Clarion DB155 User Manual

Owner’s manual

Mode d’emploi

Manual de instrucciones

DB155

CD receiver

•

Ampli-tuner lecteur CD

•

Receptor con reproductor de CD

Thank you for purchasing this Clarion product.

∗ Please read this owner’s manual in its entirety before operating this equipment. ∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). ∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.

Contents

1. FEATURES.................................................................................................................................. 2

2. CONTROLS ................................................................................................................................3

3. NOMENCLATURE ...................................................................................................................... 4

Names of the Buttons and their Functions .................................................................................. 4

4. PRECAUTIONS .......................................................................................................................... 5

Handling Compact Discs ............................................................................................................. 6

LCD Screen ................................................................................................................................. 6

5. DCP ............................................................................................................................................. 7

6. OPERATIONS ............................................................................................................................. 8

Basic Operations ......................................................................................................................... 8

Radio Operations ......................................................................................................................... 9

CD Operations ........................................................................................................................... 10

7. SPECIFICATIONS......................................................................................................................11

8. IN CASE OF DIFFICULTY ........................................................................................................ 12

9. ERROR DISPLAYS ................................................................................................................... 12

English

1. FEATURES

• High Visibility & Contrast White Negative Display (13 x 8 Digits) with Screen Saver

• CD-R/RW Playability

• High Power 51 W X 4 Built in Amplifier

•2 ch RCA Output

• Z-Enhancer and Magna Bass EX for Sound Adjustment

• “Easy to Use” Rotary Volume Knob

• DCP Case Included

Be sure to unfold and read the next page.

Veuillez déplier et vous référer à la page suivante.

Cerciórese de desplegar y de leer la página siguiente.

2 DB155

English

[ ], [ ]

[

]

[

]

[

ROTARY

]

[

RELEASE

]

[

CD SLOT

]

[

]

[

A-M

]

[

SRC

]

[

BND

]

[

ISR

]

[

]

[

RPT

]

[

DIRECT

]

[

RDM

]

[

SCN

]

Operation status indication (Frequency, clock)

Indication de l'état de fonctionnement(la fréquence, horloge)

Indicación del estado de operación ( la frecuencia, reloj)

MAGNA BASS EXTEND indication

Indication MAGNA BASS EXTEND

Indicación de MAGNA BASS EXTEND

Z-Enhancer indication

Indication de Z-Enhancer

Indicación de reforzador Z mejorado

(Z-Enhancer)

Preset channel indication (1 to 6)

Indication de canal préréglé

(1 à 6)

Indicación de canal memorizado (1 a 6)

Mute indication

Indication de mise en sourdine

Indicación de silenciamiento

Stereo indication

Indication stéréo

Indicación de estéreo

Manual indication

Indication de fonctionnement manuel

Indicación de manual

Random indication

Indication de lecture aléatoire

Indicación de reproducción aleatoria

Repeat indication

Indication de répétition

Indicación de reproducción repetida

Scan indication

Indication de balayage

Indicación de exploración

Display Items / Rubriques d’affichage / Ítemes de visualización

Source unit / Appaeil pilote / Unidad fuente

Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.

Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.

Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.

CONTROLS / LES COMMANDES / CONTROLES

Français

Español

English

3. NOMENCLATURE

Note:

• Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 3 (unfold).

Names of the Buttons and their Functions

[RELEASE] button

• Press the [RELEASE] button to unlock the

DCP.

[ROTARY] knob

• Adjust the volume by turning the knob clockwise or counterclockwise.

• Use the knob to perform various settings.

[CD SLOT]

• CD insertion slot.

[D] button

• Switch the display indication (Main display, Clock display).

• Press and hold the button for 1 second or longer to enter the adjust mode.

[Q] button

• Eject a CD when it is loaded into the unit.

[DIRECT] buttons

• Store a station into memory or recall it directly while in the radio mode.

[RPT] button

• Repeat play while in the CD mode.

[RDM] button

• Perform random play while in the CD mode.

[SCN] button

• Perform scan play for 10 seconds of each track while in the CD mode.

[ISR] button

• Recall ISR radio station in memory.

• Press and hold for 2 seconds or longer: Store current station into ISR memory (radio mode only).

[BND] button

• Switch the band, or seek tuning or manual tuning while in the radio mode.

• Play a first track while in the CD mode.

[SRC] button

• Press the button to turn on the power. Press and hold the button for 1 second or

longer to turn off the power.

• Switches the operation mode among the radio and CD mode.

[A-M] button

• Press and hold the button for 1 second or longer to switch the MAGNA BASS EXTEND on/off.

• Use the button to switch to the audio mode (bass, treble, balance, fader).

[Z] button

• Use the button to select one of the 3 types of sound characteristics already stored in memory.

[a], [d] buttons

• Select a station while in the radio mode or select a track when listening to a CD. These buttons are used to make various settings.

• Press and hold the button for 1 second or longer to switch the fast-forward/fastbackward.

[ ] button

• Play or pause a CD while in the CD mode.

• Perform preset scan while in the radio mode. When the button is pressed and held, auto store is performed.

3 DB155 4 DB155

4. PRECAUTIONS

English

1. When the inside of the car is very cold and the player is used soon after switching on the heater moisture may form on the disc or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc, wipe it off with a soft cloth. If moisture forms on the optical parts of the player, do not use the player for about one hour. The condensation will disappear naturally allowing normal operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help.

2. Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip.

3. This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts.

CAUTION

USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

THE COMPACT DISC PLAYER and MINI DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.

CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

INFORMATION FOR USERS:.

CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND WILL VIOLATE FCC APPROVAL.

MODEL

12V GROUND

AM 530-1710kHz/FM 87.9 -107.9MHz

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE M UST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT M AY CAUSE UNDESIRED OPERATION.

THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

CLARION CO.,LTD. 50 KAMITODA,TODA-SHI,SAITAMA-KEN,JAPAN

MANUFACTURED:

SERIAL No. PE-

Clarion Co.,Ltd. MADE IN

Bottom View of Source Unit

DB155 5
