Dascom Tally 2600+ User manual

Tally Dascom 2600+/2610+
I
Important Safety Ins truct ions (English)
Read the following instruc tions thoroughly before starting up your printer.
Never carry out maintenance or repair work yourself. Alw ays contact a qualified service technician.
Keep this Operator’s Manual in a place which is easily accessible at all times.
Place the printer on a solid and even base so that it cannot fall.
Never place the printer in the vicinity of inflammable gas or explosive substances.
Ensure the printer is connected to a socket with the correct mains voltage.
Always disconnect the printer from the mains before opening the device to perform maintenance work
or remedy errors.
Do not expose the printer to high temperatures, direct sunlight or dust.
Keep all liquids away from the printer.
Protect the printer from shock, impact and vibration.
Make sure that the printer and computer are switched off before connecting the data cable.
The print head will become very hot during printing; avoid contact with the print head after printing has finished.
Do not perform any operation or action in any way other than those provided in this manual. When in doubt, contact your dealer or your customer support.
The device and mains-socket must all times be easily accessible.
Tally Dascom 2600+/2610+
II
Wichtige Sic herheit shinweise (German)
Lesen Sie bitte diese Sicherheitshinweise durch, bevor sie den Drucker in Betrieb nehmen.
Führen Sie Wartungsarbeiten und Reparaturen keinesfalls selbst aus, sondern verständigen Sie immer einen qualifizierten Servicetechniker.
Bewahren Sie diese Dokum entation an einem jederzeit zugänglichen Ort auf.
Den Drucker auf stabi lem und ebenem Untergrund so aufstellen, dass er nicht zu Boden fallen kann.
Stellen Sie den Drucker keinesfalls in der Nähe von leicht entzündlichen Gasen oder explosiven Stoffen
auf.
Den Drucker nur an eine Steckdose mit der richtigen Spannung anschließen.
Wenn Sie den Drucker vom Netz trennen wollen, den Drucker ausschalten und immer den Netzstecker
an der Steckdose ziehen.
Den Drucker weder hohen Temperaturen noch direktem Sonnenlicht und Staub aussetzen.
Keine Flüssigkeiten mit dem Drucker in Berührung bringen.
Den Drucker keinen Erschütterungen, Stößen oder Vi brationen aussetzen.
Sicherstellen, dass der Drucker und der Computer ausgeschaltet sind, bevor das Datenkabel
angeschlossen wird.
Der Druckkopf wird während des Druckens heiß. Vor dem Berühren deshalb einige Zeit abk ühlen lassen.
Weichen Sie bei der Bedienung des Druckers nicht von den Anweisungen in der Dokumentation ab.
Bei Unklarheiten wenden Sie sich bitte an Ihren Händler oder Ihren Kundendienst.
Maschinenlärminformations – Verordnung – 3.GPSGV, der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäß EN IS O 7779.
Das Gerät und die Netzsteckdose müssen jeder Zeit leicht zugänglich sein.
Tally Dascom 2600+/2610+
III
Consi gnes importantes de séc urité (French)
Lire attentivement les instructions suivantes avant de mettre l’imprimante en service.
Ne jamais effectuer soi-même les travaux d’entretien et de réparations. Contacter toujours un dépanneur qualifié.
Placer l’imprimante sur un support stable de façon à c e qu’elle ne puisse pas tomber.
Ne jamais placer l’imprimante à proximité de sources de gaz aisément inflam m ables ou de substances
explosives.
Ne connecter l’imprimante à une prise que lorsque la tension est correcte.
Pour déconnecter l’imprimante de l’alimentation principale, mettre l’imprimante hors tension et toujours
débrancher le connecteur secteur de la prise murale.
Ne pas exposer l’imprimante à des températures élevées, à la lumière directe du soleil ou à la poussière.
Ne pas mettre l ’imprimante en contact avec des liqui des.
Ne pas exposer l’imprimante à des chocs, impacts ou vibrations.
S’assurer que l’imprimante et l’ordi nateur sont hors tension avant de connec ter le câble de données.
La tête d’impression est brûlante pendant l’impression. C’est pourquoi laissez-la refroidir quelques
instants avant d’y toucher.
N'exécutez aucune opération ni action d'une autre manière que celle indiquée dans ce m anuel. En cas de doute, veuillez contacter votre distributeur ou service après-vente.
Le dispositif et la prise principale doivent toujours être accessibles facilement.
Tally Dascom 2600+/2610+
IV
Indicazioni di sicur ezza importanti (Italian)
Prima di mettere in funzione la stampante, leggere attentamente le seguenti indicazioni.
Non eseguire mai da sé gli interventi di manutenzione e riparazione, ma rivolgersi sempre a un tecnico di assistenza qualificato.
Conservare le presenti istruzioni per l’uso in un luogo sempre accessibile.
Collocare la stam pante su una superficie stabile, per evitare che cada a terra.
Non collocare la stampante in prossimità di gas facilmente infiammabili o di sostanze esplosive.
Collegare la stampante a una presa di corrente con tensione adeguata.
Per scollegare la stampante dalla rete di alimentazione, spegnere la stampante e disinserire sempre il
connettore di rete dalla presa.
Non esporre la stampante ad elevate temperature né alla luce solare diretta e alla polvere.
Evitare il contatto della stampante con liquidi.
Non esporre la stampante a colpi, scosse o vibrazioni.
Verificare che la stampante e il computer siano spenti prima di collegare il cavo di trasmissione dati.
Durante la stampa, la testina si surriscal-da notevolmente. Prima di toccarla, se necessario opportuno
quindi lasciarla raffreddare qualche istante.
Non eseguire alcuna operazione o azione se non nella maniera desc ritta nel presente manuale. In caso di dubbio, contattare il rivenditore o dalla società inc aricata dell’assistenza.
Il dispositivo e la presa di corrente devono essere sempre facilmente accessibili.
Tally Dascom 2600+/2610+
V
Instrucciones de seguridad importantes ( Spanish)
Lea las siguientes instrucciones con esmero antes de poner la impresora en servicio.
Nunca lleve a cabo trabajos de mantenimiento o reparación Ud. mismo, sino consulte a un técnico de servicio calificado.
Guarde las presentes instrucciones de servicio en un lugar de fácil acceso en cualquier momento.
Ponga la impresora sobre un base estable de manera que no pueda caer al suelo.
Nunca coloque la impresora en la vecindad de gases de fácil inflamabilidad o suns tancias explosivas.
Asegure conectar la im presora sólo a un enchufe con un voltaje correcto.
Cuando quiera desconectar la impresora de la red, apague la impresora y siempre tire la clavija de
alimentación del enchufe.
No exponga la impresora a temperaturas altas, a la luz solar directa y al polvo.
No ponga la impresora en contacto con fluidos.
Nunca exponga la impresora a sacudidas, choques o vibraciones.
Asegúrese de que la impresora y el ordenador estén apagdos antes de conectar el cable de datos.
La cabeza de impresión se pone muy caliente durante la impresión. Por lo tanto, deje enfriarlo algún
tiempo antes de tocarla.
No permita que se realice cualquier operación o acción de una forma diferente a lo que se señala en el manual. En caso de duda, póngase en contacto con su comerciante o con su servicio post-venta.
El dispositivo y la toma de corriente deben estar ubic ados de forma que sea fácil acceder a ellos.
Tally Dascom 2600+/2610+
VI
Правила по технике безопасности. (Russian)
Прочитайте, пожалуйста, инструкцию по технике безопасности перед включением в работу принтера.
Не выполняйте технические работы и ремонт техники самостоятельно, но сообщайте о
неисправностях квалифицированным сервисным техникам.
Данная инструкция должна быть всегда доступна каждому пользователю.
Установите принтер на ровном и стабильном месте так, чтобы он не смог упасть на пол.
Ни в коем случае не ставьте принтер вблизи легко воспламеняющихся газов и взрывчатых
веществ.
Включайте принтер в розетку только с соответствующим напряжением.
Если Вы хотите отключить принтер от напряжения, сначала выключите принтер сам и затем
выньте штекер из розетки.
Берегите принтер от нагревания, от попадания на него прямых солнечных лучей и пыли.
Не допускайте попадания жидкости на принтер.
Нельзя подвергать принтер тряске, ударам и вибрации.
Убедитесь, что принтер и компьютер выключены, только после этого соедините принтер с
компьютером.
Печатающая головка нагревается во время работы принтера. Поэтому подождите какое-то время, прежде чем дотронуться до нее.
Пользуйтесь принтером так, как это написано в документации. Если у Вас возникают неясности, обращайтесь с вопросами к Вашим продавцам или в сервисный центр.
Устройство и розетка должны быть всегда легко доступна.
Tally Dascom 2600+/2610+
VII
Instruções Importantes sobre Segurança (Portuguese)
Leia as instruções de segurança antes de usar a impressora.
Consulte sempre um técnico qualificado para executar uma reparação .
Coloque a impressora sobre uma base sólida e nivelada, para que ela não sofra quedas.
Jamais instale a impressora nas proximidades de lugares onde haja gás inflamável ou substâncias
explosivas.
Assegure-se de conectar a impressora à tomada elétrica com a voltagem apro-priada.
Quando desligar a impressora da rede, desligue sempre a impressora e retire o cabo da tomada.
Não exponha a impressora a temperaturas altas ou luz solar direta.
Não aproxime substâncias líquidas da impressora.
Proteja a impressora de choques, impactos e vibrações.
Desligue a impressora e o computador antes de conectar o cabo da rede.
A cabeça da impressora pode ficar muito quente . Portanto, espere algum tempo antes de tocá-la.
Não faça nenhuma operação ou ação além das recomendadas neste manual. Em caso de dúvida,
contate seu revendedor ou companhia de serviço.
A impressora e a tomada devem ser facilmente em todos os momentos acessíveis.
Tally Dascom 2600+/2610+
VIII
Önemli
Güvenlik Talimatları (Turkish)
Lütfen,
yazıcıyı
Ba
kım
işletime geçirmeden
ve
tamir çaşmalarını kesinlikle
servis-teknisyenine haber verin.
Yazıcıyı, üzerinden
Yazıcıyı kesinlikle yakınına koymayın.
Yazıcı akım
Yazıcıyı
Yazıcıyı
Yazıcı
Yacı hiçbir sarsıntıya, darbeye
Veri kablosu bağlanmadan
kablosunu
şebeke
ağından ayırmak istediğinizde, yazıcıyı kapatın
ne yüksek
hiçbir sıvı maddeyle
olmalısınız.
Yazıcının başı soğumasını
Yazıcının işletimi
basma
bekleyin.
ve
görünen hususlarda
Cihaz ve elektrik prizinin her zaman kolayca erişilebilir olması gerekir.
önce bu
yere düşmesi
ve
hiçbir
surette
sadece
ısılı
ne de
temasta
önce hem
esnasında
kullanımında
lütfen
imâlatçınıza
güvenlik talimatlarını bütünüyle
ve
hiçbir
surette kendi
mümkün olmayacak
kolayca yanabilecek
doğru gerilime
doğrudan
olmamalıdır.
veya titreşime
yazıcının
yüksek
bu
dokümantasyondaki talimatların
sahip bir prize takın.
güneş
ışığına
mâruz
hem de
ısıya ulaşıyor.
veya
şteri hizmetleri servisiniz
dikkatle okuyun.
başınıza yapmayın; her
zaman kalifiye
sabit ve düz bir zemine yerleştirin.
gaz veya
ve toza
patlayıcı maddeler içeren
ve
ağ-fişini
mâruz
her zaman
kalan
mekânlarda bulundurun.
kalmamalıdır.
bilgisayarı n
Bu yüzden lütfen
kapalı
olduklarından
dokunmadan
hiç
dışına çıkmayın.
önce kısa süre
e başvurun.
nesnelerin
prizden
emin
Sorunlu
bir
çıkartın.
uzman
Tally Dascom 2600+/2610+
IX
TRADEMARK ACKNOWLEDGEMENTS
“IBM” is a trademark of International Business Mac hines Corporation. “EPSON” is a trademark of Epson America Incorporated. “DEC” is a trademark of Digital Equipment Corporation. “Centronics” is a trademark of Centronics Data Computer Corporation. “DOS” is a trademark of Microsoft Corporation. “SAP” is a trademark of SAP AG. “Windows”, “Windows 7”,”Windows 8”, “Windows 10” , “Windows 95”, “Windows 98“, “Windows NT”, “Windows
2000”, “Windows 2003/2008/2013 Server”, “Windows XP” and “Windows Vista” are trademarks of Microsoft Corporation.
All other product names and com pany names appearing in this manual are the registered trademarks or
trademarks of the individual companies.
Tally Dascom 2600+/2610+
TABLE O F CO NTENTS
1 Printer at a glance ............................................................................................................................................. 1
1.1 Unpacking the printer ................................................................................................................................. 1
1.2 Remove transport locks ............................................................................................................................. 1
1.3 Prepare your printer ................................................................................................................................... 2
1. 4 Parts description ......................................................................................................................................... 4
2 Installation .......................................................................................................................................................... 5
2.1 Placing the printer....................................................................................................................................... 5
2.2 Connecting the printer ................................................................................................................................ 6
2.2.1 Parallel interface (IEEE 1284)........................................................................................................... 6
2.2.2 USB 2.0 (Full Speed) ......................................................................................................................... 6
2. 2.3 Etherne t .............................................................................................................................................. 6
2.2.4 Serial Interface (RS-232C) as op t ion ............................................................................................... 7
2.2.5 Connecting the power ....................................................................................................................... 7
2.2.6 Switch on the printer .......................................................................................................................... 7
2.3 Installing the ribbon cartridge ..................................................................................................................... 8
3 Installing the paper .......................................................................................................................................... 10
3.1 Adjusting the print gap for various form thicknesses .............................................................................. 10
3.2 Paper path introduction ............................................................................................................................ 11
3.2.1 Cut sheet paper handling (front friction only) ................................................................................. 11
3.2.2 Fanfold paper handling.................................................................................................................... 12
3.2.3 Top-Of-Form ad j us tment ................................................................................................................. 16
4 Control Panel Operation ..................................................................................................................................... 17
4.1 Operation of the LCD Panel ......................................................................................................................... 17
4.2 The LC display ............................................................................................................................................. 17
4.3 Online mode ................................................................................................................................................ 18
4.4 Offline mode ................................................................................................................................................ 18
4.5 Setup mode ................................................................................................................................................. 19
4.6 Power on functions ...................................................................................................................................... 19
5 Printer Setting..................................................................................................................................................... 20
5.1 Setting the par am eters through the LCD Pa nel
5.1.1 Enabling access to menu mode...................................................................................................... 20
5. 1.2 Menu configurations ........................................................................................................................ 21
5. 1.3 Menu handling ................................................................................................................................. 23
5.1.4 Selecting the LC display language ................................................................................................. 24
5. 2 M enu structure .......................................................................................................................................... 25
5.3 Full list parameters setting ....................................................................................................................... 26
5. 3.1 Menu Conf i guration l i st.................................................................................................................... 26
5.3.2 Advanced Menu ............................................................................................................................... 33
5.4 Display messages .................................................................................................................................... 36
5.5 USB host interface ................................................................................................................................... 37
5.5.1 Firmware Download......................................................................................................................... 37
5. 5.2 Configuration F i le Upload................................................................................................................ 37
5. 5.3 Configuration F i le Download ........................................................................................................... 37
6 Web Panel and Internal Ethernet Interface.................................................................................................... 38
6.1 Summary ................................................................................................................................................... 38
6.1.1 Introd u ction ...................................................................................................................................... 38
6.1.2 Supported Environments ................................................................................................................. 38
6.1.3 Network Interface and Cabling ....................................................................................................... 38
6. 1.4 Connec ting the Print er..................................................................................................................... 38
6.1.5 Network Interface Status ................................................................................................................. 38
6.1.6 IPv6 Fu nc tional i t y ............................................................................................................................ 39
6. 2 IP Configuration ........................................................................................................................................ 39
6.2.1 Network IP Configuration ................................................................................................................ 39
...................................................................................... 20
1
Tally Dascom 2600+/2610+
6.2.2 Assigning the IP Address ................................................................................................................ 39
6.3 WebPanel.................................................................................................................................................. 41
6.3.1 Introd u cti o n ...................................................................................................................................... 41
6.3.2 Web Browser ................................................................................................................................... 41
6.3.3 Access to WebPanel........................................................................................................................ 42
6.3.4 Access to Config Tool ...................................................................................................................... 43
6.3.5 Printer Status ................................................................................................................................... 43
6.3.6 Printer Configuration........................................................................................................................ 44
6.3.7 Printer Actions .................................................................................................................................. 47
6. 3.8 Load Configuration .......................................................................................................................... 47
6.3.9 Save Configuration .......................................................................................................................... 48
6.3.10 Retrieve Configuration From Printer............................................................................................. 48
6.3.11 Send Configuration to Printer ........................................................................................................ 49
6.3.12 Report............................................................................................................................................. 51
6.3.13 Reset Printer .................................................................................................................................. 51
6.3.14 Pa n el Lock On /Off ......................................................................................................................... 51
6.3.15 Download Firmware ...................................................................................................................... 51
6.3.16 T allyCom S tatus ............................................................................................................................. 54
6.3.17 Advanced Configuration ................................................................................................................ 54
6.3.18 General .......................................................................................................................................... 55
6.3.19 TCP/IP ............................................................................................................................................ 56
6.3.20 SNMP ............................................................................................................................................. 57
6.3.21 Pass w or d ....................................................................................................................................... 58
6.3.22 User Name ..................................................................................................................................... 58
6.3.23 Resetting Password ...................................................................................................................... 58
6.3.24 Logical Printers .............................................................................................................................. 59
6.3.25 String Replacement Example Plain Text ...................................................................................... 60
6.3.26 Logout of TallyCom ........................................................................................................................ 61
6.3.27 Restart TallyCom ........................................................................................................................... 61
6.3.28 Virtual Control Panel ..................................................................................................................... 62
7 Addendum ......................................................................................................................................................... 63
7.1 Character Set............................................................................................................................................ 63
7.2 Control Codes Summary .......................................................................................................................... 68
7. 2.1 PJL commands ................................................................................................................................ 77
7.2.2 Barcode ............................................................................................................................................ 77
7.2.3 List of available MTPL barcodes ..................................................................................................... 78
7.2.4 US Postnet barcode ........................................................................................................................ 79
7.2.5 Royal Mail Customer barcode......................................................................................................... 80
7. 2.6 KIX bar code ..................................................................................................................................... 80
7. 2.7 USPS Intelligent Ma i l barcode ........................................................................................................ 80
7.2.8 LC printing ........................................................................................................................................ 81
7.2.9 List of additional control Codes....................................................................................................... 82
7.3 Interfac es Spec i fi catio ns .......................................................................................................................... 83
7.3.1 Parall el I/O IEE E 1284 .................................................................................................................... 84
7.3.2 Ether n et I /O 10/10 0 M ul i tp r ot oc ol ................................................................................................... 85
7.3.3 USB 2.0 I/O – Full Speed ................................................................................................................ 86
7.3.4 Optional Serial Interface RS232C .................................................................................................. 87
7. 3.5 USB A Host ...................................................................................................................................... 92
8 Options and accessories................................................................................................................................. 93
8.1 Options ...................................................................................................................................................... 93
8.2 Consumables ............................................................................................................................................ 93
8.3 Accessories ............................................................................................................................................... 94
9 General Specifications .................................................................................................................................... 95
9.1 Printer Specifications ................................................................................................................................ 95
9. 2 N on-Scalable Fonts, Code Pages and National Character Sets ........................................................... 98
9.3 Paper Specifications ............................................................................................................................... 100
2
Tally Dascom 2600+/2610+
9.3.1 Standard Tractor (Front, Rear and Pull position) – narrow and wide versions .......................... 100
9.3.2 Front F eed / Ma nual Ins er ti on – Nar r ow and wide v er si o ns ....................................................... 101
9.3.3 Paper Weights ............................................................................................................................... 101
10 Maintena nce ................................................................................................................................................ 102
10.1 Cleaning ................................................................................................................................................ 102
10.1.1 Cleaning and Vacuuming the Printer .......................................................................................... 102
10.1.2 Cleaning the Paper Rollers ......................................................................................................... 102
10.2 Troubleshooting
10.2.1 Print Quality Problems and Solutions ......................................................................................... 103
10.2.2 Paper Handling Problems and Solutions ................................................................................... 104
10.2.3 Oper a ti ng Problem s and Solutio ns ............................................................................................. 104
FCC STATEMENT ........................................................................................................................................ 105
.................................................................................................................................... 103
Symbols used Important information is highlighted in this manual by two
symbols.
CAUTION highlights informatio n which must be observed in ord er to preve nt injuries to user and damage to the pr inter
NOTE hig hlights gene r al or additiona l information about a specific topic
.
3
Tally Dascom 2600+/2610+

1 Printer at a gl ance

1.1 Unpacking the printer

Bes ides this manua l, the pa cka ge will cont ain: a powe r cord, a ribbo n cart ridge , a tractor, a CD and 6 pieces of U-wire paper support.

1.2 Remove t ransp ort locks

1
Tally Dascom 2600+/2610+

1.3 Prepare your printer

Front View
Rear View
2
Tally Dascom 2600+/2610+
For Fanfold
For Cut Sheets
3
Tally Dascom 2600+/2610+
7
9
11 13
15

1.4 Parts description

1
Control Panel
2
Latch
3
Front Cover
4
Power Switch
5
Hand Whee l
Sliding it down unfo lds the c ut she et support.
Unlock ing the fro nt co ve r unfolds the cut sheets support.
Turns on and off the printer.
A LCD display and two keys indicates the ope ra ting status and allows simple settings of the pr inter.
Turn the knob to load or clear the paper . It s hould be inser ted the full way until you can hears some sort of “Click”.
6
Paper Support
At slanted posit ion, it stacks cut sheets; at flat position, it separates fanf old printouts from incoming for m s .
Top Covers 1&2 Protect the internal parts and r educe the noise.
8
Head Gap Lever
Adjusts the gap between the print head and various form thickness.
Paper Path Lever Selects various paper sources.
10
Upper Friction Guides the form when cut sheets or fanfold forms are used. Power Socket
A power cord is plugged into the socket to supply the power.
12
Interfaces
The interface cable of the host computer is plugged int o one of the interfaces.
Mute Cover Latch You must open it before you open the top cover 1.
14
Print Head Utilizes 24 needles to strike on ink r ibbon and paper . Ribbon Cartridge Holds t he ink ribbon fabr ic .
16
Tractors Holds and transports fanfold forms.
17
Paper Guides Left/Right
18
Cut Sheet Support A flat sur face suppor ts a sheet or multi-part form.
Sliding t he guides va r ies the form width and the left margin on a cut sheet.
4
Tally Dascom 2600+/2610+

2 Installation

2.1 Pl acing the printer

Place the printer on a solid, flat, stable surface such that the printer sits firmly and cannot move. Sel ect an environment with sufficient v entilation, easy access to the control pan el and paper input areas as well as the pr inted output.
When selecting the printer loca tion, obs erve the following additional requirements:
1) Never p lace the print er near to any flammable gas or explosive substances.
2) Do not expose the printer to direct sunlight. If you cannot avoid placing the
prin t er near a window, protect it from the sunlight with a curtain.
3) When connectin g a computer to the pri nter, make sure the maximum recommended cable lengt h i s no t exceeded.
4) Ensure sufficient distance between the printer and any heating devices/radiators.
5) Avoid exposing the printer to extreme temperatu re or air humidi ty f luctu at ions. Above all, avoid dusty environments.
5
Tally Dascom 2600+/2610+

2.2 Connecting the printer

This print er is conf igur ed with a Parallel, USB and Ethernet interfa c e as standard. An optional Ser ial interface ca n be ins talled additionally.

2.2.1 Parallel interface (IEEE 1284) Make sure that the printer and the computer are switched off and connect the par allel cable

between the printer and the computer. Lock the connector with the 2 clips on the printer interface connector; tighten up the 2 sc re ws on the other end connecting to the computer.

2.2.2 USB 2.0 (F ull S peed) Plug in the USB cable to t he pr inter and the computer.

2.2.3 Ethernet

6
Tally Dascom 2600+/2610+

2.2.4 Serial Interface (RS-232C) a s option

2.2.5 Connecting the power Plug in the power co r d to the printer power socket as shown in the diagram.

Conn ect t he printer to the correct voltage power source.
The so cket-outlet shall be installed near the equipment and shall be easily accessible.

2.2.6 Swit c h on t he printer Swit c h on t he printer as shown in the diagra m .

7
Tally Dascom 2600+/2610+

2.3 I nstall ing the ribbon cartridge

1) Swit c h off the power.
2) Unfo ld the top cover and follow the steps 1.2.3.4.5 in t he below picture.
3) Flip the upper friction assembly
8
Tally Dascom 2600+/2610+
4) I nse r t the ribbon cartr idge till it is tightly lo c k ed in position.
5) Take of f the Ribbo n Guide fro m Ribbo n Cartr idge and insert it betwee n Carriage and Ribbo n Mask.
6) Turn the knob on the left hand side sever al tim es in order to tighten the fabric, and the
fa br ic will slide downwards into the correct position between print head and r ibbon mask after the moving.
7) Restor e the upper friction assembly to its original pos ition.
Print head may be h ot, pl ease move the pri nth ead by moving the carr iage.
9
Tally Dascom 2600+/2610+
1-part
1
Original + 1 copy
2
Original + 2 copies
3
Original + 3 copies
4
Original + 4 copies
5
Original + 5 copies
6

3 Installing the paper

The print er can ha ndle either single s heets or continuous forms. The printer is able to print up to 5 co pies (original plus 5) .
To ensure the print quality and protect the print head, set a proper print gap by the gap l ever ( see 3.1) for the form thickness and do not load folded, damaged, wrinkled, or curled paper.

3.1 Adjusting the print gap for various form thic knesses

The print gap lever is on the left side of the printer inside the top cover. Take care to adjust the print gap lever to a suitable position whenever you change the number of copies being printed. Using the wrong print gap may cause print head damage or paper jams.
The recommende d gap le ve r position for dif ferent form t hic k ness is:
Paper type Lever position
The po s ition “Ribbon” only is suit able for loading the ribbon. When the le v er is set highe r than appropriate it will r esult in poor print. The ribbon and head life will be shortened.
10
Tally Dascom 2600+/2610+

3.2 Paper path introduction

3.2.1 Cut s heet paper handling (front friction only)

1) Place the paper path lever to the cut sheet position.
2) Unlock the front cover with the latch to unfold the c ut she et support.
3) Adjus t the gap lever if necessary; see 3.1.
4) It is re commended to align t he le ft paper guide exactly to the mark > I <. This ma r k s the left
edge of the stationery. Slide the right guide to the pos ition of the right edge of the stationery.
5) Insert the statione r y st ra ightly all the wa y into the guided slo t until it stops.
6) Press the load key to feed the paper to the correct print position, automatically. The printer
clears the Paper End condition and goes into the ready or online state.
11
Tally Dascom 2600+/2610+

3.2.2 Fa nfold paper handling

3.2.2.1 Front push tractors for fanfold
1) Close the front cover if previously opened. Switch the paper path lever to one of the
desired tractor positions.
2) Mov e the paper path lever to the desired position.
3) Adjus t the head gap lever if necessary .
4) Open the front cover by tilting the cover fro m bottom to the to p, a nd m ake sure it’s locked in
place (see below pic tures).
Lock the front cover in the way that is shown in the pictures.
Make sure the front cover is l ocked.
12
Tally Dascom 2600+/2610+
5) I f you do not need to a djust the lef t ma rgin go to the next ste p. Ope n the right a nd left tractor
fla ps , insert fanfold paper into the lef t-hand tracto r, and ma ke sure tha t at lea s t three paper transport holes are positioned on the tractor pins, close the tractor flap, open the latch lever and align the tractor so that the first printing position o n the paper matches the IIIIXIIII mark on the printe r housing, then lo c k the le v er again.
6) Align the right-hand tractor to th e width of the paper and insert th e paper ( Make sur e that it
is inserted by the same length as on the left-hand tractor in order to avoid any paper jam). Then close the tractor flap and slide the tractor to the right until the paper is slightly tensioned, then lock the tractor.
7) L ower t he fr ont cover, switch the printer on. The ac tive paper source (TrFront) appears in
the displa y, the pa per will automatically load when t he print er is in online mo de and rec eive s data from the computer. Also, you can press the load ke y (key 4) only to load paper before starting the printout.
13
Tally Dascom 2600+/2610+
3.2.2.2 Rear tractors for fanfold
14
Tally Dascom 2600+/2610+
3.2.2.3 Top pull tractors for fanfold
For the steps ② and ③, p lease refer to the 2.3
15
Tally Dascom 2600+/2610+

3.2.3 Top-Of-F orm adjustment

Fo r pull tractor (PullTr), follow the steps be low to adjus t the first pr int position:
1) Remove Paper from printer.
2) Power on the printer.
3) Lift the Top Cover so you can see t he tra ns parent ribbon guide in front of the print head.
4) Install the paper into the pull tra c tor.
5) Move the paper w ith the hand wheel so the pe r foration of the fa nfold paper lies exactly at
the top of the tr ansparent ribbo n guide.
6) Close the Top Cover.
7) Press the Load key on the panel.
8) The pr inter now moves the paper to the corr ect first print position on a pa ge (TOF ) .
16
Tally Dascom 2600+/2610+

4 Cont rol Pane l Operati on

Gener al fun c tions f or the keys ar e c l early design at ed on the P an el label. Some ot her s p ec ial sett i ngs need pressing multiple switches simultan eously or holding some keys when powering on the printer. This Chapter will describe the functions of the keys and display on the Panel.

4.1 Operation of the LCD Panel

The Online mode is the printer’s normal operating mode. Data from your computer can be
received and printed.
In the Offline mode the link between printer and computer is interrupted, i.e. no data can
be received and printed.
In the Setup mode you can either select the printer menu or carry out the quick-switch
function. The quick-switch option wa s inc luded so that you can change the most important parameters (f or example adjustments, character density, font, paper path, adjustments directly without having to enter them via the menu. The settings for the parameters character density and font are lost when the printer is switched off. They can be selected permanently in the menu mode of the printer.
In the Menu mode further printer settings (line spacing, size of the interface buffer etc.) can
be altered and saved permanently.

4.2 The LC display

The LC display tells you all the important printer settings and informs you which functions are currently assigned to which keys.
The upper line informs you that the printer is either in online or offline mode (in the example below the printer is in the Online mode), a nd the selected paper path (below: TrFront = tractor front mode).
17
Tally Dascom 2600+/2610+

4.3 Online mode

After switching on, the printer is automatically set to online mode. Only in this mode can it receive data from the computer.
Online key: To ggle betwee n Online and Offline mo de.
Tear key (4): Activates the tear function when fanfold
paper is loaded.
If Load is displayed above this key, no paper is loaded
in the printer or the paper is in park position. In this case the display switches between Online and Park
Position. Press the key to feed paper to the printing position.
Setup key: Sets the printer to setup mode.

4.4 Offline mode

Only in this m ode is it poss ible to perform s tep, line, or form feeds from the control panel, however, data cannot be received.
Park key (1)
If fanfo ld paper is loade d in the printer, it is fed to the
park position or the tear po s ition. If a single sheet is loaded, it is ejec ted.
key (2)
Each press: Paper is transported upwards ste p by step. Holding: Continuous tr ansport upwards.
key (3)
Each press: Paper is transported do wnwards step by step. Holding: Continuous t r ansport downw ards.
LF/FF (4)
Paper in the printer: Each press: performs a line fe ed (LF). Holding: performs a form feed (FF).
Load key (4)
No paper in the printe r : The pre s s on this key loads t he paper to the first pr int position.
Setup key: Sets the printer to setup mode. Online key: Sets the printer to online mode.
18
Tally Dascom 2600+/2610+

4.5 Setup mode

I n this m ode, the following settings ar e available :
Setup key: Sets the printer to set up mo de, in which the
following settings can be selected.
Menu key (1): Othe r menu settings. Access may be
disabled by menu settings (see note below).
Adjust key (2): Sets the Tear position and fir s t printing line
(TOF). If yo u have the PullTr (Pull - Tra cto r) selected Adjust is not av ailable.
Char key (4): Sets the font and the number of characters
per inc h temporar ily .
Access to t he other menu set t ings (Menu) may be disabled by the man ufacturer.
Proceed as follows to release this lock temporarily.
1) Switch off the printer for approx. 5 seconds.
2) Switch the printer on again kee ping the Setup key pressed.

4.6 Power on functions

If yo u k eep o ne of the following keys pr essed during power-on unt il the printer has co m pleted initia liz ation, t he c orresponding funct ion is activ ated:
If you keep the Online key presse d while turning on t he printer, you ent er t he pr inter’s
advanced menu mode. The advanced menu mode is described in the section 5.4.2 manual.
If you keep the Setup key pressed while turning on the printer, you regain access to the
printer menu if you had lo c k ed it before with the help of the Menu Lock function.
If all four function keys (keys 1 to 4) are press ed simultaneously while turning on t he power,
all printer settings are reset to the default values , exce pt the Forml (Form length) s etting in advanced menu mode.
Holding Function key 4 while turning on the print er prints out the par ameter settings.
of this
19
Tally Dascom 2600+/2610+

5 Printer Setting

(Progr amming via the c ontrol panel)
Apart fro m being able to cont ro l yo ur pr inter via the applicatio ns so ft ware you use, you can also program the printer directly . The r e a re two programming options you can us e:
Programming via t he control panel. Program m ing v ia the interface using Escape se quences or control codes.
Settings made by escape sequences have priority over settings made i n menu
mode; therefore they will override th ese.
Pro gr amming via the interface gives you far greater free dom for designing your printed pages, however, it is also a more sophisticated method and r equires some ex perience with progr amming langua ges and printer control syste m s .
All pr ogramming via the interface is lost a fter you turn of f t he pr inter, whe reas t he progr am ming ca rrie d out using t he contr o l panel is save d and sto red eve n after you turn of f the printer.

5.1 S ett ing the param eters thr ough the LCD Panel

This chapter descr ibes the handling of the opera tor’s panel wit h optional display.

5.1.1 Enabling acces s to me nu m ode

The menu can be locke d by default to protect it from accidental or unaut horized acces s . Proceed as follows to release this lock temporarily.
1) Sw itch off the printer for approx . 5 seconds.
2) Sw itch the printe r on again keeping the Se tup key pressed.
Calling up the me nu
You c an a c ce s s the me nu in the following way:
Press the Setup key. The printer switches to Setup mode. (The Setup mode can be s ele c ted both in the
Online and Offline mo de ) To access the printer menu, press the key directly underneath the wor d M enu (1).
20
Tally Dascom 2600+/2610+

5.1.2 Menu configurations

Eve r y pr inter is shipped with factory def ault settings. B asic settings s uc h as emulation, char acter size, form length etc., which many applica tions make use of , are se t. A t the end of this chapter you will f ind a menu printout which shows yo u the printer’s default settings.
Your pr inter allows you to set a nd us e fiv e independent menu configurations. If one of your applications, for example, requir es an IBM printe r while anothe r program works be tter w ith a n EPSON pr inter, you can set an IBM emulation c onfigurat ion with the desired settings, and set the se c ond configuration as an EPSO N em ulation.
The a c tive menu is alwa y s the one y ou used last. When you switch on t he pr inter for the very first time, menu no. 1 is loaded. Menu no.1 only r emains active until you load a nother menu. The la s t ac tive menu is sto re d ev en aft er the printer is sw itched off and is re loaded aut omatically when the printer is switc hed o n again.
For example, to change from menu no. 1 to menu no. 3:
Press Setup key.
Press Menu (1) key.
Press Menu (3) key.
Now t he following me s sa ge appears in the LC display: Now pre s s the < ( 2) or > (3) k ey repeatedly unt il Load Menu=3
appears. Then select menu no. 3 a s the c ur r ent setting using the Set key (1). The currently active setting is ma rked with an asterisk (*).
If changing menus it is possible that t he pr in t e r initializes due to different
emulation settings.
21
Tally Dascom 2600+/2610+
Menu Printout
22
Tally Dascom 2600+/2610+

5.1.3 Menu handling

You c an na v igate in the current menu using the four function a nd se lection keys arr anged below the LC display field. Each function and parameter displayed in the LCD is exe c uted or selected by the cor r esponding key below, respectively. Usually two parameter gr oups are com bined at o ne leve l. In the fo llowing ex am ple, the se are the LPI a nd Skip par ame ter gro ups.
If yo u do no t wis h to change one of the tw o parameters you can either press the Next key (to acc ess the two follo wing parameter gr oups in the menu) , o r yo u ca n pr ess the Back key (to acc ess the two previous paramete r groups in the menu).
If yo u want to change a setting, (e.g. t he line density) , t hen press the LPI ke y (LPI = lines per inch) to access the actual parameter level.
The currently valid setti ng is m ar k ed by an as t er i s k (in t h e exam p le bel ow the cur r en t setting is 6 lpi). With the < and > keys you can view the other parameters available for this setting.
Example:
Save settings
Once the desired para me ter is displayed on the LC display, you can save it by pres s ing the Set ke y. The paramet er is t hen set a nd the printe r aut oma tically displa ys t he para mete r groups again. With the Exit key you can leave the s ublevel without sa v ing y our changes.
23
Tally Dascom 2600+/2610+

5.1.4 Selecting the LC dis play language

This sec tion describes how to make set tings in the menu, us ing the selection of the national language as an exam ple.
I n this us er guide all LC dis play messages are shown in English language. Your printer o ffers also the po s s ibility to show t he dis play messages in German, French, Italian, Spanish or Turkish language. This example shows how to change fr om t he E nglis h language to the Ge r ma n language. The same proce dur e applies to the ot her languages (Fr enc h, Italian, Spanis h and Turkish).
Select the Setup mode by pressing the Se tup key.
Setup mode and Menu mode may be disabled. Hold down the Setup key while switching on the printer to enable menu m ode. If you want to enabl e access to this mode permanently, you need to change the approp riate setting in the menu.
Press the next key ( 4) se v eral times until the display indica tes Language.
Press the Language key (3).
The display now change s to Pa ra m eter mode and indicates
English in the top line. The lo wer line displa y s Se t and Exit. The two ar ro ws < (2)
and > (3) represent the symbols for parameter selection
(“<” indicates descending a nd “ >” ascending). P r ess the <
(2) or > (3) key until the desired language is displayed, in our example German.
Sav e y our selectio n by pre s s ing the Set key ( 1) . An acoustic signal v erifies t his a c tion.
You can exit Parameter mode without saving a setting by pres s ing the Exit key ( 4) , the old setting is retained.
Aft er saving your sett ing ( S et), the displa y in our example
Ges.Men indicates the following tex t:
Thi s setti ng is retained even after switching off your printer.
Terminating Setup mode press either the Setup key to change into Offline mode or the Online key to change to Online mode.
24
Tally Dascom 2600+/2610+
MENU
Menu
Font
CPI
ETH-INT
Format
1)
Special
1) 2)
Protocol
1)
DTR
1)
CG-Tab
CharSet
Single
Tr Front
Tr Rear
Aut o Tear
Barmode
FFmode
RightMrg
Country
Language
Eject
Quietm

5.2 M enu structure

The menu structure o f your printer may be s lightly differ ent from the example shown here, depending on the pr inter software.
Back
Next
1) Only with optional serial interface
Print
Reset
LPI Skip
ESCChar Emulate
Bidir
I/O
Serial
1)
Interf.
Baud
LeftMrg
Barcode
Width
Paper
Buffer
1)
MenLock
Auto-CR
Pull Tr
Auto-LF
Sl.Zero
2) Only if ENQ/STX, ETX/ACK or ACK/NAK proto col is selected
25
Tally Dascom 2600+/2610+
Adjust
TOF Tear Print
Print t he menu settings.
Menu
Load Menu=1
A menu is loaded, you can choose
Reset
Reset Menu Yes No
We the ref o re recom mend that you print
Quietm
Off
Font
HS-Draft
Draft
Draft Copy
Roman LQ
Roman PS NLQ
Roman PS LQ
CourierNLQ
Sans Serif NLQ
Sans S er i f LQ
Couri er LQ
S Serif PS NLQ
S Serif PS LQ
Prestige NLQ
Prestige LQ
Script NLQ
Script LQ
OCR-B NLQ
OCR-B LQ
Couri er I NLQ
Couri er I LQ
Orator LQ
Sou venir NLQ
Courier I PS NLQ
Gothic NLQ
CPI
10 CPI, 12 CPI, 15 CP I, 17.1 CPI, 20 CPI,

5.3 Full lis t paramet ers set ting

5.3.1 Menu Configurat ion list

Menu
V alid Settings Function
Load Me nu=2 Loa d M enu=3 Load Me nu=4 Loa d M enu=5
On
Setting the tear po s itio n. Setting the first pr inting line (TOF).
bet ween five menus .
Press the No (1) or Yes (2) key to select the desired setting.
All m anually alte re d settings in the current menu ar e lost when it is rese t to the default settings.
out the menu first. Swit c hes between nor m al a nd quiet
mode printing. For all printing
OCR-A NLQ OCR-A LQ Orator NLQ
Sou venir LQ Couri er I PS LQ Gothi c LQ
5 CPI, 6 CPI, 7.5 CPI, 8.6 CPI.
modes, the print-o ut is made with the bidirec tional method in quiet mode printing. In the firs t step the first ro w of pins is a c tivated, during the second step the se c ond row is used.
This parameter selects the character style a nd its quality permanently.
Sets the characters per inch (character pitch). The higher parameter the smaller character spacing.
26
Tally Dascom 2600+/2610+
LPI
6 LPI, 8 LPI, 12 LPI, 2 LPI, 3 LPI , 4 LPI.
Skip
Skip=0.0 Inch, ESCChar
ESCChar=ESC
Emulate
Epson LQ-2550
another printer type, it is said to emulate
Bidir
Bidir=On Bidir=Off
I/O
Serial
Baud
Baud=9600
Format
8Bit No 1Stop
7Bit No 2Stop
Sets the lines per inch (line density) . The highe r parame ter the smaller line spac ing ( r andom LPI can be se lected via the ESC sequences).
Skips the perforation; 7 diffe r ent values
Skip=0.5 Inch, Skip=1.0 Inch,
(in inche s ) c an be define d. Skip=1.5 Inch, Skip=2. 0 Inch, Skip=2.5 Inch, Skip=3. 0 Inch,
Skip=3.5 Inch.
Selects the start signal for control ESCChar= ESC+$$
sequences. Setting ESC: Only chara cte r
Escape can be used. Setting ESC+$$:
Character Escape or alternatively two
$ characters ($$) can be used.
Epso n LQ-2170 I B M Propr. XL24 I B M ProXL24+AGM Epson FX MTPL
Baud=19200 Baud=600 Baud=1200 Baud=2400
Selects the emulation. When a print er
unders tands the control set wr itt en fo r
the other printer.
Setting On: Printe r pr ints in both
direc tions (bidirec tional).
Setting Off: Printer prints only in one
direc tion (from left to right).
Selects the data transmission rate (baud
rate) (baud=bit pe r se c ond).
Baud=4800
8Bit No 2Stop 8Bit Even 1Stop 8Bit Odd 1Stop 8Bit Mark 1Stop 8Bit Spc 1Stop
27
This parameter serves to define t he
number of data bits, the parity check for
rec eived data bytes and the number of
stop bits per data by te.
Tally Dascom 2600+/2610+
7Bit Spc 2Stop
Protocol
XON/XOFF
ACK/NAK
DTR
DTR=DTR
Interf.
Interf.=Share
Buffer
Buffer=0 KB
IPv4Addr
Octets 1-4
Input of the IPv4 address of the printer
Gateway
Octets 1-4
7Bit Even 1Stop 7Bit Odd 1Stop 7Bit Even 2Stop 7Bit Odd 2Stop 7Bit Mark 1Stop 7Bit Spc 1Stop 7Bit Mark 2Stop
This parameter serves to selec t the typ e
Robust XON/XOFF ENQ/STX
of protocol, i.e. a certain set of rules and
proc edures for e ns ur ing error-free data
exchanges between computer and
ETX/ACK
printer.
DTR=Ready
Interf.=Parallel Interf.=Serial
Buffer=32 KB Buffer=64 KB Buffer=96 KB Buffer=128 KB Buffer=160KB Buffer=192KB Buffer=224KB
Def ines the conductor t o which the DTR
signal is c onnected
(DTR=Da ta Term inal Ready ).
Selects the interface. Printer is
configured either for par allel. Ethe r net or
optional se r ial connection or in
automatic change for the parallel or the
optional serial interface (Shared).
Sel ec ts t h e size of the interface buf fer.
Buffer=256KB
ETH-INT
0 to 255
0 to 255
This menu level offers the possibility to
set the IPv4 addre s s, whic h is div ided
into four digit groups (octet 1 to 4). The
IPv6 IP address settings are ex ecuted
fully automatic.
Input of the Gateway address of the
printer.
28
Tally Dascom 2600+/2610+
Subnet
Octets 1-4
Input of the Subnet mask address of the
IP Get M
DHCP BOOTP
Selects the way of administrating the IP
Banner
Off On
be printed out, w he n us ing the LPD/LPR
EthSpeed
CG-Tab
CG-Tab=Graphic
CharSet
Extended Standard
Country
E-US ASCII
E-France
E-German
E-UK
E-Denmark I
E-Sweden
E-Italy
E-Spain I
E-Japan
E-Norway
E-Denmark II
E-Spain II
E-L.America
E-Korea
E-Legal
ISO8859-5
ISO8859-7
ISO8859-9
ISO8859-15
ELOT-928
BRASCII
Abicomp
Roman8
US-ASCII
UK ASCII
French
German
Italian
Swedish
Norwegian
Cro-ASCII
Coax/Twinax
Tab l e 43 7
0 to 255
Static
printer.
address.
Specifies whe ther a banner page is to
protocol.
Auto-Sense The tr ansmission speed is detected
automatically.
10Mbit Half Sets the tra ns m is s ion speed to 10 MB it
half duplex per second.
10Mbit Full Sets the transmiss ion speed to 10 MB it
full dup lex per second.
100Mbit Half Sets the trans m is s ion speed to 100 MBit
half duplex per second.
100Mbit Full Sets t he t r ansmission s peed to 100 MBit
CG-Tab=DLL CG-Tab=Italic
ISO8859-1 ISO8859-1 SAP ISO8859-2
Spanish Portuguese Greek DEC
full dup lex per second.
Only available fo r E ps on
LQ-2550/LQ-2170 emulation. Either the
Epson character set Italics or the IBM
graphics character set or a DLL
(download) chara c ter set, as defined
before, can be activated in the code
range from hex. A0 to hex. FE.
Selects the IBM standard characters or
the extended IBM char ac ters.
Selects the national character set.
These character sets can be used
acc ording to the selec ted emu lation .
29
Tally Dascom 2600+/2610+
New-437
Tab l e 73 7
775 Bal ti c
Tab l e 85 0
New-Dig 850
Tab l e 85 1
Tab l e 85 2
Tarama
Tab l e 85 7
Tab l e 85 8
Tab l e 86 0
Old-Code 860
Tab l e 86 1
Tab l e 86 3
Flarro 863
Tab l e 86 5
865 Hebrew
Tab l e 86 6
866 Bul g ar i a
866 Ukraine
866 Kazakhs t.
Kamenicky
Mazovia
Siemens Turk.
DEC T urkish
Tab l e 12 50
Tab l e 12 51
Tab l e 12 52
Tab l e 12 53
Tab l e 12 54
Tab l e 12 57
Sl.Zero
Sl.Zero=Off Sl.Zero=On
AutoCR
Auto-CR=On Auto-CR=Off
AutoLF
Auto LF=Off A uto LF=On
Switches the automatic line feed (LF) on
Menlock
Menlock=Off
(se tting the print head gap [ Head], top of
Selects if normal zero (0) or the slashed
zero (Ø) is printed.
Menlock=Menu Menlock=All
Swit c hes the automatic carriage retur n
on or off after receiv ing the signal LF
(line feed).
or off after receiving the signal CR
(carriage return).
With MenLock=Off, all funct ions and
settings are acce s s ible without
res triction in Online, Offline and S etup
mode.
If MenLock=Menu is activated, all
functions and settings are still
acc essible in Online a nd Offline mode,
however, in Se tup mode you can only
acc ess the para me ter groups Adjust
form [TOF] and tear position [Tear]),
Paperway (setting the paper path), Font
(se tting the font) and the character
spac ing ( CP I), while access to Menu
mode (Menu key) is disabled.
If you select MenLock=All, you can
acc ess the Online/Offline, Loa d/Park,
Paper and Paper Feed (LineFeed/Form
Fee d, / ) functions in O nline a nd Offline
mode w hile Setup mode is dis abled.
I n this c ase, the Setup menu c an o nly
be called up by holding the key Setup
while switching o n the pr inter.
30
Tally Dascom 2600+/2610+
Language
English German French Italian
Paper
Single TrFront TrRear PullTr
Formlen
Lines
=6 – 132 Please note that the adjus tment in Line s
example 8 LPI at a sele c ted line number
inches . The se lec table range is between
Standard
No format fo r ma ts. Using St andard, different paper
FormAdj
FormAdj=0 -220/72”
n/72 inch, s eparately adjustable for each
The menu can be shown in six Spanish Turkish
languages.
Selects the paper parameters Formlen
(form length), FormAdj (first print ing
position/TOF) separately for each paper
source in the current menu.
Sets the form length via line formats.
Default 6LPI = 66
depends on the selected LPI. For
Single:322 inches TrFrontTrRear PullTr:122 inches
DI N A3 (420 mm) DI N A4 (297 mm) DI N A5 (210 mm) DI N B 5 ( 250 m m ) DI N B 6 ( 176 m m ) DI N C6 ( 162 m m ) Exe c utive 10.5"
Letter 11"
of 96 lines results in a form length of 12
inches ( 96lines/[8lines/inch]) = 12
3 and 21 inches, i.e. fo r 2 LPI from 6 to
42 lines and for 12 LPI fro m 24 to 262
lines.
If t he form length is set it will not be
changed by changing the LPI later on.
Selects the fo r m le ngth by standa r d
formats can be select ed directly, e.g.
DI N A4, Legal, Lette r.
The Menu indicate s No format if a value
is se lected by the Line function or ESC
sequences, which does not correspond
to a standard format.
Fa nfold 12” Legal 14"
Def ault 12/72”
Sets the first print position of a for m in
paper path.
31
Tally Dascom 2600+/2610+
Autotear
ViewTear =Off
printed text is visible. A s soo n as data is
Width
Width=13.6Inch Eject
Eject=Top
It controls the exit direct ion of the frictio n
Barcode
Barcode=Off Barmode
Unsecured
FFmode
FFmode=Off
LeftMrg
Wide: LeftMrg=0 - 134/10”
RightMrg
Wide: RightMrg=2 - 136/10”
The a uto tear functio n or the auto view View=1s/3s/6s
function can be selected as desire d. Tear=1s/3s/6s
Tear at TOF
Width=8Inch Width=13.2Inch
When a uto view is switched on, the last
received the paper moves to the
“nor m al” print position. A fter printing the
printer waits for the giv en interval to
bring the paper once more to the auto
view po s ition.
The pa per is in the tear off position
when auto tear is switche d on, the
perforation of the positioned at the tear
of f edge o f t he pr inter. If data is
rec eived, the paper ret ur ns to the
norm al print posit ion. Af ter printing, the
printer waits for the giv en interval to
bring the paper once more to the tear off
position. If the tear off edge doe s is not
aligned with the pe rforation of the paper
then this can be corrected.
Selects the line length in inches. With
the setting of 8 Inch, the printer operates
like a printer wit h a width of only 8
inches.
Eject=Front
Barcode=On
Secured
FFmode=On
Narrow: LeftMrg=0 - 78/10”
Narrow: RightMrg=2 - 80/10”
This is va lid for single sheet mode only.
sheet paper.
With this f unc tion selected it is poss ible
to pr int different bar c odes a nd LCP
(Lar ge Character P r inting).
Allows printing of normal characters on
the left and right of the barcode.
Specifies whe ther a form feed is to be
performed when the paper reaches the
to p pr int line.
The le ft print mar gin c an be se t to a
fixed value.
The right pr int margin can be set to a
fixed value.
32
Tally Dascom 2600+/2610+
Advanced
ASCII80
8 inch wide print of test pattern
ASCII136
13.6 inch wide print of t est patter n
H-Dump
dat a fr om the computer is printed o ut in two
Formlen
12” 11”
APW
APW=Off
Paphand
Physlm
Physlm=0 - 30/10” mar gin. This parameter cannot be changed

5.3.2 Advanced Menu

Menu
(only 2610)
V alid Settings Function
To check operational readiness, your printer conta ins a se lf-test routine whic h allows testing o f t he pr inter configuration, the pr int quality and correct operat ion of your pr inter .
With the interface te s t(Hex-Dump/H-Dump) you can test data transmission from the com puter to the printer. During t his test, the
colum ns . The text in the left column is printed in hexadecimal format and in the right column in ASCII for ma t.
APW=On
PLM
PLM=On PLM=Off
The Formlen function allows you to set the basic (default) form length to meet your requirements. 11 inches are common in the USA , as opposed to 12 inches in E ur ope.
Automatic paper w idth recognition. If set to On, the printout outside of actual
loaded paper is s uppr essed.
Permanent ( phy s ic al) setting of the left by em ulation depe ndent margin settings.
Mar gin s etting values entered by ESC seq u ences are add ed t o t h e Ph y s lm.
Parameter “PLM”. This item’s full name is Paper Load Mode. It is located beneath the already existing m enu item “Papha nd” (Pa per Handling).
This setting enables (on) / disable s (o ff) a horiz ontal carr iage movement in order to fla tten the paper so it finds its way into the upper friction.
However the movement is determined by the me nu items Pagewid & Widt hc on.
If Widthcon = Off Narrow: The movement of carriage goes all
the way = 8”
33
Tally Dascom 2600+/2610+
Wide: The movement of carriage goes all
Par ameter “Pagewid” . This item’ s full name
s se tting enables (on) / disable s (o ff) the
CX-bid
CX-bid=ON
bid=ON se ts the pa ralle l int erfa ce of the
com patibility mo de in order to ensur e
the way = 13.6” If Widthcon = On Narrow/Wide: The movement of carriage
goes rightmost to Pagewid Position This function is ON by default and is valid
for Rear Tractor only .
is Pa gewidth. It is located beneath the alr eady exist ing
menu it em “Paphand” ( Pa per Handling). This setting tells t he printer logic the width
Pagewid
2610+:Pagewid=20 136 /10” 2600+: Pagewid=20 80 /10”
of the installe d pape r and is v alid for all paper ways.
By de fault this parameter is maxim um width.
Widthcon
Widthcon=Off Widthcon=On
2600+: 80 Characters (80/10”) 2610+: 136 Characters (136/10”) The value can be c hanged in 1/10” in a
range between 20 a nd 136 ( 80) . Par ameter “Widthcon”. This item’s full
name is Width Control. It is located beneath the alr eady exist ing
menu item “Papha nd” ( Pa per Handling). Thi
poss ibility to define the position of the car r iage during loading & ejecting pape r.
If Off 2600+: t he carriage’s position is 4” 2610+: t he carriage’s position is 5.3” If On 2600+/2610+:Half of Value defined in
Pagewid This function is OFF by default and is valid
for al l paper ways.
CX-bid=OFF
CX­printer to bidirect ional mode (IE E E 1284, Nibble mode), e. g. for Windows Plug & Play.
CX-bid=OFF sets the interface to
34
Tally Dascom 2600+/2610+
reliable oper ation with special external
Wrap
Wrap=On
Wrap=On: If more characters than can be
line are cut off.
Sound
Sound=On
Pap.back
Pap.back=normal
Hvy Form
HvyForm=ON
SerialN
factory set
AssetN
10 digit s empty GrSpeed
GrSpeed=Normal
ndent ly to the driver . It affects
Jobcntl
Jobcntl=On
This parameter a ctiv ates the print er
boxes.
Wrap=Off
Sound=Off
Pap.back=dark
HvyForm=OFF
printed are transmitted per line , t he char acters which cannot be printed on t his line a re printed at the be ginning o f nex t line . Wrap=Of f: If more characters than can be printed are transmitted per line , t he char acters which cannot be printed on t his
When Sound=On, a bee p is generated every second to notify that paper is em pty.
Pap.back=norma l is the standa r d for norm al paper.
Pap.back=dark can be set to process paper with a grey back.
Paper with a complete ly black back side cannot be used if the ink is carbon-based. However, the printer can handle aniline­based black pa per ( undefined colors).
If yo u s et HvyForm=ON, the pr inter prints the sa m e line twice at do uble strike. This setting ensure s that copy paper pro duc es optimum results.
GrSpeed=High
Jobcntl=Off
With the S erialN function you have the poss ibility to cha nge t he 12 digit serial number of the printer. The num ber can be writ ten with any ASCII chara c ter between hex 20 and hex 7E.
With the A ss etN f unc tion you have the poss ibility to cha nge t he 10 digit asset number of the printer. The num ber can be writ ten with any ASCII chara c ter between hex 20 and hex 7E.
This parameter a llows improved Gra phic Speed indepe only the print spee d o f graphic printout s at 180 x 180 dpi.
language PJL ( P r inter Job Language ) in connection with the internal Ethernet
interface (ETH-INT) or the external TallyCom
35
III interface (ETH-EXT).
Tally Dascom 2600+/2610+
service technician.
its print spe ed.
A par ity e r r or during data transmission is indicated.
hardware self-test.
The user is requeste d to tear o ff paper w hic h has been advanced to the tear.

5.4 Display messages

If the printer detects an internal fault or user error or if it ex pects you to do something, a mes s age will appear in the LC display.
It als o displays the s tatus during an operation (e.g. Initializing). Below yo u will find a list o f messages with brief descriptions of ea ch me ssage.
Messages LCD Panel
LCD Messages
Eject error Har d ware Al ar m Head hot
Initializing
Load error
Loading default
Load paper from
Parity error
Meaning
The printer cannot ejec t the paper/advance it to park position.
I nternal hardware error, contact your dealer or
The print head is too hot. The printer will reduce
This mes s age appears during the printer’s initializing phase afte r sw itching on the pr inter.
The print er fails to load the paper. Fa c tory defined paramet ers will be reloaded in all
available menus after switching on the printer.
The printer has detected paper end during oper ation/printer was switched on with no paper loaded.
Park position
Press any key
Selftest Tear Paper off Switch Paper Lever
Printer was switc hed on with no paper loaded. The user is requested to press any key.
After power-on , the printer e xec u tes a short
Choose correct paper path. Turn paper lever
36
Tally Dascom 2600+/2610+

5.5 USB h ost interface

The print er is equipped with a USB ho st interface. A standard USB memory device can be plugged into this int erface and can then be used for firmware dow nload a nd c onfig file up- and download. The USB device must be formatted w ith FAT16 or FA T32 f ile syste m , other formats like NTF S are not supported. It is strongly recommended to use an empty and newly formatted device; otherwise the data transfer may not work. The firmware or config files for download must always be lo ca ted in the root dire c tory! The format of the config files is the same that is used when you up-/download the printer configuration via the we bpanel or via the config tool.

5.5.1 Firmware Download This function will be activated by pressing key 1 dur ing power on. The dis play now show s

“USBH firm. down.” and “Insert USB stick”. After a USB stick was connec ted, the printer w ill search the root directory for a file with the extension *.mot. If more than one file with this extension is found, the first one w ill be used. If no file wa s found, the display will s how “no file fo und”. A f ter the do w nload wa s co m pleted, the printer will reboot.

5.5.2 Configuration File Upload This function will be activated by pressing key 2 dur ing power on. The dis play will now s how

“upload cfg file.” and “Insert USB stick ” . After a USB stick was connected, the printer will wr ite the co nfig file (extens ion *.cfg) to the US B s tick. The file name is the sa m e as the firmwa r e ID number. During t he write t ime , t he dis play will sho w “ please wait”. If the sa me file already exists, the displa y will show “cf g file exists” and “please delete it ” . Then the user s hould delete the file and try it aga in. After t he upload was completed, the print er will reboo t.

5.5.3 Configura tion File Download The func tion will be a c tiva ted by pressing key 3 during powe r on. The display will now show

“USBH cfg down.” and “Insert USB stick” . Af ter a USB stick was connected, the printer will search the root directory for a file with the extension *.cfg. If more than one file with t his extension is found, the first one w ill be used. If no file wa s found, the display will s how “no file fo und” . Y ou then have the cha nc e to r emove the USB stick and try again, m ay be with a dif ferent device. After t he do wnload was co m pleted, the printer will reboot.
37
Tally Dascom 2600+/2610+

6 Web Panel and Internal Ethernet Interface

6.1 Summary

6.1.1 Introduction It is a s s um ed you have the following:

A working kno wledge of your network system and re lated utilities. Access to the su pervis or or administrator accou nt as a network ad min istrator.

6.1.2 Suppor ted Environm ents The built-in networ k interface suppor ts the following platfor m s a nd pr otocols:

Microso ft ® Windows® NT 4.0, 2000, XP,7,8.1/10, Serve r 2003/2008/2012/2016 Linux – Red Hat®, SuSE® Unix® – Sun Solaris®, HP-UX®, IBM AIX® TCP/IP, HTTP, LPR/LPD

6.1.3 Network Interface and Cabling The print er requires:

Ethernet 10Ba se-TX or 100Base-TX interface. Category 5e or 6 Ethernet ca ble with RJ-45 socket connectors.

6.1.4 Connecting the Pr inter Connect the Ethernet cable to the network interface port RJ-45 connector on the rear center of

the pr inter.

6.1.5 Network Interface Status There are two status lights (LEDs) next to the RJ-45 connector on the rea r panel.

Right green light (Link Status) is solid: This s hows the printer is conne cted to the networ k. Right green light is blinking: Shows network activity. Left yellow light (Duplex Status) is so lid: Shows network interface is in full duplex mode.
Unless the link status light is green, the printer will not be able to connect to the
Network.
38
Tally Dascom 2600+/2610+

6.1.6 IPv6 Functionality The print er is now supporting IPv6 as a supplement for the still existing IPv4 funct ionality. The

IPv6 address settings are execute d fully automatic. There is no need and no option for configuring the se ttings. The IPv6 addresses will be shown on t he s tatus page a nd print server status frame.

6.2 IP Configuration

6.2.1 Net work IP Configuration The ne twork interface of the printer requires an IP a ddr ess. There are several ways to assign an IP address to the printer:

DHCP (A Dyna m ic Host Configuration Proto co l se r v er assigned I P address.) Static (An IP addr ess obtained fro m yo ur network administ r ator added to t he printer
manually.)
BOOTP (Boo t st rap Protocol server assigned IP address. )

6.2.2 Assigning the IP Address If t he pr inter menu is loc ked, please see t he 4.2.5.

1. Automatic DHCP IP address assignment:
Press <Set up>, then <Menu>. Press <Next> until the I/ O selection appears. Select <I/ O>. Press <Next> until the E TH-INT selection appears. Select <ETH-INT>. Press <Next> until the IP Get M se lection appears. Select <IP Get M> Select <DHCP>. Verify tha t your printer was assigned an IP address by printing the “Current Settings ”
configuration page or in the operator panel menu.
1) At power-up, the printer networ k interface broa dc asts a DHCP request for an IP address. If a DHCP server is prese nt, the request will be pro ce s se d, and a n IP address will be returne d to t he pr inter networ k interf ac e. Upon re ce ipt of the I P address, the pr inter accepts and uses this new IP address (and subnet ma s k, and default gateway, if any).
2) Once a n IP addre s s has been assigned, the printer network inte rface will no lo nger broadcast DHCP re que s ts. The printer w ill bro adcast a DHCP request each time you t ur n on the print er .
3) The DHC P se r v e r may gr ant a t em porar y IP address, cal led a temporary lease or temporary reserv ation, which expires l ater, or may grant a permanent or unlimited time lease or re se r vation, whic h does not expire.
4) Devices s uc h as the pr inter tha t are gra nted a temporary lease will be notified be fore the lease expires and as ke d if t hey would lik e to extend the lease . The pr inter ne twork inte r face w ill co ntinue extending its lease indefinitely (unless prohibited by your DHCP ser ve r configuration), and thus mainta in a consistent IP address.
39
Tally Dascom 2600+/2610+
5)
If the printer is not turned o n or is not connecte d to t he network when the DHCP server is sending r eque s ts to extend the lea se , t he lease will not be exte nded. The DHCP server will canc el the leas e and ma y as s ign the I P address to another de v ice. Therefore, it is highly re c om m ende d to explic itly specify the printer lea se as permanent or unlimited in your DHCP se r ve r conf igur ation.
2. Static assignment using the oper ator panel:
Press < Setup >, then < Menu >. Press < Next > until the I /O selectio n appears. Sele ct < I/O >. Press < Next > until the ETH-INT selection appears. Select < ETH-INT >, then< IP Addr > Enter the v alue for Octe t 1by pr essing < OCTET 1 >. Use the for ward and backward arrows
to inc r ement/decre me nt the number. When finishe d with ea c h entry press< Set > w hic h will set t he currently displayed value . To exit out wit hout changing the va lue press < Exit >. Enter the Octet 2 value in the same way , pressing < OCTET 2 >. To get to Octet 3 and Octet 4, select < Next > and then sele c t <O CTET 3> and < OCTE T 4 >.
Enter the default Gateway and Subnet mask in the same way. < Gateway > is availa ble
from the screen you are returned to. Press < Next > to select < Subnet >.
Enter the IP address get method under the selection <IP Get M>. Se lect <Static>.
3. BOOTP IP address assignment:
Press <Setup>, then <Menu>. Press <Next> until the I/ O selection appears. Select <I/ O>. Press <Next> until the E TH-INT selection appears. Select <ETH-INT>. Press <Next> until the IP Get M se lection appears. Select <IP Get M> Select <BOOTP> Obtain the E thernet MAC a ddr ess by printing the “ Cur r ent Settings ” c onfigurat ion page,
Turn of f printer.
Configure y our BOOTP ser ve r with desired IP addr ess and MAC addr ess. Turn on printer. Verify t hat the printer network interface received an I P a ddr ess by printing the “ Current
Settings” conf igur ation page or in t he operator panel me nu.
40
Tally Dascom 2600+/2610+

6.3 WebPanel

6.3.1 Introduction

WebPanel is an intuitive browse r interface that allows you to remot ely manage your network at tached printer. From WebPa nel, you can do virtually everything yo u c an do from the pr inter's control panel.
I n addition, WebPanel provide s full access to all of the TallyCom networking features. Before using WebPanel, you must configure your printer with an IP address , using one of the three metho ds dis c us s ed in the Assigning the IP Address se c tio n abo ve .
The screen shots that are u sed in thi s do cument to demon st rat e t he functionality
may va r y depe nding on the printer mode l .

6.3.2 Web Browser

WebPanel is acce s se d fro m the pr inter through a web browser, i.e. Int ernet Explorer, Firefox, etc. The brow se r needs to be co nfigure d wit h cache and histo ry e mpty , and the brow ser set up to c hec k for ne w pages e v ery time, to insur e that connections to WebPane l will pr oduce the lat est data.
WebPanel does not work thro ugh a prox y ser ver. The refo re, t he web brow ser must be setup to NOT use the Proxy Server for local IP addresses.
Disclaimer: Dasc om WebPanel runs in conjunction with third part y so ft ware, notably web browsers, which are designed to run independently of the Dascom software. Dascom cannot control the third party output or how it behaves from release to release. The above browser ver s ions have bee n tested with WebPanel a nd while there is full functionality, there will undoubt edly be visual differences and anomalies between products and ve r sio ns with which Dascom has no control.
41
Tally Dascom 2600+/2610+

6.3.3 A ccess to WebPanel

Once an IP a ddr ess has been se t up, y ou can access WebPa nel by typing the printer's IP address into your bro wser address box.
The c ur r ent status of yo ur pr inter is displayed on the right hand side of the scre en. This is refre s hed e v ery 20 seconds, whenever you refresh the page o r click Printer Stat us. The left side allows you to query the printer, configure it and access network options.
If you try to access the prin t er af t er power on the printer it may l ast up to o ne minute until the printer is visible in the network.
42
Tally Dascom 2600+/2610+

6.3.4 Access to Config Tool

The software interface for the Co nfig Tool is shown a s below. Click “Co nnect” to select the related interface. (A fter the Configuration Tool is co nnected, the operation inte r face is similar to the WebPanel, thus the ope r ation instruction not be star ted a gain).

6.3.5 Printer Stat us

Selecting this o ptio n re fre s hes the status dis play. Display ed on this page are:
Processing sta te Loaded menu Error state Firmware level Serial number Asset number Panel lock status
Options to change the Online / Offline sta te , netwo rk configura t ion and the virtua l co ntrol pa nel for your printer are all accessed from this page.
43
Tally Dascom 2600+/2610+

6.3.6 Pr inter Conf igur ation

Selecting this o ptio n allows you to co nfigure specific parameter s in the pr inter. When one of the se menu o ptions is sele cte d, a new page w ill loa d show ing the opt io ns which can be viewe d or mo dified.
44
Tally Dascom 2600+/2610+
Example 1 Chang the dr opdown menu option. I n this ex ample, we are m odifying the selec ted font to a different font. Sele c t “Font”. A new
pag e appears.
Select the Font dropdo wn menu and choo se the new f ont. Se lect “Send”.
1) Changes are not applied until “S end” is selected.
2) To r eset the changed va lue to the prio r value, select “Refresh” instead o f “S end” .
3) To return to the prior page without applying the c hange, select “Back”.
45
Tally Dascom 2600+/2610+
Example 2 Chang an entered value menu option. In this example, we a r e m odifying the se lec ted form le ngth to a different form le ngth. Select
“Forms”. A new page appears:
Select the Form Length f ield by highlighting the co ntents of the box and enter the new for m length.
The acceptable parameters are listed to the right of the field. S ele c t “Send”.
1) Cha nges are not applied until “Send” is s elected.
2) If the entered value is out of range of the acceptable parameters, the previous value will be
re-instated.
3) To reset the changed value to the prior value, select “Refresh” instead of “Send”. To re t urn
to the prior page wit ho ut apply ing the change, select “Bac k ” .
4) The default nam e is “ c onf.cfg”, but it can be renamed. Sa ve the file to disk. This will allow it
to be tra ns ferred to othe r print ers using the “ Send Configuration To Printe r ” option on the act ions web page.
46
Tally Dascom 2600+/2610+

6.3.7 Printer Actions

Selecting the Print er Actions link will produce a page with a list of actions that can be performed on the print er.

6.3.8 Lo ad Configurat ion

Loads the settings s tore d in a menu into the pr inter as the current settings. When the Load Conf igur ation link is selected, the following pa ge will be display ed:
Select a menu and co nfirm your selec tion by s ele c ting the Send button.
47
Tally Dascom 2600+/2610+

6.3.9 Save Configuration

You can save selected printer settings in up to 5 indepe ndent menus. When the Save Configuration link is selec ted, the follow ing page will be displayed:
Select a menu. Select send.

6.3.10 Ret r ieve Configuration From Printer

Selecting this o ptio n will s ave all the printer settings of all menus in a f ile. Uploading this file to ot her printers will clo ne the printe r menu se ttings to the ot her printer.
When this option is selected, the fo llowing will appear (note that t he ac tual im age will be browser specific):
48
Tally Dascom 2600+/2610+

6.3.11 Send Configuration to Printer

Selecting this o ptio n will upload a Conf igur ation File of another printer (see “Retrieve Conf igur ation From P r inter”). The com plete configuration of this s ource printer will be transferred to your printer.
To uplo ad the configuration file, first click “Send Configura tion To Printe r ” . The following page will be displayed:
49
Tally Dascom 2600+/2610+
Use the “Browse” but ton to find the file to upload. Once the file is selected, click on the “ Se nd” button. It is impor tant to note the war ning on this page. There is some delay while the file is transmitted so it is im portant not to re s end o r c lic k on t he “Send” button until the pro ce s s is complete.
If t he pr ocess is successful, the printer w ill r ebo ot a nd the following page will be display ed:
Since the printer will reboot with successful completion of this action, the user will have to reconnect to the printer through the browser.
50
Tally Dascom 2600+/2610+

6.3.12 Report

Selecting the repo r t link w ill open up a separ ate browser w indow a nd a r eport of the printer set tings will appea r . This f unc tionality is the same as press ing the “Print” option on the co ntrol panel of the printer.

6.3.13 Reset Printer

This link do e s a hard re set of t he print er, s imila r to cycling po we r. Ther e is no user feedba ck as to succe s s s inc e the printer is rebooting. Since the pr inter will reboot with succes s ful completion of this a ction, the user will have to reconnect to the printer thro ugh the browser .

6.3.14 Panel Lock On/Off

This link t oggles the pa nel lo c k feature of the printer. This option affects the phy s ic al control panel on the printer as well a s the v ir tual panel in WebPa nel. The state of t he option is displayed in t he printer status page on the r ight o f the display.

6.3.15 Download Firmware

Through t his link it is poss ible to downlo ad f ir m ware updates to the pr inter. When this link is selected, the follow page will a ppear:
51
Tally Dascom 2600+/2610+
Aft er fo llowing the directions on this page, select the “Co ntinue“ link a nd the following page
is displayed:
Using the “Bro wse ” butto n, find the fir mwa re file to downlo a d. Once the f ile is selecte d, click on the “ Se nd” button. It is important to note the warning on this page. The r e w ill be some delay while the file is transmitted so it is important NOT to re s end or click on the “ Se nd” button until the process is complete.
52
Tally Dascom 2600+/2610+
If t he pr ocess is successful, the printer w ill r ebo ot a nd the following page will be display ed:
Since the printer w ill r eboot with successful comple tion of this actio n, t he us er will have to reconnect to the printer through the br owser.
53
Tally Dascom 2600+/2610+

6.3.16 TallyCom Status

Selecting this link will replace the information in t he Printer Sta tus a re a with networ k ing info r m ation on the pr inter.
The Na m e, Contact and Location info r ma tion is set up from the General link within the Advanced Co nfiguration pa ge.

6.3.17 Adv anced Configuration

The Advanced Configuration pa ge allows the user to se t up and mo dify network connectivity info rma tion as well as set ting up t he pas sword, email no tif icat ion and logic al printers. From this page it is also poss ible to Logout of TallyCom and restart TallyCom. The Administration pa ge looks like this:
54
Tally Dascom 2600+/2610+

6.3.18 General

The General page se ts up the tim ers and the labels for name, co ntact and locat ion of the printer.
The Print Server Nam e i s given by default and can be changed accordingly. This
name is used by Name Server (DNS/DHCP ) .
55
Tally Dascom 2600+/2610+

6.3.19 TCP/IP

The TCP/IP Page allows the user to mo dify the existing TCP/IP info r ma tio n for the printe r . Aft er changing the pa rticular pa ramete rs, it is necessary to restart TallyCom from theAdvanced Configuration page . I f t he IP Address is cha nged a nd the Send button se lected you will disconne c t from the curr ent session a nd will need to reconnect at the new IP A ddr ess.
56
Tally Dascom 2600+/2610+

6.3.20 SNMP

The SNMP page allows the us er to set the Co m m unity Name and the Ac c ess. The page looks like this:
57
Tally Dascom 2600+/2610+

6.3.21 Password

The Password pa ge allows the user to se t a pas s word which wo uld lim it access to ce r tain configuration a nd act ion links in WebPa nel. The maximum num ber of chara c ters for the pass word is 7. The defa ult password is no password at all (“null“ ) . Howe ve r , “adm ” is also acc eptable as the de fault password to be compatible with the external TallyCom pocket NICs (Options), which use this as the default passwor d. If this or no password at all (“null“) is set a s the passwo rd, all of the web page s are acce ss ible by every one. I f any othe r pas sword is set, the first time a user accesses a password protected page, a window will open asking for ver ification with user a nd password info r m ation. Once the pa s s word has been succe s s fully rec ognized, all password protected pages will be available. Once t he password is recognized, a t ime r is se t, base d on t he P assword Timer v alue set in the General web page. If ther e is inactivity in the br owser which lasts beyond the time r time , the pa s s word will have to be reentered to access the protected pages.
The pa s s word page look s lik e this:

6.3.22 User Name

The de fault user name is “ adm” and cannot be c hanged.

6.3.23 Re s etting Password

I n or der to re s et password the pr inter needs to be de faulted. See Loading D e fa ult
”.
58
Tally Dascom 2600+/2610+

6.3.24 Lo gic al Printer s

The lo gic al printers page will add text o r co m m ands to the beginning a nd ending of pr int jobs. This is done by pre and post strings, defined in eac h of the logica l pr inters. For entering binary dat a in these strings, the backslas h c haracter is used followed by 2 hex ade c im al digits.
Exam ples of this ar e \1b for an escape character, \0a for linefeed and \\ for backslash. Selecting the Logic al Printers link giv es the follo wing page which lis ts seven possible logical printers plus Raw Po r t, which is port 9100:
59
Tally Dascom 2600+/2610+
When selecting one o f the logic al printers under the Desc r iption column, t he following pa ge is displayed:
I n this ex ample if the E nable checkbox is c hec k ed, the pre-st r ing of “Beginning to print job” fo llowed by a CR/LF will pr int at the beginning of every job sent to this LPR Que ue. At the end of the print job, the message “ E nd of job” with a for m feed w ill pr int. Unchecking the Enable chec k box will not send the pr e o r pos t st r ings . The LPD Queue Nam e is the nam e of the print queue that come s fro m the hos t. The Descriptio n ca n be changed by the us er and does not hav e to mat c h the LPD Queue Na me .

6.3.25 St r ing Replacem ent Example Pla in Text

Original Text / New Text
String Replacement Example Com ma nds /\1B[8419t/\1B[4196t/ Control codes are entered with a back slash “\”. I n this ex ample the Fo r m length of A4 (8419”/720) repre s ented by “1B[8419t” is being replaced by the string “1B[4196t ” ( 4196” /720) which r esults in A 5. Multiple strings are separated by a se m ic olon “;”.
60
Tally Dascom 2600+/2610+

6.3.26 Logou t of TallyCom

The Lo gout link disco nnects the browser session from the pr inter. Clicking on the “Home” link reestablishes the connection.

6.3.27 Restart TallyCom

Selecting this link will reboot the pr inter and disco nnect the curr ent printer connec tion. It is used to reset certain TCP/IP variables that were set in t he General and TCP/IP pages. Once TallyCom has re sta rted, t hose new set ting will t ake effe ct. When this link is select ed, t he follow page is displaye d, giving the user t he option to continue o r not.
61
Tally Dascom 2600+/2610+

6.3.28 Virtual Co ntrol Pa nel

The Virtual Control Panel link is in the Printer Stat us area of the web page. This co ntrol panel is a v is ual representat ion o f t he actual control panel on the printer. It allows the user to remotely rea d and set panel info r m ation as if they wer e s tanding at the control panel. The functionality of the v ir tual panel is identica l to the physical LCD panel.
Before using the virtual panel, it is im portant to configure the br owser to allow po pup windows from the printer, ot herwise the pane l will not display. Once the br owser is configured, the page will look similar to t his :
The Virtual Control Panel will be the ac tive window. This windo w will show the c ur r ent error state a nd displa y the co ntent s of the printe r’s LCD displa y. Se lec ting t he buttons o n the displa y will behave the sa me a s if se lecting the butt ons on the printer itself. The LCD informatio n o n the v ir tual panel ref re s hes eve r y 15 seconds. The phy s ic al panel, virtua l pane l and Online Status in the Printer Status are all a c tive, so there may be s ome synchro niz ation dela y issues if a us er presses a button on the phy s ic al printer or the Online S tatus in the Printer St atus area. The Panel Lock feature affects the virtual panel in the same way as the phys ic al panel. The only functional difference between the phy s ic al and virtual pa nel is that in the v ir tual pane l, the LF/F F o ption will alwa y s do a FF .
To close the virtua l panel, click on the X in the upper right of the window.
This fe ature needs t he br owser to allow po p ups .
62
Tally Dascom 2600+/2610+

7 Addendum

7.1 Character Set

standard character set 1
standard character set 2
63
Tally Dascom 2600+/2610+
IBM character set 1
IBM character set 2
64
Tally Dascom 2600+/2610+
OCR-A character set 1
OCR-A character set 2
65
Tally Dascom 2600+/2610+
OCR-B character set 1
OCR-B character set 2
66
Tally Dascom 2600+/2610+
Country
Basic Command
USA
FRANCE
UK
DENMARK 1
ESC>“R”CHR
SWEDEN
ITALY
ESC>“R”CHR
SPAIN 1
NORWAY
DENMARK 2
SPAIN 2
LATINAMERICA
DENMARK/NORWAY
CHINA
I nternationa l Character Set Comma nds
GERMANY
JAPAN
International character sets
<ESC>“R”CHR$(0) <ESC>“R”CHR$(1) <ESC>“R”CHR$(2) <ESC>“R”CHR$(3)
$(4)
ESC“R”CHR$(5
$(6)
<ESC>“R”CHR$(7) <ESC>“R”CHR$(8) <ESC>“R”CHR$(9) <ESC>“R”CHR$(10) <ESC>“R”CHR$(11) <ESC>“R”CHR$(12) <ESC>“R”CHR$(13) <ESC>“R”CHR$(16)
67
Tally Dascom 2600+/2610+
<BS>
Control character BS (Backspace)
<CR>
Control character CR (Carriage return)
<DC3>
Deselecting the printer
<DC4>
Double-wide printing OFF (set by <SO> or <ESC><SO>) <DEL>
Delete line. Epson: Delete last character
<ESC>
Start character for programming sequence
<ESC>#
Bit 8 = unchanged
<ESC>$<n1><n2>
Perform absolute horizontal step
<ESC>%<0><0>
Select ROM character generator
* * *
<ESC>%1<n1><n2>
Graphics print with 180 dpi/HQ
* * *
<ESC>%2<n1><n2>
Graphics print with 360 dpi/HQ
* * *
<ESC>%3<n1> <n2>
Graphics print with 60 dpi
* * *
* * *
<ESC>%7<n1> <n2>
Graphics print with 240 dpi
* * *
<ESC>%8<n1> <n2>
Graphics print with 72 dpi
* * *
<ESC>&<s><x><y>..
Define download character
* * *
<ESC>(*
Character set ISO 8859-5
* * *

7.2 Contr ol Codes Sum mary

The following table shows sequences marked by a √ if t h ey are availa ble in the various emula t ions . The MTPL seque nce s ca n be used within all e mulat io n mode s. The corre sponding sequences are marked by a *.
I
f you want to learn more abo ut co ntrol co des, we recommend to download
the Programmer’s Ap pl ic a t io n M a nua l from our internet support pag es.
MTPL
√ √
IBM
XL24
√ √
IBM
AGM
Epson
LQ-2550
√ √ √ √
Epson
LQ-2170
√ √ √ √
Code
<BEL>
<CAN>
<CSI>
Function
Signal tone
Deleting a data line
Start character for MTPL sequences, corr. ESC [
√ √
√ √ √ √ √ √ √ √
√ √ √
*
*
*
*
*
*
*
*
*
*
*
√ √ √
*
*
*
*
*
<DC1> <DC2>
<ESC>!<n>
<ESC>%<1><0>
<ESC>%4<n1> <n2> <ESC>%5<n1> <n2>
*
<ESC>%9<n1><n2>
<ESC>(&
*
<ESC>(+
Selecting the printer Condensed printing OFF (set by <Sl> or <ESC><Sl>)
Print mode selection
Select download generator
Graphics print with 120 dpi Graphics print with 80 dpi
Graphics print with 90 dpi
Character set ISO 8859-2
Character set ISO 8859-1 SAP
68
Tally Dascom 2600+/2610+
* * *
<ESC>(/
Character set ISO 8859-15
<ESC>(c
Defining the page format
<ESC>(t
Assigning a character table
* * *
<ESC>(m
Character set BRASCII
* * *
<ESC>(n
Character set Abicomp
* * *
<ESC>(q
Windows character set 1251 (Cyrillic)
* * *
<ESC>(t
Windows character set 1254 (Turkish)
<d1><dn>
* * *
<ESC>(B
Character set US-ASCII
* * *
<ESC>(MI>F
Assign character set G0
<ESC>(G
Selecting graphics mode
* * *
* * *
<ESC>(R
Character set French
* * *
<ESC>(Z
Character set Spanish
* * *
<ESC>)MI>F
Assign character set G1
<ESC>*<1><n1> <n2>
Set graphics print to 120 dpi
<ESC>*<2><n1> <n2>
Set graphics print to 120 dpi
<ESC>*<3><n1> <n2>
Set graphics print to 240 dpi
<ESC>*<38><n1> <n2>
Set graphics print to 90 dpi
<ESC>*<39><n1> <n2>
Set graphics print to 180 dpi
MTPL
√ √ √
IBM
XL24
*
*
*
IBM
AGM
*
*
√ √ √ √ √ √ √
*
*
*
*
*
*
*
*
*
*
√ √
*
*
*
√ √ √ √
*
*
*
*
*
*
*
√ √ √
*
*
*
*
√ √ √ √ √ √ √ √
Epson
LQ-2550
*
*
*
*
*
*
*
*
*
√ √ √ √ √ √ √ √
Epson
LQ-2170
*
*
*
*
*
*
√ √
*
*
√ √
*
√ √ √ √ √ √ √ √
Code
<ESC>(.
<ESC>(<
<ESC>(v
<ESC>(p
<ESC>(r
<ESC>(`
<ESC>(^<n1><n2>
<ESC>(A
<ESC>(B<n1>-<n8> Bar code Setup and pr int <ESC>(C
<ESC>(H <ESC>(K <ESC>(L
<ESC>(U <ESC>(V <ESC>(Y
<ESC>*<0><n1> <n2>
<ESC>*<32><n1> <n2> Set graphics print to 60 dpi <ESC>*<33><n1> <n2> Set graphics print to 120 dpi
Function
Character set ISO 8859-9
Character set Cro ASCII
Relative vertical printing position
Windows character set 1250 (Latin2)
Windows character set 1252 (Latin1)
Character set Norwegian Print data as characters Character set UK-ASCII
Defining the page length
Character set Swedish-Finnish Character set German Character set Portuguese
Setting positioning units in n/3600 inch Absolute vertical printing position Character set Italian
Set graphics print to 60 dpi
69
Tally Dascom 2600+/2610+
<ESC>*<40><n1> <n2>
Set graphics print to 360 dpi
<ESC>-<n>
Underlining ON/OFF
<ESC>.
Printing raster graphics
<ESC>:
Condensed printing 12 cpi ON
<ESC>:<0><n><m>
Copy ROM character set
<ESC>=
Set bit 8 = 0
<ESC>>
Set bit 8 = 1
sequence
* * *
* * *
<ESC>[>z
Bold OFF
* * *
<ESC>[?1~
MTPL command set
* * *
* * *
<ESC>[?4~
MTPL + IBM Proprinter-24 command set
* * *
<ESC>[?50h
Selecting character sets with 256 characters
* * *
*
<ESC>[?51h
Proportional fonts automatic NLQ and LQ
*
<ESC>[?51l
Proportional fonts in draft mode possible
* * *
<ESC>[?52h
Font selection (ESC[10...19m]) possible only for NLQ and LQ
* * *
<ESC>[?52l
Font selection (ESC[10...19m]) Draft
* * *
<ESC>[?53h
Extended character set
* * *
<ESC>[?53l
Standard character set
<ESC>[?8~
MTPL + EPSON LQ-2170 command set
MTPL
IBM
XL24
*
*
√ √
IBM
AGM
*
*
Epson
LQ-2550
√ √
*
√ √
√ √ √
√ √ √
*
Epson
LQ-2170
√ √
*
√ √ √
√ √ √
*
Code
<ESC>*<4><n1> <n2> Set graphics print to 80 dpi
<ESC>*MI>F
<ESC>/<m>
<ESC><
<ESC>=<C1><C2>... Load font/character set
<ESC>?<s><n> <ESC>@ <ESC>[
Function
Assign character set G2
Select vertical tab channels
Unidirectional printing for 1 line
Reload a graphics mode Initialize printer MTPL start character for programming
√ √ √ √ √ √ √ √ √ √ √ √
√ √ √ √ √ √
*
*
*
*
<ESC>[:y <ESC>[=z
<ESC>[?10~ <ESC>[?11~
<ESC>[?50l
<ESC>[?6~
<ESC>[?7h
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
* * * *
*
*
*
*
*
*
Right justification and centering OFF Bold ON
Barcode interpretation OFF Start barcode interpretation
Selecting character sets with 94 characters
MTPL + EPSON LQ-2550 command set
Line overrun = CR + LF
70
Tally Dascom 2600+/2610+
* * *
<ESC>[?<n>~
Change emulation
<ESC>[\<n1> <n2>...
Change vertical base units
* * *
<ESC>[0;0r
Clear top and bottom margin
* * *
<ESC>[0;0s
Clear left and right margin
* * *
<ESC>[0g
Clear horizontal tab at the current print head position
* * *
<ESC>[0m
Reset color (reserved)
* * *
<ESC>[0 SP K
Set horizontal pitch to 10 cpi
* * *
* * *
<ESC>[0y
Selecting Draft printing quality
* * *
* * *
<ESC>[10y
Right and center adjustment OFF
* * *
<ESC>[10z
Microscript ON
* * *
* * *
<ESC>[11w
Set 20 cpi
* * *
* * *
<ESC>[12w
Set horizontal pitch to 10 cpi
* * *
<ESC>[12y
Select print quality LQ
* * *
* * *
<ESC>[13m
Font 3 Default: Sans Serif NLQ
* * *
<ESC>[13y
Select print qua lity LQ
* * *
<ESC>[13z
Double height ON (lower portion)
* * *
* * *
<ESC>[15 SP K
Set horizontal pitch to 15 cpi
MTPL
√ √
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
IBM
XL24
*
*
√ √
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
IBM
AGM
√ √
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2550
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2170
*
*
*
*
*
*
*
*
*
*
*
*
Code
<ESC>[?7l
<ESC>[@<n1> <n2>... Set double height
<ESC>[0;;n{
<ESC>[0m
<ESC>[0 SP I
<ESC>[0 SP L <ESC>[0 SP X <ESC>[0w
<ESC>[0z <ESC>[10m
<ESC>[11e <ESC>[11h <ESC>[11m
<ESC>[11y <ESC>[12m <ESC>[12 SP K
<ESC>[12z
<ESC>[14m <ESC>[15m
Function
Line overrun = Truncating data outside of the printing area
Select single sheet operation
Clear all selected fonts
Measuring unit decipoint
Set vertical spacing to 6 lpi LQ print quality Set 5 cpi
Superscript ON Font 0 Default: Draft
Set PUM (absolute measuring unit) to OFF Set PUM (absolute measuring unit) to ON Font 1 Default: Courier NLQ
Select print quality HS-Draft Font 2 Default: Courier LQ Set horizontal pitch to 12 cpi
Double height ON (top portion)
Font 4 Default: Sans Serif LQ Font 5 Default: Roman LQ
71
Tally Dascom 2600+/2610+
* * *
<ESC>[17m
Font 7 Default: Prestige LQ
* * *
<ESC>[19m
Font 9 Default: OCR-A LQ
* * *
<ESC> [ 1 SP k
Printout in Royal Mail customer barcode
* * *
<ESC>[1 SP L
Set vertical spacing to 4 lpi
* * *
<ESC>[1 SP p
Initiate US Postnet Barcode
* * *
<ESC>[1w
Set 6 cpi
* * *
<ESC>[1z
Subscript ON
* * *
* * *
<ESC>[23m
Italics OFF
* * *
* * *
<ESC>[2g
Clear all horizontal tabs in the current line
* * *
<ESC>[2J
Print page
* * *
* * *
<ESC>[2 SP X
Print quality Draft
* * *
* * *
<ESC>[2z
Superscript, subscript and microscript OFF
* * *
<ESC>[30m
Black
* * *
* * *
<ESC>[3g
Clear all horizontal tabs
* * *
<ESC>[3m
Italics ON
* * *
<ESC>[3 SP L
Set vertical spacing to 12 lpi
* * *
* * *
<ESC>[4g
Clear all vertical tabs
MTPL
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
IBM
XL24
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
IBM
AGM
Epson
LQ-2550
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2170
*
*
*
*
*
*
*
*
*
*
*
*
*
Code
<ESC>[16m
<ESC>[18m
<ESC>[1 g
<ESC>[1 SP X
<ESC>[1y
<ESC>[21{ <ESC>[22{ <ESC>[21m
<ESC>[24m <ESC>[26m
<ESC>[2 SP l <ESC> [ 2 SP k <ESC>[2 SP L
<ESC>[2w <ESC>[2y <ESC>[2z
<ESC>[<n>m
<ESC>[3w <ESC>[3z
Function
Font 6 Default: Script LQ
Font 8 Default: OCR-B LQ
Clear vertical tab at current position
Print quality NLQ
Print quality NLQ
ASF-1: Select feeder front ASF-2: Select feeder rear Double underlining
Underline OFF Proportional font ON
Measuring unit decipoint Printout in Kix barcode Set vertical spacing to 3 lpi
Set 7.5 cpi Proportional font ON Double height OFF
Color; n = 31…36
Set 8.6 cpi Line density 6 lpi (= line spacing 1/6 inch)
72
Tally Dascom 2600+/2610+
* * *
<ESC>[4 SP L
Set vertical spacing to 8 lpi
* * *
<ESC>[4y
Selecting NLQ printing quality at 10 cpi
* * *
<ESC>[5{
Select fanfold paper mode tractor 1
* * *
<ESC>[6{
Select fanfold paper mode tractor 2
* * *
<ESC>[50m
Proportional font OFF
* * *
<ESC>[51{
Page at tear off position (perforation)
* * *
<ESC>[53m
Overlining ON
* * *
* * *
<ESC>[5y
NLQ with 12 cpi
* * *
* * *
<ESC>[6 SP K
Set horizontal pitch to 6 cpi
* * *
<ESC>[6w
Set 15 cpi
* * *
* * *
<ESC>[7z
Bit 8 = unchanged
* * *
* * *
<ESC>[9 SP L
Set vertical spacing to 2 lpi
* * *
<ESC>[9w
Set double stroke
* * *
* * *
<ESC>[9z
Set bit 8 = 1
<ESC>[g<n1> <n2><0>
Set graphics print to 60 dpi
<ESC>[g<n1> <n2><1>
Set graphics print to 120 dpi
MTPL
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
IBM
XL24
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
√ √ √ √
IBM
AGM
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2550
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2170
*
*
*
*
*
*
*
*
*
*
*
*
Code
<ESC>[4m
<ESC>[4w
<ESC>[4z
<ESC>[50{
<ESC>[52{
<ESC>[55m <ESC>[5n <ESC>[5w
<ESC>[5z <ESC>[6~
<ESC>[6z <ESC>[7w <ESC>[7y
<ESC>[8w <ESC>[8y <ESC>[8z
<ESC>[9y
<ESC>[g<n1> <n2><11> Set graphics print to 180 dpi <ESC>[g<n1> <n2><12> Set graphics print to 360 dpi
Function
Underline ON
Set 10 cpi
Line density 8 lpi (= line spacing 1/8 inch)
Page at print position
Page at view position
Overlining OFF Request status report Set 12 cpi
Graphics normal Initialize the printer
Graphics inverted Set 17.1 cpi Proportional font OFF
Reset double stroke Right justification ON Set bit 8 = 0
Centering ON
73
Tally Dascom 2600+/2610+
<ESC>[g<n1> <n2><3>
Set graphics print to 240 dpi
<ESC>[g<n1> <n2><9>
Set graphics print to 120 dpi
* * *
<ESC>[<n1> <n2>f
Set absolute horizontal and vertical position
* * *
<ESC>[<n>+w
Interface holding time n = 1 - 30 s
* * *
<ESC>[<n>+x
Head position horizontal in n/720", also paper load pos.
* * *
* * *
<ESC>[<n1> <n2>f
Set absolute horizontal and vertical position
* * *
* * *
<ESC>[<n1> <n2>r
Set top and bottom margin
* * *
* * *
<ESC>[<n> d
Set absolute vertical position
* * *
<ESC>[<n> e
Set relative vertical position
* * *
* * *
<ESC>[<n> q
Set horizontal step
* * *
<ESC>[<n> SP \
Set additional spaces
* * *
* * *
<ESC>[<n> SP g
Set character spacing
* * *
<ESC>[<n> SP h
Line spacing
* * *
* * *
<ESC>[<n> SP U
Beginning of line (default value)
* * *
<ESC>[<n> SP V
End of line (default value)
* * *
<ESC>[<n> t
Set form length in lines
* * *
√ √ √ √
IBM
XL24
MTPL
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
IBM
AGM
Epson
LQ-2550
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Epson
LQ-2170
*
*
*
*
*
*
*
*
Code
<ESC>[g<n1> <n2><2> Set graphics print to 120 dpi
<ESC>[g<n1> <n2><8> Set graphics print to 60 dpi
<ESC>[j
<ESC>[<n>SP q <ESC>[<n1>...<n5>+v Paper handling options <ESC>[<n1>...<n16>SP
<ESC>[<n1> <n2>SP 0 Change character size <ESC>[<n1> <n2>SP D Select font <ESC>[<n1> <n2>SP G Set character/line spacing
<ESC>[<n1> <n2>s <ESC>[<n> a
<ESC>[<n> j <ESC>[<n> k <ESC>[<n> p
<ESC>[<n> SP C <ESC>[<n> SP f
<ESC>[<n> SP s
<ESC>[<n> u
Function
Position paper back 1/180"
Load menu
Print transparent characters
Set left and right margin Set relative horizontal position
Relative horizontal position back (to the left) Relative vertical position back (to the top) Set HMI
Select character size Set reduced spacing
Transmits the “n” character as an ASCII character (n= 0–255)
Set horizontal tab
74
Tally Dascom 2600+/2610+
<ESC>[\<n1><n2>
Perform relative horizontal step
<ESC>^
Transparent mode for the character following
<ESC>0
Set line feed to 1/8 inch
<ESC>1
Set line feed to 7/72 inch
<ESC>2
Set line feed to 1/6 inch
<ESC>3<n>
Set line feed to n/180 inch
<ESC>4
Italics ON
<ESC>6
Print ASCII codes dec. 129 to dec. 159
<ESC>7
PC character set 1 (standard)
<ESC>a<n>
Select orientation
<ESC>b<m><n><0>
Set vertical tabs in channels
<ESC>B<n1>...<n64><0
Set vertical tabs <ESC>c
Reset to initialization status
<ESC>c
Setting the horizontal motion index (HMI)
<ESC>d<n1> <n2>
Perform relative horizontal step
<ESC>D<0>
Clear all horizontal tabs
<ESC><DC2>
Condensed printing OFF
MTPL
IBM
XL24
√ √ √ √ √ √ √
*
IBM
AGM
Epson
LQ-2550
*
*
√ √ √ √
Epson
LQ-2170
*
√ √
Code
<ESC>[<n> v
<ESC>\<n1>;<n2>
<ESC>_<n>
<ESC>2
<ESC>3>n>
<ESC>4 <ESC>5 <ESC>5<n>
<ESC>6 <ESC>7
<ESC>A<n> <ESC>A<n> <ESC>b<m><0>
<ESC>B<0> <ESC>B<n1>...<n16><0> Set vertical tabs
Function
Set vertical tab
Transparent mode for the characters following
Overline ON/OFF
Set line feed to n/72 inch
Set line feed to n/216 inch
Set beginning of form Italics OFF Autom. line feed ON/OFF
PC character set 2 (expanded) Suppress ASCII codes 129 to 159
Line spacing n/60 inch Prepare line spacing n/72 inch Clear all tabs
Clear all vertical tabs
√ √ √ √ √
√ √
√ √ √ √ √
√ √
√ √
√ √
√ √ √ √ √ √
>
<ESC>C<0><n> <ESC>C<n>
<ESC>D<n1>...<n32><0> Set horizontal tabs
<ESC><DC4>
75
Set form length in inches Set form length in lines
Double-wide printing OFF (set with <SO> or <ESC><SO>)
Tally Dascom 2600+/2610+
<ESC>T
Superscript or subscript OFF
<ESC>Un
Unidirectional print ON/OFF
<ESC>w<n>
Double height print ON/OFF
<ESC>x<0>
sets Draft or HS-Draft
<ESC>X
Font selection according to pitch and points
* * *
<ESC>+F
Assign character set G3
* * *
* * *
<ESC>}
Character generator LS2R
<FF>
Form feed
<HTS>
Set tab stop at actual horizontal position
<LF>
Line feed
<RI>
Line feed without CR back
<SI>
Switching the character generator (SS 3)
<SO>
Switching the character generator (SS 2)
<VTS>
Set tab stop at current vertical position
IBM
XL24
MTPL
√ √
√ √ √ √ √ √ √ √ √ √ √ √ √
√ √ √
√ √
*
*
*
*
√ √
IBM
AGM
√ √
√ √ √
√ √
*
Epson
LQ-2550
√ √ √ √ √ √ √ √ √ √ √
√ √
*
√ √
Epson
LQ-2170
√ √ √ √ √ √ √ √ √ √ √ √
√ √
*
√ √
Code
<ESC><SO> <ESC><SP><n> <ESC>t<n>
<ESC>U<n>
<ESC>W<n>
<ESC>x<n>
<ESC>x<1>
<ESC>X<n><m> <ESC>Y<n1> <n2> <ESC>Z<n1> <n2>
<ESC>|
<ESC>~
<HT>
<IND>
<NEL> <PLD> <PLU>
<SI>
<SO>
<VT>
Function
Double-wide printing ON Set character spacing Select character set
Unidirectional print ON/OFF
Continuous double width ON/OFF
Set print quality (PQ)
sets LQ or NLQ
Set left and right margin Set graphics print to 120 dpi Set graphics print to 240 dpi
Character generator LS3R
Character generator LS1R
Horizontal tab jump
Line feed without CR
Line feed with CR Half step line feed Half step line feed back
Condensed printing of 17.1 cpi ON
Double-wide printing ON
Vertical tab jump
76
Tally Dascom 2600+/2610+
@PJL EOJ NAME=
@PJL USTATUS PAGE = ON

7.2.1 PJL commands

These PJL commands c an be use d with interna l E the r net interfac e as well as with ext ernal TallyCom III Pocket interface.
This functionality may be activa ted via the parameter Jobcntl in the Advanced Menu.
Sequence Brief description
"ESC"%-12345X@PJL Univer s al Exit Language (UEL) @PJL ECHO ECHO command @PJL EOJ
EOJ (End of Job) commands
@PJL INFO STATUS INFO (Information Request) command @PJL INFO CONFIG INFO of the pr inter configuration @PJL INFO VARIABLES INFO of va r iables which can be set by @PJL INFO MEMORY INFO about the memory of the printer
@PJL USTATUS DEVICE = ON @PJL USTATUS DEVICE = OFF
USTATUS ( uns olicite d s tatus) commands
@PJL USTATUS DEVICE = VERBOSE @PJL USTATUS JOB = ON @PJL USTATUS JOB = OFF
@PJL JOB NAME =
JOB (Start of Job) commands @PJL JOB FILE = @PJL JOB START = @PJL JOB END = @PJL JOB COPY =
@PJL ENTER LANGUAGE Exit PJL and start normal parse r @PJL INF O USTATUS List each type of unsolicited sta tus @PJL USTATUS TIMED Enables timed unsolicited status

7.2.2 Barcode Eve n the standard ver s ion o f yo ur pr inter has the possibility of using up to 23 different MTPL

barc ode types.
Barcode m ode can be accessed within every emulation. The user can decide
whether b arcode is activated permanently or activated depending on the situat ion by means of an escape sequence. The printer prints small barcode in 240 dpi and wider barcodes in 120 dpi.
77
Tally Dascom 2600+/2610+
Type
Barcode
Type
Barcode
A*
2/5 Matrix (defa ult)
N
UPC A (with HRI)
B*
2/5 Industrial
O
UPC A (without HRI)
D*
Code 11
Q
UPC E (w ithout HRI)
E*
BCD Matrix
R*
Delt a Distance (IBM )
F*
Code 39
S
Code 128
G*
Codabar
T
EA N 128
H
EA N 8 (with HRI)
1)
US-Postnet
I
EA N 8 (wi thout HRI)
1)
KIX Barcode
K
EA N 13 ( with HRI)
1)
Barcode
L
EA N 13 ( without HRI)
1)
Barcode
M*
MSI/modified PLESSEY

7.2.3 List of ava ilable MTPL barcodes

C* 2/5 Interleaved P UPC E (w ith HRI)
Royal Mail Cust omer
USPS Intelligent M ail
*These barcodes ma y be pr inted out hor izo ntal and vertical, the unmarked only
horizontal.
1) See description o n following page s . The ba r c ode types K, L, N, O may be expanded by using A dd-On Barcodes:
Add-On 2 a nd A dd-On 5. The information to be printed is tra ns m itted in a “brack et” (DC4) A contro l
sequence (Header) defines the parameters of the used barcode once (e.g. type, ratio, etc.). If no hea der is defined, t he informatio n in the “ br acket” will be pr inted in Code 2/5 Matrix.
Please note that within the Barcode environment th e barcode comm and s have prio rity in case of conflicts with the emulation.
Additional information is provided in the Barcode Programmer’s Application Manual
on this CD-ROM.
78
Tally Dascom 2600+/2610+
ASCII
ESC
[ 1 SP P 1 2 3 4 5
CR
HEX
1B
5B
31
20
70
31
32
33
34
35
0D
Resident Barcodes:
1 - Code 2/5 Industrial 2 - Code 2/5 Interleaved 3 - Code 39 4 - Code EAN-8 with clea r tex t line 5 - Code EAN-8 without clear text line 6 - Code EAN-13 with clea r text line 7 - Code EAN-13 without clear text line 8 - Code UPC-A with clear text line 9 - Code UPC-A without c lear text line 10 - Code UPC-E with clear text line 11 - Code UPC-E without clear text line 12 - Code 128 EAN (also c alled EAN-128) 13 - Code 128 14 - U.S Postnet (fix format, non-scalable)

7.2.4 US Postnet barcode Pos tnet is a spe c ial US-American type of barcode. Is printed in c haracter size. Numeric values

fro m 0 to 9 are pr intable. Aft er activ ating this ba r co de type, numeric c haracters from 0 (hex. 30) to 9 (hex . 39) are
interpreted as barcode figures. All other characters terminate the Barcode mode. Exception: the TAB function (hex . 09) is allowed within B arcode mode. The Po s tnet sequence
is ac c essible in every emulation.
The ch aract er ( e.g. CR = carri age return, hex. 0D), which terminates the barcode is not printed or carried out . US Postnet barco de does not require a barcode bracket.
Example:
The numbers 1 to 5 are pr inted as Postnet str ipes.
79
Tally Dascom 2600+/2610+
ASCII
ESC
[ 1 SP k S O 3 6 X Y 1 A CR
HEX
1B
5B
31
20
6B
53
4F
33
36
58
59
31
41
0D
ASCII
ESC
[ 2 k S O 3 6 X Y 1 A
CR
HEX
1B
5B
31
6B
53
4F
33
36
58
59
31
41
0D

7.2.5 Royal Mail Customer barcode The Royal Mail Custome r barco de is a special Ma il type ba rco de. It is printed in character size.

Numer ic v alues from 0 to 9 and a lpha- numeric va lues from A to Z are pr intable. After activating this bar c ode type, nume r ic c har acters from 0 (hex .30) to 9 (hex. 39) and alphanumeric values from A (hex. 41) to Z (hex. 5A) are interpreted as barcode figure s . Lower cases from a (hex. 61) to z (hex. 7a) are automatically converted to capital characters. Control characters from hex. 0 (dec. 0) to hex.1F (dec. 31) terminates this barcode mode. A ll ot her characters are ignored. Exception: the TA B function (hex. 09) is allowed within Barcode mode. The Ro y al Mail Customer seque nc e is accessible in M TPL emulation. The printer pr ints barc ode in LQ.
The ch aract er ( e.g. CR = carri age return, hex. 0D), which terminates th e barcode is not printed or carried out .
Royal mail customer barcode does not requ ired barcode bracket.
Example
:
The characters “SO36XY1A” are printed as Royal Mail Custo mer stripes.

7.2.6 KIX barcode The KI X barcode print s num eric values from 0 to 9 and alpha-numeric values from A to Z as

barcode characters. Aft er activ ating this ba r co de type, numeric c haracters from 0 (hex. 30) to 9 (hex. 39) and
alphanumeric values from A(hex. 41) to Z (hex. 5A) are interpreted as barcode figures. Lower cases from a (hex. 61) to z (hex. 7a) are automatically converted to capital characters. Control characters from hex. 0 (dec. 0) to hex.1F (dec. 31) terminates this barcode mode. A ll ot her characters are ignored. Exc eption: the TAB functio n ( hex. 09) is allowed w ithin Barco de mode. The KI X s equence is acces s ible in MTPL emulation. The pr inter prints barc ode in LQ.
The ch aract er ( e.g. CR = carri age return, hex. 0D), which terminates th e barcode is not printed or carried out. KIX barcod e does not require a barcode bracket.
Example
:
The characters “SO36XY1A” are printed a s KIX stripes.

7.2.7 USPS Intelligent Mail barcode The USPS Intelligent Mail barco de is a 4-s tate barcode which works in MTPL, IBM and Epson

emulation. 4-stat e barcode data m us t be co nv erted into only 0, 1, 2 or 3. Each number represents one of the four possible bars. Tabs (Hex 09) and spaces can separate either the bars or the barco des ho rizont al, but every other cha racter below Hex 20 will termina te barco de mode.
80
Tally Dascom 2600+/2610+
ASCII
ESC
[ 9 SP K <data>
HEX
1B
5B
39
02
6B
<data>
ID
23
24
40
5B
5C
5D
5E
60
7B
7C
7D
7E
# $ @
[ \ ] ? ` { | } ¯
# $ § Ä * Ü ? ` ä * ü ß
ASCII
ESC
P L S 0 1
ESC
\
53 30 31 1B 5C
76 83 48
You c an e nter the barcode mo de with the sequenc e ESC [ ? 11 ~, the sequence ESC [ 10 ~ exit s the barcode mode.
:
Example

7.2.8 LC printi ng Certain professional applications may require unusually Large character sizes. Therefore your

printer has the possibility of scaling standard size characters up to factor 99 by means of control sequenc es (LCP *) .
The He ader seque nce defines the parameters (e.g. height ) once. This definition rema ins until the pr inter is switched off. The printa ble LCP* inform ation is transm itted in an LCP “bracket” (SI).
The following character sets (with national characters) are available .
US ASCII 01 GERMAN 02
The characte r sets are sele cte d via the follo w ing LCP se que nce ESC ”P“ ”L“ ”S“ n ESC ”\“. The value o f n ma y ra nge between 01 and 02 ( as ASCII characters) – see ID column in the above table.
To select e.g. the German character set, you must use the following data set:
HEX
DEC
1B
27
50 4C 80
49* 27 92
The p rintout of LCP characters can be selected in all of the emulations.
Prerequisite: Prin t er must be in Barco de mode. Note that this printer also sup po rt s some scalabl e f onts in the LQ-2170 emulation if a compatible driver is used.
81
Tally Dascom 2600+/2610+
Sequences
Control codes
Function
Header
Function
<DLE> [ !] nn E M
LCP header
<SUB> [F] a [nn][;xyz][;p] EM
Barcode header

7.2.9 List of additional co ntro l Codes You c an use both the ESC se quences and the c ontrol codes

<ESC>[?10~ <ESC>[?11~ <ESC> PSC 0 <ESC> \ <ESC> PSC 1 <ESC> \ <ESC> PLS <n> <ESC> \ <ESC>[<n><SP>s
<ESC>[20<SP>s <ESC>[16<SP>s <ESC>[25<SP>s <ESC>[15<SP>s <ESC>[26<SP>s <ESC>[1 SP p <ESC>[1 SP k
<ESC>[2 SP k <ESC>[9 SP k
— — — — — —
<DC4> <DLE>
<EM>
<SI>
<SUB>
— —
Barcode Off Barcode On Unsecured mode
Sec ur ed mode LCP character set Sends a character as ASCII
character; n > 0–255 dec im al
Barcode bracket Start code LCP Header Termination code Header LCP bracket Start code Barcode-Header US-Postnet Barcode Royal Mail Customer Bar-
code Kix-Barcode USPS Intelligent M ail Bar-
code
Additional information is provided in the Barcode Programmer’s Application Manual on this CD-ROM.
[ ] = optional nn = factor
[ ] = optional a = Barcode type p = 0: Barcode horizontal
p = 9: Barcode vertical
82
Tally Dascom 2600+/2610+

7.3 Interfaces Specifications

Your m atrix printer offers connectiv ity via a parallel interfac e, USB and Ethernet interface. Serial I/O RS 232C interface is an o ption. This appe ndix inform s yo u about the paralle l Interface, USB, Ethernet interface and optional serial interface RS232C, and describes the com m unic ation between your computer and the printe r.
These interfac es are link ed to for m a c alled share d interface. Your printer can be configured to use only one interface or three alternately . When o nly one inte rfac e is us ed, it is monito r ed by the pr inter. If the printer is configured to use three interfaces simultaneously it monitors all inte r faces for inco m ing data. As soon as the pr inter recognizes a signal, it switc hes to the res pective interface and sends the B USY signal to the othe r interface. After f inishi ng the data transmission, the pr inter remains switched to the interface fo r a certain period of time (30 sec onds). When this tim e has e lapsed, the controller again enables all int erfaces and the sequence described restarts. If incoming data is on the other interface and t he c ur r ent print position is not “To p of Form”, a form feed is ca r r ied o ut.
83
Tally Dascom 2600+/2610+

7.3.1 Parallel I/O IEEE 1284 The bidirectiona l parallel inter face offers the “nibble” mode of IEEE 1284 interfa ce. This

enables installation in accordance with Windows “ P lug & P lay”. The st andard para llel interface is able to transfe r data at a speed of max. 30, 000 bytes per
sec ond. When the receiving buffer is f ull, the data input is blocked until the data buffer is empty.
Connector assignment
Connector no.
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17 18
19–30
31 32 33
34–35
36
Direction
Printer–PC
← ← ← ← ← ← ← ← ← → ↔ ↔ ↔ ↔
一 一 一
← ↔
Signal
STROBE (active low) DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 DATA 8 ACK (active low) BUSY PAPER EMPTY (PE) SELECT AUTO FEED (active low) not used SIGNAL GROUND CHASSIS GROUND 5 V (Imax = 500 mA) SIGNAL GROUND INIT (active low) ERROR (active low) SIGNAL GROUND not used SELECT IN
Transmission length: max. 2,0 m
84
Tally Dascom 2600+/2610+
LAN/Ethernet: RJ45, Ethernet 100BaseTX with 100
Mbps
Speed: 100 Mbps / Full Duplex
Windows XP, Windows Server 2003, Windows 2000,
Sun
Solaris
SNMP
Ipr / Ipd Port 9100
DHCP Static (manually via the printer’s control panel)
HTTP TCP/IP
SNMP
PING
Web Panel Setup via the printer’s control
panel

7.3.2 Ethernet I/O 10/100 Mulitprotocol The Ethernet interface enables the printer to connect to local area networks. Its attributes are:

Hardware
Supported operating Systems
Supported Protocols
Designation of IP Address
Configuration
Status
(IEEE802.3u), 10Base-TX with 10 Mbps (IEEE802.3)
Windows NT, Windows 7, Windows 10, Windows Vista, Windows Server 2008, Wi ndows Server 2013, Windows 8 Linux Unix
SMTP TCP/IP FTP
BOOTP
TCP/IP SMTP
Management
HP Web Jet Admin Pre-string, Post-String, String Replacement
Setup
Web Panel
Ethernet TCP/IP
When using your printer in a local network with Ethernet connections and the TCP/IP protocol, you have to assign address information.
Address information for the Ethernet Port can only be made available by your network administrator, who has the necessary rights to install Printers on the network and/or make any changes.
(HTTP/HTML)
85
Tally Dascom 2600+/2610+
Example of a Printer connected to a computer in an Network(IPv4)
The assumed address space corresponds to the TCP/IP address, class C, 192.168.1.xxx. The subnet mask to be used is 255.255.255.0. The address of the router, or gateway, is 0.0.0.0, if not available.
Examp le of several devi ces in an Ethernet

7.3.3 USB 2.0 I/O – Full Speed The USB interface co nforms to the Universal Serial B us 2.0 Specifications. It suppor ts the Full

Speed mode at 12 M bps . It uses the “B” ty pe US B c onnector.
86
Tally Dascom 2600+/2610+
Type
RS232C interface
Signal status ON (log. 0) +3 V to +15 V
Interface connections
Transmission protocol Capacity of data buffer
512Byte min. 256KByte max
Connector no.
Direction Printer–PC
Signal

7.3.4 Optional Serial Interface RS232C Your printe r’s se rial int erfa ce suppo rts the RS 232C spe cific a tio n. The signals are rece ived and

transmitted by a 9 pin connector. Bas ic ally 3 lines a re enough for excha nging information between computer and print er (one
rec eive line, one se nd line, one line for co m mo n gr ounding).
Synchronization Transmission rate
Connection cable
Connector assignm ent
3 TxD 4 DTR 2 RxD 6 DSR 7 RTS 8 CTS 5 Signal Ground SG
Shield
Asynchronous 600 Baud to 19200 Baud OFF (log.1) -3 V to -15 V
up to 15 m length I TT Ca nnon connector, series DB-9 S XON/XOFF, ENQ/STX, READY/ BUSY, Robust XON/XOFF, ETX/ ACK, ACK/ NAK
Frame Ground FG
87
Loading...
