Contents

General Guide ...........................EN-2

Using the 10-key Pad (bp)...................................EN-4

Using the FUNCTION Button (

).......................EN-4

Getting Ready to Play ..............EN-5

Preparing the Music Stand ...................................EN-5

Power Supply .......................................................EN-5

Playing the Digital Keyboard...EN-6

Turning on Power and Playing .............................EN-6

Using Headphones ...............................................EN-6

Using the Metronome ...........................................EN-7

Controlling the

Keyboard Sounds .....................EN-8

Select from a variety of musical

instrument sounds ................................................EN-8

Using Reverb........................................................EN-9

Using a Pedal .......................................................EN-9

Changing the Pitch (Transpose, Tuning)............EN-10

Sampling a Sound and Playing it on the Keyboard

(Sampling) ...............................EN-11

Playing the SAMPLING DEMO ..........................EN-11

Sampling a Sound and Playing It .......................EN-11

Sounding Sampled Sounds ................................EN-13

Applying an Effect to a Sound Sample ...............EN-14

Using a Sampled Sound in a Rhythm

(VOICE PERCUSSION) .....................................EN-15

Starting a Sampling Operation Manually ............EN-15

Deleting Sampled Data.......................................EN-15

Enabling or Disabling the Sampling Play Back...EN-16 Enabling or Disabling Auto Incrementing

during Short Sampling ........................................EN-16

Playing Built-in Songs........... EN-17

Playing the Demo Songs ....................................EN-17

Playing Back a Particular Song ..........................EN-17

Using Built-in Songs to

Master Keyboard Play ........... EN-21

Phrases ..............................................................EN-21

Step Up Lesson Flow .........................................EN-21

Selecting the Song, Phrase,

and Part You Want to Practice ...........................EN-22

Lessons 1, 2, and 3 ............................................EN-23

Lesson Settings ..................................................EN-24

Using Auto Step Up Lesson ...............................EN-25

Using Auto

Accompaniment ..................... EN-27

Playing the Rhythm Part only .............................EN-27

Playing All Parts .................................................EN-28

Using Auto Accompaniment Effectively ..............EN-30

Using One-Touch Preset ....................................EN-31

Connecting External

Devices ................................... EN-32

Connecting a Computer......................................EN-32

MIDI Settings......................................................EN-33

Connecting to Audio Equipment .........................EN-35

Reference................................ EN-36

Troubleshooting..................................................EN-36

Specifications .....................................................EN-38

Operating Precautions........................................EN-39

Song List.............................................................EN-40

Fingering Guide ..................................................EN-41

Chord Example List ............................................EN-42

MIDI Implementation Chart

English

Included Accessories

● Music Stand

● Song Book

● Leaflets

• Safety Precautions

• Appendix

• Other (Warranty, etc.)

Items included as accessories are subject to change without notice.

Separately Available Accessories

• You can get information about accessories that are separately for this product from the CASIO catalog available from your retailer, and from the CASIO website at the following URL.

http://world.casio.com/

EN-1

General Guide

• In this manual, the term “Digital Keyboard” refers to the CTK-2090/CTK-2400.

• Illustrations in this User’s Guide show the CTK-2400.

• In this manual, buttons and other controllers are identified using the numbers shown below.

1 2 34

6789bk bl

cm cn co cqcp cr cs cm

bm bp

bnbo

bq br bs bt ck cl

EN-2

ct dk

General Guide

• The following explains the meaning of the $ symbol that appears on the product console and with the key names below. $ : Indicates a function that is enabled by holding down the button for some time.

P(POWER) button ☞EN-6

VOLUME slider ☞EN-6

FUNCTION button ☞EN-4

METRONOME, $ BEAT button ☞EN-7

TEMPO buttons ☞EN-7, 19, 31

REPEAT, INTRO button ☞EN-18, 30

REW, NORMAL/FILL-IN button ☞EN-18, 30

FF, VAR./FILL-IN button ☞EN-18, 30

PAUSE, SYNCHRO/ENDING button ☞EN-18, 30

PLAY/STOP, START/STOP button ☞EN-11, 17, 27

PART SELECT, ACCOMP/$ CHORDS button

☞EN-20, 28

TONE, SAMPLING DEMO button ☞EN-8, 11

RHYTHM, ONE TOUCH PRESET $ button

☞EN-12, 27, 31

SONG BANK button ☞EN-11, 17

Number buttons, [–]/[+] keys ☞EN-4

SAMPLED TONES/EFFECTS 1,

LISTEN button ☞EN-14, 23

SAMPLED TONES/EFFECTS 2,

WATCH button ☞EN-14, 23

SAMPLED TONES/EFFECTS 3,

REMEMBER button ☞EN-14, 24

SAMPLED TONES/EFFECTS 4, NEXT button

☞EN-14, 22

SAMPLED TONES/EFFECTS 5, AUTO button

☞EN-14, 25

VOICE PERCUSSION, LESSON button ☞EN-15, 22

Speakers

Song Bank list

Built-in microphone

Display

SAMPLING button ☞EN-11

Rhythm list

Tone list

CHORD root names ☞EN-28

Percussion instrument list ☞EN-8

English

■ Back

dl dm

USB port ☞EN-32

SUSTAIN jack ☞EN-9

dn do dp

AUDIO IN jack ☞EN-11, 35

DC 9.5V terminal ☞EN-5

PHONES/OUTPUT jack ☞EN-6, 35

EN-3

General Guide

Using the 10-key Pad (bp)

Use the number buttons and the [–] and [+] keys to change the settings of the parameters that appear in the upper left area of the display.

Setting

Mde r nPno

Number Buttons

Use the number buttons to enter numbers and values.

• Enter the same number of digits as the currently displayed

value. Example: To enter tone number 004, input 0 3 0 3 4.

• Negative values cannot be input using the number buttons.

Use [+] (increase) and [–] (decrease) instead.

[–] and [+] Keys

You can use the [+] (increase) and [–] (decrease) keys to change the displayed number or value.

• Holding down either key scrolls the displayed setting.

• Pressing both keys at the same time will revert to the initial

default setting or the recommended setting.

Next press 3 (FUNCTION) until the parameter whose setting you want to change is displayed.

• Each press of 3 (FUNCTION) cycles through the available parameters.

• To scroll backwards through parameters, hold down (FUNCTION) as you press

Parameter Display See Page

1 Transpose Trans. EN-10 2 Accompaniment Volume AcompVol EN-31 3 Song Volume Song Vol EN-19 4 Tuning Tune EN-10 5 Reverb Reverb EN-9 6 Voice Fingering Guide Speak EN-24 7 Note Guide NoteGuid EN-25 8 Performance Evaluation Scoring EN-25

9 Phrase PhraseLn EN-25 10 Sampling Start SampAuto EN-15 11 Sampling Play Back SampPB EN-16

Auto Incrementing during

Short Sampling 13 Keyboard Channel Keybd Ch EN-33 14 Navigate Channels Navi. Ch EN-33 15 Local Control Local EN-34 16 Accomp Out AcompOut EN-34 17 Pedal Effect Jack EN-9

When the parameter you want is displayed, use

(10-key) to change its setting.

• The parameter setting will disappear from the upper left area of the screen if you do not perform any operation for some time.

(METRONOME).

AutoIncr EN-16

Using the FUNCTION Button (3)

Use the FUNCTION button ( you select the reverb type, pedal effect, etc.

Press 3 (FUNCTION).

) to access settings that let

Setting

Trans .

Parameter

EN-4

• The tone and other parameters revert to their initial defaults whenever you turn on power (page EN-6).

Getting Ready to Play

Preparing the Music Stand

Music stand

Power Supply

Either an AC adaptor or batteries can be used to power this Digital Keyboard. Normally, use of AC adaptor power is recommended.

• The AC adaptor does not come with this Digital Keyboard. Purchase it separately from your retailer. See page EN-1 for information about options.

Using the AC Adaptor

Make sure that you use only the AC adaptor specified for this Digital Keyboard. Use of a different type of AC adaptor can cause malfunction.

Specified AC Adaptor: AD-E95100L

(JEITA Standard plug)

Household power outlet DC 9.5V terminal

AC adaptor

Using Batteries

• Be sure to turn off power before loading batteries.

• It is up to you to prepare six commercially available AA-size batteries. Do not use oxyride batteries or any other nickel based batteries.

Open the battery cover on the bottom of the Digital Keyboard.

Load six AA-size batteries into the battery compartment.

Make sure the positive + and negative - ends of the batteries are facing as shown in the illustration.

Insert the tabs of the battery cover into the holes on the side of the battery compartment, and close the cover.

Tabs

English

• Be sure to turn off Digital Keyboard power before connecting or disconnecting the AC adaptor.

• The AC adaptor will become warm to the touch after very long use. This is normal and does not indicate malfunction.

• To prevent breaking of the wire, take care to avoid putting any type of load on the power cord.

No bending! No winding!

• Never insert metal, pencils, or any other objects into the product’s 9.5V DC terminal. Doing so creates the risk of accident.

■ Low Battery Indication

The indicator shown below starts to flash to let you know when battery power is low. Replace the batteries with new ones.

Low battery indicator (flashes)

EN-5

Playing the Digital Keyboard

11 22 bmbm

Turning on Power and Playing

Press 1.

This turns on power.

• To turn off the Digital Keyboard, press

Try playing something on the keyboard. Use 2 to adjust volume.

• Turning off the Digital Keyboard power causes all current settings to be cleared. The Digital Keyboard will revert to initial default settings the next time you turn it on.

• The message “Pls wait” will remain on the display while a data save operation is in progress. Do not perform any other operation while it is displayed. Turning off the Digital Keyboard can cause Digital Keyboard data to be deleted or become corrupted.

Increase

Decrease

again.

Using Headphones

Using headphones cuts off output from the built-in speakers, which means you can practice playing even late at night without disturbing others.

• Be sure to turn down the volume level before connecting headphones.

• Headphones do not come with the Digital Keyboard.

• Use commercially available headphones. See page EN-1 for information about options.

• Do not listen to very high volume output over headphones for long period. Doing so creates the risk of hearing damage.

• If you are using headphones that require an adaptor plug, make sure you do not leave the adaptor plugged in when removing the headphones.

Auto Power Off

If you do not perform any operation on the Digital Keyboard for one of the trigger times noted below, Auto Power Off will turn off power.

During battery operation : 6 minutes During AC adaptor operation: 30 minutes

■ Disabling Auto Power Off

You can disable Auto Power Off to ensure that power is not turned off automatically during a concert, etc.

While holding down bm (TONE), turn on power.

Auto Power Off will be disabled.

bpbp

PHONES/OUTPUT jack

EN-6

Playing the Digital Keyboard

Using the Metronome

The metronome lets you play and practice along with a steady beat to help keep you on tempo.

Start/Stop

Press 4.

This starts the metronome.

This pattern changes with each beat.

Press 4 again to stop the metronome.

Changing the Beats per Measure

You can configure the metronome to use a bell sound for the first beat of each measure of the song you are playing.

• You can specify 0, or a value from 2 to 6 as the number of beat per measure.

• When playing a built-in song, the beats per measure setting (which determines when the bell sounds) is configured automatically for the currently selected song.

Hold down 4 until the beats per measure setting screen appears on the display.

Changing the Metronome Tempo

Use the following procedure to change the tempo of the metronome.

Press 5.

Use w (slower) and q (faster) to change the tempo setting. Holding down either button changes the setting at high speed.

• Pressing w and q at the same time will initialize the

tempo setting in accordance with the currently selected song or rhythm.

• Pressing display. While the tempo value is flashing, you can use

Note that you must input leading zeros, so 89 is input as 089.

• The tempo value will stop flashing if you do not perform any operation for a short while.

Tempo value (flashes)

causes the tempo value to flash on the

(10-key) to change it.

Changing the Metronome Sound Volume

The metronome volume setting is changed automatically with the volume level of the currently selected Auto Accompaniment or song. The metronome volume cannot be adjusted independently.

• For information about changing the Auto Accompaniment volume, see page EN-31.

• For information about changing the song volume, see page EN-19.

English

Bea t

• If you do not perform any operation for after the beats per measure setting screen appears, the display will return to the screen displayed before you pressed

Use bp (10-key) to enter the number of beats per measure.

• The bell will not sound if you specify 0 for this setting. In this case, all beats are indicated by a click sound. This setting lets you practice with a steady beat, without worrying how many beats there are in each measure.

• You cannot adjust the balance between the metronome and note volume during Auto Accompaniment and built-in tune play.

EN-7

Controlling the Keyboard Sounds

Select from a variety of musical instrument sounds

Your Digital Keyboard lets you select tones for a wide variety of musical instrument sounds, including violin, flute, orchestra, and more. Even the same song sound takes on a different feel by changing the instrument type.

To select an instrument for playing

Press bm (TONE).

Tone number

St .GrPno

Tone name

Use bp (10-key) to select the tone number you want.

The corresponding tone number and tone name will appear on the screen.

• Use the number buttons to enter the tone number. Specify three digits for the tone number. Example: To select 001, enter 0 3 0 3 1.

bnbn

bmbm

Try playing something on the keyboard.

The tone of the instrument you selected will sound.

bpbp

Playing with a Piano Tone (Piano Setup)

Press

(TONE) and bn (RHYTHM) at the same time.

This selects the grand piano tone.

Settings

Tone Number: “001” Reverb: “06” Transpose: “00” Pedal Effect: SUS Rhythm Number: “131” Accompaniment: Rhythm part only Local Control: On Voice Percussion:Off

• See the separate “Appendix” for a complete list of available tones.

• When one of the drum sets is selected (tone numbers 395 through 400), each keyboard key is assigned a different percussion sound.

EN-8

Controlling the Keyboard Sounds

Using Reverb

Reverb adds reverberation to notes. You can change the duration of the reverb.

Press 3 (FUNCTION) a number of times until “Reverb” appears on the display (page EN-4).

Reverb

Use bp (10-key) [–] and [+] keys to select the reverb setting you want.

Off (oFF) Turns off reverb. 1 to 10 The larger the number selected, the longer

the reverb duration.

Reverb

Indicator disappears when reverb is turned off.

Using a Pedal

A pedal can be used to change notes in various ways while playing.

• A pedal unit does not come with the Digital Keyboard. Purchase one separately from your retailer. See page EN-1 for information about options.

Connecting a Pedal Unit

Connect an optional pedal unit.

SUSTAIN jack

Selecting the Pedal Effect

Press 3 (FUNCTION) a number of times until “Jack” appears on the display (page EN-4).

Jack

Use bp (10-key) [–] and [+] keys to select the pedal effect you want.

• The following shows the available pedal effects.

Sustain (SUS)

Sostenuto (SoS)

Soft (SFt)

Rhythm (rHy)

Sustains notes played while the pedal is depressed. Organ and other similar tone notes are sustained even if the pedal is not pressed.

Sustains notes that are playing when the pedal is depressed before the keyboard keys are released.

Slightly softens notes played while the pedal is depressed.

Pressing the pedal starts and stops Auto Accompaniment or song playback.

English

EN-9

Controlling the Keyboard Sounds

Changing the Pitch (Transpose, Tuning)

Changing the Pitch in Semitone Steps (Transpose)

The transpose feature lets you change the pitch, in semitone steps. A simple operation lets you instantly change the pitch to match that of a singer.

• The transpose setting range is –12 to +12 semitones.

Press 3 (FUNCTION).

Trans .

Use bp (10-key) [–] and [+] keys to select the transpose setting you want.

Fine Tuning (Tuning)

Use the tuning feature when you need to adjust the pitch slightly to play along with another musical instrument. Also, some artists perform their music with slightly altered tuning. You can use the tuning feature to adjust tuning so it exactly matches a performance on a CD.

• The tuning feature specifies the frequency of the A4 note. You can set a frequency within the range of 415.5 to

465.9 Hz. The initial default setting is 440.0 Hz.

Press 3 (FUNCTION) a number of times until “Tune” appears on the display (page EN-4).

Tune

Use bp (10-key) [–] and [+] keys to adjust the tuning.

• Performing this step causes the display to change from “Tune” to a value that indicates the current frequency setting as shown below. You can change the frequency in 0.1Hz steps.

440.0Hz

• Even if you do not perform a adjust the tuning, the current frequency setting will appear automatically after a few seconds.

EN-10

(10-key) operation to

Sampling a Sound and Playing it on the Keyboard (Sampling)

11 cqcq

bqbq brbr bsbs btbt ckck clclbkbk

bmbm

bnbn

bobo

bpbp

English

You can use the digital keyboard’s built-in microphone to record a sound and then play it with the keyboard keys. The sampling feature is a great way to create your own original sounds.

Playing the SAMPLING DEMO

Use the procedure below to play a demo tune that features sampled sounds.

Hold down bm (SAMPLING DEMO).

This starts playback.

To stop demo play, press bm or bk.

• Sampled sounds are recorded in monaural.

• The built-in microphone is only for inputting and recording external sounds for use with the sampling function. Sounds input with the built-in microphone are not output through the speakers.

• You cannot sample sounds input through the AUDIO IN jack.

Sampling a Sound and Playing It

There are two sampling methods: long sampling and short sampling. Long sampling is used for sampling in the Song Bank Mode, while short sampling is use for sampling in the Rhythm Mode.

■ Long Sampling

This method allows sampling of a single sound with a duration of two seconds.

• Sampling a new sound overwrites all previously recorded data (including data recorded with short sampling).

Press bo (SONG BANK).

Press cq (SAMPLING) and release it.

This enters sampling standby.

Speak !

Flashes

EN-11

Sampling a Sound and Playing it on the Keyboard (Sampling)

Produce the desired sound in the direction of the built-in microphone.

Sampling will start automatically.

Press cq (SAMPLING) and release it.

This enters sampling standby.

• At this time tone number 412 (which is short sampling 1 tone) is selected.

Samp l i n g

• Sampling will not start if the volume level of the sound being sampled with the microphone is too low.

• Sampling will stop automatically two seconds after it starts, or if the sound being input through the microphone stops before then.

Flashes

• Random phrases using the sampled sound will play back to indicate that sampling is complete.

• What you sample is stored as tone number 401.

Press a keyboard key.

This will play the recorded sound.

■ Short Sampling

With short sampling, you can record up to five samples, each with a length of up to approximately 0.4 seconds. Short samples are assigned rhythm parts, and can be sounded as voice percussion. For details, see “Using a Sampled Sound in a Rhythm (VOICE PERCUSSION)” (page EN-15).

• Sampling a new sound overwrites all previously recorded data (including data recorded with long sampling).

Press bn (RHYTHM).

• If you want to use a rhythm for sampling, select it here.

Speak !

Flashes

Produce the desired sound in the direction of the built-in microphone.

Sampling will start automatically.

Samp l i n g

• Sampling will not start if the volume level of the sound being sampled with the microphone is too low.

• Sampling will stop automatically 0.4 seconds after it is started.

Samp l ed !

Lights

EN-12

• The sampled sound is assigned a rhythm number and start to play to indicate that sampling is complete.

• What you sample is stored as tone number 412.

Press a keyboard key.

This will play the recorded sound.

Press cq (SAMPLING).

• At this time tone number 415 (which is short sampling 2 tone) is selected.

• Each subsequent short sampling operation is automatically assigned to the next sequential tone number. After sampling reaches tone number 424 (short sampling 5 tone), it cycles back to tone number 412 (short sampling 1 tone).

• If you want to assign a sample to a specific number manually, press the SAMPLED TONES/EFFECTS button (1 to 5) that corresponds to the number you want before pressing the SAMPLING button. This will perform short sampling and assign the result to the number that corresponds to the button you press.

Repeat steps 2 through 5 as many times as necessary to perform the short sampling you want.

Sampling a Sound and Playing it on the Keyboard (Sampling)

Sounding Sampled Sounds

■ Long Sample

In the Song Bank Mode, the five SAMPLED TONES/ EFFECTS buttons have the functions described below.

1: Sounds the original sampled tone as-is. 2 to 5: Select effects.

• The SAMPLING L indicator appears on the display when there is a long sample (sample created with long sampling) available.

■ Short Sample

In the Rhythm Mode, the five SAMPLED TONES/EFFECTS button can be used to select short sample tones. 1: Tone number 412 2: Tone number 415 3: Tone number 418 4: Tone number 421 5: Tone number 424

• The SAMPLING S indicator appears on the display when there is one or more sample (sample created with short sampling) available.

English

EN-13

Sampling a Sound and Playing it on the Keyboard (Sampling)

Applying an Effect to a Sound Sample

Use the procedure below to apply effects to a sample that was recorded using either long sampling or short sampling.

Press one of the five bq - ck (SAMPLED TONES/EFFECTS) buttons to cycle through available effects.

Example: Button 1 (tone number 412) Original tone 3 Loop 1 3 Loop 2 3 Original tone 3 See the “Sampled Sound Tone Numbers” table below for details about the effects that are assigned to each button.

■ Sampled Sound Tone Numbers

The original sampled sound and its modified (by effects) versions are assigned to sequential tone numbers (the same as builtin tones). This makes it easy to select a version of a sampled sound using

SAMPLED TONES/

EFFECTS button

Tone No. Effect Name Description

401 Original Long – 402 Loop 1 Long Loops the sampled sound.

403 Loop 2 Long

404 Loop 3 Long

405 Pitch 1 Long Changes the pitch from low to high, at an increasing rate. 406 Pitch 2 Long Changes pitch from high to low, at a decreasing rate.

407 Pitch 3 Long

408 Tremolo Long Alternates volume between high and low. 409 Funny 1 Long Adds vibrato and changes pitch by a gradually increasing amount. 410 Funny 2 Long Alternates between high pitch and low pitch. 411 Funny 3 Long Adds vibrato and changes pitch from low to high. 412 Original Short 1 – 413 Loop 1 Short 1 Loops the sampled sound.

414 Loop 2 Short 1

415 Original Short 2 –

416 Loop 3 Short 2

417 Pitch 1 Short 2 Changes the pitch from low to high, at an increasing rate. 418 Original Short 3 – 419 Pitch 2 Short 3 Changes pitch from high to low, at a decreasing rate.

420 Pitch 3 Short 3

421 Original Short 4 – 422 Tremolo Short 4 Alternates volume between high and low. 423 Funny 1 Short 4 Adds vibrato and changes pitch by a gradually increasing amount. 424 Original Short 5 – 425 Funny 2 Short 5 Alternates between high pitch and low pitch. 426 Funny 3 Short 5 Adds vibrato and changes pitch from low to high.

Loops the sample sound and raises the pitch of the resonating sound when the keyboard key is released.

Loops the sample sound and lowers the pitch of the resonating sound when the keyboard key is released.

Changes pitch from high to low, at a decreasing rate, and then raises the pitch when the key is released.

Loops the sample sound and raises the pitch of the resonating sound when the keyboard key is released.

Loops the sample sound and lowers the pitch of the resonating sound when the keyboard key is released.

Changes pitch from high to low, at a decreasing rate, and then raises the pitch when the key is released.

(10-key).

EN-14

Sampling a Sound and Playing it on the Keyboard (Sampling)

Using a Sampled Sound in a Rhythm (VOICE PERCUSSION)

Use the following procedure to replace a percussive instrument with a sampled sound you sampled with short sampling and play auto accompaniment rhythms (page EN-27) with it.

Each press of cl (VOICE PERCUSSION) button toggles between the VOICE PERCUSSION mode and the normal rhythm mode.

• The VOICE PERCUSSION indicator will be on the display while the VOICE PERCUSSION mode is selected.

Lights

Start rhythm play (page EN-27).

• Some rhythm part sounds are replaced by sampled sounds you sampled with short sampling.

• In the VOICE PERCUSSION mode, the rhythm accompaniment volume level is balanced with the volume of the sampled sound. Because of this, the rhythm accompaniment (chords and obbligato) volume level will be lowered automatically.

Starting a Sampling Operation Manually

Press 3 (FUNCTION) a number of times until “SampAuto” appears on the display (page EN-4).

Deleting Sampled Data

To delete all sampled data

Press 1 to turn off power.

While holding down bo (SONG BANK) and bp (10-key) [0] button, press on again.

• Make sure the digital keyboard is not connected to a computer when performing the above steps. Otherwise, data may not be deleted correctly.

To delete the long sample

Press bo (SONG BANK).

Hold down bq (SAMPLED TONES/EFFECTS 1).

• This will cause the confirmation message “Sure?” to appear.

Press bp (10-key) [YES] key to delete the data or

(10-key) [NO] key to cancel.

To delete the data for a specific short sample number

Press bn (RHYTHM).

Hold down the SAMPLED TONES/EFFECTS button ( delete.

• This will cause the confirmation message “Sure?” to appear.

Press bp (10-key) [YES] key to delete the data or

to ck) whose data you want to

(10-key) [NO] key to cancel.

to turn power back

English

SampAu t o

Press bp (10-key) [–] key to select the OFF setting.

This enables manual sampling. When this setting is selected, sampling starts as soon as you release step 2 under “Long Sampling” (page EN-11) or step 2 under “Short Sampling” (page EN-12).

• When the above setting is “oFF”, sampling starts when you release not start if you keep

, not when you press it. Sampling will

depressed.

EN-15

Sampling a Sound and Playing it on the Keyboard (Sampling)

Enabling or Disabling the Sampling Play Back

Use the procedure below to enable or disable the auto playback routine (song or rhythm using sampled sound) that is performed after sampling is complete.

Keep pressing 3 (FUNCTION) until “SampPB” appears on the display.

Press bp (10-key) [–] key to disable the demo routine.

• While the demo routine is disabled, the playback in step 3 at the end of long sampling and short sampling is not performed.

Enabling or Disabling Auto Incrementing during Short Sampling

Use this procedure to enable or disable auto incrementing of the short sampling number during short sampling.

Keep pressing 3 (FUNCTION) until “AutoIncr” appears on the display.

Press bp (10-key) [–] key to disable short sample number incrementing.

When short sample number incrementing is turned off, short sampling is repeated using the number (number does not change) selected with the SAMPLED TONES/ EFFECTS (1 to 5) button. To change short sampling to another number, you need to press a different SAMPLED

TONES/EFFECTS (1 to 5) button before pressing the SAMPLING button.

EN-16

Playing Built-in Songs

66 77 88 99 bkbk blbl

bobo

bpbp

English

With this Digital Keyboard, built-in tune data is referred to as “songs”. You can listen to the built-in songs for your own enjoyment, or you can play along with them for practice.

• In addition to simple listening enjoyment, the built-in songs can be used with the lesson system (page EN-21) for practice.

Playing the Demo Songs

Use the following procedure to play back built-in songs (001 to

090).

Press bk and bl at the same time.

This will start playback of the demo songs. Demo playback continues until you stop it.

• See page EN-40 for a complete list of available songs.

• Demo playback always starts from song number 001.

Song number

Tw i nk l e

Flashes

To change to another song while demo playback is in progress, use [+] keys to enter the song number you want (page EN-4).

This will cause demo playback to jump to the song whose number you entered.

• You cannot use song.

To stop demo playback, press bk.

Demo playback continues until you stop it by pressing bk.

Tune name

(10-key) [–] and

(10-key) number buttons to select a

Playing Back a Particular Song

Use the procedure below to play back one of the built-in songs. You can play along on the keyboard with song playback.

Start/Stop

Press bo (SONG BANK).

Song number

Tw i nk l e

Lights

Use bp (10-key) to enter the number of the song you want.

• See page EN-40 for a complete list of available songs.

• Use the number buttons to enter the song number. Specify three digits for the song number. Example: To select 001, enter 0 3 0 3 1.

Tune name

Lights

EN-17

Playing Built-in Songs

Press bk.

This starts playback of the song.

Sustain pedal

Key

Measure

Beat

Tempo

Press bk again to stop playback.

Song playback will continue (repeat) until you press bk to stop it. You can cancel song repeat by pressing

Note

Fingering

■ Skip Forward

Press 8.

This skips song playback forward to the next measure. Each press of down

• Pressing lesson function phrase skip forward (page EN-22).

skips ahead one measure. Holding

skips forward at high speed until you release it.

while song playback is stopped performs

Measure number

■ Skip Back

Press 7.

This skips song playback back to the previous measure. Each press of

skips back at high speed until you release it.

• Pressing lesson function phrase skip back (page EN-22).

skips back one measure. Holding down

while song playback is stopped performs

Indicator disappears when song repeat is turned off.

Pause, Skip Forward, Skip Back

Use the operations in this section to perform pause, skip forward, and skip back operations.

■ Pause

Press 9.

This pauses song playback.

Press 9 again to resume playback from the point where you paused it.

Repeating Playback of Specific Measures

You can use the procedure in this section to repeat particular measures for practice playing along until you master it. You can specify the start measure and the end measure of the section you want to play and practice.

Start End

These measures are repeated.

Press 6 to temporarily turn off song repeat.

Disappears

EN-18

When song playback reaches the measure you want to specify as the start measure, press

This specifies the measure as the start measure.

Flashes

When playback reaches the measure you want to select as the end measure, press

This specifies the measure as the end measure and starts repeat playback of the measures in the specified range.

• During repeat play you can use to skip forward, or 7 to skip back.

Lights

Pressing 6 again returns to normal playback.

Changing the song number clears the start measure and end measure of the repeat operation.

to pause playback,

again.

Playing Built-in Songs

Changing Playback Speed (Tempo)

You can use the following procedure to change the speed (tempo) in order to slow down playback to practice difficult passages, etc.

Press 5.

Use w (slower) and q (faster) to change the tempo setting. Holding down either button changes the setting at high speed.

• Pressing w and q at the same time will return the

current song to its original default tempo.

• Pressing display. While the tempo value is flashing, you can use

flashing if you do not perform any operation for a short while.

• Changing the song number will return the song to its original default tempo.

causes the tempo value to flash on the

(10-key) to change it. The tempo value will stop

Adjusting the Song Volume

Use the following procedure to adjust the balance between the volume of what you play on the keyboard and song playback volume.

Press 3 (FUNCTION) a number of times until “Song Vol” appears on the display (page EN-4).

Song Vo l

English

Disappears

Use bp (10-key) [–] and [+] keys to adjust the song volume.

EN-19

Playing Built-in Songs

Playing with the Tone as Song Playback

The procedure below lets you select the same keyboard tone as the one being used in the song and play along with your favorite tunes.

After selecting a song, hold down bo (SONG BANK) for about two seconds until the displayed tone name changes to the tone name of the song.

• If your currently selected tone is the same as the song tone, the display contents will not change.

Play along with song playback.

• If you select a song that uses different tones for left and right hand play, the right hand part tone is assigned to the keyboard.

Turning Off the Part of One Hand for Practice (Part Select)

You can turn off the right hand part or the left hand part of a song during playback and practice playing the along with the remaining part.

Press bl to select the part you want to turn off.

Each press of bl cycles through the settings shown below.

Right hand part off

Left hand part off

Both hand parts off

Both hand parts on

Press bk.

This starts playback in accordance with the setting you selected in step 1.

• During playback with one part turned off, only the notes of the part that is turned off are shown on the display.

EN-20

Using Built-in Songs to Master Keyboard Play

bpbp

bobo

English

66 77 88 bkbk blbl

To master a song, it is best to break it up into shorter parts (phrases), master the phrases, and then put everything together. Your Digital Keyboard comes with a Step Up Lesson feature that helps you to do just that.

Phrases

The built-in songs are pre-divided into phrases to help you master keyboard play.

Song start Song end

Phrase 1 Phrase 2 Phrase 3 . . . .

Final

Phrase

bqbq brbr bsbs btbt ckck clcl

Step Up Lesson Flow

Step Up Lesson takes you through practice of the right hand part, left hand part, and both hand parts for each phrase of a song. Master all of the phrases and you master the song.

Phrase 1

• Right Hand Lesson 1, 2, 3

• Left Hand Lesson 1, 2, 3

• Both Hand Lesson 1, 2, 3

Repeat the above to practice phrase 2, 3, 4, and so on, until you reach the final phrase of the song.

After mastering all of the phrases, practice the entire song.

Now you have mastered the entire song!

EN-21

Using Built-in Songs to Master Keyboard Play

Messages that Appear during Lessons

The following are the messages that appear on the display during Step Lessons.

Message Description

<Phrase> Appears when you select a phrase, when a

<Wait> Appears when the lesson starts with an intro

NextPhrs Appears when advancing automatically to the

From Top This message appears during Auto Step Up

Complete Appears at the end of Auto Step Up Lesson

lesson starts, etc.

• Note that certain phrases will cause “<Wait>” to appear instead of “<Phrase>”.

or fill-in phrase that is not included in the phrases to be practiced. Play toll advance automatically to the next phrase after the unincluded phrase plays, so wait until then to start playing on the keyboard.

next phrase. This message appears following a phrase for which “<Wait>” (see above) is displayed, and during an Auto Step Up Lesson (page EN-25).

Lesson (page EN-25) immediately before practice from Phrase 1 up until the phrase currently being practiced.

(page EN-25).

To turn lesson function on or off

Press bo (SONG BANK).

Press cl (LESSON) to turn on the lesson function.

This causes the LESSON indicator to appear on the display.

Selecting the Song, Phrase, and Part You Want to Practice

First, select the song, phrase, and part you want to practice.

Select the song you want to practice (page EN-17).

This will select the first phrase of the song.

Press bt (or 8) to move forward one phrase, or

to move back one phrase.

• Holding down 8 or 7 scrolls through phrases at high speed.

• The Digital Keyboard remembers the last phrase you practiced for up to 20 songs. To recall the last practice phrase for the current song (if it is available), hold down

Phrase number

Phrase

Press bl to select the part you want to practice.

Each press of bl cycles through the settings shown below.

First measure of the selected phrase

Right hand practice

Left hand practice

Lights

To turn off the lesson function, press cl (LESSON).

This causes the LESSON indicator to disappear on the display.

Disappears

EN-22

Both hand practice

* This indicator (setting) is skipped if you press

a lesson is in progress.

Hold down bo (SONG BANK) for about two seconds.

The same tone used for song playback will be assigned to the keyboard (page EN-20).

while

Lessons 1, 2, and 3

Now it is time to start the lessons. First, select the song and part you want to practice.

Lesson 1: Listen to the song.

First, listen to the example a few times to familiarize yourself with what it sounds like.

Press bq.

This starts example play.

Lights

Using Built-in Songs to Master Keyboard Play

Play notes on the keyboard in accordance with the instructions provided on the display and by voice fingering guide.

During this lesson, the display shows the key you need to press next. Voice fingering guide uses a simulate voice to announce which finger you should use.

Flashes

Lights

English

To stop Lesson 1, press bq or bk.

Lesson 2: Watch how the song is played.

Play the song on the keyboard. During this lesson, the display shows the key you need to press next. Voice fingering guide also uses a simulate voice to announce which finger you should use. Follow the instructions to press the correct keyboard keys and play the notes. Don’t worry if you play the wrong note. Song playback will wait until you play the correct note. Take your time and play at your own pace.

Press br.

This starts Lesson 2.

Lights

Master playing the correct note with the correct finger as instructed by the guidance. Practice playing with the correct timing.

Song playback will wait for you to play the correct note.

• Keyboard key goes from flashing to lit.

• Note guide sounds the correct note to be played.

• Voice Fingering Guide tells you what finger to use.

Pressing the correct keyboard key causes song playback to resume and the key for the next note flashes.

To stop Lesson 2, press br or bk.

● If you complete Lesson 2 play to the end, a score that rates your play appears on the screen.

Bravo! You pass! Advance to the next lesson. Again! Go back and try again.

EN-23

Using Built-in Songs to Master Keyboard Play

Lesson 3: Remember what you learned as you play.

Though song playback stands by waiting for you to press the correct keys as in Lesson 2, the Digital Keyboard does not provide any guidance about what note you need to play next. Remember everything you have learned up to Lesson 2 as you play.

Press bs.

This starts Lesson 3.

Lights

Play the song along with the song playback.

Press the keyboard keys you learned in Lesson 2.

Song playback will wait for you to play the correct note.

• Note guide sounds the correct note to be played.

If you are still unable to press the correct keyboard key, the Digital Keyboard will display keyboard guidance and voice fingering guide will tell you what finger to use, just as in Lesson 2.

Pressing the correct key will cause song playback to resume.

To stop Lesson 3, press bs or bk.

• If you complete Lesson 3 play to the end, a score that rates your play appears on the screen the same as with Lesson 2.

Playing a Particular Song All the Way Through

After you successfully complete all of the phrases in Lessons 1, 2, and 3, it is time to try playing the entire song from beginning to end.

Use bl to turn off both hand parts and then press

Try playing with both hands and find out how the Digital Keyboard evaluates your effort.

Lesson Settings

Playing without Phrase Repeat

You can turn off phrase repeat for Lessons 1, 2, and 3.

Press 6.

This disables phrase repeat play.

Tw i nk l e

Disappears

Turning Off Voice Fingering Guide

Use the following procedure to turn off voice fingering guide, which tells you which finger to use to play each note in Lesson 2 and Lesson 3.

Press 3 (FUNCTION) a number of times until “Speak” appears on the display (page EN-4).

EN-24

Speak

Press the bp (10-key) [–] key to select the OFF setting.

Using Built-in Songs to Master Keyboard Play

Turning Off Note Guide

Use the following procedure to turn off note guide, which sounds the note to be played next in Lesson 2 and Lesson 3.

Press 3 (FUNCTION) a number of times until “NoteGuid” appears on the display (page EN-4).

No t eGu i d

Press the bp (10-key) [–] key to select the OFF setting.

Turning Off Performance Evaluation

Use the following procedure to turn off performance evaluation, which evaluates your performance and displays a score in Lesson 2 and Lesson 3.

Press 3 (FUNCTION) a number of times until “Scoring” appears on the display (page EN-4).

Sco r i ng

Press the bp (10-key) [–] key to select the OFF setting.

Using Auto Step Up Lesson

With Auto Step Up Lesson, the Digital Keyboard advances through each lesson automatically.

Select the song and part you want to practice (page EN-17).

Press ck.

Listen to the first phrase in Lesson 1.

• In Lesson 1, the sample phrase is played only once before advancing to Lesson 2.

Flashes

Lights

Auto Step Up Lesson stops automatically after you are able to get through all of the lessons successfully.

• In Lesson 2 and Lesson 3, the Digital Keyboard advances to the next lesson if you are able to achieve the “Bravo!” evaluation result.

• To cancel a lesson, press

• You can change the step and phrase during Auto Step Up Lesson using

• Starting Auto Step Up Lesson turns on Phrase Repeat (page EN-24), Note Guide (page EN-25) and Performance Evaluation (page EN-25) automatically. These features cannot be turned off during lessons.

7, 8

, and bq to bt.

or bk.

English

Lesson Play without Dividing Songs into Phrases

When the phrase function is turned off, lessons go through an entire song from beginning to end, without dividing it up between phrases.

Press 3 (FUNCTION) a number of times until “PhraseLn” appears on the display (page EN-4).

PhraseLn

Press the bp (10-key) [–] key to select the OFF setting.

EN-25

Using Built-in Songs to Master Keyboard Play

■ Auto Step Up Lesson Procedure

Phrase 1

Lesson 1

Lesson 2

Lesson 3

Phrase 2

Lesson 1

Lesson 2

Lesson 3

Phrase 1, 2

• Lesson 3*

Phrase 3

Lesson 1

Lesson 2

Lesson 3

Phrase 1, 2, 3

• Lesson 3*

Next phrase practice using the same procedure

Final phrase

Lesson 1

Lesson 2

Lesson 3

From Phrase 1 to the final phrase

• Lesson 3*

Lesson complete

* Auto Step Up Lesson advances to the next phrase,

regardless of whether the “Bravo!” result is attained.

EN-26

Using Auto Accompaniment

66 77 88 99 blbl

With Auto Accompaniment, simply select an accompaniment pattern. Each time you play a chord with your left hand the appropriate accompaniment will play automatically. It’s like having a personal backup group along with you wherever you go.

• Auto Accompaniments are made up of the following three parts. (1) Rhythm (2) Bass (3) Harmony

You can have only the rhythm part play, or you can have all three parts play at the same time.

bkbk

Playing the Rhythm Part only

The rhythm part is the foundation each Auto Accompaniment. Your Digital Keyboard comes with a variety of built-in rhythms, including 8-beat and waltz. Use the following procedure to play the basic rhythm part.

bnbn

bpbp

Starting and Stopping the Rhythm Part only

Press bn (RHYTHM).

Rhythm number

Funk 8Bt

Rhythm pattern name

Use bp (10-key) to select the rhythm number you want.

• See the separate “Appendix” for information about individual rhythms.

• Use the number buttons to enter the rhythm number. Specify three digits for the rhythm number. Example: To select 001, enter 0 3 0 3 1.

English

• With rhythms 140, and 142 to 150, nothing will sound until you play a chord on the keyboard.

Press bk or 7.

This starts the rhythm.

This pattern changes with each beat.

Play along with the rhythm.

To stop the rhythm, press bk again.

EN-27

Using Auto Accompaniment

Playing All Parts

Pressing bl again returns to rhythm only accompaniment.

Auto Accompaniment with Chords

Playing a chord with your left hand automatically adds bass and harmony accompaniment parts to the currently selected rhythm. It is just like having your own personal back up group on call.

Start play of the Auto Accompaniment rhythm part.

Press bl.

This enables chord input on the accompaniment keyboard.

Accompaniment keyboard

Lights

Use the accompaniment keyboard to play chords.

This will cause bass and harmony Auto Accompaniment parts to be added to the rhythm part.

Chords (no melody played)

Melody

• For information about starting Auto Accompaniment as soon as a chord is played, see “Using Synchro Start” on page EN-31.

Selecting a Chord Input Mode

You can select from among the following five chord input modes.

• FINGERED 1

• FINGERED 2

• FINGERED 3

• CASIO CHORD

• FULL RANGE CHORD

Hold down bl until the chord input mode selection screen appears on the display.

Chord input mode

Chord

Use bp (10-key) [–] and [+] keys to select the chord input mode you want.

• If you do not perform any operation after the chord input mode selection screen appears, the display will return automatically to the screen that was displayed before you held down

Example: Pressing D-F#-A-C on the accompaniment keyboard

Accompaniment for the D-F

Play other chords with left hand as you play the

-A-C chord (D7) sounds.

melody with your right hand.

EN-28

Using Auto Accompaniment

■ FINGERED 1, 2, and 3

With these three input modes, you play chords on the accompaniment keyboard using their normal chord fingerings. Some chord forms are abbreviated, and can be fingered with one or two keys. See page EN-41 for information about chords that are supported and how they are fingered on the keyboard.

Accompaniment keyboard

● FINGERED 1

Play the component notes of the chord on the keyboard.

● FINGERED 2

Unlike FINGERED 1, 6th input is not possible. m7 or m7

is input.

● FINGERED 3

Unlike FINGERED 1, allows input of fraction chords with the lowest keyboard note as the bass note.

■ CASIO CHORD

With CASIO CHORD, you can use simplified fingerings to play the four types of chords described below.

Accompaniment keyboard

CASIO CHORD Fingering

Chord Type Example

Major Chords

Letters above the accompaniment keyboard indicate the chord assigned

C (C Major)

E#G

DE F F

DE F

to each key. Pressing a single accompaniment area key in the CASIO CHORD mode will play the major chord whose name is marked above the key. All of the accompaniment area keys that are marked with the same chord name play exactly the same chord.

Minor Chords

To play a minor chord, press the accompaniment area key that

Cm (C Minor)

E#G

DE F F

DE F

corresponds to the major chord, while also pressing one other accompaniment area key to the right.

Seventh Chords

To play a seventh chord, press the accompaniment area key that

C7 (C Seventh)

E#G

DE F

DE F F

corresponds to the major chord, while also pressing two other accompaniment area keys to the right.

Minor Seventh Chords

To play a minor seventh chord, press the accompaniment area key that corresponds to the major chord, while

Cm7 (C Minor Seventh)

DE F F

E#G

DE F

also pressing three other accompaniment area keys to the right.

• When playing a minor, seventh, or minor seventh chord, it makes no different whether the additional keys you press are black or white.

■ FULL RANGE CHORD

With this mode, you can use the full range of the keyboard to play chords and the melody. See page EN-41 for information about chords that are supported.

Accompaniment keyboard / Melody keyboard

English

EN-29

Using Auto Accompaniment

Using Auto Accompaniment Effectively

Auto Accompaniment Pattern Variations

Use the following procedures to play intro and ending patterns, to play fill-in patterns, and to play variations of basic Auto Accompaniment patterns.

■ Auto Accompaniment Variation

Each Auto Accompaniment pattern has a basic “normal pattern” as well as a “variation pattern”.

Press 8.

This starts the variation pattern.

Lights

Pressing 7 returns to normal pattern.

Lights

■ Auto Accompaniment Intro

Use the following procedure to play an intro of a few measures.

Press 6.

This starts the intro pattern. Normal pattern play will start when the intro pattern is finished.

• If you press the variation pattern will start when the intro pattern is finished.

while an intro pattern is being played,

Lights

■ Auto Accompaniment Fill-in

Use the procedure below to play a fill-in pattern during a performance.

• A “fill-in” is a short phrase played where you want to change the mood of a piece. A fill-in pattern can be used to create a link between two melodies or an accent.

• Normal and variation patterns have their own unique fill-in patterns.

● Normal Pattern Fill-in

While a normal pattern is playing, press 7.

This plays the fill-in for the normal pattern.

• Normal pattern play will resume after the fill in pattern is complete.

Lights

● Variation Pattern Fill-in

While a variation pattern is playing, press 8.

This plays the fill-in for the variation pattern.

• Variation pattern play will resume after the fill in pattern is complete.

Lights

■ Auto Accompaniment Ending

Use the following procedure to play an ending of a few measures.

While an Auto Accompaniment is playing, press

This will play the ending pattern and then stop Auto Accompaniment play automatically.

Lights

EN-30

Using Auto Accompaniment

■ Using Synchro Start

Use the following procedure to configure the Digital Keyboard to start Auto Accompaniment play as soon as you press a keyboard key.

Press 9.

This enters accompaniment start standby.

Flashes

Play a chord on the keyboard.

This will start full part accompaniment (normal).

Any of the following operations can be performed while in synchro standby to start a non-normal pattern.

• To start with intro pattern, press

• To start with variation pattern play, press

Changing Auto Accompaniment Speed (Tempo)

Use the following procedure to change Auto Accompaniment speed to a level that suits you.

Press 5.

Use w (slower) and q (faster) to change the tempo setting. Holding down either button changes the setting at high speed.

• Pressing w and q at the same time will initialize the

rhythm setting in accordance with the currently selected rhythm.

• While the tempo value is flashing, you also can use (10-key) to change it.

• If you do not perform any operation for after the tempo setting screen appears, the display will return to the screen displayed before you pressed

Adjusting the Accompaniment Volume

Use the following procedure to adjust the balance between what you are playing on the keyboard and the volume of the Auto Accompaniment.

Press 3 (FUNCTION) a number of times until “AcompVol” appears on the display (page EN-4).

Ac ompVo l

Use bp (10-key) [–] and [+] keys to adjust the accompaniment volume.

Using One-Touch Preset

With One-Touch Preset, the Digital Keyboard automatically configures optimal tone, tempo, and other settings in accordance with the rhythm pattern you select.

Hold down bn (RHYTHM) until the current tone screen appears on the display.

This will automatically apply the One-Touch Preset settings in accordance with the rhythm pattern that is currently selected.

Play a chord on the keyboard.

This will start accompaniment automatically.

English

Flashes

EN-31

Connecting External Devices

blbl

Connecting a Computer

You can connect the Digital Keyboard to a computer and exchange MIDI data between them. You can send play data from the Digital Keyboard to music software running on your computer, or you can send MIDI data from your computer to the Digital Keyboard for playback.

Minimum Computer System Requirements

The following shows the minimum computer system requirements for sending and receiving MIDI data. Check to make sure that your computer complies with these requirements before connecting the Digital Keyboard to it.

• Operating System

Windows® XP (SP2 or later) Windows Vista® Windows® 7 Windows® 8 Windows® 8.1 Mac OS® X (10.3.9, 10.4.11, 10.5.X, 10.6.X, 10.7.X,

10.8.X, 10.9.X) *1: Windows XP Home Edition

Windows XP Professional (32-bit)

*2: Windows Vista (32-bit) *3: Windows 7 (32-bit, 64-bit) *4: Windows 8 (32bit, 64bit) *5: Windows 8.1 (32bit, 64bit)

• USB port

• Never connect to a computer that does not conform to the above requirements. Doing so can cause problems with your computer.

*2 *3 *4

bpbp

Connecting the Digital Keyboard to Your Computer

• Make sure you follow the steps of the procedure below exactly. Connecting incorrectly can make data send and receive impossible.

Turn off the Digital Keyboard and then start up your computer.

• Do not start up the music software on your computer yet!

After starting up your computer, use a commercially available USB cable to connect it to the Digital Keyboard.

B connector

USB cable

(A-B type)

Turn on the Digital Keyboard.

• If this is the first time you are connecting the Digital Keyboard to your computer, the driver software required to send and receive data will be installed on your computer automatically.

Start up your computer’s music software.

Digital Keyboard USB port

A connector

Computer USB port

EN-32

Configure the music software settings to select one of the following as the MIDI device.

CASIO USB-MIDI: For Windows 8.1, Windows 8,

USB Audio Device:For Windows XP

• For information about how to select the MIDI device, see the user documentation that comes with the music software you are using.

• Be sure to turn on the Digital Keyboard first before starting up your computer’s music software.

• USB send and receive is disabled during playback of a Song Bank song (page EN-17).

• Once you are able to connect successfully, there is no problem with leaving the USB cable connected when you turn off your computer and/or Digital Keyboard.

• This Digital Keyboard conforms to General MIDI Level 1 (GM).

• For detailed specifications and connections that apply to MIDI data send and receive by this Digital Keyboard, see the latest support information provided by the website at the following URL.

http://world.casio.com/

Windows 7, Windows Vista, Mac OS X

Connecting External Devices

MIDI Settings

Keyboard Channel

A keyboard channel is the channel used for sending Digital Keyboard data to a computer. You can select the channel you want for sending Digital Keyboard data to a computer.

• The keyboard channel setting range is 01 to 16.

Press 3 (FUNCTION) a number of times until “Keybd Ch” appears on the display (page EN-4).

Keybd Ch

Use bp (10-key) [–] and [+] keys to change the keyboard channel.

Navigate Channels

The navigate channels can be used to display only the notes of a particular channel (part) as on-screen guide information from among the note information of a tune sent from the computer.

■ Specifying the Navigate Channels

From among the 16 available channels (numbered 1 to 16), you can specify any two neighboring channels (such as 05 and 06) as navigate channels. The smaller numbered channel is the navigate (L) channel, while the larger numbered channel is the navigate (R) channel. Specifying the navigate (R) channel will automatically configure the navigate (L) channel as well.

Press 3 (FUNCTION) a number of times until “Navi. Ch” appears on the display (page EN-4).

English

Nav i . Ch

Use bp (10-key) to specify the navigate (R) channel.

This also will automatically configure the next lower channel number as the navigate (L) channel.

EN-33

Connecting External Devices

■ Turning Off the Navigate Channel Sound and Playing the Part on the Keyboard

You can turn off the sound on one or both of the navigate channels and play the cancelled part on the keyboard yourself.

Press bl to select the channel setting you want to turn off.

Each press of bl cycles through settings (1) through (4) described below.

• If you turn off one channel, you can play the cancelled part on the keyboard using the same tone as the channel you turned off. If you turn off both channels (option (3)), what you play on the keyboard sounds using the tone of the navigate (R) channel.

Selected channel indicator appears.

Navigate (L)

Channel

Sound

screen

Guide

(1) R only displayed { ××{ (2) L only displayed × {{ × (3) LR displayed × { × { (4) LR not displayed {{{{

On-

Navigate (R)

Channel

Sound

On-

screen

Guide

Local Control

There are times when exchanging data with a computer when you may not want the Digital Keyboard to sound notes you play on its keyboard. The local control setting lets you do just that.

Press 3 (FUNCTION) a number of times until “Local” appears on the display (page EN-4).

Local

Use bp (10-key) [–] and [+] keys to specify the local control setting.

Accomp Out

Enabling the Accomp Out setting causes Auto Accompaniment data to be sent to the computer.

Press 3 (FUNCTION) a number of times until “AcompOut” appears on the display (page EN-4).

Ac ompOu t

Use bp (10-key) [–] and [+] keys to turn Accomp Out on or off.

EN-34

Connecting to Audio Equipment

This Digital Keyboard can be connected to commercially available stereo, amplifier, or recording equipment, to a portable audio player or other equipment.

Outputting Digital Keyboard Notes to Audio Equipment

Connection requires commercially available connecting cords, supplied by you. The connecting cords should have a stereo standard plug on one end and a plug that matches the configuration of the external device on the other end.

• Turn off the external device when making connections. After connecting, turn down the Digital Keyboard and external device volume levels whenever turning power on or off.

• After connecting, turn on the Digital Keyboard and then the external device.

• If Digital Keyboard notes sound distorted when they are sounded from external audio equipment, lower the Digital Keyboard’s volume setting.

Audio equipment, amplifier, etc.

Stereo standard plug

Digital Keyboard PHONES/OUTPUT jack

Connecting External Devices

English

Playing an External Device from the Digital Keyboard

Connection requires commercially available connecting cords, supplied by you. The connecting cords should have a stereo mini plug on one end and a plug that matches the configuration of the external device on the other end.

• Turn off the Digital Keyboard when making connections. After connecting, turn down the Digital Keyboard and external device volume levels whenever turning power on or off.

• After connecting, turn on the external device and then the Digital Keyboard.

• If notes are distorted when they are sounded on the external device, lower the volume setting of the external device.

Portable audio player, etc.

Stereo mini plug

Digital Keyboard AUDIO IN jack

EN-35

Reference

Troubleshooting

Symptom Action

Included Accessories

I can’t find something that should be here. Carefully check inside all of the packing materials.

Power Requirements

Power will not turned on. • Check the AC adaptor or make sure that the batteries are facing

The Digital Keyboard outputs a loud sound and then suddenly powers down.

The Digital Keyboard suddenly powers down after a few minutes.

Display

The display keeps going out or are flashing. Replace the batteries with new ones or switch over to AC adaptor

On-screen keyboard keys or notes remain on the display.

Screen contents are visible only from straight ahead. This is dues to production limitations. It does not indicate malfunction.

Sound

Nothing happens when I press any keyboard key. • Adjust the main volume setting (page EN-6).

Nothing happens or notes do not play normally when I play notes on the left side of the keyboard.

Nothing happens when I start an Auto Accompaniment.

Nothing happens when I start playback of a built-in song.

The metronome does not sound. • Check and adjust the accompaniment volume setting (page

Notes keep sounding, without stopping. • Turn power off and then back on to initialize all Digital Keyboard

correctly (page EN-5).

• Replace the batteries with new ones or switch over to AC adaptor power (page EN-5).

Replace the batteries with new ones or switch over to AC adaptor power (page EN-5).

This happens when Auto Power Off (page EN-6) is triggered.

power (page EN-5).

A Step Up Lesson is in progress and the Digital Keyboard is waiting for you to play the next note in the song. To stop this from happening, cancel the lesson (page EN-23).

• Check if something is plugged into the PHONES/OUTPUT jack

) on the back of the Digital Keyboard.

(

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

Press bl to disable chord input in the accompaniment keyboard area (page EN-28).

• With rhythms 140, and 142 to 150, nothing will sound until you play a chord on the keyboard. Try playing a chord (page EN-28).

• Check and adjust the accompaniment volume setting (page EN-31).

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

• It takes a little time after you press the button until the song starts to play. Wait for a moment for the song to start.

• Check and adjust the song volume (page EN-19).

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

EN-31).

• Check and adjust the song volume (page EN-19).

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

settings (page EN-6).

• Replace the batteries with new ones or switch over to AC adaptor power (page EN-5).

EN-36

Reference

Symptom Action

Some notes are cut off while they are playing. Notes are cut off whenever the number of notes being sounded

The volume or tone setting I made has changed. • Adjust the main volume setting (page EN-6).

In certain keyboard ranges, the volume and tone quality sound are slightly different from those in other keyboard ranges.

With some tones, octaves do not change at the far ends of the keyboard.

The pitch of the notes does not match other accompanying instruments or sounds strange when played long with other instruments.

The reverb of notes seems to change suddenly. • Check and adjust the reverb setting (page EN-9).

Sounds I sampled were deleted. Be sure to press the power button to turn off power. Unplugging or

Even though I didn’t input anything with the built-in microphone, the message “Sampled!” appears on the display when I release the SAMPLING button.

Rhythms played in the VOICE PERCUSSION Mode sound strange and unnatural.

Operation

When I perform a skip forward or skip back operation, the skip operation moves multiple song measures instead of only a single measure.

Computer Connection

I can’t exchange data between the Digital Keyboard and a computer.

exceeds the maximum polyphony value of 48 (24 for some tones). This does not indicate malfunction.

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

• Replace the batteries with new ones or switch over to AC adaptor power (page EN-5).

This is due to system limitations. It does not indicate malfunction.

• Check and adjust the transpose (page EN-10) and tuning settings (page EN-10).

• Turn power off and then back on to initialize all Digital Keyboard settings (page EN-6).

disconnecting the AC adaptor without first pressing the power button to turn off power will cause sampled sounds to be deleted.

• Perform the sampling operation where it is quiet.

• You may be making noise, which is picked up as sampled sound, when releasing the SAMPLING button release operation. If this is the case, release the SAMPLING button carefully to avoid making noise.

• Use the procedure under “Starting a Sampling Operation Manually” (page EN-15) to turn off SampAuto, and then try manual sampling.

In order to assure proper balance for the rhythm, be sure to record all five short samples. Playing a rhythm in the VOICE PERCUSSION Mode while there is no short sample will cause a preset sample to sound. If there is even a single short sample recorded, rhythm instruments will sound only for the recorded short sample.

While song playback is stopped or a Step Up Lesson is in progress, skip forward and skip back operations are performed in phrase units (page EN-18).

• Check to make sure that the USB cable is connected to the Digital Keyboard and computer, and that the device is selected correctly with your computer’s music software settings (page EN-32).

• Turn off the Digital Keyboard and then exit the music software on your computer. Next, turn the Digital Keyboard back on and then restart the music software on your computer.

English

EN-37

Reference

Specifications

Model CTK-2090/CTK-2400 Keyboard 61 standard-size keys Maximum Polyphony 48 notes (24 for certain tones) Tones

Built-in Tones 400 Sampling Tones 1 (Long Sampling) or 5 (Short Sampling)

Reverb 1 to 10, Off Metronome

Beats per Measure 0, 2 to 6 Tempo Range 30 to 255

Song Bank

Tunes 110

Step Up Lesson

Lessons 5 (Listen, Watch, Remember, Next, Auto) Lesson Part L, R, LR Functions Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation

Auto Accompaniment

Rhythm Patterns 150 One Touch Presets 150

Other Functions

Transpose ±1 octaves (–12 to +12 semitones) Tuning A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)

MIDI 16 multi-timbre received, GM Level 1 standard Musical Information Function Tone, Rhythm, Song Bank numbers and names, staff notation, fingering, pedal operation,

Inputs/Outputs

USB port TYPE B Sustain jack Standard jack (sustain, sostenuto, soft, rhythm) Phones/Output jack Stereo standard jack

Audio In jack Stereo mini jack

Built-in microphone

Power Jack 9.5V DC Power Supply 2-way

Batteries 6 AA-size zinc-carbon batteries or alkaline batteries Battery Life Approximately 3 hours continuous operation on alkaline batteries AC Adaptor AD-E95100L Auto Power Off Approximately 6 minutes (during battery operation) or 30 minutes (during AC adaptor

Speakers 10cm × 2

Output 2W + 2W

Power Consumption 9.5V = 7.7W Dimensions 94.6 × 30.7 × 9.2 cm (37 Weight Approximately 3.4kg (7.5 lbs) (without batteries)

• Design and specifications are subject to change without notice.

Sampling Time: 2 second (Long Sampling) or approximately 0.4 seconds each (Short

Effects: 5 types Sampling Demo Tune: 1

tempo, measure and beat number, chord name, etc.

Output Impedance: 200Ω, Output Voltage: 4.5V (RMS) MAX

Input Impedance: 9kΩ, Input Sensitivity: 200mV

operation) without any operation

Sampling)

/4 × 12 1/16 × 3 5/8 inch)

EN-38

Reference

Operating Precautions

Be sure to read and observe the following operating precautions.

■ Location

Avoid the following locations for this product.

• Areas exposed to direct sunlight and high humidity

• Areas subjected to temperature extremes

• Near a radio, TV, video deck, or tuner The above devices will not cause malfunction of the product, but interference from the product can cause audio or video interference of a nearby device.

■ User Maintenance

• Never use benzine, alcohol, thinner, or other chemical agents to clean the product.

• To clean the product or its keyboard, wipe with a soft cloth moistened in a weak solution of water and a mild neutral detergent. Wring all excess moisture from the cloth before wiping.

■ Included and Optional Accessories

Use only accessories that are specified for use with this product. Use of unauthorized accessories creates the risk of fire, electric shock, and personal injury.

■ Weld Lines

Lines may be visible on the exterior of the product. These are “weld lines” that result from the plastic molding process. They are not cracks or scratches.

■ Musical Instrument Etiquette

Always be aware of others around you whenever using this product. Be especially careful when playing late at night to keep the volume at levels that do not disturb others. Other steps you can take when playing late at night are closing the window and using headphones.

English

EN-39

Reference

Song List

SONG BANK

WORLD

001 TWINKLE TWINKLE LITTLE STAR 002 LIGHTLY ROW 003 LONG LONG AGO 004 ON TOP OF OLD SMOKEY 005 SAKURA SAKURA 006 WHEN THE SAINTS GO MARCHING IN 007 AMAZING GRACE 008 AULD LANG SYNE 009 COME BIRDS 010 DID YOU EVER SEE A LASSIE? 011 MICHAEL ROW THE BOAT ASHORE 012 DANNY BOY 013 MY BONNIE 014 HOME SWEET HOME 015 AURA LEE 016 HOME ON THE RANGE 017 ALOHA OE 018 SANTA LUCIA 019 FURUSATO 020 GREENSLEEVES 021 JOSHUA FOUGHT THE BATTLE OF JERICHO 022 THE MUFFIN MAN 023 LONDON BRIDGE 024 UNDER THE SPREADING CHESTNUT TREE 025 SIPPIN’ CIDER THROUGH A STRAW 026 GRANDFATHER’S CLOCK 027 ANNIE LAURIE 028 BEAUTIFUL DREAMER

IF YOU’RE HAPPY AND YOU KNOW IT, CLAP YOUR

029

HANDS 030 MY DARLING CLEMENTINE 031 LITTLE BROWN JUG 032 HOUSE OF THE RISING SUN 033 SHE WORE A YELLOW RIBBON 034 YANKEE DOODLE 035 MY OLD KENTUCKY HOME 036 SZLA DZIEWECZKA 037 TROIKA 038 WALTZING MATILDA 039 ON THE BRIDGE OF AVIGNON 040 I’VE BEEN WORKING ON THE RAILROAD 041 OH! SUSANNA 042 CAMPTOWN RACES 043 JEANNIE WITH THE LIGHT BROWN HAIR 044 TURKEY IN THE STRAW 045 JAMAICA FAREWELL

EVENT

046 SILENT NIGHT 047 WE WISH YOU A MERRY CHRISTMAS 048 JINGLE BELLS 049 JOY TO THE WORLD 050 O CHRISTMAS TREE

PIANO/CLASSICS

051 MARY HAD A LITTLE LAMB 052 LE CYGNE FROM “LE CARNAVAL DES ANIMAUX” 053 JE TE VEUX 054 SONATA op.13 “PATÉTIQUE” 2nd Mov. 055 HEIDENRÖSLEIN 056 AIR FROM “SUITE no.3” 057 SPRING FROM “THE FOUR SEASONS” 058 HABANERA FROM “CARMEN” 059 BRINDISI FROM “LA TRAVIATA” 060 HUNGARIAN DANCES no.5 061 MINUET IN G MAJOR 062 MUSETTE IN D MAJOR 063 GAVOTTE (GOSSEC) 064 ARABESQUE (BURGMÜLLER) 065 CHOPSTICKS 066 DECK THE HALL 067 ODE TO JOY 068 AVE MARIA (GOUNOD) 069 SONATINA op.36 no.1 1st Mov. 070 PRELUDE op.28 no.7 (CHOPIN) 071 RÊVERIE 072 GYMNOPÉDIES no.1 073 GOING HOME FROM “FROM THE NEW WORLD” 074 FÜR ELISE 075 TURKISH MARCH (MOZART) 076 SONATA op.27 no.2 “MOONLIGHT” 1st Mov. 077 ETUDE op.10 no.3 “CHANSON DE L’ADIEU” 078 THE ENTERTAINER

WEDDING MARCH FROM “MIDSUMMER NIGHT’S

079

DREAM” 080 AMERICAN PATROL 081 FRÖHLICHER LANDMANN 082 LA CHEVALERESQUE 083 SONATA K.545 1st Mov. 084 LA PRIÈRE D’UNE VIERGE 085 VALSE op.64 no.1 “PETIT CHIEN” 086 LIEBESTRÄUME no.3 087 JESUS BLEIBET MEINE FREUDE 088 CANON (PACHELBEL) 089 SERENADE FROM “EINE KLEINE NACHTMUSIK” 090 MARCH FROM “THE NUTCRACKER”

EXERCISE

091-100 EXERCISE I 101-110 EXERCISE II

EN-40

Reference

Fingering Guide

Fingered 1, Fingered 2 Chords

Cdim

Caug

Csus4

Csus2

Cm7

CM7

Cm7

C7sus4

Fingered 3, Full Range Chords

In addition to the chords that can be fingered with Fingered 1 and Fingered 2, the following chords also are recognized.

DCECFCGCA

      

GmCAmCBbmCDdimCAb7CF7CFm7CGm7CAbadd9

      

• With Fingered 3, the lowest note fingered is interpreted as the base note. Inverted forms are not supported.

• With Full Range Chord, when the lowest note fingered is a certain distance from the neighboring note, the chord is interpreted as a fraction chord.

• Unlike Fingered 1, 2, and 3, Full Range Chord requires pressing of at least three keys to form a chord.

BCC#mCDm

English

Cadd9

Cmadd9

CmM7

Cdim7

C69

C6 *1

Cm6 *2

*1 With Fingered 2, interpreted as Am7. *2 With Fingered 2, interpreted as Am7 *3 Inverted form not supported in some cases.

EN-41

Reference

)

(

AFCC

)

(

)

(

Chord Example List

EN-42

Root

)

(

)

(

Chord

Type

dim

aug

sus4

sus2

7sus4

add9

madd9

mM7

dim7

• Since the chord input range is limited, this model may not support some of the chords shown above.

**:no relation

**:sin relación

Bank select

Modulation

Data entry

Volume

Pan

Expression

1 - 16

Mode 3

0 - 127

36 - 96

9nH v = 1 - 127 O

9nH v = 0, 8nH v = X

9nH v = 0

9nH v = 100

(MSB only)

OOOOO

MIDI Implementation Chart

Function Transmitted Recognized Remarks

Default

Changed

Default

Messages

Altered

True voice

Note ON

Note OFF

Key’s

0, 3216, 38

Ch’s

Models: CTK-2090/CTK-2400 Version : 1.0

Basic

Channel

Mode

Note

Number

Velocity

After

Touch

Pitch Bender

Control

Change

Hold 1

Sostenuto

Soft pedal

Reverb send

OOOOO

RPN LSB, MSB

0 - 127 O

O : Yes

X : No

RPN y los mensajes exclusivos del sistema,

consulte Implementación MIDI en

XXX

OXO

*1: Depende del tono.

2: Para obtener información acerca de NRPN,

http://world.casio.com/

3: De acuerdo con el ajuste de efecto de pedal.

*3*3*

OOO

646667

100, 101

0 - 127 O

:True #

Program

Change

System Exclusive

XXX

: Song Pos

: Song Sel

System

Common

: Tune

: Clock

: Commands

System

Real Time

XOXOX

: All sound off

: Reset all controller

Aux

: Local ON/OFF

: All notes OFF

: Active Sense

: Reset

Messages

exclusive messages, see MIDI

2: For details about NRPN, RPN, and system

*1: Depends on tone.

Remarks

Implementation at

http://world.casio.com/

Mode 2 : OMNI ON, MONO

3: In accordance with pedal effect setting.

Mode 4 : OMNI OFF, MONO

Mode 1 : OMNI ON, POLY

Mode 3 : OMNI OFF, POLY

This recycle mark indicates that the packaging conforms to the environmental protection legislation in Germany.

Esta marca de reciclaje indica que el empaquetado se ajusta a la legislación de protección ambiental en Alemania.

MA1402-A Printed in China

Casio CTK-2090, CTK-2400 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
