Denon AVR-5800, AVC-A1SE Service Manual
Specifications and Main Features
a) Model: AVR-5800/AVC-GA1SE
b) Audio Section:
- Rated O/P of the power amplifiers:
- 170 W + 170 W at 8 ohms from the range of 20Hz to 20kHz, at 0.05% T.H.D
- 200 W + 200 W at 6 ohms from the range of 20Hz to 20kHz at 0.05 % T.H.D
- Dynamic power68 : 310 w at 4 ohms and 390 w at 2 ohms
- Frequency Response was measured to be anywhere from 10Hz to 100 kHz
- The signal-to-noise ratio is at a 105 dB (DIRECT mode).
- Maximum output range of 6-16 ohm for Front/Center amp and surround amp which is also 60-16 ohm
- To_iso level and impedance:
- 47K ohm at 200 mV
- Digital audio interface: Format – 2.5mv
- Rated Output: 2V(an estimated of 0db playing).
- Total Harmonic Distortion: H1 of 0.003% at 1 KHz and 0db.
Video Section:
- The rated S-Video Outputs are:
- Peaking at 1 Vp-p at 75 ohm for C/S-Video inputs and outputs.
- Color component video terminal:
- Y (brightness) signal - 1 Vp-peg at 75 ohm.
- Cb (blue) signal - 0.7 Vp-peg at 75 ohm
- Cr (red) signal - 0.7 Vp-pegs
Tuner Section (only for AVR-5800):
- The entire tuner range covers: 87.5 - 107.9 MHz
- A usable range of 1.0 μV (11.2 dBf)
- Total harmonic distortion started from 0.15 at mono and 0.3 when in stereo.
General:
- Power supply: AC 120 V, 60 Hz (Models designed for USA, Canada and Taiwan), AC 230 Volt, 50 Hz (Models for Europe and Asia), AC 220 Volt, 50 Hz (Chinese model).
- Power consumption: 720 W (Europe, Asia and China), 670 W (Taiwan).
- Size: 434 (width) x 216 (height) x 486 (depth) mm.
- Weight: 28 kg.
- Remote Control Unit:
- Model: RC-8000 for AVR-5800 and RC-871 for AVC-A1SE.
- Batteries: 4 pieces LR6/AA Type batteries.
- External dimensions: 96 (width) x 38 (height) x 168.5 (depth) mm.
- Weight: 242 grams (not including batteries).
