D Link DBT320A1 User Manual

This product works with Bluetooth enabled PC with the following operating systems: Windows 98SE, Me, 2000, and XP.

Personal

DBT-320

™

Air

Bluetooth USB Printer Adapter

Before You Begin

You must have at least the following:

• Bluetooth Enabled PC Supporting HCRP and SPP Bluetooth Profiles for Printing, Bluetooth Enabled Mobile Phone, or Bluetooth enabled PDA.

• USB Printer* with One Available Type B USB Port.

(*PCL3 Printer is required for Printing from Cell Phone or PDA)

Check Your Package Contents

These are the items included with your purchase: If any of the below items are missing, please contact your reseller.

DBT-320 Bluetooth USB Printer Adapter

Wall Mount Cradle

Using a power supply

AC Power Adapter

respective holders. Software and specifications subject to change without notice. DBT-320. 03052004

with a different voltage rating will damage this product and void the warranty.

Installing the DBT-320

Plug the DBT-320 Type B USB connector into the Type B USB port located on the back of your printer.

Using the included power adapter, connect the yellow coded plug to the yellow power connector port on the DBT-320 and the other end of the power connector to an available power strip or outlet.

The DBT-320 Bluetooth USB Printer Adapter set up is now complete! You will now be able to enjoy wireless printing from your cell phone, PDA, laptop, or computer with the DBT-320 Bluetooth USB Printer Adapter.

DBT-320 LED Indicators

Power Indicator

Bluetooth Link Indicator

The DBT-320 features two LED indicators, the Ready LED and the BT LED.

• The Ready LED indicator will light solid green when the DBT-320 is

powered on with the external power adapter. When the printer is powered on, a blinking green Ready LED indicates a successful printer connection.

• The BT Indicator will blink green when a file is being sent to the printer from a

laptop, computer, PDA, or cell phone.

Printing from your Laptop/PC using the DBT-320

Your Bluetooth enabled laptop or computer will have Bluetooth software that will enable you to connect to the DBT-320 printer adapter. The instructions on the following page are based on a D-Link DBT-120 USB Bluetooth adapter used with a PC running Windows XP with Widcomm Bluetooth Software v1.4.2.10. Depending on the Bluetooth setup on your system, the installation procedure may vary slightly.
