware Installation ...............................................9
Wireless Installation Considerations ...................... 10
Starting the Camera Installation Wizard ................ 11
WPS - Hardware Push Button Setup ............... 12
Conguration ............................................................. 13
Using the Conguration Menu ............................... 13
Live Video ........................................................ 15
Setup > Wizard ................................................15
Internet Connection Setup Wizard .............. 16
Network Setup ............................................18
Setup > Wireless ..............................................19
Wireless Interface ....................................... 19
Setup > DDNS ................................................20
Setup > Image Setup ....................................... 21
Image Settings ............................................ 21
Setup > Video ..................................................22
Video Conguration ....................................22
Setup > Audio ..................................................23
Setup > Motion Detect .....................................24
Setup > Mail ..................................................... 25
Email Account ............................................. 25
Time Schedule ............................................ 26
Setup > FTP .....................................................27
FTP Server .................................................27
Time Schedule ............................................ 28
Setup > Time and Date .................................... 29
Maintenance > Admin ...................................... 30
Maintenance > System ....................................31
Maintenance > Firmware Upgrade ..................32
Status > Device Info .........................................33
Status > Active User ........................................34
Using & Conguring the DCS-930 ......................... 35
Wireless Security.......................................................38
What is WEP? .......................................................38
What is WPA? .......................................................39
Using & Conguring the DCS-930 with a NAT
Router .............................................................. 40
Troubleshooting ........................................................ 47
Table of Contents
3D-Link DCS-930 User Manual
Table of Contents
Wireless Basics ......................................................... 49
Networking Basics ....................................................54
Check your IP address ..........................................54
Statically Assign an IP address .............................55
Technical Specications........................................... 56
4D-Link DCS-930 User Manual
Section 1 - Product Overview
• DCS-930 Network Camera
• CAT5 Ethernet Cable
• Power Adapter
• Manual and Software on CD
• Quick Install Guide
• Camera Stand
Note: Using a power supply with a different voltage than the one included with your
product will cause damage and void the warranty for this product.
If any of the above items are missing, please contact your reseller.
System Requirements
• Computer with Microsoft Windows® 7, XP®, or Vista
®
• PC with 1.3GHz or above; at least 128MB RAM
• Internet Explorer 6 or above , Firefox 3.5 or above, Safari 4
• Existing 10/100 Ethernet-based network or 802.11n wireless network
Product Overview
Package Contents
5D-Link DCS-930 User Manual
Section 1 - Product Overview
Introduction
Congratulations on your purchase of the DCS-930 Network Camera. The DCS-930 is a versatile and unique solution for your small
ofce or home. Unlike a webcam, the DCS-930 is a stand-alone system with a built-in CPU that transmits high quality video images
for monitoring. The DCS-930 can be remotely accessed, and controlled using a Web browser over the Intranet or Internet. The simple
installation procedure and intuitive Web-based interface offer easy integration with your Ethernet/Fast Ethernet or 802.11n wireless
network. The DCS-930 also comes with remote monitoring capability for a complete and cost-effective home security solution.
