CITIZEN CLE331XEBXXX Product Data Sheet
The contemporary high-resolution label
CL-E331
printer
Outstanding prints at 300 dpi
Stylish, fast and compact
The CL-E331‘s compact, modern,
functional design takes up very little desk
space, is easy to use and is also perfectly
at home in any location, from warehouses
to hospitals. It also has a fast print speed
of 6 inches-per-second, is quick to setup
and to load with media.
Well connected
The CL-E331 features on-board LAN,
USB and Serial interfaces. All industrystandard emulations are fully supported,
with the option of remote operation via a
web browser, using the Citizen
LinkServer™ management tool.
Label, Desktop
Applications
Manufacturing
Healthcare
Pharmacy
Retail
High quality printing in 300dpi
The CL-E331 the ideal choice for
applications ranging from small test tube
labels in healthcare to detailed rating
plates in manufacturing. It is also equally
suited to printing EAN barcodes and
asset labels in the retail sector.
Citizen Systems Europe GmbH, Elizabeth House, 56-60 London Road, Staines-Upon-Thames, TW18 4HF, United Kingdom
Prints at a resolution of 300 dpi for when
a clearer more detailed output is needed.
CITIZEN SYSTEMS EUROPE GMBH
CL-E331
Label, Desktop
Ethernet LAN, USB and Serial interfaces as standard
Specifications
Model CL-E331
Printing Technology Thermal Transfer + Direct Thermal
Resolution 300 dpi
Print Speed
(maximum)
Print Width
(maximum)
Media Width (min to
max)
Roll Size (max), Core
Size
Media Thickness (min
to max)
Main Interface Triple interface USB 2.0, RS-232 and 10/100 Ethernet
Mechanism Hi-Lift™ metal mechanism with wide opening head
6 inches per second (150 mm/s)
4 inches (104 mm)
1 to 4 inches (25 to 118 mm)
Inside diameter 5 inches (125 mm) Core size 1 inch (25mm)
63.5 to 190 ?m
Features & Benefits
Hi-Open™ case for vertical opening, no
increase in footprint and safe closing.
ENERGY STAR® compliant
Small footprint
Emulations
(Languages)
Size (W x D x H) and
Weight
Warranty
EMC and safety
standards
Citizen Systems Europe GmbH, Elizabeth House, 56-60 London Road, Staines-Upon-Thames, TW18 4HF, United Kingdom
Citizen Original Commands, Datamax® I-Class™ & DMX400™, Cross-Emulation™ automatic switching between Zebra® ZPL-II® and Datamax® I-Class®, DMX400,
Zebra® ZPL-II®, BASIC interpreter for data stream processing
178 x 266 x 173 mm, 2.6 Kg
2 years manufacturer's warranty or 100 Kms on printer. 6 months or 50 Kms in TT mode
or 30 Kms in DT mode on printhead
CE, TUV, UL, FCC, VCCI
The CL-E331 has a wide opening 90º HiLift™ case, and uses full size, 300m
ribbons with standard 1 inch cores.
