Citizen CL-S700II Service Manual

Thermal Transfer Barcode & Label Printer
CL-S700 Series
USER'S MANUAL
CL-S700 CL-S703 CL-S700R

CONTENTS

Before Operation
Chapter 1 Setup
Confirmation of Carton Contents -------------------------------------------------10 Part Names and Functions----------------------------------------------------------11 Connection to Power ---------------------------------------------------------------18 Driver Installation ------------------------------------------------------------------- 18 Connection to a Computer --------------------------------------------------------19
Chapter 2 Printer Operation
Chapter 3 Printer Adjustments
Chapter 4 Tr oubleshooting --------------------- 64 Appendixes
2

INTRODUCTION

Thank you for purchasing a Citizen CL-series label printer offering high performance printing at up to 10 inches per second on media up to 4.65 inches wide.
❚❚❚ Main Features ❚❚❚
<Easy Access - Easy Operation>
The printer is designed for all day-to-day operations to be accessible from the front of the printer so there is no need to move items near to the printer for access for media loading.
<Hi-OpenTM printer case>
The main printer’s case lifts directly upwards meaning that no space is needed on either side of the printer. The power switch is located in a recessed panel at the front of the printer so it can be easily accessed without moving the printer.
<The Easiest Media Loading>
The Hi-LiftTM metal print head mechanism opens so that it is completely clear of the media path so that the paper and ribbons can be loaded without any part of the printer in the way.
<Easy Printer Control and Configuration>
The clear, easy-to-see backlit LCD makes both configuration and operation easy with simple messages about the printer’s status and also the ability for quick configuration when needed.
<Flexible Media Usage>
The printer features an adjustable media sensor which allows the customer to use any type of media. The media (label) rolls can be inside or outside would. Similarly, the ink ribbon can be wound either way: ‘ink in’ or ‘in out’.
<Optimum Ribbon Tension>
The patented ARCPTM function - Active Ribbon Control and Positioning - maintains even ribbon tension from beginning to end of a ribbon. This eliminates ribbon wrinkle and improves print positioning, especially for small labels. Smudging caused by ribbon slippage is also removed.
<Dual Programming Language>
This printer contains both the Datamax® and Zebra® emulations. By using the keys on the operation panel, it is easy to simply switch between the two emulations to meet your program.
<Interfaces and Options>
Parallel, Serial and USB interfaces are supplied as standard and optional Ethernet and Wireless LAN boards can be fitted quickly and easily. An auto-cutter and peeler option is also available and can be easily installed.
<Easy Rewinder operation> (CL-S700R only)
The internal rewinder is easily accessed from the front of the printer and it can be used for winding liner or printed batches of labels.
3
COMPLIANCE STATEMENT
FOR EUROPEAN USERS
CE marking shows conformity to the following criteria and provisions: Low Voltage Directive (2006/95/EC)/EN60950-1 EMC Directive (2004/108/EC)/EN55022, EN55024, EN61000-3-2 & EN61000-3-3

GS MARK STATEMENT

This product has been tested under EN ISO 7779 and has an acoustic level output no higher than 55db(A).
This device is not intended for use at a video workstation in compliance with Bildscharb V.
This device is not intended for use in the direct field of view at visual display workplaces. To avoid incommoding reflections at visual display workplaces this device must not be placed in the direct field of view.
FCC COMPLIANCE STATEMENT
FOR AMERICAN USERS
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
4
EMI COMPLIANCE STATEMENT
FOR CANADIAN USERS
This Class A digital apparatus complies with Canadian ICES-003.
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This equipment is designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help. CAUTION: Use shielded cables to connect this device to computers.
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.
ETAT DE CONFORMITE EMI A L’USAGE
DES UTILISATEURS CANADIENS
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Cet équipment produit et utilise l’énergie à radiofréquences et s’iln’est pas installé et utilisé correctment, c’esst à dire en accord strict avec les instructions du fabricant, il risque de provoquer des intérferences avec la réception de la radio et de latélévision.
Le présent appareil numérique n’émet pas de bruite radio électriques dépassant les limites applicables aux appareils numériques de la classe A prescrites dans le Réglement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.
Cet équipment est conçu pour fournir une protection satisfaisante contre de telles interférences dans une installation résidentielle. Cependant, il n’y a pas de garantie contre les interférences avec les réceptions radio ou télévision, provoquées par la mise en et hors circuit de l’équipment; aussi, il est demandé a l’utilisateur d’essayer de corriger l’interférence par l’une ou plus des mesures suivantes:
• Réorienter l’antenne de réception.
• Installer l’ordinateur autre part, par égard pour le récepteur.
• Brancher l’ordinateur dans une prise de courant différente de façon à ce que l’ordinateur et le
récepteur soient branchés sur des circuits différents.
5

IMPORTANT SAFETY INSTRUCTIONS

• Read all of these instructions and save them for later reference.
• Follow all warnings and instructions marked on the product.
• Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. The product may fall, causing serious damage
to the product.
• Slots and openings on the cabinet and the back or bottom are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, do not block or cover these openings. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation unless proper ventilation is provided.
• This product should be operated from the type of power source indicated on the marking label. If you are not sure of the type of power available, consult your dealer or local power company.
• This product is equipped with a three-pronged plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
• Do not allow anything to rest on the power cord. Do not locate this product where the cord will be walked on.
• If an extension cord is used with this product, make sure that the total of the ampere ratings on the products plugged into the extension cord do not exceed the extension cord ampere rating. Also, make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes for 120V outlet and
7.5 amperes for 220V-240V outlet.
• Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
• Except as explained elsewhere in this manual, don't attempt to service this product yourself. Opening and removing those covers that are marked "Do Not Remove" may expose you to dangerous voltage points or other risks. Refer all servicing on those compartments to service personnel.
• The mains plug on this equipment must be used to disconnect mains power. Please ensure that the socket outlet is installed near the equipment and shall be easily accessible.
• Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally when the operating instructions are followed. Adjust only
those controls that are covered by the operating instructions since improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product
to normal operation. E. If the product has been dropped or the cabinet has been damaged. F. If the product exhibits a distinct change in performance, indicating a need for service.
6

NOTICE

• Before use, be sure to read this manual. And keep it handy for reference when needed.
• The contents of this manual may change without prior notice.
• Reproduction, transfer, or transmission of the contents of this manual without prior consent is strictly
prohibited.
• We are not liable for any damage resulting from the use of the information contained herein, regardless of errors, omissions, or misprints.
• We are not liable for any problems resulting from the use of optional products and consumable supplies other than the designated products contained herein.
• Do not handle, disassemble or repair the parts other than those specified in this manual.
• We are not liable for any damage caused by user's erroneous use of the printer and inadequate environment.
• Data residing in the printer is temporary. Therefore, all data will be lost if power is lost. We are not liable for
any damage or loss of profits caused by data loss due to failures, repairs, inspections, etc.
• Please contact us if there are any mistakes or ambiguities within this manual.
• If there are missing or incorrectly collated pages in this manual, contact us to obtain a new manual.
CITIZEN is a registered trademark of CITIZEN HOLDINGS CO., Japan.
CITIZEN es una marca registrada de CITIZEN HOLDINGS CO., Japón.
Copyright © 2009 by CITIZEN SYSTEMS JAPAN CO., LTD.
7

SAFETY INSTRUCTIONS

which must be strictly observed !
• To prevent personal injury or property damage, the following shall be strictly observed.
• The degree of possible injury and damage due to incorrect use or improperly following
instructions is described below.
Warning
Caution
: This is a mark to call attention to the reader.
Indicates a situation which, if not observed and handled properly, could result in death or serious injury.
Indicates a situation which, if not observed and handled properly, could result in injury.
Warning
Never perform the following. If not avoided, these may cause damage or trouble to the printer or cause the printer to overheat and release smoke and cause burns or an electrical shock. If the printer is damaged or is malfunctioning, be sure to turn the printer off immediately and remove the power cord from the outlet, then consult our service personnel.
• Do not place the printer in a poorly ventilated area, or shut off the air vent of the printer.
• Do not place the printer where chemical reactions occur, such as in laboratories or where air is mixed
with salt or gas.
• Do not use a power voltage or frequency other than those specified.
• Do not plug/unplug the power cord or attach/detach the interface cable by simply grabbing the
power cord or interface cable. Do not pull or carry the printer when the tension of the power cord or interface cable is increased.
• Do not drop or put foreign matter such as clips and pins into the printer. This may cause problems.
• Do not plug the power cord into an outlet with many loads.
• Do not spill drinks such as tea, coffee and juice on the printer or spray insecticide on the printer. If
drink or water is spilled, first be sure to turn the power off and remove the power cord from the outlet, then consult our service personnel.
• Do not disassemble or modify the printer.
Discard or safely store the plastic packing bag. This bag should be kept away from children.
If the bag is pulled over a child’s head, it may cause suffocation.
8
General Precautions
Caution
• Prior to operation, read the safety instructions carefully and observe them.
• Do not drop or put foreign matter such as clips and pins into the printer. This may cause problems.
• Be careful when moving or carrying the printer. Dropping the printer may cause injury or property
damage.
• Make sure if you open the top cover, it is opened all the way. If only partially open, the cover could
slam shut, possibly causing injury.
• When the cover is open, be careful of the corners of the cover. They could cause injury.
• Do not open the printer during printing.
• When cleaning the surface of the printer case, do not use the cloth that is soaked in thinner,
trichloroethylene, benzine, ketone or similar chemicals.
• Do not use the printer where there is a lot of oil, iron particles, or dust.
• Do not spill liquids or spray insecticide on the printer.
• Do not jolt or impact to the printer by stepping on, dropping or hitting the printer.
• Operate the control panel properly. A careless, rough handling may cause problems or malfunction.
Do not use such sharp-edged tool as a ballpoint pen for operation.
• Be careful of the edges of the plates so injury or property damage is possible.
• If a problem occurs during printing, stop the printer immediately and unplug the power cord from
the outlet.
• When printer trouble occurs, do not try to dissemble it. Instead, consult our service personnel.
Precautions When Installing the Printer
Caution
• Prior to operation, read the safety instructions carefully and observe them.
• Do not use or store the printer near fire, excessive moisture, in direct sunlight, near an air conditioner
or heater or other source of unusually high or low temperature or humidity or excessive dust.
• Do not place the printer where chemical reactions occur, such as in a laboratory.
• Do not place the printer where air is mixed with salt or gas.
• The printer must sit on a firm, level surface where there is ample ventilation. Never allow the printer's
air vent to be blocked by a wall or other object.
• Do not put anything on the top of printer.
• Do not place the printer near a radio or television, and do not use the same wall outlet for the
printer and radio or television. Radio or television reception could be adversely affected.
• Use the power cord supplied with the product. Never use the power cord for other product.
• Do not put anything on the power cord or step on it.
• Do not drag or carry the printer with the power cord or interface cable.
• Avoid plugging the power cord into an outlet with many loads.
• Do not bundle the power cord when inserting the plug.
• Always grip the plug housing, not the cord, to plug/unplug the power cord.
• Make certain the power is turned off before connecting/disconnecting the interface cable.
• Avoid lengthening the signal cable or connecting it to any noise-producing device. If it is unavoidable,
use the shielded cable or twisted pair for each signal.
• Place the printer near the outlet where the power cord can be unplugged easily to shut off power.
• Use the AC outlet that accepts a three-pronged plug. Otherwise, static electricity may be generated
and there will be danger of electric shock.
9
1

Setup

Confirmation of Carton Contents

Removing the Packing Material

The printer is shipped with adhesive tape in place to hold the top cover closed. Simply remove the two pieces of tape on either side of the top cover. Then simply open the cover by lifting up and tipping it backwards.
There is another strip of adhesive tape that must be removed which holds the mechanism closed for shipping. Remove the tape and attached paper by carefully peeling from the plastic case.
Retain the tape should you need to transport the printer again. A further piece of packing paper is inside the mechanism and you can remove this when the head is opened as explained later in the manual.
Check that the following accessories are included with the printer in the carton.
Sample ribbonRibbon holder
Head cleaner
Te st label media Power cord
CD-ROM
Printer [Model CL-S700/CL-S703]
Paper core (for ribbon)
Media holder barMedia holder guide
CL-S700 Series
Thermal Transfer Barcode & Label Printer
U
SER'S
M
ANUAL
CL-S700 CL-S703 CL-S700R
Quick-start guide
Note: The empty carton and packing materials should be stored for future
shipping of the printer. When removing the CL-S700R from the box, there is the extra cardboard “sling” to make lifting easier.
10
Caution
• Be careful when moving or carrying the printer and when taking the printer out of the carton. The printer may cause injury or property damage if dropped. Be sure to grip the printer housing firmly when taking it out of the carton. Do not grip the printer by the foam packing material which may break, causing the printer to drop.
• When opening the cover, open it all the way. If only part way open, the cover could slam shut, possibly causing injury.
• Be careful of the edge of the cover when the cover is opened. It may cause injury or property damage.
• Be careful of the edges of the metal plates as injury or property damage is possible.

Part Names and Functions

Inside the printer

1
Setup
Operation Panel (p.16)
Setting the Ribbon (p.32)
3
4
2
5
1 Top cover
Is opened vertically to set media or ribbon.
2 Operation panel
This is used to make changes and adjustments to the printer and its configuration.
3 Top cover window
The amount of ribbon and media remaining can be checked through this window.
4 Ribbon drive unit
Power ON/OFF (p.20)
5 Power switch
This is the power switch for the printer.
11
1
Setup
Part Names and Functions
1
3
2
1 Ribbon holder
It is used to attach the ribbon and paper core.
2 Media holder guide
This guide is moved horizontally to match the media size. The guide can be sliding it from the holder bar.
3 Media holder bar
The media is supported by the media holder bar when installed in the printer.
12
1
Setup
Part Names and Functions
6
4
2
Media Thickness Adjustment (p.57)
Media Width Adjustment (p.58)
3
1 Media thickness adjustment screw
It is adjusted to match the thickness of the media.
2 Media width adjustment indicator
3 Media width adjustment knob
It is adjusted to match the width of the media.
4 Media thickness adjustment indicator
5 Head open lever
The head unit can be raised to install media by pushing this lever. It locks the head unit during printing.
6 Sensor arm open lever
The sensor arm can be raised to install media by pushing this lever.
5
13
1
Setup
Part Names and Functions
1
2
Sensor Adjustments and Calibration (p.54)
Installing the Media (p.26, p33)
3
8
5 7
4
6
1 Thermal printhead
This is the printhead. Avoid touching this with your fingertips and leaving grease or dirt on the printhead surface.
2 Sensor arm
The media can be installed by raising this arm. The media can be held in place by lowering this arm.
3 Adjustable (rear) sensor
Detects the label or tag position. This sensor is switched “on” by default.
4 Fixed media sensor
Alternative method to detect the label or tag position. This sensor is more accurate for small labels as it is closer to the print head. It is switch “off” by default.
5 Left media guide
This is a fixed part of the printer. The left side of the media (labels, tags) as viewed from the front of the printer should be placed against this media guide.
6 Right, movable media guide
Slide the right media guide so that it just touches the media. It should “guide” the media through the printer. It should not hold it firmly otherwise the media will jam.
7 Platen
Interlocked with the thermal printhead, it feeds media backwards or forwards.
8 Adjustable sensor position knob
This is used to change the left-to-right position of the adjustable media sensor across the media. See Chapter 3, Printer Adjustments for more details.
14
4
Setup
Part Names and Functions
5
3
[Model CL-S700R]
2
1
1 Rewinder cover
When using the rewinder function, open the door by pulling the opening handle on the front.
2 Media entry slit cover
When rewinding the printed batches of media, remove the Media Entry Slit Cover and insert the media from the head unit through the slit. It should then be rewound around the Rewinder Flange.
3 Rewinder paper guide (available as an option from your supplier)
When the printer is being used in Peel mode, this curved guide is not needed. In batch mode, when rewinding printed media, this curved guide must be installed to guide the media through the media slit.
4 Peeler rollers
The peeler rollers provide the pressure on the liner to cause the printer to peel off labels one-by-one.
5 Rewinder flange
The liner or batches of printed media are wrapped around the central core of the rewinder flange.
15
1
Setup
Part Names and Functions

Operation Panel

1
LED Functions (p.22)
Normal Operating Mode (p.21)
2 4 5
1 LCD display
This displays the operational status of the printer.
2 POWER LED
This is lit when the printer power is on. (green)
3 ERROR LED
This is lit or flashes when the printer is in an alarm or error status. (orange)
4 FEED key
This key feeds the media to the top of the next label or form.
5 PAUSE key
This temporarily stops printing.
6 STOP key
This stops printing or cancels the alarm.
POWER ERROR
FEED
PAUSE
MENU
STOP
3
6
7
Menu Setup Mode (p.37)
7 MENU key
In normal operation, this key will enter the menu configuration mode. It can be configured to repeat the previous label, if preferred.
16

Rear View

1
Setup
Part Names and Functions
4
Parallel Interface (p.72)
Serial Interface (p.70)
USB Interface (p.75)
Connection to Power (p.18)
2
[Model CL-S700/CL-S703]
3
1 Parallel interface (Centronics parallel or IEEE1284)
This receives parallel transmission of data from a host computer.
2 Serial interface (RS232C)
This receives serial transmission of data from a host computer.
3 USB interface
This receives USB transmission of data from a host computer.
4 Heat air opening
It allows warm air to vent from the printer. Be sure not to block it with media etc.
5 Power cord inlet
The connector of the enclosed power cord is connected here.
5
17
1
Setup

Connection to Power

1. The power switch is located on the front of the printer recessed below the control panel. Check that the power switch is turned OFF.
2. Insert the power cord in to the inlet on the printer.
3. Insert the plug of the power cord in the AC outlet.
Power Switch
AC Outlet
Power Cord Inlet
Caution
Use an AC outlet that accepts a three-pronged plug. Otherwise, static electricity may be generated and there will be danger of electric shock.

Driver Installation

The computer may automatically detect the presence of the new printer when it is first started, depending on the computer type, interface and operating system. Follow any on-screen instruction and also instructions supplied with any additional CD-ROM or floppy disk included with your printer. Your supplier will assist you with the correct drivers and software which are compatible with your particular computer system.
18
Setup

Connection to a Computer

This product has three interfaces that can be used to receive printing data: a serial port (RS232C), parallel port (IEEE1284, Non-L. P. S.), and a USB port (USB1.1). An optional internal network interface can be added by your dealer. To connect the cable, proceed as follows:
1. Turn OFF both power switches of the printer and the computer.
2. Connect one end of the interface cable to the interface connector on the back of the printer and secure it with locks or locking screws, where available.
3. Connect the other end of the interface cable to the interface connector on the computer and secure it with locks or locking screws, where available.
Serial Interface (p.70) Parallel Interface (p.72) USB Interface (p.75)
Replacing the Interface Board (p.76)
Parallel Interface Cable
Serial Interface Cable
USB Interface Cable
Note: If an optional network interface is used, the standard parallel port is
removed from the printer, so the parallel interface cannot be used.
19
2
2

Printer Operation

Printer Operation

Power ON/OFF

Turning on the power

1. The power switch is conveniently located at the front of the printer for easy access during normal operation. It is in the recess underneath the control panel so it cannot be accidentally operated by mistake.
2. The POWER LED is lit.
Operation Panel
POWER ERROR
FEED
Power Switch

Turning off the power

1. Turn off the power switch of the printer.
2. The POWER LED goes off.
Power Switch
[Model CL-S700/CL-S703]
20
Menu Setup Mode (p.37)
Printer Operation

Normal Operating Mode

When the power is turned on, the printer enters normal operating mode. The control keys activate the following functions.
On Line
Ready
POWER ERROR
1
PAUSE
FEED
STOP
2 3
MENU
4
1 PAUSE key: Temporarily pauses printing
• When this key is pushed once, the LCD indicates "Pause" and the printer
temporarily pauses.
• When it is pushed during printing, the printer pauses after the label
currently being printed is issued. Pressing the key a second time restarts printing and the remaining number of designated labels are printed.
2 FEED key: Feeds media
• Pressing this key feeds media to the print start position. The distance
it is fed is determined by automatically detecting the front end of the media when using label media, and when continuous media has been designated, a fixed quantity is fed, then feeding stops.
• When the TEAR OFF setting is effective, feeding stops when the media
has been fed to the TEAR OFF location.
• When the optional cutter unit is installed, the media is fed to the cut
position then it is cut.
• If the optional peeler unit is installed, the media is fed to the peeling
location. When the media is pausing at the peeling position, feeding does not occur, even if the FEED key is pushed.
3 STOP key: It stops printing and cancels the alarm
Pushing this key once during printing puts the printer in pause mode after the label is issued. It is possible to cancel 1 batch of label issuing data by pressing the STOP key for 4 seconds or longer in pause status. (The LCD indicates "Job Clear" during cancel.)
Menu Setup Mode (p.37)
4 MENU key:
In normal operation, this key will enter the menu configuration mode. It can be configured to repeat the previous label, if preferred.
21
2
1 2
Printer Operation
Normal Operating Mode

LED Functions

1 POWER LED
It lights up when printer power is turned on. (green)
2 ERROR LED
This is lit or flashes when the printer is in error status. (orange)
Table of Alarm and Error Indications
In addition to normal operating mode, when an abnormal condition is detected in the printer, an alarm sounds and ERROR LED either lights up or flashes to indicate the type of error. The LCD indicates the error message.
Printing possible (no error) OFF On Line Stop or Pause key on operation panel pressed OFF Pause
Head temperature - high temperature abnormality Flashing
Head temperature - low temperature abnormality Flashing
PF motor temperature abnormality Flashing
Fan motor malfunction Flashing
Cutter motor temperature abnormality Flashing
Head open Flashing
Paper end Flashing
Paper out (paper position undetectable) Flashing
Paper jam Flashing
Head low resistance value abnormality Flashing
Ribbon end Flashing
Communication error (receiving buffer overrun) Flashing
Communication error (parity) Flashing
Communication error (framing) Flashing
Cover open Flashing
*Auto-cutter abnormality (foreign object etc.) Flashing
**Rewinder full (CL-S700R only) Flashing
**Rewinder cover open (CL-S700R only) Flashing
**Rewind fail (CL-S700R only) Flashing
**Rewinder Hot (CL-S700R only) Flashing
* Applicable only when using the optional auto cutter ** Applicable only with the rewinder version
POWER ERROR
FEED
PAUSE
MENU
Item ERROR LED LCD
Alarm
Head Hot
Error
Head Cold
Alarm
PFMotor Hot
Error
Fan Lock
Alarm
Cutter Hot
Error
Head Open
Error
Paper End
Error
Paper Load
Error
Paper Jam
Alarm
Head Check
Error
Ribbon End
Error
Serial Over Run
Error
Serial Parity
Error
Serial Framing
Error
Cover Open
Error
Cutter Fail
Error
Rewinder Full
Error
Rewinder Open
Error
Rewind Fail
Alarm
Rewinder Hot
STOP
22
Printer Operation

Setting the Media

Media Sizes

The position of label and tag media is sensed by either a transparent sensor or a reflective sensor. Transparent sensor: Detects the gaps between label media and notches of
tag media
Reflective sensor: Detects the black mark
Size of media
Continuous media
C
Label media
B A
Notch detection Black mark detection
D
H
G
F E
Printable area
Left margin Right marginPrintable area
Label
Label
Label
Use of media gap sensor
104.0mm 11.5mm2.5mm
I
KK
I
J
L
M
N
Use of black mark sensor
Direction of media feed
Printable area
Black mark OD value:1.5 or more Carbon black ink
23
2
Printer Operation
Setting the Media
When Using Front Sensors
A Label width 7.62 (0.3) 118.00 (4.65) B Liner width 25.40 (1.0) 118.00 (4.65) C Left end of label 0 (0) 2.54 (0.10) D Gap between labels 2.54 (0.10) 812.80 (32.00) E Label length 6.35 (0.25) 812.80 (32.00)
F Label pitch 6.35 (0.25) 812.80 (32.00) G Liner thickness 0.06 (0.0025) 0.125 (0.0049) H Media thickness 0.06 (0.0025) 0.25 (0.01)
I Right end of notch 8.3 (0.32) 11 (0.43)
J Left end of notch 0 (0) 4.7 (0.19) K Notch length 2.54 (0.10) 17.80 (0.70)
L Right end of black mark 15.00 (0.59) — — M Left end of black mark 0 (0) 1.5 (0.06) N Black mark width 3.18 (0.125) 17.80 (0.70)
Menu Setting Table (p.43)
* Use a transparent sensor for label media gaps and media with black marks. * Use a transparent sensor for fan fold media. * If the label pitch is 1 inch or less, set the Small Media Adjustment menu to ON and
match it to the label that uses the value of the Small Media Length menu.
Minimum value mm (in) Maximum value mm (in)
Menu Setting Table (p.43)
When Using Adjustable Sensor
Minimum value mm (in) Maximum value mm (in) A Label width 25.24 (1.0) 118.00 (4.65) B Liner width 25.24 (1.0) 118.00 (4.65) C Left end of label 0 (0) 2.54 (0.10) D Gap between labels 2.54 (0.10) 812.80 (32.00) E Label length 12.70 (0.50) 812.80 (32.00)
F Label pitch 12.70 (0.50) 812.80 (32.00) G Liner thickness 0.05 (0.0025) 0.125 (0.0049) H Media thickness 0.05 (0.0025) 0.25 (0.01)
I Right end of notch 3.6 (0.14) 60.8 (2.39)
J Left end of notch 0 (0) 57.2 (2.25) K Notch length 2.54 (0.10) 17.80 (0.70)
L Right end of black mark 15.00 (0.59) 66.5 (2.62) M Left end of black mark 0 (0) 51.5 (2.02) N Black mark width 3.18 (0.125) 17.80 (0.70)
* Use a transparent sensor for label media gaps and media with black marks. * Use a transparent sensor for fan fold media. * If the label pitch is 1 inch or less, set the Small Media Adjustment menu to ON and
match it to the label that uses the value of the Small Media Length menu.
24
Loading...
+ 56 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
