DP-581
Mobile
Printer
Large print
with small dimensions
HIGHLIGHTS AT A GLANCE:
• Easy-to-read control interface and simple drop-in
paper loading.
• Dual tear bars allow easy tear-offs
• True WYSIWYG printing with the Windows driver.
• Printer integration is quick and easy with Windows
TM
driver or Android
SOLUTIONS FOR BUSINESS PRINTING
and Microsoft SDKs
2 JAHRE
VOR-ORT-
GARANTIE
DP-581
The DP-581 is a low profile, highly reliable mobile printer for a variety of applications. Fully self-contained unit means
easy to deploy and easy to use.
This printer is great for when workers need to stay focused on their job,not their printers. That’s because the DP-581
is engineered to create crisp, professional looking full page receipts,tickets, invoices,schematics,etc. automatically
and reliably. One look will convince you — DP-581 takes full page mobility and ease of use to a whole new level.
TECHNICAL SPECIFICATIONS
Print speed Up to 2 inch/sec (50 mm/sec)
Resolution 203 dp (8 dots/mm)
Lifetime print head 50 km
Memory 256 kB FLASH, 512 MB DRAM
Print width Up to 216 mm
Interfaces Standard USB 2.0 (Typ C)
Interfaces Optional Bluetooth (4.0) or WiFi (802.11 b/g/n)
Bluetooth Compatible Bluetooth 4.0 Stack
Protocols: L2CAP, RFCOMM, SDP
Profile: GAP, SDAP, SPP, BTLE
WiFi Encryption: WEP, WPA-PSK/TKIP, WPA2-AES, 802.1x EAP with TLS, TTLS, LEAP,
FAST, PEAP
Administration Internal Website
Emulations Zebra CPCP and ZPL, EPL, ESC/POS, PostScript, Extech, IPL
Roll diameter Max. diameter 50,8 mm
Roll capacity Approx. 30 m (equals 100 DIN A pages)
Battery Rechargeable 6 cells Lithium-Ion (5.900 mAh)
Endurance more then 300 printed pages
Charging time 5,7 hours
Weight 1,6 kg (standard model); 1,95 kg (battery model)
Dimensions 305 x 64 x 107 mm (W x D x H)
Voltage 19 V; 3,4 A
Power consumption 30 Watt (printing); 1,9 Watt (stand-by)
Temperature -18° to +50° C (printing); -20° bis 60° C (storage)
Humidity 10% to 90% rel. humidity
MTBF 10.000 hours
Drivers Windows 7/8/10, Windows CE/Pocket PC, Windows Mobile, Android
Certifications CE, FCC Class B, UL, E1
Configurations:
• DP-581 Standard model
• DP-581 Battery model
