Corel CorelCAD 2015 Instruction Manual
This document contains information for IT administrators that need to deploy CorelCAD™ 2015 in
a network.
The instructions in this document refer to CorelCAD 2015 for Windows, being deployed to
Windows 8 (incl. Windows 8.1) or Windows 7 workstations.
Note for Apple Mac OS X: CorelCAD 2015 for Mac OS X does not support any deployment
mechanisms. Please install CorelCAD 2015 directly from CD or download installation files (DMG).
Please read the additional notes related to product activation in the “Activating CorelCAD 2015
installation server image” section in this document.
Workstation requirements
You can install CorelCAD 2015 for Windows on workstations that meet the following
requirements:
32-bit application version: Microsoft
64-bit application version: Microsoft
Intel
®
Pentium® 4 (2 GHz or faster)
®
Windows® 8 or Windows® 7 (32-bit or 64-bit editions)
®
Windows® 8 or Windows® 7 64-bit editions
2 GB RAM (4 GB or higher recommended)
500 MB hard disk space
High Color (16 bit) graphics card (3D graphics accelerator card recommended)
1024 x 768 screen resolution (1280 x 800 or higher recommended)
Mouse or Tablet
Microsoft
(Microsoft
®
.NET Framework 3.5
®
.NET Framework 4.5 setup is included and will be installed with the application if
not present)
CorelCAD 2015 Network deployment instructions v2014-10 page 1 of 6
.\files\CommonAppDataFolder\
Application files to be installed to \Common\AppData folder
.\files\program files\
CorelCAD administrative install files
.\files\CorelCAD.msi
CorelCAD administrative installer
.\files\NDP452-KB2901954Web.exe
Microsoft .NET Framework 4.5.2 Setup
.\files\vsta_setup.exe
Microsoft VisualStudio Tools for Applications 2012 installer
file
.\CorelCADInstaller.exe
The install chainer
Deploying CorelCAD 2015 for Windows
Deploying CorelCAD 2015 for Windows is done in 2 stages:
1) Creating a server image of the installer files
2) Installing the software to the client PCs
Creating a server image
CorelCAD2015_x86.exe and CorelCAD2015_x64.exe (as either downloaded from coreldraw.com or
received on CD) contain all files needed to deploy the application in the network.
For installing the application to multiple PCs in the network you need to extract the installation
files to a network share using an administrative installation as initial step:
Preparing software deployment / Creating an administrative setup:
To initialize the setup for creating a server image, you use a command line.
You can create either a 32-bit server image or a 64-bit image.
The following command line lets you create a 32-bit server image from the installation disc
(where X: is the disc drive, U: is the target network share for the installation files to be placed):
X:\CorelCAD2015_x86.exe /a “U:\ServerImages\CorelCAD2015_x86\”
The following command line lets you create a 64-bit server image:
X:\CorelCAD2015_x64.exe /a “U:\ServerImages\CorelCAD2015_x64\”
This will create the following items (identical file/ folder names for 64-bit and 32-bit installation):
Activating CorelCAD 2015 installation server image
CorelCAD 2015 needs to be activated in order to run with all features enabled. Without product
activation the application will only start in Demo mode (with limited functionality, no output
(save, export, print) capabilities), asking for a product activation every time it is started.
When deploying the software to multiple clients you can use a central activation which is stored
with the administrative installation in a license file on the server image.
CorelCAD 2015 Network deployment instructions v2014-10 page 2 of 6
