CLARION DB288RUSB User Manual
Owner’s manual
Mode d’emploi
Bedienungsanleitung
Istruzioni per l’uso
Gebruiksaanwijzing
Manual de instrucciones
Bruksanvisning
Manual de instruções
DB288RUSB
CD/USB/MP3/WMA RECEIVER
AUTORADIO CD/USB/MP3/WMA
CD/USB/MP3/WMA-RECEIVER
SINTOLETTORE CD/USB/MP3/WMA
CD/USB/MP3/WMA-RADIO-COMBINATIE
RECEPTOR
CD/USB/MP3/WMA-RADIO
RECEPTOR CD/USB/MP3/WMA
CD/USB/MP3/WMA
English
CAUTIONS:
This appliance contains a laser system and
is classified as a “CLASS 1 LASER
PRODUCT”. To use this model properly,
read this Owner’s Manual carefully and keep
this manual for your future reference. In
case of any trouble with this player, please
contact your nearest “AUTHORIZED service
station”. To prevent direct exposure to the
laser beam, do not try to open the
enclosure.
!CAUTION
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED IN THE OWNER’S
MANUAL MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
ADVARSEL.
Denne mærking er anbragt udvendigt på
apparatet og indikerer, at apparatet arbejder
med laserstråler af klasse 1, hvilket betyder,
at der anvendes laserstråler af svageste
klasse, og at man ikke på apparatets
yderside kan blive udsat for utilladelig
kraftig stråling.
APPARATET BØR KUN ÅBNES AF
FAGFOLK MED SÆRLIGT KENDSKAB TIL
APPARATER MED LASERSTRÅLER!
Indvendigt i apparatet er anbragt den her
gengivne advarselsmækning, som advarer
imod at foretage sådanne indgreb i
apparatet, at man kan komme til at udsaætte
sig for laserstråling.
OBS!
Apparaten innehåller laserkomponenten som
avger laserstrålning överstigande gränsen
för laserklass 1.
VAROITUS
Suojakoteloa si saa avata. Laite sisältää
laserdiodin, joka lähettää näkymätöntä
silmille vaarallista lasersäteilyä.
2 DB288RUSB
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
Contents
1. FEATURES...................................................................................................................................... 4
2. PRECAUTIONS ............................................................................................................................... 4
Handling Compact Discs .................................................................................................................. 5
3. CONTROLS ..................................................................................................................................... 6
Names of the Buttons and Their Functions ...................................................................................... 6
Display Items.................................................................................................................................... 8
Display Screen ................................................................................................................................. 8
4. DCP (DETACHABLE CONTROL PANEL)...................................................................................... 9
5. OPERATIONS................................................................................................................................ 10
Basic Operations ............................................................................................................................ 10
Radio Operations ........................................................................................................................... 13
RDS Operations ............................................................................................................................. 15
CD/MP3/WMA Operations ............................................................................................................. 19
Operations Common to Each Mode ............................................................................................... 22
6. ACCESSORIES ............................................................................................................................. 24
USB Operations ............................................................................................................................. 24
7. TROUBLESHOOTING................................................................................................................... 26
8. ERROR DISPLAYS ....................................................................................................................... 28
9. SPECIFICATIONS ......................................................................................................................... 28
English
3 DB288RUSB
English
1. FEATURES
• Front USB Slot
• Front-panel auxiliary input & 4ch RCA output
• MP3/WMA compatible with ID3-TAG display
2. PRECAUTIONS
1. This unit is applicable for on-road 4 wheel
vehicle purpose only. Use for tractor, fork
truck, bulldozer, off road vehicle, 2 or 3
wheel motor bicycle, marine boat or other
special purpose vehicle is not appropriate.
2. When the inside of the car is very cold and
the player is used soon after switching on the
heater moisture may form on the disc or the
optical parts of the player and proper
playback may not be possible. If moisture
forms on the disc, wipe it off with a soft cloth.
If moisture forms on the optical parts of the
player, do not use the player for about one
hour. The condensation will disappear
naturally allowing normal operation.
3. Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
INFORMATION FOR USERS:
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE
MANUFACTURER WILL VOID THE
WARRANTY.
4 DB288RUSB
Handling Compact Discs
Use only compact discs bearing the or
mark.
Do not play heart-shaped, octagonal, or other
specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode
may not be usable.
Handling
• Compared to ordinary music CDs, CD-R and
CD-RW discs are both easily affected by high
temperature and humidity and some of CD-R
and CD-RW discs may not be played.
Therefore, do not leave them for a long time
in the car.
• New discs may
have some
roughness
around the
edges. If such
discs are used,
the player may
not work or the
sound may skip. Use a ball-point pen or the
like to remove any roughness from the edge
of the disc.
• Never stick labels on the surface of the
compact disc or mark the surface with a
pencil or pen.
• Never play a compact disc with any
cellophane tape or other glue on it or with
peeling off marks. If you try to play such a
compact disc, you may not be able to get it
back out of the CD player or it may damage
the CD player.
• Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use
of such discs may cause misoperation or
damage.
• To remove a compact disc from its storage
case, press down on the center of the case
and lift the disc out, holding it carefully by the
edges.
• Do not use commercially available CD
protection sheets or discs equipped with
stabilizers, etc. These may damage the disc
or cause breakdown of the internal
mechanism.
Ball-point pen
Roughness
English
Storage
• Do not expose compact discs to direct
sunlight or any heat source.
• Do not expose compact discs to excess
humidity or dust.
• Do not expose compact discs to direct heat
from heaters.
Cleaning
• To remove fingermarks and dust, use a soft
cloth and wipe in a straight line from the
center of the compact disc to the
circumference.
• Do not use any solvents, such as
commercially available cleaners, anti-static
spray, or thinner to clean compact discs.
• After using special compact disc cleaner, let
the compact disc dry off well before playing it.
5 DB288RUSB
English
[
RELEASE
]
[ ][
DISP
]
[
SRC
]
[
BND
]
[TA]
[
ROTARY
]
[
SCN
]
[
RPT
]
[DN]
[UP]
[
] (EJECT)
[
RDM
]
[
SOUND
]
[
AUX
]
[
USB SLOT
]
[
DIRECT
]
[
CD SLOT
]
3. CONTROLS
Names of the Buttons and Their Functions
[RELEASE] button
• Press the [RELEASE] button to unlock the
DCP.
[DISP] button
• Switch the display indication.
• Press and hold the button for 1 second or
longer to enter the adjust mode.
[] button
• Perform preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
• Play or pause a track while in the CD/MP3/
WMA mode.
• Confirm various settings.
[CD SLOT]
• CD insertion slot.
[USB SLOT]
• USB memory insertion slot.
[AUX] input jack
• The input jack for connecting an external
device.
6 DB288RUSB
[SOUND] button
• Use the button to switch to the sound adjust
mode.
• Press and hold the button for 1 second or
longer to turn on or off the MAGNA BASS
EXTEND mode.
[UP], [DN] buttons
• Select the folder while in the MP3/WMA
mode.
• Use the buttons to perform various settings.
[DIRECT] buttons
• Store a station into memory or recall it directly
while in the radio mode.
[RDM] button
• Perform random play while in the CD/MP3/
WMA mode.
• Press and hold the button for 1 second or
longer to perform folder random play while in
the MP3/WMA mode.
[RPT] button
• Perform repeat play while in the CD/MP3/
WMA mode.
• Press and hold the button for 1 second or
longer to perform folder repeat play while in
the MP3/WMA mode.
Names of the Buttons and Their Functions
[SCN] button
• Perform scan play for 10 seconds of each
track while in the CD/MP3/WMA mode.
• Press and hold the button for 1 second or
longer to perform folder scan play while in the
MP3/WMA mode.
[ROTARY] knob
• Adjust the volume by turning the knob
clockwise or counterclockwise.
[TA] button
• Use the button to set the TA (Traffic
Announcement) standby mode.
[BND] button
• Switch the band, or seek tuning or manual
tuning while in the radio mode.
English
[SRC] button
• Press the button to turn on the power.
• Press and hold the button for 1 second or
longer to turn off the power.
• Switch the operation mode among the radio
mode, etc.
[x], [v] buttons
• Select a station while in the radio mode or
select a track while in the CD/MP3/WMA
mode.
This button is used to make various settings.
• Press and hold the button for 1 second or
longer to enter the fast-forward or fastbackward mode.
[Q] (EJECT) button
• Eject a disc when it is loaded into the unit.
7 DB288RUSB
Display Items
English
Operation status indication
PS name, PTYs, CT (clock), etc. are displayed.
: MUTE indication
AF : Alternative frequency indication
REG
TA
TP
PTY
MANU
: Regional indication
: Traffic announcement indication
: Traffic programme indication
: Programme type indication
: Manual indication
: Preset channel indication (1 to 6)
: Enter indication
: MP3 indication
MP3
WMA
: WMA indication
Display Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
8 DB288RUSB
4. DCP
DCP
(DETACHABLE CONTROL PANEL)
English
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the car.
Removing the DCP
1. Press the [SRC] button for 1 second or
longer to switch off the power.
2. Press in the [RELEASE] button.
∗ The DCP is unlocked
3. Remove the DCP.
[
RELEASE
] button
Storing the DCP in the DCP Case
Hold the DCP, in the orientation as shown in the
figure below, and put it into the supplied DCP
case. (Ensure the DCP is in the correct
orientation.)
DCP
DCP case
CAUTION
• The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
• When the Release button is pressed and
the DCP is unlocked, the car’s vibrations
may cause it to fall. To prevent damage to
the DCP, always store it in its case after
detaching it.
• The connector connecting the main unit
and the DCP is an extremely important
part. Be careful not to damage it by
pressing on it with fingernails, pens,
screwdrivers, etc.
DCP Rear Panel
Main Unit Front
Attaching the DCP
1. Insert the right side of the DCP into the main
unit.
2. Insert the left side of the DCP into the main
unit.
2.
DCP
1.
DCP
connector
Note:
• If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
Main unit connector
9 DB288RUSB
Loading...
