Citizen iDP3110 User Manual

DOT MATRIX PRINTER

MODEL

iDP3110

Manufacturer’s Name: : Japan CBM Corporation
Manufacturer’s Address : CBM Bldg., 5-68-10, Nakano, Nakano-ku,

Declare the Product

Product Name Dot Matrix Printer
Model Number(s) iDP3110 Series

Conform to the following Standards

LVD:EN60950:A4:1997
EMC : EN55022 : 1998 Class B

iDP3110 User's Manual

Declaration of Conformity

T okyo, 164-0001, Japan

(iDP3110R, iDP3110P)
(S.No. 0090001 ~ )

: EN61000-3-2 : 1995+A1:1998+A2:1998
: EN61000-3-3 : 1995
: EN55024 : 1998
: EN61000-4-2 : 1995 ±4KV CD, ±8KV AD
: EN61000-4-3 : 1996
: EN61000-4-4 : 1995 ±1.0KV(ACMai ns), ±0.5KV(Signal Lines)
: EN61000-4-5 : 1995 ±1KV (Normal mode), ±2KV (Common mode)
: EN61000-4-6 : 1996 3V, 0.15MHz-80MHz AM 1KHz 80%
: EN61000-4-8 : 1993 50Hz, 3A/m
: EN61000-4-11 : 1994 0%, 5000ms/ 70%, 500ms/ 0%, 10ms

4.5V/m, 80MHz-1000MHz AM 1KHz 80%

Supplementary Information

“The product complies with the requirements of the Low Voltage Directive 73/23/EEC, 93/68/EEC and
the EMC Directive 89/336EEC, 92/31/EEC, 93/68EEC”

Place T okyo, Japan Signature

Date September, 2000

Full Name : Mikio Moriya
Position : General Manager

R & D Department

Europe Contact :

Norco Declaration AB

Box 7146 S-250 07 Helsingborg Sweden

This declaration is applied only for 230Vmodel.

CITIZEN

iDP3110 User's Manual

IMPORTANT SAFETY INSTRUCTIONS

* Read all of these instructions and save them for later reference.
* Follow all warnings and instructions marked on the product.
* Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners.

Use a damp cloth for cleaning.
* Do not use this product near water.
* Do not place this product on an unstable cart, stand of table. The product may fall, causing serious damage to the

product.
* Slots and openings on the cabinet and the back or bottom are provided for ventilation.

To ensure reliable operation of the product and to protect it from overheating, do not block or cover these

openings. The openings should never be blocked by placing the product on a bed, sofa, rug of other similar

surface.

This product should never be placed near or over a radiator or heat register.

This product should not be placed in a built-in installation unless proper ventilation is provided.
* This product should be operated from the type of power source indicated on the marking label.

If you’re not sure of the type of power available, consult your dealer or local power company.
* Do not allow anything to rest on the power cord. Do not locate this product where the cord will be walked on.
* In an extension cord is used with this product, make sure that the total of the ampere ratings on the products

plugged into the extension cord do not exceed the extension cord ampere rating.

Also, make sure that the total of all products plugged into the wall outlet dose not exceed 15 amperes.
* Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points

or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
* Except as explained elsewhere in this manual, don’t attempt to service this product yourself.

Openi ng an d remov ing thos e cover s tha t are mar ked “D o Not Remo ve” may exp ose yo u to danger ous vo ltage

points or other risks. Refer all servicing on those compartments to service personnel.
* Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following

conditions:

A. When the power cord or plug is damaged or frayed
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product dose not operate normally when the operating instructions are followed. Adjust only

those controls that are covered by the operating instructions since improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to restore
the product to normal operation.

E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance, indicating a need for service.

CITIZEN

iDP3110 User's Manual

IMPORTANT:

This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in
accordance with the instruction manual, may cause interference to radio communications. It has been tested and
found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules,
which are designed to provide reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which case the
user at his own expense will be required to take whatever measures may be necessary to correct the interference.

CAUTION: Use shielded cable for this equipment.

For Uses in Canada

This digital apparatus does not exceed the class A limits for radio noise emissions from apparatus, as set out in
the radio interface regulations of the canadian department of comm unications.

Pour L’ utilisateurs Canadi ens

Cet appareil numérique ne dépasse pas limites de carégorie a pour les émissions de bruit radio émanant
d’appareils numériques, tel que prévu dand les réglements sur l’interference radio du départment canadien des
communications.

CITIZEN

iDP3110 User's Manual

CONTENTS

1. INTRODUCTION.........................................................................................................................................1

1.1 Features................................................................................................................................................................1

1.2 Accessories...........................................................................................................................................................1

2. TYPE CLASSIFICATIONS..........................................................................................................................2

2.1 Type......................................................................................................................................................................2

2.2 AC adapter............................................................................................................................................................2

2.3 Specifications.......................................................................................................................................................3

3. EXTERNAL APPEARANCE AND PART DESCRIPTION.......................................................................... 4

3.1 External Appearance............................................................................................................................................4

3.2 Part Descriptions..................................................................................................................................................5

4. OPERATIONS .............................................................................................................................................6

4.1 Connection of the AC Adapter.............................................................................................................................6

4.2 Setting of the Printer Cover..................................................................................................................................7

4.3 Setting of Ribbon Cassettes..................................................................................................................................8

4.4 Setting Paper.........................................................................................................................................................9

4.5 Self Test Printing................................................................................................................................................10

4.6 General Notices..................................................................................................................................................10

5. PARALLEL INTERFACE...........................................................................................................................11

5.1 Specifications.....................................................................................................................................................11

5.2 Connector Pin Assignment.................................................................................................................................11

5.3 Description of Input / Output Signals.................................................................................................................12

6. SERIAL INTERFA CE................................................................................................................................14

6.1 Specifications.....................................................................................................................................................14

6.2 Connector Pin Assignment.................................................................................................................................15

6.3 Description of Input / Output Signal ..................................................................................................................15

7. DIP SWITCH SETTING.............................................................................................................................18

7.1 Serial Interface Type...........................................................................................................................................18

7.2 Parallel Interface Type........................................................................................................................................18

8. PRINT CONTROL FUNCTION .................................................................................................................19

8.1 Control Command..............................................................................................................................................19

9. CHAR ACTER SET....................................................................................................................................26

9.1 Character code....................................................................................................................................................26

10. E X TERNAL DIMENSIONS.....................................................................................................................29

CITIZEN

iDP3110 User's Manual

1. INTRODUCTION

The iDP3110 is a dot-impact printer suitable for use with various data communication terminals, and measurement
terminals.
This product is ex tremely compact a nd features extensi ve functions s uited for a wi de range of ap plications. Pl ease
read this manual thoroughly to understand the printer before use.

1.1 Features

1. Compact desk-top dot matrix printer

2. Light weight

3. High speed printing

4. Low power consumption

1.2 Accessories

The following attachments are included in this set aside from the printer itself. Please confirm.

Paper roll (1 roll)
Ribbon cassette (1 unit)
AC adapter (1unit)
User’s manual (1 booklet)

CITIZEN

1

2. TYPE CLASSIFICATIONS

2.1 Type

The product is categorized according to the naming plan indicated below.

iDP3110 User's Manual

iDP3110 24

40

iDP3110 24 P J 120 A

Model Name

Number of columns A : 60mm(Dia.)
24 : 24 columns/144 dots Paper roll
40 : 40 columns/180 dots B : 80mm(Dia.)

Interface
P : Parallel (Centronics)
R : Serial (RS-232C) Character

P

R

J

F

120
230

Power source
120 : AC 120V
230 : AC 220-240V

J : Japanese
F : International

A
B

Printer cover

Paper rol l

2.2 AC adapter

Please use the excl usi ve ada pt er indica ted below.
90AD-U (AC 120V)
90AD-E (AC 220-240V)

CITIZEN

2

2.3 Specifications

1 Printing method Dot matrix
2 P r i nt i n g di rection One- way pri nting
3 Character configuration

(W × H)
4 Number of columns per line 24 columns: 144 dot/line 40 columns: 180 dot/line
5 Printing speed Approx. 2.5 line/sec. Approx. 1.8 lines/sec.
6 Character size (W × H) 1.6 × 2.4 mm 1.08 × 2.4 mm
7 Line pitch 3.52 mm
8 Paper Paper Roll 57.5 ± 0.5(W) × 60 (Dia) mm

9 Interface Type P: Parallel Interface (Centronics)

10 Ribbon cassette Exclusive ribbon cassette

11 Voltage DC 7V ± 1V (Printing)

12 Power consumption Printing : approx. 7VA

13 Weight Approx. 400g
14 Dimension 106(W) × 180(D) × 88(H) mm (60 Dia. Paper Roll)

15 Operating temp.
16 Storage temp

iDP3110 User's Manual

Item iDP3110-24* iDP3110-40*

(5 + 1) × 8 (4 + 0.5) × 8

57.5 ± 0.5(W) × 80 (Dia) mm

Type R: Serial Interface (RS-232C)

Purple print : IR-91P
Black print : IR-91B (Option)

Use exclusive adapter (DC 7V, 1.2A)

Stand-by : approx. 0.5VA

106(W) × 180(D) × 106(H) mm (80 Dia. Paper Roll)
0°C to 40°C

-20°C to 60°C

CITIZEN

3

3. EXTERNAL APPEARANCE AND PART DESCRIPTION

3.1 External Appearance

iDP3110 User's Manual

CITIZEN

4

iDP3110 User's Manual

3.2 Part Descriptions

1. DC Jack Insert the output plug of the AC adapter attached.

2. Power Switch When switched ON, power is supplied to the printer, starting the initializing operation.

3. Power Lamp Lighted when power is turned ON and goes out when turned OFF.

4. SEL Lamp Lighted when printer is in the selected condition (ON-LINE).
Printer becomes operational only when this lamp is on.

5. LF Swit ch Paper is f ed w hen s witc h is pres se d (de- se lect co ndit io n only) . Us ed t o su ppl y pap er or to
insert some space in the output.

6. SEL Switch Printer is selected (ON-LINE) by pressing this switch.
Printer is de-selected (OFF-LINE) by pressing the switch again.

7. Interface Connector Printer is connected to various hosts via cables.
Please ensure that both the printer and the host are turned off before connecting.

8. Printer Cover Opened to exchange ribbon cassette and paper roll.

CITIZEN

5

iDP3110 User's Manual

4. OPERATIONS

4.1 Connection of the AC Adapter

(1) Ensure that the power switch is OFF.
(2) Insert the output plug of the AC adapter into the DC jack of the printer.
(3) Insert the power plug of the AC adapter into a power concent supplying the designated voltage.

(Use of exclusive AC adapter is recommended. Output is DC 7V, 1.2A. Avoid using power sources not conforming to
this specification.)

CITIZEN

6

iDP3110 User's Manual

4.2 Setting of the Printer Cover

(1) Hold the protruding section at the rear of the printer cover and lift in the direction indicated.
(2) Attach the cover by pressing downward after hooking the cover to the acceptor located in the front part.

CITIZEN

7

iDP3110 User's Manual

4.3 Setting of Ribbon Cassettes

(1) Remove the printer cover after turning OFF the printer.
(2) Press down on the Ribbon cassette while inserting the ribbon between the printing head and the platen.
(3) Wind up the ribbon slack by turning the knob in the direction of the arrow.

CITIZEN

8

iDP3110 User's Manual

4.4 Setting Paper

(1) Remove the printer cover.
(2) Ensure that the end of the paper is straight or incline as indicated in the diagram.
(3) Insert the end of the paper into the slot of the printer mechanism.
(4) After turning ON the printer, press the LF switch until 5 to 6 cm of paper is fed out of the printer mechanism.
(5) Insert pa per after moving asi de the paper holder in the directi on of the a rrow. Then, sec ure the ce nter of t he roll

with the holder.

(6) Then, attach the printer cover so the end of the paper comes out of the opening in the cover.

CITIZEN

9

iDP3110 User's Manual

4.5 Self Test Printing

A self-printing function is incorporated in this product to enable the printer to check itself.
This function is triggered by the following procedure.
(1) Set paper to the printer.
(2) Ensure that the ribbon cassette is attached correctly and turn the power OFF.
(3) Turn ON the power switch while holding the LF switch down. Release the LF switch after the self-printing

operation has started.

Printing is initiated by this operation. To end self-printing, turn OFF the printer.

4.6 General Notices

(1) Never operate your printer without loading paper and ribbon cassette. Any printing without paper and ribbon

cas se t te ma y c a us e damage to printe r head.

(2) Replace ribbon cassette before it is worn with rents.
(3) Be careful not to drop any foreign matters, such as paper clips and pin and the like into your printer.

Those can cause mechanical trouble.

(4) Nothing shall be placed on the radiation vents to the printer.
(5) Place your printer always on a stable desk which is set horizontal.
(6) No organic solvent (thinner, benzin or the lie) shall be used in sweeping clean the surface of the main body case.
(7) Make sure that the power of the printer is turned off whenever you do the following.

1) Taking out any foreign matter which was dropped into the printer.

2) Replacing the ribbon cassette.

CITIZEN

10

5. PARALLEL INTERFACE

5.1 Specifications

a) Data input system : 8 bit parallel (DATA 1-8)
b) Control signal : ACK, BUSY, STB, RESET, SELECT
c) Compatible Connector : Printer side : 57LE-40360

(AMPHENOL or equivalent)

: Cable side : 57-30360

(AMPHENOL or equivalent)

5.2 Connector Pin Assignment

PIN SIGNAL NAME PIN SIGNAL NAME

1 STB 19 TWISTED PAIR GND
2DATA1 20
3
4
5
6
7
8

9
10 ACK 28
11 BUSY 29
12 GND 30 GND
13 SELECT 31 RESET
14 GND 32
15 33 GND
16 GND 34
17 FRAME GND 35
18 36

″ 2
″ 3
″ 4
″ 5
″ 6
″ 7
″ 8

21
22
23
24
25
26
27

iDP3110 User's Manual

″
″
″
″
″
″
″
″
″
″

CITIZEN

11

iDP3110 User's Manual

5.3 Desc ription of Input / Output Signals

(1) Input signal

All input signals utilize type 74HC of CMOS and can be used in TTL level as the input is pulled up with 3.3 kΩ
resistance.

- DATA 8 bit parallel signal (positive logic)

- STB Strobe signal for reading out data (negative logic)

- RESET Signal for resetting the entire unit (negative logic 4ms or more)

(2) Output signal

TTL is utilized for all output signals. The output is pulled up with 3.3 kΩ resistance.

- ACK Signal for requesting data. ACK is issued at the end of the BUSY signal (negative logic)

- BUSY Signal indicating the printer is busy. Input new data when the signal is in “LOW”
condition.(positive logic)

- SELECT Signal indicating the printer is set to a selected condition (on-line). “ HIGH” state signifies the
printer is selected.

(3) Others

- GND The common circuit ground.

- FG Equivalent to “case ground”.

• Input
[ Printer side ] [ Host side ]

DATA : 74HC373 equivalent
STB : 74HC14 equivalent
RESET : 74HC04 equivalent

CITIZEN

12

• Output

[ Printer side ] [ Host side ]

(4) Timing chart

1) Timing for data entry and printing

iDP3110 User's Manual

T1 0.5 µs MIN
T2, T3 1 µs MIN
T4 2 µs TYPE

(5) Data receiving

Printer is capable of accepting data from the host while the BUSY signal is in the “LOW” state. Printer cannot
accept data when the signal is “HIGH”.

CITIZEN

13

6. SERIAL INTERFACE

6.1 Specifications

1) Synchronization : Asynchronous

2) Baud rate : User selection, 4,800; 9,600 Baud / sec

3) Word configuration : Start bit 1 bit
: Data bit 8 bit
: Stop bit More than 1 bit

4) Signal polarity

RS-232C

* Mark = Logic “1” (-3 to –12V)

* Space = Logic “0” (+3 to +12V)

TTL(RESET)

* H level = Logic “1” (refer to (3), section 6.3)

* L level = Logic “0”

5) Input control (DTR signal)

* Mark : Data transmission not possible
* Space : Data transmission possible

iDP3110 User's Manual

CITIZEN

14

iDP3110 User's Manual

6.2 Connector Pin Assignment

SIGNAL SIGNAL SIGNAL DIRECTION FUNCTION RS232C TTL

PIN NAME HOST-PRINTER

1 FG Frame ground
7 GND Signal ground

3RD
20 DTR
23 RESET

→
←
→

Received data
Printer BUSY signal
Printer reset signal

Note: 1. Signals for RS-232C are based on EIA RS-232C level.

Applicable connector (D-Sub connector)
Printer : 17LE-13250 (Anphenol equivalent)
Cable : 17JE-23250 (Anphenol equivalent)

6.3 Desc ription of Input / Output Signal

(1) I / O signals

1) RD
Serial input data signal. Data is ignored when framing error, overrun error, or parity error has occurred.

2) DTR
Input command or data while this signal is in ready state. Data input while the signal is BUSY will cause an
overrun error to occur and the data will be ignored. Data can be provided to the input buffer even if the printer is
printing.
Busy state may also occur when power is applied, or during test printing, on-line, or when the printer is reset.

CITIZEN

15

3) RESET
Signal resets the entire printer. (More than 4ms.)

4) FG
Frame ground

5) GND
Common ground for the circuit.

(2) Data configuration

(1) Start bit (1 bit)
(2) Data bit (8 bit)
(3) Stop bit (more than 1)

iDP3110 User's Manual

CITIZEN

16

(3) Electrical characteristics

1) RS-232C circuit

Input (RD)

[PRINTER] [HOST]

MAX 232 equivalent Mark = (-8V) : Stop bit

Output (DTR)

iDP3110 User's Manual

Space = (+8V) : Start bit

MAX 232 equivalent

2) TTL circuit

Input (RESET)

7HC14 equivalent Set to LOW when reset

DTR (-8V) when BUSY

(+8V) when READY

CITIZEN

17

7. DIP SWITCH SETTING

7.1 Serial Interface Type

Switch Functions OFF ON Shipping

NO. Setting

1 Character direction Normal Inverted OFF

selection character character

2 Baud rate selection 9600 BPS 4800 BPS ON

3,4 Not used OFF

7.2 Parallel Interface Type

Switch Function OFF ON Shipping

NO. Setting

1 Character direction Normal Inverted OFF

selection Charact er character

2Print command CR LF OFF

selection

3, 4 Not used OFF

iDP3110 User's Manual

Dip switch position

The Arrow mark in the figure below indicates the location of the dip switch with the printer cover removed.
Power switch OFF the printer before altering the settings.

CITIZEN

18

iDP3110 User's Manual

8. PRINT CONTROL FUNCTION

8.1 Contr o l Command

(1) Print command (CR or LF)

In case of initiate parallel transmission, select code CR (0DH) or LF (0AH) on the DIP switch 2.
If the selected code (CR or LF) is input, the data in the print buffer is printed and line feed is performed.
When the serial interface is used, only the CR code becomes effective.
When graphic (mosaic) printing is performed, line feed is not performed by the print command, and graphic
(mosaic) printing is allowed on the next line.

(2) Input data cancel command (CAN)

By entering the CAN (18H) code, all data entered prior to the entry of the code on a same line is canceled.

(3) Enlarged character printing (SO)

By entering the SO (0EH) code on a specific digit, data entered there-after is output as enlarged characters.
The function is cleared by entering the print code (CR or LF) or DC4 (14H).
The number of printable columns per line for an entire line of enlarged characters are indicated in the table
below.

Model Number of columns
iDP3110-24* 12 columns
iDP3110-40* 20 columns

CITIZEN

19

iDP3110 User's Manual

(4) Power down function

In order to reduce power consumption when printer is waiting for the operation, 2 power down modes triggered
by the codes DC2 and DC3 are incorporated into this product. When the printer receives power down
commands (DC2 or DC3), it switches to the power down mode after all entered data is printed out.

a) DC2 (12H)

Unit switches to power down mode when DC2 code is entered. Operation of the oscillator is not
terminated.

[Power down release]
(a-1) RESET input

By applying “LOW” pulse to the RESET terminal for more than 4ms, the power down mode is
cleared, thereby switching the unit to operational condition approximately 100ms after initialization.

b) DC3 (13H)

Unit switches to power down mode when DC3 code is entered.
Operation of the oscillator is terminated, reducing the power consumption to less than that of the DC2
power down mode.

[Power down release]
(b-1)RESET input

By applying “LOW” pules to the RESET terminal for more than 4ms, the power down mode is
cleared, thereby in HIGH-lev el switching the unit to operational condition approximately 100ms after
initialization.

(5) Escap e con tro l co mmand

By entering ESC (1BH) followed by an ASCII code, the control command indicated below are performed.
Symbol n after the ASCII code indicates an 8 bit binary number. The “+” symbol is used merely as a separator
and is not to be entered.

CITIZEN

20

iDP3110 User's Manual

a) Line spacing setting command (ESC + A + n)

Dot line space setting is determined by entering the code ESC +A + n.
Initial setting is 2 dot line space. The n should be an even number in the range of 0 ≤ n ≤ 255.
Note) If an old number is entered, the dot line is set to “n-1”.

Continuous printing is enabled by specifying n = 0 or 1.

b) Bit image printing (ESC + K + n1 + n2 + n3)

By entering ESC + K + n1 + n2 + n3, print mode is switched from the text mode to bit image mode. n1,
n2, and n3 indicate the transmission volume of the bit image data to follow. That is, n1 indicates the
horizontal byte while n2 and n3 signify the vertical dot lines.
(Relation between the data and printout)

(Range of parameter setting)

MODELn1n2n3
iDP3110-24* 1 to 18 0 to 255 0 to 1
iDP3110-40* 1 to 23 0 to 255 0 to 1

In case a number is beyond the specificable range is specified, and if n2 = n3 = 0 is spec ified, the bit
image mode is canceled and the printer returns to text mode.

CITIZEN

21

iDP3110 User's Manual

As this printer prints out 4 dot lines as one unit, the lacking data is output as space once the data for 4 dot lines
are read in or the output of data specified in n1, n2 and n3 has finished.

Note 1) If n1 = 23 is specified in iDP3110-40 specification, 4 dots from the topmost dot (MSC DOT)

become invalid. This is due to the fact that the output position for a single line consists of 180
dots.

Note 2) Although the printer returns to text mode when bit image mode printout is completed, line

spacing is set to 0 to enable further output in the bit image mode. Line feed is required in order
to commence text mode output.
For bit image printing, inverted printing is not performed but normal printing, even if the DIP
switch 1 is set to “ON”.

c) International character setting (ESC + R + n)

By entering the code ESC + R + n, characters input hereafter are set to the characters for the following
countries.
Then n value and country setting is as indicated in the table below.

n Country n Country
0 America 5 Sweden
1France 6 Italy
2Germany7 Spain
3 England 8 Japan
4Denmark

n other than that specified becomes invalid and the setting prior to the invalid specification is employed.
When the printer is turned on or RESET, the country is set to n = 0 (America).

CITIZEN

22

iDP3110 User's Manual

d) Character registration (ESC + & + A1 + A2)

Individual patterns can be registered by entering the code ESC + & + A1 + A2, then entering the pattern
data.
A maximum of 8 characters can be registered, and any address in the range of 20H to FFH can be used for
the registration. However, if a new pattern is registered in an address already in use, existing data is cleared
and the newly entered data becomes valid. If more than 8 characters are registered, all existing c haracter
registration is cleared.

[Address setting]

Specified address is matched to the character code and can be accessed likewise to the stored fixed
character record.
If a fixed character is defined in the specified address, the fixed character becomes invalid.
A1 signifies the starting address for the registration and A2 is the ending address.

[Method of data transmission]

d-1) Single character registration

Select the address to be defined (character code) from among 20H to FFH and designate is as A1.
When registering a single character, starting and ending addresses match each other. Tat is, A1 = A2.

<Example> A 6 × 8 dot matrix full dot pattern is to be registered in address 41H (code for the fixed

character “A”).

(Numerals are hexadecimal.)
1B • 26 • 41• 41 • FF • FF • FF • FF • FF • FF

↑ ↑ ↑ ↑
ESC & A1 A2 Pattern data (6 bytes)

In the successive controls, a 6 × 8 dot matrix full dot is output whenever the character code 41H is
specified. (Character “A” cannot be accessed.)

CITIZEN

23

iDP3110 User's Manual

d-2) Multiple character registration

By repeating the single character registration, a maximum of 8 characters can be registered.
When defining multiple characters in a successive address (character code), register pattern data for a
maximum of 8 characters by designation A1 as the starting address and A2 as the ending address.

Note) A1<A2, A2-A1≤7

[Pattern data configuration]

d-3) In case of iDP3110-24* (24 columns) specific ation

Pattern data to be registered must consist of 6 bytes per character. That is, pattern data configured by
a 6 × 8 dot matrix is broken up into 6 vertically positioned units each of which is represe nted by 1
byte of data. All together, 6 bytes of data are transmitted.
<Example> When transmitting the following data,

CITIZEN

24

iDP3110 User's Manual

d-4) In case of iDP3110-40* (40 columns) specif ication

Pattern data to be registered must consist of 7 bytes per character.
That is, pattern data configured by a 7 × 8 dot matrix is broken up into 7 vertically positioned units
each of which is represented by 1 byte of data. All together, 7 bytes of data are transmitted.
<Example> When transmitting the following data,

As the model utilizes the half-dot printing method, it is not capable of positioning successive dots in
the printing direction (between print). Therefore, pattern specification in the position “*” to the right
of the position “•” in the diagram above will not be registered as pattern data.

e) Continuous paper feed command (ES + B + n)

By entering the code ESC + B + n, continuous paper feed operation is carried out for n dot lines.
The n should be an even number in the range of 4 ≤ n ≤ 255. If an odd number is entered, the dot line is set
to “n-1”. The command is canceled if a number exceeding this range is specified.
If printout data is stored within the input buffer when the command is entered, the printer commences with
the printout. However, the print line (10 dot line) will be included in the line feed value “n”. Therefore, if
4 ≤ n ≤ 9 is specified, line space shall be set as “0”.

CITIZEN

25

9. CHARACTER SET

9.1 Character code

(In the following Table *1-*12 are the characters of the next page by a command, ECS + R + n.)

iDP3110 User's Manual

CITIZEN

26

iDP3110 User's Manual

CITIZEN

27

Individual Country

Character Codes

iDP3110 User's Manual

CITIZEN

28

10. EXTERNAL DIMENSIONS

iDP3110 User's Manual

CITIZEN

29

iDP3110 User's Manual

CITIZEN

30

Information Systems Division CBM Bldg., 5-68-10, Nakano, Nakano-ku, Tokyo 164-0001, Japan
Head Office Tel: [phone] Fax: [phone]

20-990914-5000-0036-005.25 Printed in Japan
