Delonghi ESAM6700 Instruction Manual

5713211231/07.08

MACCHINA PER CAFFÈ E CAPPUCCINO

Istruzioni per l’uso

ESAM6700

IT

FR

MACHINE À CAFÉ ET À CAPPUCCINO

Mode d'emploi

A23

A24

B4

B6

B5

B1

B2

B3

A

B

C

A1

A19

A20

A2

A5A4

A6

A7
A8

A13

A14

A12

A11

A15

A16A17A18

A21

A9

A10

Ready

espresso

C1C15 C16 C3

C4
C5

C2

C6C12

C13

C14

C7C8C10 C9C11

A22

A3

3

4

4

12 3

56

89101511

13 14

12

7

5

22

23

normal coffee

M

A
X

31

30

28

29

3

17 18 19

20 21

27

16

2624 25

6

32

33

34

35

36

40 41

37

38

39

42

INDEX....................................................................27

INTRODUCTION.................................................28

Symbols used in these instructions..................28

Letters in brackets ............................................28

Troubleshooting and repairs.............................28

SAFETY.................................................................28

Fundamental safety warnings ...........................28

Designated use .................................................29

Instructions.......................................................29

DESCRIPTION....................................................29

Description of appliance ...................................29

Description of milk container............................29

Description of control panel (touch screen) .....29

PRELIMINARY CHECKS .................................30

Controls after transport ....................................30

Installing the appliance.....................................30

Connecting the appliance..................................30

Setting up the appliance ...................................31

TURNING THE APPLIANCE ON....................31

TURNING THE APPLIANCE OFF ................31

CHANGING THE MENU SETTINGS.............32

Setting the language ........................................32

Setting the clock...............................................32

Setting auto-start time......................................32

Setting the temperature ....................................32

Setting auto-off.................................................33

Resetting default values (reset) ........................33

Statistics function.............................................33

Acoustic signal (Beep enabled).........................33

MAKING COFFEE .............................................33

Selecting the coffee taste..................................33

Selecting the quantity of coffee in the cup ......33

Programming the espresso "my coffee"

quantity ............................................................33

Programming the long "my coffee" quantity ....34

Regulating the coffee mill.................................34

Making espresso coffee using coffee beans .....34

Making long coffee using coffee beans ............34

Making espresso or long coffee using

pre-ground coffee.............................................35

MAKING DRINKS WITH MILK......................35

Filling and attaching the milk container ............35

Making caffelatte .............................................35

Making cappuccino...........................................36

Making macchiato ...........................................36

Making milk ......................................................36

Cleaning the milk container after use................36

Programming the quantities of coffee and

milk in the cup..................................................36

HOT WATER........................................................37

Preparation .......................................................37

Changing the quantity ......................................37

CLEANING ..........................................................37

Cleaning the coffee maker ................................37

Cleaning the coffee grounds container .............37

Cleaning the drip tray........................................38

Cleaning the water tank ....................................38

Cleaning the coffee nozzles...............................38

Cleaning the pre-ground coffee feed funnel......38

Cleaning the inside of the machine...................38

Cleaning the infuser..........................................38

Cleaning the milk container ..............................39

Cleaning the touch screen ...............................39

DESCALING.........................................................39

SETTING WATER HARDNESS ......................40

Measuring water hardness................................40

Setting water hardness.....................................40

TECHNICAL SPECIFICATION........................40

DISPOSAL ...........................................................40

DISPLAYED MESSAGES.................................41

TROUBLESHOOTING.......................................43

27GB28

INTRODUCTION

Thank you for choosing the ESAM 6700 automa­tic coffee and cappuccino maker.
We hope you enjoy using your new appliance.
Take a few minutes to read these instructions.
This will avoid all risks and damage to the machi­ne.

Symbols used in these instructions

Important warnings are identified by these
symbols.
These warnings must absolutely be respected.

Danger!

Failure to observe the warning could result in pos­sibly life threatening injury from electric shock.

Important!

Failure to observe the warning could result in
injury or damage to the appliance.

Danger of burns!

Failure to observe the warning could result in
scalds or burns.

N.B.:

This symbol identifies important advice or infor­mation for the user. .

Letters in brackets

The letters in brackets refer to the legend in the
description of the appliance on page 3.

Troubleshooting and repairs

In the event of problems, first try and resolve
them following the information given in the sec­tions "Displayed messages" on page 41 and
"Troubleshooting" on page 43.
If this does not resolve the problem or you requi­re further information, you should consult
Customer Services by calling the number given on
the annexed "Customer Service" sheet.
If your country is not among those listed on the
sheet, call the number given in the guarantee.
If repairs are required, contact De'Longhi custo­mer services only.
The addresses are given in the guarantee certifi­cate provided with the machine.

SAFETY

Fundamental safety warnings

Danger!

This is an electrical appliance

and may cause electric shock.
You should therefore respect the following safety

warnings:

• Never touch the appliance with damp hands.

• Never touch the plug with damp hands.

• Make sure the socket used is freely accessible
at all times, enabling the appliance to be
unplugged when necessary.

• Unplug directly from the plug only. Never pull
the power cable as you could damage it.

• To disconnect the appliance completely, place
the main switch at the back of the appliance in
the 0 position.

• If the appliance is faulty, do not attempt to
repair. Turn it off, unplug from the mains soc­ket and contact Customer Services.

• If the plug or power cable is damaged, it must
be replaced by De'Longhi customer services
only to avoid all risk.

Important!

Keep all packaging (plastic

bags, polystyrene foam) away from children.

Important!

Do not allow the appliance to
be used by persons (including children) with
psychological, physical or sensory impairments
or with inadequate experience or knowledge,
unless closely supervised and instructed by
someone responsible for their safety.
Children must be supervised to ensure they do
not play with the appliance.

Important: Risk of burns!

This appliance
produces hot water and steam may form while it
is in operation.
Avoid contact with splashes of water or hot
steam.
When the appliance is in operation, please be
aware that the cup warmer shelf (A7) becomes
hot.

29

Designated use

This appliance is designed and made to prepare
coffee and heat drinks.
All other use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deri­ving from improper use of the appliance.

Instructions

Read these instructions carefully before using the
appliance.

- Failure to follow these instructions may result
in burns or damage to the appliance.
The manufacturer is not liable for damage
deriving from failure to follow these instruc­tions.

N.B.:

Keep these instructions If the applian­ce is passed to other persons, they must also be
provided with these instructions.

DESCRIPTION

Description of appliance

(page 3 - A )

A1. Grinding coarseness regulator knob
A2. Container for coffee beans
A3. Main switch
A4. Bean container lid
A5. Cover for funnel and measure

compartment
A6. Measure compartment
A7. Cup warmer shelf
A8. Ground coffee feed funnel
A9. Display
A10. Touch screen (control panel)
A11. Hot water and steam nozzle
A12. Infuser
A13. Water tank
A14. Power cable
A15. Cup tray
A16. Drip tray
A17. Compartment for macchiato/caffelatte

glass
A18. Grounds tray
A19. Service door
A20. Coffee spout (adjustable height)
A21. Coffee guide
A22. ON/STAND-BY button
A23. Hot water spout
A24. Measure

Description of milk container

(page 3 - B )

B1. Milk frother pointer
B2. Milk container handle
B3. CLEAN button
B4. Milk intake tube
B5. Frothed milk spout
B6. Lid with milk frother

Description of control panel (touch
screen)

(page 3 - C )

N.B.! Only the icons relating to the con-

trols enabled for the particular function currently
being used will be lit on the touch screen.

C1. Display: guides the user in using the

appliance.
C2. icon: to scroll forwards through the

programming menu.
C3. icon: to deliver a cup of espresso

coffee.

GB

30

C4. icon: to deliver two cups of

espresso coffee.

C5. OK icon: to enable and confirm the

selected function.

C6. icon: to rinse or deliver hot

water.
C7. MILK icon: to deliver a cup of milk.
C8. LATTE MACCHIATO icon: to deliver a

cup of macchiato.
C9. LONG icon: to deliver one cup of

LONG coffee.
C10. CAPPUCCINO icon: to deliver a

cappuccino.
C11. CAFFELATTE icon: to deliver a

caffelatte.
C12. P icon: to access the programming

menu.
C13. ESC icon: to exit the selected function.
C14. icon: to select the coffee taste.
C15. icon: to select the coffee

quantity.
C16. icon: to scroll backwards

through the programming menu.

N.B.! A light touch is enough to activate

the icon.

PRELIMINARY CHECKS

Controls after transport

After removing the packaging, make sure the pro­duct is complete and undamaged and that all
accessories are present.
Do not use the appliance if it is visibly damaged.
Contact Customer Services.

Installing the appliance

Important!

When you install the appliance, you should follow
the safety warnings below:

• The appliance gives off heat. After positioning
the appliance on the work top, leave a space
of at least 3 cm between the surfaces of the
appliance and the side and rear walls and at
least 15 cm above the coffee maker.

• Water penetrating the appliance could cause
damage. Do not place the appliance near taps
or sinks.

• The appliance could be damaged if the water
it contains freezes. Do not install the applian­ce in a room where the temperature could
drop below freezing point.

• Arrange the power cable in such a way that it
cannot be damaged by sharp edges or contact
with hot surfaces (e.g. electric hot plates).

Connecting the appliance

Important!

Check that the mains power
supply voltage corresponds to the value indicated
on the rating plate on the bottom of the appliance.

Connect the appliance to an efficiently earthed and
correctly installed socket with a minimum current
rating of 10A only. If the power socket does not
match the plug on the appliance, have the socket
replaced with a suitable type by a qualified pro­fessional.

Setting up the appliance

N.B.!

• Coffee has been used to factory test the
appliance and it is therefore completely nor­mal for there to be traces of coffee in the mill.
The machine is, however, guaranteed to be
new.

• You should customise water hardness as
soon as possible following the instructions in
the section "Setting water hardness" on page

40.

1. Plug the appliance into the mains socket and
place the main switch on the back of the
appliance in the I position (fig. 1).

You must first select the language (the languages
scroll through at intervals of about two seconds):

2. When English appears, press the OK icon for
3 seconds (fig. 2). Once the language has
been saved, the message "English installed" is
displayed.

Follow the instructions indicated by the appliance:

3. "FILL TANK!": remove the water tank, fill to the
MAX line with fresh water then replace in the
appliance (fig. 3).

4. "INSERT WATER SPOUT AND PRESS OK":
Check that the hot water spout is inserted on
the nozzle and place a container underneath
(fig. 4).
Press the OK icon (fig. 2). "PLEASE WAIT..." is
displayed and the appliance begins to deliver
hot water.

The appliance ends the first start up procedure,
then the message "Turning off, please wait..." is
displayed and the appliance goes off.
The coffee maker is now ready for normal use.

N.B.!

When using the appliance for the first
time, you need to make 4/5 cups of coffee and 4/5
cappuccinos before the appliance starts to give
satisfactory results.

TURNING THE APPLIANCE
ON

N.B.!

Before turning the appliance on, make
sure the main switch on the back of the appliance
is in the I position (fig. 1).

Each time the appliance is turned on, it performs
an automatic preheat and rinse cycle which can­not be interrupted.

The appliance is ready for use only after comple­tion of this cycle.

Danger of burns!

During rinsing, a little
hot water comes out of the coffee spouts and is
collected in the drip tray underneath.
Avoid contact with splashes of water.

• To turn the appliance on, press the button on

the left side of the machine (fig. 5): the
message "Heating up... please wait" is displa-

yed.
When heating is complete, the message changes to:
"Rinsing". As well as heating the boiler, this also heats
the internal circuits by circulating hot water.
The appliance is at temperature when the message
"STANDARD COFFEE standard taste" is displayed.

TURNING THE APPLIANCE
OFF

Each time the appliance is turned off, it performs
an automatic rinse cycle which cannot be inter­rupted.

Danger of burns!

During rinsing, a little hot
water flows from the coffee spouts.
Avoid contact with splashes of water.

To turn the appliance off, press the button
(fig. 5). The appliance performs the rinse cycle
then goes off.

N.B.!

If the appliance is not used for an
extended period, place the main switch on the
back of the appliance in the 0 position (fig. 6).

31GB32

CHANGING THE MENU
SETTINGS

Setting the language

To modify the language on the display, proceed as
follows:

1. Press the P icon to enter the programming
menu;

2. Press the or icon until "Set language" is
displayed;

3. Press the OK icon;

4. Press the or icon until the required lan­guage is displayed;

5. Press the OK icon to confirm (or the ESC icon
to cancel the operation);

6. Press the ESC icon to exit the menu.

Setting the clock

To adjust the time on the display, proceed as fol­lows:

1. Press the P icon to enter the programming
menu;

2. Press the or icon until "Adjust time" is
displayed;

3. Press the OK icon: the hours flash on the dis-
play;

4. Press the or icon to change the hours;

5. Press the OK icon to confirm (or the ESC icon
to cancel the operation): the minutes flash on
the display;

6. Press the or icon to change the minu­tes;

7. Press the OK icon to confirm (or the ESC icon
to cancel the operation);

8. Press the ESC icon to exit the programming
menu.

Setting auto-start time

You can set the auto-start time in order to have
the appliance ready at a certain time (for example
in the morning) so you can make coffee immedia­tely.

1. Press the P icon to enter the programming
menu;

2. Press the or icon until "Auto-start" is
displayed;

3. Press the OK icon: the hours flash on the dis-
play;

4. Press the or icon to change the hours;

5. Press the OK icon to confirm (or the ESC icon
to cancel the operation): the minutes flash on
the display;

6. Press the or icon to change the minu­tes;

7. Press the OK icon to confirm (or the ESC icon
to cancel the operation);

8. Press the ESC icon to exit the menu: a symbol

appears next to the clock to indicate

that auto-start has been programmed.

To deactivate the function:

1. Press the P icon to enter the programming
menu;

2. Press the or icon until "Auto-start" is
displayed;

3. Press the OK icon: the hours flash on the dis-
play;

4. Press the ESC icon. This deactivates the func-
tion and the symbol disappears from the
display.

5. Press the ESC icon to exit the menu.

N.B.!

To activate this function, the time

must have been set previously.

Setting the temperature

To modify the temperature (low, medium, high) of
the water used to make the coffee, proceed as fol­lows:

1. Press the P icon to enter the menu;

2. Press the or icon until "Temperature" is
displayed;

3. Press the OK icon;

4. Press the or icon until the required
temperature (low, medium or high) is displa­yed;

5. Press the OK icon to confirm (or the ESC icon
to cancel the operation);

6. Press the ESC icon to exit the menu.

33

Setting auto-off

N.B.!

The appliance is set to switch auto­matically to stand-by if not used for 30 minutes.
The time can be changed so that the appliance
switches off after 1 or 2 hours.

1. Press the P icon to enter the menu;

2. Press the or icon until "Auto-off" is dis-

played;

3. Press the OK icon;

4. Press the or icon until the required

number of hours of operation (30 minutes, 1
or 2 hours) is displayed;

5. Press the OK icon to confirm (or the ESC icon

to cancel the operation);

6. Press the ESC icon to exit the menu..

Resetting default values (reset)

This resets all menu settings and programmed
quantities back to the default values (with the
exception of the language which remains as set).

1. Press the P icon to enter the menu;

2. Press the or icon until "Default values"

is displayed;

3. Press the OK icon;

4. The message "Confirm?" is displayed.

5. Press the OK icon to confirm and exit (or the

ESC icon to cancel the operation);

Statistics function

This displays statistics relating to the machine.
To display, proceed as follows:

1. Press the P icon to enter the menu;

2. Press the or icon until "Statistics" is

displayed;

3. Press the OK icon;

4. By pressing the or icon, you can check:

- how many coffees have been made;

- how many drinks with milk have been made;

- how many times the machine has been desca-

led;

- the total number of litres of water delivered;

- how many times the water filter has been

replaced.

5. Press the ESC icon twice to exit the menu.

Acoustic signal (Beep enabled)

This activates or deactivates the beep emitted by
the machine each time an icon is pressed or an
accessory is inserted/removed. The beep is ena­bled by default.

1. Press the P icon to enter the menu;

2. Press the or icon until "Beep enabled"

is displayed;

3. Press the OK icon to confirm, "Confirm?" is
displayed;

4. Press the OK icon again to confirm activa-
tion or the ESC icon to deactivate the func­tion;

5. Press the ESC icon to exit the menu.

MAKING COFFEE

Selecting the coffee taste

The appliance is preset to make coffee with a stan­dard taste.
You can choose between 5 different coffee tastes:

Extra-mild taste
Mild taste
Standard taste
Strong taste
Extra-strong taste

To change the flavour, press the icon (fig. 7)
repeatedly until the required taste is displayed.

Selecting the quantity of coffee in
the cup

To select the quantity of coffee, press the
icon repeatedly (fig. 8) until the required quantity
of coffee is displayed. The quantities delivered are
different according to the type of coffee selected:

Programming the espresso "my
coffee" quantity

The appliance is set by default to automatically deli­ver 30 ml of espresso coffee.
To modify this quantity, proceed as follows:

1. Press the icon repeatedly (fig. 8) until
"MY COFFEE" is displayed.

2. Press the one cup icon (fig. 9) until
"Program quantity" is displayed, then release.
The machine starts delivering the coffee and
the icon flashes;

GB

ESPRESSO

(ml)

LONG COFFEE

(ml)

MY COFFEE

max: ≃ 180 max: ≃ 250

SHORT COFFEE

≃ 40 ≃ 125

STANDARD COFFEE

≃ 60 ≃ 175

LONG COFFEE

≃ 90 ≃ 210

EXTRA LONG COFFEE

≃ 120 ≃ 250

34

3. As soon as the coffee in the cup reaches the
required level, press the icon again.

The quantity set has now been programmed.

N.B.!

This setting is valid for making both
one and two cups. You do not need to specifically
programme a quantity for two cups.

Programming the long "my coffee"
quantity

The appliance is set by default to automatically
deliver ≃100ml of LONG coffee. To modify this
quantity, proceed as follows:

1. Press the icon repeatedly (fig. 8) until

"MY COFFEE" is displayed.

2. Press the LONG icon (fig. 10) until

"Program quantity" is displayed, then release.
The machine starts delivering the coffee and
the LONG icon flashes;

3. As soon as the coffee in the cup reaches the

required level, press the LONG icon again.

The quantity set has now been programmed.

Regulating the coffee mill

The coffee mill is preset in the factory to prepare
coffee correctly and should not require regulating
initially.
However, if after making the first few coffees you
find that delivery is either too fast or too slow (a
drop at a time), this can be corrected by regula­ting the grinding adjustment knob (fig. 11).

Important!

The grinding coarseness regu­lator must only be turned when the coffee mill is
in operation.

For slower coffee deli­very and a creamier cof­fee, turn one click
towards "1" (finer
ground coffee).

For more rapid coffee
delivery (not in drops),
turn one click towards
"7" (coarser ground cof­fee).

N.B.!

These adjustments will only be evi­dent after at least two cups of coffee have been
made.

Making espresso coffee using
coffee beans

Important!

Do not use caramelised or
candied coffee beans as they could stick to the
coffee mill and make it unusable.

1. Fill the container with coffee beans (fig. 12).

2. Place under the coffee spouts:

- one cup, if you want one coffee (fig. 13);

- two cups, if you want two coffees (fig. 14);

3. Lower the spouts as near as possible to the

cup. This makes a creamier coffee (fig. 15).

4. Press the icon corresponding to the number

of coffees required (one cup or two cups

) (fig. 9 and 16).

5. Preparation begins. A progress bar appears

on the display and gradually advances as the

procedure progresses (fig. 17).
Once the coffee has been made, the appliance is
ready to use again.

N.B.!

• While the machine is making coffee, delivery

can be interrupted at any moment by pressing

the lit cup icon.

• At the end of delivery (when the progress bar

is complete), to increase the quantity of coffee

in the cup, just press (within 3 seconds) one

of the coffee icons ( or ) until the

required quantity is reached.

• For a hotter coffee, before delivery rinse the

appliance through by pressing the icon

and confirming with the OK icon. Hot water

flows out of the coffee spouts and heats the

internal circuit of the machine so that the cof-

fee delivered will be hotter.

• For an even hotter coffee, heat the cups by

rinsing them with the hot water.

• If the coffee is delivered in drops, too fast and

not creamy enough or too cold, read the tips

in the "Troubleshooting" section on page 43.

Making long coffee using coffee
beans

N.B.!

When this function is activated, a

long coffee similar to drip coffee is obtained.

Important!

Do not use caramelised or
candied coffee beans as they could stick to the
coffee mill and make it unusable.

35

GB

1. Fill the container with coffee beans (fig. 12).

2. Adjust the height of the spout according to the
cup used. Put the cup for long coffee under
the spouts (fig. 18);

3. Press the LONG icon (fig. 10). Preparation
begins. A progress bar appears on the display
and gradually advances as the procedure pro­gresses.

N.B.!

• While the machine is making coffee, delivery
can be interrupted at any moment by pressing
the LONG icon.

• Only one cup of long coffee can be made at a
time.

• When delivering more than 125 ml, the
appliance automatically grinds more coffee
halfway through delivery.

Making espresso or long coffee
using pre-ground coffee

Important!

• Never add pre-ground coffee when the machi­ne is off or it could spread through the inside
of the machine and dirty it.

• Never use more than one level measure or it
could dirty the inside of the machine or block
the funnel.

N.B.!

If you use pre-ground coffee, you can

only make one cup of coffee at a time.

1. Press the icon repeatedly (fig. 7) until
"Pre-ground" flashes on the display.

2. Put one level measure of pre-ground coffee
into the funnel (fig. 19).

3. Place a cup under the coffee spouts..

4. To make espresso coffee, press the one cup
icon (fig. 9).
To make a long coffee, press the LONG icon
(fig. 10).

N.B.!

LONG COFFEE: when delivering

more than 125 ml, the appliance requests a new
level measure of pre-ground coffee halfway
through delivery. When you have added the pre­ground coffee, confirm by pressing the OK icon.

MAKING DRINKS WITH
MILK

Filling and attaching the milk
container

1. Turn the lid of the milk container clockwise
until it becomes noticeably difficult to turn,
then remove the lid (fig. 20).

2. Riempire il contenitore latte con una quantità
sufficiente di latte, non superando il livello
MAX impresso sull’impugnatura (fig. 21).

N.B.!

Do not use full fat milk. Use skim­med or semi-skimmed milk at refrigerator tempe­rature (about 5°C).
To avoid milk with poor froth or large bubbles,
always clean the milk lid and hot water nozzle as
described in the section "Cleaning the milk contai­ner" on pages 17 and 19.

3. Make sure the milk intake tube is correctly

inserted in the bottom of the milk container lid
(fig. 22).

4. Replace the milk container lid and turn anti-

clockwise as far as it will go.

5. Remove the hot water spout from the nozzle

(fig. 23).

6. Attach the container to the nozzle and push as

far as it will go (fig. 24). The machine emits a
beep (if the beep function is enabled).

7. Place a sufficiently large cup under the coffee

spouts and frothed milk spout.
To use particularly tall cups/glasses, raise the
lid of the special compartment in the cup tray
(fig. 25).

Making caffelatte

1. After attaching the milk container, position the

frothed milk regulator on CAFFELATTE (fig.

26) printed on the milk container lid.

2. 2. Press the CAFFELATTE icon (fig. 27).

The message "Caffelatte... Jug pointer in posi­tion: 3" appears. After a few seconds, frothed
milk is delivered from the milk spout into the
cup below. The milk will stop automatically
and delivery of coffee will begin.

N.B.!

If during delivery you want to stop
preparing milk, press the CAFFELATTE icon or
interrupt preparation of the coffee by pressing the

icon.

36

Making cappuccino

1. After attaching the milk container, position the
frothed milk regulator on CAPPUCCINO (fig.

28) printed on the milk container lid. The

quality of froth can be adjusted by moving
the regulator towards the word LATTE MAC­CHIATO for a denser froth.
Moving it towards the word CAPPUCCINO
obtains a less dense froth.

2. Press the CAPPUCCINO icon (fig. 29). The
message "Cappuccino... Jug pointer in posi­tion: 1" appears . After a few seconds, frothed
milk flows out of the milk spout into the cup
below.
The milk will stop automatically and delivery
of coffee will begin.

N.B.!

If during delivery you want to stop
preparing milk, press the CAPPUCCINO icon or
interrupt preparation of the coffee by pressing the

icon.

Making macchiato

1. After attaching the milk container, position the

frothed milk regulator (B1) on LATTE MAC­CHIATO (fig. 30) printed on the milk container
lid.

2. Press the LATTE MACCHIATO button (fig. 31).

The message "Macchiato... Jug pointer in
position: 2" appears.
After a few seconds, frothed milk flows out of
the milk spout into the cup below.
The milk will stop automatically and delivery
of coffee will begin.

N.B.!

If during delivery you want to stop
preparing milk, press the LATTE MACCHIATO icon
or interrupt preparation of the coffee by pressing
the icon.

Making milk

1. After attaching the milk container, position the

frothed milk regulator (B1) according to the
quantity of froth you require (pos. 3 CAFFE­LATTE = little froth; pos. 1 CAPPUCCINO =
abundant froth).

2. Press the MILK icon (fig. 32). "MILK" appears

on the display and after a few seconds, fro­thed milk is delivered from the milk spout into
the cup below. Delivery of milk stops auto­matically.

N.B.!

If during delivery you want to stop

preparing milk, press the MILK icon once.

Cleaning the milk container after
use

Important! Danger of burns

When clea­ning the internal tubes of the milk container, a litt­le hot water leaks out of the frothed milk tube
(B5). Avoid contact with splashes of water.

When "Press CLEAN button" flashes on the display
(each time you use a milk function):

1. Leave the jug in the machine (you do not need

to empty it);

2. Place a cup or other recipient under the fro-

thed milk spout.

3. Press the CLEAN button (fig. 33) and keep

pressing until the progress bar which appears
on the display together with the message
"Cleaning..." is complete.

4. Remove the milk container and always clean

the nozzle with a sponge (fig. 34).

N.B.!

• When "Press CLEAN button" flashes on the

display, you can still prepare any type of cof­fee or milk. If you have to make a number of
drinks with milk, wait until you have delivered
the last cup before cleaning the container.

• The milk left in the jug can be kept in the refri-

gerator.

Programming the quantities of
coffee and milk in the cup

The appliance is factory preset to automatically
deliver standard quantities.
To change these quantities, proceed as follows:

1. Place a cup under the coffee spouts and milk

spout.

2. Press the icon corresponding to the function

you want to programme (CAFFELLATTE, CAP­PUCCINO, LATTE MACCHIATO or MILK) until
"Milk for... Program quantity" appears on the
display and the icon corresponding to the
selected function flashes.

3. Release the icon. The appliance starts delive-

ring milk.

4. When the required quantity of milk has been

delivered into the cup, press the icon again.

5. After a few seconds, the appliance starts deli-

vering coffee into the cup and the message
"Coffee for... Program quantity" is displayed

37

GB

(with the exception of the MILK function) and
the icon flashes.

6. As soon as the coffee in the cup reaches the
required level, press the icon. Coffee deli­very stops.

The machine is now reprogrammed with the new
quantities.

HOT WATER

Preparation

Important!

Danger of burns. Never leave the

machine unsupervised while delivering hot water.
The hot water spout becomes hot while water is
being delivered and must be held by the handle only.

1. Make sure the hot water spout is attached
correctly (fig. 4).

2. Place a container under the spout (as close as
possible to avoid splashes).

3. Press the OK icon (fig. 35). The message
"Rinsing" "Hot water..." is displayed.

4. Press the icon to select the "Hot water..."
function (the selected message flashes on the
display) and confirm the selection by pressing
the OK icon (or cancel the selection by pres­sing the ESC icon).

5. Water flows out of the spout. Delivery stops
automatically after 250 ml.

6. To interrupt delivery of hot water manually,
press the icon again.

Important:

You should not deliver hot

water for more than two minutes at a time.

Changing the quantity

The appliance is factory preset to automatically
deliver 250 ml. To modify these quantities, pro­ceed as follows:

1. Position a container under the spouts.

2. Once the "Hot water" function has been selec­ted, keep pressing the OK icon until "Hot water
Program quantity" appears and the icon
flashes.

• When the hot water in the cup reaches the
required level, press the icon again.

The machine is now reprogrammed with the new
quantity.

CLEANING

Cleaning the coffee maker

The following parts of the appliance must be clea­ned regularly:

- coffee grounds container (A18),

- drip tray (A16),

- water tank (A13),

- coffee spouts (A20) and hot water nozzle
(A11),

- pre-ground coffee feed funnel (A8),

- inside the machine, accessible after opening
the service door (A19),

- infuser (A12),

- milk container (B)

- control panel (C)

Important!

• Do not use solvents, abrasive detergents or
alcohol to clean the coffee maker. With
De'Longhi superautomatic coffee makers, you
need not use chemical products to clean the
machine. The descaler recommended by
De'Longhi is made from natural and comple­tely biodegradable substances.

• None of the components of the appliance can
be washed in a dishwasher with the exception
of the milk container (B).

• Do not use metal objects to remove encrusta­tions or coffee deposits as they could scratch
metal or plastic surfaces.

Cleaning the coffee grounds
container

When "EMPTY GROUNDS CONTAINER" is displa­yed, the grounds container must be emptied and
cleaned. Until the grounds container has been
cleaned, the appliance continues to display the
message and coffee cannot be made.
To clean:

• open the service door on the front of the
appliance (fig. 36), extract the drip tray (fig.

37), empty and clean.

• Empty the grounds container and clean tho­roughly to remove all residues left on the bot­tom.

Important!

when removing the drip tray,
the grounds container must be emptied, even if it
is not completely full.

38

If this is not done, when you make the next cof­fees, the grounds container may fill up more than
expected and clog the machine.

Cleaning the drip tray

Important!

If the drip tray is not emptied
regularly, the water could overflow from the edge
and seep inside or around the machine. This could
damage the machine, the surface it rests on or the
surrounding area.

The drip tray is fitted with a level indicator (red)
showing the level of water it contains (fig. 38).
Before the indicator protrudes from the cup tray,
the drip tray must be emptied and cleaned.

To remove the tray:

1. Open the service door (fig. 36);

2. Remove the drip tray and the grounds contai-

ner (Fig. 37);

3. Empty the drip tray and grounds container

(A18) and wash them;

4. Replace the drip tray complete with grounds

container (A18);

5. Close the service door.

Cleaning the water tank

1. Clean the water tank (A13) regularly (about

once a month) with a damp cloth and a little
mild washing up liquid.

2. Clean to remove all washing up liquid resi-

dues, then rinse the water tank thoroughly.

Cleaning the coffee nozzles

1. Clean the nozzle periodically using a sponge

or cloth (fig. 39).

2. Check regularly that the holes in the coffee

spout are not blocked.
If necessary, remove coffee deposits with a
toothpick (fig. 40).

Cleaning the pre-ground coffee
feed funnel

• Check regularly (about once a month ) that

the pre-ground coffee funnel is not blocked.
If necessary, remove coffee deposits with a
knife.

Danger of electric shock!

Before perfor­ming any cleaning operations, the machine must
be turned off and disconnected from the mains
power supply. Never immerse the coffee maker in
water.

Cleaning the inside of the machine

1. Check regularly (about once a week) that the
inside of the machine is not dirty. If neces­sary, remove coffee deposits with a knife and
sponge.

2. Remove the residues with a vacuum cleaner
(fig. 41).

Cleaning the infuser

The infuser must be cleaned at least once a
month.

Important!

The infuser (A8) must not be
removed when the appliance is on. Do not attempt
to use force to remove the infuser as this could
damage the machine.

1. Make sure the machine is correctly turned off

(see Turning off).

2. Open the service door (fig. 36);

3. Remove the drip tray and grounds container

(fig. 37);

4. Press the two red release buttons inwards and

at the same time pull the infuser outwards
(fig. 42).

Important!

Do not use washing up liquid to
clean the infuser. The detergent would remove the
lubricant applied to the inside of the piston, cau­sing the infuser to seize up and become unusable.

5. Soak the infuser in water for about 5 minutes,

then rinse under the tap.

6. After cleaning, replace the infuser by sliding it

onto the internal support and pin at the bot­tom, then push the PUSH symbol fully in until
it clicks into place.

N.B.!

If the infuser is difficult to insert,

you must first adapt it to the right dimension by

Pin

Support

39

GB

pressing it forcefully from
the bottom and top as
shown in the figure.

7. Once inserted, make
sure the two red but­tons have snapped
out.

8. Replace the drip tray
and grounds contai­ner.

9. Close the service
door.

Cleaning the milk container

Clean the milk container each time you prepare
milk as described below:

1. Turn the milk con­tainer lid clockwi­se then remove it.

2. Remove the milk
spout and intake
tube.

3. Remove the poin­ter by pulling it
outwards.

4. Wash all the com­ponents tho­roughly with hot
water and mild
washing-up liquid.
All components
can be washed in a
dishwasher, placing
them in the top
basket of the dish­washer.
Make sure there are no milk residues left insi­de the holes and the groove on the fine end of
the pointer.

5. Check that the intake tube and spout are not
clogged with milk residues.

6. Replace the pointer, milk spout and intake
tube.

7. Replace the lid on the milk container, turning
it anticlockwise to hook it in place.

Cleaning the touch screen

1. If the machine is on, turn off by pressing the

button (fig. 5) to avoid starting it acci-

dentally during cleaning.

2. Clean the control panel with a damp cloth. Do
not use solvents, aggressive detergents

and/or sharp objects as they could damage
the surface of the panel.

DESCALING

Descale the machine when the message "DESCA­LE!" flashes on the icon display.

Important!

Descaler contains acids which
may irritate the skin and eyes. It is vital to adhere to
the manufacturer’s safety warnings given on the
descaler pack and the warnings relating to the pro­cedure to follow in the event of contact with the skin
and eyes.

N.B.!

Use De'Longhi descaler only. Under
no circumstances should you use sulphamic or
acetic based descalers. Their use invalidates the
guarantee. Failure to descale the appliance as
described above also invalidates the guarantee.

1. Turn the machine on.

2. Enter the programming menu by pressing the

P icon.

3. Press the or icon until "Descaling" is

displayed.

4. Select by pressing the OK icon.

"Descaling Confirm?" is displayed. Press OK
to activate the function.

5. The message " Add descaler. Confirm?" is dis-

played.

6. Before confirming, empty the water tank

(A13).
Pour the descaler diluted with water (respec­ting the proportions indicated on the descaler
bottle) into the water tank.
Place an empty container with a minimum
capacity of 1.5 litres under the hot water
spout (1.5 l).

Important!

Danger of burns Hot water con-

taining descaler flows out of the hot water spout.
Avoid contact with splashes of water.

7. Confirm by pressing the OK icon.

8. The message "Descaling Underway..." is dis­played. The descaling programme starts and
the descaler liquid comes out of the water
spout.

The descale programme automatically performs a
series of rinses and pauses to remove limescale
deposits from inside the machine.

Spout

Milk intake
tube

Groove

Pointer

Hole

Hole

40

After about 30 minutes, the message "Rinsing
FILL TANK!" is displayed.

9. The appliance is now ready for rinsing
through with clean water.
Remove the water tank, empty, rinse under
running water, fill with clean water and repla­ce. "Rinsing... Press OK" is displayed.

10. Empty the container used to collect the desca­ler solution and replace it under the hot water
spout.

11. Press the OK button to start rinsing. Hot water
flows out of the spout and the message
"Rinsing..." is displayed.

12. When the water tank is completely empty, the
message "Rinsing complete... Press OK but­ton?" is displayed.

13. Press the OK button, fill the water tank and the
appliance is ready for use.

SETTING WATER HARDNESS

The DESCALE message is displayed after a period
of time established according to water hardness.
The machine is factory set for a hardness value of
4 (very hard water).
The machine can also be programmed according
to the actual hardness of the mains water in the
various regions, varying the frequency with which
the message is displayed.

Measuring water hardness

1. Remove the "TOTAL HARDNESS TEST" indica­tor paper from its pack.

2. Immerse the paper completely in a glass of
water for about a second.

3. Remove the paper from the water and shake
lightly.
After about a minute, 1, 2, 3, or 4 red squares
form, depending on the hardness of the water.
Each square corresponds to one level.

Setting water hardness

1. Press the P icon to enter the programming
menu.

2. Press the or icon and select "Water
hardness".

3. Confirm the selection by pressing the OK
icon.

4. Press the or icon to set the number of
squares formed on the reactive strip (see figu­re in the previous section).

5. Press the OK icon to confirm the setting.

6. Press the ESC icon to exit the menu.

The machine is now reprogrammed with the new
water hardness setting.

TECHNICAL SPECIFICATION

Voltage: 220-240 V~ 50/60 Hz 10A max.
Absorbed power: 1350 W
Pressure: 15 bars
Water tank capacity: 1.8 litres
Size: LxHxD: 282x374x441 mm
Weight: 11.4 kg

The appliance complies with the following
EC directives:

• Low Voltage Directive 2006/95/EC;

• EMC Directive 89/336/EEC and subsequent
amendments 92/31/EEC and 93/68/EEC.

Materials and accessories coming into contact
with food conform to EC regulation 1935/2004.

DISPOSAL

Electrical appliances must not be disposed
of as household waste.
Appliances with this symbol are covered

by European Directive 2002/96/EC.
All unused electric and electronic appliances must
be disposed of separately from household waste
by taking them to the special centres provided by
the State.
Disposing of the unused appliance correctly
avoids damage to the environment and a risk to
health.
For more information on disposing of the unused
appliance, contact the local administration, the
waste disposal department or the shop where the
appliance was bought.

soft water

G

slightly hard wate

r

GG

hard water

GGG

very hard water

GGGG

41

DISPLAYED MESSAGES

DISPLAYED MESSAGE POSSIBLE CAUSE REMEDY

FILL TANK!

• The water tank is empty or
positioned incorrectly.

• Fill the tank with water and/or
insert it correctly, pushing it as
far as it will go.

GROUND TOO FINE ADJUST
MILL!
Insert water spout and press
OK

• The grinding is too fine and the
coffee is delivered too slowly.

• The machine cannot make cof­fee as there is air in the hydrau­lic circuit

• - Make the coffee again and
turn the grinding adjustment
knob one click clockwise
towards "7" while the coffee
mill is in operation. The effect
is only visible after delivering
two coffees.

• Press the OK icon to deliver
water from the spout until it
flows out normally.

INSERT WATER SPOUT!

• The water spout is not inserted
or is inserted incorrectly.

EMPTY GROUNDS CONTAINER

• The grounds container is too
full or more than 3 days have
passed since you last made
coffee (this guarantees correct
hygiene of the machine).

• Empty the grounds container
and clean, then replace.
Important: when removing the
drip tray, the grounds container
MUST be emptied, even if it is
not completely full.
If this is not done, when you
make the next coffees, the
grounds container may fill up
more than expected and clog
the machine.

INSERT GROUNDS
CONTAINER

• After cleaning, the grounds
container has not been
replaced.

• Open the service door and
insert the grounds container.

INSERT MILK CONTAINER!

• The milk container is not inser­ted.

• Insert milk container as far as it
will go.

• Insert water spout as far as it
will go.

DESCALE!

• The machine must be descaled. • The descaling procedure
described in the "Descaling"
section needs to be performed
as soon as possible.

LESS COFFEE!

• Too much coffee has been

used.

• Select a milder taste or reduce
the quantity of pre-ground cof­fee, then make the coffee again.

42

INSERT INFUSER ASSEMBLY!

• The infuser has not been repla­ced after cleaning.

• Insert the infuser as described
in the section "Cleaning the
infuser".

DISPLAYED MESSAGE POSSIBLE CAUSE REMEDY

CLOSE DOOR!

• The service door is open • Close the service door.

FILL BEANS CONTAINER!

• The coffee beans have run out.

• The ground coffee funnel is
clogged.

• Fill bean container

• Empty the funnel with the help
of a knife, as described in the
section "Cleaning the funnel to
add coffee".

GENERAL ALARM!

• The inside of the appliance is
very dirty.

• Clean the inside of the applian­ce thoroughly as described in
the section "Cleaning the inside
of the machine".
If the message is still displayed
after cleaning, contact custo­mer services.

ADD PRE-GROUND COFFEE!

• The "pre-ground coffee" func­tion has been selected without
placing any pre-ground coffee
in the funnel.

• The funnel (A8) is blocked.

• Place pre-ground coffee in the
funnel.

• Empty the funnel with the help
of a knife, as described in the
section "Cleaning the pre­ground coffee feed funnel".

PRESS CLEAN BUTTON

• Milk has been delivered
recently and the tubes inside
the milk container must be
cleaned.

• Press the CLEAN button and
keep it pressed until the pro­gress bar which appears on the
display together with the mes­sage "Cleaning" is complete.

ADD PRE-GROUND COFFEE!
PRESS OK

• The appliance is delivering a
LONG coffee of more than 125
ml.

• Add a level measure of pre­ground coffee and confirm by
pressing the OK icon.

43

GB

The coffee is delivered too
quickly.

• The coffee is ground too coar­sely.

• Avoid turning the grinding
coarseness regulator excessi­vely otherwise when you select
two cups, the coffee may be
delivered a drop at a time.
The effect is only visible after
delivering two coffees.

PROBLEM POSSIBLE CAUSE REMEDY

TROUBLESHOOTING

Below is a list of some of the possible malfunctions.
If the problem cannot be resolved as described, contact customer services.

The coffee is not hot

• The cups have not been pre­heated.

• The infuser has cooled down
because 2/3 minutes have
elapsed since the last coffee
was made.

• Warm the cups by rinsing them
with hot water.

• Before making coffee, rinse as
described in the notes in the
section "Preparing coffee using
coffee beans".

The coffee is not creamy
enough

• The coffee is ground too coar­sely.

• Wrong type of coffee.

• Turn the grinding adjustment
knob one click anticlockwise
towards "1" while the coffee mill
is in operation (fig. 11).
Continue one click at a time until
coffee delivery is satisfactory.
The effect is only visible after
delivering two coffees.

• Use a type of coffee for espresso
coffee makers.

The coffee is delivered too
slowly or a drop at a time.

• The coffee is ground too finely.

• Turn the grinding adjustment
knob one click clockwise
towards "7" while the coffee
mill is in operation (fig. 11).
Continue one click at a time
until coffee delivery is satisfac­tory. The effect is only visible
after delivering two coffees.

Coffee does not come out of
one of the spouts.

• The spouts are blocked. • Clean the spouts with a tooth­pick (fig. 40).

44

The milk contains bubbles or
squirts out of the milk spout.

• The milk is not cold enough or

is not semi-skimmed.

• The milk frother pointer is

incorrectly adjusted.

• The milk container lid is dirty.

• You should ideally use skim­med or semi-skimmed milk at
refrigerator temperature (about
5°C).
If the result is still disappoin­ting, try another brand of milk.

• Adjust following the instruc­tions in the section on prepa­ring drinks with milk.

• Clean the milk container lid as
described in the section
"Cleaning the milk container".

PROBLEM POSSIBLE CAUSE REMEDY

The milk does not come out of
the milk spout (B5).

• The intake tube is not inserted
or is inserted incorrectly.

• Insert the intake tube (B4) in
the rubber washer in the milk
container lid (fig. 22).

The milk is not well frothed.

• The milk frother pointer is
incorrectly adjusted.

• The milk container lid is dirty.

• Adjust following the instruc­tions in the section on prepa­ring drinks with milk.

• Clean the milk container lid as
described in the section
"Cleaning the milk container".

The coffee does not come out
of the spouts, but from around
the service door (A19).

• The holes in the spouts are
clogged with dry coffee dust.

• The coffee guide (A21) inside
the service door is blocked and
cannot swing.

• Clean the spouts with a tooth­pick, sponge or hard bristled
kitchen brush.

• Thoroughly clean the coffee
guide (A21), particularly near
the hinges.

Water comes out of the spouts
instead of coffee.

• The ground coffee may be
blocked in the funnel (A8).

• Empty the funnel with the help
of a knife, as described in the
section "Cleaning the funnel to
add pre-ground coffee".

The appliance does not come
on.

• It is not plugged into the mains
socket.

• The main switch is not turned
on.

• Plug into the mains socket.

• Place the main switch on the
back of the appliance in the I
position (fig. 1).

The LONG coffee has too much
froth

• The coffee is ground too finely. • Turn the grinding adjustment
knob one click clockwise
towards "7" while the coffee
mill is in operation (fig. 11).
Continue one click at a time
until coffee delivery is satisfac­tory. The effect is only visible
after delivering two coffees.
