Dascom Tally T2250 User Manual

Matrix
Printer

T2250

At home in
all applications

HIGHLIGHTS AT A GLANCE:

• Multifunctional dot matrix printer for a wide vari­ety of applications

• Flexible paper input via cut sheet feeders and
endless tractors

• Extensive automatic functions for unattended
printing

• Diversity of interfaces, emulations and drivers

• Robust construction for reliable and quiet operation

2 JAHRE

VOR-ORT-

GARANTIE

SOLUTIONS FOR BUSINESS PRINTING

T2250

With the T2250 DASCOM provides a dot matrix printer, which is characterized by a particularly extensive equipment.
Print speed and monthly print volume, ease-of-use and reliability - the T2250 with 136-character print width offers an

excellent price / performance ratio.
Extensive automatic functions such as paper thickness scanning, paper path switching and single sheet feed detec-

tion as well as numerous standard and optional paper processing functions ensure optimum readiness of the printer in
a wide variety of application areas.

TECHNICAL DATA

Print Speed 720 cps (Fastest Draft), 600 cps (Draft), 270 cps (DPQ), 180 cps (NLQ) bei 10 cpi
Resolution up to 360 x 360 dpi
Throughput (ECMA 132) 482 pages per hour
Character Density 10, 12, 15, 17.1, 20 cpi
Line Density 2, 3, 4, 6, 8, 12 lpi
Lifetime Print Head 400 million characters
Memory 128 kB
Interfaces Parallel (bi-directional) and Serial RS232
Emulation Standard IBM ProPrinter XL24, Epson LQ2250, MTPL + Barcode + LCP

IGP Version: IGP/PGL, Code V, MT660, Printronix P6000, HP2564C, Genicom ANSI

Emulation Optional DEC LA 75, ECMA 9011, Eastern Europe, MT50
Fonts HS Draft, Draft, Courier, Roman, Sans Serif, Prestige, Script, OCR-A/B, 23 barcodes

and large characters printing

Consumables Ribbon: 5 million characters
Paper Handling Standard Push tractor and friction, Continuous aper with straight paper path,

Manual cut sheet from front, tear-off function, park position

Paper Handling Optional Additional push tractor front, additonal push tractor rear
Copies Push tractor front: 1 original + 5 copies;

Push tractor rear: 1 original +1 copies;
Cut sheet: 1 original + 5copies

Paper Types Continuous paper, single sheet, multi-part forms
Paper Weight 60-120 g/m²
Paper Format Width: 76 to 420 mm; Length: 76 to 599 mm
Weight 10,5 kg
Dimension 600 x 300 x 295 mm (W x D x H)
Noise Level 53 dB(A)
Voltage 230 V - 50/60 Hz
Power Consumption 40 Watt (Printing); <10 W (Sleep Mode)
Temperature +10° to +35° C; 20% to 80% rel. humidity
Print Volume 26.000 pages per month
MTBF 20.000 hours
Driver Windows 7/8/10 and Server 2008/2012 (32/64 Bit); SAP

Configurations:

• T2250 Standard model

DASCOM GB Ltd

Hart House, Priestley Road
Basingstoke | Hampshire RG24 9PU | ENGLAND
Tel.: [phone]| Fax: [phone]
info.gb@dascom-com | www.dascom.co.uk

All com pany and pro duct names ar e trademar k of theri re spective o wner. Copy right © 2019 DAS COM. Speci fication ar e subject to ch ange witho ut notice.

Version 1.0

Subjec t to modific ation, of err or or misprint .

DASCOM Europe GmbH

Heuweg 3 | 89079 Ulm | GERMANY
Tel.: [phone] | Fax: [phone]
[e-mail] | www.dascomeurope.de

DASCOM (Holdings) LTD.

R. 1811-1816A | Nan Fung Centre
264 -298 Castle Peak Road | Tuen Wan, N. T. | Hong Kong
Tel.: [phone] | Fax: [phone]
