Casio CTK810, WK110 User Manual

USER’S GUIDE GUÍA DEL USUARIO
ES
CTK810/WK110ES1A
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THE UNIT IN THE U.S.A. (not applicable to other areas).
NOTICE
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Declaration of Conformity
Model Number: CTK-810/WK-110 Trade Name: CASIO COMPUTER CO., LTD. Responsible party: CASIO, INC. Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801 Telephone number: 973-361-5400 This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Important!
Please note the following important information before using this product.
• Before using the optional AD-5 Adaptor to power the unit, be sure to check the AC Adaptor for any damage first. Carefully check the power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is seriously damaged.
• Never attempt to recharge batteries.
• Do not use rechargeable batteries.
• Never mix old batteries with new ones.
• Use recommended batteries or equivalent types.
• Always make sure that positive (+) and negative (–) poles are facing correctly as indicated near the battery compartment.
• Replace batteries as soon as possible after any sign they are getting weak.
• Do not short-circuit the battery terminals.
• The product is not intended for children under 3 years.
• Use only CASIO AD-5 adaptor.
• The AC adaptor is not a toy.
• Be sure to disconnect the AC adaptor before cleaning the product.
This mark applies in EU countries only.
CASIO Europe GmbH Bornbarch 10, 22848 Norderstedt, Germany
Safety Precautions
Congratulations on your selection of the CASIO electronic musical instrument.
• Before using the instrument, be sure to carefully read through the instructions contained in this manual.
• Please keep all information for future reference.
Symbols
Various symbols are used in this user’s guide and on the product itself to ensure that the product is used safely and correctly, and to prevent injury to the user and other persons as well as damage to property. Those symbols along with their meanings are shown below.
DANGER
This symbol indicates information that, if ignored or applied incorrectly, creates the danger of death or serious personal injury.
WARNING
This indication stipulates matters that have the risk of causing death or serious injury if the product is operated incorrectly while ignoring this indication.
Symbol Examples
This triangle symbol ( ) means that the user should be careful. (The example at left indicates electrical shock caution.)
This circle with a line through it ( means that the indicated action must not be performed. Indications within or nearby this symbol are specifically prohibited. (The example at left indicates that disassembly is prohibited.)
The black dot ( indicated action must be performed. Indications within this symbol are actions that are specifically instructed to be performed. (The example at left indicates that the power plug must be unplugged from the electrical socket.)
)
) means that the
CAUTION
This indication stipulates matters that have the risk of causing injury as well as matters for which there is the likelihood of occurrence of physical damage only if the product is operated incorrectly while ignoring this indication.
E-1
Safety Precautions
DANGER
Alkaline Batteries
Perform the following steps immediately if fluid leaking from alkaline batteries ever gets into your eyes.
1. Do not rub your eyes! Rinse them with water.
2. Contact your physician immediately.
Leaving alkaline battery fluid in your eyes can lead to loss of sight.
WARNING
Smoke, Strange Odor, Overheating
Continued use of the product while it is emitting smoke, a strange odor, or heat creates the risk of fire and electric shock. Take the following steps immediately.
1. Turn off power.
2. If you are using the AC adaptor for power, unplug it from the wall outlet.
3. Contact your original retailer or an authorized CASIO Service Provider.
AC Adaptor
Misuse of the AC adaptor creates the risk of fire and electric shock. Always make sure you observe the following precautions.
• Be sure to use only the AC adaptor
that is specified for this product.
• Use only a power source whose
voltage is within the rating marked on the AC adaptor.
• Do not overload electrical outlets and
extension cords.
Misuse of the AC adaptor’s electric cord can damage or break it, creating the risk of fire and electric shock. Always make sure you observe the following precautions.
• Never place heavy objects on the cord
or subject it to heat.
• Never try to modify the cord or subject
it to excessive bending.
• Never twist or stretch the cord.
• Should the electric cord or plug
become damaged, contact your original retailer or authorized CASIO Service Provider.
Never touch the AC adaptor while your hands are wet. Doing so creates the risk of electric shock.
Use the AC adaptor where it will not be splashed with water. Water creates the risk of fire and electric shock.
Do not place a vase or any other container filled with liquid on top of the AC adaptor. Water creates the risk of fire and electric shock.
Batteries
Misuse of batteries can cause them to leak, resulting in damage to nearby objects, or to explode, creating the risk of fire and personal injury. Always make sure you observe the following precautions.
• Never try to take batteries apart or allow them to become shorted.
• Never expose batteries to heat or dispose of them by incineration.
• Never mix old batteries with new ones.
• Never mix batteries of different types.
• Do not charge the batteries.
• Make sure the positive (+) and negative (–) ends of the batteries are facing correctly.
Do not incinerate the product.
Never throw the product into fire. Doing so can cause it to explode, creating the risk of fire and personal injury.
Water and Foreign Matter
Water, other liquids, and foreign matter (such as pieces of metal) getting into the product create the risk of fire and electric shock. Take the following steps immediately.
1. Turn off power.
2. If you are using the AC adaptor for power, unplug it from the wall outlet.
3. Contact your original retailer or an authorized CASIO Service Provider.
Disassembly and Modification
Never try to take this product apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, or other personal injury. Leave all internal inspection, adjustment, and maintenance up to your original retailer or authorized CASIO Service Provider.
E-2
Safety Precautions
Dropping and Impact
Continued use of this product after it has been damaged by dropping or subjecting it to strong impact creates the risk of fire and electric shock. Take the following steps immediately.
1. Turn off power.
2. If you are using the AC adaptor for power, unplug it from the wall outlet.
3. Contact your original retailer or an authorized CASIO Service Provider.
Plastic Bags
Never place the plastic bag the product comes in over your head or in your mouth. Doing so creates the risk of suffocation. Particular care concerning this precaution is required where small children are present.
Keep off of the product and stand.*
Climbing onto the product or stand can cause it to tip over or become damaged. Particular care concerning this precaution is required where small children are present.
Location
Avoid locating the product on an unstable stand, on an uneven surface, or any other unstable location. An unstable location can cause the product to fall over, creating the risk of personal injury.
CAUTION
AC Adaptor
Misuse of the AC adaptor creates the risk of fire and electric shock. Always make sure you observe the following precautions.
• Do not locate the electric cord near a
stove or other sources of heat.
• Never pull on the cord when
unplugging from the electrical outlet. Always grasp the AC adaptor when unplugging.
Misuse of the AC adaptor creates the risk of fire and electric shock. Always make sure you observe the following precautions.
• Insert the AC adaptor into the wall
outlet as far as it will go.
• Unplug the AC adaptor from the wall
outlet during lightening storms or before leaving on a trip or other long­term absence.
• To keep dust from building up in the
area between the prongs of the power plug, unplug it from the power outlet and use a dry cloth or vacuum cleaner to remove dust at least once a year.
• Never use detergent to clean the power
cord, especially the plug and jack parts.
Relocating the Product
Before relocating the product, always unplug the AC adaptor from the wall outlet and disconnect all other cables and connecting cords. Leaving cords connected creates the risk of damage to the cords, fire, and electric shock.
Cleaning
Before cleaning the product, always unplug the AC adaptor from the wall outlet first. Leaving the AC adaptor plugged in creates the risk of damage to the AC adaptor, fire, and electric shock.
Batteries
Misuse of batteries can cause them to leak resulting in damage to nearby objects, or to explode, creating the risk of fire and personal injury. Always make sure you observe the following precautions.
• Use only batteries that are specified for use with this product.
• Remove batteries from the product if you do not plan to use it for a long time.
E-3
Safety Precautions
Connectors
Connect only the specified devices and equipment to the product’s connectors. Connection of a non-specified device or equipment creates the risk of fire and electric shock.
Location
Avoid the following locations for this product. Such locations create the risk of fire and electric shock.
• Areas subject to high humidity or large amounts of dust.
• In food preparation areas or other areas subject to oil smoke.
• Near air conditioning equipment, on a heated carpet, in areas exposed to direct sunlight, inside of a vehicle parked in the sun, or any other area that subjects the product to high temperatures.
Display Screen
• Never push on the display screen’s LCD panel or subject it to strong impact. Doing so can cause the LCD panel’s glass to crack, creating the risk of personal injury.
• Should the LCD panel ever crack or break, never touch the liquid inside of the panel. LCD panel liquid can cause skin irritation.
• Should LCD panel liquid ever get inside your mouth, immediately wash out your mouth with water and contact your physician.
• Should LCD panel liquid ever get into your eyes or onto your skin, rinse with clear water for at least 15 minutes, and then contact a physician.
Correct Stand* Assembly
An incorrectly assembled stand can tip over, causing the product to fall and creating the risk of personal injury. Make sure you assemble the stand correctly, following the assembly instructions that come with it. Make sure you mount the product on the stand correctly.
* Stand is available as an option.
IMPORTANT!
When using batteries, be sure to replace them or shift to one of the alternate power sources whenever you notice any of the following symptoms.
• Dim power supply indicator
• Instrument does not turn on.
• Dim, difficult to read display
• Abnormally low speaker/headphone volume
• Distortion of sound output
• Occasional interruption of sound when playing at high volumes
• Sudden power failure when playing at high volumes
• Dimming of the display when playing at high volume
• Continued sound output even after you release a key
• A totally different tone may sound
• Abnormal rhythm pattern and demo tune play
Company and product names used in this manual may be registered trademarks of others.
Sound Volume
Do not listen to music at very loud volumes for long periods. Particular care concerning this precaution is required when using headphones. High volume settings can damage your hearing.
Heavy Objects
Never place heavy object on top of the product. Doing so can make the product top heavy, causing the product to tip over or the object to fall from it, creating the risk of personal injury.
E-4
Main Features
515 tones
A wide selection of tones includes stereo piano and synthesized sounds, drum sets, and much more. Other features include digital effects that control the acoustical characteristic of tones.
PIANO SETTING button
The press of a button optimizes the keyboard setup for piano play.
3-Step Lesson System
• 3-Step Lesson System: Now you can learn the parts that make up the keyboard’s built-in tunes and SMF data you download over the Internet step-by-step. Guidance that appears on the monitor screen helps lead you down the path to music proficiency.
• Evaluation System: The keyboard can be configured to evaluate your 3-Step Lesson progress. You can even have the keyboard display your points, both part way through and at the end of a lesson.
100 built-in tunes
120 rhythms
A selection of rhythms cover rock, pops, jazz and just about any other musical style imaginable.
Auto Accompaniment
Simply play a chord and the corresponding rhythm, bass, and chord parts play along automatically. One Touch Presets instantly recalls the most suitable tone and tempo settings to match the rhythm you are using.
Registration Memory
Keyboard setups can be stored in memory for later recall and instant settings whenever you need them. Up to 32 setups (4 setups × 8 banks) can be stored in registration memory.
Recording and Play Back
With lesson recording you can record as you play along with built-in tunes for later playback. Performance recording lets you record your performances, including Auto Accompaniment, in real time.
Storing and Playing Back Tune Data You Transferred from Your Computer
You can connect your keyboard to a computer, use special CASIO conversion software to convert SMF data you purchase or create to CASIO format, and then transfer it to the keyboard.
E-5
Contents
Safety Precautions ................ E-1
Main Features ........................ E-5
General Guide........................ E-8
Attaching the Score Stand ..................... E-12
Quick Reference .................. E-13
To play the keyboard .............................. E-13
Power Supply ...................... E-15
Using batteries ....................................... E-15
Using the AC Adaptor ............................. E-16
Auto Power Off ....................................... E-17
Memory Contents ................................... E-17
Connections ........................ E-18
Phones/Output Terminal......................... E-18
Connecting to a Computer or Other
Equipment .............................................. E-18
Sustain/Assignable jack Terminal........... E-19
Accessories and Options ....................... E-19
Playing a Built-in Tune........ E-22
To play back a Song Bank tune ............. E-22
Adjusting the Tempo............................... E-23
To pause playback ................................. E-23
To fast reverse ....................................... E-23
To fast forward ....................................... E-23
Looping a Musical Phrase ...................... E-24
To change the melody tone .................... E-24
To play all tunes in succession ............... E-24
3-Step Lesson...................... E-25
Evaluation Mode .................................... E-26
Using the Lesson Functions and
Evaluation Mode .................................... E-26
Step 1 – Master the timing. .................... E-27
Step 2 – Master the notes. ..................... E-27
Step 3 – Play at normal speed. .............. E-28
Evaluating Your Keyboard Play .............. E-28
Voice Fingering Guide............................ E-29
Using the Metronome ............................. E-29
Basic Operations................. E-20
To play the keyboard .............................. E-20
Selecting a Tone..................................... E-20
Using Tone Effects ................................. E-21
PIANO SETTING Button ........................ E-21
E-6
Auto Accompaniment ......... E-30
Selecting a Rhythm ................................ E-30
Playing a Rhythm ................................... E-31
Adjusting the Tempo............................... E-31
Using Auto Accompaniment ................... E-31
Using an Intro Pattern ............................ E-35
Using a Fill-in Pattern ............................. E-35
Contents
Using a Rhythm Variation ....................... E-35
Using a Fill-in Pattern with a Variation
Rhythm ................................................... E-35
Synchro Starting Accompaniment with
Rhythm Play ........................................... E-35
Finishing with an Ending Pattern ........... E-36
Using One-touch Preset ......................... E-36
Registration Memory .......... E-37
Registration Memory Features ............... E-37
To Save a Setup in Registration
Memory .................................................. E-38
To Recall a Setup from Registration
Memory .................................................. E-38
Recording and Play Back ... E-39
Parts and Tracks .................................... E-39
Transposing the Keyboard ..................... E-47
Adjusting Accompaniment and
Song Bank Volume ................................ E-47
Using Touch Response .......................... E-48
Tuning the Keyboard .............................. E-48
Connection to a
Computer ............................. E-49
Connecting to a Computer ..................... E-49
Expanding the Selections in the
Song Bank Tunes................................... E-50
Using the SMF Data on the Bundled
CD-ROM ................................................ E-51
General MIDI Tone ................................. E-51
Changing the Settings ............................ E-51
Troubleshooting .................. E-54
Recording Play Along with a
Built-in Tune ........................................... E-40
Playing Back a Lesson Recording ......... E-41
Recording a Performance ...................... E-41
Playing Back a Performance
Recording ............................................... E-43
Overdubbing a Performance
Recording ............................................... E-44
Deleting a Specific Part/Track ................ E-44
Keyboard Settings .............. E-45
Using Layer ............................................ E-45
Using Split .............................................. E-45
Using Layer and Split Together .............. E-46
Specifications ...................... E-56
Operating Precautions........ E-57
Appendix ................................ A-1
Tone List ................................................... A-1
Drum Assignment List .............................. A-5
FINGERED Chord Chart .......................... A-7
Rhythm List .............................................. A-8
Song List .................................................. A-9
MIDI messages that can be sent and received using the USB port
E-7
CTK-810
General Guide
2
1
8 C
35476 *2
D *1F
9 :A B
DGE H
E-8
IJ
P
ONMLK
QR
VWXY
TSZ]\[
U
1
Power indicator
2
POWER button
3
MODE switch
4
RECORDER button
5
TRANSPOSE/SETTING button
6
REVERB/CHORUS button
7
ONE TOUCH PRESET button
8
VOLUME knob
9
SONG BANK button
0
RHYTHM button
A
TONE button
B
DATA ACCESS lamp
C
PIANO SETTING button
D
Speaker
E
TONE list
F
Display
G
RHYTHM list
H
SONG BANK list
I
CHORD root names
J
Percussion instrument list
General Guide
RHYTHM/SONG CONTROLLER
K
INTRO button, REPEAT button
L
NORMAL/FILL-IN button, REW button
M
VARIATION/FILL-IN button, FF button
N
SYNCHRO/ENDING button, PAUSE button
O
START/STOP button, PLAY/STOP button
P
Rhythm controller indicator
Q
Song controller indicator
R
TEMPO buttons
S
BANK button
T
REGISTRATION buttons
U
STORE button
3-STEP LESSON SYSTEM
V
LEFT/TRACK 1 button
W
RIGHT/TRACK 2 button
X
SPEAK button
Y
METRONOME button
Z
STEP 1 to 3 button
[
SCORING button
\
SPLIT button
]
LAYER button
E-9
General Guide
WK-110
3
21
B BC D F*1 E
5476 98 : *2A
GH
E-10
I
O
J K L M N P
S TR Y ]\Z
Q
U V W X [
1
POWER button
2
Power indicator
3
MODE switch
4
RECORDER button
5
TRANSPOSE/SETTING button
6
REVERB/CHORUS button
7
ONE TOUCH PRESET button
8
SONG BANK button
9
RHYTHM button
0
TONE button
A
PIANO SETTING button
B
Speaker
C
RHYTHM list
D
SONG BANK list
E
Display
F
TONE list
G
CHORD root names
H
Percussion instrument list
I
VOLUME knob
General Guide
RHYTHM/SONG CONTROLLER
J
INTRO button, REPEAT button
K
NORMAL/FILL-IN button, REW button
L
VARIATION/FILL-IN button, FF button
M
SYNCHRO/ENDING button, PAUSE button
N
START/STOP button, PLAY/STOP button
O
Rhythm controller indicator
P
Song controller indicator
Q
TEMPO buttons
R
BANK button
S
REGISTRATION buttons
T
STORE button
3-STEP LESSON SYSTEM
U
LEFT/TRACK 1 button
V
RIGHT/TRACK 2 button
W
SPEAK button
X
METRONOME button
Y
STEP 1 to 3 button
Z
SCORING button
[
DATA ACCESS lamp
\
SPLIT button
]
LAYER button
E-11
General Guide
NOTE
Illustrations in this Users Guide shows the WK-110.
*1 Attaching the Score Stand
Insert the score stand into the slot at the top of the keyboard as shown in the illustration.
*2
Rear Panel
b c d e
^
Number buttons
a
[+]/[–]
buttons
For input of numbers to change a displayed number or setting.
Negative values cannot be input using the number buttons. Use [+] (increase) and [–] (decrease) instead.
b
USB port
c
SUSTAIN/ASSIGNABLE JACK terminal
d
PHONES/OUTPUT terminal
e
DC 9V jack
Controller Indicators
PP
P
Rhythm controller indicator (CTK-810:
Pressing the RHYTHM button to enter the Rhythm Mode causes the Rhythm controller indicator to light. This indicates that buttons K through O (WK-110: J through N) are currently functioning as rhythm control buttons.
PP
, WK-110:
OO
O
OO
)
QQ
Q
Song controller indicator (CTK-810:
Pressing the SONG BANK button, or pressing the RHYTHM and TONE buttons at the same time to start demo tune play causes the Song controller indicator to light. This indicates that buttons K through O (WK-110: J through N) are currently functioning as playback control buttons.
QQ
, WK-110:
PP
P
PP
)
NOTE
Display examples shown in this Users Guide are intended for illustrative purposes only. The actual text and values that appear on the display may differ from the examples shown in this Users Guide.
Viewing a liquid crystal display screen from an angle can change the appearance of display contrast. The display contrast of this keyboard is set to allow easy viewing for a person seated on a chair in front of the keyboard. Note that display contrast is fixed, and cannot be adjusted.
E-12
Quick Reference
MODE
Power indicator
POWER
PLAY/STOP
This section provides a quick overview of keyboard operation using steps one and two of the 3-step lesson feature. With the 3-step lesson feature, the on-screen keyboard guide keys light to show the next note of the tune.
To play the keyboard
1
Press the POWER button to turn on power.
This causes the power indicator to light.
Lit
SONG BANK
Number buttons
STEP 2
STEP 1
4
Find the tune you want to play in the SONG BANK List, and then use the number buttons to input its three-digit number.
See page A-9 for the SONG BANK List.
Example: To select “047 ALOHA OE, input 0, 4 and
then 7.
Aloha Oe
5
Press the STEP 1 button or STEP 2 button.
The keyboard sounds a count beat and waits for you to play something on the keyboard. The keys that you need to press first flash on the display.
2
Set the MODE switch to NORMAL.
3
Press the SONG BANK button.
Indicator appears
6
Play the melody along with the selected tune’s accompaniment.
Play in accordance with the keyboard keys, fingerings and notes that appear on the display.
Aloha Oe
FingeringKeyboard key used
Note pitch
E-13
Quick Reference
If you selected lesson Step 1
Play the notes on the keyboard.
Accompaniment (left-hand part) plays in time with
the notes.
With Step 1, the correct melody note is played no matter which keyboard key you press.
If you selected lesson Step 2
Play the correct notes on the keyboard.
While an on-screen keyboard guide key is lit, press
the corresponding key on the actual keyboard. In the case of a two-hand tune, the keyboard guide indication turns off when you press a keyboard key, and the on-screen keyboard guide key lights for the next note to be played.
Accompaniment (left-hand part) plays in time with the notes, as long as you press the correct keyboard keys.
7
To stop play at any time, press the PLAY/STOP button.
E-14
Power Supply
This keyboard can be powered by current from a standard household wall outlet (using the specified AC adaptor) or by batteries. Always make sure you turn the keyboard off whenever you are not using it.
Using batteries
Always make sure you turn off the keyboard before loading or replacing batteries.
NOTE
The keyboard may not function correctly if you load or replace batteries with power turned on. If this happens, turning the keyboard off and then back on again should return functions back to normal.
To load batteries
<CTK-810>
1
Remove the battery compartment cover.
<WK-110>
1
Remove the battery compartment cover.
2
Load six D-size batteries into the battery compartment.
Make sure that the positive (+) and negative (–) ends are facing correctly.
3
Insert the tabs on the battery compartment cover into the holes provided and close the cover.
tab
2
Load 6 AA-size batteries into the battery compartment.
Make sure that the positive (+) and negative (–) ends are facing correctly.
3
Insert the tabs on the battery compartment cover into the holes provided and close the cover.
tab
E-15
Power Supply
Important Battery Information
The following shows the approximate battery life.
Alkaline batteries .......................... <CTK-810> 2.5 hours
Manganese batteries ..................... <WK-110> 6 hours
The above value is standard battery life at normal temperature, with the keyboard volume at medium setting. Temperature extremes or playing at very loud volume settings can shorten battery life.
WARNING
Misuse of batteries can cause them to leak, resulting in damage to nearby objects, or to explode, creating the risk of fire and personal injury. Always make sure you observe the following precautions.
Never try to take batteries apart or allow them to become shorted.
Never expose batteries to heat or dispose of them by incineration.
Never mix old batteries with new ones.
Never mix batteries of different types.
Do not charge the batteries.
Make sure the positive (+) and negative () ends of
the batteries are facing correctly.
CAUTION
Misuse of batteries can cause them to leak resulting in damage to nearby objects, or to explode, creating the risk of fire and personal injury. Always make sure you observe the following precautions.
Use only batteries that are specified for use with this product.
Remove batteries from the product if you do not plan to use it for a long time.
Using the AC Adaptor
Make sure that you use only the AC adaptor specified for this keyboard.
Specified AC Adaptor: AD-5
[Rear Panel]
DC 9V jack
Note the following important precautions to avoid damage to the power cord.
During Use
Never pull on the cord with excessive force.
Never repeatedly pull on the cord.
Never twist the cord at the base of the plug or connector.
The power cord should not be stretched tight while it is
in use.
During Movement
Before moving the keyboard, be sure to unplug the AC adaptor from the power outlet.
During Storage
Loop and bundle the power cord, but never wind it around the AC adaptor.
AC adaptor AD-5
AC outlet
NOTE
Do not use an oxyride battery or any other type of nickel­based primary battery with this product. Incompatibility between such batteries and product specifications can result in shorter battery life and product malfunction.
E-16
IMPORTANT!
Make sure that the keyboard is turned off before connecting or disconnecting the AC adaptor.
Using the AC adaptor for a long time can cause it to become warm to the touch. This is normal and does not indicate malfunction.
Auto Power Off
When you are using battery power, keyboard power turns off automatically whenever you leave it on without performing any operation for about 6 minutes. When this happens, press the POWER button to turn power back on.
NOTE
Auto Power Off is disabled (it does not function) when you are using the AC adaptor to power the keyboard.
To disable Auto Power Off
Hold down the TONE button while turning on the keyboard to disable Auto Power Off.
NOTE
When this function is turned off, the keyboard does not turn off automatically no matter how long it is left with no operation being performed.
Auto Power Off is enabled again when you manually turn off power and then turn it back on again.
Power Supply
Memory Contents
Registration memory contents, recorder memory contents, and song bank data you transfer from a computer to keyboard memory are all retained when the keyboard is turned off, either by pressing the power button or by Auto Power Off.
Electrical Power
The memory contents described above are retained as long as the keyboard is being supplied with electrical power. Unplugging the AC adaptor when batteries are not loaded or when loaded batteries are dead cuts off the keyboard’s electrical power supply. This clears all data stored in memory.
Power Requirements
Note the following precautions whenever you want to ensure that current memory contents are not lost.
Make sure the keyboard is being supplied power through the AC adaptor before replacing its batteries.
Before unplugging the AC adaptor, make sure that fresh batteries are loaded in the keyboard.
Make sure that keyboard power is turned off before replacing batteries or unplugging the AC adaptor.
E-17
Connections
Phones/Output Terminal
PREPARATION
Before connecting headphones or other external equipment, be sure to first turn down the volume settings of the keyboard and the connected equipment. You can then adjust volume to the desired level after connections are complete.
[Rear Panel]
PHONES/OUTPUT terminal
Stereo standard plug
2
AUX IN or similar terminal
3
Keyboard amp, guitar amp, etc.
Connecting Headphones (Figure 1)
Connecting headphones cuts off output from the keyboard’s built-in speakers, so you can play even late at night without disturbing anyone.
Audio Equipment (Figure 2)
Connect the keyboard to an audio equipment using a commercially available connecting cord with a standard plug on one end and two PIN plugs on the other end. Note that the standard plug you connect to the keyboard must be a stereo plug, otherwise you will be able to output only one of stereo channels. In this configuration, you normally set the input selector of the audio equipment to the terminal (usually marked AUX IN or something similar) where the cord from the keyboard is connected. See the user documentation that comes with your audio equipment for full details.
Audio connection
White
RIGHT
LEFT
of audio amplifier
Red
1
PIN plug
Musical Instrument Amplifier (Figure 3)
Use a commercially available connecting cord to connect the keyboard to a musical instrument amplifier.
NOTE
Be sure to use a connecting cord that has a stereo standard plug on the end you connect to the keyboard, and a connector that provides dual channel (left and right) input to the amplifier to which you are connecting. The wrong type of connector at either end can cause one of the stereo channels to be lost.
When connected to a musical instrument amplifier, set the volume of the keyboard to a relatively low level and make output volume adjustments using the amplifiers controls.
Connection Example
To keyboards PHONES/OUTPUT terminal
Stereo standard plug
PIN plug (red)
PIN plug (white)
PIN jack
Standard plug
INPUT 1
INPUT 2
Keyboard or guitar amp
Connecting to a Computer or Other Equipment
You can also connect the keyboard to a computer. See Connecting to a Computer on page E-49 for details.
E-18
Sustain/Assignable jack Terminal
You can connect an optional sustain pedal (SP-3 or SP-20) to the SUSTAIN/ASSIGNABLE JACK terminal to enable the capabilities described below.
For details on how to select the pedal function you want, see SUSTAIN/ASSIGNABLE JACK (Default: SUS) on page E-53.
SUSTAIN/ASSIGNABLE JACK Terminal
SP-20
Sustain Pedal
With piano tones, depressing the pedal causes notes to linger, much like a pianos damper pedal.
With organ tones, depressing the pedal causes notes to continue to sound until the pedal is released.
Connections
Sostenuto Pedal
As with the sustain pedal function described above, depressing the sostenuto pedal causes notes to be sustained.
This difference between a sostenuto pedal and sustain pedal is the timing. With a sostenuto pedal, you press the keys and then depress the pedal before you release the keys.
Only the notes that are sounding when the pedal is depressed are sustained.
Soft Pedal
Depressing the pedal softens the sound of the notes being played.
Rhythm Start/Stop Pedal
In this case, the pedal performs the same functions as the START/STOP button.
Accessories and Options
Use only the accessories and options specified for this keyboard. Use of non-authorized items creates the danger of fire, electrical shock, and personal injury.
E-19
Basic Operations
REVERB/CHORUS
MODE
POWER
VOLUME
This section provides information on performing basic keyboard operations.
To play the keyboard
1
Press the POWER button to turn the keyboard on.
2
Set the MODE switch to NORMAL.
3
Use the VOLUME knob to set the volume to a relatively low level.
4
Play something on the keyboard.
Selecting a Tone
This keyboard comes with 515 built-in tones. Use the following procedure to select the tone you want.
TONE
3
Use the number buttons to input the three-digit tone number of the tone you want to select.
Example: To select “111 ACOUSTIC BASS, input 1, 1
and then 1.
PIANO SETTING
Number buttons
[+] / [–]
Acous . Bs
NOTE
Always input all three digits for the tone number, including leading zeros (if any). If you input one or two digits and stop, the display will automatically clear your input after a few seconds.
You can also increment the displayed tone number by pressing [+] and decrement it by pressing [–].
When one of the drum sets is selected (tone numbers 501 through 515), each keyboard key is assigned a different percussion sound. See page A-5 for details.
To select a tone
1
Find the tone you want to use in the TONE List and note its tone number.
Not all of the available tones are shown on the tone list printed on the keyboard console. For a complete list, see the Tone List on page A-1.
2
Press the TONE button.
Indicator
appears
E-20
Polyphony
The term polyphony refers to the maximum number of notes you can play at the same time. The keyboard has 32-note polyphony, which includes the notes you play as well as the rhythms and auto-accompaniment patterns that are played by the keyboard. This means that when a rhythm or auto­accompaniment pattern is being played by the keyboard, the number of notes (polyphony) available for keyboard play is reduced. Also note that some of the tones offer only 16-note polyphony.
When rhythm or auto accompaniment is playing, the number of sounds simultaneously played is reduced.
Basic Operations
Using Tone Effects
Reverb: Makes your notes resonate Chorus: Adds more breadth to your notes
1
Press the REVERB/CHORUS button to cycle through the effect settings as shown below.
You can find out the current effect setting by looking at the REVERB and CHORUS indicators.
Reverb on
Chorus on
Both on
Both off
2
After turning on the effect you want, use the number buttons or the [+]/[–] buttons to select the effect type you want.
Note that you need to select an effect type with the number buttons or the [+]/[–] buttons within a few seconds after turning on an effect. If you dont, the display will exit the setting screen.
Effect List
Reverb 1: Room 1
2: Room 2 3: Hall 1 4: Hall 2
Chorus 1: Chorus 1
2: Chorus 2 3: Chorus 3 4: Chorus 4
PIANO SETTING Button
Pressing this button changes the setup of the keyboard to optimize it for piano play.
Settings
Tone Number: 001 Rhythm Number: 101 Layer: Off Split: Off Reverb: On (Type 3) Chorus: Off Transpose: 00 Touch Response:
Off: Returns to initial default
On: No change Assignable Jack: SUS Local Control: On
To optimize keyboard settings for piano play
1
Set the MODE switch to NORMAL.
2
Press the PIANO SETTING button.
3
Now try playing something on the keyboard.
The notes you play will sound with a piano tone.
If you want to play with rhythm accompaniment,
press the START/STOP button. This causes a rhythm that is optimized for piano will start to play.
To stop rhythm play, press the START/STOP button again.
NOTE
Pressing the PIANO SETTING button while a rhythm is playing stops rhythm play and then changes the keyboard setup.
The setup of the keyboard does not change if you press the PIANO SETTING button when any one of the following exists.
During real-time recording of the Song Memory
During demo tune play
E-21
Playing a Built-in Tune
TEMPO
REPEAT
REW
FF PAUSE SONG BANK
Your keyboard comes with a total of built-in 100 tunes. You can play back built-in tunes for your own listening pleasure, or you can use them for practice. Built-in tunes are divided between the two groups described below.
Tune Numbers
Auto-accompaniment Tunes
Two-hand tune
In addition to the built-in tunes, you can also play back the tunes you download over the Internet (page E-50).
<CTK-810>001, 004 through 050 <WK-110> 003 through 050
<CTK-810>002, 003, and 051 through 100 <WK-110> 001, 002, and 051 through 100
PLAY/STOP
To play back a Song Bank tune
PREPARATION
Adjust the main volume (page E-20).
RHYTHM
Left-hand Part
Auto-accompaniment (percussion, bass, chords)
Left-hand notes
NOTE
Tune Number 001 is the initial default Song Bank tune setting whenever you turn on keyboard power.
You can also increment the displayed tune number by pressing [+] and decrement is by pressing [–].
TONE
Number buttons
[+] / [–]
Right-hand Part
Melody
Right-hand notes
1
Find the tune you want to play in the SONG BANK List, and note its number.
See page A-9 for the SONG BANK List.
2
Press the SONG BANK button to enter the Song Bank Mode.
Indicator appears
3
Use the number buttons to input the tunes three­digit number.
Example: To select 047 ALOHA OE, input 0, 4 and
then 7.
Aloha Oe
Song number Song name
E-22
4
Press the PLAY/STOP button to start play of the tune.
Staff display
Al oha Oe
Chord name
5
Press the PLAY/STOP button to stop playback of the Song Bank tune.
The tune you select continues to play until you stop it.
Keyboard keys used
Fingering
Playing a Built-in Tune
Adjusting the Tempo
Each tune has a preset default tempo (beats per minute) that is set automatically whenever you select a tune. While the tune is playing, you can change the tempo setting to a value in the range of 30 to 255.
To set the tempo
1
Use the TEMPO buttons to set the tempo.
: Increases the tempo value. : Decreases the tempo value.
Flash
Tempo value
NOTE
While the tempo value is flashing, you can also use the number buttons or [+] and [–] to input a three-digit value. Note that you must input leading zeros, so 90 is input as 090.
Pressing both the and TEMPO buttons at the same time automatically returns the currently selected rhythm to its default tempo.
To pause playback
1
Press the PAUSE button while a tune is playing to pause it.
To fast reverse
1
While a tune is playing or paused, hold down the REW button to skip in a reverse direction at high speed.
The fast reverse operation skips back one measure at a time.
The measure and beat numbers on the display change while the fast reverse operation is being performed.
Beat numberMeasure number
2
Releasing the REW button starts song playback from the measure whose number is shown on the display.
NOTE
Fast reverse does not work while tune play is stopped.
To fast forward
1
While a tune is playing or paused, hold down the FF button to skip forward at high speed.
The fast forward operation skips forward one measure at a time.
The measure and beat numbers on the display change while the fast forward operation is being performed.
2
Pressing the PAUSE button again resumes play from the point where it was paused.
Beat numberMeasure number
2
Releasing the FF button starts song playback from the measure whose number is shown on the display.
NOTE
Fast forward does not work while tune play is stopped.
E-23
Playing a Built-in Tune
Looping a Musical Phrase
You can select one or more measures and loop them, which means that they play again and again until you stop playback.
1
While the tune is playing, press the REPEAT button while the measure you want to start from is playing.
Flash
2
When playback is within the measure you want to specify as the end of the loop, press the REPEAT button again.
Lit
To cancel repeat play of a loop, press the REPEAT button again so the repeat indicator is not displayed.
To play all tunes in succession
1
Press the RHYTHM button and TONE button at the same time.
Playback starts from Song Bank tune number 001.
2
To stop tune play, press the PLAY/STOP button.
NOTE
While a tune is playing, you can use the number buttons or [+] and [–] to change to another tune.
You can play along with the tunes on the keyboard.
To change the melody tone
1
Press the TONE button.
Indicator
appears
2
Find the tone you want in the TONE List, and then use the number buttons to input its three-digit number.
Example: To select “131 VIOLIN, input 1, then 3, then 1.
You can select any one of the keyboard’s built-in tones.
Viol in
NOTE
You can also use the [+] and [–] buttons to change the melody tones.
Specifying the tune number for the same tune that is currently selected returns the melody tone to the default setting for that tune.
E-24
3-Step Lesson
With the 3-Step Lesson System, you can practice built-in tunes and SMF data you download over the Internet, and even plot your progress according to the evaluation points the keyboard awards you.
* See “Expanding the Selections in the Song Bank Tunes on
page E-50 for information about the SMF data you download over the Internet.
Lesson Progress
Step 1 Step 2 Step 3 Evaluation
3-Step Lesson
The 3-step lesson feature takes you through the three distinct steps described below to help you learn to play tunes on the keyboard.
Step 1 – Master the timing.
Step 2 – Master the notes.
Step 3 – Play at normal speed.
Lesson Parts
3-Step Lesson lets you practice the right-hand part, left-hand part, or the parts for both hands.
Display Contents During 3-step Lesson Play
Whenever you select an Auto Accompaniment tune for 3­step lesson play, the on-screen keyboard guide and staff notation shows the note you should play and its length. The on-screen keyboard guide also shows the notes you play on the keyboard. The following describes the information that appears on the display.
Next Note
An on-screen keyboard guide key flashes to indicate the next note to be played, while a number appears on the display near the finger you should use to play the next note.
Series of Same Pitch Notes
The on-screen keyboard guide key turns off momentarily between the notes, and lights again for each successive note. The staff notation and fingerings also turn off and back on again.
Example: When play requires pressing keys with fingers
Next note
Current note
On-screen keyboard guide
3, 2, and then 1
1st Note 2nd Note 3rd Note
Flash
Lit
Flash
Lit
Flash
Lit
NOTE
Note length is not indicated when you are using two­hand tunes with 3-step lesson Steps 1 and 2. As soon as you press a key that is lit on the on-screen keyboard guide, it goes out and the next key you need to press starts to flash.
Note length is indicated by the on-screen keyboard guide when you use two-hand tunes with Step 3. In this case, the next key to be pressed does not flash when you press a lit key.
During Step 3, the next finger number does not appear on the display. Only the current finger number is shown.
Note Pitch
The key you should press lights on the on-screen keyboard guide, while the actual pitch of the note appears in the displays staff notation area. The fingers you should use to play the notes are also shown on the display.
Note Length
The key stays lit on the on-screen keyboard guide for as long as the note should be sustained. The staff notation and fingerings also remain on the display for the length of the note.
3-step Lesson Tempo Setting
Use the procedure under Adjusting the Tempo on page E-23 to adjust the tempo for 3-step lesson play.
E-25
3-Step Lesson
Evaluation Mode
The keyboard can be configured to evaluate your 3-Step Lesson progress. A perfect score is 100. You can even have the piano display your points, both part way through and at the end of a lesson.
Evaluation Mode Display
Level Indicator (9 Levels): This indicator shows the evaluation of your current performance at a glance. The more segments that appear, the higher your points.
Example: 50 points
Timing Indicator: In the Evaluation Mode, the configuration
of the star changes with each note to let you know how your timing is. The more stars, the better your timing.
Using Tone Guide
When the keyboard senses that your timing is off, it will let you know by changing the notes you play to a tone that is different from the one you currently have selected.
Evaluation Results
After you finish playing, the keyboard calculates an evaluation of your total performance, from beginning to end, and displays your total score on the monitor screen.
Evaluation Rank Display Messages
Display Message
Bravo! <High>Great!” “Not bad!” “Again! <Low>
**** : indicates that the Evaluation Mode was exited
before an evaluation result could be obtained.
Evaluation Ranges
Using the Lesson Functions and Evaluation Mode
Perform the following steps to master your favorite tunes.
E-26
3-Step Lesson
TEMPO
PLAY/STOP
Step 1 – Master the timing.
1
Select the tune you want to use.
2
Press the RIGHT/TRACK 2 button or the LEFT/ TRACK 1 button to specify the part you want to practice.
Indicator appears on the display whose part is selected for practice.
LEFT/TRACK 1
STEP 1
4
5
RIGHT/TRACK 2
SPEAK
Number buttons
[+] / [–]
METRONOME
SCORING
STEP 2
Press any keyboard keys to play the notes.
The key for the next note to be played flashes on the on-screen keyboard guide and the keyboard waits for you to play it. When you press any key to play the note, the on-screen key remains lit as the note plays.
Accompaniment (left-hand part) waits until you press any key to play a note.
If you accidentally press more than one key in succession, accompaniment is played for the corresponding number of notes.
Pressing more than one key at the same time counts as a single note. Pressing a key while another key is held down is counted as two notes.
To stop play at any time, press the STEP 1 or PLAY/ STOP button.
STEP 3
Indicator appears
If you want to practice both hands, press both buttons at the same time.
3
Press the STEP 1 button to start Step 1 play.
Indicator appearsNote pitch
Al oha Oe
Keyboard keys used Fingering
After a count sounds, they keyboard stands by and waits for you to play the first note of the tune.
Voice fingering guide will use a simulated human voice to call out fingering numbers during one-hand part practice. See Voice Fingering Guide on page E-29 for details.
Step 2 – Master the notes.
1
Select the tune you want to use.
2
Press the RIGHT/TRACK 2 button or the LEFT/ TRACK 1 button to specify the part you want to practice.
Indicator appears on the display whose part is selected for practice.
If you want to practice both hands, press both buttons at the same time.
E-27
3-Step Lesson
3
Press the STEP 2 button to start Step 2 play.
Indicator appears
3
Press the STEP 3 button to start Step 3 play.
Indicator appears
Aloha Oe
Keyboard keys used Fingering
After a count sounds, the keyboard stands by and waits for you to play the first note of the tune.
Voice fingering guide will use a simulated human voice to call out fingering numbers during one-hand part practice. See Voice Fingering Guide on page E-29 for details.
4
Play the notes as indicated by the on-screen keyboard guide.
The key for the next note to be played flashes on the on-screen keyboard guide and the keyboard waits for you to play it. When you press any key to play the note, the on-screen key remains lit as the note plays.
If multiple keys light on the on-screen keyboard guide when you are using a two-hand tune, it means that you must press all of the keys that are lit.
5
To stop play at any time, press the STEP 2 or PLAY/ STOP button.
Al oha Oe
Keyboard keys used Fingering
Accompaniment (left hand part) starts to play at normal speed.
4
Play the notes as indicated by the on-screen keyboard guide.
5
To stop play at any time, press the STEP 3 or PLAY/ STOP button.
Evaluating Your Keyboard Play
1
Press the SCORING button.
This causes the SCORING indicator to appear on the display.
Step 3 – Play at normal speed.
1
Select the tune you want to play.
2
Press the RIGHT/TRACK 2 button or the LEFT/ TRACK 1 button to specify the part you want to practice.
Indicator appears on the display whose part is selected for practice.
If you want to practice both hands, press both buttons at the same time.
E-28
Indicator appears
A count beat sounds and then evaluation mode starts.
2
Play in accordance with the guidance on the monitor screen.
To stop evaluation, press the PLAY/STOP button. This displays only the points accumulated up to that point.
3
After you finished playing, your evaluation result appears on the display.
For information about evaluation ranks, seeEvaluation Results on page E-26.
Pressing the SONG BANK button returns to the tune
selection screen.
Bravo!
Voice Fingering Guide
Voice fingering guide uses a simulated human voice to call out fingering numbers during Step 1 and Step 2 one-hand part practice. If you need to press a key with your thumb, for example, voice fingering guide says, One! In the case of a chord to be played with your thumb, middle and little finger, voice fingering guide says, One, three, five! Voice Fingering Guide calls out fingerings only when you do not press the proper key when you should.
Voice Fingering Guide
One : Thumb Two : Forefinger Three : Middle finger Four : Ring finger Five : Little finger
To turn voice fingering guide on or off
Press the SPEAK button to toggle voice fingering guide on (voice fingering guide indicator displayed) and off (indicator not displayed).
3-Step Lesson
2
Use the number buttons or [+] and [–] to change the number of beats per measure.
You can specify 0, or a value from 2 to 6 as the number of beats per measure.
Bea t
NOTE
The bell (indicating the first beat of a measure) does not sound while 0 beat per measure is specified. All beats are indicated by a click sound. This setting lets you practice with a steady beat, without worrying about how many beats there are in each measure.
3
Use the TEMPO buttons to set the tempo.
Press to increase the tempo (make if faster) or to decrease it (make it slower).
Flash
Indicator appears
NOTE
Note that Voice Fingering is disabled in the Evaluation Mode.
Exiting the Evaluation Mode automatically restores the Voice Fingering setting that was in effect when you entered the Evaluation Mode.
Using the Metronome
The metronome feature of this keyboard produces a bell sound for the first beat of each measure, followed by click sounds for each successive beat of the measure. It is the perfect tool for practicing tunes without accompaniment (rhythm).
To start the metronome
1
Press the METRONOME button to start sounding the metronome.
This causes Beat to appear on the display. Perform step 2 within five seconds after Beat appears.
Tempo value
NOTE
While the tempo value is flashing, you can also use the number buttons or [+] and [–] to input a three-digit value. Note that you must input leading zeros, so 90 is input as 090.
Pressing both the and TEMPO buttons at the same time automatically returns the currently selected rhythm or tune to its default tempo.
4
To turn off the metronome, press the METRONOME button.
NOTE
The metronome is disabled whenever you are using Step 1 or Step 2 of the 3-step lesson.
E-29
Auto Accompaniment
ONE TOUCH PRESET
MODE
INTRO
NORMAL/FILL-IN
VARIATION/FILL-IN
This keyboard automatically plays bass and chord parts in accordance with the chords you finger. The bass and chord parts are played using sounds and tones that are automatically selected to select the rhythm you are using. All of this means that you get full, realistic accompaniments for the melody notes you play with your right hand, creating the mood of an one-person ensemble.
START/STOP
SYNCHRO/ENDING
TEMPO
RHYTHM
Number buttons
[+] / [–]
Selecting a Rhythm
This keyboard provides you with 120 exciting rhythms that you can select using the following procedure.
To select a rhythm
1
Find the rhythm you want to use in the RHYTHM List and note its rhythm number.
Not all of the available rhythms are shown on the rhythm list printed on the keyboard console. For a complete list, see the Rhythm List on page A-8.
2
Press the RHYTHM button to enter the Rhythm Mode.
Indicator
appears
3
Use the number buttons to input the three digit rhythm number for the rhythm you want to select.
Example: To select “095 HAWAIIAN, input 0, 9 and
then 5.
Hawaiian
NOTE
You can also increment the displayed rhythm number by pressing [+] and decrement it by pressing [–].
Some rhythms (No. 110, 112 to 120) consist of chord accompaniments only, without any drums or other percussion instruments. Such rhythms do not sound unless CASIO CHORD, FINGERED, or FULL RANGE CHORD is selected as the accompaniment mode.
E-30
Auto Accompaniment
Playing a Rhythm
Use the following procedure to start and stop rhythm play.
To play a rhythm
1
Set the MODE switch to NORMAL.
2
Press the START/STOP button to start play of the currently selected rhythm.
3
To stop rhythm play, press the START/STOP button again.
NOTE
All of the keyboard keys are melody keys while the MODE switch is set to NORMAL.
Adjusting the Tempo
The tempo (beats per minute) can be set to a value in the range of 30 to 255. The tempo value you set is use for Song Bank, 3-step lesson, and Auto Accompaniment chord play, as well as playback from the recorder and metronome operation.
Using Auto Accompaniment
The following procedure describes how to use the keyboard’s Auto Accompaniment feature. Before starting, you should first select the rhythm you want to use and set the tempo of the rhythm to the value you want.
To use Auto Accompaniment
1
Set the MODE switch to CASIO CHORD, FINGERED, or FULL RANGE CHORD.
2
Press the START/STOP button to start play of the currently selected rhythm.
3
Play a chord.
The actual procedure you should use to play a chord depends on the current MODE switch position. Refer to the following pages for details on chord play.
CASIO CHORD .......................... Page E-32
FINGERED ................................... Page E-33
FULL RANGE CHORD ............. Page E-34
Hawaiian
To set the tempo
1
Use the TEMPO buttons to set the tempo.
: Increase the tempo value. : Decreases the tempo value.
Metronome
Beat number
NOTE
While the tempo value is flashing, you can also use the number buttons or [+] and [–] to input a three-digit value. Note that you must input leading zeros, so 90 is input as 090.
Pressing both the and TEMPO buttons at the same time automatically returns the currently selected rhythm to its default tempo.
Flash
Tempo value
(The chord form that appears here may show notes that differ from those actually pressed on the keyboard. With some chords, inverted chord
Chord name
4
NOTE
If you press the SYNCHRO/ENDING button and then
If you press the SYNCHRO/ENDING button in place of
You can adjust the accompaniment part volume level
forms may be displayed.)
To stop Auto Accompaniment play, press the START/ STOP button again.
the INTRO button in place of the START/STOP button in step 2, accompaniment will start with an intro pattern when you perform the operation in step 3. For details about these buttons, see pages E-35 and E-36.
the START/STOP button in step 4, an ending pattern will play before accompaniment play is ended. For details about this button, see page E-36.
independently of the main volume. For details, see Adjusting Accompaniment and Song Bank Volume on page E-47.
E-31
Auto Accompaniment
CASIO CHORD
This method of chord play makes it possible for anyone to easily play chords, regardless of previous musical knowledge and experience. The following describes the CASIO CHORD Accompaniment keyboard and Melody keyboard, and tells you how to play CASIO CHORDs.
CASIO CHORD Accompaniment Keyboard and Melody Keyboard
<WK-110>
Accompaniment
keyboard
<CTK-810>
Accompaniment
keyboard
NOTE
The accompaniment keyboard can be used for playing chords only. No sound will be produced if you try playing single melody notes on the accompaniment keyboard.
The split point (page E-46) is the point that separates the Auto Accompaniment area and the melody area of the keyboard. You can change the location of the split point, which also changes the sizes of the keyboard areas.
Melody keyboard
Melody keyboard
Chord Types
CASIO CHORD accompaniment lets you play four types of chords with minimal fingering.
Chord Types
Major chords
Major chord names are marked above the keys of the accompaniment keyboard. Note that the chord produced when you press an accompaniment keyboard does not change octave, regardless of which key you use to play it.
Minor chords (m)
To play a minor chord, keep the major chord key depressed and press any other accompaniment keyboard key located to the right of the major chord key.
Seventh chords (7)
To play a seventh chord, keep the major chord key depressed and press any other two accompaniment keyboard keys located to the right of the major chord key.
Minor seventh chords (m7)
To play a minor seventh chord, keep the major chord key depressed and press any other three accompaniment keyboard keys located to the right of the major chord key.
Example
C Major (C)
CDEF GABCDE F
C minor (Cm)
CDE F GABC DE F
C seventh (C7)
CDEFGABCDEF
C minor seventh (Cm7)
CDEF GABCDE F
NOTE
It makes no difference whether you press black or white keys to the right of a major chord key when playing minor and seventh chords.
E-32
Auto Accompaniment
FINGERED
FINGERED provides you with a total of 15 different chord types. The following describes the FINGERED Accompaniment keyboard and Melody keyboard, and tells you how to play a C-root chord using FINGERED.
FINGERED Accompaniment Keyboard and Melody Keyboard
<WK-110>
Accompaniment
keyboard
<CTK-810>
Accompaniment
keyboard
NOTE
The accompaniment keyboard can be used for playing chords only. No sound will be produced if you try playing single melody notes on the accompaniment keyboard.
The split point (page E-46) is the point that separates the Auto Accompaniment area and the melody area of the keyboard. You can change the location of the split point, which also changes the sizes of the keyboard areas.
Melody keyboard
Melody keyboard
C
*1
Caug
*2
Cm7
5 *1
C7
Cmadd9
See the FINGERED Chord Chart on page A-7 for details on playing chords with other roots.
*1: Inverted fingerings cannot be used. The lowest note is
the root.
*2: The same chord can be played without pressing the 5th
G.
Cm
Csus4
Cmaj7
C7sus4
CmM7
*2
*2
Cdim
*2
C7
Cm7
Cadd9
Cdim7
5
*1
NOTE
Except for the chords specified in note*1 above, inverted fingerings (i.e. playing E-G-C or G-C-E instead of C-E­G) will produce the same chords as the standard fingering.
Except for the exception specified in note*2 above, all of the keys that make up a chord must be pressed. Failure to press even a single key will not play the desired FINGERED chord.
E-33
Auto Accompaniment
2
FULL RANGE CHORD
This accompaniment method provides a total of 38 different chord types: the 15 chord types available with FINGERED plus 23 additional types. The keyboard interprets any input of three or more keys that matches a FULL RANGE CHORD pattern to be a chord. Any other input (that is not a FULL RANGE CHORD pattern) is interpreted as melody play. Because of this, there is no need for a separate accompaniment keyboard, so the entire keyboard, from end to end, can be used for both melody and chords.
FULL RANGE CHORD Accompaniment Keyboard and Melody Keyboard
<WK-110>
Accompaniment keyboard/Melody keyboard
<CTK-810>
Accompaniment keyboard/Melody keyboard
< Chords Recognized by This Keyboard >
Chord Types
Corresponding
FINGERED Chord
Other Chords
15 (page E-33)
23
The following are examples of chords that use C as the bass note.
C6 Cm6 C69
C
Ddim
Number of Types
D
E
C
C
BCCmCDm
C
C
C
A
7
CF7C
FCGC A
FmCGmCAmCBm
Fm7CGm7CA
C
C
add9
B
C
C
Example: To play the chord C major.
Any of the fingerings shown in the illustration below will produce C major.
<WK-110>
1
EG C
E
G C
2
1 .... Chord C
2 .... Chord C
C E
<CTK-810>
1
EG C
E
NOTE
As with the FINGERED mode (page E-33), you can play the notes that form a chord in any combination (1).
When the composite notes of a chord are separated by 6 or more notes, the lowest sound becomes the bass (2).
< Music Example >
Tone: 001, Rhythm: 102, Tempo: 070
D
#
DBmGA

 
C
4
4
4
4

 
G C
Bm
A
  
1 .... Chord C
2 .... Chord C
E7
A
C E
A G
 
E-34
Auto Accompaniment
Using an Intro Pattern
This keyboard lets you insert a short intro into a rhythm pattern to make startup smoother and more natural.
The following procedure describes how to use the Intro feature. Before starting, you should first select the rhythm you want to use, and set the tempo.
To insert an intro
1
Press the INTRO button to start the selected rhythm with an intro pattern.
With the above setup, the intro pattern is played and the auto accompaniment with intro pattern starts as soon as you play chords on the accompaniment keyboard.
NOTE
The standard rhythm pattern starts to play after the intro pattern is complete.
Pressing the VARIATION/FILL-IN button while an intro pattern is playing causes the variation pattern to sound after the intro pattern is complete.
Using a Fill-in Pattern
Fill-in patterns let you momentarily change the rhythm pattern to add some interesting variation to your performances.
The following procedure describes how to use the Fill-in feature.
To insert a fill-in
1
Press the START/STOP button to start rhythm play.
2
Press the NORMAL/FILL-IN button to insert a fill­in pattern for the rhythm you are using.
NOTE
The fill-in pattern does not play if you press the NORMAL/FILL-IN button while an intro pattern is playing.
Using a Rhythm Variation
In addition to the standard rhythm pattern, you can also switch to a secondary variation rhythm pattern for a bit of variety.
To insert the variation rhythm pattern
1
Press the START/STOP button to start rhythm play.
2
Press the VARIATION/FILL-IN button to switch to the variation pattern for the rhythm you are using.
NOTE
To switch back to the standard rhythm pattern, press the NORMAL/FILL-IN button.
Using a Fill-in Pattern with a Variation Rhythm
You can also insert a fill-in pattern while a variation rhythm pattern is playing.
To insert a fill-in into a rhythm variation
1
While a variation rhythm pattern is playing, press the VARIATION/FILL-IN button to insert a fill-in pattern for the variation rhythm you are using.
Synchro Starting Accompaniment with Rhythm Play
You can set up the keyboard to start rhythm play at the same time you play the accompaniment on the keyboard.
The following procedure describes how to use synchro start. Before starting, you should first select the rhythm you want to use, set the tempo, and use the MODE switch to select the chord play method you want to use (NORMAL, CASIO CHORD, FINGERED, FULL RANGE CHORD).
E-35
Auto Accompaniment
To use synchro start
1
Press the SYNCHRO/ENDING button to put the keyboard into synchro start standby.
Flash
2
Playing a chord and the rhythm pattern starts to play automatically.
NOTE
If the MODE switch is set to NORMAL, only the rhythm plays (without a chord) when you play on the accompaniment keyboard.
If you press the INTRO button before playing anything on the keyboard, the rhythm starts automatically with an intro pattern when you play something on the accompaniment keyboard.
Pressing the VARIATION/FILL-IN button before playing anything on the keyboard causes play to start with the variation pattern when something is played on the keyboard.
To cancel synchro start standby, press the SYNCHRO/ ENDING button one more time.
Using One-touch Preset
One-touch preset automatically makes the settings listed below in accordance with the rhythm pattern you are using.
Keyboard tone
Layer, Split, or Layer Split on/off
Layered tone (when layer is turned on), split tone (when
split is turned on), or layered split tone (when layer and split are turned on)
Tempo
Reverb and chorus settings
To use one-touch preset
1
Select the rhythm you want to use.
2
Use the MODE switch to select the accompaniment mode you want to use.
3
Press the ONE TOUCH PRESET button.
This automatically configures the one-touch preset settings in accordance with the rhythm you selected, and enters synchro start standby.
4
Play a chord. This will cause the rhythm pattern to start to play automatically.
Accompaniment is played using the one touch preset settings.
Finishing with an Ending Pattern
You can end your performances with an ending pattern that brings the rhythm pattern you are using to a natural-sounding conclusion. The following procedure describes how to insert an ending pattern. Note that the actual ending pattern played depends on the rhythm pattern you are using.
To finish with an ending pattern
1
While the rhythm is playing, press the SYNCHRO/ ENDING button.
This causes the ending pattern to play, which brings rhythm accompaniment to an end.
E-36
Registration Memory
Registration Memory Features
Registration memory lets you store up to 32 keyboard setups (4 sets × 8 banks) for instant recall whenever you need them. The following is a list of settings that are saved in registration memory.
Registration Memory Settings
Tone
Rhythm
Tempo
Layer on/off
Split on/off
Split point
Effect settings
Touch Response settings
Assignable jack setting
Synchro standby state
NOTE
Each bank of registration memory initially contains data when you first use the keyboard. Simple replace the existing data with your own data.
Setup Names
You can assign setups into one of 32 areas, which you can select using BANK button and the four REGISTRATION buttons. Area names range from 1-1 through 8-4 as shown below.
21
123
1-1BANK 1 1-2 1-3 1-4
2-1BANK 2 2-2 2-3
3-1BANK 3 3-2
4-1BANK 4 4-2 4-3 4-4
5-1BANK 5 5-2
6-1BANK 6 6-2 6-3 6-4
7-1BANK 7 7-2 7-3
8-1BANK 8 8-2 8-3 8-4
3-3
5-3
1 Use the BANK button to select the bank. Each press of
BANK cycles through the bank numbers from 1 to 8.
2 Pressing one of the REGISTRATION buttons (1 to 4) selects
the corresponding area in the currently selected bank.
4
2-4
3-4
5-4
7-4
NOTE
Whenever you save a setup and assign it a setup name, any setup data previously assigned to that name is replaced with the new data.
E-37
Registration Memory
Number buttons
BANK
REGISTRATION STORE
To Save a Setup in Registration Memory
1
Select a tone and rhythm, and otherwise set up the keyboard the way you want it.
See Registration Memory Settings on page E-37 for details on what data is stored in the registration memory.
2
Use the BANK button or the number buttons to select the bank you want.
If you do not perform any operation for about three seconds after pressing the BANK button, the display returns to the contents in step 1, above.
Bank 1 selected.
Bank
3
While holding down the STORE button, press a REGISTRATION button (1 to 4).
The following display appears when you press the 2 button.
Store
To Recall a Setup from Registration Memory
1
Use the BANK button or the number buttons to select the bank.
If you do not perform any operation for about three seconds after pressing the BANK button, the keyboard automatically clears the registration memory recall screen.
Bank
2
Press the REGISTRATION button (1 to 4) for the area whose setup you want to recall.
Reca l l
The setup name along with the message Recall appears on the display.
NOTE
If you press a REGISTRATION button without using the BANK button to select a bank first, the last bank number selected is used.
4
Release the STORE and REGISTRATION buttons.
NOTE
The setup is saved as soon as you press a REGISTRATION button in step 3, above.
E-38
Recording and Play Back
RECORDER SONG BANK
MODE
START/STOP
You can record your lesson play (lesson recording) and keyboard play along with the Auto Accompaniment you are using (performance recording).
Parts and Tracks
How data is recorded to the keyboard and the type of data that is recorded depends on whether you are performing a performance recording operation or a lesson recording operation.
Lesson Recording
With lesson recording, you use the LEFT/TRACK 1 button and the RIGHT/TRACK 2 button to select recording of only the left-hand part, only the right-hand part, or both the left­hand and right-hand parts.
Performance Recording
With performance recording, the keyboard operates like a tape recorder or sequencer. In this case, you can use the LEFT/ TRACK 1 button and the RIGHT/TRACK 2 button to select the track you want to record to. Performance recording records the data shown in the illustration below, using two memory tracks.
Start End
Track 1
Track 2
Since each track is independent of the other, you can edit a recording by re-recording only one of the tracks.
Auto Accompaniment
(rhythm, bass, chords), melody
Melody
Data recorded in track
RHYTHM
[+] / [–]
RIGHT/TRACK 2
LEFT/TRACK 1TEMPO
Using the RECORDER Button
Each press of the RECORDER button cycles through the recording options in the sequence shown below.
Playback
Standby
Displayed
Record
Standby
Flashing Not displayed
Normal
Memory Capacity
This keyboard can hold a total of approximately 12,000 notes, which can be divided between a lesson recording and a performance recording. Note that you can use up all 12,000 notes for either the lesson recording or the performance recording. If you do, you will not be able to record anything for the other type of recording.
The recorder shares the same memory area with the song bank area used for storing song data transferred from a computer. Because of this, you may not be able to store the full 12,000 notes of data.
When the number of remaining notes becomes less than about 100 while you are recording, the RECORDER indicator and the track/part indicator (L, R) will start to flash at high speed.
Recording will stop automatically if memory becomes full.
If you are using Auto Accompaniment or a rhythm, they will also stop playing at this time.
IMPORTANT!
Never turn off the keyboard while it is recording or standing by for recording to the keyboard. Doing so will cause all of the song data currently stored in the Song Bank user area to be deleted.
E-39
Recording and Play Back
Recorded Data Storage
Anything previously stored in the keyboard is replaced whenever you make a new recording.
Recorder contents are retained even when power is turned off, as long as the keyboard is being supplied battery or AC adaptor power. If you remove the batteries or should the batteries go dead while the keyboard is not being supplied power by the AC adaptor, recorder contents will be deleted. Be sure to supply power to the keyboard with the AC adaptor when replacing batteries.
Turning off the keyboard while a record operation is in progress causes the contents of the track you are currently recording to be lost.
CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or damage to you or any third party arising out of the loss or corruption of data.
Recording Play Along with a Built­in Tune
You can use the lesson recording procedure to record notes you play along with one of the keyboards built-in tunes. When you start a lesson recording, the keyboard plays the song minus the part(s) you selected as the recording part(s).
Part/Track Indicators in Recording Standby
Press the part/track button of the part you want to play on the keyboard (recording part). This causes its part/track indicator to flash.
Playback part (not displayed)
Example: The above indicates the left-hand part is the
playback part, and the right-hand part is the recording part.
Recording part (flashing)
Selecting Parts
Press the part/track button that corresponds to the part(s) you want to select as the recording part(s).
To select this part:
Left-hand Right-hand
Both hands
The part that is currently selected is indicated by the part/ track indicators (L and R) that appear on the display as described below.
Press this button:
LEFT/TRACK 1 RIGHT/TRACK 2 LEFT/TRACK 1 +
RIGHT/TRACK 2
E-40
Recording and Play Back
To record as you play along with a built-in tune
1
Press the SONG BANK button to select the mode that includes the tune you want to play along with.
Indicator appears
2
Use the RECORDER button to select record standby.
This causes the RECORDER indicator to flash on the display.
3
Select the tune you want to play along with.
See To play back a Song Bank tune on page E-22 for information about selecting Song Bank tunes.
4
Use the LEFT/TRACK 1 button or RIGHT/TRACK 2 button to select the part(s) (left-hand, right-hand) you want to mute in the built-in tune playback and play along on the keyboard.
If you want to mute and play both parts, press both buttons at the same time.
5
Configure the following settings as required.
Tone (page E-20)
Tempo (page E-23)
Lesson Recording Data
In addition to the notes you play on the keyboard and the accompaniment of the built-in song you selected, the following data is also stored by a lesson recording operation.
Tone setting
Tempo setting
Tune name
Recording part selection
Pedal operations
Layer and split settings, and their tone settings
Effect setting
Playing Back a Lesson Recording
1
Press the SONG BANK button to select the bank of the built-in tune that you originally used to record the lesson recording.
2
Use the RECORDER button to select playback standby.
3
Press the controller block START/STOP button.
This starts playback of lesson recording contents.
You can adjust the tempo at this point, if you want.
4
To stop playback, press the controller block START/ STOP button again.
6
Press the controller block START/STOP button.
This starts recording.
7
Play the notes for the part(s) you selected in step 4 on the keyboard.
8
Recording stops automatically when playback of the built-in tune is finished.
To interrupt recording part way through, press the controller block START/STOP button. This will play back everything you recorded up to that point.
If you want to hear what you recorded immediately, press the controller block START/STOP button again.
Recording a Performance
Use this procedure when you want to record what you play on the keyboard in real time. Performance recording records both the notes you play and any accompaniment patterns that you use.
Selecting a Track
Press the part/track button that corresponds to the track you want to select.
To select this track:
Track 1 Track 2
The track that is currently selected is indicated by the part/ track indicator (L or R) that appears on the display as described below.
Press this button:
LEFT/TRACK 1 RIGHT/TRACK 2
E-41
Recording and Play Back
Part/Track Indicators in Playback Standby
Each press of a part/track button toggles playback of that track on (part/track indicator displayed) and off (indicator not displayed).
Track 1 Track 2
Playback (displayed)
Example: The above indicates that Track 1 will be played back,
while Track 2 will not.
No playback (not displayed)
Part/Track Indicators in Recording Standby
The part/track indicator will be displayed if its track already contains data. Press the part/track button of the track to which you want to record (record track). This causes its part/track indicator to flash. The part/track indicator of the other track will remain displayed (without flashing) to indicate that it will playback during recording (playback track).
To record your keyboard performances
IMPORTANT!
Recording to a track that already contains data causes the existing data to be replaced by your new performance.
1
Press the RHYTHM button to enter the rhythm mode.
Indicator appears
2
Use the RECORDER button to select record standby.
This causes the RECORDER indicator to flash on the display.
3
Press the LEFT/TRACK 1 button to select Track 1.
This causes the L indicator to flash, indicating that Track 1 is the recording track.
Playback track (displayed)
Example: The above indicates Track 1 is the playback track,
and Track 2 is the record track.
Record track (flashing)
Flashing
4
Configure the following settings as required.
Tone (page E-20)
Rhythm (page E-30)
MODE switch setting (page E-31)
Use a slower tempo if you feel you might have trouble
playing properly at a faster tempo (page E-23).
5
Press the controller block START/STOP button.
This starts recording.
6
Play the notes you want on the keyboard.
Besides notes, any chords you play on the keyboard are recorded, along with their Auto Accompaniment patterns. Melody notes you play are also recorded.
Any pedal operations you perform while playing are also recorded.
7
To stop recording, press the controller block START/ STOP button again.
If you make a mistake, you need to go back and re­record from step 2.
If you want to immediately hear what you recorded, press the controller block START/STOP button again.
E-42
Recording and Play Back
Track 1 Data
In addition to notes played on the keyboard and chord accompaniments, the following data is also stored in Track 1 during performance recording.
Tone number
Rhythm number
INTRO button, SYNCHRO/ENDING button, NORMAL/
FILL-IN button, VARIATION/FILL-IN button operations
Pedal operations
Layer and split settings, and their tone settings
Split point
Tempo setting
Effect setting
Track 1 Recording Variations
To record without rhythm
Skip step 5 of the above procedure.
Recording without rhythm starts as soon as you press a keyboard key.
To start recording with synchro start
In place of step 5 of the above procedure, press the SYNCHRO/ENDING button.
Now Auto Accompaniment and recording will start when you play a chord within the accompaniment keyboard range.
To insert an intro, ending, or fill-in into a recording
During recording, press the INTRO button, SYNCHRO/ ENDING button, NORMAL/FILL-IN button, or VARIATION/FILL-IN button as required.
To start recording with an intro using synchro start
In place of step 5 of the above procedure, press the SYNCHRO/ENDING button and then the INTRO button.
Now Auto Accompaniment and recording will start with an intro pattern when you play a chord within the accompaniment keyboard range.
To start Auto Accompaniment part way into a recording
In place of step 5 of the above procedure, press the SYNCHRO/ENDING button, and play something within the melody range of the keyboard.
This records the melody without any accompaniment. Auto Accompaniment will start when you play a chord within the accompaniment keyboard range.
Playing Back a Performance Recording
Perform the following procedure when you want to play back a tune you recorded with performance recording.
1
Press the RHYTHM button to enter the rhythm mode.
Indicator appears
2
Use the RECORDER button to select playback standby.
3
Press the controller block START/STOP button.
This starts playback of performance recording contents. During playback, you can press the LEFT/ TRACK 1 or RIGHT/TRACK 2 button to mute either track and listen to the contents of the other track only.
You can adjust the tempo at this point, if you want.
4
To stop playback, press the controller block START/ STOP button again.
NOTE
During performance recording playback, the entire range of the keyboard operates as a melody keyboard, regardless of the MODE switch setting. You can play along with performance recording playback, if you want. You could use layer and split (page E-45 through E-47) at this time to assign multiple tones to the keyboard.
Note that pause, skip forward, and skip back operations cannot be performed during performance recording playback.
You can send playback of performance recording contents as MIDI data.
E-43
Recording and Play Back
Overdubbing a Performance Recording
You can use the following procedure to record a melody in Track 2 so it combines with a recording you previously made in Track 1.
1
Press the RHYTHM button to enter the rhythm mode.
Indicator appears
2
Use the RECORDER button to select record standby.
3
Press the RIGHT/TRACK 2 button to select Track 2 as the recording track.
Flashing
4
Select the tone you want to use.
5
Press the controller block START/STOP button.
This starts playback of Track 1 and recording in Track 2.
6
Play the melody notes you want as you listen to the playback from Track 1.
7
To stop recording, press the controller block START/ STOP button again.
If you make a mistake, you need to go back and re­record from step 2.
If you want to immediately hear what you recorded, press the controller block START/STOP button again.
Track 2 Data
In addition to notes played on the keyboard, the following data is also recorded to Track 2.
Tone number
Pedal operations
Deleting a Specific Part/Track
You can use the following procedure to delete a specific part/track from a lesson recording or performance recording.
Getting Ready
When deleting a lesson recording part
Press the SONG BANK button.
When deleting a performance recording track
Press the RHYTHM button.
1
Press the RECORDER button to enter record standby.
2
Select the part/track you want to delete by pressing the LEFT/TRACK 1 button or RIGHT/TRACK 2 button.
3
Hold down the RECORDER button.
This causes a confirmation message to appear on the display.
To cancel the delete operation, press the [–] (NO) button .
4
Press the [+] (YES) button to delete the part/track.
This causes the keyboard to return to playback standby.
NOTE
Pressing the RECORDER button while the part/track delete screen is on the display returns to record standby.
NOTE
Track 2 is a melody-only track, which means that chord accompaniment cannot be recorded there. Because of this, the entire range of the keyboard becomes a melody keyboard when recording the Track 2, regardless of the current MODE switch setting.
If you want to record without playback from a recorded track, enter playback standby, deselect the playback track, and then enter record standby. Note, however, that you cannot turn off rhythm and Auto Accompaniment.
E-44
Keyboard Settings
TRANSPOSE/SETTING TONE
Number buttons
[+] / [–]
This section describes how to use layer (to play two tones with a single key) and split (to assign different tones to either end of the keyboard), and how to make touch response, transpose, and tuning settings.
Using Layer
Layer lets you assign two different tones (a main tone and a layered tone) to the keyboard, both of which play whenever you press a key. For example, you could layer the FRENCH HORN tone on the BRASS tone to produce a rich and brassy sound.
To layer tones
1
First select the main tone.
Example: To select “180 BRASS as the main tone, press
the TONE button and then use the number buttons or [+] and [–] buttons to input 1, 8 and then 0.
Brass
2
Press the LAYER button.
St r i ngs
Selected layer tone Indicator appears
SPLIT
3
Select the layered tone.
Example: To select “178 FRENCH HORN as the layered
tone, use the number buttons or [+] and [–] buttons to input 1, 7 and then 8.
LAYER
Fr .Horn
4
Now try playing something on the keyboard.
Both tones are played at the same time.
5
Press the LAYER button again to unlayer the tones and return the keyboard to normal.
LAYER
Example: WK-110
Main Tone (BRASS) + Layered Tone (FRENCH HORN)
Using Split
With split you can assign two different tones (a main tone and a split tone) to either end of the keyboard, which lets you play one tone with your left hand and another tone with your right hand. For example, you could select STRINGS as the main (high range) tone and PIZZICATO STRINGS as the split (low range) tone, putting an entire string ensemble at your fingertips. Split also lets you specify the split point, which is the location on the keyboard where the changeover between the two tones occurs.
E-45
Keyboard Settings
To split the keyboard
1
First select the main tone.
Example: To select “146 STRINGS as the main tone,
press the TONE button and then use the number buttons or [+] and [–] buttons to input 1, 4 and then 6.
St r ings
2
Press the SPLIT button.
Acous . Bs
Indicator appears
3
Select the split tone.
Example: To select “134 PIZZICATO STRINGS as the
split tone, use the number buttons or [+] and [–] buttons to input 1, 3 and then 4.
Pizz. tSr
4
Specify the split point. While holding down the SPLIT button, press the keyboard where you want the leftmost key of the high end range to be.
Example: To specify G3 as the split point, press the G3
key.
G 3
Using Layer and Split Together
You can use layer and split together to created a layered split keyboard. It makes no difference whether you layer tones first and then split the keyboard, or split the keyboard and then layer tones. When you use layer and split in combination, the high range of the keyboard is assigned two tones (main tone + layered tone), and the low range two tones (split tone + layered split tone).
To split the keyboard and then layer tones
1
Press the TONE button and then input the tone number of the main tone.
Brass
2
Press the SPLIT button and then input the number of the split tone.
Pizz.Str
Indicator appears
After specifying the split tone, press the SPLIT button to unsplit the keyboard.
3
Press the LAYER button and then input the number of the layered tone.
Note that you can reverse steps 2 and 3, specifying the layered tone first and then the split tone.
5
Now try playing something on the keyboard.
Every key from F3 and below is assigned the PIZZICATO STRINGS tone, while every key from G3 and above is assigned the STRINGS tone.
6
Press the SPLIT button again to unsplit the keyboard and return it to normal.
SPLIT
Example: WK-110
(PIZZICATO STRINGS)
Split point
E-46
Main Tone (STRINGS)Split Tone
Fr .Horn
Indicator appears
4
Press the SPLIT button or the LAYER button so both of the SPLIT and LAYER indicators are displayed.
5
Input the number of the layered split tone.
St r i ngs
6
Specify the split point.
While holding down the SPLIT button, press the keyboard where you want the leftmost key of the low end range to be.
Keyboard Settings
7
Play something on the keyboard.
Press the LAYER button to unlayer the keyboard, and the SPLIT button to unsplit it.
LAYER SPLIT
Example: WK-110
(BRASS)
Split Tone
(PIZZICATO STRINGS)
Layered Split Tone (STRINGS)
+
Split point
Main Tone
Layered Tone (FRENCH HORN)
+
About TRANSPOSE/SETTING button
Each press of the TRANSPOSE/SETTING button cycles through the setting screens. If you accidentally pass the screen you want to use, keep pressing the TRANSPOSE/SETTING button until the screen appears again.
Transposing the Keyboard
Transpose lets you raise and lower the overall key of the keyboard in semitone units. If you want to play an accompaniment for a vocalist who sings in a key that’s different from the keyboard, for example, simply use transpose to change the key of the keyboard.
If you leave the transpose screen on the display for about five seconds without doing anything, the screen is automatically cleared.
The transpose setting also affects playback from memory and Auto Accompaniment.
To return the keyboard to its default key, perform the above procedure and press both of the [+] and [–] buttons at the same time in step 2.
The effect of a transpose operation depends on the pitch of each note and on the tone you are currently using. If a transpose operation causes a note to be outside of the allowable range for a tone, the same note in the nearest octave within the range will be substituted.
Adjusting Accompaniment and Song Bank Volume
You can adjust the volume of the accompaniment and Song Bank tunes independently of the notes you play on the keyboard. You can specify a volume level in the range of 000 (minimum) to 127 (maximum).
To adjust the accompaniment volume
1
Press the TRANSPOSE/SETTING button until the accompaniment volume adjustment screen appears.
Aco
mpVo l
To transpose the keyboard
1
Press the TRANSPOSE/SETTING button until the transpose setting screen appears.
Trans.
2
Use the number buttons or the [+]/[–] buttons to change the key of the keyboard.
Example: To transpose the keyboard five semitones
upwards.
Trans.
NOTE
The keyboard can be transposed within a range of –12 (one octave downwards) to +12 (one octave upwards).
The default transpose setting is 00 when keyboard power is turned on.
Current accompaniment volume setting
2
Use the number buttons or the [+]/[–] buttons to change the current volume setting value.
Example: 110
Aco
NOTE
The current accompaniment volume value that appears in Step 1 automatically clears from the display if you do not input anything within about five seconds.
mpVo l
To adjust built-in tune volume
Enter the Song Bank mode, and then perform the procedure under To adjust the accompaniment volume”.
In this case, a song volume screen will appear in place of the accompaniment volume screen.
E-47
Keyboard Settings
Using Touch Response
When touch response is turned on, the relative volume of sound output by the keyboard is varied in accordance with the amount of pressure applied, just like an acoustic piano.
Touch response provides a choice of three settings, described below.
OFF: This setting turns off touch response. Keyboard pressure
does not have any affect on the output notes.
1:This setting provides touch response that is suited for
normal play.
2:This setting increases touch response, so stronger keyboard
pressure has a greater effect than the “1” setting.
1
Press the TRANSPOSE/SETTING button until the TOUCH RESPONSE SELECT screen appears.
Touch
2
Use the [+] and [–] or [0] and [1] buttons to change the setting.
Example: To select touch response 2.
Touch
Touch response is on when touch response indicator is on.
Indicator appears
Tuning the Keyboard
Use the following procedure to fine tune the keyboard to match the tuning of another musical instrument.
To tune the keyboard
1
Press the TRANSPOSE/SETTING button until the tuning screen appears.
Tune
2
Use the [+], [–], and the number buttons to adjust the tuning value.
Example: To lower tuning by 20
Tune
NOTE
The keyboard can be tuned within a range of –50 cents to +50 cents. * 100 cents is equivalent to one semitone.
The default tuning setting is 00 when keyboard power is turned on.
If you leave the tuning screen on the display for about five seconds without doing anything, the screen is automatically cleared.
The tuning setting also affects playback from recorder and Auto Accompaniment.
To return the keyboard to its default tuning, perform the above procedure and press the [+] and [–] buttons at the same time in step 2.
Touch response is off when touch response indicator is off.
NOTE
Recording playback and accompaniment do not affect the touch response setting.
E-48
Connection to a Computer
TRANSPOSE/SETTING
Number buttons
[+] / [–]
Connecting to a Computer
The keyboards USB port makes it quick and simple to connect to a computer. After installing the USB MIDI driver onto your computer from the CD-ROM that comes with the keyboard, you will be able to use commercially available MIDI software on your computer to exchange data between the keyboard and your computer.
To install the USB MIDI driver
1
On the computer to which you plan to connect, install the USB MIDI driver that comes on the CD­ROM that comes bundled with the keyboard.
For information about installing the USB MIDI driver, see the CASIO USB MIDI Driver Users Guide (manual_e.pdf) on the USB Manual and Driver CD­ROM”.
NOTE
Before starting actual installation of USB MIDI driver, be sure to read the contents of the readme.txt file in the English folder on the CD-ROM.
Use Adobe Reader or Acrobat Reader to access the USB MIDI driver users guide.*
* You need to have Adobe Reader or Acrobat Reader installed on
your computer in order to view the contents of the “CASIO USB MIDI Driver User’s Guide” (manual_e.pdf). If your computer does not have either Adobe Reader or Acrobat Reader installed, use the procedure below to install it.
LEFT/TRACK 1
Minimum Computer system Requirements
Supported Operating Systems
Operation is supported under Windows® XP Professional, Windows® XP Home Edition, Windows® 2000 Professional, Windows® Me, Windows® 98SE, and Windows® 98.
RIGHT/TRACK 2
Universal
IBM AT or compatible computer
USB port that provides normal operation under Windows
CD-ROM drive (for installation)
At least 2MB of free hard disk space (not including space
required for Adobe Reader)
Windows XP
300MHz or higher Pentium processor
At least 128MB of memory
Windows 2000
166MHz or higher Pentium processor
At least 64MB of memory
Windows Me, Windows 98SE, Windows 98
166MHz or higher Pentium processor
At least 32MB of memory
NOTE
Company and product names used herein are trademarks of their respective owners.
Installing Adobe Reader (Acrobat Reader**)
Place the USB Manual and Driver CD-ROM into your computers CD-ROM drive.
On the CD-ROM, navigate to the folder named Adobe, open the folder named English, and then double-click ar601enu.exe (ar505enu.exe**). Follow the instructions that appear on your computer screen to install Adobe Reader.
** Adobe Reader cannot be installed on a computer running
Windows 98. If your computer is running under Windows 98, double-click “ar505enu.exe” to install Acrobat Reader.
E-49
Connection to a Computer
Using the USB port
Note that you need to purchase a commercially available USB cable to connect the keyboard to a computer using the USB port.
To connect to a computer using the USB port
1
Use a commercially available USB cable to connect the keyboard to the computer.
Computer
USB port
USB cable
USB connector
Keyboard USB port
DATA ACCESS Lamp
The DATA ACCESS lamp lights whenever the keyboard is exchanging data with a connected computer over a USB cable connection. Never disconnect the USB cable while the DATA ACCESS lamp is lit.
Expanding the Selections in the Song Bank Tunes
You can transfer song data from your computer to the keyboard. You can store up to 5 tunes as Song Bank tunes 101 through 105. For SMF data you purchase or create, you need to use an SMF Converter to convert it to CASIO format before transferring it to the keyboard.
To install the SMF Converter
1
On the computer to which you plan to connect, install the SMF Converter that comes on the CD­ROM that comes bundled with the keyboard.
On the CD-ROM, double-click SMFConv-e.exe, and then follow the instructions that appear on your computer screen to install SMF Converter.
• Before installing SMF Converter, be sure to read the contents of the “smfreadme.txt” file in each language folder on the CD-ROM.
For information about using SMF Converter, double-click index.html in the [help] folder, which was created when you installed SMF Converter. You can also access user documentation from the Windows [Start] menu by clicking [Programs] - [CASIO] - [SMF Converter] - [manual].
• A browser that supports frames (like Internet Explorer 4 or Netscape Navigator 4.04 or higher) is required to view the SMF Converter manual.
Minimum Computer System Requirements
Operating System:
Windows 98SE Windows Me Windows XP Home Edition/XP Professional
Storage
At least 10MB free HDD space
USB interface
E-50
You can also obtain a copy of the SMF Converter by downloading it at the Web page shown below. After downloading, install the software on your computer.
CASIO MUSIC SITE
http://music.casio.com/
In addition to the software itself, the CASIO MUSIC SITE will also provide you with information about its installation and use. You can also find out about the latest news about your keyboard and other CASIO musical instruments, and much more.
Connection to a Computer
Song Data Storage
Song data saved as Song Bank tunes are retained even when power is turned off, as long as the keyboard is being supplied battery or AC adaptor power. If you remove the batteries or should the batteries go dead while the keyboard is not being supplied power by the AC adaptor, song data will be deleted. Be sure to supply power to the keyboard with the AC adaptor when replacing batteries.
NOTE
This keyboard supports SMF 0 and 1 format data.
Voice Fingering Guide, on-screen fingering indicators,
and voice announcement of evaluation points are not supported for SMF data you purchase or create.
Using the SMF Data on the Bundled CD-ROM
The CD-ROM that comes bundled with the keyboard contains demos as well as 25 tunes (SMF data) that you can use for step lessons. It also contains PDF format files that contain the sheet music of the included tunes. For a full list of the tunes that are included, open the List.txt file located inside the MusicDataFolder on the CD-ROM. For each tune, List.txt shows the tune name, SMF file name, PDF file name of the music score, and the type of lesson★ for which the tune can be used. A tune marked with an asterisk (*) can be used for a both-
hand lesson. A tune that is not marked with an asterisk can be used for a right-hand lesson.
NOTE
You can load SMF data from the CD-ROM to the keyboard using the SMF converter tool (page E-50).
You will need to have Adobe Reader or Acrobat Reader installed on your computer in order to view the contents of a music score PDF file. If neither of these applications is installed on your computer, see Installing Adobe Reader (Acrobat Reader) on page E-49.
General MIDI Tone
The General MIDI standard defines the tone numbering sequence, the drum sound numbering sequence, the number of MIDI channels that can be used, and other general factors that determine the sound source configuration. Because of this, musical data produced on a General MIDI sound source can be played back using similar tones and identical nuances as the original, even when played on another manufacturers sound source. This keyboard conforms with General MIDI standards, so it can be connected to a computer and used to play back General MIDI data that has been purchased, downloaded from the Internet, or obtained from any other source.
Changing the Settings
This section tells you how to make the settings required when connecting to a computer.
KEYBOARD CHANNEL (Default: 1)
The keyboard channel is the channel used to send messages from this keyboard to a computer. You can specify one channel from 1 to 16 as the keyboard channel.
1
Press the TRANSPOSE/SETTING button until the KEYBOARD CHANNEL screen appears.
Keybd Ch
2
Use the [+], [–], and the number buttons to change the channel number.
Example: To specify channel 4
Keybd Ch
E-51
Connection to a Computer
NAVIGATE CHANNEL (Default: 4)
When messages are received from a computer for play on this keyboard, the navigate channel is the channel whose note data appears on the display. You can select one channel from 01 to 16 as the navigate channel. Since this setting lets you use the data on any channel of commercially available SMF data to light on the on-screen keyboard guide, you can analyze how different parts of an arrangement are played.
1
Press the TRANSPOSE/SETTING button until the NAVIGATE CHANNEL screen appears.
Nav i . Ch
2
Use the [+], [–], and the number buttons [0] through [9] to change the channel number.
Example: To specify channel 2
Nav i . Ch
To turn off specific sounds before playing back tune data that is being received
<<Navigate channel on/off>>
1
While playing tune data, press the RIGHT/TRACK 2 button.
This cuts the sound of the navigate channel, but on­screen keyboard guide keys continue to light in accordance with the channels data as it is received. Press RIGHT/TRACK 2 button again to turn the channel back on.
<<Next lower channel from navigate channel on/off>>
LOCAL CONTROL (Default: On)
oFF: Anything played on the keyboard is output as a message
from the USB port, without being sounded by the internal sound source.
Note that no sound is produced by the keyboard if LOCAL CONTROL is turned off and no external device is connected.
1
Press the TRANSPOSE/SETTING button until the LOCAL CONTROL screen appears.
Example: When LOCAL CONTROL is on
Loca l
2
Use the [+] and [–] or [0] and [1] buttons to turn the setting on and off.
Example: To turn LOCAL CONTROL off
Loca l
ACCOMP OUT (Default: Off)
on: Auto Accompaniment is played by the keyboard and
the corresponding message is output from the USB port.
oFF: Auto Accompaniment messages are not output from the
USB port.
1
Press the TRANSPOSE/SETTING button until the ACCOMP OUT screen appears.
Example: When ACCOMP OUT is off
1
While playing tune data, press the LEFT/TRACK 1 button.
This cuts the sound of the channel whose number is one less than the navigate channel, but on-screen keyboard guide keys continue to light in accordance with the channels data as it is received. Press LEFT/ TRACK 1 button again to turn the channel back on.
Example: If the navigate channel is channel 4, the above
operation turns off channel 3.
E-52
Aco
2
Use the [+] and [–] or [0] and [1] buttons to turn the setting on and off.
Example: To turn ACCOMP OUT on
Aco
mpOu t
mpOu t
SUSTAIN/ASSIGNABLE JACK (Default: SUS)
SUS(sustain): Specifies a sustain*1 effect when the pedal is
depressed.
SoS (sostenuto): Specifies a sostenuto*2 effect when the
pedal is depressed.
SFt (soft): Specifies reduction of the sounds volume when
the pedal is depressed.
rHy (rhythm): Specifies START/STOP button operation
when the pedal is depressed.
1
Press the TRANSPOSE/SETTING button until the SUSTAIN/ASSIGNABLE JACK screen appears.
Example: When sustain is currently set
Jack
2
Use the [+] and [–] or [0], [1], [2], and [3] buttons to change the setting.
Example: To select rhythm
Connection to a Computer
Jack
*1 Sustain
With piano tones and other sounds that decay, the pedal acts as a damper pedal, with sounds being sustained longer when the pedal is depressed. With organ tones and other continuous sounds, notes played on the keyboard continue to sound until the pedal is released. In either case, the sustain effect is also applied to any notes that are played while the pedal is depressed.
*2 Sostenuto
This effect performs the same way as sustain, except that it is applied only to notes that are sounding already when the pedal is depressed. It does not affect notes that are played after the pedal is depressed.
E-53
Troubleshooting
Problem Possible Cause See pageAction
No keyboard sound
Any of the following symptoms while using battery power.
Dim power supply indicator
Instrument does not turn on
Dim, difficult to read display
Abnormally low speaker/headphone volume
Distortion of sound output
Occasional interruption of sound when playing at high volumes
Sudden power failure when playing at high volumes
Dimming of the display when playing at high volume
Continued sound output even after you release a key
A totally different tone may sound
Abnormal rhythm pattern and demo tune play
1. Power supply problem.
2. Power is not turned on.
3. Volume setting is too low.
4. The MODE switch is in the CASIO CHORD or FINGERED position.
5. LOCAL CONTROL is off.
Low battery power
1. Correctly attach the AC adaptor, make sure that batteries poles (+/–) are facing correctly, and check to make sure that batteries are not dead.
2. Press the POWER button to turn on power.
3. Use the VOLUME knob to increase volume.
4. Normal play is not possible on the accompaniment keyboard while the MODE switch is set to CASIO CHORD or FINGERED. Change the MODE switch setting to NORMAL.
5. Turn on LOCAL CONTROL.
Replace the batteries with a set of new ones or use the AC adaptor.
Pages E-15, 16
Page E-20
Page E-20
Page E-31
Page E-52
Pages E-15, 16
Auto Accompaniment does not sound.
Sound output does not change when key pressure is varied.
On-screen keyboard guide keys stay on.
When playing with another instrument, keys or tunings do not match.
E-54
Accompaniment volume is set to
000.
Touch response is turned off.
Keyboard is waiting for play of the correct note during Step 1 or Step 2 play.
Transpose or tuning is set to a value other than 00.
Use the TRANSPOSE/SETTING button to increase the volume.
Press the TRANSPOSE/SETTING button to turn it on.
1. Press the lit key to continue with Step 1 or Step 2 play.
2. Press the PLAY/STOP button to quit Step 1 or Step 2 play.
Use the TRANSPOSE/SETTING button to display the applicable setting screens and set both transpose and tuning to 00.
Page E-47
Page E-48
Pages E-27, 28 Pages E-27, 28
Page E-47
Problem Possible Cause See pageAction
Cannot record Auto Accompaniment or rhythm.
Cannot record chord accompaniment data on a computer.
After transferring song data from my computer, playback stops part way through.
A tones quality and volume sounds slightly different depending where it is played on the keyboard.
Troubleshooting
Track other than Track 1 is selected as the recording track.
ACCOMP OUT is turned off.
Digital noise from the USB cable or power cord caused data communication between your computer and keyboard to be interrupted.
This is an unavoidable result of the digital sampling process,* and does not indicate malfunction. * Multiple digital samples are taken for the low range, middle range, and high range of
the original musical instrument. Because of this, there may be a very slight difference in tonal quality and volume between sample ranges.
Use the track select buttons to select Track 1. (Track 2 is melody track.)
Turn on ACCOMP OUT.
Stop playback, disconnect the USB cable from and then reconnect it to the keyboards USB port, and then try playing back the tune again. If this does not correct the problem, exit the MIDI software you are using, and then disconnect the USB cable from and then reconnect it to the keyboards USB port. Next, restart your MIDI software and try playback again.
Page E-41
Page E-52
Page E-50
E-55
Specifications
Models: CTK-810/WK-110
Keyboard: CTK-810: 61 standard-size keys, WK-110: 76 standard-size keys (with touch
Tones: 515; with layer and split Polyphony: 32 notes maximum (16 for certain tones)
Auto Accompaniment
Rhythm Patterns: 120 Tempo: Variable (226 steps, = 30 to 255) Chords: 3 fingering methods (CASIO CHORD, FINGERED, FULL RANGE CHORD) Rhythm Controller: START/STOP, INTRO, NORMAL/NORMAL FILL-IN, VARIATION/
Accomp Volume: 0 to 127 (128 steps) One Touch Presets: Recalls settings for tone, tempo, layer, split, reverb, and chorus.
3-step Lesson: 3 lessons (Step 1, 2, 3)
Playback: Repeat play of a single tune Evaluation Mode: Scoring Voice Fingering Guide: On/Off
Song Bank
Number of Tunes: Song Bank: 100, download songs: Up to 5 (Capacity: Approximately 70 KB*)
Controllers: PLAY/STOP, PAUSE, FF, REW, REPEAT, LEFT/RIGHT
Musical Information Function: Tone, Auto Accompaniment, Song Bank, numbers and names; staff notation,
Metronome: On/Off
Beat Specification: 0, 2 to 6
Registration Memory:
Number of Setups: 32 (4 setups × 8 banks)
Recorder
Number of Songs: Two (1 Lesson Recording, 1 Performance Recording) Recorded Data: Lesson Recording: Right-hand part, left-hand part, both-hand parts
Recording Method: Real-time Memory Capacity: Approximately 12,000 notes (total for two songs)
Other Functions
Transpose: 25 steps (–12 semitones to +12 semitones) Tuning: 101 steps (A4 = approximatery 440Hz ±50Cents)
Terminals
USB port: TYPE B Sustain/Assignable Jack: Standard jack (sustain, sostenuto, soft, rhythm start/stop) Headphone/Output Terminal: Stereo standard jack
Power Jack: 9V DC
Power Supply: 2-way
Batteries: CTK-810: 6 AA-size batteries, WK-110: 6 D-size batteries Battery Life: CTK-810: Approximately 2.5 hours continuous operation on alkaline batteries
AC Adaptor: AD-5 Auto Power Off: Turns power off approximately 6 minutes after last key operation. Enabled
response on/off)
VARIATION FILL-IN, SYNCHRO/ENDING
* Calculated based on 1 KB = 1024 bytes.
tempo, metronome, measure and beat number, step lesson display, chord name, fingering, pedal operation, Keyboard, Voice Fingering Guide, Evaluation Mode, Recorder indicator
Performance Recording: Track 1 (chord accompaniment), Track 2 (melody)
<CTK-810> Output Impedance: 150, Output Voltage: 4.5V (RMS) MAX <WK-110> Output Impedance: 200, Output Voltage: 5.2V (RMS) MAX
WK-110: Approximately 6 hours continuous operation on manganese batteries
under batter power only, can be disabled manually.
E-56
Speaker Output: 2.5W + 2.5W
Power Consumption: 9V 7.7W Dimensions: CTK-810: 94.5 × 37.3 × 13.1 cm (37 1/4 × 14 11/16 × 5 1/8 inch)
WK-110: 118.7 × 40.0 × 15.3 cm (46 3/4 × 15 3/4 × 6 inch)
Weight: CTK-810: Approximately 4.8 kg (10.6 lbs)(without batteries)
WK-110: Approximately 7.0 kg (15.4 lbs)(without batteries)
Design and specifications are subject to change without notice.
Specifications
Operating Precautions
Be sure to read and observe the following operating precautions.
Location
Avoid the following locations for this product.
Areas exposed to direct sunlight and high humidity
Areas subjected to temperature extremes
Near a radio, TV, video deck, or tuner
The above devices will not cause malfunction of the product, but interference from the product can cause audio or video interference of a nearby device.
User Maintenance
Never use benzene, alcohol, thinner, or other chemical agents to clean the product.
To clean the product or its keyboard, wipe with a soft cloth moistened in a weak solution of water and a mild neutral detergent. Wring all excess moisture from the cloth before wiping.
Included and Optional Accessories
Use only accessories that are specified for use with this product. Use of unauthorized accessories creates the risk of fire, electric shock, and personal injury.
Weld Lines
Lines may be visible on the exterior of the product. These are weld lines that result from the plastic molding process. They are not cracks or scratches.
Musical Instrument Etiquette
Always be aware of others around you whenever using this product. Be especially careful when playing late at night to keep the volume at levels that do not disturb others. Other steps you can take when playing late at night are closing the window and using headphones.
Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
The contents of this manual are subject to change without notice.
E-57
Appendix/Apéndice
C
C
C
32
32
16
2
4
8
25
25
25
3456
2
Cambio de programa
Tipo de gama
STEEL STR.GUITAR 1
STEEL STR.GUITAR 2
12 STR.GUITAR
C
32
2
26
JAZZ GUITAR
C
16
8
26
OCT JAZZ GUITAR
C
32
2
27
CLEAN GUITAR 1
C
32
3
27
CLEAN GUITAR 2
C
32
2
28
MUTE GUITAR
C
16
8
27
CRUNCH ELEC.GUITAR
C
C
C
C
C
C
32
32
16
16
16
16
2
2
5
4
8
9
29
30
30
30
31
25
OVERDRIVE GT
DISTORTION GT
POWER DIST. GT
RHYTHM DIST. GT
FEEDBACK GT
CHORUS STEEL GT
C
C
C
C
C
C
C
16
16
32
16
32
32
32
6
3
2
2
2
2
32
30
25
32
32
33
34
35
DIST.GT & BASS
STEEL GT HARMONICS
BASS
ACOUSTIC BASS
RIDE BASS
FINGERED BASS
PICKED BASS
FRETLESS BASS
C
C
C
C
C
C
C
C
C
32
16
32
32
32
32
16
32
32
2
3
2
2
3
1
1
4
3
37
37
38
39
38
39
38
38
33
SLAP BASS
DOUBLED STRINGS BASS
SAW SYNTH-BASS
SQR SYNTH-BASS
VOCODER BASS
DIGI ROCK BASS
SOUL SYNTH-BASS
TRANCE BASS
MELLOW FINGERED BASS
A
C
C
16
16
3
4
39
39
BASS & KICK
CLAVI BASS
A
C
C
32
32
32
32
3
4
6
5
34
33
39
39
RHYTHM PICKED BASS
RHYTHM FINGERED BASS
SINE BASS
ORGAN BASS
STR/ORCHESTRA
A
A
A
C
32
32
32
32
2
8
2
2
40
40
42
45
VIOLIN
SLOW VIOLIN
CELLO
PIZZICATO STRINGS
A
A
A
A
C
32
16
32
16
16
2
1
8
4
9
46
40
42
40
40
HARP 1
DOUBLE VIOLIN
SLOW CELLO
VIOLIN SECTION
SLOW VIOLIN SECTION
A
16
1
45
PIZZICATO ENSEMBLE
1
094
095
096
3: Program Change/
6: Range Type/
A
A
A
16
16
16
2
2
2
13
14
15
3456
ía máxima
Polifon
2
Nombre de sonido
VIBRAPHONE & MARIMBA
TUBULAR BELL
DULCIMER
1
047
048
049
2: Tone Name/
5: Maximum Polyphony/
A
A
16
32
2
1
ón de banco
3456
0
0
097
098
099
100
101
102
103
104
A
A
B
A
A
A
A
32
16
16
16
16
16
16
1
8
8
8
2
1
3
8
8
9
11
16
16
16
BRIGHT CELESTA
CHORUS CELESTA
CHORUS GLOCKENSPIEL
CHORUS VIBRAPHONE
ORGAN
DRAWBAR ORGAN 1
DRAWBAR ORGAN 2
DRAWBAR ORGAN 3
050
051
052
053
054
055
056
A
A
A
A
A
A
A
A
16
16
16
16
16
16
16
16
2
3
3
1
8
5
2
9
1
0
1
1
0
1
3
3
105
106
107
108
A
A
A
A
32
16
16
16
2
3
8
32
17
17
17
16
ROTARY DRAWBAR
PERC.ORGAN 1
PERC.ORGAN 2
ELEC.ORGAN 1
057
058
059
060
A
A
A
A
16
16
16
16
8
2
3
4
3
2
2
0
111
110
112
109
A
A
16
16
4
4
16
17
ELEC.ORGAN 2
JAZZ ORGAN 1
061
062
A
A
16
16
9
5
0
0
113
A
A
A
A
16
16
32
16
2
2
8
2
18
19
19
20
ROCK ORGAN 1
CHURCH ORGAN
CHAPEL ORGAN
REED ORGAN
063
064
065
066
A
A
A
32
16
16
2
8
1
6
6
6
114
115
116
117
118
A
A
A
A
A
16
16
16
32
16
2
8
2
2
8
21
21
23
22
22
ACCORDION 1
OCTAVE ACCORDION
BANDONEON
HARMONICA 1
HARMONICA 2
067
068
069
070
071
A
A
A
A
A
32
16
16
32
32
2
3
5
7
5
4
5
5
4
4
119
120
121
122
123
A
A
A
A
A
16
16
16
16
16
6
3
5
6
1
19
23
16
17
18
THEATER
OCTAVE BANDONEON
DRAWBAR ORGAN 4
JAZZ ORGAN 2
ROCK ORGAN 2
072
073
074
075
076
A
A
A
A
A
16
16
16
16
16
9
6
2
8
8
4
4
5
4
5
124
125
126
127
128
129
A
A
A
A
A
A
16
16
16
16
16
16
6
8
1
5
3
4
16
17
17
17
18
18
DRAWBAR ORGAN 5
JAZZ ORGAN 3
PERC.ORGAN 3
8ORGAN
ROCK ORGAN 3
ROCK ORGAN 4
077
078
079
080
081
082
A
A
A
A
A
A
16
16
32
16
32
32
3
1
4
4
2
1
4
4
4
5
7
7
130
131
132
133
A
A
A
A
A
32
16
16
32
32
9
7
1
3
16
7
16
17
19
19
FULL DRAWBAR
ORGAN PAD
SEQUENCE ORGAN
PIPE ORGAN 1
PIPE ORGAN 2
083
084
085
086
087
A
A
A
A
16
16
16
32
3
8
9
2
7
7
7
8
134
135
136
137
138
139
140
A
A
A
A
A
C
16
16
32
16
16
32
4
5
3
1
4
2
19
19
21
23
23
24
ORGAN & HARPSICHORD
PIPE ORGAN PAD
ACCORDION 2
BANDONEON SOLO
BANDONEON & VIOLIN
GUITAR
NYLON STR.GUITAR
088
089
090
091
092
093
B
A
A
A
A
A
A
32
16
32
32
16
16
16
2
2
2
2
3
3
3
9
9
11
10
11
12
12
2
O
Tone List/Lista de sonidos
1: No./N
PIANO
STEREO GRAND PIANO
GRAND PIANO
BRIGHT PIANO
MELLOW PIANO
MODERN PIANO
DANCE PIANO
STRINGS PIANO
SYNTH-STR PIANO
HONKY-TONK
Bank Select MSB/MSB de selecci
1
:
4
001
002
003
004
005
006
007
008
009
1 OCTAVE PIANO
2 OCTAVE PIANO
011
010
ELEC.GRAND PIANO
MODERN E.G.PIANO
STEREO PIANO
STEREO PIANO WIDE
PIANO PAD
HARPSICHORD
COUPLED HARPSICHORD
HARPSICHORD PAD
012
013
014
015
016
017
018
019
ELECTRIC PIANO
ELEC.PIANO 1
ELEC.PIANO 2
FM ELEC.PIANO
DYNO ELEC.PIANO
60S ELEC.PIANO
020
021
022
023
024
CHORUS EP 1
CHORUS EP 2
MODERN E.PIANO
SOFT E.PIANO
E.PIANO PAD 1
025
026
027
028
029
SYNTH-STR. E.PIANO
E.PIANO PAD 2
CLEAN E.PIANO
HARPSICHORD E.PIANO
CLAVI
SOFT CLAVI
CLAVI & DRAWBAR
DETUNE CLAVI
030
031
032
033
034
035
036
037
SEQUENCE CLAVI
CHROMATIC PERC.
CELESTA
038
039
GLOCKENSPIEL
MUSIC BOX
VIBRAPHONE
MARIMBA
GLOCKENSPIEL PAD
SYNTH-VIBRAPHONE
040
041
042
043
044
045
A-1
SYNTH-MARIMBA
046
Appendix/Apéndice
A
A
A
A
A
A
16
16
16
16
16
16
2
5
2
4
1
2
82
82
83
83
83
3456
2
CALLIOPE 1
1
247
C
32
VENT LEAD
248
C
32
85
CHIFF LEAD 1
DROP LEAD
EP LEAD
VOICE LEAD 1
249
250
251
252
A
A
A
32
16
16
A
A
A
A
A
A
16
16
16
16
16
16
2
3
4
6
7
16
87
80
80
80
80
80
BASS+LEAD
SQUARE LEAD 2
SLOW SQUARE LEAD
SLOW SQUARE PULSE
SEQUENCE SQUARE
SEQUENCE PULSE 1
253
254
255
256
257
258
A
C
C
C
C
C
32
16
32
16
16
16
A
A
A
A
A
A
32
16
32
16
16
16
1
1
4
5
81
81
81
SAW LEAD 2
SLOW SAW LEAD
PULSE SAW LEAD
261
262
263
C
C
C
16
16
32
6
81
SLOW SAW PULSE
264
A
32
32
80
80
SQUARE LEAD 3
SQUARE LEAD 4
259
260
C
C
16
32
A
A
A
A
A
A
A
16
16
16
16
16
16
16
1
9
3
1
4
16
86
81
81
FIFTH SEQUENCE
SEQUENCE PULSE 2
SEQUENCE SAW 2
265
266
267
A
A
C
32
16
32
8
82
82
82
84
CALLIOPE 2
VENT SYNTH
PURE LEAD
DISTORTION LEAD
268
269
270
271
C
C
C
C
32
16
16
16
A
A
A
A
A
16
16
16
16
16
2
3
4
8
5
84
85
85
85
85
OCTAVE CHARANG
VOICE LEAD 2
CHURCH LEAD
DOUBLE VOICE LEAD
VOICE CHOIR LEAD
272
273
274
275
276
A
A
C
32
B
C
32
32
32
16
A
A
A
A
A
A
16
16
16
16
16
16
6
7
2
3
1
3
85
85
86
86
87
87
EP & VOICE LEAD
SYNTH-VOICE LEAD
FIFTH SAW LEAD
FIFTH SQUARE LEAD
BASS+SAW LEAD
SYNTH-BASS+LEAD
SYNTH-PAD
277
278
279
280
281
282
A
A
A
A
A
A
A
32
16
16
16
32
32
16
A
16
2
88
FANTASY 1
283
A
16
A
16
3
88
FANTASY 2
284
A
32
A
A
16
16
2
8
89
89
WARM PAD
WARM VOX
285
286
A
B
32
16
A
A
16
16
3
2
89
90
SINE PAD
POLYSYNTH 1
287
288
A
A
16
16
A
16
8
90
POLY SAW
289
A
32
A
16
5
90
POLYSYNTH PAD 1
290
A
16
A
16
3
91
SPACE STRINGS PAD
291
A
16
2
92
BOWED PAD
292
A
16
A
16
3
92
GLASS PAD
293
A
16
A
16
2
93
ETHNIC PAD
294
A
16
A
16
2
94
HALO PAD 1
295
A
16
A
A
A
A
16
16
16
16
3
2
2
8
94
96
97
97
HALO PAD 2
RAIN DROP 1
SOUND TRACK 1
RAVE
296
297
298
299
A
A
A
A
16
16
32
32
A
32
2
98
CRYSTAL
300
A
16
3
8
1
9
58
60
61
3456
62
2
TUBA 2
FRENCH HORN SOLO
MELLOW BRASS
ANALOG SYNTH-BRASS 2
1
194
195
196
197
A
A
A
C
16
16
16
32
4
3
2
1
42
45
41
3456
46
2
3
2
63
64
SYNTH-BRASS PAD
REED/PIPE
SOPRANO SAX
198
199
A
A
16
32
8
2
46
48
1
2
65
65
ALTO SAX 1
ALTO SAX 2
200
201
A
A
32
16
2
16
49
48
8
3
6
65
65
65
BREATHY A.SAX
HARD A.SAX
RICH A.SAX
202
203
204
A
A
A
16
16
32
3
8
32
48
48
48
1
2
8
9
2
66
66
66
66
67
TENOR SAX 1
TENOR SAX 2
BREATHY T.SAX
T.SAXYS
BARITONE SAX
205
206
207
208
209
A
A
A
A
A
32
32
16
32
32
2
2
3
2
8
50
51
51
52
52
2
2
8
68
71
64
OBOE
CLARINET
BREATHY S.SAX
211
210
212
A
A
A
32
32
16
2
2
8
53
54
54
5
4
9
7
65
65
65
65
SOFT A.SAX
SOLO A.SAX
SAX SECTION
SAX SECTION SFZ
213
214
215
216
A
A
A
A
16
16
16
16
2
4
4
4
55
50
51
48
3
66
DETUNE T.SAX
217
A
32
3
49
5
66
SOFT T.SAX
218
A
16
4
49
4
66
SOLO T.SAX
219
A
16
1
48
4
68
SOLO OBOE
220
A
32
3
50
4
2
2
1
8
4
71
72
73
73
73
72
VELO.CLARINET
PICCOLO 1
FLUTE 1
FLUTE 2
PURE FLUTE
PIPE SECTION 1
221
222
223
224
225
226
A
A
A
A
A
A
32
16
16
32
32
16
9
3
4
3
1
9
52
52
52
53
54
54
2
2
2
2
74
75
76
77
RECORDER
PAN FLUTE 1
BOTTLE BLOW
SHAKUHACHI
227
228
229
230
A
C
C
32
32
32
2
2
2
56
57
58
2
2
3
4
78
79
72
73
WHISTLE 1
OCARINA
PICCOLO 2
PIPE SECTION 2
231
232
233
234
A
A
C
C
32
16
16
32
2
2
2
16
59
60
60
61
5
3
3
73
78
75
SOFT FLUTE
WHISTLE 2
PAN FLUTE 2
SYNTH-LEAD
235
236
237
A
A
A
A
16
16
16
16
3
8
4
5
61
61
61
61
2
5
5
2
8
8
32
80
80
83
81
81
81
80
SQUARE LEAD 1
SQUARE PULSE LEAD
SEQUENCE LEAD
SAW LEAD 1
MELLOW SAW LEAD
SEQUENCE SAW 1
SINE LEAD
238
239
240
241
242
243
244
A
A
A
A
A
A
A
16
16
32
16
16
32
32
6
8
2
2
1
8
4
61
62
62
63
62
56
56
9
3
80
81
VELO.SINE LEAD
SS LEAD
245
246
C
C
16
32
4
1
57
57
CELLO SECTION
1
141
A-2
OCTAVE PIZZICATO
DOUBLE VIOLA
HARP 2
CHORUS HARP
ENSEMBLE
142
143
144
145
STRINGS
SLOW STRINGS 1
WIDE STRINGS
OCTAVE STRINGS 1
CHAMBER
146
147
148
149
150
STRINGS SFZ
SYNTH-STRINGS 1
SYNTH-STRINGS 2
SYNTH-STRINGS 3
CHOIR AAHS
CHOIRS 1
151
152
153
154
155
156
VOICE DOO
SYNTH-VOICE 1
SYNTH-VOICE PAD
ORCHESTRA HIT
HARP & STRINGS
157
158
159
160
161
FLUTE & STRINGS
ORCHESTRA STRINGS
SLOW STRINGS 2
STRINGS VOICE
OCTAVE STRINGS 2
FAST SYNTH STRINGS
SLOW CHOIR
CHOIR STRINGS
162
163
164
165
166
167
168
169
CHOIRS 2
VOICE UUH
SYNTH-VOICE 2
CHORUS SYNTH-VOICE
BRASS
TRUMPET
170
171
172
173
174
TROMBONE
TUBA 1
MUTE TRUMPET
FRENCH HORN
175
176
177
178
HORN ORCHESTRA
BRASS
BRASS SECTION 1
BRASS SFZ
BRASS & STRINGS
HARD BRASS
BRASS SECTION 2
179
180
181
182
183
184
185
ANALOG SYNTH-BRASS 1
SYNTH-BRASS 1
SYNTH-BRASS 2
TRANCE BRASS
MELLOW TRUMPET
VELO.TRUMPET
VELO.TROMBONE
MELLOW TROMBONE
186
187
188
189
190
191
192
193
A
A
A
32
32
32
0
0
0
36
37
38
3456
2
GM SLAP BASS 1
GM SLAP BASS 2
GM SYNTH-BASS 1
1
411
409
410
A
A
A
32
16
16
A
A
A
A
A
A
A
32
32
32
32
32
32
32
0
0
0
0
0
0
0
39
40
41
42
43
44
45
GM SYNTH-BASS 2
GM VIOLIN
GM VIOLA
GM CELLO
GM CONTRABASS
GM TREMOLO STRINGS
GM PIZZICATO
412
413
414
415
416
417
418
A
A
A
A
A
A
A
32
32
32
16
32
16
32
A
A
A
32
32
32
0
0
0
46
47
48
GM HARP
GM TIMPANI
GM STRINGS 1
419
420
421
A
A
A
16
16
16
A
A
A
A
A
A
A
32
32
32
32
32
16
16
0
0
0
0
0
0
0
49
50
51
52
53
54
55
GM STRINGS 2
GM SYNTH-STRINGS 1
GM SYNTH-STRINGS 2
GM CHOIR AAHS
GM VOICE DOO
GM SYNTH-VOICE
GM ORCHESTRA HIT
422
423
424
425
426
427
428
A
A
A
A
A
A
16
16
16
16
32
32
A
A
A
A
A
32
32
32
32
16
0
0
0
0
0
56
57
58
59
60
GM TRUMPET
GM TROMBONE
GM TUBA
GM MUTE TRUMPET
GM FRENCH HORN
429
430
431
432
433
A
A
A
A
A
16
32
16
32
16
A
A
A
A
A
A
A
32
32
16
32
32
32
32
0
0
0
0
0
0
0
61
62
63
64
65
66
67
GM BRASS
GM SYNTH-BRASS 1
GM SYNTH-BRASS 2
GM SOPRANO SAX
GM ALTO SAX
GM TENOR SAX
GM BARITONE SAX
434
435
436
437
438
439
440
A
A
A
A
A
A
A
32
32
32
32
16
32
32
A
A
A
A
A
A
32
32
32
32
32
32
0
0
0
0
0
0
68
69
70
71
72
73
GM OBOE
GM ENGLISH HORN
GM BASSOON
GM CLARINET
GM PICCOLO
GM FLUTE
441
442
443
444
445
446
A
A
A
A
A
A
32
32
16
16
16
16
Appendix/Apéndice
A
A
A
A
A
A
A
A
A
A
32
32
16
16
32
32
16
16
16
16
0
0
0
0
0
0
0
0
0
0
74
75
76
77
78
79
80
81
82
83
GM RECORDER
GM PAN FLUTE
GM BOTTLE BLOW
GM SHAKUHACHI
GM WHISTLE
GM OCARINA
GM SQUARE LEAD
GM SAW LEAD
GM CALLIOPE
GM CHIFF LEAD
447
448
449
450
451
452
453
454
455
456
A
A
A
A
A
A
A
A
A
A
16
32
16
32
16
32
32
32
32
32
A
A
A
A
A
16
16
16
16
16
0
0
0
0
0
84
85
86
87
88
GM CHARANG
GM VOICE LEAD
GM FIFTH LEAD
GM BASS+LEAD
GM FANTASY
457
458
459
460
461
A
A
A
A
A
32
32
32
32
32
A
A
16
16
0
0
89
90
GM WARM PAD
GM POLYSYNTH
462
463
A
A
32
32
8
1
16
72
3456
111
107
2
DI ZI
YANG QIN & ER HU
ZHENG
1
355
356
357
A
A
A
16
16
16
1
2
2
98
99
3456
100
2
8
32
32
111
105
109
SUO NA
PI PA 1
SHENG
358
359
360
A
A
A
16
16
16
2
2
2
101
102
103
5
107
KOTO PAD
361
A
16
8
103
3
104
SITAR 2
362
A
16
1
88
8
4
104
104
TAMBRA
SITAR PAD
363
364
A
A
16
16
4
5
89
89
8
4
105
105
RABAB
PI PA 2
365
366
A
A
16
16
1
1
89
90
3
4
3
4
106
107
107
106
SHAMISEN 2
DETUNE KOTO
SYNTH-KOTO
SHAMISEN & TAIKO
367
368
369
370
A
A
A
A
16
16
16
16
6
4
2
1
89
90
91
91
32
16
77
15
XIAO
SANTUR
371
372
A
A
16
16
1
3
92
93
0
0
0
1
GM TONES
GM PIANO 1
GM PIANO 2
373
374
A
A
A
16
16
16
4
1
1
93
93
94
0
0
0
0
2
3
4
5
GM PIANO 3
GM HONKY-TONK
GM E.PIANO 1
GM E.PIANO 2
375
376
377
378
A
A
A
A
16
16
16
16
4
2
1
1
94
95
95
96
0
0
0
0
0
0
0
6
7
8
9
11
10
12
GM HARPSICHORD
GM CLAVI
GM CELESTA
GM GLOCKENSPIEL
GM MUSIC BOX
GM VIBRAPHONE
GM MARIMBA
379
380
381
382
383
384
385
A
A
A
A
A
A
A
16
16
16
16
16
16
16
3
3
1
5
3
8
16
96
97
97
98
98
98
98
0
0
0
0
0
0
13
14
15
16
17
18
GM XYLOPHONE
GM TUBULAR BELL
GM DULCIMER
GM ORGAN 1
GM ORGAN 2
GM ORGAN 3
386
387
388
389
390
391
A
A
A
A
A
A
16
16
16
16
16
16
5
1
1
3
1
3
99
99
100
100
102
102
0
0
0
0
0
0
19
20
21
22
23
24
GM PIPE ORGAN
GM REED ORGAN
GM ACCORDION
GM HARMONICA
GM BANDONEON
GM NYLON STR.GUITAR
392
393
394
395
396
397
A
A
A
A
A
16
16
16
16
32
4
1
2
1
2
102
103
104
104
105
0
25
GM STEEL STR.GUITAR
398
A
32
1
105
0
0
0
0
26
27
28
29
GM JAZZ GUITAR
GM CLEAN GUITAR
GM MUTE GUITAR
GM OVERDRIVE GT
399
400
401
402
A
A
A
A
32
32
16
32
2
1
2
2
106
106
107
108
0
0
0
0
0
0
30
31
32
33
34
35
GM DISTORTION GT
GM GT HARMONICS
GM ACOUSTIC BASS
GM FINGERED BASS
GM PICKED BASS
GM FRETLESS BASS
403
404
405
406
407
408
A
A
A
A
A
A
32
16
32
32
32
16
2
2
8
9
8
9
15
111
114
15
110
110
SOFT CRYSTAL
1
301
ATMOSPHERE
BRIGHTNESS 1
GOBLIN
ECHO PAD
STAR THEME 1
302
303
304
305
306
SPACE PAD
307
NEW AGE PAD
308
SOFT PAD
309
HORN PAD
310
THICK PAD
311
POLYSYNTH 2
OLD TAPE PAD
POLYSYNTH PAD 2
HEAVEN
312
313
314
315
UTOPIA
316
SQUARE PAD
317
SOFT METAL PAD
318
HARD METAL PAD
319
TINE PAD
320
CHORUS PAD
321
ORGAN CHOIR PAD
322
SWEEP PAD
323
SWEEP CHOIR
CLAVI PAD
RAIN DROP 2
SOUND TRACK 2
SPACE VOICE
324
325
326
327
328
CHORAL BELL
GLOCKENSPIEL CHIME
CHRISTMAS BELL
VIBRAPHONE BELL
NYLON+EP
CELESTA PAD
BRIGHT BELL PAD
BRIGHTNESS 2
329
330
331
332
333
334
335
336
ECHO VOICE
ECHO DROP
POLY DROP
STAR THEME 2
ETHNIC/CHINESE
337
338
339
340
SITAR 1
341
WARM SITAR
342
BANJO
MUTE BANJO
SHAMISEN 1
TSUGARU
343
344
345
346
KOTO
THUMB PIANO
SHANAI
STEEL DRUMS
347
348
349
350
ER HU 1
ER HU 2
YANG QIN 1
351
352
353
YANG QIN 2
354
A-3
Appendix/Apéndice
........Notes in these ranges are produced by playing the notes in range b that are in the
nearest octave as the result of transpose and message receive operations.
........Las notas en estas gamas se producen ejecutando las notas en la gama b que se
encuentre en la octava más cercana como resultado de las operaciones de
transposición y recepción de mensajes.
a
........Keyboard range
........Gama del teclado
b
........Available range (using transpose or message receive)
........Gama disponible (usando la transposición o recepción de mensajes)
c
C-1 C9C8C7
G7
C6C5C4C3
C2C1
C0
E0
E1
E2
G6 G8 G9
A=440Hz
No scale for tones.
Sin escala para los sonidos.
D
(Sound Effect)
(Efecto de sonido)
B
040 GLOCKENSPIEL/
052 CHORUS GLOCKENSPIEL/
222 PICCOLO 1/
233 PICCOLO 2
C
Instrumentos de
altura tonal baja
Low pitch
instruments
Range Type/Tipo de gama
A
(Standard type)
(Tipo estándar)
040 GLOCKENSPIEL/
052 CHORUS GLOCKENSPIEL/
222 PICCOLO 1/
233 PICCOLO 2
<CTK-810>
<WK-110>
<CTK-810>
<WK-110>
<CTK-810>
<WK-110>
The meaning of each range type is described below.
NOTE
El significado de cada tipo de gama se describe debajo.
NOTA
3456
2
1
A-4
A
A
16
16
0
0
91
92
GM SPACE CHOIR
GM BOWED GLASS
464
465
A
16
0
93
GM METAL PAD
466
A
A
16
16
0
0
94
95
GM HALO PAD
GM SWEEP PAD
467
468
A
A
A
A
A
A
16
16
16
16
16
16
0
0
0
0
0
0
96
97
98
99
100
101
GM RAIN DROP
GM SOUND TRACK
GM CRYSTAL
GM ATMOSPHERE
GM BRIGHTNESS
GM GOBLINS
469
470
471
472
473
474
A
A
A
16
16
16
0
0
0
102
103
104
GM ECHOES
GM SF
GM SITAR
475
476
477
A
A
A
32
32
32
0
0
0
105
106
107
GM BANJO
GM SHAMISEN
GM KOTO
478
479
480
A
A
A
A
32
16
32
32
0
0
0
0
111
110
108
109
GM THUMB PIANO
GM BAGPIPE
GM FIDDLE
GM SHANAI
481
482
483
484
A
A
A
D
32
32
16
32
0
0
0
0
112
113
114
115
GM TINKLE BELL
GM AGOGO
GM STEEL DRUMS
GM WOOD BLOCK
485
486
487
488
D
32
0
116
GM TAIKO
489
A
D
D
D
32
32
32
32
0
0
0
0
117
118
119
120
GM MELODIC TOM
GM SYNTH-DRUM
GM REVERSE CYMBAL
GM GT FRET NOISE
490
491
492
493
A
D
D
D
D
32
16
16
32
32
0
0
0
0
0
121
122
123
124
125
GM BREATH NOISE
GM SEASHORE
GM BIRD
GM TELEPHONE
GM HELICOPTER
494
495
496
497
498
D
D
D
D
D
D
16
32
0
0
120
120
120
120
0
1
2
126
127
GM APPLAUSE
GM GUNSHOT
DRUM SET
499
500
4
STANDARD SET 1
STANDARD SET 2
STANDARD SET 3
STANDARD SET 4
501
502
503
504
D
D
D
D
120
120
120
120
8
16
65
64
ROOM SET
POWER SET
ROCK SET
HIPHOP SET
505
506
507
508
D
D
D
D
D
D
120
120
120
120
120
120
24
25
30
31
32
40
ELECTRONIC SET
SYNTH SET 1
SYNTH SET 2
TRANCE SET
JAZZ SET
BRUSH SET
511
509
510
512
513
514
D
120
48
ORCHESTRA SET
515
C-1
D-1
E-1
F-1
G-1
A-1
B-1
C0
D0
E0
F0
G0
A0
B0
C1
D1
E1
F1
G1
A1
B1
C2
D2
E2
F2
G2
A2
B2
C3
D3
E3
F3
G3
A3
B3
C4
D4
E4
F4
G4
A4
B4
C5
D5
E5
F5
G5
A5
B5
C6
D6
E6
F6
G6
A6
B6
C7
D7
E7
1
3
5
6
8
10
12
13
15
17
18
20
22
24
25
27
29
30
32
34
36
37
39
41
42
44
46
48
49
51
53
54
56
58
60
61
63
65
66
68
70
72
73
75
77
78
80
82
84
85
87
89
90
92
94
96
97
99
101
Key/
Note number
DRUMS SET LIST
2
4
7
9
11
14
16
19
21
23
26
28
31
33
35
38
40
43
45
47
50
52
55
57
59
62
64
67
69
71
74
76
79
81
83
86
88
91
93
95
98
100
C#-1
E
-1 F#-1
A
-1 B
-1
C#0
E
0
F#0
A
0
B
0
C#1
E
1
F#1
A
1
B
1
C#2
E
2
F#2
A
2
B
2
C#3
E
3
F#3
A
3
B
3
C#4
E
4
F#4
A
4
B
4
C#5
E
5
F#5
A
5
B
5
C#6
E
6
F#6
A
6
B
6
C#7
E
7
SYNTH SET 2
TRANCE SET JAZZ SET BRUSH SET
ORCHESTRA SET
———————————————————————————씯씯씯씯씯씯씯씯
Synth2 Kick 2
Synth2 Kick 1씯Synth2 Snare 1씯Synth2 Snare 2씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯Synth1 Cowbell씯씯씯씯씯씯씯씯씯씯씯씯씯Synth1 Maracas씯씯씯씯
Synth1 Claves씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
——————————————————————————Trance Open Hi-Hat 3
씯씯씯씯씯씯씯씯Synth2 Kick 2
Trance Kick
Side Stick 2
Trance Snare 1
Hand Clap 3
Trance Snare 2씯Trance Closed Hi-Hat
Trance Open Hi-Hat 1
Trance Open Hi-Hat 2
씯씯씯씯씯씯씯
Trance Tambourine씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————씯씯씯씯씯씯씯씯
Jazz Kick 2
Jazz Kick 1씯Brush Snare 1
Brush Slap
Brush Snare 2씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————
Closed Hi-Hat
Pedal Hi-Hat
Open Hi-Hat
Ride Cymbal 1씯씯씯씯
Jazz Kick 1
Concert BD 1씯Concert SD
Castanets
Concert SD
Timpani F
Timpani F#
Timpani G
Timpani G#
Timpani A
Timpani A#
Timpani B
Timpani c
Timpani c#
Timpani d
Timpani d#
Timpani e
Timpani f씯씯씯Concert Cymbal 2씯Concert Cymbal 1씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
———————————————————————————씯씯씯씯씯씯씯씯
Jazz Kick 2
Jazz Kick 1씯Jazz Snare 1씯Jazz Snare 2씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
STANDARD SET 1 STANDARD SET 2 STANDARD SET 3
ROOM SET
POWER SET
ROCK SET HIP-HOP SET
ELECTRONIC SET
SYNTH SET 1
STANDARD SET 4
———————————————————————————
High Q
Slap
Scratch Push
Scratch Pull
Sticks
Square Click
Metronome Click
Metronome Bell
Standard1 Kick 2
Standard1 Kick 1
Side Stick 1
Standard1 Snare 1
Hand Clap 1
Standard1 Snare 2
Low Tom 2
Closed Hi-Hat
Low Tom 1
Pedal Hi-Hat
Mid Tom 2
Open Hi-Hat
Mid Tom 1
High Tom 2
Crash Cymbal 1
High Tom 1
Ride Cymbal 1
Chinese Cymbal
Ride Bell
Tambourine
Splash Cymbal
Cowbell
Crash Cymbal 2
Vibraslap
Ride Cymbal 2
High Bongo
Low Bongo
Mute High Conga
Open High Conga
Open Low Conga
High Timbale
Low Timbale
High Agogo
Low Agogo
Cabasa
Maracas
Short High Whistle
Long Low Whistle
Short Guiro
Long Guiro
Claves
High Wood Block
Low Wood Block
Mute Cuica
Open Cuica
Mute Triangle
Open Triangle
Shaker
Jingle Bell
Bell Tree
Castanets
Mute Surdo
Open Surdo
Applause 1
Applause 2
Fanfare——————————
———————————————————————————씯씯씯씯씯씯씯씯
Standard2 Kick 2
Standard2 Kick 1씯Standard2 Snare 1
Hand Clap 2
Standard2 Snare 2씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————씯씯씯씯씯씯씯씯
Standard3 Kick 2
Standard3 Kick 1씯Standard3 Snare 1씯Standard3 Snare 2
Low Tom 4
Standard3 Closed Hi-Hat
Low Tom 3
Standard3 Pedal Hi-Hat
Mid Tom 4
Standard3 Open Hi-Hat
Mid Tom 3
High Tom 4
Crash Cymbal 3
High Tom 3
Ride Cymbal 3씯씯씯씯씯Crash Cymbal 4씯Ride Cymbal 4씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
Standard4 Kick 1
Standard4 Kick 2
Standard4 Kick 3
Standard4 Snare 1
Standard4 Snare 2
Standard4 Snare 3
Standard4 Closed Hi-Hat 1
Standard4 Closed Hi-Hat 2
Standard4 Open Hi-Hat 1
Standard4 Open Hi-Hat 2
—————————————————씯씯씯씯씯씯씯씯
Standard4 Kick 2
Standard3 Kick 1
Side Stick 3
Standard4 Snare 2씯Standard4 Snare 4
Standard4 Closed Hi-Hat 2
Rock Pedal Hi-Hat
Standard4 Open Hi-Hat 2
씯씯Rock Crash Cymbal씯씯씯씯씯씯씯Crash Cymbal 4씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
———————————————————————————씯씯씯씯씯씯씯씯
Power K ick 2
Power K ick 1씯Power Snare 1씯Power Snare 2
Power Low Tom 2씯Power Low Tom 1씯Power Mid Tom 2씯Power Mid Tom 1
Power High Tom 2씯Power High Tom 1씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————씯씯씯씯씯씯씯씯
Rock Kick 2
Rock Kick 1씯Rock Snare 1씯Rock Snare 2
Low Tom 4
Rock Closed Hi-Hat
Low Tom 3
Rock Pedal Hi-Hat
Mid Tom 4
Rock Open Hi-Hat
Mid Tom 3
High Tom 4
Rock Crash Cymbal
High Tom 3
Ride Cymbal 3씯씯씯Rock Splash Cymbal씯Crash Cymbal 4씯Ride Cymbal 4씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
———————————————————————————씯씯씯씯씯씯씯씯
Room Kick 2
Room Kick 1씯Room Snare 1씯Room Snare 2
Room Low Tom 2씯Room Low Tom 1씯Room Mid Tom 2씯Room Mid Tom 1
Room High Tom 2씯Room High Tom 1씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————씯씯씯씯씯씯씯씯
Elec. Kick 2
Elec. Kick 1씯Elec. Snare 1씯Elec. Snare 2
Elec. Low Tom 2씯Elec. Low Tom 1씯Elec. Mid Tom 2씯Elec. Mid Tom 1
Elec. High Tom 2씯Elec. High Tom 1씯Reverse Cymbal씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯——————————
———————————————————————————씯씯씯씯씯씯씯씯
Synth1 Kick 2
Synth1 Kick 1
Synth1 Rim Shot
Synth1 Snare 1
Hand Clap 2
Synth1 Snare 2
Synth1 Low Tom 2
Synth1 Closed HH 1
Synth1 Low Tom 1
Synth1 Closed HH 2
Synth1 Mid Tom 2
Synth1 Open HH
Synth1 Mid Tom 1
Synth1 High Tom 2
Synth1 Crash Cymbal
Synth1 High Tom 1
Synth1 Ride Cymbal
씯씯Synth1 Tambourine씯Synth1 Cowbell씯씯씯Synth1 High Bongo
Synth1 Low Bongo
Synth1 Mute Hi Conga
Synth1 Open Hi Conga
Synth1 Open Low Conga씯씯씯씯씯Synth1 Maracas씯씯씯씯
Synth1 Claves씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
———————————————————————————씯씯씯씯씯씯씯씯
HipHop Kick 2
HipHop Kick 1
Side Stick 2
HipHop Snare 1
Hand Clap 3
HipHop Snare 2
Low Tom 4
HipHop Closed Hi-Hat
Low Tom 3
HipHop Pedal Hi-Hat
Mid Tom 4
HipHop Open Hi-Hat
Mid Tom 3
High Tom 4
Crash Cymbal 3
High Tom 3
Ride Cymbal 3씯씯씯Rock Splash Cymbal씯Crash Cymbal 4씯Ride Cymbal 4씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯씯—————————
Appendix/Apéndice
ón de batería
Drum Assignment List/Lista de asignaci
A-5
F7
G7
A7
B7
C8
D8
E8
F8
G8
A8
B8
C9
D9
E9
F9
G9
102
104
106
108
109
111
113
114
116
118
120
121
123
125
126
128
F#7
A 7
B 7
C#8
E 8
F#8
A 8
B 8
C#9
E 9
F#9
Key/
Note number
DRUMS SET LIST
103
105
107
110
112
115
117
119
122
124
127
SYNTH SET 2
TRANCE SET JAZZ SET BRUSH SET
ORCHESTRA SET
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
STANDARD SET 1 STANDARD SET 2 STANDARD SET 3
ROOM SET
POWER SET
ROCK SET HIP-HOP SET
ELECTRONIC SET
SYNTH SET 1
STANDARD SET 4
———————
One
Two
Three
Four
Five—————Piko Piko————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
———————씯씯씯씯씯—————씯—————————
Appendix/Apéndice
Indicates the same sound as STANDARD SET 1.
Indica el mismo sonido que STANDARD SET 1.
A-6
•“
NOTE
•“
NOTA
FINGERED Chord Chart Cuadro de acordes digitados
Chord
Type
Root
C
C/(D)
D
(D)/E
E
F
F/(G)
G
(G)/A
A
(A)/B
B
mM
Appendix/Apéndice
M77 m7 dim7
*
*
*
dim m7
-5
Chord
Type
Root
C
C/(D)
D
(D)/E
E
F
F/(G)
G
(G)/A
A
(A)/B
B
sus4aug add97
7sus4 m add9 mM7
-5
<CTK-810 only>
* These chords can be
fingered if you expand the accompaniment area of the keyboard by changing the split point. For details, see Using Split on page E-45.
<Sólo CTK-810>
* Estos acordes se pueden
digitar si expande el área de acompañamiento del teclado cambiando el punto de división. Para más información, vea Usando la división” en la página S-45.
*
*
A-7
Appendix/Apéndice
Rhythm List Lista de ritmos
8 BEAT / 16 BEAT
001 STRAIGHT 8 BEAT 002 MELLOW 8 BEAT 003 MODERN 8 BEAT 004 GUITAR 8 BEAT 005 8 BEAT POP 006 8 BEAT 007 60S 8 BEAT 008 16 BEAT 1 009 16 BEAT 2 010 16 BEAT SHUFFLE 1 011 16 BEAT SHUFFLE 2
BALLAD
012 MODERN BALLAD 013 SLOW BALLAD 014 16 BEAT BALLAD 015 SOUL BALLAD 016 POP BALLAD 1 017 POP BALLAD 2 018 6/8 BALLAD 019 ROCK BALLAD 1 020 ROCK BALLAD 2
DANCE
021 HIP-HOP 022 RAP POP 023 DANCE POP 024 DISCO POP 025 TECHNO POP 026 TRANCE 027 MODERN R&B 1 028 MODERN R&B 2 029 MODERN DANCE 030 DISCO SOUL
POPS
031 POP 1 032 POP 2 033 POP ROCK 034 GUITAR POP 035 FAST SOUL 036 SLOW SOUL 037 60S SOUL
ROCK
038 SHUFFLE ROCK 1 039 SHUFFLE ROCK 2 040 BLUES 041 SOFT ROCK 042 LATIN ROCK 043 MODERN ROCK 044 SLOW ROCK 045 NEW ORLNS R&R 046 ROCK WALTZ
JAZZ
047 SLOW BIG BAND 048 MIDDLE BIG BAND 049 FAST BIG BAND 050 SWING 1 051 SWING 2 052 SLOW SWING 053 JAZZ WALTZ 1 054 JAZZ WALTZ 2 055 FOX TROT 056 QUICKSTEP 057 JAZZ COMBO 1
EUROPEAN
058 SCHLAGER 059 POLKA 060 POP POLKA 061 WALTZ 1 062 SLOW WALTZ 063 VIENNESE WALTZ 064 FRENCH WALTZ 065 SERENADE 066 TANGO 067 MARCH 1 068 MARCH 2
LATIN
069 BOSSA NOVA 1 070 BOSSA NOVA 2 071 BEGUINE 072 SAMBA 1 073 SAMBA 2 074 MAMBO 075 RHUMBA 076 CHA-CHA-CHA 077 MERENGUE 078 BOLERO 079 SALSA 080 REGGAE 081 POP REGGAE 082 PUNTA 083 SKA
VARIOUS
084 COUNTRY 8 BEAT 085 COUNTRY BALLAD 086 COUNTRY SHUFFLE 087 BLUEGRASS 088 DIXIE 089 TEX-MEX 090 FAST GOSPEL 091 SLOW GOSPEL 092 PASODOBLE 093 FOLKLORE
094 SIRTAKI 095 HAWAIIAN 096 ADANI 097 BALADI 098 ENKA 099 SYMPHONY 100 STR QUARTET
FOR PIANO
101 PIANO 8 BEAT 102 PIANO BALLAD 1 103 PIANO BALLAD 2 104 EP BALLAD 1 105 EP BALLAD 2 106 BLUES BALLAD 107 JAZZ COMBO 2 108 JAZZ COMBO 3 109 RAGTIME 110 PIANO ROCK & ROLL 111 BOOGIE-WOOGIE 112 ARPEGGIO 1 113 ARPEGGIO 2 114 ARPEGGIO 3 115 6/8 MARCH 116 MARCH 3 117 STRIDE PIANO 118 WALTZ 2 119 WALTZ 3 120 WALTZ 4
NOTE
Some rhythms (No. 110, 112 to 120) consist of chord accompaniments only, without any drums or other percussion instruments. Such rhythms do not sound unless CASIO CHORD, FINGERED, or FULL RANGE CHORD is selected as the accompaniment mode.
NOTA
Algunos ritmos (NO 110, 112 a 120) consisten solamente de los acompañamientos de acordes, sin ninguna batería ni otros instrumentos de percusión. Tales ritmos no suenan a menos que CASIO CHORD, FINGERED o FULL RANGE CHORD se seleccione como el modo de acompañamiento.
A-8
Song List/Lista de canciones
SONG BANK List Lista SONG BANK
Appendix/Apéndice
DEMO TUNES
CTK-810
001 GROOVEE! 002 WHATEVER WILL BE WILL BE (QUE SERA SERA)
003 ARIANFOR
WK-110
001 ARIANFOR 002 WHATEVER WILL BE WILL BE (QUE SERA SERA) 003 GROOVEE!
EVENT
004 WE WISH YOU A MERRY CHRISTMAS 005 JINGLE BELLS
006 SILENT NIGHT 007 JOY TO THE WORLD
008 O CHRISTMAS TREE
WORLD
009 WHEN THE SAINTS GO MARCHING IN 010 GREENSLEEVES
011 SWING LOW, SWEET CHARIOT 012 AMAZING GRACE
013 AULD LANG SYNE 014 TWINKLE TWINKLE LITTLE STAR 015 LIGHTLY ROW 016 UNDER THE SPREADING CHESTNUT TREE 017 COME BIRDS 018 THE MUFFIN MAN
019 LONG LONG AGO 020 DID YOU EVER SEE A LASSIE?
021 LONDON BRIDGE 022 THE FARMER IN THE DELL
023 ON THE BRIDGE OF AVIGNON 024 SIPPIN CIDER THROUGH A STRAW
025 GRANDFATHERS CLOCK 026 MICHAEL ROW THE BOAT ASHORE 027 ANNIE LAURIE 028 MY BONNIE 029 MY DARLING CLEMENTINE 030 HOME SWEET HOME
031 ON TOP OF OLD SMOKEY 032 IVE BEEN WORKING ON THE RAILROAD
033 LITTLE BROWN JUG 034 AURA LEE
035 OH! SUSANNA 036 HOUSE OF THE RISING SUN
037 SHE WORE A YELLOW RIBBON 038 CAMPTOWN RACES 039 SWANEE RIVER (OLD FOLKS AT HOME) 040 JEANNIE WITH THE LIGHT BROWN HAIR 041 YANKEE DOODLE 042 RED RIVER VALLEY
043 TURKEY IN THE STRAW 044 MY OLD KENTUCKY HOME
045 HOME ON THE RANGE 046 JAMAICA FAREWELL
047 ALOHA OE 048 SAKURA SAKURA
049 SANTA LUCIA 050 WALTZING MATILDA
CONCERT PIECES
051 FÜR ELISE 052 TURKISH MARCH (MOZART)
053 PIANO SONATA op.27-2 “MOONLIGHT” 1st Mov. 054 ETUDE op.10-3 CHANSON DE L’ADIEU”
055 GYMNOPÉDIES no.1 056 THE ENTERTAINER 057 MAPLE LEAF RAG 058 HUNGARIAN DANCES no.5 059 TRÄUMEREI 060 LA FILLE AUX CHEVEUX DE LIN
061 HUMORESKE (DVO 062 PROMENADE FROM TABLEAUX DUNE EXPOSITION
063 MOMENTS MUSICAUX op.94-3 064 LE CYGNE FROM LE CARNAVAL DES ANIMAUX
065 VALSE op.64-1 PETIT CHIEN 066 CHANSON DU TOREADOR FROM “CARMEN”
067 LARGO (HÄNDEL) 068
WEDDING MARCH FROM MIDSUMMER NIGHTS DREAM 069 AMERICAN PATROL 070 CSIKOS POST 071 DOLLYS DREAMING AND AWAKENING
072 LA CHEVALERESQUE 073 PIANO SONATA K.545 1st Mov.
074 LA PRIÈRE DUNE VIERGE 075 MARCIA ALLA TURCA
076 NOCTURNE op.9-2 (CHOPIN) 077 LIEBESTRÄUME no.3
078 MARCHE MILITAIRE no.1 079 BLUMENLIED 080 GRANDE VALSE BRILLANTE op.18-1
ETUDES
081 MINUET IN G MAJOR 082 GAVOTTE (GOSSEC) 083 ARABESQUE (BURGMÜLLER) 084 CHOPSTICKS
085 FRÖHLICHER LANDMANN 086 INVENTIONEN no.1
087 AVE MARIA (GOUNOD) 088 JESUS BLEIBET MEINE FREUDE
089 CANON (PACHELBEL) 090 SONATINA op.36-1 1st Mov.
091 PIANO SONATA op.13 “PAT HÉTIQUE” 2nd Mov. 092 PRELUDE op.28-7 (CHOPIN) 093 JE TE VEUX 094 RÊVERIE 095 ODE TO JOY 096 SERENADE FROM EINE KLEINE NACHTMUSIK
097 MARCH FROM THE NUTCRACKER 098 GOING HOME FROM FROM THE NEW WORLD
099 BEAUTIFUL DREAMER 100 DANNY BOY
101 - 105
User Songs/Canciones del usuario
ÁK)
A-9
Version: 1.0
Remarks
= no relation
página A-1.
*1: See Tone List on page A-1.
*1: Vea la lista de sonidos en la
= sin relación
XX
XX
XX
v =
Bank select
Modulation
Data entry
Volume
Pan
Expression
Hold1
Sostenuto
CTK-810/WK-110
1-16
1-16
Recognized
1
1-16
Transmitted
Function ...
X
Mode 3
0-127
0 - 127 *1
❊❊❊❊❊❊❊❊❊❊❊❊❊❊
X
Mode 3
28 -103 (WK-110)
36 - 96 (CTK-810)
❊❊❊❊❊❊❊❊❊❊❊❊❊❊
Default
Altered
❊❊❊❊❊❊❊❊❊❊❊❊❊❊
X
v = 1-127
v = 0, 8nH
9nH
O*2
O
9nH X
X
X
8nH v = 64
9nH v = 1-127
X
O
Note OFF
O
O
O
O
O
O*2
X
O
1
0, 32
O*3
X
X
6, 38
O
X
O
X
X
O*4
O*4
11
64
66
MIDI messages that can be sent and received using the USB port
Models
Los mensajes MIDI pueden enviarse y recibirse usando el puerto USB
Basic Default
Channel Changed
Mode Messages
Note
Number: True voice
Velocity Note ON
After Key's
Touch Ch's
Pitch Bender
Control 7
Change 10
Soft pedal
Reverb send
Chorus send
RPN LSB, MSB
O
O
O
O*3
X
X
O
O*4
All sound off
Reset all controller
O
O
0-127 O
❊❊❊❊❊❊❊❊❊❊❊❊❊❊
X
O
0-127 O
: Yes
: No
O
X
GM DESACTIVADO: [F0] [7E] [7F] [09] [02] [F7]
vv=00: Room1, 01: Room2, 04: Hall1, 03: Hall2
vv=00: Chorus1, 01: Chorus2, 02: Chorus3, 03: Chorus4
La modulación y después del toque para cada canal tienen el mismo efecto.
FINE TUNE, recepción COARSE TUNE, y PITCH BEND SENSE, recepción RPN Null
De acuerdo con el ajuste de la toma asignable
• Tipo de reverberación [F0] [7F] [7F] [04] [05] [01] [01] [01] [01] [01] [00] [vv] [F7]
• Tipo de Chorus [F0] [7F] [7F] [04] [05] [01] [01] [01] [01] [02] [00] [vv] [F7]
2
3
X
X
X
X
X
O*5 *6
X
X
O*5
X
O
X
O
X
O
O
*
X
O
X
X
• Afinación fina maestro [F0] [7F] [7F] [04] [03] [ll] [mm] [F7]
4
5
*
*
*
Los bytes de orden inferior [II] se suponen que son 00H.
• Activación/desactivación GM GM ACTIVADO: [F0] [7E] [7F] [09] [01] [F7]
• Afinación aproximada maestro [F0] [7F] [7F] [04] [04] [ll] [mm] [F7]
• [II] indica bytes de orden inferior, y [mm] indica bytes de orden superior.
• Volumen maestro [F0] [7F] [7F] [04] [01] [ll] [mm] [F7]
6
*
67
91
93
120
121
100, 101
❊❊❊❊❊❊❊❊❊❊❊❊❊❊
Program
Change: True #
System Exclusive
System : Song Pos
Common : Song Sel
: Tune
System : Clock
Commands
: Local ON/OFF
: All notes OFF
Aux
Real Time :
vv=00: Room1, 01: Room2, 04: Hall1, 03: Hall2
Modulation and after touch for each channel are the same effect.
2
*
vv=00: Chorus1, 01: Chorus2, 02: Chorus3, 03: Chorus4
FINE TUNE, COARSE TUNE receive, and PITCH BEND SENSE, RPN Null receive
In accordance with sustain/assignable jack setting
• Reverb Type [F0] [7F] [7F] [04] [05] [01] [01] [01] [01] [01] [00] [vv] [F7]
• Chorus Type [F0] [7F] [7F] [04] [05] [01] [01] [01] [01] [02] [00] [vv] [F7]
3
4
5
*
*
*
Low-order bytes [ll] are assumed to be 00H.
GM on/off GM ON : [F0] [7E] [7F] [09] [01] [F7] GM OFF : [F0] [7E] [7F] [09] [02] [F7]
• Master Fine Tune [F0] [7F] [7F] [04] [03] [ll] [mm] [F7]
• Master Coarse Tune [F0] [7F] [7F] [04] [04] [ll] [mm] [F7]
• Master Volume [F0] [7F] [7F] [04] [01] [ll] [mm] [F7]
• [ll] indicates low-order bytes, [mm] indicates high order bytes.
6
*
: Reset
Messages : Active Sense
Remarks
Mode 1 : OMNI ON, POLY Mode 2 : OMNI ON, MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO
This recycle mark indicates that the packaging conforms to the environmental protection legislation in Germany.
Esta marca de reciclaje indica que el empaquetado se ajusta a la legislación de protección ambiental en Alemania.
CASIO COMPUTER CO.,LTD.
6-2, Hon-machi 1-chome
Shibuya-ku, Tokyo 151-8543, Japan
C
MA0702-A Printed in China
CTK810/WK110ES1A
Loading...
