Denon DMV-3700 User Manual

DVD VIDEO AUTO CHANGER
DVM-3700
OPERATING INSTRUCTIONS MODE D’EMPLOI
POWER
ON / STANDBY
HDCD AL24
MAX
PHONES LEVEL
PHONES
PCM AUDIO TECHNOLOGY / DVD VIDEO AUTO CHANGER
DVM-3700
¢
OFF
£
B
5 DVD Video Automatic Disc Loading System
STILL / PAUSE
STOP
SLOW / SEARCH
SKIP
RANDOM REPEAT
DISC SKIP
CONTROL
OPEN / CLOSEPLAY
DISC 1
DISC 2
DISC 3
DISC 4
DISC 5
B
8967
31
REMOTE CONTROL UNIT RC-542
SELECT
TITLE
MENU
DISPLAY
RETURN
SUBTITLE
AUDIO ANGLE
MARKER
45
3
DISC SKIP 1 2
RANDOM
SET UP
REPEAT A-B REPEAT
CALL
PROG/DIRECT
POWER
OPEN/CLOSE
243
78
56
1
0 CLEAR910
FL DISPLAY
V.S.S.
CONTROL2STOP
SLOW/SEARCH
PLAY
STILL/PAUSE
-
SKIP
-
REMOTE SENSOR
FOR ENGLISH READERS PAGE 06 ~ PAGE 062 POUR LES LECTEURS FRANCAIS PAGE 63 ~ PAGE 119
2
IMPORTANT TO SAFETY
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
1. Handle the power supply cord carefully
Do not damage or deform the power supply cord. If it is damaged or deformed, it may cause electric shock or malfunction when used. When removing from wall outlet, be sure to remove by holding the plug attachment and not by pulling the cord.
2. Do not open the top cover
In order to prevent electric shock, do not open the top cover. If problems occur, contact your DENON DEALER.
3. Do not place anything inside
Do not place metal objects or spill liquid inside the DVD video player. Electric shock or malfunction may result.
Please, record and retain the Model name and serial number of your set shown on the rating label. Model No. DVM-3700 Serial No.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PESONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
NOTE:
This DVD video player uses the semiconductor laser. To allow you to enjoy music at a stable operation, it is recommended to use this in a room of 5°C (41°F) — 35°C (95°F).
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR REFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
FOR U.S.A. & CANADA MODEL ONLY
CAUTION
TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
POUR LES MODELES AMERICAINS ET
CANADIENS UNIQUEMENT
ATTENTION
POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN PROLONGATEUR UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
3
ENGLISH FRANCAIS
FRONT PANEL PANNEAU AVANT
REAR PANEL PANNEAU ARRIERE
POWER
ON / STANDBY
HDCD AL24
MIN
MAX
PHONES LEVEL
PHONES
PCM AUDIO TECHNOLOGY / DVD VIDEO AUTO CHANGER
DVM-3700
¢
OFF
£
B
5 DVD Video Automatic Disc Loading System
STILL / PAUSE
STOP
SLOW / SEARCH
SKIP
RANDOM REPEAT
DISC SKIP
CONTROL
OPEN / CLOSEPLAY
q
e
w
r
y
t
u
i
!8
!7!3!1!5
o !0 !2 !4 !6
DISC 1
DISC 2
DISC 3
DISC 4
DISC 5
!9@0@1@2
REMOTE SENSOR
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE
CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
@3 @4 @55 @6 @7@8 #0
@9 #1 #2
4
SAFETY INSTRUCTIONS
1. Read Instructions – All the safety and operating instructions should be read before the appliance is operated.
2. Retain Instructions – The safety and operating instructions should be retained for future reference.
3. Heed Warnings – All warnings on the appliance and in the operating instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Water and Moisture – The appliance should not be used near water – for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.
6. Carts and Stands – The appliance should be used only with a cart or stand that is recommended by the manufacturer.
6A. An appliance and cart
combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.
7. Wall or Ceiling Mounting – The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation – The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.
9. Heat – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.
10. Power Sources – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.
11. Grounding or Polarization – Precautions should be taken so that the grounding or polarization means of an appliance is not defeated.
12. Power-Cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
14. Cleaning – The appliance should be cleaned only as recommended by the manufacturer.
15. Power Lines – An outdoor antenna should be located away from power lines.
16. Outdoor Antenna Grounding – If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure A.
17. Nonuse Periods – The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.
18. Object and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.
19. Damage Requiring Service – The appliance should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been
damaged; or
B. Objects have fallen, or liquid has been spilled into
the appliance; or C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or
exhibits a marked change in performance; or E. The appliance has been dropped, or the enclosure
damaged.
20. Servicing – The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL ELECTRICAL CODE
ANTENNA LEAD IN WIRE
GROUND CLAMP
ELECTRIC SERVICE EQUIPMENT
ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)
GROUNDING CONDUCTORS (NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
5
NOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION
• Avoid high temperatures. Allow for sufficient heat dispersion when installed on a rack.
• Eviter des températures élevées Tenir compte d’une dispersion de chaleur suffisante lors de l’installation sur une étagère.
• Keep the set free from moisture, water, and dust.
• Protéger l’appareil contre l’humidité, l’eau et lapoussière.
• Do not let foreign objects in the set.
• Ne pas laisser des objets étrangers dans l’appareil.
• Do not let insecticides, benzene, and thinner come in contact with the set.
• Ne pas mettre en contact des insecticides, du benzène et un diluant avec l’appareil.
• Never disassemble or modify the set in any way.
• Ne jamais démonter ou modifier l’appareil d’une manière ou d’une autre.
• Unplug the power cord when not using the set for long periods of time.
• Débrancher le cordon d’alimentation lorsque l’appareil n’est pas utilisé pendant de longues périodes.
* (For sets with ventilation holes)
• Do not obstruct the ventilation holes.
• Ne pas obstruer les trous d’aération.
• Handle the power cord carefully. Hold the plug when unplugging the cord.
• Manipuler le cordon d’alimentation avec précaution. Tenir la prise lors du débranchement du cordon.
ENGLISHFRANCAIS
Copyrights / Droits dauteur
2 It is prohibited by law to reproduce, broadcast, rent or play discs in public without the consent of the copyright holder.
2 La reproduction, la diffusion, la location, le prêt ou la lecture publique de ces disques sont interdits sans le consentement du détenteur des droits
d’auteur.
B
CAUTION:
At the bottom of the player there is shipping screw for use when the player is transported. Before using the player, turn the shipping screw (located under the player) counterclockwise and remove it. The player cannot start playing unless this screw is removed. Keep this screw for future use. When the player is going to be transported, remove the discs and close the disc tray. Turn off the power after “000 00 00” is displayed, then unplug the power cable from the outlet. Insert the shipping screw and turn clockwise. Tighten until secure.
ATTENTION:
Au-dessous du lecteur se trouve une vis de transport qui doit être utilisée pour transporter l’appareil. Avant d’utiliser le lecteur, dévissez cette vis de transport (située sous le lecteur) en tournant en sens inverse des aiguilles d’une montre et retirez-la. Le lecteur ne peut pas fonctionner tant que cette vis n’est pas enlevée. Conservez cette vis pour une utilisation ultérieure. Lorsque le lecteur va devoir être transporté, retirez les disques et fermer le tiroir à disque. Eteignez l’appareil après que
“000 00 00”
soit affiché, puis débranchez le câble d’alimentation de la prise.
Insérrez la vis de transport et vissez-là dans le sens des aiguilles d’une montre. Serrez à fond.
ENGLISH
6
— TABLE OF CONTENTS —
z
Features ……………………………………………………………6, 7
x
Discs …………………………………………………………………8
c
Cautions on Handling Discs ………………………………………9
v
Connections ……………………………………………………10~14
b
Part Names and Functions ……………………………………15, 16
n
Remote Control Unit …………………………………………17, 18
m
Loading Discs …………………………………………………19, 20
,
Playback ………………………………………………………21~25
.
Using the GUI Screens ………………………………………26~30
⁄0
Marking Scenes You Want to See Again ………………………31
Please check to make sure the following items are included with the main unit in the carton:
The DVM-3700 is DENON’s top grade DVD video auto changer equipped with the latest in digital technology. This includes AL 24 Processing, a newly developed analog waveform reproduction technology with sights on next generation media, as well as a multi 24-bit D/A converter with 96 kHz sampling compatibility taking maximum advantage of the high quality offered by AL 24 Processing.
1. Newly developed AL 24 Processing
(1) AL 24 Processing, an advanced version of conventional
APLHA Processing, is a newly developed analog waveform reproduction technology, and offers compatibility with the high number of bits and high sampling rates of next generation media. AL 24 Processing compensates the input digital data to reproduce the sound with analog waveforms as close as possible to those existing in nature and with 24-bit quality. The result is increased musical reproduction capabilities of reverberations, etc., at low levels, for a sound that seems to draw you into the concert hall.
(2) AL 24 Processing of course carries over Adaptive Line
Pattern Harmonized Algorithm & Automatic Low Pass Filter Harmonic Adjustment, the strong points of conventional ALPHA Processing. On the DVM-3700 these filters have been dramatically improved, resulting
⁄1
Playing Repeatedly ……………………………………………32, 33
⁄2
Playing Tracks in the Desired Order …………………………34, 35
⁄3
Playing the Tracks in Random Order ……………………………35
⁄4
100 CD Changer Control Function ………………………………36
⁄5
Using the Multiple Audio, Subtitle
and Angle Functions …………………………………………37~41
⁄6
Using the Menus ………………………………………………42, 43
⁄7
Changing the Default Settings ………………………………44~60
⁄8
Troubleshooting ……………………………………………………61
⁄9
Main Specifications
………………………………………………62
ACCESSORIES
4. Dolby Digital (AC-3) bitstream output compatibility (NOTE 1)
The DVM-3700 is compatible with Dolby Digital (AC-3) bitstream output. When a Dolby Digital (AC-3) decoder is connected, the three-dimensional sense and positioning of the sound is recreated extremely naturally, resulting in a strong sense of presence, as if you were in a movie theater or concert hall.
5.
®,
HDCD®(High Definition Compatible
Digital®) decoder (NOTE 2)
HDCD is an encoding/decoding technology that greatly reduces the distortion occurring at the time of digital recording while maintaining compatibility with the conventional CD format. HDCD allows 24-bit data to be converted into the 16-bit data of current CDs with no loss in sound quality. The use of this HDCD decoder makes it possible to achieve the high resolution and low distortion characteristic of HDCD when playing HDCD-compatible discs, and DENON’s digital technology optimizes the high sound quality possibilities of HDCD technology. Furthermore, normal CDs, DVDs and HDCD-compatible CDs are automatically identified, and the optimum digital signal processing for that type of disc is used.
6. DTS bitstream output compatibility (NOTE 3)
The DVM-3700 is compatible with DTS bitstream output, an optional audio format for DVD video. DTS sound can be enjoyed by connecting a commercially available DTS decoder and AV amplifier.
7. Advanced Virtual Surround Sound (V.S.S.) function
Even when just two front speakers are being used, the user can simply press the V.S.S. (Virtual Surround Sound) button during playback of a Dolby Digital DVD (2 channel and above) to provide a rear surround effect. (This does not work with DVD Karaoke discs. In addition, this effect may differ depending on the kind of DVD used.)
8. High picture quality thanks to a 10-bit video D/A converter
(1) The 8-bit/13.5 MHz brightness and color component
signals recorded on DVDs are expanded to 10-bit/27 MHz signals and requantized, leaving room to spare in the processing of the recorded signals to provide the beautiful pictures DVDs have to offer. Furthermore, color component video output terminals are provided for even more faithful reproduction of the colors.
(2) An array of picture quality modes yielded by digital
processing
Signal deterioration is kept to the minimum by processing the data as digital data. This feature can be used as the picture quality setting individually tailored for DVD playback.
Digital Cinema Mode Using the On-Screen Menu Icons enables the cinema mode, which is best for the playback of movie programs, to be selected.
ENGLISH
7
In addition, the picture quality best suited to the type of solftware programs concerned can be selected. In all, four picture quality modes are provided: normal, soft, fine and cinema.
User selection Using the On-Screen Menu Icons, the contrast, color hue, equalizer and brightness can be adjusted to suit your own preference.
Monitor selector Once the type of TV used [Standard (Direct View TV), CRT Projector, LCD Projector, Projection TV] has been selected when the initial setting operations are performed, the optimum picture quality for the type of TV concerned will be automatically selected.
9. Many convenient functions
(1) Multiple audio function
Selection of up to 8 audio languages. (The number of languages offered differs from DVD to DVD.)
(2) Multiple subtitle function
Selection of up to 32 subtitle languages. (The number of languages offered differs from DVD to DVD.)
(3) Multiple angle function
The angle of view can be changed. (For DVDs on which multiple angles are recorded.)
(4) GUI (Graphical User Interface) function
The on-screen display button on the remote control unit can be used to display player and disc information on the TV screen.
(5) Marker function
The positions of up to five scenes can be stored in the memory, so you can watch your favorite scenes whenever you want.
(6) Playback disable function
This function can be used to disable playback of DVDs you do not want children to watch.
NOTES:
1. Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Work. ©1992 – 1997 Dolby Laboratories, Inc. All rights reserved.
2.
®
, HDCD®, High Definition Compatible Digital
®
and Pacific Microsonics™ are either registered trademarks or trademarks of Pacific Microsonics, Inc. in the United States and/or other countries. HDCD system manufactured under license from Pacific Micorsonics, Inc. This product is covered by one or more of the following: In the USA: 5,479,168, 5,638,074, 5,640,161, 5,808,574, 5,838,274, 5,854,600, 5,864,311, 5,872,531, and in Australia: 669114. Other patents pending.
3. “DTS” is a trademark of Digital Theater Systems, Inc.
ENGLISH
8
2 Disc terminology
Titles and chapters (DVDs)
DVDs are divided into several large sections called “titles” and smaller sections called “chapters”. Numbers are allotted to these sections. These numbers are called “title numbers” and “chapter numbers”.
Tracks (video and music CDs)
Video and music CDs are divided into sections called “tracks”. Numbers are allotted to these sections. These numbers are called “track numbers”.
Playback control (video CDs)
Video CDs including the words “playback control” on the disc or jacket are equipped with a function for displaying menus on the TV screen for selecting the desired position, displaying information, etc., in dialog fashion. In this manual, playing video CDs using such menus is referred to “menu playback”. Video CDs with playback control can be used on the DVM-3700.
NOTE:
• This DVD video player is designed and
manufactured to respond to the Region Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD video player, this DVD video player cannot play this disc. The Region number for this DVD video player is
1.
1
For example:
Title 1
Title 2
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
For example:
Track 1
Track 2 Track 3
Track 4
Track 5
DISCS
2
• The types of discs listed on the table below can be used on the DVM-3700. The marks are indicated on the disc labels or jackets.
Usable
discs
DVD video
Video CD
CD
Mark
(logo)
Recorded
signals
Digital audio +
digital video
(MPEG2)
Digital audio +
digital video
(MPEG1)
Digital audio
Disc size
12 cm
8 cm
12 cm
8 cm
12 cm
8 cm
Maximum
recording time
Approx. 240
minutes per side
Approx. 480
minutes for both
sides
Approx. 80
minutes per side
Approx. 160
minutes for both
sides
74 minutes
20 minutes
74 minutes
20 minutes
2 The following types of discs cannot be played on the
DVM-3700:
DVD with Region No. other than “1” or “ALL”
Disc of PAL system
VSD
DVD+RW
DVD-ROM
CDV
CVD
DVD-R/DVD-RAM
CD-G
SVCD
CD-ROM
CD-R/RW
Divx Video Disc etc.
Do not try to play Photo CD or CD-R.
(Otherwise, data on the disc may be damaged.)
* If you attempt to play CD-R or photo CD, the data on the
disc may be damaged.
ENGLISH
9
CAUTIONS ON HANDLING DISCS
3
Discs
Only the discs including the marks shown on page 8 can be played on the DVM-3700. Note, however, that discs with special shapes (heart-shaped discs, hexagonal discs, etc.) cannot be played on the DVM-3700. Do not attempt to play such discs, as they may damage the player.
Holding Discs
Avoid touching the surface of discs when loading and unloading them.
Be careful not to get fingerprints on the signal surface (the side which shines in rainbow colors).
Cleaning Discs
2 Fingerprints or dirt on the disc may lower sound and picture
quality or cause breaks in playback. Wipe off fingerprints or dirt.
2 Use a commercially available disc cleaning set or a soft cloth to
wipe off fingerprints or dirt.
Wipe gently from the middle outwards.
Do not wipe with a circular motion.
NOTE:
• Do not use record spray or antistatic. Also do not use volatile chemicals such as benzene or thinner.
Cautions on Handling Discs
• Do not get fingerprints, grease or dirt on discs.
• Be especially careful not to scratch discs when removing them from their cases.
• Do not bend discs.
• Do not heat discs.
• Do not enlarge the center hole.
• Do not write on the labeled (printed) side with a ball-point pen or a pencil.
• Water droplets may form on the surface if the disc is moved suddenly from a cold place to a warm one. Do not use a hairdryer, etc., to dry the disc.
Cautions on Storing Discs
• Always eject discs after playing them.
• Keep discs in their cases to protect them from dust, scratches and warping.
• Do not put discs in the following places:
1. Places exposed to direct sunlight for long periods of time
2. Humid or dusty places
3. Places exposed to heat from heaters, etc.
Cautions on Loading Discs
• Only load one disc at a time. Loading one disc on top of another may result in damage or scratch the discs.
• Load 8 cm discs securely in the disc guide, without using an adapter. If the disc is not properly loaded, it may slip out of the guide and block the disc tray.
• Be careful not to let your fingers get caught when the disc tray is closing.
• Do not place anything but discs in the disc tray.
• Do not load cracked or warped discs or discs that have been fixed with adhesive, etc.
• Do not use discs on which the adhesive part of cellophane tape or glue used to attach the label is exposed, or discs with traces of tape or labels that have been peeled off. Such discs may get stuck inside the player, resulting in damage.
Record
spray
Thinner
Benzene
ENGLISH
10
CONNECTIONS
4
• Read the manuals of all the components when making connections.
• Keep the power cord unplugged until all connections have been completed.
• If the power is on when connections are made, noise may be generated and damage the speakers.
• Be sure to connect the left and right channels properly, L (left) to L, R (right) to R.
NOTES:
• Plug the power cord securely into the power outlet. Incomplete connection may result in noise.
• Binding the power cord together with connection cords may result in humming or noise.
• Plug in the power cord in the direction in which the sound is most to your liking.
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE
CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
VIDEO IN
AUDIO IN
L
R
S-VIDEO IN
(1) Connecting to an AV TV
• Use the included video/audio cord to connect the TV’s video input connectors and audio input connector to the DVM-3700’s video output connectors and audio output connector.
DVM-3700
S-Video output connector
The video signals are divided into color (C) and
brightness (Y) signals, achieving a clearer picture.
If the TV is equipped with an S-Video input
connector, we recommend connecting it to the
DVM-3700’s S-Video output connector using a
commercially available S-Video connection cord.
To power outlet
TV
Standard (Direct View TV) (See pages 10 and 11.)
Conventional TV set (4:3), Wide-screen TV set (16:9), Digital TV etc.
CRT projector (See pages 10 and 11.)
Cinema-size images can be enjoyed by projecting from three light sources onto a large screen.
LCD projector (See pages 10 and 11.)
Cinema-size images can be enjoyed by projecting from an LCD panel onto a large screen.
Projection TV (See pages 10 and 11.)
Powerful images can be enjoyed with a large rear screen projector.
Video equipment you own
ENGLISH
11
(2) Connecting to a TV or Monitor Equipped with Color Component Input Connectors
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE
CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
COMPONENT VIDEO IN
YCbCr
AUDIO IN
L
R
NOTE:
• Use three commercially available 75 /ohm pin-plug cord to connect the DVM-3700’s color component output connectors to the TV or monitor.
Color component output connectors (Cr, Cb and Y)
The red (Cr), blue (Cb) and brightness (Y) signals are output independently, achieving more faithful reproduction of
the colors.
• The color component input connectors may be marked differently on some TVs or monitors (Pr, Pb and Y/R-Y, B-
Y and Y/Cr, Cb and Y, etc.). For details, refer to the TV’s operating instructions.
DVM-3700
To power outlet
• Connect the DVM-3700’s video outputs to the TV either directly or through an AV amplifier. Do not connect it via a VCR (video cassette recorder).
NOTES:
• Some discs contain copy prohibit signals. If such discs are played via a VCR, the copy prohibit system may cause disturbance in the picture.
TV
ENGLISH
12
(3) Connecting to a Dolby Digital (AC-3) or DTS (digital theater systems) Decoder
When DVDs recorded in Dolby Digital or DTS are played, Dolby Digital or DTS bitstream signals are output from the DVD player’s digital audio output connectors. If a Dolby Digital or DTS decoder is connected, you can achieve sound with the power and sense of presence of a movie theater or concert hall.
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE
CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
VIDEO IN
2 Connecting an optical fiber cable (commercially available) to the digital audio input connector (OPTICAL)
NOTE:
• Store the dust cap in a safe place, and be careful not to lose it. When not using the terminal, attach the cap to protect the terminal from dust.
DVM-3700
TV
Digital audio input
connector (COAXIAL)
Front speaker (left)
Center speaker
Front speaker (right)
Digital audio input connector (OPTICAL)
Dolby Digital (AC-3) or DTS decoder (digital surround processor)
Subwoofer
Surround speaker (left)
AV amplifier
(AV control center)
Surround speaker (right)
Dust cap
Line up in proper direction
Remove the dust cap, line up the cable in the proper directly, then insert it securely as far as it goes.
ENGLISH
13
2 Sound output from the DVM-3700s digital audio output connectors
Disc played
DVD video
Audio recording format
Dolby Digital (AC-3)
Sound output
• Dolby Digital bitstream (1 to 5.1 channels) or PCM (48 kHz/16 bit) (2 channels). (NOTE 1, 2)
* Select with the “Digital Audio Output” default setting. (See page 56.)
DTS
• dts bitstream or no output.
* Select with the “Digital Audio Output” default setting. (See page 56.)
Linear PCM
48 kHz/96 kHz
16/20/24 bit
• Linear PCM (48 kHz/16 bit only) (2 channels) or no output. (NOTE 2)
* Select with the “Digital Audio Output” default setting. (See page 56.)
MPEG1 • PCM (44.1 kHz) (NOTE 1)
Video CD
Linear PCM • Linear PCM (44.1 kHz)CD
NOTE 1: The type of audio output from the connector can be selected by “7 Digital Audio Output” of the initial setting. (See page 56.) NOTE 2: Compressed audio is converted to PCM before output.
• Linear PCM audio is the signal recording format used for music CDs. While the signals are recorded at 44.1 kHz/16 bit for music CDs, for DVDs they are recorded at 48 kHz/16 bit to 96 kHz/24 bit, providing higher sound quality than music CDs.
(4) Connecting to a Digital Recorder (MD Recorder, DAT Deck, etc.)
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE
CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
89
B
VIDEO IN
* Set the “Digital Audio Output” default setting as shown below.
(See page 56.)
• “LPCM 96k / 48k” / “NO”
• “Dolby Digital” / “PCM”
• “dts” / “OFF” Playing DVDs with incorrect settings may result noise that could damage your ears or the speakers.
DVM-3700
TV
Digital audio input
connector (OPTICAL)
Digital audio input
connector (COAXIAL)
NOTE:
• Some dts decorders which do not support DVD- dts interface may not work properly with the DVD video auto changer.
ENGLISH
14
1
2
S-VIDEO OUT
COMPONENT
VIDEO OUT
VIDEO OUT
ANALOG OUT
DIGITAL OUT
(PCM/BITSTREAM)
REMOTE CONTROL
CONTROL
1
2
CrCbYLINOUT
OUT
COAXIAL
OPTICAL
R
VIDEO IN
(5) Connecting to a Stereo Component
DVM-3700
TV
Stereo component
NOTE:
• Use commercially available 75 /ohm pin-plug cord to connect the DVM-3700‘s video out connector to the TV or monitor.
ENGLISH
15
PART NAMES AND FUNCTIONS
5
(1) Front Panel
q
POWER button
• Press once to turn the power on.
• Press again to set to the “OFF” position and turn the power off.
• Set the power to the standby mode by pressing the POWER button on the remote control unit while the power is on.
• Turn the power on from the standby mode by pressing the POWER button on the remote control unit.
w
Power indicator
• This indicator lights when the power is on and when the power is in the standby mode.
e
CONTROL button
• Press this button to set the control mode. In the control mode, the separately sold 100 CD changer (DCM-5000/5001) can be operated using the buttons on the DVM-3700 or the included remote control unit (RC-542).
• The CONTROL OUT connector on the rear panel of the DVM­3700 must be connected to the REMOTE CONTROL IN connector on the separately sold 100 CD changer (DCM­5000/5001) in order to use this function.
r
RANDOM button
• Press this button to begin random play.
• Pressing this button during stop, and press play button play to full automatic random play.
• This button does not work when playing DVDs.
t
HDCD indicator
• This indicator lights when playing discs recorded in HDCD
®
format.
y
AL 24 indicator
• This indicator lights when the audio signals of a DVD, etc., are being processed digitally with the AL 24 processor, a newly developed analog waveform reproduction technology.
u
REPEAT button
• Press this button for repeated playback. (Refer to page 32 for details.)
i
DISC SKIP button
• Each time this button is pressed, the carousel will rotate in a clockwise direction to the next tray position. This allows for loading or unloading of discs.
• This button is also used to select the next disc, in the normal play continuously.
o
Remote control sensor (REMOTE SENSOR)
!0
Display
• Information on the disc that is currently playing is shown on the display. (See page 16.)
!1
SKIP button (8)
• Press this to move back to the beginning of the current track (or chapter).
• Press again to move back to the beginning of the previous track (or chapter).
!2
PLAY button (1)
• Press this to play the disc.
!3
SKIP button (9)
• Press this to move ahead to the beginning of the next track (or chapter).
!4
STILL/PAUSE button (3)
• Press this button to stop play temporarily.
!5
SLOW/SEARCH button (6)
• Press this button in the play mode to search in the reverse direction.
• Press the button in the still mode for slow play in the reverse direction.
(2) Rear Panel
!6
STOP button (2)
• Press this to stop the disc. (See page 23.)
!7
SLOW/SEARCH button (7)
• Press the button in the play mode to search in the forward direction.
• Press the button in the still mode for slow play in the forward direction.
!8
OPEN/CLOSE button (5)
• Press this button to open and close the disc tray.
!9
Disc number button (1~5)
• Press these button to specify which disc you want to play.
@0
Disc tray (1~5)
• Load discs here.
• Press the OPEN/CLOSE button !8 to open and close the disc tray.
• The disc tray is also closed when the PLAY button
!2 is
pressed.
@1
PHONES jack
• Use this to connect separately sold headphones.
@2
PHONES LEVEL control
• Use this to adjust the output level of the headphones jack.
@3
Video output connectors (VIDEO OUT)
• Connect using the included video cord.
@4
S-Video output connectors (S-VIDEO OUT)
• Connect using an S-Video connection cord (available in stores).
@5
Component video output connectors (COMPONENT)
• Connect using video cords (available in stores).
@6
ANALOG OUT connectors
• Connect these to the input connectors of an amplifier, etc., to hear the sound of the DVM-3700 over the speakers through the amplifier.
@7
Digital audio output connector (COAXIAL)
• Connect using an audio cord. Connect a commercially available 75 /ohms pin-plug cord.
• Digital data is output from this connector.
@8
Digital audio output connector (OPTICAL)
• Connect using an optical fiber cable (available in stores).
• Digital data is output from this connector.
@9
Remote control input connector (REMOTE CONTROL IN)
• This is the input connector for wired remote control. Consult your DENON dealer if you wish to use this connector.
#0
Remote control output connector (REMOTE CONTROL OUT)
• This is the output connector for wired remote control. Consult your DENON dealer if you wish to use this connector.
#1
Control output connector (CONTROL OUT)
• Connect with the REMOTE CONTROL IN connector of a separately sold 100 CD changer (DCM-5000/5001) to control the 100 CD changer from the DVM-3700.
#2
Power cord
• Plug this into a wall power outlet.
96 kHz Indicator
• Lights during playback of linear PCM sound with a sampling frequency of 96 kHz.
ENGLISH
16
(3) Display
Source Indicators
Play Indicator
Still/Pause Indicator
• The title/chapter number is displayed here for DVDs, the track number for video and music CDs.
• The title and elapsed track time are displayed here during playback.
These indicate the type of disc currently playing.
Angle Indicator
Random Indicator
Repeat Indicator
Program Indicator Music calendar
24 bit Indicator
• Lights during playback of 24­bit linear PCM sound.
Disc Indicator
• The number of the trays in which discs are loaded light.
• “ ” lights for tray numbers in which CDs and Video CDs are loaded.
• “ ” lights for tray numbers in which DVDs are loaded.
ENGLISH
17
REMOTE CONTROL UNIT
6
2 The DVM-3700 can be controlled from a distance using the included remote control unit (RC-542).
(1) Inserting Batteries
q Remove the remote control unit’s rear cover.
w Place two batteries (“AA” (R6P)) in the battery compartment in
the direction indicated by the marks.
e Close the rear cover.
Cautions On Batteries
• Use batteries (“AA” (R6P)) in this remote control unit.
• Replace the batteries with new ones approximately once a year, though this depends on the frequency with which the remote control unit is used.
• If the remote control unit does not operate from close to the main unit, replace the batteries with new ones, even if less than a year has passed.
• When inserting the batteries, be careful to do so in the proper direction, following the < and > marks in the remote control unit’s battery compartment.
• To prevent damage or battery fluid leakage:
• Do not use a new battery with an old one.
• Do not use two different types of batteries.
• Do not short-circuit, disassemble, heat or dispose of
batteries in flames.
• Remove the batteries when not planning to use the remote control unit for a long period of time.
• If the batteries should leak, carefully wipe off the fluid from the inside of the battery compartment, then insert new batteries.
(2) Using the Remote Control Unit
• When operating the remote control unit, point it at the remote control sensor as shown on the diagram.
• The remote control unit can be used from a direct distance of approximately 7 meters. This distance will be shorter, however, if there are obstacles in the way or if the remote control unit is not pointed directly at the remote control sensor.
• The remote control unit can be operated at a horizontal angle of up to 30° with respect to the remote control sensor.
B
8
9
6
7
3
1
B
30°
30°
Approx. 7 meters
NOTES:
It may be difficult to operate the remote control unit if the remote control sensor is exposed to direct sunlight or strong artificial light.
Do not press buttons on the main unit and on the remote control unit at the same time. Doing so will result in malfunction.
B
8967
31
REMOTE CONTROL UNIT RC-542
SELECT
TITLE
MENU
DISPLAY
RETURN
SUBTITLE
AUDIO ANGLE
MARKER
45
3
DISC SKIP 1 2
RANDOM
SET UP
REPEAT A-B REPEAT
CALL
PROG/DIRECT
POWER
OPEN/CLOSE
243
78
56
1
0 CLEAR910
FL DISPLAY
V.S.S.
CONTROL2STOP
SLOW/SEARCH
PLAY
STILL/PAUSE
-
SKIP
-
ENGLISH
18
(3) Names and Functions of Remote Control Unit Buttons
POWER button
Press this to switch the power between on and standby.
SKIP buttons
STOP button
Cursor buttons/SELECT button
Use the and ª buttons to select in the vertical direction. Use the
0 and 1 buttons to select in the
horizontal direction. Press the SELECT button to select the item selected with the cursor buttons.
SUBTITLE button
Press this to switch the DVDs subtitle language.
AUDIO button
For DVDs, press this to switch the audio language. For video CDs, press this to switch the channel between LR, “L” and “R”.
Number buttons
Use these to input numbers. Use the
10 button to input numbers of
10 or over. Example: To input 25
SET UP button
Press this to display the default setting screen.
FL DISPLAY button
Press this to display audio information on the currently playing disc on the fluorescent display.
STILL/PAUSE button
OPEN/CLOSE button
SLOW/SEARCH buttons
PLAY button
DISPLAY button
Press this to display the GUI screen.
MENU button
Press this to display the DVD menu recorded on the disc.
TITLE button
Press this to display the title menu recorded on the disc.
REPEAT button
ANGLE button
Press this to switch the angle.
MARKER button
Press this to mark places you want to see again.
PROG/DIRECT button
Press this to switch between the normal play, programmed play.
RETURN button
Press this to return to the previous menu screen.
A-B REPEAT button
Use this to repeat sections between two specific points.
CLEAR button
Press this to clear numbers that you have input.
DISC SKIP button
V.S.S. button
Sets the virtual surround sound. (Functions when playing DVDs recorded in Dolby Digital with two or more channels.)
CALL button
Press this to check the program contents.
RANDOM button
Disc Number button (1 ~ 5)
CONTROL button
ENGLISH
19
LOADING DISCS
7
2 Set discs in the disc tray with the labeled (printed) side facing up.
5 DVD Video Automatic Disc Loading System
8 cm disc guide
NOTES:
Do not move the DVM-3700 while a disc is playing. Doing so may scratch the disc.
For discs on which both sides can be played, load the disc with the side you want to play facing down.
(1) Opening and Closing the Disc Tray
q Turn on the power. w Press the OPEN/CLOSE button.
5 DVD Video Automatic Disc Loading System
Disc tray
NOTES:
Be sure to turn on the power before opening and closing the disc tray.
Do not strike on the button with a pencil, etc.
12 cm disc guide Disc tray
OPEN/CLOSE button
IMPORTANT SETUP INFORMATION
This set has the following presettings: “Disc Languages”, “Ratings”, “Menu Language”, “On-Screen Messages”, “FL Display”, “TV
Aspect, Digital Audio Output and Other Settings”. These presettings have been preset upon shipment from the factory. If you wish to change them to suit your specific purposes, refer to pages 44 to 60.
Loading...
+ 43 hidden pages
