Brocade Network OS YANG User Manual v14.1.1

53-1003230-01

®

14 March 2014

Network OS YANG

Reference Manual

Supporting Network OS v4.1.1

Copyright © 2014 Brocade Communications Systems, Inc. All Rights Reserved.

Brocade, Brocade Assurance, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, MLX, NetIron, SAN Health, ServerIron,
TurboIron, VCS, and VDX are registered trademarks, and AnyIO, Brocade One, CloudPlex, Effortless Networking, ICX, NET Health,
OpenScript, and The Effortless Network are trademarks of Brocade Communications Systems, Inc., in the United States and/or in
other countries. Other brands, products, or service names mentioned may be trademarks of their respective owners.

Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning
any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to
this document at any time, without notice, and assumes no responsibility for its use. This informational document describes
features that may not be currently available. Contact a Brocade sales office for information on feature and product availability.
Export of technical data contained in this document may require an export license from the United States government.

The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with
respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that
accompany it.

The product described by this document may contain “open source” software covered by the GNU General Public License or other
open source license agreements. To find out which open source software is included in Brocade products, view the licensing
terms applicable to the open source software, and obtain a copy of the programming source code, please visit
http://www.brocade.com/support/oscd.

Brocade Communications Systems, Incorporated

Corporate and Latin American Headquarters
Brocade Communications Systems, Inc.
130 Holger Way
San Jose, CA 95134
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

European Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour B - 4ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Asia-Pacific Headquarters
Brocade Communications Systems China HK, Ltd.
No. 1 Guanghua Road
Chao Yang District
Units 2718 and 2818
Beijing 100020, China
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Asia-Pacific Headquarters
Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)
Citic Plaza
No. 233 Tian He Road North
Unit 1308 – 13th Floor
Guangzhou, China
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Document History

Title Publication number Summary of changes Date

Network OS YANG Reference Manual 53-1002566-01 New document September 2012

Network OS YANG Reference Manual 53-1003049-01 Updated for NOS 4.0.0 September 2013

Network OS YANG Reference Manual 53-1003172-01 Updated for NOS 4.1.0 February 2014

Network OS YANG Reference Manual 53-1003230-01 Updated for NOS 4.1.1 March 2014

Contents

About This Document

How this document is organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Supported hardware and software . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Notes, cautions, and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Key terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Brocade resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Other industry resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Getting technical help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Chapter 1 Using YANG

Yang overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using the Network OS YANG Reference Manual . . . . . . . . . . . . . . . . . 1

Chapter 2 YANG Modules

brocade-aaa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

brocade-aaa-ext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

brocade-ag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

brocade-arp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

brocade-beacon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

brocade-bgp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

brocade-bprate-limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

brocade-bum-storm-control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

brocade-cdp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

brocade-cee-map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

brocade-certutil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

brocade-chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

brocade-clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

brocade-common-def. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Network OS YANG Reference Manual iii
53-1003230-01

brocade-dhcp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

brocade-diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

brocade-dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

brocade-eld. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

brocade-Enclosure-show . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

brocade-fabric-service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

brocade-fc-auth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

brocade-fcoe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

brocade-fcoe-ext. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

brocade-firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

brocade-firmware-ext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

brocade-hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

brocade-ha . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

brocade-http-config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

brocade-icmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

brocade-igmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

brocade-igmp-snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

brocade-interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

brocade-interface-ext. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

brocade-intf-loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

brocade-ip-access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

brocade-ip-administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

brocade-ip-config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

brocade-ip-forward. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

brocade-ip-policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

brocade-ipv6-access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

brocade-lacp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

brocade-lag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112

brocade-license . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

brocade-linecard-management. . . . . . . . . . . . . . . . . . . . . . . . .116

brocade-lldp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118

brocade-logical-chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

brocade-mac-access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

brocade-mac-address-table . . . . . . . . . . . . . . . . . . . . . . . . . . .123

brocade-nameserver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124

brocade-netconf-ext. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126

brocade-ntp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127

iv Network OS YANG Reference Manual

53-1003230-01

brocade-ospf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

brocade-pim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136

brocade-policer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138

brocade-port-profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

brocade-port-profile-ext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144

brocade-qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145

brocade-ras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150

brocade-ras-ext. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155

brocade-rbridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161

brocade-rmon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162

brocade-rtm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .164

brocade-sec-services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166

brocade-sflow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168

brocade-snmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169

brocade-span . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

brocade-system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

brocade-system-monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172

brocade-system-monitor-ext . . . . . . . . . . . . . . . . . . . . . . . . . . .175

brocade-terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

brocade-threshold-monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

brocade-threshold-monitor-ext . . . . . . . . . . . . . . . . . . . . . . . . .181

brocade-trilloam. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

brocade-tunnels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184

brocade-udld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185

brocade-vcs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .186

brocade-vlan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188

brocade-vrf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190

brocade-vrrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191

brocade-vswitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195

brocade-xstp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200

brocade-xstp-ext. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206

brocade-zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212

Appendix A Custom RPCs

Appendix B Actions

Network OS YANG Reference Manual v
53-1003230-01

vi Network OS YANG Reference Manual

53-1003230-01

About This Document

In this chapter

• How this document is organized . . . . . . . . . . . . . . . . . vii

• Supported hardware and software . . . . . . . . . . . . . . . vii

• Document conventions. . . . . . . . . . . . . . . . . . . . . . . . viii

• Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

• Additional information . . . . . . . . . . . . . . . . . . . . . . . . . ix

• Getting technical help. . . . . . . . . . . . . . . . . . . . . . . . . . . x

• Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

How this document is organized

This document is organized to help you find the information that you want as quickly and easily as
possible.

The document contains the following components:

• Chapter 1, “Using YANG” introduces the YANG language and provides information about how to

use this manual.

• Chapter 2, “YANG Modules” provides an overview and structural details for each YANG module.

• Appendix A, “Custom RPCs” lists the custom RPCs defined in the YANG modules and identifies

the host module for each.

• Appendix B, “Actions” lists the functions implemented by proprietary actions in the YANG

modules.

Supported hardware and software

Although many different software and hardware configurations are tested and supported by
Brocade Communications Systems, Inc. for Network OS v4.1.0, documenting all possible
configurations and scenarios is beyond the scope of this document.

The following hardware platforms are supported by this release of Network OS.

• Brocade VDX 6710

• Brocade VDX 6720

• Brocade VDX 6730

• Brocade VDX 6740

Network OS YANG Reference Manual vii
53-1003230-01

• Brocade VDX 6740T

NOTE

ATTENTION

• Brocade VDX 8770-4

• Brocade VDX 8770-8

Document conventions

This section describes text formatting conventions and important notice formats used in this
document.

Text formatting

The narrative-text formatting conventions that are used are as follows:

bold text Identifies command names

italic text Provides emphasis

Identifies the names of user-manipulated GUI elements
Identifies keywords and operands
Identifies text to enter at the GUI or CLI

Identifies variables
Identifies paths and Internet addresses
Identifies document titles

code text Identifies CLI output

Identifies command syntax examples

.

Notes, cautions, and warnings

The following notices and statements are used in this manual. They are listed below in order of
increasing severity of potential hazards.

A note provides a tip, guidance, or advice, emphasizes important information, or provides a
reference to related information.

An Attention statement indicates potential damage to hardware or data.

viii Network OS YANG Reference Manual

53-1003230-01

CAUTION

A Caution statement alerts you to situations that can be potentially hazardous to you or cause

DANGER

damage to hardware, firmware, software, or data.

A Danger statement indicates conditions or situations that can be potentially lethal or extremely
hazardous to you. Safety labels are also attached directly to products to warn of these conditions
or situations.

Key terms

For definitions specific to Brocade and Fibre Channel, see the technical glossaries on MyBrocade.
See “Brocade resources” on page x for instructions on accessing MyBrocade.

For definitions of SAN-specific terms, visit the Storage Networking Industry Association online
dictionary at:

http://www.snia.org/education/dictionary

Notice to the reader

This document may contain references to the trademarks of the following corporations. These
trademarks are the properties of their respective companies and corporations.

These references are made for informational purposes only.

Corporation trademarks and products

Microsoft Corporation Windows, Windows NT, Internet Explorer

Oracle Corporation Oracle, Java

Netscape Communications Corporation Netscape

Red Hat, Inc.

Additional information

This section lists additional Brocade and industry-specific documentation that you might find
helpful.

Red Hat, Red Hat Network, Maximum RPM, Linux Undercover

Network OS YANG Reference Manual ix
53-1003230-01

Brocade resources

To get up-to-the-minute information, go to http://my.brocade.com to register at no cost for a user ID
and password.

White papers, online demonstrations, and data sheets are available through the Brocade website
at:

http://www.brocade.com/products-solutions/products/index.page

For additional Brocade documentation, visit the Brocade website:

http://www.brocade.com

Release notes are available on the MyBrocade website.

Other industry resources

For additional resource information, visit the Technical Committee T11 website. This website
provides interface standards for high-performance and mass storage applications for Fibre
Channel, storage management, and other applications:

http://www.t11.org

For information about the Fibre Channel industry, visit the Fibre Channel Industry Association
website:

http://www.fibrechannel.org

Getting technical help

Contact your switch support supplier for hardware, firmware, and software support, including
product repairs and part ordering. To expedite your call, have the following information available:

1. General Information

- Switch model

- Switch operating system version

- Software name and software version, if applicable

- Error numbers and messages received

- supportSave command output

- Detailed description of the problem, including the switch or fabric behavior immediately

following the problem, and specific questions

- Description of any troubleshooting steps already performed and the results

- Serial console and Telnet session logs

- syslog message logs

2. Switch Serial Number

x Network OS YANG Reference Manual

53-1003230-01

The switch serial number and corresponding bar code are provided on the serial number label,
as illustrated below:

*FT00X0054E9*

FT00X0054E9

The serial number label is located on the switch ID pull-out tab located on the bottom of the
port side of the switch.

Document feedback

Quality is our first concern at Brocade and we have made every effort to ensure the accuracy and
completeness of this document. However, if you find an error or an omission, or you think that a
topic needs further development, we want to hear from you. Forward your feedback to:

[e-mail]

Provide the title and version number of the document and as much detail as possible about your
comment, including the topic heading and page number and your suggestions for improvement.

Network OS YANG Reference Manual xi
53-1003230-01

xii Network OS YANG Reference Manual

53-1003230-01

Chapter

Using YANG

In this chapter

Yang overview

YANG is a data modeling language. It is used to model configuration and state data for
manipulation by the Network Configuration Protocol (NETCONF) using NETCONF remote procedure
calls (RPCs).

Refer to RFC 6020, YANG - A Data Modeling Language for the Network Configuration Protocol
(NETCONF) for full; details of how to use YANG, and for a reference of all the features of the YANG
language.

1

•Yang overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

•Using the Network OS YANG Reference Manual . . . . . . . . . . . . . . . . . . . . . . . 1

Using the Network OS YANG Reference Manual

This manual provides a reference for YANG modules supported by Network OS v4.1.0.

Each module provides a data model for a specific part of the system. It models the data using one
or more of the following entities:

• Top-level nodes and their subtrees

• Subtrees that augment nodes in other YANG modules

• Custom RPCs

• Custom actions that make use of the proprietary action mechanism

For each module, this manual provides a high-level description of what the module does. It also
provides the structure of each top-level node, external augmentation, custom RPC, and action.

The pyang command with the -f tree option is used to illustrate the YANG code. This utility resolves
the uses and augments statements to provide an easy-to-read view of the structure of the YANG
code. The following example shows part of the module.

module:
+--rw interface
| +--rw fc-port [name]
| +--rw name interface-type
| +--rw fc-speed-cfg? fc-speed-cfg-type
| +--rw fill-word? fc-fillword-cfg-type
| +--rw long-distance? fc-long-distance-cfg-type
| +--rw vc-link-init? fc-vc-link-init-cfg-type
| +--rw desire-distance? desire-distance-type
| +--rw isl-r_rdy-mode? empty

Network OS YANG Reference Manual 1
53-1003230-01

Using the Network OS YANG Reference Manual

1

| +--rw trunk-enable? empty
| +--rw shutdown? empty

In addition to showing the structure, the output of the pyang -f tree command provides information
about each node, as shown in Figure 1.

FIGURE 1 Syntax of pyang output

Field definitions and possible values follow:

status Status of the node can be one of the following values:

flags The type of information can be one of the following values:

+ Current
xDeprecated
oObsolete

rw Read-write—The node contains configuration data
ro Read-only—The node contains operational data

-x RPC statement

-n Notification (not supported)

name The name of the node can be further modified by one of the following values:

(name) Choice node
:(name) Case node
prefix:name Augmented from external module

options The following optional values can be used:

? Optional leaf or presence container
*Leaf list
[keys]Keys for a list

type The type of the leaf or leaf-list. If the specified type is other than one of the

basic types, then the type is defined in a typedef statement in the .yang file.

2 Network OS YANG Reference Manual

53-1003230-01

Chapter

YANG Modules

brocade-aaa

Description Provides a data model for configuring authentication, authorization, and accounting (AAA). This

module supports authentication performed by a local, RADIUS, TACACS, or LDAP server.

Top-level

containers

Top-level nodes and their subtree hierarchies follow.

module: brocade-aaa
+--rw aaa-config
| +--rw aaa
| +--rw authentication
| | +--rw login
| | +--rw first? enumeration
| | +--rw second? enumeration
| +--rw accounting
| +--rw exec
| | +--rw defaultacc
| | +--rw start-stop
| | +--rw server-type? acc_srv_type
| +--rw commands
| +--rw defaultacc
| +--rw start-stop
| +--rw server-type? acc_srv_type
+--rw username [name]
| +--rw name string
| +--rw user-password user-passwd
| +--rw encryption-level? enumeration
| +--rw role string
| +--rw desc? string
| +--rw enable? username-enable
| +--rw expire? date
+--rw service
| +--rw password-encryption? empty
+--rw user
+--rw role
| +--rw name [name]
| +--rw name string
| +--rw desc? string
+--rw radius-server
| +--rw host [hostname]
| +--rw hostname string
| +--rw auth-port? rad-auth-port
| +--rw protocol? rad-auth-protocols
| +--rw key? string
| +--rw encryption-level? enumeration
| +--rw retries? uint32
| +--rw timeout? uint32
+--rw tacacs-server
| +--rw host [hostname]
| +--rw hostname string

2

Network OS YANG Reference Manual 3
53-1003230-01

2

brocade-aaa

| +--rw port? tac-auth-port
| +--rw protocol? tac-auth-protocols
| +--rw key? string
| +--rw encryption-level? enumeration
| +--rw retries? uint8
| +--rw timeout? uint8
+--rw ldap-server
| +--rw host [hostname]
| | +--rw hostname string
| | +--rw port? ldap-auth-port
| | +--rw retries? uint8
| | +--rw timeout? uint8
| | +--rw basedn? string
| +--rw maprole
| +--rw group [ad-group]
| +--rw ad-group string
| +--rw switch-role string
+--rw password-attributes
| +--rw min-length? uint32
| +--rw max-retry? uint32
| +--rw character-restriction
| | +--rw upper? uint32
| | +--rw lower? uint32
| | +--rw numeric? uint32
| | +--rw special-char? uint32
| +--rw admin-lockout-enable? empty
+--rw banner
| +--rw login? string
| +--rw motd? string
| +--rw incoming? string
+--rw rule [index]
| +--rw index uint32
| +--rw action? rule-action
| +--rw operation? rule-operation
| +--rw role? string
| +--rw command
| +--rw (cmdlist)?
| +--:(container-cmds)
| | +--rw enumList? enumeration
| +--:(interface-a)
| | +--rw interface-int
| | +--rw interface-cont?
| +--:(interface-b)
| | +--rw interface-fcoe
| | +--rw interface
| | +--rw fcoe-cont?
| +--:(interface-c)
| | +--rw interface-te
| | +--rw interface
| | +--rw tengigabitethernet-cont?
| +--:(interface-d)
| | +--rw interface-fcoe-leaf
| | +--rw interface
| | +--rw fcoe-leaf? string
| +--:(interface-e)
| | +--rw interface-te-leaf
| | +--rw interface
| | +--rw tengigabitethernet-leaf? string
| +--:(interface-f)
| | +--rw interface-mgmt

4 Network OS YANG Reference Manual

53-1003230-01

| | +--rw interface
| | +--rw management-cont?
| +--:(interface-g)
| | +--rw interface-ge
| | +--rw interface
| | +--rw gigabitethernet-cont?
| +--:(interface-h)
| | +--rw interface-ge-leaf
| | +--rw interface
| | +--rw gigabitethernet-leaf? string
| +--:(interface-i)
| | +--rw interface-pc
| | +--rw interface
| | +--rw port-channel-cont?
| +--:(interface-j)
| | +--rw interface-pc-leaf
| | +--rw interface
| | +--rw port-channel-leaf? string
| +--:(interface-k)
| | +--rw interface-vlan
| | +--rw interface
| | +--rw vlan-cont?
| +--:(interface-l)
| | +--rw interface-vlan-leaf
| | +--rw interface
| | +--rw vlan-leaf? string
| +--:(copy-a)
| | +--rw copy-cp
| | +--rw copy-cont?
| +--:(copy-b)
| | +--rw copy-running
| | +--rw copy
| | +--rw running-config-cont?
| +--:(copy-c)
| | +--rw copy-support
| | +--rw copy
| | +--rw support-cp?
| +--:(clear-a)
| | +--rw clear-cl
| | +--rw clear-cont?
| +--:(clear-b)
| | +--rw clear-logging
| | +--rw clear
| | +--rw logging-cont?
| +--:(clear-c)
| | +--rw clear-support
| | +--rw clear
| | +--rw support-cl?
| +--:(protocol-a)
| | +--rw protocol-pr
| | +--rw protocol-cont?
| +--:(protocol-b)
| | +--rw protocol-spanning
| | +--rw protocol
| | +--rw spanning-tree-cont?
| +--:(protocol-c)
| +--rw protocol-lldp
| +--rw protocol
| +--rw lldp-cont?
+--rw alias-config

brocade-aaa

2

Network OS YANG Reference Manual 5
53-1003230-01

2

brocade-aaa

+--rw alias [name]
| +--rw name string
| +--rw expansion string
+--rw user [name]
+--rw name string
+--rw alias [name]
+--rw name string
+--rw expansion string

External

augmentations

RPCs None

Actions Proprietary actions defined in this module follow.

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw clear
| +--rw brcd-aaa:login

Unlock a user account:

module: brocade-aaa
+--rw user
| +--ro unlock
| +--ro input
| | +--ro username string
| | +--ro rbridge-id? common-def:rbridge-id-all-type
| +--ro output
| +--ro Result? string

module: brocade-common-def
+--rw clear
| +--rw brcd-aaa:login
| | +--ro brcd-aaa:sessions
| | +--ro brcd-aaa:input
| | | +--ro brcd-aaa:rbridge-id? common-def:rbridge-id-all-type
| | +--ro brcd-aaa:output

6 Network OS YANG Reference Manual

53-1003230-01

brocade-aaa-ext

brocade-aaa-ext

Description Provides extensions to the brocade-aaa module for returning operational state information.

2

Top-level

containers

External

augmentations

RPCs Custom RPCs defined in this module follow.

Actions Proprietary actions defined in this module follow.

None

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show
| +--rw aaa-extensions:aaa-users

Return user information:

+---x user-session-info
+--ro output
+--ro user-role? string

module: brocade-common-def
+--rw show
| +--rw aaa-extensions:aaa-users
| | +--ro aaa-extensions:users
| | +--ro aaa-extensions:input
| | +--ro aaa-extensions:rbridge-id? common-def:rbridge-id-all-type

Network OS YANG Reference Manual 7
53-1003230-01

brocade-ag

2

brocade-ag

Description Provides a data model for managing Access Gateway.

Top-level

containers

External

augmentations

None

Nodes that augment other modules and their subtrees follow:

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw ag:ag
| +--rw ag:nport-menu
| | +--rw ag:nport-interface
| | +--rw ag:nport [agNPortNb]
| | +--rw ag:agNPortNb nport-interfaces-type
| | +--rw ag:map
| | +--rw ag:map-fport
| | +--rw ag:map-fport-interface
| | +--rw ag:map-fcoe* fport-interfaces-type
| +--rw ag:pg [pgid]
| | +--rw ag:pgid pgid-type
| | +--rw ag:nport
| | | +--rw ag:pg-nport-interface
| | | +--rw ag:nports* nport-interfaces-type
| | +--rw ag:modes* pg-policy-types
| | +--rw ag:rename? string
| +--rw ag:timeout
| | +--rw ag:fnmtovalue? uint32
| +--rw ag:counter
| +--rw ag:reliabilitycountervalue? uint32

RPCs None

Actions None

8 Network OS YANG Reference Manual

53-1003230-01

brocade-arp

Description Provides a data model for managing the Address Resolution Protocol (ARP).

brocade-arp

2

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-arp
+--rw hide-arp-holder
o--rw system-max
| +--rw arp? uint32
+--rw arp-entry [arp-ip-address]
+--rw arp-ip-address inet:ipv4-address
+--rw mac-address-value? mac-access-list:mac-address-type
+--rw interfacename? enumeration
+--rw (interfacetype)?
+--:(GigabitEthernet)
| +--rw GigabitEthernet? interface:interface-type
+--:(TenGigabitEthernet)
| +--rw TenGigabitEthernet? interface:interface-type
+--:(FortyGigabitEthernet)
| +--rw FortyGigabitEthernet? interface:interface-type
+--:(HundredGigabitEthernet)
| +--rw HundredGigabitEthernet? interface:interface-type
+--:(Ve)
+--rw Ve? interface:vlan-type

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw vrf:vrf [vrf-name]
| +--rw vrf:address-family
| | +--rw arp:arp-entry [arp-ip-address]
| | | +--rw arp:arp-ip-address inet:ipv4-address
| | | +--rw arp:mac-address-value?
mac-access-list:mac-address-type
| | | +--rw arp:interfacename? enumeration
| | | +--rw (interfacetype)?
| | | +--:(GigabitEthernet)
| | | | +--rw arp:GigabitEthernet? interface:interface-type
| | | +--:(TenGigabitEthernet)
| | | | +--rw arp:TenGigabitEthernet?
interface:interface-type
| | | +--:(FortyGigabitEthernet)
| | | | +--rw arp:FortyGigabitEthernet?
interface:interface-type
| | | +--:(HundredGigabitEthernet)
| | | | +--rw arp:HundredGigabitEthernet?
interface:interface-type
| | | +--:(Ve)
| | | +--rw arp:Ve? interface:vlan-type

RPCs Custom RPCs defined in this module follow.

Return ARP entries of the managed entity:

+---x get-arp
+--ro input
| +--ro (input-type)?
| +--:(interface)

Network OS YANG Reference Manual 9
53-1003230-01

2

brocade-arp

| | +--ro interface-type? enumeration
| | +--ro interface-name? union
| +--:(dynamic)
| | +--ro dynamic? empty
| +--:(static)
| | +--ro static? empty
| +--:(ip)
| +--ro ip-address? inet:ipv4-address
+--ro output
+--ro arp-entry [ip-address]
+--ro ip-address inet:ipv4-address
+--ro mac-address? mac-access-list:mac-address-type
+--ro interface-type? enumeration
+--ro interface-name? union
+--ro is-resolved? boolean
+--ro age? string
+--ro entry-type? enumeration

Actions None

10 Network OS YANG Reference Manual

53-1003230-01

brocade-beacon

brocade-beacon

Description Provides a data model enabling and disabling the interface beacon and chassis beacon.

2

Top-level

containers

External

augmentations

RPCs None

Actions Proprietary actions defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-beacon
+--rw beacon
+--rw enable
+--rw disable

None

Enable the interface beacon:

module: brocade-beacon
+--rw beacon
+--rw enable
| +--ro interface
| | +--ro input
| | | +--ro (interface-type)?
| | | +--:(fortygigabitethernet)
| | | | +--ro fortygigabitethernet string
| | | +--:(hundredgigabitethernet)
| | | | +--ro hundredgigabitethernet string
| | | +--:(gigabitethernet)
| | | | +--ro gigabitethernet string
| | | +--:(tengigabitethernet)
| | | +--ro tengigabitethernet string
| | +--ro output

Disable the interface beacon:

module: brocade-beacon
+--rw beacon
+--rw disable
+--ro interface
| +--ro input
| | +--ro (interface-type)?
| | +--:(fortygigabitethernet)
| | | +--ro fortygigabitethernet string
| | +--:(hundredgigabitethernet)
| | | +--ro hundredgigabitethernet string
| | +--:(gigabitethernet)
| | | +--ro gigabitethernet string
| | +--:(tengigabitethernet)
| | +--ro tengigabitethernet string
| +--ro output

Enable the chassis beacon:

module: brocade-beacon
+--rw beacon
+--rw enable
| +--ro chassis

Network OS YANG Reference Manual 11
53-1003230-01

brocade-beacon

2

| +--ro input
| +--ro output

Disable the chassis beacon:

module: brocade-beacon
+--rw beacon
+--rw disable
| +--ro chassis
| +--ro input
| +--ro output

12 Network OS YANG Reference Manual

53-1003230-01

brocade-bgp

Description This management module is an instrumentation to manage BGP Protocol.

brocade-bgp

2

Top-level

None

containers

External

Nodes that augment other modules and their subtrees follow.

augmentations

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw router
| +--rw bgp:bgp [vrf-name]
| | +--rw bgp:vrf-name string
| | +--rw bgp:router-bgp-cmds-holder
| | +--rw bgp:router-bgp-attributes
| | | +--rw bgp:local-as? local-as-type
| | | +--rw bgp:always-compare-med? empty
| | | +--rw bgp:compare-med-empty-aspath? empty
| | | +--rw bgp:med-missing-as-worst? empty
| | | +--rw bgp:as-path-ignore? empty
| | | +--rw bgp:compare-routerid? empty
| | | +--rw bgp:install-igp-cost? empty
| | | +--rw bgp:cluster-id
| | | | +--rw (ch-cluster-id)?
| | | | +--:(ca-cluster-id)
| | | | | +--rw bgp:cluster-id-value? decimal-number
| | | | +--:(ca-cluster-id-ipv4-address)
| | | | +--rw bgp:cluster-id-ipv4-address? inet:ipv4-address
| | | +--rw bgp:default-local-preference? local-preference-number
| | | +--rw bgp:distance
| | | | +--rw bgp:ext-route-distance? ext-route-distance
| | | | +--rw bgp:int-route-distance? int-route-distance
| | | | +--rw bgp:lcl-route-distance? lcl-route-distance
| | | +--rw bgp:capability
| | | | +--rw bgp:as4-enable? empty
| | | +--rw bgp:maxas-limit
| | | | +--rw bgp:in
| | | | +--rw bgp:num-as-in-path? num-as-in-path
| | | +--rw bgp:enforce-first-as? empty
| | | +--rw bgp:fast-external-fallover? empty
| | | +--rw bgp:timers
| | | | +--rw bgp:keep-alive? nei-keep-alive
| | | | +--rw bgp:hold-time? nei-hold-time
| | | +--rw bgp:log-dampening-debug? empty
| | | +--rw bgp:peer-grps
| | | | +--rw bgp:neighbor-peer-grp [router-bgp-neighbor-peer-grp]
| | | | +--rw bgp:router-bgp-neighbor-peer-grp bgp-peergroup
| | | | +--rw bgp:peer-group-name? empty
| | | | +--rw bgp:remote-as? bgp-remote-as
| | | | +--rw bgp:description? neighbor-description
| | | | +--rw bgp:shutdown
| | | | | +--rw bgp:shutdown-status? empty
| | | | | +--rw bgp:generate-rib-out? empty
| | | | +--rw bgp:local-as
| | | | | +--rw bgp:local-as-value? local-as-num

Network OS YANG Reference Manual 13
53-1003230-01

brocade-bgp

2

| | | | | +--rw bgp:no-prepend? empty
| | | | +--rw bgp:next-hop-self
| | | | | +--rw (ch-next-hop-self-type)?
| | | | | +--:(ca-next-hop-self-always)
| | | | | | +--rw bgp:next-hop-self-always? empty
| | | | | +--:(ca-next-hop-self-status)
| | | | | +--rw bgp:next-hop-self-status? empty
| | | | +--rw bgp:advertisement-interval
| | | | | +--rw bgp:value? adv-value
| | | | +--rw bgp:ebgp-multihop
| | | | | +--rw (ch-ebgp-multihop-type)?
| | | | | +--:(ca-ebgp-multihop-flag)
| | | | | | +--rw bgp:ebgp-multihop-flag? empty
| | | | | +--:(ca-ebgp-multihop-count)
| | | | | +--rw bgp:ebgp-multihop-count? uint32
| | | | +--rw bgp:maxas-limit
| | | | | +--rw bgp:in
| | | | | +--rw (ch-maxas-limit)?
| | | | | +--:(ca-maxas-limit-enable)
| | | | | | +--rw bgp:num-as-in-as-path? num-as-in-as-path
| | | | | +--:(ca-maxas-limit-disable)
| | | | | +--rw bgp:maxas-limit-disable? empty
| | | | +--rw bgp:password? bgp-password
| | | | +--rw bgp:enforce-first-as
| | | | | +--rw bgp:nei-enforce-first-as? empty
| | | | | +--rw bgp:nei-enforce-first-as-disable? empty
| | | | +--rw bgp:neighbor-capability
| | | | | +--rw bgp:as4
| | | | | +--rw bgp:neighbor-as4-enable? empty
| | | | | +--rw bgp:neighbor-as4-disable? empty
| | | | +--rw bgp:timers
| | | | | +--rw bgp:nei-keep-alive? nei-keep-alive
| | | | | +--rw bgp:nei-hold-time? nei-hold-time
| | | | +--rw bgp:update-source
| | | | | +--rw (ch-update-source)?
| | | | | +--:(ca-ipv4)
| | | | | | +--rw bgp:sip-ipv4-address? sip-ipv4-address
| | | | | +--:(ca-eth)
| | | | | | +--rw bgp:ethernet-interface
| | | | | | +--rw bgp:interface-type? enumeration
| | | | | | +--rw bgp:ethernet? update-source-ethernet-type
| | | | | +--:(ca-loopback)
| | | | | | +--rw bgp:loopback? loopback-interface
| | | | | +--:(ca-ve)
| | | | | +--rw bgp:ve-interface? interface:ve-type
| | | | +--rw bgp:remove-private-as? empty
| | | | +--rw bgp:as-override? empty
| | | | +--rw bgp:soft-reconfiguration
| | | | +--rw bgp:inbound? empty
| | | +--rw bgp:neighbor-ips
| | | +--rw bgp:neighbor-addr [router-bgp-neighbor-address]
| | | +--rw bgp:router-bgp-neighbor-address inet:ip-address
| | | +--rw bgp:remote-as? bgp-remote-as
| | | +--rw bgp:associate-peer-group? bgp-peergroup
| | | +--rw bgp:description? neighbor-description
| | | +--rw bgp:shutdown
| | | | +--rw bgp:shutdown-status? empty
| | | | +--rw bgp:generate-rib-out? empty
| | | +--rw bgp:local-as
| | | | +--rw bgp:local-as-value? local-as-num

14 Network OS YANG Reference Manual

53-1003230-01

brocade-bgp

| | | | +--rw bgp:no-prepend? empty
| | | +--rw bgp:next-hop-self
| | | | +--rw (ch-next-hop-self-type)?
| | | | +--:(ca-next-hop-self-always)
| | | | | +--rw bgp:next-hop-self-always? empty
| | | | +--:(ca-next-hop-self-status)
| | | | +--rw bgp:next-hop-self-status? empty
| | | +--rw bgp:advertisement-interval
| | | | +--rw bgp:value? adv-value
| | | +--rw bgp:ebgp-multihop
| | | | +--rw (ch-ebgp-multihop-type)?
| | | | +--:(ca-ebgp-multihop-flag)
| | | | | +--rw bgp:ebgp-multihop-flag? empty
| | | | +--:(ca-ebgp-multihop-count)
| | | | +--rw bgp:ebgp-multihop-count? uint32
| | | +--rw bgp:maxas-limit
| | | | +--rw bgp:in
| | | | +--rw (ch-maxas-limit)?
| | | | +--:(ca-maxas-limit-enable)
| | | | | +--rw bgp:num-as-in-as-path? num-as-in-as-path
| | | | +--:(ca-maxas-limit-disable)
| | | | +--rw bgp:maxas-limit-disable? empty
| | | +--rw bgp:password? bgp-password
| | | +--rw bgp:enforce-first-as
| | | | +--rw bgp:nei-enforce-first-as? empty
| | | | +--rw bgp:nei-enforce-first-as-disable? empty
| | | +--rw bgp:neighbor-capability
| | | | +--rw bgp:as4
| | | | +--rw bgp:neighbor-as4-enable? empty
| | | | +--rw bgp:neighbor-as4-disable? empty
| | | +--rw bgp:timers
| | | | +--rw bgp:nei-keep-alive? nei-keep-alive
| | | | +--rw bgp:nei-hold-time? nei-hold-time
| | | +--rw bgp:update-source
| | | | +--rw (ch-update-source)?
| | | | +--:(ca-ipv4)
| | | | | +--rw bgp:sip-ipv4-address? sip-ipv4-address
| | | | +--:(ca-eth)
| | | | | +--rw bgp:ethernet-interface
| | | | | +--rw bgp:interface-type? enumeration
| | | | | +--rw bgp:ethernet? update-source-ethernet-type
| | | | +--:(ca-loopback)
| | | | | +--rw bgp:loopback? loopback-interface
| | | | +--:(ca-ve)
| | | | +--rw bgp:ve-interface? interface:ve-type
| | | +--rw bgp:remove-private-as? empty
| | | +--rw bgp:as-override? empty
| | | +--rw bgp:soft-reconfiguration
| | | +--rw bgp:inbound? empty
| | +--rw bgp:address-family
| | +--rw bgp:ipv4
| | +--rw bgp:ipv4-unicast?
| | +--rw bgp:af-ipv4-uc-and-vrf-cmds-call-point-holder
| | | +--rw bgp:bgp-redistribute-internal? empty
| | | +--rw bgp:redistribute
| | | +--rw bgp:connected
| | | | +--rw bgp:redistribute-connected? empty
| | | | +--rw bgp:unicast-metric? conn-metric
| | | | +--rw bgp:redistribute-route-map? rmap-type
| | | +--rw bgp:ospf

2

Network OS YANG Reference Manual 15
53-1003230-01

brocade-bgp

2

| | | | +--rw bgp:redistribute-ospf? empty
| | | | +--rw bgp:match
| | | | | +--rw bgp:ospf-internal? empty
| | | | | +--rw bgp:ospf-external1? empty
| | | | | +--rw bgp:ospf-external2? empty
| | | | +--rw bgp:ospf-metric? conn-metric
| | | | +--rw bgp:ospf-route-map? rmap-type
| | | +--rw bgp:static
| | | +--rw bgp:redistribute-static? empty
| | | +--rw bgp:unicast-static-metric? conn-metric
| | | +--rw bgp:static-route-map? rmap-type
| | +--rw bgp:static-network [static-network-address]
| | | +--rw bgp:static-network-address inet:ipv4-prefix
| | | +--rw bgp:static-network-distance? sdistance
| | +--rw bgp:aggregate-address [aggregate-ip-prefix]
| | | +--rw bgp:aggregate-ip-prefix inet:ipv4-prefix
| | | +--rw bgp:advertise-map? advertise-map
| | | +--rw bgp:as-set? empty
| | | +--rw bgp:attribute-map? attribute-map
| | | +--rw bgp:summary-only? empty
| | | +--rw bgp:suppress-map? suppress-map
| | +--rw bgp:network [network-ipv4-address]
| | | +--rw bgp:network-ipv4-address inet:ipv4-prefix
| | | +--rw bgp:network-weight? absolute-decimal-number
| | | +--rw bgp:backdoor? empty
| | | +--rw bgp:network-route-map? rmap-type
| | +--rw bgp:af-ipv4-neighbor-peergroup-holder
| | | +--rw bgp:af-ipv4-neighbor-peergroup [af-ipv4-neighbor-peergroup-name]
| | | +--rw bgp:af-ipv4-neighbor-peergroup-name bgp-peergroup
| | | +--rw bgp:activate? empty
| | | +--rw bgp:filter-list
| | | | +--rw bgp:direction-in
| | | | | +--rw bgp:filter-list-direction-in-acl-name? ip-filter-name
| | | | | +--rw bgp:filter-list-name-direction-in? empty
| | | | +--rw bgp:direction-out
| | | | +--rw bgp:filter-list-direction-out-acl-name? ip-filter-name
| | | | +--rw bgp:filter-list-name-direction-out? empty
| | | +--rw bgp:maximum-prefix
| | | | +--rw bgp:max-prefix-limit? max-prefix-limit
| | | | +--rw bgp:threshold-holder
| | | | +--rw bgp:threshold? max-prefix-threshold
| | | | +--rw bgp:teardown? empty
| | | +--rw bgp:default-originate
| | | | +--rw bgp:default-originate-status? empty
| | | | +--rw bgp:default-originate-route-map? rmap-type
| | | +--rw bgp:prefix-list
| | | | +--rw bgp:direction-in
| | | | | +--rw bgp:prefix-list-direction-in-prefix-name?
nei-prefix-list-filter
| | | | | +--rw bgp:prefix-list-direction-in? empty
| | | | +--rw bgp:direction-out
| | | | +--rw bgp:prefix-list-direction-out-prefix-name?
nei-prefix-list-filter
| | | | +--rw bgp:prefix-list-direction-out? empty
| | | +--rw bgp:neighbor-route-map
| | | | +--rw bgp:neighbor-route-map-direction-in
| | | | | +--rw bgp:neighbor-route-map-name-direction-in?
common-def:name-string64
| | | | +--rw bgp:neighbor-route-map-direction-out

16 Network OS YANG Reference Manual

53-1003230-01

brocade-bgp

| | | | +--rw bgp:neighbor-route-map-name-direction-out?
common-def:name-string64
| | | +--rw bgp:route-reflector-client? empty
| | | +--rw bgp:send-community
| | | | +--rw bgp:send-community-status? empty
| | | | +--rw bgp:both? empty
| | | | +--rw bgp:extended? empty
| | | | +--rw bgp:standard? empty
| | | +--rw bgp:unsuppress-map
| | | | +--rw bgp:map-name? rmap-type
| | | +--rw bgp:af-nei-weight? nei-weight
| | +--rw bgp:af-ipv4-neighbor-address-holder
| | | +--rw bgp:af-ipv4-neighbor-address [af-ipv4-neighbor-address]
| | | +--rw bgp:af-ipv4-neighbor-address inet:ip-address
| | | +--rw bgp:activate? empty
| | | +--rw bgp:filter-list
| | | | +--rw bgp:direction-in
| | | | | +--rw bgp:filter-list-direction-in-acl-name? ip-filter-name
| | | | | +--rw bgp:filter-list-name-direction-in? empty
| | | | +--rw bgp:direction-out
| | | | +--rw bgp:filter-list-direction-out-acl-name? ip-filter-name
| | | | +--rw bgp:filter-list-name-direction-out? empty
| | | +--rw bgp:maximum-prefix
| | | | +--rw bgp:max-prefix-limit? max-prefix-limit
| | | | +--rw bgp:threshold-holder
| | | | +--rw bgp:threshold? max-prefix-threshold
| | | | +--rw bgp:teardown? empty
| | | +--rw bgp:default-originate
| | | | +--rw bgp:default-originate-status? empty
| | | | +--rw bgp:default-originate-route-map? rmap-type
| | | +--rw bgp:prefix-list
| | | | +--rw bgp:direction-in
| | | | | +--rw bgp:prefix-list-direction-in-prefix-name?
nei-prefix-list-filter
| | | | | +--rw bgp:prefix-list-direction-in? empty
| | | | +--rw bgp:direction-out
| | | | +--rw bgp:prefix-list-direction-out-prefix-name?
nei-prefix-list-filter
| | | | +--rw bgp:prefix-list-direction-out? empty
| | | +--rw bgp:neighbor-route-map
| | | | +--rw bgp:neighbor-route-map-direction-in
| | | | | +--rw bgp:neighbor-route-map-name-direction-in?
common-def:name-string64
| | | | +--rw bgp:neighbor-route-map-direction-out
| | | | +--rw bgp:neighbor-route-map-name-direction-out?
common-def:name-string64
| | | +--rw bgp:route-reflector-client? empty
| | | +--rw bgp:send-community
| | | | +--rw bgp:send-community-status? empty
| | | | +--rw bgp:both? empty
| | | | +--rw bgp:extended? empty
| | | | +--rw bgp:standard? empty
| | | +--rw bgp:unsuppress-map
| | | | +--rw bgp:map-name? rmap-type
| | | +--rw bgp:af-nei-weight? nei-weight
| | +--rw bgp:af-common-cmds-holder
| | | +--rw bgp:maximum-paths
| | | | +--rw bgp:load-sharing-value? uint32
| | | | +--rw bgp:ebgp? ebgp-paths
| | | | +--rw bgp:ibgp? ibgp-paths

2

Network OS YANG Reference Manual 17
53-1003230-01

brocade-bgp

2

| | | | +--rw bgp:use-load-sharing? empty
| | | +--rw bgp:multipath
| | | | +--rw bgp:multipath_ebgp? empty
| | | | +--rw bgp:multipath_ibgp? empty
| | | | +--rw bgp:multi-as? empty
| | | +--rw bgp:always-propagate? empty
| | | +--rw bgp:default-information-originate? empty
| | | +--rw bgp:rib-route-limit? decimal-number
| | | +--rw bgp:client-to-client-reflection? empty
| | | +--rw bgp:dampening
| | | | +--rw (ch-dampening-source)?
| | | | +--:(ca-dampening-flag)
| | | | | +--rw bgp:dampening-flag? empty
| | | | +--:(ca-dampening-specify-values)
| | | | | +--rw bgp:values
| | | | | +--rw bgp:half-time? htime
| | | | | +--rw bgp:reuse-value? damp-reuse-value
| | | | | +--rw bgp:start-suppress-time? damp-start-suppress-value
| | | | | +--rw bgp:max-suppress-time? damp-max-suppress-value
| | | | +--:(ca-dampening-route-map)
| | | | +--rw bgp:dampening-route-map? rmap-type
| | | +--rw bgp:default-metric? default-metric-number
| | | +--rw bgp:next-hop-enable-default? empty
| | | +--rw bgp:table-map
| | | | +--rw bgp:table-map-route-map? rmap-type
| | | +--rw bgp:update-time? update-time-type
| | +--rw bgp:next-hop-recursion? empty

RPCs None

Actions None

18 Network OS YANG Reference Manual

53-1003230-01

brocade-bprate-limit

Description Provides a data model for configuring the BP rate limit.

brocade-bprate-limit

2

Top-level

containers

External

augmentations

RPCs None

Actions None

Top-level nodes and their subtree hierarchies follow.

module: brocade-bprate-limit
+--rw bp-rate-limit
+--rw heavy
+--rw bp-rate-limit-slot [bp-rate-limit-slot-num]
+--rw bp-rate-limit-slot-num slotnumber

None

Network OS YANG Reference Manual 19
53-1003230-01

brocade-bum-storm-control

2

brocade-bum-storm-control

Description Provides a data model for controlling traffic storms. A traffic storm occurs when packets flood the

LAN, creating excessive traffic and degrading network performance. The BUM storm control feature
is meant to prevent disruptions on Layer 2 physical ports caused by excessive ingress broadcast,
multicast, and unknown unicast traffic. BUM Storm control allows you to limit the amount of BUM
traffic admitted to the system

Top-level

containers

External

augmentations

None

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw bum-storm-control:storm-control
| | | +--rw bum-storm-control:ingress [protocol-type]
| | | +--rw bum-storm-control:protocol-type enumeration
| | | +--rw bum-storm-control:rate-format? enumeration
| | | +--rw bum-storm-control:rate-bps? bps-rate-limit
| | | +--rw bum-storm-control:rate-percent? percentage-rate-limit
| | | +--rw bum-storm-control:bum-action? enumeration
| +--rw tengigabitethernet [name]
| | +--rw bum-storm-control:storm-control
| | | +--rw bum-storm-control:ingress [protocol-type]
| | | +--rw bum-storm-control:protocol-type enumeration
| | | +--rw bum-storm-control:rate-format? enumeration
| | | +--rw bum-storm-control:rate-bps? bps-rate-limit
| | | +--rw bum-storm-control:rate-percent? percentage-rate-limit
| | | +--rw bum-storm-control:bum-action? enumeration
| +--rw fortygigabitethernet [name]
| | +--rw bum-storm-control:storm-control
| | | +--rw bum-storm-control:ingress [protocol-type]
| | | +--rw bum-storm-control:protocol-type enumeration
| | | +--rw bum-storm-control:rate-format? enumeration
| | | +--rw bum-storm-control:rate-bps? bps-rate-limit
| | | +--rw bum-storm-control:rate-percent? percentage-rate-limit
| | | +--rw bum-storm-control:bum-action? enumeration
| +--rw hundredgigabitethernet [name]
| | +--rw bum-storm-control:storm-control
| | | +--rw bum-storm-control:ingress [protocol-type]
| | | +--rw bum-storm-control:protocol-type enumeration
| | | +--rw bum-storm-control:rate-format? enumeration
| | | +--rw bum-storm-control:rate-bps? bps-rate-limit
| | | +--rw bum-storm-control:rate-percent? percentage-rate-limit
| | | +--rw bum-storm-control:bum-action? enumeration

RPCs None

Actions None

20 Network OS YANG Reference Manual

53-1003230-01

brocade-cdp

Description Provides a data model for enabling or disabling the Cisco Discovery Protocol (CDP).

brocade-cdp

2

Top-level

containers

External

augmentations

RPCs None

Actions None

None

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw protocol
| +--rw cdp:cdp?

Network OS YANG Reference Manual 21
53-1003230-01

brocade-cee-map

2

brocade-cee-map

Description Provides a data model for managing the Converged Enhanced Ethernet (CEE) map.

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-cee-map
+--rw cee-map [name]
+--rw name common-def:name-string32
+--rw precedence? int32
+--rw priority-group-table [PGID]
| +--rw PGID qos-type-PGID
| +--rw weight? int32
| +--rw pfc enumeration
+--rw priority-table
| +--rw map-cos0-pgid? string
| +--rw map-cos1-pgid? string
| +--rw map-cos2-pgid? string
| +--rw map-cos3-pgid? string
| +--rw map-cos4-pgid? string
| +--rw map-cos5-pgid? string
| +--rw map-cos6-pgid? string
| +--rw map-cos7-pgid? string
+--rw remap
+--rw fabric-priority
| +--rw fabric-remapped-priority? int32
+--rw lossless-priority
+--rw lossless-remapped-priority? int32

None

RPCs None

Actions None

22 Network OS YANG Reference Manual

53-1003230-01

brocade-certutil

brocade-certutil

Description Provides a data model for certificate management operations. It provides tail-f actions to perform

the following functions:

• Import an LDAP CA certificate

• Remove an LDAP CA certificate

• Show the LDAP certificate

2

Top-level

containers

External

augmentations

RPCs None

Actions Proprietary actions defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-certutil
+--rw certutil
+--rw import

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw no
| +--rw certutil:certutil
+--rw show
| +--rw certutil:cert-util

Import an LDAP CA certificate:

module: brocade-certutil
+--rw certutil
+--rw import
+--ro ldapca
| +--ro input
| | +--ro protocol enumeration
| | +--ro user string
| | +--ro password? string
| | +--ro host string
| | +--ro directory string
| | +--ro file string
| | +--ro rbridge-id? common-def:rbridge-id-all-type
| +--ro output

Import a syslog server CA certificate:

module: brocade-certutil
+--rw certutil
+--rw import
+--ro syslogca
| +--ro input
| | +--ro protocol enumeration
| | +--ro user string
| | +--ro password? string
| | +--ro host string
| | +--ro directory string
| | +--ro file string
| | +--ro rbridge-id? common-def:rbridge-id-all-type
| +--ro output

Network OS YANG Reference Manual 23
53-1003230-01

brocade-certutil

2

Import an SSH public key:

module: brocade-certutil
+--rw certutil
+--rw import
+--ro sshkey
+--ro input
| +--ro user string
| +--ro host string
| +--ro directory string
| +--ro file string
| +--ro login string
| +--ro password? string
| +--ro rbridge-id? common-def:rbridge-id-all-type
+--ro output

Remove an LDAP CA certificate:

module: brocade-common-def
+--rw no
| +--rw certutil:certutil
| | +--ro certutil:ldapca
| | | +--ro certutil:input
| | | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | | +--ro certutil:output

Remove a syslog server CA certificate:

module: brocade-common-def
+--rw no
| +--rw certutil:certutil
| | +--ro certutil:syslogca
| | | +--ro certutil:input
| | | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | | +--ro certutil:output

Remove an SSH public key:

module: brocade-common-def
+--rw no
| +--rw certutil:certutil
| | +--ro certutil:sshkey
| | +--ro certutil:input
| | | +--ro certutil:user string
| | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | +--ro certutil:output

Show the LDAP CA certificate:

module: brocade-common-def
+--rw show
| +--rw certutil:cert-util
| | +--ro certutil:ldapcacert
| | | +--ro certutil:input
| | | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | | +--ro certutil:output

Show the syslog server CA certificate:

module: brocade-common-def
+--rw show
| +--rw certutil:cert-util
| | +--ro certutil:syslogcacert
| | | +--ro certutil:input

24 Network OS YANG Reference Manual

53-1003230-01

brocade-certutil

| | | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | | +--ro certutil:output

Show the SSH public key:

module: brocade-common-def
+--rw show
| +--rw certutil:cert-util
| | +--ro certutil:sshkey
| | +--ro certutil:input
| | | +--ro certutil:user string
| | | +--ro certutil:rbridge-id? common-def:rbridge-id-all-type
| | +--ro certutil:output

2

Network OS YANG Reference Manual 25
53-1003230-01

brocade-chassis

2

brocade-chassis

Description Provides a data model for enabling and disabling the chassis.

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-chassis
+--rw hide-virtual-ip-holder
| +--rw chassis
| +--rw virtual-ip? common-def:ipv4-prefix-mask
| +--rw virtual-ipv6? common-def:ipv6-address-prefix
| +--rw oper-address
| +--ro virtual-oper-Vip-address?
common-def:ipv4-address-prefix-type
| +--ro virtual-oper-VipV6-address* string
+--rw chassis
+--rw beacon
+--rw fan
+--rw airflow-direction

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw chassis:chassis
| +--rw chassis:virtual-ip? common-def:ipv4-prefix-mask
| +--rw chassis:virtual-ipv6? common-def:ipv6-address-prefix
| +--rw chassis:oper-address
| +--ro chassis:virtual-oper-Vip-address?
common-def:ipv4-address-prefix-type
| +--ro chassis:virtual-oper-VipV6-address* string

RPCs None

Actions Proprietary actions defined in this module follow.

Enable the chassis:

module: brocade-chassis
+--rw chassis
+--ro enable

Disable the chassis:

module: brocade-chassis
+--rw chassis
+--ro disable

Enable the chassis beacon:

module: brocade-chassis
+--rw chassis
+--rw beacon
| +--ro enable

Disable the chassis beacon:

module: brocade-chassis
+--rw chassis
+--rw beacon
| +--ro disable

26 Network OS YANG Reference Manual

53-1003230-01

Set the airflow direction to port-side-intake:

module: brocade-chassis
+--rw chassis
+--rw fan
+--rw airflow-direction
+--ro port-side-intake

Set the airflow direction to port-side-exhaust:

module: brocade-chassis
+--rw chassis
+--rw fan
+--rw airflow-direction
+--ro port-side-exhaust

brocade-chassis

2

Network OS YANG Reference Manual 27
53-1003230-01

brocade-clock

2

brocade-clock

Description Provides a data model for managing the local clock. It provides mechanisms for setting the local

clock time and time zone and for retrieving local clock information.

Top-level

containers

External

augmentations

RPCs Custom RPCs defined in this module follow.

Actions Proprietary actions defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-clock
+--rw clock-set-datetime
+--rw clock-set-timezone

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
| +--rw clock-server:clock

Retrieve local clock information:

+---x show-clock
+--ro input
| +--ro rbridge-id? common-def:rbridge-id-all-type
+--ro output
+--ro clock-time
+--ro rbridge-id-out? common-def:rbridge-id-type
+--ro current-time? ietfyang:date-and-time
+--ro timezone? string

Set the date and time:

module: brocade-clock
+--rw clock-set-datetime
| +--ro clock
| +--ro input
| | +--ro set ietfyang:date-and-time
| | +--ro rbridge-id? common-def:rbridge-id-all-type
| +--ro output

Set the time zone:

module: brocade-clock
+--rw clock-set-timezone
+--ro clock
+--ro input
| +--ro timezone common-def:timezone
| +--ro rbridge-id? common-def:rbridge-id-all-type
+--ro output

Set the time zone:

module: brocade-common-def
+--rw no
| +--rw clock-server:clock
| | +--ro clock-server:timezone
| | +--ro clock-server:input
| | | +--ro clock-server:rbridge-id? common-def:rbridge-id-all-type
| | +--ro clock-server:output

28 Network OS YANG Reference Manual

53-1003230-01

brocade-common-def

brocade-common-def

Description Provides a data model for commonly used data types derived in the Brocade namespace.

2

Top-level

containers

External

augmentations

RPCs None

Actions None

Top-level nodes and their subtree hierarchies follow.

module: brocade-common-def

+--rw show
| +--rw defaults
+--rw clear
+--rw no
+--rw ip
+--rw ipv6
+--rw router

None

Network OS YANG Reference Manual 29
53-1003230-01

brocade-dhcp

2

brocade-dhcp

Description Provides a data model to manage DHCP functionality.

Top-level

containers

External

augmentations

None

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw brocade-interface:interface
| | +--rw ip-config:ip
| | | +--rw dhcp:interface-ve-dhcp-conf
| | | | +--rw dhcp:dhcp
| | | | +--rw dhcp:relay
| | | | +--rw dhcp:servers [relay-ip-addr server-vrf-name]
| | | | +--rw dhcp:relay-ip-addr dhcp-ipv4-address
| | | | +--rw dhcp:server-vrf-name common-def:vrf-name

module: brocade-interface
+--rw interface

| +--rw hundredgigabitethernet [name]
| | +--rw ip
| | | +--rw dhcp:interface-hu-dhcp-conf
| | | | +--rw dhcp:dhcp
| | | | +--rw dhcp:relay
| | | | +--rw dhcp:servers [relay-ip-addr server-vrf-name]
| | | | +--rw dhcp:relay-ip-addr dhcp-ipv4-address
| | | | +--rw dhcp:server-vrf-name common-def:vrf-name

module: brocade-interface
+--rw interface
| +--rw fortygigabitethernet [name]
| | +--rw ip
| | | +--rw dhcp:interface-fo-dhcp-conf
| | | | +--rw dhcp:dhcp
| | | | +--rw dhcp:relay
| | | | +--rw dhcp:servers [relay-ip-addr server-vrf-name]
| | | | +--rw dhcp:relay-ip-addr dhcp-ipv4-address
| | | | +--rw dhcp:server-vrf-name common-def:vrf-name

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet [name]
| | +--rw ip
| | | +--rw dhcp:interface-te-dhcp-conf
| | | | +--rw dhcp:dhcp
| | | | +--rw dhcp:relay
| | | | +--rw dhcp:servers [relay-ip-addr server-vrf-name]
| | | | +--rw dhcp:relay-ip-addr dhcp-ipv4-address
| | | | +--rw dhcp:server-vrf-name common-def:vrf-name

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw ip
| | | +--rw dhcp:interface-gi-dhcp-conf
| | | | +--rw dhcp:dhcp

30 Network OS YANG Reference Manual

53-1003230-01

| | | | +--rw dhcp:relay
| | | | +--rw dhcp:servers [relay-ip-addr server-vrf-name]
| | | | +--rw dhcp:relay-ip-addr dhcp-ipv4-address
| | | | +--rw dhcp:server-vrf-name common-def:vrf-name

RPCs None

Actions None

brocade-dhcp

2

Network OS YANG Reference Manual 31
53-1003230-01

brocade-diagnostics

2

brocade-diagnostics

Description Provides a data model for managing diagnostic tests. It provides the ability to enable or disable

power-on self tests (POSTs) and actions to initiate the tests listed in Table 1.

TABLE 1 Diagnostic actions

Action Purpose

burninerrclear Clears the errors that are stored in the nonvolatile storage on the slot during the

burn-in process.

clearerror Clears the diagnostics failure status.

portledtest Runs various action modes on the port LEDs and validates the functionality.

portloopbacktest Sends frames between various ASICs on the switch and validates the ASIC

functionality.

post Performs power on self test? REVIEWERS PLEASE CONFIRM!!!!

prbstest Performs pseudo-random binary-sequence tests.

setcycle Configures all the parameters required for the system verification test.

setdbg Changes the debug level.

systemverification Runs a combination of various hardware diagnostic tests.

turboramtest Performs a turbo static RAM (SRAM) test of the ASIC chips.

Top-level

containers

External

augmentations

RPCs None

Actions Proprietary actions defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-diagnostics
+--rw diag
| +--rw post
+--rw fos

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show

| +--rw diagnostics:diag
| | +--rw diagnostics:post

Run the turbo RAM test:

module: brocade-diagnostics

+--rw diag
| +--ro turboramtest
| | +--ro input
| | | +--ro slot slotidtype
| | | +--ro passcnt? uint32
| | +--ro output
| | +--ro result? string

Run the port loopback test:

module: brocade-diagnostics

+--rw diag
| +--ro portloopbacktest

32 Network OS YANG Reference Manual

53-1003230-01

brocade-diagnostics

| | +--ro input
| | | +--ro (interfaces)?
| | | | +--:(slot)
| | | | | +--ro slot slotidtype
| | | | +--:(ethernet)
| | | | | +--ro ethernet? interfaces:interface-type
| | | | +--:(fibrechannel)
| | | | +--ro fibrechannel? interfaces:interface-type
| | | +--ro nframes? uint32
| | | +--ro lbmode? uint32
| | | +--ro spdmode? enumeration
| | +--ro output
| | +--ro result? string

Run the port LED test:

module: brocade-diagnostics

+--rw diag
| +--ro portledtest
| | +--ro input
| | | +--ro (interfaces)?
| | | | +--:(slot)
| | | | | +--ro slot slotidtype
| | | | +--:(ethernet)
| | | | | +--ro ethernet? interfaces:interface-type
| | | | +--:(fibrechannel)
| | | | +--ro fibrechannel? interfaces:interface-type
| | | +--ro action? enumeration
| | | +--ro npass? uint32
| | +--ro output
| | | +--ro result? string

2

Run the system verification test:

module: brocade-diagnostics

+--rw diag
| +--ro systemverification
| | +--ro input
| | | +--ro (sysv)?
| | | +--:(short)
| | | | +--ro short? empty
| | | +--:(stop)
| | | +--ro stop? empty
| | +--ro output
| | | +--ro result? string

Run the pseudorandom binary sequence test:

module: brocade-diagnostics

+--rw diag
| +--ro prbstest
| | +--ro input
| | | +--ro slot slotidtype
| | | +--ro pattern? enumeration
| | +--ro output
| | | +--ro result? string

Clear the diagnostic failure status:

module: brocade-diagnostics

+--rw diag

| +--ro clearerror
| | +--ro output

Network OS YANG Reference Manual 33
53-1003230-01

brocade-diagnostics

2

| | | +--ro result? string

Clear the errors that are stored in the nonvolatile storage during the burn-in process:

module: brocade-diagnostics

+--rw diag

| +--ro burninerrclear

| | +--ro output
| | | +--ro result? string

Configure all the parameters required for the system verification test:

module: brocade-diagnostics

+--rw diag

| +--ro setcycle
| | +--ro input
| | | +--ro tbr_passes? uint32
| | | +--ro num_of_runs? uint32
| | | +--ro min_lb_mode? uint32
| | | +--ro plb_nframes? uint32
| | +--ro output
| | | +--ro result? string

Set debug:

module: brocade-diagnostics

+--rw diag

| +--ro setdbg
| | +--ro input
| | +--ro level? enumeration

Run post verification test:

module: brocade-diagnostics

+--rw diag

| +--rw post
| +--rw rbridge-id [rbridge-id]
| | +--rw enable? empty
| | +--rw rbridge-id common-def:rbridge-id-type
| +--rw enable? empty

Run native FOS commands:

module: brocade-diagnostics

+--rw fos

+--ro exec
+--ro input
| +--ro (op)?
| +--:(file)
| | +--ro file? string
| +--:(cmd)
| +--ro cmd? string
+--ro output

Displays results of Diagpost:

module: brocade-common-def

+--rw show
| +--rw diagnostics:diag
| | +--rw diagnostics:post
| | | +--ro diagnostics:results
| | | +--ro diagnostics:input
| | | | +--ro (localremote)?
| | | | | +--:(local)

34 Network OS YANG Reference Manual

53-1003230-01

brocade-diagnostics

| | | | | | +--ro diagnostics:slot slotidtype
| | | | | +--:(remote)
| | | | | +--ro diagnostics:rbridge-id? common-def:rbridge-id-type
| | | | +--ro (postresult)?
| | | | +--:(brief)
| | | | | +--ro diagnostics:brief? empty
| | | | +--:(detailed)
| | | | +--ro diagnostics:detailed? empty
| | | +--ro diagnostics:output
| | | +--ro diagnostics:result? string

2

Displays currently running diagnostic tests:

module: brocade-common-def

+--rw show
| | +--ro diagnostics:status
| | | +--ro diagnostics:input
| | | | +--ro (localremote)?
| | | | +--:(local)
| | | | | +--ro diagnostics:slot slotidtype
| | | | +--:(remote)
| | | | +--ro diagnostics:rbridge-id? common-def:rbridge-id-type
| | | +--ro diagnostics:output
| | | +--ro diagnostics:result? string

Check the status of last run system verification test:

module: brocade-common-def

+--rw show

| | +--ro diagnostics:burninstatus
| | | +--ro diagnostics:input
| | | | +--ro diagnostics:rbridge-id? common-def:rbridge-id-type
| | | +--ro diagnostics:output
| | | +--ro diagnostics:result? string

Check error log:

module: brocade-common-def

+--rw show

| | +--ro diagnostics:burninerrshow
| | +--ro diagnostics:input
| | | +--ro diagnostics:rbridge-id? common-def:rbridge-id-type
| | +--ro diagnostics:output
| | +--ro diagnostics:result? string

Network OS YANG Reference Manual 35
53-1003230-01

brocade-dot1x

2

brocade-dot1x

Description Provides a data model for managing the 802.1x authorization feature.

IEEE 802.1X is an IEEE standard for port-based Network Access Control (PNAC). It is a networking
protocol that provides an authentication mechanism to devices attempting to attach to a LAN or
WLAN. IEEE 802.1X defines the encapsulation of the Extensible Authentication Protocol (EAP) over
IEEE 802, which is known as EAP over LAN or EAPoL.

802.1x involves three parties:

• Supplicant—A device that connects to a network

• Authenticator—A network device such as an Ethernet switch

• Authentication server—A host running software that supports RADIUS and EAP

This module defines the parameters used for the PNAC.

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-dot1x
+--rw dot1x
+--rw enable? empty
+--rw test
+--rw timeout? dot1x-readinesstest-timeout-interval

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw interface
| +--rw gigabitethernet
| | +--rw dot1x:dot1x
| | | +--rw dot1x:authentication? empty
| | | +--rw dot1x:port-control? enumeration
| | | +--rw dot1x:protocol-version? uint32
| | | +--rw dot1x:quiet-period? uint32
| | | +--rw dot1x:reauthMax? uint32
| | | +--rw dot1x:reauthentication? empty
| | | +--rw dot1x:timeout
| | | +--rw dot1x:re-authperiod? dot1x-reauth-timeout-interval
| | | +--rw dot1x:server-timeout? dot1x-server-timeout-interval
| | | +--rw dot1x:supp-timeout? dot1x-supp-timeout-interval
| | | +--rw dot1x:tx-period? dot1x-tx-timeout-interval

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet
| | +--rw dot1x:dot1x
| | | +--rw dot1x:authentication? empty
| | | +--rw dot1x:port-control? enumeration
| | | +--rw dot1x:protocol-version? uint32
| | | +--rw dot1x:quiet-period? uint32
| | | +--rw dot1x:reauthMax? uint32
| | | +--rw dot1x:reauthentication? empty
| | | +--rw dot1x:timeout
| | | +--rw dot1x:re-authperiod? dot1x-reauth-timeout-interval
| | | +--rw dot1x:server-timeout? dot1x-server-timeout-interval
| | | +--rw dot1x:supp-timeout? dot1x-supp-timeout-interval
| | | +--rw dot1x:tx-period? dot1x-tx-timeout-interval

36 Network OS YANG Reference Manual

53-1003230-01

brocade-dot1x

module: brocade-interface
+--rw interface
| +--rw fortygigabitethernet
| | +--rw dot1x:dot1x
| | | +--rw dot1x:authentication? empty
| | | +--rw dot1x:port-control? enumeration
| | | +--rw dot1x:protocol-version? uint32
| | | +--rw dot1x:quiet-period? uint32
| | | +--rw dot1x:reauthMax? uint32
| | | +--rw dot1x:reauthentication? empty
| | | +--rw dot1x:timeout
| | | +--rw dot1x:re-authperiod? dot1x-reauth-timeout-interval
| | | +--rw dot1x:server-timeout? dot1x-server-timeout-interval
| | | +--rw dot1x:supp-timeout? dot1x-supp-timeout-interval
| | | +--rw dot1x:tx-period? dot1x-tx-timeout-interval

module: brocade-interface
+--rw interface
| +--rw hundredgigabitethernet
| | +--rw dot1x:dot1x
| | | +--rw dot1x:authentication? empty
| | | +--rw dot1x:port-control? enumeration
| | | +--rw dot1x:protocol-version? uint32
| | | +--rw dot1x:quiet-period? uint32
| | | +--rw dot1x:reauthMax? uint32
| | | +--rw dot1x:reauthentication? empty
| | | +--rw dot1x:timeout
| | | +--rw dot1x:re-authperiod? dot1x-reauth-timeout-interval
| | | +--rw dot1x:server-timeout? dot1x-server-timeout-interval
| | | +--rw dot1x:supp-timeout? dot1x-supp-timeout-interval
| | | +--rw dot1x:tx-period? dot1x-tx-timeout-interval

2

RPCs None

Actions None

Network OS YANG Reference Manual 37
53-1003230-01

brocade-eld

2

brocade-eld

Description Provides a data model for configuring global parameters for Edge-Loop-Detection. Interface

parameters are modeled in the brocade-interface module.

Top-level

containers

External

augmentations

RPCs None

Actions None

None

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw protocol
| +--rw eld:edge-loop-detection
| | +--rw eld:pdu-rx-limit? uint32
| | +--rw eld:hello-interval? uint32
| | +--rw eld:shutdown-time? uint32
| | +--rw eld:mac-refresh-time-config
| | +--rw eld:mac-refresh-time? uint32
| | +--rw eld:mac-refresh-type? enumeration

38 Network OS YANG Reference Manual

53-1003230-01

brocade-Enclosure-show

brocade-Enclosure-show

Description Provides a data model for obtaining the enclosure related information on embedded paltforms.

2

Top-level

containers

External

augmentations

RPCs None

Actions Run to check the present slot-id of switch:

None

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show
| +--rw Enclosure-show:enclosure

module: brocade-common-def
+--rw show
| +--rw Enclosure-show:enclosure
| | +--ro Enclosure-show:slotid
| | | +--ro Enclosure-show:input

Run to check the chassis model name:

module: brocade-common-def
+--rw show
| +--rw Enclosure-show:enclosure
| | +--ro Enclosure-show:modelname
| | | +--ro Enclosure-show:input

Network OS YANG Reference Manual 39
53-1003230-01

brocade-fabric-service

2

brocade-fabric-service

Description Provides a data model for managing VCS fabric-related information. VCS fabric refers to the ability

of a group of physical Ethernet switches, inter-connected in an arbitrary way using the regular
front-end data ports, to present themselves as one unified and transparent Ethernet switching
service to the external network.

The inter-connecting network that contains the individual switches is referred as the fabric. The
group of physical Ethernet switches in the fabric is referred to as the cluster.

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-fabric-service
+--rw fabric
x--rw route
+--rw mcast
+--rw rbridge-id [rbridge-id]
+--rw rbridge-id common-def:rbridge-id-type
+--rw priority? common-def:mcast-priority-type

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric
| | +--rw fabric-service:route

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]

+--rw fabric-service:fabric
| +--rw fabric-service:ecmp
| | +--rw fabric-service:ecmp-load-balance? enumeration
| | +--rw fabric-service:load-balance-hash-swap? hashswap-type
| +--rw fabric-service:route
| | +--rw fabric-service:mcast
| | +--rw fabric-service:priority? common-def:mcast-priority-type
| +--rw fabric-service:port-channel [po-id]
| +--rw fabric-service:po-id uint32
| +--rw fabric-service:vlag-load-balance? enumeration

RPCs Custom RPCs defined in this module follow.

+---x show-linkinfo
| +--ro input
| | +--ro all? empty
| +--ro output
| +--ro show-link-info [linkinfo-rbridgeid]
| +--ro linkinfo-rbridgeid common-def:rbridge-id-type
| +--ro linkinfo-domain-reachable? linkinfo-domain-reachable-type
| +--ro linkinfo-wwn? common-def:wwn-type
| +--ro linkinfo-version? uint32
| +--ro linkinfo-isl [linkinfo-isl-linknumber]
| +--ro linkinfo-isl-linknumber uint32
| +--ro linkinfo-isllink-destdomain?
| +--ro linkinfo-isllink-srcport? uint16
| +--ro linkinfo-isllink-srcport-type? interfacetype-type
| +--ro linkinfo-isllink-srcport-interface?
| +--ro linkinfo-isllink-destport? uint16

40 Network OS YANG Reference Manual

53-1003230-01

brocade-fabric-service

| +--ro linkinfo-isl-linkcost? uint32
| +--ro linkinfo-isllink-costcount? uint32
| +--ro linkinfo-isllink-type? uint32
| +--ro linkinfo-trunked? linkinfo-trunked-type
+---x show-portindex-interface-info
| +--ro input
| | +--ro all? empty
| +--ro output
| +--ro show-portindex-interface [portsgroup-rbridgeid]
| +--ro portsgroup-rbridgeid common-def:rbridge-id-type
| +--ro show-portindex [port-index]
| +--ro port-index uint32
| +--ro port-type? ethernet-port-type
| +--ro port-interface? interface:interface-type
+--ro input
| +--ro all? empty
+--ro output
+--ro show-fibrechannel-interface [portsgroup-rbridgeid]
+--ro portsgroup-rbridgeid common-def:rbridge-id-type
+--ro show-fibrechannel-info [port-index]
+--ro port-interface? interface:interface-type
+--ro port-index uint32
+--ro port-type? porttype-type
+--ro port-wwn? common-def:wwn-type
+--ro remote-port-wwn? common-def:wwn-type
+--ro remote-node-wwn? common-def:wwn-type
+--ro port-state? string
+--ro port-status? string
+--ro port-status-message? string
+--ro port-health? string
+--ro port-trunked? boolean
+--ro port-trunk-master? uint32
+--ro port-actual-distance? uint32
+--ro port-desired-credit? uint32
+--ro port-buffer-allocated? uint32
+--ro port-licensed? boolean
+--ro port-address? fabric-portid-type

2

Actions Proprietary actions defined in this module follow.

Obtain the entire VCS fabric membership information:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric
| | +--ro fabric-service:all
| | | +--ro fabric-service:input
| | | +--ro fabric-service:output
| | | +--ro fabric-service:fabric-showall-cluster
[fabric-showall-rbridge-id]
| | | +--ro fabric-service:fabric-showall-rbridge-id
common-def:rbridge-id-type
| | | +--ro fabric-service:fabric-showall-wwn?
common-def:wwn-type
| | | +--ro fabric-service:fabric-showall-ipaddress?
common-def:inet-address-type
| | | +--ro fabric-service:fabric-showall-name? string
| | | +--ro fabric-service:fabric-showall-version? string
| | | +--ro fabric-service:fabric-showall-swbd-number? int32
| | | +--ro fabric-service:fabric-is-principalswitch? boolean

Network OS YANG Reference Manual 41
53-1003230-01

brocade-fabric-service

2

| | | +--ro fabric-service:fabric-showall-ipv6address?
common-def:inet-address-type

Obtain ISL information:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--ro fabric-service:isl
| | | +--ro fabric-service:input
| | | +--ro (rbridge-id-or-all)?
| | | +--:(rbridge-id)
| | | | +--ro fabric-service:rbridge-id? common-def:rbridge-id-type
| | | +--:(all)
| | | +--ro fabric-service:all? empty

Obtain detailed information about all ISL ports:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--ro fabric-service:islports
| | | +--ro fabric-service:input
| | | +--ro fabric-service:rbridge-id? common-def:rbridge-id-type

Obtain ISL trunk information:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--ro fabric-service:trunk
| | | +--ro fabric-service:input
| | | | +--ro (rbridge-id-or-all)?
| | | | +--:(rbridge-id)
| | | | | +--ro fabric-service:rbridge-id? common-def:rbridge-id-type
| | | | +--:(all)
| | | | +--ro fabric-service:all? empty
| | | +--ro fabric-service:output
| | | +--ro fabric-service:show-trunk-list
| | | +--ro fabric-service:trunk-list-groups
| | | +--ro fabric-service:trunk-list-group? uint32
| | | +--ro fabric-service:trunk-list-member
| | | +--ro fabric-service:trunk-list-src-port? uint32
| | | +--ro fabric-service:trunk-list-interface-type?
interfacetype-type
| | | +--ro fabric-service:trunk-list-src-interface?
interface:interface-type
| | | +--ro fabric-service:trunk-list-nbr-rbridge-id? uint32
| | | +--ro fabric-service:trunk-list-nbr-port? uint32
| | | +--ro fabric-service:trunk-list-nbr-wwn?
common-def:wwn-type
| | | +--ro fabric-service:trunk-list-is-primary?
trunk-list-is-primary-type

Obtain multicast routing information:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--rw fabric-service:route
| | +--ro fabric-service:multicast
| | | +--ro fabric-service:input
| | | +--ro (rbridge-id-or-all)?

42 Network OS YANG Reference Manual

53-1003230-01

brocade-fabric-service

| | | +--:(rbridge-id)
| | | | +--ro fabric-service:rbridge-id?
common-def:rbridge-id-type
| | | +--:(all)
| | | +--ro fabric-service:all? empty

Obtain fabric topology information from the perspective of a VCS fabric node:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--rw fabric-service:route

| | +--ro fabric-service:topology
| | | +--ro fabric-service:input
| | | +--ro fabric-service:dest-rbridge-id?
common-def:rbridge-id-type
| | | +--ro fabric-service:src-rbridge-id?
common-def:rbridge-id-type

Obtain routing information and states along a path that includes multiple switches:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--rw fabric-service:route

| | +--ro fabric-service:pathinfo
| | | +--ro fabric-service:input

2

Obtains link information for all the links in the fabric:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--rw fabric-service:route

| | +--ro fabric-service:linkinfo
| | | +--ro fabric-service:input
| | | +--ro fabric-service:output
| | | +--ro fabric-service:show-link-info [linkinfo-rbridgeid]
| | | +--ro fabric-service:linkinfo-rbridgeid
common-def:rbridge-id-type
| | | +--ro fabric-service:linkinfo-domain-reachable?
linkinfo-domain-reachable-type
| | | +--ro fabric-service:linkinfo-wwn?
common-def:wwn-type
| | | +--ro fabric-service:linkinfo-version? uint32
| | | +--ro fabric-service:linkinfo-isl [linkinfo-isl-linknumber]
| | | +--ro fabric-service:linkinfo-isl-linknumber
uint32
| | | +--ro fabric-service:linkinfo-isllink-destdomain?
common-def:rbridge-id-type
| | | +--ro fabric-service:linkinfo-isllink-srcport?
uint16
| | | +--ro fabric-service:linkinfo-isllink-srcport-type?
interfacetype-type
| | | +--ro fabric-service:linkinfo-isllink-srcport-interface?
interface:interface-type
| | | +--ro fabric-service:linkinfo-isllink-destport?
uint16
| | | +--ro fabric-service:linkinfo-isllink-destport-type?
interfacetype-type

Network OS YANG Reference Manual 43
53-1003230-01

brocade-fabric-service

2

| | | +--ro fabric-service:linkinfo-isllink-destport-interface?
interface:interface-type
| | | +--ro fabric-service:linkinfo-isl-linkcost?
uint32
| | | +--ro fabric-service:linkinfo-isllink-costcount?
uint32
| | | +--ro fabric-service:linkinfo-isllink-type?
uint32
| | | +--ro fabric-service:linkinfo-trunked?
linkinfo-trunked-type

Obtain the Fabric Shortest Path First (FSPF) link state information for a VCS fabric node:

module: brocade-common-def
+--rw show
| +--rw fabric-service:fabric

| | +--rw fabric-service:route

| | +--ro fabric-service:neighbor-state
| | +--ro fabric-service:input
| | +--ro (rbridge-id-or-all)?
| | +--:(rbridge-id)
| | | +--ro fabric-service:rbridge-id?
common-def:rbridge-id-type
| | +--:(all)
| | +--ro fabric-service:all? empty

44 Network OS YANG Reference Manual

53-1003230-01

brocade-fc-auth

brocade-fc-auth

Description Provides a data model for configuring Fibre Channel authentication through Fibre Channel Security

Protocol (FCSP) and Switch Connection Control (SCC) security policy parameters.

2

Top-level

containers

Top-level nodes and their subtree hierarchies follow.

module: brocade-fc-auth
+--rw fcsp
| +--rw auth-secret
+--rw fcsp-sa
| +--rw fcsp
| +--rw auth
| +--rw proto
| | +--rw auth-type? fcsp-authtype
| | +--rw group? string
| | +--rw hash? fcsp-hashtype
| +--rw policy
| +--rw switch? fcsp-switch-policy-state
+--rw secpolicy
| +--rw action
+--rw secpolicy-sa
+--rw secpolicy
+--rw defined-policy
| +--rw policies [policy]
| +--rw policy secpolicy-type
| +--rw member-entry [member]
| +--rw member string
+--rw active-policy
+--rw policies [policy]
+--rw policy secpolicy-type
+--rw member-entry [member]
+--rw member string

External

augmentations

Network OS YANG Reference Manual 45
53-1003230-01

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show

| +--rw brcd-fc-auth:fcsp
| +--rw brcd-fc-auth:authsecret

module: brocade-common-def

+--rw no
| +--rw brcd-fc-auth:fcsp
| +--rw brcd-fc-auth:auth-secret

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw brcd-fc-auth:fcsp
| +--rw brcd-fc-auth:auth
| +--rw brcd-fc-auth:proto
| | +--rw brcd-fc-auth:auth-type? fcsp-authtype
| | +--rw brcd-fc-auth:group? string
| | +--rw brcd-fc-auth:hash? fcsp-hashtype
| +--rw brcd-fc-auth:policy
| +--rw brcd-fc-auth:switch? fcsp-switch-policy-state

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]

brocade-fc-auth

2

+--rw brcd-fc-auth:secpolicy
| +--rw brcd-fc-auth:defined-policy
| | +--rw brcd-fc-auth:policies [policy]
| | +--rw brcd-fc-auth:policy secpolicy-type
| | +--rw brcd-fc-auth:member-entry [member]
| | +--rw brcd-fc-auth:member string
| +--rw brcd-fc-auth:active-policy
| +--rw brcd-fc-auth:policies [policy]
| +--rw brcd-fc-auth:policy secpolicy-type
| +--rw brcd-fc-auth:member-entry [member]
| +--rw brcd-fc-auth:member string

RPCs None

Actions Proprietary actions defined in this module follow.

Configure the authorization secret for DH-CHAP:

module: brocade-fc-auth

+--rw fcsp
| +--rw auth-secret
| +--ro dhchap
| +--ro input
| | +--ro node string
| | +--ro peer-secret? string
| | +--ro local-secret? string
| +--ro output
| +--ro result? string

Return the device WWN for which a shared secret is configured:

module: brocade-common-def
+--rw show

| +--rw brcd-fc-auth:fcsp
| | +--rw brcd-fc-auth:authsecret
| | +--ro brcd-fc-auth:dhchap
| | +--ro brcd-fc-auth:input
| | +--ro brcd-fc-auth:output
| | +--ro brcd-fc-auth:auth-show-secret [nodeid]
| | +--ro brcd-fc-auth:nodeid string

Delete the authorization secret for DH-CHAP:

module: brocade-common-def
+--rw no

| +--rw brcd-fc-auth:fcsp
| +--rw brcd-fc-auth:auth-secret
| +--ro brcd-fc-auth:dhchap
| +--ro brcd-fc-auth:input
| | +--ro (op)?
| | +--:(node)
| | | +--ro brcd-fc-auth:node common-def:wwn-type
| | +--:(all)
| | +--ro brcd-fc-auth:all empty

Activate all the defined FC authorization policies:

module: brocade-fc-auth

+--rw secpolicy
| +--rw action
| +--ro activate

46 Network OS YANG Reference Manual

53-1003230-01

brocade-fc-auth

| +--ro input
| | +--ro rbridge-id? common-def:rbridge-id-all-type
| +--ro output

2

Network OS YANG Reference Manual 47
53-1003230-01

brocade-fcoe

2

brocade-fcoe

Description Provides a data model for managing the Fibre Channel over Ethernet (FCoE) feature. It provides a

mechanism to configure FCoE maps and the FCoE interface.

FCoE is an encapsulation of Fibre Channel frames over Ethernet networks which allows Fibre
Channel to use 10 Gigabit Ethernet networks (or higher speeds) while preserving the Fibre Channel
protocol.

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-fcoe
+--rw fcoe-fsb
| +--rw fcoe-fsb-enable? empty
+--rw fcoe
+--rw fcoe-fabric-map [fcoe-fabric-map-name]
| +--rw fcoe-fabric-map-name fcoe-fabric-map-name-type
| +--rw fcoe-fabric-map-vlan? fcoe-vlan-type
| +--rw fcoe-fabric-map-priority? fcoe-priority-type
| +--rw fcoe-fabric-map-virtual-fabric? fcoe-vfid-type
| +--rw fcoe-fabric-map-fcmap? fcoe-fcmap-type
| +--rw fcoe-fabric-map-max-enodes? fcoe-max-enodes-per-rbridge-type
| +--rw fcoe-fabric-map-enodes-cfg? fcoe-enodes-cfg-type
| +--rw fcoe-fip-advertisement
| | +--rw fcoe-fip-advertisement-interval? int32
| +--rw fcoe-fip-keep-alive
| +--rw fcoe-fip-keep-alive-timeout? empty
+--rw fcoe-map [fcoe-map-name]
+--rw fcoe-map-name fcoe-map-name-type
+--rw fcoe-map-fabric-map [fcoe-map-fabric-map-name]
| +--rw fcoe-map-fabric-map-name fcoe-fabric-map-name-type
+--rw fcoe-map-cee-map
+--rw fcoe-map-cee-map-leaf? fcoe-cee-map-name-type

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw fcoe:fabric
| | | +--rw fcoe:neighbor-discovery

| | | +--rw fcoe:disable? empty

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet [name]

| | +--rw fcoe:fabric
| | | +--rw fcoe:fabric-isl
| | | | +--rw fcoe:fabric-isl-enable? empty
| | | +--rw fcoe:fabric-trunk
| | | | +--rw fcoe:fabric-trunk-enable? empty
| | | +--rw fcoe:neighbor-discovery
| | | +--rw fcoe:disable? empty
| | +--rw fcoe:fcoeport
| | | +--rw fcoe:fcoeport-map? fcoe-map-name-type

module: brocade-interface
+--rw interface
| +--rw fortygigabitethernet [name]

48 Network OS YANG Reference Manual

53-1003230-01

brocade-fcoe

| | +--rw fcoe:fabric
| | | +--rw fcoe:fabric-isl
| | | | +--rw fcoe:fabric-isl-enable? empty
| | | +--rw fcoe:fabric-trunk
| | | | +--rw fcoe:fabric-trunk-enable? empty
| | | +--rw fcoe:neighbor-discovery
| | | +--rw fcoe:disable? empty
| | +--rw fcoe:fcoeport
| | | +--rw fcoe:fcoeport-map? fcoe-map-name-type

module: brocade-interface
+--rw interface
| +--rw hundredgigabitethernet [name]
| | +--rw fcoe:fabric
| | | +--rw fcoe:fabric-isl
| | | | +--rw fcoe:fabric-isl-enable? empty
| | | +--rw fcoe:fabric-trunk
| | | | +--rw fcoe:fabric-trunk-enable? empty
| | | +--rw fcoe:neighbor-discovery
| | | +--rw fcoe:disable? empty
| | +--rw fcoe:fcoeport
| | | +--rw fcoe:fcoeport-map? fcoe-map-name-type

module: brocade-interface
+--rw interface
| +--rw fcoe:fcoe [fcoe-interface-name]
| +--rw fcoe:fcoe-interface-name interface-fcoe-type
| +--rw fcoe:fcoe-interface-shutdown? empty
| +--rw fcoe:fcoe-interface-bind
| +--rw (fcoe-interface-bind-type)?
| | +--:(fcoe-interface-bind-te)
| | | +--rw fcoe:fcoe-interface-bind-te? empty
| | +--:(fcoe-interface-bind-fo)
| | | +--rw fcoe:fcoe-interface-bind-fo? empty
| | +--:(fcoe-interface-bind-po)
| | | +--rw fcoe:fcoe-interface-bind-po? empty
| | +--:(fcoe-interface-bind-mac)
| | | +--rw fcoe:fcoe-interface-bind-mac? empty
| | +--:(fcoe-interface-bind-hu)
| | +--rw fcoe:fcoe-interface-bind-hu? empty
| +--rw fcoe:fcoe-interface-bind-name? string

2

module: brocade-interface
+--rw interface
| +--rw port-channel [name]
| | +--rw fcoe:fcoeport
| | | +--rw fcoe:fcoeport-map? fcoe-map-name-type

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw fcoe:fcoe-config
| +--rw fcoe:fcoe-enode-fabric-map [fcoe-enode-fabric-map-name]
| +--rw fcoe:fcoe-enode-fabric-map-name
fcoe-enode-fabric-map-name-type
| +--rw fcoe:fcoe-max-enode?
fcoe-max-enodes-per-rbridge-type

RPCs None

Network OS YANG Reference Manual 49
53-1003230-01

2

brocade-fcoe

Actions None

50 Network OS YANG Reference Manual

53-1003230-01

brocade-fcoe-ext

brocade-fcoe-ext

Description Provides extensions to the brocade-fcoe module, including custom RPCs for returning operational

information about FCoE ports and logins.

2

Top-level

containers

External

augmentations

RPCs Custom RPCs defined in this module follow.

None

None

+---x get-vlan-brief
| +--ro input
| | +--ro (request-type)?
| | +--:(get-request)
| | | +--ro vlan-id? interface:vlan-type
| | +--:(get-next-request)
| | +--ro last-rcvd-vlan-id? interface:vlan-type
| +--ro output
| +--ro vlan [vlan-id]
| | +--ro vlan-id interface:vlan-type
| | +--ro vlan-type? enumeration
| | +--ro vlan-name? string
| | +--ro vlan-state? enumeration
| | +--ro interface [interface-type interface-name]
| | +--ro interface-type enumeration
| | +--ro interface-name union
| | +--ro tag? enumeration
| | +--ro classification [classification-type classification-value]
| | +--ro classification-type enumeration
| | +--ro classification-value string
| +--ro last-vlan-id? interface:vlan-type
| +--ro has-more? boolean
+---x get-interface-switchport
| +--ro output
| +--ro switchport [interface-type interface-name]
| +--ro interface-type enumeration
| +--ro interface-name union
| +--ro mode? interface:switchport-mode-type
| +--ro fcoe-port-enabled? boolean
| +--ro ingress-filter-enabled? boolean
| +--ro acceptable-frame-type? enumeration
| +--ro default-vlan? interface:vlan-type
| +--ro active-vlans
| | +--ro vlanid* interface:vlan-type
| +--ro inactive-vlans
| +--ro vlanid* interface:vlan-type
+---x get-ip-interface
| +--ro input
| | +--ro (request-type)?
| | +--:(get-request)
| | +--ro interface-type? enumeration
| | +--ro interface-name? union
| | +--ro rbridge-id? uint32
| +--ro output
| +--ro interface [interface-type interface-name]

Network OS YANG Reference Manual 51
53-1003230-01

brocade-fcoe-ext

2

| | +--ro interface-type enumeration
| | +--ro interface-name union
| | +--ro if-name? string
| | +--ro ip-address [ipv4]
| | | +--ro ipv4 string
| | | +--ro ipv4-type? enumeration
| | | +--ro broadcast? string
| | | +--ro ip-mtu? interface:mtu-type
| | +--ro if-state? enumeration
| | +--ro line-protocol-state? enumeration
| | +--ro proxy-arp? string
| | +--ro vrf? string
| +--ro has-more? boolean
+---x get-interface-detail
| +--ro input
| | +--ro (request-type)?
| | +--:(get-request)
| | | +--ro interface-type? enumeration
| | | +--ro interface-name? union
| | +--:(get-next-request)
| | +--ro last-rcvd-interface
| | +--ro interface-type? enumeration
| | +--ro interface-name? union
| +--ro output
| +--ro interface [interface-type interface-name]
| | +--ro interface-type enumeration
| | +--ro interface-name union
| | +--ro ifindex? uint64
| | +--ro mtu? interface:mtu-type
| | +--ro ip-mtu? interface:mtu-type
| | +--ro if-name? string
| | +--ro if-state? enumeration
| | +--ro line-protocol-state? enumeration
| | +--ro line-protocol-state-info? string
| | +--ro line-protocol-exception-info? string
| | +--ro hardware-type? enumeration
| | +--ro logical-hardware-address? yang:mac-address
| | +--ro current-hardware-address? yang:mac-address
| | +--ro media-type? enumeration
| | +--ro wavelength? uint32
| | +--ro if-description? string
| | +--ro actual-line-speed? string
| | +--ro configured-line-speed? line-speed
| | +--ro line-duplex-state? enumeration
| | +--ro flow-control? bits
| | +--ro queuing-strategy? enumeration
| | +--ro port-role? enumeration
| | +--ro port-mode? enumeration
| +--ro has-more? boolean
+---x get-media-detail
+--ro input
| +--ro interface-type? enumeration
| +--ro interface-name? union
+--ro output
+--ro interface [interface-type interface-name]
+--ro interface-type enumeration
+--ro interface-name union
+--ro (interface-identifier)?
+--:(sfp)
| +--ro sfp

52 Network OS YANG Reference Manual

53-1003230-01

| +--ro speed? line-speed
| +--ro connector? enumeration
| +--ro encoding? enumeration
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
| +--ro distance? enumeration
| +--ro media-form-factor? enumeration
| +--ro wavelength? string
| +--ro serial-no? string
| +--ro date-code? string
| +--ro temperature? uint32
| +--ro voltage? decimal64
| +--ro current? decimal64
| +--ro tx-power? decimal64
| +--ro rx-power? decimal64
+--:(on-board)
| +--ro on-board
| +--ro speed? line-speed
| +--ro connector? enumeration
| +--ro encoding? enumeration
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
+--:(gbic)
| +--ro gbc
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
+--:(xfp)
| +--ro xfp
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
+--:(unknown)
| +--ro unknown
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
+--:(qsfp)
| +--ro qsfp
| +--ro speed? line-speed
| +--ro connector? enumeration
| +--ro encoding? enumeration
| +--ro vendor-name? string
| +--ro vendor-oui? string
| +--ro vendor-pn? string
| +--ro vendor-rev? string
| +--ro distance? enumeration
| +--ro media-form-factor? enumeration
| +--ro wavelength? string
| +--ro serial-no? string
| +--ro date-code? string
| +--ro temperature? uint32
| +--ro voltage? decimal64

brocade-fcoe-ext

2

Network OS YANG Reference Manual 53
53-1003230-01

brocade-fcoe-ext

2

Actions None

| +--ro current? decimal64
| +--ro tx-power? decimal64
| +--ro rx-power? decimal64
+--:(qsfpp)
+--ro qsfpp
+--ro speed? line-speed
+--ro connector? enumeration
+--ro encoding? enumeration
+--ro vendor-name? string
+--ro vendor-oui? string
+--ro vendor-pn? string
+--ro vendor-rev? string
+--ro distance? enumeration
+--ro media-form-factor? enumeration
+--ro wavelength? string
+--ro serial-no? string
+--ro date-code? string
+--ro temperature? uint32
+--ro voltage? decimal64
+--ro current? decimal64
+--ro tx-power? decimal64
+--ro rx-power? decimal64

54 Network OS YANG Reference Manual

53-1003230-01

brocade-firmware

brocade-firmware

Description Provides a data model for managing the download of firmware and for reporting firmware download

status. It includes the custom actions listed in Table 2.

TABLE 2 Custom actions for firmware version management

Action Purpose

<ftp> Download firmware with FTP.

<scp> Download firmware with SCP.

<usb> Download firmware from a USB device.

<interactive> Download firmware interactively.

<commit> Commits a firmware upgrade after evaluation.

<restore> Restores a firmware version.

<sync> Synchronizes the firmware with its peer.

<fastboot> Reboots the control processor (CP), bypassing

the power-on self-tests (POSTs).

2

Top-level

containers

External

augmentations

RPCs Custom RPCs defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw default-config
| | +--rw logical-chassis
| | | +--rw default-config
| +--rw auto-sync
| +--rw autoupgrade
| +--rw autoupgrade-params
+--rw reboot
+--rw dhcp
+--rw auto-deployment

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show
| +--rw firmware:dhcp-auto-deployment

+---x fwdl-status
| +--ro input
| | +--ro fwdl-tid? int32
| +--ro output
| +--ro number-of-entries? uint32
| +--ro fwdl-state? enumeration
| +--ro fwdl-entries
| +--ro index? uint32
| +--ro message-id? int32
| +--ro date-and-time-info? string
| +--ro message? string
| +--ro blade-slot? int32

Network OS YANG Reference Manual 55
53-1003230-01

brocade-firmware

2

| +--ro blade-swbd? int32
| +--ro blade-name? string
| +--ro blade-state? enumeration
| +--ro blade-app? string
+---x activate-status
| +--ro input
| | +--ro rbridge-id? rbridge-ids-all-type
| +--ro output
| +--ro overall-status? int32
| +--ro overall-error-msg? string
| +--ro activate-entries
| +--ro rbridge-id? common-def:rbridge-id-type
| +--ro status? int32
+---x logical-chassis-fwdl-sanity
| +--ro input
| | +--ro user string
| | +--ro password? string
| | +--ro host string
| | +--ro directory string
| | +--ro file? string
| | +--ro rbridge-id rbridge-ids-all-type
| | +--ro (cluster-options)?
| | | +--:(auto-activate)
| | | | +--ro auto-activate? empty
| | | +--:(coldboot)
| | | +--ro coldboot? empty
| | +--ro protocol enumeration
| +--ro output
| +--ro fwdl-cmd-status? int32
| +--ro fwdl-cmd-msg? string
| +--ro cluster-output
| +--ro rbridge-id? uint32
| +--ro fwdl-status? int32
| +--ro fwdl-msg? string
+---x logical-chassis-fwdl-status
| +--ro input
| | +--ro rbridge-id? rbridge-ids-all-type
| +--ro output
| +--ro overall-status? int32
| +--ro cluster-fwdl-entries
| +--ro rbridge-id? uint32
| +--ro fwdl-state? enumeration
| +--ro fwdl-entries
| +--ro index? uint32
| +--ro message-id? int32
| +--ro date-and-time-info? string
| +--ro message? string
| +--ro blade-slot? int32
| +--ro blade-swbd? int32
| +--ro blade-name? string
| +--ro blade-state? enumeration
| +--ro blade-app? string
+---x dad-status
+--ro output
+--ro dad-last-state? enumeration
+--ro dad-status-entries
+--ro index? uint32
+--ro date-and-time-info? string
+--ro message? string

56 Network OS YANG Reference Manual

53-1003230-01

Actions Proprietary actions defined in this module follow.

Download firmware from an FTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro ftp
| | | +--ro input
| | | | +--ro user string
| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro (options)?
| | | | +--:(manual)
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro nocommit? empty
| | | | +--:(noactivate)
| | | | | +--ro noactivate? empty
| | | | +--:(coldboot)
| | | | +--ro coldboot? empty
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

brocade-firmware

2

Download firmware from an SFTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro sftp
| | | +--ro input
| | | | +--ro user string
| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro (options)?
| | | | +--:(manual)
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro nocommit? empty
| | | | +--:(noactivate)
| | | | | +--ro noactivate? empty
| | | | +--:(coldboot)
| | | | +--ro coldboot? empty
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Download firmware from an SCP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro scp
| | | +--ro input
| | | | +--ro user string

Network OS YANG Reference Manual 57
53-1003230-01

brocade-firmware

2

| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro (options)?
| | | | +--:(manual)
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro nocommit? empty
| | | | +--:(noactivate)
| | | | | +--ro noactivate? empty
| | | | +--:(coldboot)
| | | | +--ro coldboot? empty
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Download firmware from a USB device:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro usb
| | | +--ro input
| | | | +--ro directory string
| | | | +--ro (options)?
| | | | +--:(manual)
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro nocommit? empty
| | | | +--:(noactivate)
| | | | | +--ro noactivate? empty
| | | | +--:(coldboot)
| | | | +--ro coldboot? empty
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Download firmware interactively:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro interactive
| | | +--ro input
| | | +--ro output
| | | +--ro result? string

Default Configuration on the FTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw default-config
| | | +--ro ftp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string

58 Network OS YANG Reference Manual

53-1003230-01

brocade-firmware

| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro rbridgeid? common-def:rbridge-id-type
| | | | | +--ro vcs-id? uint32
| | | | | +--ro vcs-mode? uint32
| | | | +--ro output
| | | | +--ro fwdl-tid? int32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Default Configuration on the SCP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw default-config
| | | +--ro scp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro rbridgeid? common-def:rbridge-id-type
| | | | | +--ro vcs-id? uint32
| | | | | +--ro vcs-mode? uint32
| | | | +--ro output
| | | | +--ro fwdl-tid? int32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

2

Default Configuration on the SFTP server

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw default-config
| | | +--ro sftp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro manual? empty
| | | | | +--ro noreboot? empty
| | | | | +--ro rbridgeid? common-def:rbridge-id-type
| | | | | +--ro vcs-id? uint32
| | | | | +--ro vcs-mode? uint32
| | | | +--ro output
| | | | +--ro fwdl-tid? int32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Network OS YANG Reference Manual 59
53-1003230-01

brocade-firmware

2

Default Configuration on a USB device:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw default-config
| | | +--ro usb
| | | +--ro input
| | | | +--ro directory string
| | | | +--ro manual? empty
| | | | +--ro noreboot? empty
| | | | +--ro rbridgeid? common-def:rbridge-id-type
| | | | +--ro vcs-id? uint32
| | | | +--ro vcs-mode? uint32
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Logical Chassis Configuration on a FTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--ro ftp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro rbridge-id rbridge-ids-all-type
| | | | | +--ro (cluster-options)?
| | | | | +--:(auto-activate)
| | | | | | +--ro auto-activate? empty
| | | | | +--:(coldboot)
| | | | | +--ro coldboot? empty
| | | | +--ro output
| | | | +--ro fwdl-cmd-status? int32
| | | | +--ro fwdl-cmd-msg? string
| | | | +--ro cluster-output
| | | | +--ro rbridge-id? uint32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Logical Chassis Configuration on a SCP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--ro scp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro rbridge-id rbridge-ids-all-type

60 Network OS YANG Reference Manual

53-1003230-01

brocade-firmware

| | | | | +--ro (cluster-options)?
| | | | | +--:(auto-activate)
| | | | | | +--ro auto-activate? empty
| | | | | +--:(coldboot)
| | | | | +--ro coldboot? empty
| | | | +--ro output
| | | | +--ro fwdl-cmd-status? int32
| | | | +--ro fwdl-cmd-msg? string
| | | | +--ro cluster-output
| | | | +--ro rbridge-id? uint32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Logical Chassis Configuration on a SFTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--ro sftp
| | | +--ro input
| | | | +--ro user string
| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro rbridge-id rbridge-ids-all-type
| | | | +--ro (cluster-options)?
| | | | +--:(auto-activate)
| | | | | +--ro auto-activate? empty
| | | | +--:(coldboot)
| | | | +--ro coldboot? empty
| | | +--ro output
| | | +--ro fwdl-cmd-status? int32
| | | +--ro fwdl-cmd-msg? string
| | | +--ro cluster-output
| | | +--ro rbridge-id? uint32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

2

Logical Chassis default configuration on a FTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--rw default-config
| | | +--ro ftp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro rbridge-id rbridge-ids-all-type
| | | | +--ro output
| | | | +--ro fwdl-cmd-status? int32
| | | | +--ro fwdl-cmd-msg? string
| | | | +--ro cluster-output

Network OS YANG Reference Manual 61
53-1003230-01

brocade-firmware

2

| | | | +--ro rbridge-id? uint32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Logical Chassis default configuration on a SCP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--rw default-config
| | | +--ro scp
| | | | +--ro input
| | | | | +--ro user string
| | | | | +--ro password? string
| | | | | +--ro host string
| | | | | +--ro directory string
| | | | | +--ro file? string
| | | | | +--ro rbridge-id rbridge-ids-all-type
| | | | +--ro output
| | | | +--ro fwdl-cmd-status? int32
| | | | +--ro fwdl-cmd-msg? string
| | | | +--ro cluster-output
| | | | +--ro rbridge-id? uint32
| | | | +--ro fwdl-status? int32
| | | | +--ro fwdl-msg? string

Logical Chassis default configuration on a SFTP server:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--rw logical-chassis
| | | +--rw default-config
| | | +--ro sftp
| | | +--ro input
| | | | +--ro user string
| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro rbridge-id rbridge-ids-all-type
| | | +--ro output
| | | +--ro fwdl-cmd-status? int32
| | | +--ro fwdl-cmd-msg? string
| | | +--ro cluster-output
| | | +--ro rbridge-id? uint32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Commit a firmware version:

module: brocade-firmware
+--rw firmware
| +--rw download
| +--ro commit
| | +--ro input
| | +--ro output
| | +--ro result? string

62 Network OS YANG Reference Manual

53-1003230-01

Firmware download sanity check:

module: brocade-firmware
+--rw firmware
| +--rw download
| | +--ro sanity-check
| | +--ro input
| | | +--ro user string
| | | +--ro password? string
| | | +--ro host string
| | | +--ro directory string
| | | +--ro file? string
| | | +--ro protocol string
| | | +--ro rbridge-id rbridge-ids-all-type
| | +--ro output
| | +--ro fwdl-tid? int32
| | +--ro fwdl-status? int32
| | +--ro fwdl-msg? string

Restore a firmware version:

module: brocade-firmware
+--rw firmware
| +--rw download
| +--ro restore
| | +--ro input
| | +--ro output
| | +--ro result? string

brocade-firmware

2

Synchronize firmware to peer processor:

module: brocade-firmware
+--rw firmware
| +--rw download
| +--ro sync
| | +--ro input
| | +--ro output
| | +--ro result? string

Activate the firmware:

module: brocade-firmware
+--rw firmware
| +--rw download
| +--ro activate
| | +--ro input
| | | +--ro rbridge-id? rbridge-ids-all-type
| | +--ro output
| | +--ro overall-status? int32
| | +--ro overall-error-msg? string
| | +--ro activate-output [rbridge-id]
| | +--ro rbridge-id common-def:rbridge-id-type
| | +--ro status? int32

Recover a firmware:

module: brocade-firmware
+--rw firmware
| +--rw download
| +--ro recover
| | +--ro input
| | | +--ro rbridge-id? rbridge-ids-all-type
| | +--ro output

Network OS YANG Reference Manual 63
53-1003230-01

brocade-firmware

2

| | +--ro result? string

Auto-synchronize the firmware:

module: brocade-firmware
+--rw firmware
| +--rw auto-sync
| | +--ro enable
| | | +--ro input
| | | +--ro output
| | | +--ro result? string
| | +--ro disable
| | +--ro input
| | +--ro output
| | +--ro result? string

Firmware clean-install using FTP:

module: brocade-firmware
+--rw firmware
| +--rw install
| | +--ro ftp
| | | +--ro input
| | | | +--ro user string
| | | | +--ro password? string
| | | | +--ro host string
| | | | +--ro directory string
| | | | +--ro file? string
| | | | +--ro manual? empty
| | | | +--ro rbridgeid? common-def:rbridge-id-type
| | | | +--ro vcs-id? uint32
| | | | +--ro vcs-mode? uint32
| | | | +--ro keep-baseconfig? empty
| | | +--ro output
| | | +--ro fwdl-tid? int32
| | | +--ro fwdl-status? int32
| | | +--ro fwdl-msg? string

Firmware clean-install using SCP:

module: brocade-firmware
+--rw firmware
| +--rw install
| | +--ro scp
| | +--ro input
| | | +--ro user string
| | | +--ro password? string
| | | +--ro host string
| | | +--ro directory string
| | | +--ro file? string
| | | +--ro manual? empty
| | | +--ro rbridgeid? common-def:rbridge-id-type
| | | +--ro vcs-id? uint32
| | | +--ro vcs-mode? uint32
| | | +--ro keep-baseconfig? empty
| | +--ro output
| | +--ro fwdl-tid? int32
| | +--ro fwdl-status? int32
| | +--ro fwdl-msg? string

64 Network OS YANG Reference Manual

53-1003230-01

Auto-upgrade the firmware:

module: brocade-firmware
+--rw firmware
| +--rw autoupgrade
| | +--rw enable? empty
| +--rw autoupgrade-params
| +--rw path? string
| +--rw protocol? enumeration
| +--rw ipaddress? string
| +--rw username? string
| +--rw pass? string

Reload the system without running POSTs:

module: brocade-firmware
+--rw reboot
| +--ro fastboot
| +--ro input

Enable the deployment of firmware download:

module: brocade-firmware
+--rw dhcp
+--rw auto-deployment
+--ro enable
+--ro input
+--ro output
+--ro dad-cmd-msg? string

brocade-firmware

2

Retrieve the current status of firmware download:

module: brocade-common-def
+--rw show
| +--rw firmware:dhcp-auto-deployment
| | +--ro firmware:dadstatus
| | +--ro firmware:input
| | +--ro firmware:output
| | +--ro firmware:result? string

Network OS YANG Reference Manual 65
53-1003230-01

brocade-firmware-ext

2

brocade-firmware-ext

Description Provides a data model with extensions to the brocade-firmware model for reporting firmware

information.

Top-level

containers

External

augmentations

RPCs Custom RPCs defined in this module follow.

None

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show

| +--rw firmware-extensions:firmware

Return firmware version information:

+---x show-firmware-version
+--ro input
| +--ro switchid? ras-extensions:switchid-type
+--ro output
+--ro show-firmware-version
+--ro switchid? ras-extensions:switchid-type
+--ro os-name? string
+--ro os-version? string
+--ro copy-right-info? string
+--ro build-time? string
+--ro firmware-full-version? string
+--ro control-processor-vendor? string
+--ro control-processor-chipset? string
+--ro control-processor-memory? string
+--ro node-info
+--ro slot-no? uint32
+--ro node-instance-no? uint32
+--ro node-type? node-type-enum
+--ro is-active-cp? boolean
+--ro firmware-version-info
+--ro application-name? string
+--ro primary-version? string
+--ro secondary-version? string

Actions Proprietary actions defined in this module follow.

Return the firmware download status:

module: brocade-common-def
+--rw show
| +--rw firmware-extensions:firmware
| | +--ro firmware-extensions:firmwaredownloadstatus
| | | +--ro firmware-extensions:input
| | | | +--ro firmware-extensions:rbridge-id?
ras-extensions:switchid-type
| | | | +--ro firmware-extensions:brief? empty
| | | | +--ro firmware-extensions:summary? empty
| | | | +--ro firmware-extensions:logical-chassis? empty
| | | +--ro firmware-extensions:output
| | | +--ro firmware-extensions:result? string

66 Network OS YANG Reference Manual

53-1003230-01

brocade-firmware-ext

Return the firmware download history:

module: brocade-common-def
+--rw show
| +--rw firmware-extensions:firmware
| | +--ro firmware-extensions:firmwaredownloadhistory
| | | +--ro firmware-extensions:input
| | | | +--ro firmware-extensions:rbridge-id? string
| | | +--ro firmware-extensions:output
| | | +--ro firmware-extensions:result? string

Check firmware:

module: brocade-common-def
+--rw show
| +--rw firmware-extensions:firmware
| | +--ro firmware-extensions:firmware
| | | +--ro firmware-extensions:input
| | | | +--ro firmware-extensions:auto-sync? enumeration
| | | +--ro firmware-extensions:output
| | | +--ro firmware-extensions:result? string

Return the firmware version string:

module: brocade-common-def
+--rw show
| +--rw firmware-extensions:firmware
| | +--ro firmware-extensions:version
| | | +--ro firmware-extensions:input
| | | | +--ro firmware-extensions:rbridge-id?
ras-extensions:switchid-type
| | | | +--ro firmware-extensions:brief? empty
| | | | +--ro firmware-extensions:all-partitions? empty
| | | +--ro firmware-extensions:output
| | | +--ro firmware-extensions:result? string

2

Return firmware features:

module: brocade-common-def
+--rw show
| +--rw firmware-extensions:firmware
| | +--ro firmware-extensions:firmware-features
| | +--ro firmware-extensions:input
| | +--ro firmware-extensions:output
| | +--ro firmware-extensions:result? string

Network OS YANG Reference Manual 67
53-1003230-01

brocade-hardware

2

brocade-hardware

Description Provides a data model for managing connectors. It can be used to breakout the connectors and set

the type of the connectors.

Top-level

containers

External

augmentations

RPCs None

Actions None

Top-level nodes and their subtree hierarchies follow.

module: brocade-hardware
+--rw hardware
+--rw connector [name]
| +--rw name interface:interface-type
| +--rw sfp
| +--rw breakout? empty
+--rw port-group [name]
+--rw name interface:port-group-type
+--rw mode
+--rw performance? empty

None

68 Network OS YANG Reference Manual

53-1003230-01

brocade-ha

Description Provides a data model for:

• Enabling and disabling high availability

• Displaying high availability status information,

• Rebooting the chassis

• Performing failover

• Displaying the high availability state

brocade-ha

2

Top-level

containers

External

augmentations

RPCs None

Actions Proprietary actions defined in this module follow.

Top-level nodes and their subtree hierarchies follow.

module: brocade-ha
+--rw ha
| +--rw sync
+--rw system

Nodes that augment other modules and their subtrees follow.

module: brocade-common-def
+--rw show
| +--rw ha:ha

module: brocade-common-def
+--rw show

| +--rw ha:redundancy

Enable HA:

module: brocade-ha
+--rw ha
| +--ro enable
| | +--ro input

Diable HA:

module: brocade-ha
+--rw ha
| +--ro disable
| | +--ro input

Dump HA:

module: brocade-ha
+--rw ha
| +--ro dump
| | +--ro input

Reboot HA:

module: brocade-ha
+--rw ha
| +--ro chassisreboot

Network OS YANG Reference Manual 69
53-1003230-01

2

brocade-ha

| | +--ro input

Check HA failover

module: brocade-ha
+--rw ha
| +--ro failover
| | +--ro input

Start HA synchronization:

module: brocade-ha
+--rw ha
| +--rw sync
| +--ro start
| | +--ro input
| | +--ro output
| | +--ro result? string

Stop HA synchranization:

module: brocade-ha
+--rw ha
| +--rw sync
| +--ro stop
| +--ro input
| +--ro output
| +--ro result? string

Reboot the system:

module: brocade-ha

+--rw system
+--ro reload
+--ro input
| +--ro rbridge-id? ras-extensions:switchid-type
| +--ro system? empty
| +--ro standby? empty
+--ro output

module: brocade-common-def
+--rw show
| +--rw ha:ha
| | +--ro ha:ha
| | +--ro ha:input
| | +--ro ha:rbridge-id? ras-extensions:switchid-type
| | +--ro ha:all-partitions? empty

Display the current HA redundancy state:

module: brocade-common-def
+--rw show

| +--rw ha:redundancy
| | +--ro ha:redundancy
| | +--ro ha:input
| | +--ro ha:rbridge-id? ras-extensions:switchid-type

70 Network OS YANG Reference Manual

53-1003230-01

brocade-http-config

Description Provides a data model for configuring HTTP server.

brocade-http-config

2

Top-level

containers

External

augmentations

RPCs None

Actions None

module: brocade-http-config
+--rw http-sa
+--rw http
+--rw server
+--rw shutdown? empty

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]
+--rw http-config:http
| +--rw http-config:server
| +--rw http-config:shutdown? empty

Network OS YANG Reference Manual 71
53-1003230-01

brocade-icmp

2

brocade-icmp

Description Provides a data model for configuring ICMP parameters like echo reply, rate-limiting and

unreachable destination which are used in controlling ICMP frames.

Top-level

containers

External

augmentations

None

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]

+--rw brocade-interface:interface
| | +--rw ip-config:ip
| | | +--rw icmp:interface-ve-icmp-conf
| | | | +--rw icmp:icmp
| | | | +--rw icmp:echo-reply? empty
| | | | +--rw icmp:rate-limiting? uint64
| | | | +--rw icmp:unreachable? empty

module: brocade-interface
+--rw interface
| +--rw fortygigabitethernet [name]
| | +--rw ip
| | | +--rw icmp:interface-phy-icmp-conf
| | | | +--rw icmp:icmp
| | | | +--rw icmp:echo-reply? empty
| | | | +--rw icmp:rate-limiting? uint64
| | | | +--rw icmp:unreachable? empty

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet [name]
| | +--rw ip
| | | +--rw icmp:interface-phy-icmp-conf
| | | | +--rw icmp:icmp
| | | | +--rw icmp:echo-reply? empty
| | | | +--rw icmp:rate-limiting? uint64
| | | | +--rw icmp:unreachable? empty

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw ip
| | | +--rw icmp:interface-phy-icmp-conf
| | | | +--rw icmp:icmp
| | | | +--rw icmp:echo-reply? empty
| | | | +--rw icmp:rate-limiting? uint64
| | | | +--rw icmp:unreachable? empty

RPCs None

Actions None

72 Network OS YANG Reference Manual

53-1003230-01

brocade-igmp

brocade-igmp

Description Provides a data model for configuring the Internet Group Management Protocol (IGMP). IGMP

alleviates excessive traffic caused by Layer 2 forwarding of received multicast packets.

2

Top-level

containers

External

augmentations

None

Nodes that augment other modules and their subtrees follow.

module: brocade-rbridge
+--rw rbridge-id [rbridge-id]

+--rw brocade-interface:interface
| | +--rw ip-config:ip
| | | +--rw igmp:igmp
| | | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | | +--rw igmp:immediate-leave? empty
| | | | +--rw igmp:static-group [sg-addr]
| | | | +--rw igmp:sg-addr inet:ipv4-address

module: brocade-interface
+--rw interface-vlan
| +--rw interface
| +--rw ve [name]
| | +--rw igmp:igmp
| | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | +--rw igmp:immediate-leave? empty
| | | +--rw igmp:static-group [sg-addr]
| | | +--rw igmp:sg-addr inet:ipv4-address

module: brocade-interface
+--rw interface
| +--rw hundredgigabitethernet[name]
| | +--rw ip

| | | +--rw igmp:igmp-phy-intf-cfg
| | | | +--rw igmp:igmp
| | | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | | +--rw igmp:immediate-leave? empty
| | | | +--rw igmp:static-group [sg-addr]
| | | | +--rw igmp:sg-addr inet:ipv4-address

module: brocade-interface
+--rw interface
| +--rw fortygigabitethernet [name]
| | +--rw ip

| | | +--rw igmp:igmp-phy-intf-cfg
| | | | +--rw igmp:igmp
| | | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | | +--rw igmp:immediate-leave? empty
| | | | +--rw igmp:static-group [sg-addr]

Network OS YANG Reference Manual 73
53-1003230-01

2

brocade-igmp

| | | | +--rw igmp:sg-addr inet:ipv4-address

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet [name]
| | +--rw ip

| | | +--rw igmp:igmp-phy-intf-cfg
| | | | +--rw igmp:igmp
| | | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | | +--rw igmp:immediate-leave? empty
| | | | +--rw igmp:static-group [sg-addr]
| | | | +--rw igmp:sg-addr inet:ipv4-address

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw ip

| | | +--rw igmp:igmp-phy-intf-cfg
| | | | +--rw igmp:igmp
| | | | +--rw igmp:last-member-query-interval? igmp-snooping:lmqt-type
| | | | +--rw igmp:query-interval? igmp-snooping:qi-type
| | | | +--rw igmp:query-max-response-time? igmp-snooping:qmrt-type
| | | | +--rw igmp:immediate-leave? empty
| | | | +--rw igmp:static-group [sg-addr]
| | | | +--rw igmp:sg-addr inet:ipv4-address

RPCs None

Actions None

74 Network OS YANG Reference Manual

53-1003230-01

brocade-igmp-snooping

brocade-igmp-snooping

Description Provides a data model for configuring the Internet Group Management Protocol (IGMP) snooping.

IGMP snooping alleviates excessive traffic caused by Layer 2 forwarding of received multicast
packets.

2

Top-level

containers

External

augmentations

Top-level nodes and their subtree hierarchies follow.

module: brocade-igmp-snooping
+--rw igmp-snooping
+--rw ip
+--rw igmp
+--rw snooping

+--rw enable? empty

Nodes that augment other modules and their subtrees follow.

module: brocade-interface
+--rw interface-vlan
| +--rw interface
| +--rw vlan [name]

+--rw ip
| | | +--rw igmp-snooping:igmp
| | | +--rw igmp-snooping:last-member-query-interval? lmqt-type
| | | +--rw igmp-snooping:query-interval? qi-type
| | | +--rw igmp-snooping:query-max-response-time? qmrt-type
| | | +--rw igmp-snooping:snooping
| | | | +--rw igmp-snooping:enable? empty
| | | | +--rw igmp-snooping:fast-leave? empty
| | | | +--rw igmp-snooping:mrouter-timeout? mrti-type
| | | | +--rw igmp-snooping:querier
| | | | | +--rw igmp-snooping:qenable? empty
| | | | +--rw igmp-snooping:mrouter
| | | | +--rw igmp-snooping:interface [if-type value]
| | | | +--rw igmp-snooping:if-type enumeration
| | | | +--rw igmp-snooping:value string-type
| | | +--rw igmp-snooping:static-group [mcast-address interface if-type
value]
| | | +--rw igmp-snooping:mcast-address inet:ipv4-address
| | | +--rw igmp-snooping:interface enumeration
| | | +--rw igmp-snooping:if-type enumeration
| | | +--rw igmp-snooping:value string-type

RPCs None

Actions None

Network OS YANG Reference Manual 75
53-1003230-01

brocade-interface

2

brocade-interface

Description Provides the data model for managing Ethernet network interfaces and their sublayers.

Tab le 3 lists the Ethernet interfaces and other entities modeled by high-level nodes in this

management module.

TABLE 3 Entities managed through brocade-interface module

High-level node name Description

interface/fc-port Models Fibre Channel interfaces

interface/fortygigabitethernet Models 40 GbE physical Ethernet interfaces

interface/gigabitethernet Models 1 GbE physical Ethernet interfaces

interface/management Models the management port or management interfaces

interface/port-channel Models port-channel or LAG interfaces

interface/tengigabitethernet Models 10 GbE physical Ethernet interfaces

interface/hundredgigabitethernet Models 100 GbE physical Ethernet interfaces

interface-vlan Models Layer 2 VLAN interfaces

protocol Models protocol configuration and status

reserved-vlan Models the reserved VLAN configuration

Top-level

containers

This module provides the mechanism to support the following actions:

• Discover and characterize the interface sublayers.

• Configure various attributes of these interfaces.

• Structure the interfaces such that various Layer 2 or Layer 3 access and security policies,

network discovery policies, QoS policies, and link aggregation policies can be applied using
other modules supported by the managed entity.

Top-level nodes and their subtree hierarchies follow.

High level nodes:

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| +--rw tengigabitethernet [name]
| +--rw fortygigabitethernet [name]
| +--rw hundredgigabitethernet [name]
| +--rw port-channel [name]
| +--rw management [name]
| +--rw fc-port [name]
+--rw interface-vlan
| +--rw interface
+--rw protocol
+--rw reserved-vlan

interface/fc-port:

module: brocade-interface
+--rw interface
| +--rw fc-port [name]
| +--rw name interface-type
| +--rw fc-speed-cfg? fc-speed-cfg-type

76 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| +--rw fill-word? fc-fillword-cfg-type
| +--rw long-distance? fc-long-distance-cfg-type
| +--rw vc-link-init? fc-vc-link-init-cfg-type
| +--rw desire-distance? desire-distance-type
| +--rw isl-r_rdy-mode? empty
| +--rw trunk-enable? empty
| +--rw shutdown? empty
| +--rw config-mode? interface-fc-config-mode-type

interface/gigabitethernet:

module: brocade-interface
+--rw interface
| +--rw gigabitethernet [name]
| | +--rw name interface-type
| | +--ro ifindex? uint64
| | +--rw description? string
| | +--rw shutdown? empty
| | +--rw channel-group
| | | +--rw port-int? portchannel-type
| | | +--rw mode? po-mode
| | | +--rw type? po-type
| | +--rw mtu? mtu-type
| | +--rw switchport-basic
| | | +--rw basic? empty
| | +--rw switchport
| | | +--rw port-security?
| | | | +--rw port-sec-max? uint32
| | | | +--rw port-sec-violation? port-sec-violation
| | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw sticky?
| | | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw allowed-ouis [oui]
| | | | | +--rw oui oui-type
| | | | +--rw shutdown-time? uint32
| | | +--rw mode
| | | | +--rw vlan-mode? l2-mode-type
| | | | +--rw private-vlan
| | | | +--rw private-vlan-trunk
| | | | | +--rw trunk-basic? empty
| | | | | +--rw trunk-promiscuous? empty
| | | | | +--rw trunk-host? empty
| | | | +--rw promiscuous? empty
| | | | +--rw host? empty
| | | +--rw access
| | | | +--rw accessvlan? vlan-type
| | | | +--rw rspan-access
| | | | +--rw rspan-access-vlan? vlan-type
| | | +--rw access-mac-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw trunk-private-vlan-classification
| | | | +--rw private-vlan
| | | | +--rw trunk

2

Network OS YANG Reference Manual 77
53-1003230-01

brocade-interface

2

| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | +--rw access-mac-group-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-group]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-group mac-group-id-type
| | | +--rw trunk
| | | | +--rw allowed
| | | | | +--rw vlan
| | | | | | +--rw all? empty
| | | | | | +--rw none? empty
| | | | | | +--rw add? ui32-1k-vlan-range
| | | | | | +--rw except? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | x--rw vlanoper
| | | | | | +--rw vlan
| | | | | | +--rw add? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | +--rw rspan-vlan
| | | | | | +--rw add-rspan-trunk-vlan? ui32-vlan-range
| | | | | | +--rw remove-rspan-trunk-vlan? ui32-vlan-range
| | | | | +--rw trunk-rspan-vlan-classification
| | | | | +--rw rspan-vlan
| | | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw trunk-vlan-classification
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw add [trunk-vlan-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | | +--rw remove [trunk-vlan-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | +--rw default-vlan-config
| | | | | +--rw default-transparent-vlan? non-dot1q-vlan-type
| | | | +--rw tag?
| | | | | +--rw native-vlan? empty
| | | | +--rw native-vlan-classification
| | | | | +--rw native-vlan-id? native-vlan-type
| | | | | +--rw native-vlan-ctag-id? dot1q-vlan-type
| | | | +--rw native-vlan-xtagged-config
| | | | | +--rw native-vlan-id-xtagged? vlan-type
| | | | | +--rw native-vlan-ctag-id-xtagged? dot1q-vlan-type
| | | | | +--rw native-vlan-egress-type-xtagged? enumeration
| | | | +--rw native-vlan-untagged-config
| | | | +--rw native-vlan-id-untagged? vlan-type
| | | +--rw private-vlan
| | | | +--rw trunk

78 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| | | | | +--rw native
| | | | | | +--rw pvlanNativevlan? vlan-type
| | | | | | +--rw pvlan-native-vlan-ctag-id? dot1q-vlan-type
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw pvlan_all? empty
| | | | | +--rw pvlan_none? empty
| | | | | +--rw pvlan_add? ui32-vlan-range
| | | | | +--rw pvlan_except? ui32-vlan-range
| | | | | +--rw pvlan_remove? ui32-vlan-range
| | | | +--rw host-association
| | | | | +--rw host-pri-pvlan? vlan-type
| | | | | +--rw host-sec-pvlan? vlan-type
| | | | +--rw association
| | | | | +--rw trunk [trunk-pri-pvlan trunk-sec-pvlan]
| | | | | +--rw trunk-pri-pvlan vlan-type
| | | | | +--rw trunk-sec-pvlan vlan-type
| | | | +--rw mapping [promis-pri-pvlan]
| | | | +--rw promis-pri-pvlan vlan-type
| | | | +--rw oper? secVlan-opp-type
| | | | +--rw promis-sec-pvlan-range? ui32-range-8091
| | | +--rw access-mac-rspan-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw access-mac-group-rspan-vlan-classification
| | | +--rw access
| | | +--rw vlan [access-vlan-id access-mac-group]
| | | +--rw access-vlan-id vlan-type
| | | +--rw access-mac-group mac-group-id-type
| | +--rw ip
| | +--rw vrf
| | | +--rw forwarding? common-def:vrf-name
| | +--rw ipv6
| | | +--rw ra-guard? empty
| | +--rw edge-loop-detection
| | +--rw eldprio? uint32
| | +--rw eldvlan? ui32-eldvlan-range

2

interface/management:

module: brocade-interface
+--rw interface
| +--rw management [name]
| | +--rw name man-interface-type
| | +--rw tcp
| | | +--rw tcp_burstrate? uint32
| | | +--rw tcp_lockdown? uint32
| | +--rw ip
| | | +--rw icmp
| | | | +--rw unreachable? empty
| | | | +--rw echo_reply? empty
| | | | +--rw rate_limiting? uint32
| | | +--rw address
| | | | +--rw dhcp? empty
| | | | +--rw ip-address? common-def:ipv4-address-prefix-type
| | | +--rw gateway
| | | | +--rw gateway-address? inet:ipv4-address

Network OS YANG Reference Manual 79
53-1003230-01

brocade-interface

2

| | | +--rw oper-address
| | | | +--ro oper-ip-address? common-def:ipv4-address-prefix-type
| | | +--rw oper-gateway-con
| | | +--ro oper-gateway? inet:ipv4-address
| | +--rw ipv6
| | | +--rw icmpv6
| | | | +--rw v6_unreachable? empty
| | | | +--rw v6_echo_reply? empty
| | | | +--rw v6_rate_limiting? uint32
| | | +--rw ipv6-address-cont
| | | | +--rw ipv6-global-address? common-def:ipv6-address-prefix
| | | | +--rw autoconfig? empty
| | | | +--rw dhcpv6? empty
| | | +--ro ipv6-address* string
| | | +--ro ipv6-gateways* string
| | +--rw speed? enumeration
| | +--rw line-speed
| | +--ro actual? string
| | +--ro configured? string

interface/port-channel:

module: brocade-interface
+--rw interface

| +--rw port-channel [name]
| | +--rw name portchannel-type
| | +--rw cee? common-def:name-string32
| | +--rw vlag
| | | +--rw ignore-split? empty
| | +--rw po-speed? enumeration
| | +--ro ifindex? uint64
| | +--rw description? string
| | +--rw shutdown? empty
| | +--rw minimum-links? uint32
| | +--rw mtu? mtu-type
| | +--rw switchport-basic
| | | +--rw basic? empty
| | +--rw switchport
| | | +--rw port-security?
| | | | +--rw port-sec-max? uint32
| | | | +--rw port-sec-violation? port-sec-violation
| | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw sticky?
| | | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw allowed-ouis [oui]
| | | | | +--rw oui oui-type
| | | | +--rw shutdown-time? uint32
| | | +--rw mode
| | | | +--rw vlan-mode? l2-mode-type
| | | | +--rw private-vlan
| | | | +--rw private-vlan-trunk
| | | | | +--rw trunk-basic? empty
| | | | | +--rw trunk-promiscuous? empty
| | | | | +--rw trunk-host? empty
| | | | +--rw promiscuous? empty
| | | | +--rw host? empty

80 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| | | +--rw access
| | | | +--rw accessvlan? vlan-type
| | | +--rw access-mac-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw trunk-private-vlan-classification
| | | | +--rw private-vlan
| | | | +--rw trunk
| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | +--rw access-mac-group-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-group]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-group mac-group-id-type
| | | +--rw trunk
| | | | +--rw allowed
| | | | | +--rw vlan
| | | | | | +--rw all? empty
| | | | | | +--rw none? empty
| | | | | | +--rw add? ui32-1k-vlan-range
| | | | | | +--rw except? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | x--rw vlanoper
| | | | | +--rw vlan
| | | | | +--rw add? ui32-vlan-range
| | | | | +--rw remove? ui32-vlan-range
| | | | +--rw trunk-vlan-classification
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw add [trunk-vlan-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | | +--rw remove [trunk-vlan-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | +--rw default-vlan-config
| | | | | +--rw default-transparent-vlan? non-dot1q-vlan-type
| | | | +--rw tag?
| | | | | +--rw native-vlan? empty
| | | | +--rw native-vlan-classification
| | | | | +--rw native-vlan-id? native-vlan-type
| | | | | +--rw native-vlan-ctag-id? dot1q-vlan-type
| | | | +--rw native-vlan-xtagged-config
| | | | | +--rw native-vlan-id-xtagged? vlan-type
| | | | | +--rw native-vlan-ctag-id-xtagged? dot1q-vlan-type
| | | | | +--rw native-vlan-egress-type-xtagged? enumeration
| | | | +--rw native-vlan-untagged-config
| | | | +--rw native-vlan-id-untagged? vlan-type
| | | +--rw private-vlan
| | | +--rw trunk
| | | | +--rw native

2

Network OS YANG Reference Manual 81
53-1003230-01

brocade-interface

2

| | | | | +--rw pvlanNativevlan? vlan-type
| | | | | +--rw pvlan-native-vlan-ctag-id? dot1q-vlan-type
| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw pvlan_all? empty
| | | | +--rw pvlan_none? empty
| | | | +--rw pvlan_add? ui32-vlan-range
| | | | +--rw pvlan_except? ui32-vlan-range
| | | | +--rw pvlan_remove? ui32-vlan-range
| | | +--rw host-association
| | | | +--rw host-pri-pvlan? vlan-type
| | | | +--rw host-sec-pvlan? vlan-type
| | | +--rw association
| | | | +--rw trunk [trunk-pri-pvlan trunk-sec-pvlan]
| | | | +--rw trunk-pri-pvlan vlan-type
| | | | +--rw trunk-sec-pvlan vlan-type
| | | +--rw mapping [promis-pri-pvlan]
| | | +--rw promis-pri-pvlan vlan-type
| | | +--rw oper? secVlan-opp-type
| | | +--rw promis-sec-pvlan-range? ui32-range-8091
| | +--rw ip
| | +--rw ipv6
| | | +--rw ra-guard? empty
| | +--rw edge-loop-detection
| | | +--rw eldprio? uint32
| | | +--rw eldvlan? ui32-eldvlan-range
| | +--rw load-balance? enumeration

interface/tengigabitethernet:

module: brocade-interface
+--rw interface
| +--rw tengigabitethernet [name]
| | +--rw name interface-type
| | +--rw long-distance-isl? enumeration
| | +--rw cee? common-def:name-string32
| | +--rw speed? enumeration
| | +--rw track
| | | +--rw track_enable? empty
| | | +--rw interface [track-interface-type track-interface-name]
| | | +--rw track-interface-type enumeration
| | | +--rw track-interface-name string
| | +--ro ifindex? uint64
| | +--rw description? string
| | +--rw shutdown? empty
| | +--rw channel-group
| | | +--rw port-int? portchannel-type
| | | +--rw mode? po-mode
| | | +--rw type? po-type
| | +--rw mtu? mtu-type
| | +--rw switchport-basic
| | | +--rw basic? empty
| | +--rw switchport
| | | +--rw port-security?
| | | | +--rw port-sec-max? uint32
| | | | +--rw port-sec-violation? port-sec-violation
| | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw sticky?

82 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| | | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw allowed-ouis [oui]
| | | | | +--rw oui oui-type
| | | | +--rw shutdown-time? uint32
| | | +--rw mode
| | | | +--rw vlan-mode? l2-mode-type
| | | | +--rw private-vlan
| | | | +--rw private-vlan-trunk
| | | | | +--rw trunk-basic? empty
| | | | | +--rw trunk-promiscuous? empty
| | | | | +--rw trunk-host? empty
| | | | +--rw promiscuous? empty
| | | | +--rw host? empty
| | | +--rw access
| | | | +--rw accessvlan? vlan-type
| | | | +--rw rspan-access
| | | | +--rw rspan-access-vlan? vlan-type
| | | +--rw access-mac-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw trunk-private-vlan-classification
| | | | +--rw private-vlan
| | | | +--rw trunk
| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | +--rw access-mac-group-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-group]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-group mac-group-id-type
| | | +--rw trunk
| | | | +--rw allowed
| | | | | +--rw vlan
| | | | | | +--rw all? empty
| | | | | | +--rw none? empty
| | | | | | +--rw add? ui32-1k-vlan-range
| | | | | | +--rw except? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | x--rw vlanoper
| | | | | | +--rw vlan
| | | | | | +--rw add? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | +--rw rspan-vlan
| | | | | | +--rw add-rspan-trunk-vlan? ui32-vlan-range
| | | | | | +--rw remove-rspan-trunk-vlan? ui32-vlan-range
| | | | | +--rw trunk-rspan-vlan-classification
| | | | | +--rw rspan-vlan
| | | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-id dot1q-vlan-type

2

Network OS YANG Reference Manual 83
53-1003230-01

brocade-interface

2

| | | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw trunk-vlan-classification
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw add [trunk-vlan-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | | +--rw remove [trunk-vlan-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | +--rw default-vlan-config
| | | | | +--rw default-transparent-vlan? non-dot1q-vlan-type
| | | | +--rw tag?
| | | | | +--rw native-vlan? empty
| | | | +--rw native-vlan-classification
| | | | | +--rw native-vlan-id? native-vlan-type
| | | | | +--rw native-vlan-ctag-id? dot1q-vlan-type
| | | | +--rw native-vlan-xtagged-config
| | | | | +--rw native-vlan-id-xtagged? vlan-type
| | | | | +--rw native-vlan-ctag-id-xtagged? dot1q-vlan-type
| | | | | +--rw native-vlan-egress-type-xtagged? enumeration
| | | | +--rw native-vlan-untagged-config
| | | | +--rw native-vlan-id-untagged? vlan-type
| | | +--rw private-vlan
| | | | +--rw trunk
| | | | | +--rw native
| | | | | | +--rw pvlanNativevlan? vlan-type
| | | | | | +--rw pvlan-native-vlan-ctag-id? dot1q-vlan-type
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw pvlan_all? empty
| | | | | +--rw pvlan_none? empty
| | | | | +--rw pvlan_add? ui32-vlan-range
| | | | | +--rw pvlan_except? ui32-vlan-range
| | | | | +--rw pvlan_remove? ui32-vlan-range
| | | | +--rw host-association
| | | | | +--rw host-pri-pvlan? vlan-type
| | | | | +--rw host-sec-pvlan? vlan-type
| | | | +--rw association
| | | | | +--rw trunk [trunk-pri-pvlan trunk-sec-pvlan]
| | | | | +--rw trunk-pri-pvlan vlan-type
| | | | | +--rw trunk-sec-pvlan vlan-type
| | | | +--rw mapping [promis-pri-pvlan]
| | | | +--rw promis-pri-pvlan vlan-type
| | | | +--rw oper? secVlan-opp-type
| | | | +--rw promis-sec-pvlan-range? ui32-range-8091
| | | +--rw access-mac-rspan-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw access-mac-group-rspan-vlan-classification
| | | +--rw access
| | | +--rw vlan [access-vlan-id access-mac-group]
| | | +--rw access-vlan-id vlan-type
| | | +--rw access-mac-group mac-group-id-type
| | +--rw ip
| | +--rw vrf

84 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| | | +--rw forwarding? common-def:vrf-name
| | +--rw ipv6
| | | +--rw ra-guard? empty
| | +--rw vepa
| | | +--rw vepa-enable? empty
| | +--rw edge-loop-detection
| | +--rw eldprio? uint32
| | +--rw eldvlan? ui32-eldvlan-range

interface/fortygigabitethernet:

module: brocade-interface
+--rw interface

| +--rw fortygigabitethernet [name]
| | +--rw name interface-type
| | +--rw long-distance-isl? enumeration
| | +--rw cee? common-def:name-string32
| | +--ro ifindex? uint64
| | +--rw description? string
| | +--rw shutdown? empty
| | +--rw channel-group
| | | +--rw port-int? portchannel-type
| | | +--rw mode? po-mode
| | | +--rw type? po-type
| | +--rw mtu? mtu-type
| | +--rw switchport-basic
| | | +--rw basic? empty
| | +--rw switchport
| | | +--rw port-security?
| | | | +--rw port-sec-max? uint32
| | | | +--rw port-sec-violation? port-sec-violation
| | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw sticky?
| | | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw allowed-ouis [oui]
| | | | | +--rw oui oui-type
| | | | +--rw shutdown-time? uint32
| | | +--rw mode
| | | | +--rw vlan-mode? l2-mode-type
| | | | +--rw private-vlan
| | | | +--rw private-vlan-trunk
| | | | | +--rw trunk-basic? empty
| | | | | +--rw trunk-promiscuous? empty
| | | | | +--rw trunk-host? empty
| | | | +--rw promiscuous? empty
| | | | +--rw host? empty
| | | +--rw access
| | | | +--rw accessvlan? vlan-type
| | | | +--rw rspan-access
| | | | +--rw rspan-access-vlan? vlan-type
| | | +--rw access-mac-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw trunk-private-vlan-classification

2

Network OS YANG Reference Manual 85
53-1003230-01

brocade-interface

2

| | | | +--rw private-vlan
| | | | +--rw trunk
| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | +--rw access-mac-group-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-group]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-group mac-group-id-type
| | | +--rw trunk
| | | | +--rw allowed
| | | | | +--rw vlan
| | | | | | +--rw all? empty
| | | | | | +--rw none? empty
| | | | | | +--rw add? ui32-1k-vlan-range
| | | | | | +--rw except? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | x--rw vlanoper
| | | | | | +--rw vlan
| | | | | | +--rw add? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | +--rw rspan-vlan
| | | | | | +--rw add-rspan-trunk-vlan? ui32-vlan-range
| | | | | | +--rw remove-rspan-trunk-vlan? ui32-vlan-range
| | | | | +--rw trunk-rspan-vlan-classification
| | | | | +--rw rspan-vlan
| | | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw trunk-vlan-classification
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw add [trunk-vlan-id]
| | | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | | +--rw remove [trunk-vlan-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-range? ui32-ctag-range
| | | | +--rw default-vlan-config
| | | | | +--rw default-transparent-vlan? non-dot1q-vlan-type
| | | | +--rw tag?
| | | | | +--rw native-vlan? empty
| | | | +--rw native-vlan-classification
| | | | | +--rw native-vlan-id? native-vlan-type
| | | | | +--rw native-vlan-ctag-id? dot1q-vlan-type
| | | | +--rw native-vlan-xtagged-config
| | | | | +--rw native-vlan-id-xtagged? vlan-type
| | | | | +--rw native-vlan-ctag-id-xtagged? dot1q-vlan-type
| | | | | +--rw native-vlan-egress-type-xtagged? enumeration
| | | | +--rw native-vlan-untagged-config
| | | | +--rw native-vlan-id-untagged? vlan-type

86 Network OS YANG Reference Manual

53-1003230-01

brocade-interface

| | | +--rw private-vlan
| | | | +--rw trunk
| | | | | +--rw native
| | | | | | +--rw pvlanNativevlan? vlan-type
| | | | | | +--rw pvlan-native-vlan-ctag-id? dot1q-vlan-type
| | | | | +--rw allowed
| | | | | +--rw vlan
| | | | | +--rw pvlan_all? empty
| | | | | +--rw pvlan_none? empty
| | | | | +--rw pvlan_add? ui32-vlan-range
| | | | | +--rw pvlan_except? ui32-vlan-range
| | | | | +--rw pvlan_remove? ui32-vlan-range
| | | | +--rw host-association
| | | | | +--rw host-pri-pvlan? vlan-type
| | | | | +--rw host-sec-pvlan? vlan-type
| | | | +--rw association
| | | | | +--rw trunk [trunk-pri-pvlan trunk-sec-pvlan]
| | | | | +--rw trunk-pri-pvlan vlan-type
| | | | | +--rw trunk-sec-pvlan vlan-type
| | | | +--rw mapping [promis-pri-pvlan]
| | | | +--rw promis-pri-pvlan vlan-type
| | | | +--rw oper? secVlan-opp-type
| | | | +--rw promis-sec-pvlan-range? ui32-range-8091
| | | +--rw access-mac-rspan-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw access-mac-group-rspan-vlan-classification
| | | +--rw access
| | | +--rw vlan [access-vlan-id access-mac-group]
| | | +--rw access-vlan-id vlan-type
| | | +--rw access-mac-group mac-group-id-type
| | +--rw ip
| | +--rw vrf
| | | +--rw forwarding? common-def:vrf-name
| | +--rw ipv6
| | | +--rw ra-guard? empty
| | +--rw edge-loop-detection
| | +--rw eldprio? uint32
| | +--rw eldvlan? ui32-eldvlan-range

2

interface/hundredgigabitethernet:

module: brocade-interface
+--rw interface
| +--rw hundredgigabitethernet [name]
| | +--rw name interface-type
| | +--rw cee? common-def:name-string32
| | +--ro ifindex? uint64
| | +--rw description? string
| | +--rw shutdown? empty
| | +--rw channel-group
| | | +--rw port-int? portchannel-type
| | | +--rw mode? po-mode
| | | +--rw type? po-type
| | +--rw mtu? mtu-type
| | +--rw switchport-basic
| | | +--rw basic? empty
| | +--rw switchport

Network OS YANG Reference Manual 87
53-1003230-01

brocade-interface

2

| | | +--rw port-security?
| | | | +--rw port-sec-max? uint32
| | | | +--rw port-sec-violation? port-sec-violation
| | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw sticky?
| | | | | +--rw port-secutiry-mac-address [mac-address port-sec-vlan]
| | | | | +--rw mac-address mac-address-type
| | | | | +--rw port-sec-vlan vlan-type
| | | | +--rw allowed-ouis [oui]
| | | | | +--rw oui oui-type
| | | | +--rw shutdown-time? uint32
| | | +--rw mode
| | | | +--rw vlan-mode? l2-mode-type
| | | | +--rw private-vlan
| | | | +--rw private-vlan-trunk
| | | | | +--rw trunk-basic? empty
| | | | | +--rw trunk-promiscuous? empty
| | | | | +--rw trunk-host? empty
| | | | +--rw promiscuous? empty
| | | | +--rw host? empty
| | | +--rw access
| | | | +--rw accessvlan? vlan-type
| | | | +--rw rspan-access
| | | | +--rw rspan-access-vlan? vlan-type
| | | +--rw access-mac-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-address]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-address mac-address-type
| | | +--rw trunk-private-vlan-classification
| | | | +--rw private-vlan
| | | | +--rw trunk
| | | | +--rw allowed
| | | | +--rw vlan
| | | | +--rw add [trunk-vlan-id trunk-ctag-id]
| | | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | | +--rw remove [trunk-vlan-id trunk-ctag-id]
| | | | +--rw trunk-vlan-id non-dot1q-vlan-type
| | | | +--rw trunk-ctag-id dot1q-vlan-type
| | | +--rw access-mac-group-vlan-classification
| | | | +--rw access
| | | | +--rw vlan [access-vlan-id access-mac-group]
| | | | +--rw access-vlan-id vlan-type
| | | | +--rw access-mac-group mac-group-id-type
| | | +--rw trunk
| | | | +--rw allowed
| | | | | +--rw vlan
| | | | | | +--rw all? empty
| | | | | | +--rw none? empty
| | | | | | +--rw add? ui32-1k-vlan-range
| | | | | | +--rw except? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | x--rw vlanoper
| | | | | | +--rw vlan
| | | | | | +--rw add? ui32-vlan-range
| | | | | | +--rw remove? ui32-vlan-range
| | | | | +--rw rspan-vlan

88 Network OS YANG Reference Manual

53-1003230-01
