Combo Drive
CD-R 52X/CD-RW 32X/DVD 16X
User’s Manual
C L AS S 1 L AS E R P R O D U C T
AP P AR E I L A L AS E R D E C L AS S E 1
L AS E R K L AS S E 1
L U O K AN 1 L AS E R L AI T E
P R O D U I T L AS E R
C AT E G O R I E 1
CAUTION
CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.
VORSICHT
KLASSE 3B SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG WENN GEOFFNET. NICHT IN DEN STRAHL SEHEN.
ATTENTION
RADIATION DU FAISCEAU LASER VISIBLES ET INVISIBLES DE CLASSE 3B
EN CAS D'OUVERTURE.
EVITER TOUTE EXPOSITION AUX RAYONS.
Copyright Statement
It is a criminal offence, under applicable copyright laws, to make unauthorised copies of copyright-protected material, including computer programs, films, broadcasts and sound recordings. This equipment should not be used for such purposes.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.This device may not cause harmful interference.
2.This device must accept any interference received, including interference that may cause undesired operation.
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
FOR EUROPE
“The drive is in conformity with the EMC directive and low-voltage directive.”
Table of Contents
INTRODUCTION |
1 |
FEATURES |
1 |
SYSTEM REQUIREMENTS |
2 |
PACKAGE CONTENTS |
2 |
INSTALLATION |
3 |
HOST INTERFACE CONNECTIONS |
3 |
HARDWARE INSTALLATION |
4 |
DRIVER INSTALLATION |
6 |
FOR WINDOWS ENVIRONMENT |
6 |
SOFTWARE DESCRIPTION |
6 |
DVD REGION CODING |
7 |
OPERATION & CONNECTION |
9 |
FRONT PANEL |
9 |
REAR VIEW |
10 |
TECHNICAL DATA |
11 |
TROUBLESHOOTING |
13 |
COMBO DRIVE
INTRODUCTION
Features
Welcome to a multimedia world of CD-ReWritable technology and DVD-ROM capabilities. This high-performance combo drive combines CD-RW and DVDROM in one single drive which frees up precious bay space and presents you abundant function. It reads CDs of all types at maximum 52X speed, and DVD-ROMs at 16X speed maximum. For the writing ability, it writes to CD-Rs at up to 52X speed, and to CD-RWs at up to 32X speed. . With the bundled software, you can enjoy the fun of creating customized audio and data CDs and the fascinating DVD entertainment of high resolution.
Here are some important features of this Combo Drive:
♦EIDE/ATAPI Interface for easy installation
♦8X, 16X, 24X, 32X, 40X, 48X and 52X writing speed on CD-R media
♦4X, 10X, 12X, 16X, 24X and 32X writing speed on CD-RW media
♦Adopts Buffer Underrun Prevention technology (MTKSuperLink)
♦Supports writing modes of TAO, DAO, SAO and packet writing
♦Large internal buffer: 2MB
♦Supports MultiRead function
♦Serves as RPC-2 DVD-ROM Drive
♦Smooth DVD playback
♦Low power consumption
1
COMBO DRIVE
System Requirements
For IBM compatible PCs, the system requirements recommended are as follows:
♦PC sufficient to run Windows 98/ME/2000/XP
♦Pentium II, Celeron 400MHz & above with at least 64MB of memory
♦Fast and sufficient hard disk space (minimum 200MB for installation, 1GB or more is recommended.)
♦IDE host interface supporting ATAPI MMC command
♦Microsoft Windows 98/ME/2000/XP
Package Contents
The package contains the following items:
♦Combo drive
♦Audio cable
♦Application software disc
♦A bag of screws
2
