Power Tools & Accessories Catalog
Masonry and
Concrete Drilling
2 | 2012/2013 Power Tools & Accessories Catalog
1 DrillingMasonry/Concrete
The Industry Leader in Concrete Power Tools and Accessories
Through 80 years of developing innovative tools and accessories for the concrete
professional, Bosch has become the
acknowledged leader in the industry. With a robust line that can address everything from the toughest concrete drilling tasks
to material removal, Bosch is a company whose legacy is written in concrete.
Since the introduction of the first electro-pneumatic, hand-held rotary hammer in 1932, Bosch has brought breakthrough products and new ideas to the construction industry worldwide. That heritage was further
enhanced with the 1950 launch of the Brute™ Breaker Hammer, which continues to be the hammer pros demand. In fact, the oldest Brute was rented for more than 21 years, that's 2,076 times — and still remains operational today.
The new Brute (BH2760VC) was updated in 2010 to include technology that makes it the hardest-hitting hammer in its class, proven by its ability to remove more than three tons of concrete an hour. And this productivity comes with powerful vibration control technology, which reduces vibration by up to 50 percent.
Bosch has documented achievement on the accessories side as well. In 1975, Bosch invented the industry-leading SDS-plus® shank system, which remains the interface system of choice for concrete professionals. In 1990 the company enhanced the original SDS-plus offering with the rollout of SDS-max® and created a new standard.
Today, Bosch innovation extends to flexible dust collection attachments that fit a wide array of tools, including grinders for concrete cutting and surfacing, and hammer attachments for virtually dust-free drilling.
The latest chapter in the company's concrete heritage highlights Bosch measuring tools, which brings a global perspective to laser measurement. Thanks to outstanding engineering and global manufacturing, this complete line covers interior and exterior leveling and alignment applications.
If the project requires work in concrete, from polishing and anchoring to material removal, there's only one place to turn for a complete solution. Trust Bosch to provide the professional-grade tools and accessories to get the job done right.
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 3
1 DrillingMasonry/Concrete
The Bosch Concrete System
Bosch has the right tool and accessory to optimize your project. The technology built into the tool and the interface that connects it to your bits, drives maximium power transfer. From anchoring to large material breaking, the chart below matches the right tool type and accessory style.
Type |
|
|
|
|
Wood/Metal |
Brick/Block |
Concrete |
Reinforced Concrete |
||
Hammer Drills |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ffDrilling |
|
|
|
|
|
• |
• |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
3/4"–1-1/8" Rotary Hammers |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
ffDrilling |
|
|
|
|
|
|
• |
• |
• |
|
ffAnchoring |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
||
ffLight Chiseling |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
1/8"–1-1/4" Rotary Hammers |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
ffDrilling |
|
|
|
|
|
|
• |
• |
• |
|
ffAnchoring |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
||
ffChiseling |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
1-9/16"–2" Combination Hammers |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|||
ffDrilling |
|
|
|
|
|
• |
• |
• |
||
ffAnchoring |
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|||
ffLight Demolition |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Demolition Hammers ffDemolition
1-1/8" Breaker Hammers
ffPavement Breaking
••
••
Toll free: 877-BOSCH-99
1 DrillingMasonry/Concrete
4 | 2012/2013 Power Tools & Accessories Catalog
Quick Tool Reference Guide
Item# |
1191VSRK |
HD19-2/HD19-2D |
HD21-2 |
11250VSR |
11250VSRD |
Drive System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hammer |
Hammer Drill |
Hammer Drill |
Hammer Drill |
Rotary |
Rotary |
|||||||||||
Classification |
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Amperage |
7 |
|
|
8.5 |
|
|
9.2 |
|
|
6.1 |
|
|
6.1 |
|
|
|
Impact Energy |
— |
— |
— |
1.6 |
|
|
1.6 |
|
|
|||||||
(ft.-lbs.) |
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Max. Capacity— |
5/8" |
|
|
3/4" / 7/8" |
|
7/8" / 1" |
|
|
3/4" |
|
|
3/4" |
|
|
||
Concrete/Masonry |
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Optimal Range |
1/8"–5/16" |
1/8"–3/8" |
1/8"–1/2" |
5/32"–5/8" |
5/32"–5/8" |
|||||||||||
Core Bits |
— |
— |
— |
1-1/2" |
|
|
1-1/2" |
|
|
|||||||
No Load RPM |
0–3,000 |
0–1,000/0–3,000 |
0–900/0–3,000 |
0–1,000 |
0–1,000 |
|||||||||||
No Load BPM |
0–48,000 |
0–17,000/ |
0–15,300/ |
0–4,400 |
0–4,400 |
|||||||||||
0–51,000 |
0–51,000 |
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|||||||
Modes of |
Hammer Drill |
Hammer Drill |
Hammer Drill |
Rotary Hammer |
Rotary Hammer |
|||||||||||
Operation |
Rotation Only |
Rotation Only |
Rotation Only |
Rotation Only |
Rotation Only |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Length |
11" |
|
|
13.4"/18" |
|
13.5" |
|
|
13.25" |
|
|
19.6" |
|
|
||
Weight |
4.1 lbs. |
5.8 lbs./7.2 lbs. |
5.9 lbs. |
5.4 lbs. |
7.4 lbs. |
|||||||||||
|
|
|
|
|
|
|
|
|
|
RH328VC/ |
|
|
|
|||
Item# |
11253VSR |
11255VSR |
RH228VC |
RH328VCQ |
RH432VCQ |
|||||||||||
|
|
|
|
|
|
|
|
|
™ |
|
|
™ |
|
|
™ |
|
Drive System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hammer |
Rotary |
Rotary |
Rotary |
Rotary |
Rotary |
|||||||||||
Classification |
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Amperage |
7.2 |
|
|
7.5 |
|
|
8.0 |
|
|
8.0 |
|
|
8.5 |
|
|
|
Impact Energy |
2.2 |
|
|
2.2 |
|
|
2.4 |
|
|
2.6 |
|
|
3.7 |
|
|
|
(ft.-lbs.) |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Max. Concrete |
1" |
|
|
1" |
|
|
1-1/8" |
|
|
1-1/8" |
|
|
1-1/4" |
|
|
|
Capacity |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Optimal Range |
3/16"–5/8" |
3/16"–5/8" |
3/16"–3/4" |
1/4"–7/8" |
3/8"–1" |
|||||||||||
Core Bits |
2-1/2" |
|
|
2-5/8" |
|
|
2-3/4" |
|
|
3-1/8" |
|
|
3-1/2" |
|
|
|
No Load RPM |
0–1,300 |
0–1,300 |
0–1,230 |
0–900 |
0–760 |
|||||||||||
No Load BPM |
0–5,800 |
0–5,800 |
0–5,460 |
0–4,000 |
0–3,600 |
|||||||||||
Bosch Vibration |
No |
No |
Hammer Mechanism |
Hammer Mechanism |
Hammer Mechanism |
|||||||||||
Control |
and Handle |
and Handle |
||||||||||||||
|
|
|
|
|
|
|
|
|
||||||||
**Vibration Levels m/s2 — |
— |
12 |
|
|
13 |
|
|
10 |
|
|
||||||
Modes of |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
|||||||||||
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
|||||||||||||
Operation |
Rotation Only |
|||||||||||||||
Rotation Only |
Rotation Only |
Rotation Only |
Rotation Only |
|||||||||||||
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Length |
14.8" |
|
|
17.3" |
|
|
17.4" |
|
|
12.5"/13.6" |
|
15.75" |
|
|
||
Weight |
6.4 lbs. |
6.7 lbs. |
6.9 lbs. |
7.7/7.9 lbs. |
10.3 lbs. |
|||||||||||
**Per EPTA EN 60745
Color-Coded Accessory System
For small |
For medium |
For medium |
For large |
and medium |
and large rotary |
and large rotary |
breaker or |
rotary |
hammers or |
hammers or |
demolition |
hammers. |
demolition |
demolition |
hammers. |
|
hammers. |
hammers. |
|
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 5
Item # |
11240 |
11247 |
11264EVS |
11265EVS |
11263EVS |
11245EVS |
|
|
|
|
™ |
™ |
|
Drive System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hammer |
Combination |
Combination |
Combination |
Combination |
Combination |
Combination |
|||||||||||||||||
Classification |
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Amperage |
10 |
|
|
10 |
|
|
|
|
13 |
|
|
13 |
|
|
|
|
13.5 |
|
|
14 |
|
|
|
Impact Energy |
5.2 |
|
|
5.2 |
|
|
|
|
6.8 / 8.1 (turbo+) |
6.8 / 8.1 (turbo) |
9.6 / 11.1 |
|
13.3 |
|
|
||||||||
(ft.-lbs.) |
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Max. Concrete |
1-9/16" |
|
1-9/16" |
|
|
|
1-5/8" |
|
|
1-5/8" |
|
|
|
|
1-3/4" |
|
|
2" |
|
|
|||
Capacity |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Optimal Range |
1/2"–1-3/8" |
1/2"–1-3/8" |
1/2"–1-7/16" |
1/2"–1-7/16" |
5/8"–1-9/16" |
3/4"–1-3/4" |
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Thru Hole Bits |
2-1/2" |
|
|
2-1/2" |
|
|
|
|
2-9/16" |
|
2-9/16" |
|
|
|
3-1/8" |
|
|
3-1/8" |
|
|
|||
Core Bits |
4" |
|
|
4" |
|
|
|
|
4-1/8" |
|
|
4-1/8" |
|
|
|
|
6" |
|
|
6" |
|
|
|
No Load RPM |
400 |
|
|
400 |
|
|
|
|
170–340 |
170–340 |
145–280 |
120–250 |
|||||||||||
No Load BPM |
3,000 |
|
|
3,000 |
|
|
|
|
1,700–2,900 |
1,700–2,900 |
1,350–2,800 |
1,100–2,500 |
|||||||||||
Bosch Vibration |
|
|
|
|
|
|
|
|
Hammer |
Hammer |
|
|
|
|
|
|
|||||||
No |
No |
Mechanism |
Mechanism |
No |
No |
||||||||||||||||||
Control |
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
and Handle |
and Handle |
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
**Vibration |
— |
— |
10.0 |
|
|
10.0 |
|
|
|
|
— |
— |
|||||||||||
Levels m/s2 |
|
|
|
|
|
|
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Modes of |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
Rotary Hammer |
|||||||||||||||||
Operation |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
|||||||||||||||||
Length |
17.25" |
|
|
17.25" |
|
|
|
|
19.25" |
|
|
19.25" |
|
|
|
|
21" |
|
|
23.5" |
|
|
|
Weight |
13.2 lbs. |
13.6 lbs. |
14.3 lbs. |
14.7 lbs. |
17.9 lbs. |
24.5 lbs. |
|||||||||||||||||
**Per EPTA EN 60745
1 DrillingMasonry/Concrete
|
|
|
|
|
|
|
|
BH2760VC/ |
Item # |
11387 |
11388 |
11321EVS |
11316EVS |
11317EVS |
11335K |
|
BH2760VCB/ |
|
BH2760VCD |
|||||||
|
|
|
|
™ |
|
|
™ |
™ |
BRUTE™
Drive System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hammer |
Demolition |
Demolition |
Demolition |
Demolition |
Demolition |
Breaker |
Breaker |
|||||||||||||||
Classification |
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Amperage |
10 |
|
|
10 |
|
|
13 |
|
|
14 |
|
|
12.8 |
|
|
15 |
|
|
15 |
|
|
|
Impact Energy |
5.9 |
|
|
5.9 |
|
|
9.6 |
|
|
4.4–18.4 |
4–16.5 |
34 |
|
|
49.5 ft.-lbs.* |
|||||||
(ft.-lbs.) |
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
BPM |
2,800 |
|
2,800 |
|
1,300–2,900 |
900–1,890 |
850–1,800 |
1,300 |
|
1,000 |
|
|||||||||||
Bosch Vibration |
|
|
|
|
|
|
Hammer |
|
|
|
|
|
|
Hammer |
Hammer |
|||||||
No |
No |
Mechanism |
No |
No |
Mechanism |
Mechanism |
||||||||||||||||
Control |
||||||||||||||||||||||
|
|
|
|
|
|
and Handle |
|
|
|
|
|
|
and Handle |
and Handles |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
••Vibration |
— |
— |
8.0 |
|
|
— |
— |
10.8 |
|
|
8.0 |
|
|
|||||||||
Levels m/s2 |
|
|
|
|
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Modes of |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
Hammer Only |
|||||||||||||||
Operation |
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Length |
17.5" |
|
|
17.5" |
|
|
18.6" |
|
|
22.5" |
|
|
22" |
|
|
30.4" |
|
30.5" |
|
|||
Weight |
12.0 lbs. |
11.6 lbs. |
12.8 lbs. |
22.5 lbs. |
22.0 lbs. |
38.0 lbs. |
65.0 lbs. |
|||||||||||||||
*Based on test of 230V product **Per EPTA EN 60745
Toll free: 877-BOSCH-99
Best power. Best performance. Lowest vibration.
Unleash the Bosch Bulldog™ XtremeMax and SDS-plus® Bulldog Xtreme™ Rotary Hammer Bits. Well known as the toughest tool on the jobsite, the Bosch Bulldog now hits even harder with a larger bit capacity, longer stroke and bits with four times longer life in rebar vs. standard SDS-plus bits. Featuring an integrated counter balance for vibration control, this is definitely one tool you'll want to unleash.
2012/2013 Power Tools & Accessories Catalog | 7
Hammer Drills
1191VSRK Hammer Drill
ff 1/2" three-jaw chuck for rugged hammer drilling applications
ff Dual-Mode Selector — Easily coverts from hammer drill to rotation-only mode
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
ff 360° auxiliary handle with built-in quick-release depth gauge
Includes:
360˚ Auxiliary Handle 2602025094
Depth Gauge 2603001009
Chuck Key 2607950007
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V AC |
|
Amperage |
7.0 |
|
No Load RPM |
0–3,000 |
|
No Load BPM |
0–48,000 |
|
Maximum |
|
|
Capacities: |
5/8" / 5/8" |
|
Concrete/Masonry |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
|
|
|
|
|
Maximum |
1-1/2" |
|
Capacities: Wood |
|
|
|
|
|
Maximum |
|
|
Capacities: |
5/8" |
|
Aluminum |
|
|
Length |
11.0" |
|
Weight |
4.1 lbs. |
|
1
DrillsHammer
DrillingMasonry/Concrete
Toll free: 877-BOSCH-99
1
DrillsHammer
DrillingMasonry/Concrete
8 | 2012/2013 Power Tools & Accessories Catalog
HD19-2 Two-Speed Hammer Drill
ff Torque-Control Auxiliary Handle — Securely locks into place for maximum control
ff Dual-Mode Selector — Easily converts from hammer drill to rotation-only mode
ff Two-Speed Gear Box — Select high-speed (for concrete) or high-torque (for wood and metal) drilling applications
ff Integral Slip Clutch — Helps minimize torque reaction
Includes:
360˚ Auxiliary Handle 2602025175
Depth Gauge 1613001009
Chuck Key 2607950007
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V AC |
|
Amperage |
8.5 |
|
No Load RPM |
0–1,000/0–3,000 |
|
No Load BPM |
0–17,000/0–51,000 |
|
Maximum |
|
|
Capacities: |
3/4" / 7/8" |
|
Concrete/Masonry |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
|
|
|
|
|
Maximum |
1-1/2" |
|
Capacities: Wood |
|
|
|
|
|
Length |
13.4" |
|
Weight |
5.8 lbs. |
|
HD19-2D Two-Speed Hammer Drill with Dust Collection Unit
ff Dual-Mode Selector — Easily converts from hammer drill to rotation-only mode
ff Two-Speed Gear Box — Select high-speed (for concrete) or high-torque (for wood and metal) drilling applications
ff Integral Slip Clutch — Helps minimize torque reaction
ff Dust Collection with Micro-Filter System — Dramatically reduces dust from drilling
ff Integrated Dual-Fan System — Second set of fan blades with the motor creates the air suction for maximum dust collection
Includes:
Dust Collection Unit
360˚ Auxiliary Handle 2602025175
Chuck Key 2607950007
Depth Gauge 1613001009
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V AC |
|
Amperage |
8.5 |
|
No Load RPM |
0–1,000/0–3,000 |
|
No Load BPM |
0–17,000/0–51,000 |
|
Maximum |
|
|
Capacities: |
3/4" / 7/8" |
|
Concrete/Masonry |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
|
|
|
|
|
Maximum |
1-1/2" |
|
Capacities: Wood |
|
|
|
|
|
Length |
18" |
|
Weight |
7.2 lbs. |
|
HD21-2 Two-Speed Hammer Drill
ff Torque-Control Auxiliary Handle — Securely locks into place for maximum control
ff Dual-Mode Selector — Easily converts from hammer drill to rotation-only mode
ff Two-Speed Gear Box — Select high-speed (for concrete) or high-torque (for wood and metal drilling applications)
ff Integral Slip Clutch — Helps minimize torque reaction
Includes:
360˚ Auxiliary Handle 2602025175
Chuck Key 2607950007
Depth Gauge 1613001009
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
For more details visit
Boschtools.com
Specifications |
|
|
Rating |
120V AC |
|
Amperage |
9.2 |
|
No Load RPM |
0–900/0–3,000 |
|
No Load BPM |
0–15,300/0–51,000 |
|
Maximum |
|
|
Capacities: |
7/8" / 1" |
|
Concrete/Masonry |
|
|
Maximum |
5/8" |
|
Capacities: Steel |
|
|
|
|
|
Maximum |
1-5/8" |
|
Capacities: Wood |
|
|
|
|
|
Length |
13.5" |
|
Weight |
5.9 lbs. |
|
2012/2013 Power Tools & Accessories Catalog | 9
Dust Collection Adapter
Vacuum Dust Port Adapter
Item # |
Description |
2610014502 |
For 11250VSRD and HD19-2D |
Hammer Drill Bits
Hammer Drill Bit
Fast, precise drilling in concrete, stone and masonry
Milled u-flutes with deep-cut spiral for fast dust removal
Diamond ground carbide tip for precise starts in tile and hard stone
Robust head provides long life in impact applications
PowerGrip™ shank for aggressive gripping power
|
|
HCBG700T |
HCBG501T |
||
BlueGranite™ Turbo Carbide
Hammer Drill Bits
Item # |
Diameter |
Useable |
Overall |
Qty. |
Bulk Item # |
Bulk |
|
Length |
Length |
Qty. |
|||||
HCBG01T* 1/8" |
2" |
3" |
1 |
HCBG01B25T |
25 |
||
HCBG02T* 5/32" |
3" |
6" |
1 |
HCBG0205T |
5 |
||
HCBG02B25T |
25 |
||||||
|
|
|
|
|
|||
HCBG03T* 3/16" |
3" |
4" |
1 |
HCBG0305T |
5 |
||
HCBG03B25T |
25 |
||||||
|
|
|
|
|
|||
HCBG04T* 3/16" |
4" |
6" |
1 |
HCBG0405T |
5 |
||
HCBG04B25T |
25 |
||||||
|
|
|
|
|
|||
HCBG05T* 7/32" |
4" |
6" |
1 |
HCBG0505T |
5 |
||
HCBG05B25T |
25 |
||||||
|
|
|
|
|
|||
HCBG06T* 1/4" |
4" |
6" |
1 |
HCBG0605T |
5 |
||
HCBG06B25T |
25 |
||||||
|
|
|
|
|
|||
HCBG07T* 1/4" |
8" |
10" |
1 |
— |
— |
||
HCBG08T* 1/4" |
10" |
12" |
1 |
— |
— |
||
HCBG09T* 5/16" |
4" |
6" |
1 |
HCBG09B25T |
25 |
||
HCBG10T* 5/16" |
7-1/2" |
10" |
1 |
— |
— |
||
HCBG11T* 5/16" |
10" |
12" |
1 |
— |
— |
||
HCBG12T* 3/8" |
4" |
6" |
1 |
HCBG12B25T |
25 |
||
HCBG13T* 3/8" |
8" |
10" |
1 |
— |
— |
||
HCBG14T* 3/8" |
10" |
12" |
1 |
— |
— |
||
HCBG15T* 7/16" |
4" |
6" |
1 |
HCBG15B25T |
25 |
||
HCBG16T* 1/2" |
4" |
6" |
1 |
HCBG16B25T |
25 |
||
HCBG17T* 1/2" |
8" |
10" |
1 |
— |
— |
||
HCBG18T* 1/2" |
10" |
12" |
1 |
— |
— |
||
HCBG19T* 9/16" |
7-1/2" |
10" |
1 |
— |
— |
||
HCBG20T* 5/8" |
4" |
6" |
1 |
HCBG20B25T |
25 |
||
HCBG21T* 5/8" |
10" |
12" |
1 |
— |
— |
||
HCBG22T* 3/4" |
4" |
6" |
1 |
— |
— |
||
HCBG23T* 3/4" |
10" |
12" |
1 |
— |
— |
||
HCBG24T* 7/8" |
4" |
6" |
1 |
— |
— |
||
HCBG25T* 7/8" |
10" |
12" |
1 |
— |
— |
||
HCBG26T* 1" |
4" |
6" |
1 |
— |
— |
||
HCBG27T* 1" |
10" |
12" |
1 |
— |
— |
||
*Available Spring 2012
BlueGranite™ Turbo Carbide
Hammer Drill Bit Sets
|
# of |
|
|
Case |
|
Item # |
Pieces |
Includes |
Type |
||
HCBG500T* |
|
(1) |
1/8" × 2" × 3", (1) 3/16" × 4" × 6", |
|
|
5 |
(1) 1/4" × 4" × 6", (1) 5/16" × 4" × 6", |
Pouch |
|||
|
|
(1) |
3/8" × 4" × 6" |
|
|
HCBG501T* |
|
(1) |
5/32" × 2" × 3", (1) 3/16" × 4" × 6", |
|
|
5 |
(1) 1/4" × 4" × 6", (1) 5/16" × 4" × 6", |
Pouch |
|||
|
|
(1) |
3/8" × 4" × 6" |
|
|
HCBG600T* |
6 |
(3) |
5/32" × 4" × 6", |
Pouch |
|
(3) |
3/16" × 4" × 6" |
||||
|
|
|
|||
HCBG700T* |
|
(1) |
1/8" × 2" × 3", (2) 5/32" × 3" × 6", |
Brute |
|
7 |
(2) 3/16" × 4" × 6", (1) 1/4" × 4" × 6", |
Tough™ |
|||
|
|
(1) |
3/8" × 4" × 6" |
|
|
*Available Spring 2012
Toll free: 877-BOSCH-99
1 AccessoriesDrill
Masonry/Concrete Drilling Hammer
1 AccessoriesDrill
Masonry/Concrete Drilling Hammer
10 | 2012/2013 Power Tools & Accessories Catalog
MULTICONSTRUCTION™ Bit
Drills practically everything
Robust head |
|
|
|
|
|
Sharp, ground |
|
|
|
|
|||
|
|
|
|
|
cutting edges |
|
|
|
|
|
|
||
provides long |
|
|
|
|
|
|
|
|
|
|
|
for fast drilling |
|
life in impact |
|
|
|
|
|
|
|
|
|
|
|
in hard materials |
|
applications |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Steep flute |
|
|
|
|
|
|
|
|
|
|
|
|
|
with ribs |
|
|
|
|
|
|
optimizes |
|
|
|
|
|
|
dust removal |
|
|
|
|
|
|
in any material |
Grip shank |
|
|
|
|
|
|
|
|
|
|
|
|
|
provides |
|
|
|
|
|
|
aggressive |
|
|
|
|
|
|
gripping power |
|
|
|
|
|
|
Great in Sandwich Material
ffConcrete ffMetal ffWood ffTile
Glass and Tile Bit
Drills faster, lasts longer
|
Carbide tip |
|
|
|
|
|
Precision- |
|
|
|
|
|
|||
|
|||||||
for long life in |
|
|
|
|
ground tip |
||
hard materials |
|
|
|
|
reduces |
||
|
|
|
|
|
|
|
bit walking |
|
|
|
|
|
|
|
|
Common |
|
|
|
|
|
Reinforced |
|
Applications: |
|
|
|
|
|
||
|
|
|
|
|
head |
||
ffRelief holes |
|
|
|
|
|
||
|
|
|
|
|
maximizes |
||
for glass |
|
|
|
|
|
bit life |
|
cutting |
|
|
|
|
|
||
ffBathroom/ |
|
|
|
|
|
|
|
shower |
|
|
|
|
|
|
|
installs |
|
|
|
|
|
Three flat |
|
ffTowel/shower |
|
|
|
|
|
||
|
|
|
|
||||
rods and |
|
|
|
|
|
shank |
|
soap dishes |
|
|
|
|
|
provides |
|
ffDrilling and |
|
|
|
|
|
superior grip |
|
fastening |
|
|
|
|
|
|
|
mirrors |
|
|
|
|
|
|
|
ffSetting |
|
|
|
|
|
|
|
concrete |
|
|
|
|
|
|
|
screws in tile |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For more details visit |
|
|
|
|
|
|
|
Boschtools.com |
|
|
|
|
|
|
MULTICONSTRUCTION™ Drill Bits
|
|
Usable |
Overall |
|
Bulk |
Bulk |
Item # |
Diameter |
Length |
Length |
Qty. |
Item # |
Qty. |
MC01 |
1/8" |
2" |
3" |
1 |
— |
— |
MC02 |
5/32" |
4" |
6" |
1 |
MC02B25 |
25 |
MC03 |
3/16" |
4" |
6" |
1 |
MC03B25 |
25 |
MC06 |
1/4" |
4" |
6" |
1 |
MC06B25 |
25 |
MC07 |
1/4" |
6" |
8" |
1 |
— |
— |
MC09 |
5/16" |
4" |
6" |
1 |
MC09B25 |
25 |
MC10 |
5/16" |
8" |
10" |
1 |
— |
— |
MC12 |
3/8" |
4" |
6" |
1 |
MC12B25 |
25 |
MC13 |
3/8" |
8" |
10" |
1 |
– |
— |
MC16 |
1/2" |
4" |
6" |
1 |
— |
— |
MC17 |
1/2" |
8" |
10" |
1 |
— |
— |
MULTICONSTRUCTION™ Drill Bit Set
Item # |
# of Pieces |
Includes |
Case Type |
|
|
|
(1) |
5/32" × 4" × 6", |
|
MC500 |
|
(1) |
3/16" × 4" × 6", |
|
5 |
(1) 1/4" × 4" × 6", |
Plastic |
||
|
|
(1) |
5/16" × 4" × 6", |
|
|
|
(1) |
3/8" × 4" × 6" |
|
MC500
Glass and Tile Bits
Item # |
Diameter |
GT100 |
1/8" |
GT200 |
3/16" |
GT300 |
1/4" |
GT400 |
5/16" |
GT500 |
3/8" |
GT600 |
1/2" |
GT700 |
5/8" |
GT800 |
3/4" |
GT900 |
7/8" |
GT1000 |
1" |
Glass and Tile Bit Sets
Item # |
# of Pieces Includes |
|
Case Type |
|||
GT2000 |
4 |
(1) |
1/8", (1) 3/16", |
— |
||
(1) |
1/4", (1) 5/16" |
|||||
|
|
|
||||
|
|
(1) |
1/8", (1) 3/16", |
|
||
GT3000 |
8 |
(1) |
1/4", (1) |
5/16", |
Brute Tough™ |
|
(1) |
3/8", (1) |
1/2", |
||||
|
|
|
||||
|
|
(1) |
5/8", (1) |
3/4" |
|
|
GT3000
2012/2013 Power Tools & Accessories Catalog | 11
Rebar Cutter
Cuts rebar, cost and time
Solves the #1 problem in concrete drilling
Relief hole dissipates heat and allows for slug removal
Tapered body design |
High-quality |
provides less weight |
carbide |
for smoother drilling |
for long |
|
drilling life |
Unique flute geometry with steep spiral removes debris fast
Cutting Rebar
Step 1:
Drill with SDS-plus® carbide bit and remove after contact with rebar
Step 2:
Replace bit with rebar cutter and switch to rotary mode
Step 3:
Cut through rebar and remove after contact with concrete
Step 4:
Switch back to hammer carbide bit to
continue drilling
Straight Shank Rebar Cutters |
Straight Shank Extensions |
Item # |
Diameter |
Length |
Qty. |
RCSS2064 |
3/8" |
12" |
1 |
RCSS2084 |
1/2" |
12" |
1 |
RCSS2094 |
9/16" |
12" |
1 |
RCSS2104 |
5/8" |
12" |
1 |
RCSS2124 |
3/4" |
12" |
1 |
RCSS2144 |
7/8" |
12" |
1 |
RCSS2164 |
1" |
12" |
1 |
RCSS2168 |
1-1/8" |
12" |
1 |
RCSS2172 |
1-1/4" |
12" |
1 |
RCSS2176 |
1-1/2" |
12" |
1 |
RCSS2086 |
1/2" |
18" |
1 |
RCSS2106 |
5/8" |
18" |
1 |
RCSS2126 |
3/4" |
18" |
1 |
*Available in SDS-plus® — see page 18
Item # |
Diameter |
Length |
Qty. |
EX1006 |
7/16" shank |
6" |
1 |
EX1012 |
7/16" shank |
12" |
1 |
Concrete Screw Anchoring System
Holds tight tolerances that are critical to precision anchoring
|
|
|
High-quality |
|
|
|
|
|
|
|
carbide tip |
Flat shank |
|
||
|
for long life |
||
prevents bit slippage |
|
||
|
|
||
Common Applications: ffConduit
ffElectrical boxes ffPipe straps
ffHVAC strapping ffSign fastening ffWindow frames ffBacker boards
Flat Shank Hex Masonry Drill Bits
For use with masonry fastening systems/hex sleeve drive tools. Hex drive on bit fits into driver sleeve.
|
|
|
|
Bulk |
|
|
Item # |
Diameter |
Length |
Qty. |
Item # |
Bulk Qty. |
|
TC100 |
5/32" |
3-1/2" |
1 |
TC1005 |
5 |
|
TC1025 |
25 |
|||||
|
|
|
|
|||
TC200 |
5/32" |
4-1/2" |
1 |
TC2005 |
5 |
|
TC2025 |
25 |
|||||
|
|
|
|
|||
TC300 |
5/32" |
5-1/2" |
1 |
TC3005 |
5 |
|
TC3025 |
25 |
|||||
|
|
|
|
|||
TC400 |
3/16" |
3-1/2" |
1 |
TC4005 |
5 |
|
TC4025 |
25 |
|||||
|
|
|
|
|||
TC500 |
3/16" |
4-1/2" |
1 |
TC5005 |
5 |
|
TC5025 |
25 |
|||||
|
|
|
|
|||
TC600 |
3/16" |
5-1/2" |
1 |
TC6005 |
5 |
|
TC6025 |
25 |
|||||
|
|
|
|
Flat Shank Hex Accessories
For use with masonry fastening systems/hex sleeve drive tools. Hex drive on bit fits into driver sleeve.
Item # |
Description |
Qty. |
TC700 |
Masonry screw drill bit holder |
1 |
TC800 |
Masonry screw drill bit sleeve |
1 |
TCNS516 |
Drill bit nutsetter 5/16" hex |
1 |
TCNS14 |
Drill bit nutsetter 1/4" hex |
1 |
TCSDP2 |
Concrete screwdriving bit P2 |
1 |
TCSDP3 |
Concrete screwdriving bit P3 |
1 |
Flat Shank Drill Bit Set
For use with masonry fastening systems/hex sleeve drive tools. Hex drive on bit fits into driver sleeve.
Item # # of Pieces Includes |
Case Type |
Power bits: (1) P2, (1) P3; hex
TC900 9 sockets: (1) 5/16", (1) 1/4"; drill Brute bits: (1) 3/16", (1) 5/32"; (1) drive Tough™ sleeve, (1) hex key, (1) bit holder
Toll free: 877-BOSCH-99
1 AccessoriesDrill
Masonry/Concrete Drilling Hammer
1
DrillingMasonry/Concrete plus®-SDS HammersRotary
12 | 2012/2013 Power Tools & Accessories Catalog
SDS-plus® Rotary Hammers
11250VSR 3/4" SDS-plus® Bulldog™ Rotary Hammer
ff Dual-Mode Selector — Two modes of operation: rotary hammer and rotation-only mode
ff Rotating Brush Plate — Provides equal power in reverse and extends brush life
ff Integral Clutch — Helps minimize torque reaction
ff Variable-Speed Trigger with Reversing — For accurate bit starting, as well as removing fasteners or bound bits
Includes:
360˚ Auxiliary Handle 2602025072
Depth Gauge 1613001009
Carrying Case 2605438524
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V |
|
Amperage |
6.1 |
|
No Load RPM |
0–1,000 |
|
No Load BPM |
0–4,400 |
|
Impact Energy |
1.6 |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
3/4" |
|
Concrete |
|
|
Maximum |
|
|
Capacities: |
1/2" |
|
Steel |
|
|
Maximum |
1/2"–3/4" |
|
Capacities: Wood |
||
|
||
Maximum |
|
|
Capacities: |
1-1/2" |
|
Concrete-Thin |
||
|
||
Wall Core Bit |
|
|
Length |
13.25" |
|
Weight |
5.4 lbs. |
11250VSRD 3/4" SDS-plus® Bulldog™ Rotary Hammer with Dust Collection
ff Dual-Mode Selector — Two modes of
|
|
|
operation: rotary hammer and |
|
|
|
rotation-only mode |
|
|
|
ff Integral Clutch — Helps minimize |
|
|
|
torque reaction |
|
|
|
ff Dust Collection with Micro-Filter System — |
|
|
|
Dramatically reduces dust on the jobsite |
|
|
|
ff Integrated Dual-Fan System — Second set of |
|
|
||
|
|
|
fan blades with the motor creates |
|
|
|
air suction for maximum dust collection |
|
|
|
ff Easily Adjustable Dust Collection |
|
|
|
Unit — Install or remove with one hand |
|
|
|
Includes: |
Dust Collection Unit |
|
|
360˚ Auxiliary Handle 1619P06104 |
|
|
|
Dust Collection Unit |
|
|
|
Carrying Case 2605438524 |
|
|
|
Optional dust collection attachments |
|
|
|
available on pages 15 and 274. |
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
6.1 |
|
|
No Load RPM |
0–1,000 |
|
|
No Load BPM |
0–4,400 |
|
|
Impact Energy |
1.6 |
|
|
(ft.-lbs.) |
|
||
|
|
||
Maximum |
|
|
|
Capacities: |
3/4" |
|
|
Concrete |
|
|
|
Maximum |
1/2" |
|
|
Capacities: Steel |
|
||
|
|
||
Maximum |
1/2"–3/4" |
||
Capacities: Wood |
|||
|
|
||
Maximum |
|
|
|
Capacities: |
1-1/2" |
|
|
Concrete-Thin |
|
||
|
|
||
Wall Core Bit |
|
|
|
Length |
17.90" |
|
|
Weight |
7.4 lbs. |
|
|
before |
after |
Popular Mechanics |
|
|
|
|
|
Editors Choice Award |
Professional Builder
Top 100 Best New Products
DIY Network
Cool Tools — Top 25
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 13
11253VSR 1" SDS-plus® Bulldog™ Xtreme Rotary Hammer
ff Multi-Function Selector — Three modes of operation: rotary hammer, rotation-only and hammer-only mode
ff Vario-Lock™ Positioning — Rotates and locks chisel into 36 different positions to optimize working angle
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
ff Integral Clutch — Helps minimize torque reaction
Includes:
Auxiliary Handle 1612025057
Depth Gauge 1613001009
Carrying Case 2610995968
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
7.2 |
|
|
No Load RPM |
0–1,300 |
|
|
BPM Under Load |
0–5,800 |
|
|
Impact Energy |
2.2 |
|
|
(ft.-lbs.) |
|
||
|
|
||
Maximum |
|
|
|
Capacities: |
1" |
|
|
Concrete |
|
|
|
Maximum |
1/2" |
|
|
Capacities: Steel |
|
||
|
|
||
Maximum |
1"–1-1/8" |
||
Capacities: Wood |
|||
|
|
||
Maximum |
|
|
|
Capacities: |
2-5/8" |
|
|
Concrete-Thin |
|
||
|
|
||
Wall Core Bit |
|
|
|
Length |
14.75" |
|
|
Weight |
6.4 lbs. |
|
|
11255VSR 1" SDS-plus® Bulldog™ Xtreme Rotary Hammer
HammerHook™ for quick on the job storage.
ff Multi-Function Selector — Three modes of operation: rotary hammer, rotation-only and hammer-only mode
ff Vario-Lock™ Positioning—Rotates and locks chisel into 36 different positions to optimize working angle
ff SDS-plus® Bit System — Toolless bit changes with automatic bit locking, dust protection and maximum impact energy transer rate
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
Includes:
Auxiliary Handle 1612025057
Depth Gauge 1613001009
Carrying Case 2610994810
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
7.5 |
|
|
No Load RPM |
0–1,300 |
|
|
BPM Under Load |
0–5,800 |
|
|
Impact Energy |
2.2 |
|
|
(ft.-lbs.) |
|
||
|
|
||
Maximum |
|
|
|
Capacities: |
1" |
|
|
Concrete |
|
|
|
Maximum |
1/2" |
|
|
Capacities: Steel |
|
||
|
|
||
Maximum |
1"–1-1/8" |
||
Capacities: Wood |
|||
|
|
||
Maximum |
|
|
|
Capacities: |
2-5/8" |
|
|
Concrete-Thin |
|
||
|
|
||
Wall Core Bit |
|
|
|
Length |
17.25" |
|
|
Weight |
6.7 lbs. |
|
|
RH228VC 1-1/8" SDS-plus® Bulldog™ Xtreme Max Rotary Hammer
NEW |
™ |
ff 2.4 ft.-lbs. impact energy
ff Counter-Balance Vibration—Vibration reduction in the hammer mechanism for lowest vibration levels in its class
ff 8.0 Amps — Maximum power to get the job done fast
ff Integral Clutch — Helps minimize torque reaction
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
Includes:
Auxiliary Handle 1612025057
Depth Gauge 1613001009
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V |
|
Amperage |
8.0 |
|
No Load RPM |
0–1,230 |
|
No Load BPM |
0–5,460 |
|
Impact Energy |
2.4 |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
1-1/8" |
|
Concrete |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
||
|
||
Maximum |
|
|
Capacities: |
2-3/4" |
|
Concrete-Thin |
||
|
||
Wall Core Bit |
|
|
Length |
17.4" |
|
Weight |
6.9 lbs. |
Toll free: 877-BOSCH-99
1
DrillingMasonry/Concrete plus®-SDS HammersRotary
1
DrillingMasonry/Concrete plus®-SDS HammersRotary
14 | 2012/2013 Power Tools & Accessories Catalog
RH328VC 1-1/8" SDS-plus® Rotary Hammer
™
ff Vibration Control — Vibration reduction in the hammer mechanism and the grip area provides maximum user comfort for extended work; 20% less vibration (drilling) vs. item 11239VS
ff Multi-Function Selector — Three modes of operation: rotary hammer, rotation-only and hammer-only mode
ff Integral Clutch — Helps minimize torque reaction
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
Includes:
Auxiliary Handle 1612025086
Depth Gauge 1613001009
Carrying Case
Optional dust collection attachments available on pages 15 and 274.
Specifications |
|
|
Rating |
120V |
|
Amperage |
8.0 |
|
No Load RPM |
0–900 |
|
BPM Under Load |
0–4,000 |
|
Impact Energy |
2.6 |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
1-1/8" |
|
Concrete |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
||
|
||
Maximum |
1"–1-1/8" |
|
Capacities: Wood |
||
|
||
Maximum |
|
|
Capacities: |
3-1/8" |
|
Concrete-Thin |
||
|
||
Wall Core Bit |
|
|
Length |
12.5" |
|
Weight |
7.7 lbs. |
RH328VCQ 1-1/8" SDS-plus® Rotary Hammer with Quick-Change-Chuck System
™
Same features as as RH328VC above. Also includes:
Carrying Case
Quick-Change Chuck —SDS 1617000895 Quick-Change Chuck —Keyless Three Jaw
1618572000
Optional dust collection attachments available on pages 15 and 274.
Same specifications as RH328VC above.
Specifications |
|
Length |
13.6" |
Weight |
7.9 lbs. |
RH432VCQ 1-1/4" SDS-plus® Rotary Hammer with Quick-Change-Chuck System
™
ff Vibration Control—Vibration reduction in the hammer mechanism and the grip area provides maximum user comfort for extended periods of work; 50% less vibration (drilling) vs. 11236VS
ff Quick-Change Chuck System—Allows quick change-out between SDS-plus® chuck and optional three-jaw chuck for use with a wide range of accessories (three-jaw chuck not included)
ff Multi-Function Selector — Three modes of operation: rotary hammer, rotation-only and hammer-only mode
ff Integral Clutch—Helps minimize torque reaction
ff Variable-Speed Trigger with Reversing — For accurate bit starting as well as removing fasteners or bound bits
Includes:
Auxiliary Handle 1612025079
Depth Gauge 1613001008
Carrying Case
Quick Change Chuck —SDS 1617000895
Quick Change Chuck —Keyless Three-Jaw
1618572000
Optional dust collection attachments available on pages 15 and 274.
For more details visit
Boschtools.com
Specifications |
|
|
Rating |
120V |
|
Amperage |
8.5 |
|
No Load RPM |
0–760 |
|
BPM Under Load |
0–3,600 |
|
Impact Energy |
3.7 |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
1-1/4" |
|
Concrete |
|
|
Maximum |
1/2" |
|
Capacities: Steel |
||
|
||
Maximum |
|
|
Capacities: |
3-1/8" |
|
Concrete-Thin |
||
|
||
Wall Core Bit |
|
|
|
|
|
Maximum |
|
|
Capacities: |
3-1/2" |
|
Core Bit |
|
|
Length |
15.75" |
|
Weight |
10.3 lbs. |
SDS-plus® Chucks and Adapters
SDS-plus® Right-Angle Attachment
Easily drill concrete in hard-to-reach spots. Pivots through 360° ensuring correct positioning for any application.
ff For SDS-plus® rotary hammer item numbers: 11224VSR/VSRC, 11250VSR
ff Remove side handle to attach ff Tool length increases by 2-3/4"
ff Tool length is offset by less than the shank insertion depth into the bit holder
ff Impact strength is reduced by approximately 40%
Item # |
Description |
1618580000 |
Right-angle attachment |
Keyless Three-Jaw Chuck with SDS-plus® Shank
ff 1/2" capacity three-jaw chuck with SDS-plus® shank ff Keyless ratching to quickly lock bits in place
ff For use with straight shank drill bits ff Can be used in the drill-only mode
Item # |
Description |
HA3JAW |
Keyless three-jaw chuck with SDS-plus® shank |
2012/2013 Power Tools & Accessories Catalog | 15
SDS-plus® Chipping Adapter
ff For SDS-plus® rotary hammer item numbers: 11225VSR, 11225VSRH, 11250VSR
Item # |
Description |
2607018296 |
SDS-plus® chipping adapter |
Three-Jaw Chuck
with Integral SDS-plus® Shank
ff 1/2" capacity chuck with integral SDS-plus® shank
ff Use for straight shank drill bits
ff Can be used in the drill-only mode
ff For all Bosch SDS-plus® rotary hammers
Item # |
Description |
1618571014 |
Keyed three-jaw chuck with SDS-plus® shank |
1610508015 |
Replacement dust boot |
CRK005 |
Replacement chuck key |
Keyless Three-Jaw Chuck Adapter
ff For use with Bosch RH328VCQ and RH432VCQ rotary hammer
ff Can be used in the drill-only mode
Item # |
Description |
|
HA2000 |
1/2" keyless three-jaw chuck with |
|
SDS-plus® shank |
||
|
Dust Collection Fixture and Adapter
Dust Collection Fixture
ff Attaches to tool and vacuum cleaner hose to provide excellent dust collection when drilling in dust-sensitive areas, such as computer rooms and medical facilities
ff For use with bits up to 3/4" in diameter (depending on tool's bit capacity) for extracting fine dust
ff Built-in depth gauge and adjustable depth limiter
ff For use with Bosch hammer drills and SDS-plus® rotary hammers
Vacuum Dust Port Adapter
Item # |
Description |
2610014502 |
For 11250VSRD and HD19-2D |
Item # |
Description |
1618190006 |
Dust collection fixture |
1610591006 |
Replacement dust cover |
For more information on dust collection see page 270
1
AccessoriesHammer
Rotaryplus®
-SDS
DrillingMasonry/Concrete
Toll free: 877-BOSCH-99
1
AccessoriesHammer
Rotaryplus®
-SDS
DrillingMasonry/Concrete
16 | 2012/2013 Power Tools & Accessories Catalog
SDS-plus® Hammer Bits and Chisels
SDS-plus® Bulldog™ Xtreme Solid Carbide Head*
Five innovations of the
Centric active tip guides bit through concrete and provides rounder holes
Solid carbide head tip drills faster with less carbide wear. Lasts four times longer than Hilti TE-C3X in rebar**
Wear mark
assures accuracy
of hole diamter
Flute design runs cooler with fast dust removal, optimizing flute cross section reduces stress
*Less than or equal to 5/8" diameter
**Based on independent head-to-head testing of 1/4" bits performed by Räbel
4X
Longer life in rebar vs. standard SDS-plus® bit
Diffusion bonding technology provides stronger carbide bond for a longer-lasting bit
Diffusion Bonding
Carbide and steel are bonded together at a molecular level.
Hole Shapes Based On Tip Type
Y-cutter |
Two-cutter Four-cutter |
Bulldog™ |
|
|
Xtreme |
|
|
Centric |
|
|
Conical |
The new tip shape provides rounder holes for precision anchoring applications
SDS-plus® Bulldog™ Xtreme Rotary Hammer Bits
|
Item # |
Diameter |
Useable Length |
Overall Length |
Qty. |
Bulk Item # |
Bulk Qty. |
|
HCFC2010 |
3/16" |
2" |
4" |
1 |
HCFC2010B25 |
25 |
|
HCFC2011 |
3/16" |
4" |
6-1/2" |
1 |
HCFC2011B10 |
10 |
|
HCFC2011B25 |
25 |
|||||
|
|
|
|
|
|
||
|
HCFC2012 |
3/16" |
6" |
8-1/2" |
1 |
HCFC2012B25 |
25 |
|
HCFC2014 |
3/16" |
10" |
12" |
1 |
HCFC2014B25 |
25 |
|
HCFC2040 |
1/4" |
2" |
4" |
1 |
HCFC2040B25 |
25 |
|
HCFC2041 |
1/4" |
4" |
6-1/2" |
1 |
HCFC2041B10 |
10 |
|
HCFC2041B25 |
25 |
|||||
|
|
|
|
|
|
||
|
HCFC2042 |
1/4" |
6" |
8-1/2" |
1 |
HCFC2042B25 |
25 |
|
HCFC2044 |
1/4" |
10" |
12" |
1 |
HCFC2044B25 |
25 |
|
HCFC2051 |
5/16" |
4" |
6" |
1 |
HCFC2051B25 |
25 |
|
HCFC2054 |
5/16" |
10" |
12" |
1 |
HCFC2054B25 |
25 |
|
HCFC2061 |
3/8" |
4" |
6" |
1 |
HCFC2061B25 |
25 |
|
HCFC2064 |
3/8" |
10" |
12" |
1 |
HCFC2064B25 |
25 |
|
HCFC2067 |
3/8" |
16" |
18" |
1 |
— |
— |
|
HCFC2081 |
1/2" |
4" |
6" |
1 |
HCFC2081B25 |
25 |
|
HCFC2084 |
1/2" |
10" |
12" |
1 |
HCFC2084B25 |
25 |
|
HCFC2087 |
1/2" |
16" |
18" |
1 |
— |
— |
|
HCFC2102 |
5/8" |
6" |
8-1/2" |
1 |
— |
— |
|
HCFC2103 |
5/8" |
10" |
12" |
1 |
— |
— |
|
HCFC2104 |
5/8" |
16" |
18" |
1 |
— |
— |
|
HCFC2224* |
3/4" |
8" |
10" |
1 |
— |
— |
|
HCFC2227* |
3/4" |
16" |
18" |
1 |
— |
— |
|
HCFC2244* |
7/8" |
8" |
10" |
1 |
— |
— |
|
HCFC2247* |
7/8" |
16" |
18" |
1 |
— |
— |
|
HCFC2263* |
1" |
8" |
10" |
1 |
— |
— |
|
HCFC2267* |
1" |
16" |
18" |
1 |
— |
— |
|
HCFC2283* |
1-1/8" |
8" |
10" |
1 |
— |
— |
|
HCFC2287* |
1-1/8" |
16" |
18" |
1 |
— |
— |
|
*Four cutter |
|
|
|
|
|
|
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 17
SDS-plus® Bulldog™ Rotary Hammer Bits
ff 15% faster in concrete (compared to S4L)
ff Optimized brazing and hardening process for long life
|
|
Useable |
Overall |
|
|
Bulk |
|
Item # |
Diameter |
Length |
Length |
Qty. |
Bulk Item # |
Qty. |
|
HC2000 |
5/32" |
2" |
4" |
1 |
— |
— |
|
|
|
|
|
|
HC2001B5 |
5 |
|
HC2001 |
5/32" |
4" |
6" |
1 |
HC2001B10 |
10 |
|
|
|
|
|
|
HC2001B25 |
25 |
|
HC2009 |
5/32" |
6" |
8" |
1 |
— |
— |
|
HC2010 |
3/16" |
2" |
4" |
1 |
HC2010B5 |
5 |
|
HC2010B25 |
25 |
||||||
|
|
|
|
|
|||
|
|
|
|
|
HC2011B5 |
5 |
|
HC2011 |
3/16" |
4" |
6" |
1 |
HC2011B10 |
10 |
|
|
|
|
|
|
HC2011B25 |
25 |
|
HC2012 |
3/16" |
6" |
8" |
1 |
HC2012B5 |
5 |
|
HC2012B25 |
25 |
||||||
|
|
|
|
|
|||
HC2014 |
3/16" |
10" |
12" |
1 |
HC2014B5 |
5 |
|
HC2014B25 |
25 |
||||||
|
|
|
|
|
|||
HC2016 |
3/16" |
16" |
18" |
1 |
— |
— |
|
HC2031 |
7/32" |
4" |
6" |
1 |
HC2031B5 |
5 |
|
HC2031B25 |
25 |
||||||
|
|
|
|
|
|||
HC2032 |
7/32" |
6" |
8" |
1 |
— |
— |
|
HC2040 |
1/4" |
2" |
4" |
1 |
HC2040B5 |
5 |
|
HC2040B25 |
25 |
||||||
|
|
|
|
|
|||
|
|
|
|
|
HC2041B5 |
5 |
|
HC2041 |
1/4" |
4" |
6" |
1 |
HC2041B10 |
10 |
|
|
|
|
|
|
HC2041B25 |
25 |
|
HC2042 |
1/4" |
6" |
8" |
1 |
HC2042B5 |
5 |
|
HC2042B25 |
25 |
||||||
|
|
|
|
|
|||
HC2044 |
1/4" |
10" |
12" |
1 |
— |
— |
|
HC2046 |
1/4" |
16" |
18" |
1 |
— |
— |
|
HC2051 |
5/16" |
4" |
6" |
1 |
HC2051B5 |
5 |
|
HC2051B25 |
25 |
||||||
|
|
|
|
|
|||
HC2052 |
5/16" |
6" |
8" |
1 |
— |
— |
|
HC2054 |
5/16" |
10" |
12" |
1 |
— |
— |
|
HC2055 |
5/16" |
16" |
18" |
1 |
— |
— |
|
|
|
|
|
|
HC2061B5 |
5 |
|
HC2061 |
3/8" |
4" |
6" |
1 |
HC2061B10 |
10 |
|
|
|
|
|
|
HC2061B25 |
25 |
|
HC2062 |
3/8" |
6" |
8" |
1 |
— |
— |
|
HC2064 |
3/8" |
10" |
12" |
1 |
HC2064B5 |
5 |
|
HC2064B25 |
25 |
||||||
|
|
|
|
|
|||
HC2067 |
3/8" |
16" |
18" |
1 |
— |
— |
|
HC2068 |
3/8" |
22" |
24" |
1 |
— |
— |
|
HC2069 |
3/8" |
37" |
39" |
1 |
— |
— |
|
HC2073 |
7/16" |
6" |
8" |
1 |
— |
— |
|
HC2074 |
7/16" |
10" |
12" |
1 |
— |
— |
|
|
|
|
|
|
HC2081B5 |
5 |
|
HC2081 |
1/2" |
4" |
6" |
1 |
HC2081B10 |
10 |
|
|
|
|
|
|
HC2081B25 |
25 |
|
HC2083 |
1/2" |
6" |
8" |
1 |
— |
— |
|
HC2084 |
1/2" |
10" |
12" |
1 |
HC2084B5 |
5 |
|
HC2084B25 |
25 |
||||||
|
|
|
|
|
|||
HC2087 |
1/2" |
16" |
18" |
1 |
— |
— |
|
HC2088 |
1/2" |
22" |
24" |
1 |
— |
— |
|
HC2089 |
1/2" |
37" |
39" |
1 |
— |
— |
|
HC2093 |
9/16" |
6" |
8" |
1 |
— |
— |
|
HC2094 |
9/16" |
10" |
12" |
1 |
— |
— |
|
HC2097 |
9/16" |
16" |
18" |
1 |
— |
— |
ff Optimized flute design to reduce bit stress and make the bit run cooler
ff Centric tip for optimal hole geometry
|
|
Useable |
Overall |
|
|
Bulk |
|
Item # |
Diameter |
Length |
Length |
Qty. |
Bulk Item # |
Qty. |
|
HC2102 |
5/8" |
6" |
8" |
1 |
HC2102B5 |
5 |
|
HC2102B25 |
25 |
||||||
|
|
|
|
|
|||
HC2104 |
5/8" |
10" |
12" |
1 |
— |
— |
|
HC2107 |
5/8" |
16" |
18" |
1 |
— |
— |
|
HC2108 |
5/8" |
22" |
24" |
1 |
— |
— |
|
HC2122 |
3/4" |
6" |
8" |
1 |
— |
— |
|
HC2124 |
3/4" |
10" |
12" |
1 |
— |
— |
|
HC2127 |
3/4" |
16" |
18" |
1 |
— |
— |
|
HC2128 |
3/4" |
22" |
24" |
1 |
— |
— |
|
HC2147 |
7/8" |
16" |
18" |
1 |
— |
— |
|
HC2163 |
1" |
8" |
10" |
1 |
— |
— |
|
HC2167 |
1" |
16" |
18" |
1 |
— |
— |
SDS-plus® Bulldog™
Rotary Hammer Bit Sets
|
# of |
|
|
|
|
Item # |
Pieces |
Includes |
Case Type |
||
HCK001 |
|
(1) |
3/16" × 2" × 4", (1) 1/4" × 2" × 4", |
Brute |
|
7 |
(2) |
1/4" × 4" × 6", (1) 5/16" × 4" × 6", |
|||
Tough™ |
|||||
|
|
(1) |
3/8" × 4" × 6", (1) 1/2" × 4" × 6" |
||
|
|
|
|||
|
|
|
|
|
|
HCK005 |
|
(1) |
3/16" × 4" × 6", (1) 1/4" × 2" × 4", |
|
|
5 |
(1) |
1/4" × 4" × 6", (1) 3/8" × 4" × 6", |
Tube |
||
|
|
(1) |
1/2" × 4" × 6" |
|
|
|
|
|
|
||
HCST006 |
|
(1) 5/32"× 4" × 6", (1) 3/16" × 4" × 6", |
Brute |
||
6 |
(1) |
1/4" × 2" × 4", (1) 3/8" × 4" × 6", |
|||
Tough™ |
|||||
|
|
(1) flat chisel, (1) point chisel |
|||
|
|
|
|||
|
|
|
|
|
|
HCK001 |
HCK005 |
HCST006
1
AccessoriesHammer
Rotaryplus®
-SDS
DrillingMasonry/Concrete
Toll free: 877-BOSCH-99
1
AccessoriesHammer
Rotaryplus®
-SDS
DrillingMasonry/Concrete
18 | 2012/2013 Power Tools & Accessories Catalog
SDS-plus® Stop Bits
Item # |
Diameter |
Usable Length |
Anchor Diameter |
HCSTP2061 |
3/8" |
1-1/16" |
1/4" |
HCSTP2081 |
1/2" |
13/16" |
3/8" |
HCSTP2083 |
1/2" |
1-11/16" |
3/8" |
HCSTP2084 |
5/8" |
1-3/16" |
1/2" |
HCSTP2086 |
5/8" |
2-1/16" |
1/2" |
SDS-plus® Rebar Cutters
Item # |
Diameter |
Length |
Qty. |
RC2064 |
3/8" |
12" |
1 |
RC2084 |
1/2" |
12" |
1 |
RC2094 |
9/16" |
12" |
1 |
RC2104 |
5/8" |
12" |
1 |
RC2124 |
3/4" |
12” |
1 |
RC2144 |
7/8" |
12" |
1 |
RC2164 |
1" |
12" |
1 |
RC2168 |
1-1/8" |
12" |
1 |
RC2172 |
1-1/4" |
12" |
1 |
RC2176 |
1-1/2" |
12" |
1 |
*Available in straight shank — see page 11
Anchor Blow-Out Bulb
The Bosch rubber blow-out bulb is designed to clean holes before setting anchors.
ff Palm-sized rubber bulb designed for all hand sizes ff Long nozzle for deeper clean out
ff Air intake valve for high-volume air flow
Item # |
Description |
T1854 |
Anchor blow-out bulb |
Concrete Screw Anchoring System
Holds tight tolerances that are critical to precision anchoring
|
|
|
High-quality |
|
|
|
|
|
|
|
carbide tip |
SDS-plus® shank |
|
for long life |
|
Common Applications: ffConduit
ffElectrical boxes ffPipe straps
ffHVAC strapping ffSign fastening ffWindow frames ffBacker boards
SDS-plus® Bulldog™ |
SDS-plus® Bulldog™ |
Hex Drive Rotary Hammer Bits |
Hex Drive Accessory and Kit |
For use with masonry fastening |
For use with masonry fastening systems/hex sleeve drive tools. |
systems/hex sleeve drive tools. |
Hex drive on bit fits into driver sleeve. |
Hex drive on bit fits into driver sleeve. |
ff 1/4" hex shoulder for drive sleeve used to set masonry screws |
|
|
Useable |
Overall |
|
|
Bulk |
Item # |
Diameter Length |
Length |
Qty. Bulk Item # |
Qty. |
||
HC2302 |
5/32" |
4" |
7" |
1 |
HC2302B25 |
25 |
HC2312 |
3/16" |
4" |
7" |
1 |
HC2312B25 |
25 |
HC2341 |
1/4" |
4" |
6" |
1 |
HC2341B10 |
10 |
Item # Description
AD2300 Anchor drive sleeve used to set masonry screws and concrete anchors. Accepts 5/32", 3/16" and 1/4" bits
7 pc anchor drive installation kit: 5/32" × 6-1/2" and HC2309 3/16" × 6-1/2" hex bits, #2 and #3 Phillips® power bits,
5-3/4" sleeve, 1/4" and 5/16" sockets
NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM
D-tect150 Wall/Floor Scanner with Radar
The Bosch D-tect150 Wall/Floor scanner detects the material type, exact depth and relative width of objects located beneath the surface. It can even detect rebar in up to 6" of cured concrete.
See pages 290–291 for more information on the D-tect150 wall/floor scanner.
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 19
SPEEDCORE™ Thin-Wall Core Bits
Core Bit Assembly:
Screw core bit onto shank
One-piece SDS-plus® Extension |
Thin Wall Core Bit |
SDS-plus® SPEEDCORE™ Thin Wall Core Bits
Bosch SDS-plus® rotary hammer core bits are designed for drilling with smaller hammers; core body range is 1" up to 4-3/8" with a usable cutting depth of 3".
Item # |
Diameter |
|
Item # |
Diameter |
|
Item # |
Description |
||
T3910SC |
1" |
|
T3916SC |
2-11/16" |
|
|
T3922 |
3" extension straight (2 pc) |
|
T3911SC |
1-3/16" |
|
T3917SC |
3-1/8" |
|
|
T3923SC |
4" extension SDS-plus® (2 pc) |
|
T3912SC |
1-3/8" |
|
T3918SC |
3-3/16" |
|
|
T3924 |
SpeedCore™ pilot |
|
T3913SC |
1-9/16" |
|
T3919SC |
3-1/2" |
|
|
T3925SC |
7" extension SDS-plus® (1 pc) |
|
T3914SC |
1-7/8" |
|
T3920SC |
3-7/8" |
|
|
T3926SC |
13" extension SDS-plus® (1 pc) |
|
T3915SC |
2-9/16" |
|
T3921SC |
4-3/8" |
|
|
T3927SC |
17" extension SDS-plus® (1 pc) |
|
NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM
Self-Sharpening Chisels |
30% |
|
|
|
|
|||||||
|
|
|
|
|||||||||
Works longer, faster and sharper |
|
|
|
|
||||||||
|
|
|
|
|||||||||
Bracing ribs |
|
|
|
|
Higher removal rate |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|||||
|
|
|
|
vs. standard chisel |
||||||||
|
|
|
|
|||||||||
increase stability |
|
|
|
|
Flat-spade design |
|||||||
|
|
|
|
|||||||||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
creates ‘self-sharpening’ |
|||||
|
|
|
|
|
|
|
edge, eliminates downtime |
|||||
|
|
|
|
|
|
|
and increases removal rate |
|||||
Optimized length |
|
|
||||||||||
improves handling |
Double-length spade |
|||||||||||
in tight spaces |
||||||||||||
increases service life |
||||||||||||
|
|
|
||||||||||
|
|
|
|
|
Available in 1-1/2" (HS1425) and 2-1/2" (HS1427) width. |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
SDS-plus® Bulldog™ Xtreme
Hammer Steel
Bosch offers a full assortment of SDS-plus® hammer steel points and chisels.
ff HS1465 removes material up to 40% quicker than conventional tile chisels. Ideal for smaller grout joints and specially shaped for prying and removing tiles in one piece
ff HS1470 viper flat chisel and HS1472 pointed chisel provide 30% longer life and 15% more material removal
Wide |
HS1427 |
|||||||||
Tile |
HS1465 |
|||||||||
Point |
HS1472 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
Viper Flat |
HS1470 |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
Item # |
|
Description |
||||||||
HS1425 |
|
1-1/2" × 10" wide chisel (self-sharpening) |
||||||||
HS1427 |
|
2-1/2" × 10" wide chisel (self-sharpening) |
|
|||||||
HS1465 |
|
1-1/2" × 10" tile chisel |
|
|||||||
HS1470 |
|
3/4" × 10" viper flat chisel (long life) |
|
|||||||
HS1472 |
|
10" point (long life) |
|
|||||||
SDS-plus® Bulldog™
Hammer Steel
Item # |
Description |
|
HS1415 |
10" point |
|
HS1420 |
3/4" × 10" chisel |
|
HS1430 |
1/4" × 7" wood chisel |
|
HS1435 |
1/2" × 7" wood chisel |
|
HS1440 |
3/4" × 7" wood chisel |
|
HS1445 |
1" × 7" wood chisel |
|
HS1450 |
1-1/4" × 7" wood chisel |
|
HS1475 |
10" gouging chisel |
|
HS1480 |
8" carbide tipped point |
|
HS1485 |
1-1/2" × 5-3/4" stubby scaling chisel |
|
HS1490 |
5-3/4" stubby point |
|
HS1495 |
3/4" × 5-3/4" stubby flat chisel |
|
Toll free: 877-BOSCH-99
1
AccessoriesHammer
Rotaryplus®
-SDS
DrillingMasonry/Concrete
1
Hammersmax®
-SDS
DrillingMasonry/Concrete
20 | 2012/2013 Power Tools & Accessories Catalog
SDS-max® Hammers
11240 1-9/16" SDS-max® Combination Hammer
ff “Combination” Dual-Mode Selector — Two modes of operation; rotary hammer and hammer-only mode
ff Integral Clutch—Helps minimize torque reaction
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions to optimize working angle
ff Innovative Service Modules — Designed so a qualified service technician can quickly replace the brushes and cord
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438536
Optional dust collection attachments available on pages 22 and 274.
11264EVS 1-5/8" SDS-max® Combination Hammer
™
ff Vibration Control—Vibration reduction
in the hammer mechanism and grip area provide maximum user comfort
ff One-Hand™ SDS-max®—One-hand, toolless system makes changing bits easier than ever before
ff Turbo™ Power Feature — Delivers 20% more power in hammer-only mode
ff Integral Clutch — Helps minimize torque reaction
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438536
Optional dust collection attachments available on pages 22 and 274.
11263EVS 1-3/4" SDS-max® Combination Hammer
ff “Combination” Dual-Mode Selector — Two modes of operation: rotary hammer and hammer-only mode
ff Constant Response™ Circuitry — Provides soft-start, maintains constant speed under load, provides overload protection
ff Turbo™ Power Feature — Delivers 20% more power in hammer-only mode
ff Integral Clutch — Helps minimize torque reaction
Includes:
Auxiliary Handle 1612025051
Carrying Case 3605438396
Optional dust collection attachments available on pages 22 and 274.
For more details visit
Boschtools.com
Specifications |
|
|
Rating |
120V |
|
Amperage |
10 |
|
No Load RPM |
400 |
|
No Load BPM |
3,000 |
|
Impact Energy |
5.2 |
|
(ft.-lbs.) |
|
|
|
|
|
Maximum |
|
|
Capacities: |
1-9/16" |
|
Concrete |
|
|
Maximum |
|
|
Capacities: |
4" |
|
Concrete Core Bit |
|
|
Length |
17.25" |
|
Weight |
13.2 lbs. |
|
Specifications |
|
|
Rating |
120V |
|
Amperage |
13.0 |
|
No Load RPM |
170–340 |
|
No Load BPM |
1,700–2,900 |
|
Impact Energy |
6.8/8.1 (turbo) |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
1-5/8" |
|
Concrete |
|
|
Maximum |
|
|
Capacities: |
2-9/16" |
|
Concrete Thru |
||
|
||
Hole Bit |
|
|
Maximum |
|
|
Capacities: |
4-1/8" |
|
Concrete Core Bit |
|
|
Optimal Concrete |
1/2"–1-7/16" |
|
Capacity Range |
||
|
||
Length |
19.25" |
|
Weight |
14.3 lbs. |
Specifications |
|
|
Rating |
120V |
|
Amperage |
13.5 |
|
No Load RPM |
145–280 |
|
No Load BPM |
1,350–2,800 |
|
Impact Energy |
9.6/11.1 (turbo) |
|
(ft.-lbs.) |
||
|
||
Maximum |
|
|
Capacities: |
1-3/4" |
|
Concrete |
|
|
Maximum |
|
|
Capacities: |
3-1/8" |
|
Concrete Thru |
||
|
||
Hole Bit |
|
|
Maximum |
|
|
Capacities: |
6" |
|
Concrete Core Bit |
|
|
Optimal Concrete |
5/8"–1-9/16" |
|
Capacity Range |
||
|
||
Length |
21.0" |
|
Weight |
17.9 lbs. |
2012/2013 Power Tools & Accessories Catalog | 21
11245EVS 2" SDS-max® Combination Hammer
ff “Combination” Dual-Mode Selector— Two modes of operation: rotary hammer and hammer-only mode
ff Constant Response™ Circuitry — Provides soft-start, maintains constant speed under load, provides overload protection
ff Integral Clutch — Helps minimize torque reaction
ff Service Minder™ Light — Indicates when preventative maintenance is required
Includes:
Auxiliary Handle 1612025043
Carrying Case 2605438322
Optional dust collection attachments available on pages 22 and 274.
Specifications |
|
|
Rating |
120V |
|
Amperage |
14.0 |
|
No Load RPM |
120–250 |
|
No Load BPM |
1,100–2,500 |
|
Impact Energy |
13.3 |
|
(ft.-lbs.) |
|
|
|
|
|
Maximum |
|
|
Capacities: |
2" |
|
Concrete |
|
|
Maximum |
|
|
Capacities: |
3-1/8" |
|
Concrete Thru |
|
|
|
|
|
Hole Bit |
|
|
Maximum |
|
|
Capacities: |
6" |
|
Concrete Core Bit |
|
|
Optimal Concrete |
3/4"-1-3/4" |
|
Capacity Range |
|
|
|
|
|
Length |
23.5" |
|
Weight |
24.5 lbs. |
|
11388 SDS-max® Demolition Hammer
ff Vario-Lock™ Positioning—Rotates and locks chisel into 12 different positions to optimize working angle
ff 360˚ Auxiliary Handle — Provides a wide range of movement along with operator comfort
ff Innovative Service Modules—Designed for quick brush and cord replacement by qualified technician
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438534
Optional dust collection attachments available on pages 22 and 274.
11321EVS SDS-max® Demolition Hammer
™
Specifications |
|
|
Rating |
120V |
|
Amperage |
10.0 |
|
No Load BPM |
2,800 |
|
Impact Energy |
5.9 |
|
(ft.-lbs.) |
|
|
|
|
|
Length |
17.5" |
|
Weight |
11.6 lbs. |
|
ff Vibration Control — Vibration reduction in the hammer mechanism and grip area provide maximum user comfort for extended periods of work
ff Constant Response™ Circuitry — Provides soft-start, maintains constant speed under load, provides overload protection
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions to optimize working angle
ff Auto-Max™ Variable-Speed Dial — Designed to automatically ensure maximum speed and power every time the tool is plugged in
Includes:
Auxiliary Handle 1612025061
Carrying Case
Optional dust collection attachments available on pages 22 and 274.
Specifications |
|
|
Rating |
120V |
|
Amperage |
13.0 |
|
No Load BPM |
1,300-2,900 |
|
Impact Energy |
9.6 |
|
(ft.-lbs.) |
|
|
|
|
|
Length |
18.6" |
|
Weight |
12.8 lbs. |
|
Toll free: 877-BOSCH-99
1
Hammersmax®
-SDS
DrillingMasonry/Concrete
1 Accessoriesand
DrillingMasonry/Concrete -SDS Hammersmax®
22 | 2012/2013 Power Tools & Accessories Catalog
11316EVS SDS-max® Demolition Hammer
ff Variable-Speed Dial — For controlled chipping applications
ff Constant Response™ Circuitry — Provides soft-start, maintains constant speed under load, provides overload protection
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions to optimize working angle
ff Service Minder™ Light — Indicates when preventative maintenance is required
Includes:
Auxiliary Handle 2602025076
Carrying Case 2605438297
Optional dust collection attachments available on pages 22 and 274.
SDS-max® Adapters
SDS-max® Rotary Hammer Adapters
Bosch offers adapters to make it easy to move up to SDS-max® while still utilizing your current SDS-plus® and Spline accessories.
Item # |
Description |
|
HA1030 |
SDS-max® to SDS-plus® adapter |
|
HA1031 |
SDS-max® to Spline adapter |
|
HA1032 |
SDS-max® to 3/4" hex adapter |
|
Specifications |
|
|
Rating |
120V |
|
Amperage |
14.0 |
|
No Load BPM |
900-1,890 |
|
Impact Energy |
4.4-18.4 |
|
(ft.-lbs.) |
|
|
|
|
|
Length |
22.5" |
|
Weight |
22.5 lbs. |
|
Dust Collection Attachments and Fixture
Dust Collection Attachments
For use with Bosch SDS-max® and Spline hammers.
Item # |
Description |
|
HDC-C1 |
Chipping attachment |
|
HDC-D1 |
Chipping and drilling attachment |
|
For more information on dust collection see page 270
Dust Extraction Fixture
ff Attaches to tool and vacuum cleaner hose to provide excellent dust collection when drilling in dust-sensitive areas, such as computer rooms and medical facilities
ff For use with bits up to 1-9/16" in diameter (depending on tool's bit capacity) for extracting fine dust, wood or metal drilling debris
ff Built-in depth gauge and
adjustable depth limiter ff Includes dust cover
1615502004 |
|
Item # |
Description |
1618190009 |
Dust extraction fixture |
1610502004 |
Replacement dust cover |
GRL400H Self-Leveling Rotary Laser
For fast, fully automatic exterior self-leveling. The durable Bosch GRL400H rotary laser makes leveling of concrete extremely easy and accurate.
See page 308 for more information on the GRL400H Self-Leveling Rotary Laser.
For more details visit
Boschtools.com
2012/2013 Power Tools & Accessories Catalog | 23
SDS-max® Hammer Bits and Chisels
Wear Mark Indicator |
ffAssures accuracy |
of hole diameter |
Highest Drilling Speed
ffInclined side cutters provide fast concrete drilling
Compact Head
ffFor fast dust removal and longer life
Active Centering Tip
ffProvides quick accurate starts
SDS-max® SpeedX™ Rotary Hammer Bits
Bosch carbide rotary hammer bits feature tips that stay sharper longer and deliver more holes within specification than competitors’ bits.
ff Manufactured to ANSI specification B212.14
ff SDS-max® rotary hammer bits fit Bosch SDS-max® hammers, but also competitive SDS-max® drive hammers and Hilti® hammers using TE-Y and TE-FY shanks
Item # |
Diameter |
Usable Length |
Overall Length |
HC5005† |
3/8" |
8" |
13" |
HC5010† |
1/2" |
8" |
13" |
HC5011† |
1/2" |
16" |
21" |
HC5013† |
1/2" |
24" |
29" |
HC5015† |
9/16" |
8" |
13" |
HC5016† |
9/16" |
16" |
21" |
HC5017† |
9/16" |
24" |
29" |
HC5020 |
5/8" |
8" |
13" |
HC5021 |
5/8" |
16" |
21" |
HC5024 |
5/8" |
24" |
29" |
HC5023 |
5/8" |
31" |
36" |
HC5026 |
11/16" |
16" |
21" |
HC5030 |
3/4" |
8" |
13" |
HC5031 |
3/4" |
16" |
21" |
HC5034 |
3/4" |
24" |
29" |
HC5033 |
3/4" |
31" |
36" |
HC5036 |
13/16" |
16" |
21" |
HC5040 |
7/8" |
8" |
13" |
HC5041 |
7/8" |
16" |
21" |
HC5044 |
7/8" |
24" |
29" |
HC5043 |
7/8" |
31" |
36" |
†Two cutter
Unrivaled Destructive Power
ffSolid carbide with robust S-cutter design for added speed and life
Item # |
Diameter |
Usable Length |
Overall Length |
HC5050 |
1" |
8" |
13" |
HC5051 |
1" |
16" |
21" |
HC5054 |
1" |
24" |
29" |
HC5053 |
1" |
31" |
36" |
HC5060 |
1-1/8" |
8" |
13" |
HC5061 |
1-1/8" |
16" |
21" |
HC5062 |
1-1/8" |
24" |
29" |
HC5063 |
1-1/8" |
31" |
36" |
HC5070 |
1-1/4" |
8" |
13" |
HC5071 |
1-1/4" |
16" |
21" |
HC5072 |
1-1/4" |
24" |
29" |
HC5073 |
1-1/4" |
31" |
36" |
HC5081 |
1-3/8" |
16" |
21" |
HC5082 |
1-3/8" |
24" |
29" |
HC5083 |
1-3/8" |
31" |
36" |
HC5091 |
1-1/2" |
16" |
21" |
HC5092 |
1-1/2" |
24" |
29" |
HC5093 |
1-1/2" |
31" |
36" |
HC5098 |
1-3/4" |
16" |
21" |
HC5099 |
2" |
16" |
21" |
Toll free: 877-BOSCH-99
1
DrillingMasonry/Concrete max®-SDS AccessoriesHammer
1
DrillingMasonry/Concrete max®-SDS AccessoriesHammer
24 | 2012/2013 Power Tools & Accessories Catalog
Thru-Hole Bit
Drill all the way through without stopping
Aggressive tip provides fast break-through and large chip removal
SDS-max® Thru-Hole
Rotary Hammer Bits
One-piece, thru-hole bits are designed for fast work without the need to change shanks. The all-in-one core with SDS-max® shank transmits power directly to the end of the bit. Additionally, thruhole bits are more economical due to their long life.
Item # |
Diameter |
Usable Length |
Overall Length |
HC6501 |
1-3/4" |
18" |
24" |
HC6511 |
2-1/8" |
18" |
24" |
HC6521 |
2-1/2" |
18" |
24" |
HC6531 |
3-1/8" |
18" |
24" |
NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM
Core Bits with Wave Design
Larger, cleaner holes up to 6" in diameter
Carbide- |
|
|
|
|
Asymmetrical |
||
|
|||
tipped |
|
carbide teeth |
|
centering bit |
|
for faster |
|
Item# HC88 |
|
cutting, longer life |
|
|
|
|
|
All-in-one core |
Wave design |
transmits |
transfers energy |
power directly |
to bit more |
to the end |
effectively for |
of the bit |
up to 40% faster |
|
drilling vs. |
|
previous design |
SDS-max® Core Bit Extensions
Item # |
Diameter |
CAM008 |
8" |
CAM018 |
18" |
For more details visit
Boschtools.com
SDS-max® Rotary Hammer Core Bits (1 pc)
Bosch SDS-max® carbide-tipped rotary hammer core bits offer an integral shank for better power transmission. Maximum core size
|
HCRR001 |
|
|
|
Item # |
Diameter |
Usable Length |
Overall Length |
|
HC8501 |
1-3/4" |
7" |
12" |
|
HC8506 |
1-3/4" |
17" |
22" |
|
HC8510 |
2" |
7" |
12" |
|
HC8515 |
2" |
17" |
22" |
|
HC8516 |
2-1/4" |
7" |
12" |
|
HC8517 |
2-1/4" |
17" |
22" |
|
HC8521 |
2-5/8" |
7" |
12" |
|
HC8526 |
2-5/8" |
17" |
22" |
|
HC8531 |
3-1/4" |
7" |
12" |
|
HC8536 |
3-1/4" |
17" |
22" |
|
HC8540 |
3-9/16" |
7" |
12" |
|
HC8545 |
3-9/16" |
17" |
22" |
|
HC8550 |
4" |
7" |
12" |
|
HC8555 |
4" |
17" |
22" |
|
HC8570 |
5" |
7" |
12" |
|
HC8575 |
5" |
17" |
22" |
|
HC8580 |
6" |
7" |
12" |
|
HC8595 |
6" |
17" |
22" |
|
HC88 |
— |
— |
5-5/16" |
|
centering bit |
||||
|
|
|
||
HCRR001 |
— |
— |
— |
|
rubber ring |
||||
and pin |
|
|
|
NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM
Rotary Hammer Core Bits (2 pc)
Item # |
Diameter |
|
Item # |
Diameter |
HC7501 |
1-3/4" |
|
HC7505 |
3-1/2" |
HC7502 |
2" |
|
HC7506 |
4" |
HC7503 |
2-1/2" |
|
HC7507 |
5" |
HC7504 |
3" |
|
HC7508 |
6" |
NOTE: Interchangable core bits work with SDS-max® or Spline adapters
2012/2013 Power Tools & Accessories Catalog | 25
SDS-max® R-Tec
The R-Tec Advantage
Bosch R-Tec technology for SDS-max® chisels use an energy diverting reflection element that increases material removal by 15%. Because the energy is dispersed back into the work material, the tool and bit do more of the work with less vibra-
tion for the user. And the R-Tec chisel features a unique cutting head with extra wedges for increased breakout. Bosch SDS-max® R-Tec chisels and points produce faster results in less time and help increase overall jobsite productivity and profitability.
The reflection element diverts the energy of the return shock and converts it into new impact energy.
R-Tec Chisel |
Conventional |
|
Chisel |
|
|
SDS-max® Hammer Steel
Bosch offers a full assortment of SDS-max® hammer steel points and chisels.
15%
Higher Removal Rate vs. Standard Chisel
Star-point twist tip
is self sharpening and less binding
Innovative reflection element increases material removal rate by up to 15%
Asphalt Cutter |
|
Bull Point |
Bushing Tool |
Clay Spade |
Flat Chisel |
|
Floor Scraper |
||
|
|
|
One Piece |
|
|
|
|
|
|
Ground Rod Driver |
Gouge |
Round Spade |
Scaling Chisel |
Scraping Chisel |
Seam Tool |
||||
Slotting Tool |
|
Tamper Plate Shank |
Tamper Plate |
Tile Chisel |
Winged Channel Chisel |
Carbide Bushing Tool |
|||
Item # |
Description |
Size |
|
Qty. |
Bulk Item # |
Bulk Qty. |
|||
HS1935 |
R-Tec flat chisel self-sharpening |
1" × 16" |
|
1 |
— |
|
— |
|
|
HS1936 |
R-Tec star point chisel twist |
16" |
|
1 |
— |
|
— |
||
self-sharpening, no jam |
|
|
|||||||
|
|
|
|
|
|
|
|
||
HS1906 |
Aspalt cutter |
5" × 15" |
|
1 |
— |
|
— |
|
|
HS1909 |
Bushing tool, one piece |
16 tooth head, 1-3/4" square × 9-1/4" |
1 |
— |
|
— |
|
||
HS1910 |
Scaling chisel |
3" × 12" |
|
1 |
— |
|
— |
|
|
HS1916 |
Scaling chisel |
1-1/2" × 12" |
|
1 |
— |
|
— |
|
|
HS1917 |
Scaling chisel self-sharpening |
2" × 14" |
|
1 |
— |
|
— |
|
|
HS1911 |
Flat chisel |
1" × 12" |
|
1 |
HS1911B20 |
20 |
|
||
|
HS1911B25 |
25 |
|
||||||
|
|
|
|
|
|
|
|||
HS1912 |
Flat chisel |
1" × 18" |
|
1 |
HS1912B10 |
10 |
|
||
|
HS1912B25 |
25 |
|
||||||
|
|
|
|
|
|
|
|||
HS1913 |
Bull point |
|
12" |
|
1 |
HS1913B20 |
20 |
|
|
|
|
HS1913B25 |
25 |
|
|||||
|
|
|
|
|
|
|
|||
HS1914 |
Bull point |
|
18" |
|
1 |
HS1914B10 |
10 |
|
|
|
|
HS1914B25 |
25 |
|
|||||
|
|
|
|
|
|
|
|||
HS1915 |
Tile chisel |
2" × 12" |
|
1 |
— |
|
— |
|
|
HS1918 |
Floor scraper |
6" × 25" |
|
1 |
— |
|
— |
|
|
HS1920 |
Seam tool |
1-1/8" × 15" |
|
1 |
— |
|
— |
|
|
HS1921 |
Slotting tool |
1-1/8" × 15" |
|
1 |
— |
|
— |
|
|
HS1922 |
Clay spade |
4-1/2" × 17" |
|
1 |
— |
|
— |
|
|
HS1924 |
Ground rod driver |
5/8" and 3/4" rods |
|
1 |
— |
|
— |
|
|
HS1926 |
Round spade |
5-3/8" × 16" |
|
1 |
— |
|
— |
|
|
HS1927 |
Tamper plate shank |
12" |
|
1 |
— |
|
— |
|
|
HS1828 |
Tamper plate |
5" × 5" |
|
1 |
— |
|
— |
|
|
HS1928 |
Winged channel chisel |
1" × 15" |
|
1 |
— |
|
— |
|
|
HS1929 |
Gouge |
|
1" × 12" |
|
1 |
— |
|
— |
|
HS1969 |
Carbide bushing tool |
25 tooth head (carbide), 2" × 2" square |
1 |
— |
|
— |
|
||
Toll free: 877-BOSCH-99
1
DrillingMasonry/Concrete max®-SDS AccessoriesHammer
1 HammersHex
Masonry/Concrete Drilling Spline/Round
26 | 2012/2013 Power Tools & Accessories Catalog
Spline/Round Hex Hammers
11247 1-9/16" Spline Combination Hammer
ff “Combination” Dual-Mode Selector — Two modes of operation: rotary hammer and hammer-only mode
ff Integral Clutch — Helps minimize torque reaction
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions to optimize working angle
ff Innovative Service Modules — Designed so a qualified service technician can quickly replace the brushes and cord
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438536
Optional dust collection attachments available on pages 22 and 274.
11265EVS 1-5/8" Spline Combination Hammer
™
ff Vibration Control — Vibration reduction in the hammer mechanism and the grip area provides maximum user comfort for extended periods of work
ff Turbo™ Power Feature — Delivers 20% more power in hammer-only mode
ff Integral Clutch — Helps minimize torque reaction
ff Auto-Max™ Variable Speed Dial — Designed to automatically ensure the maximum speed and power every time the tool is plugged in
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438536
Optional dust collection attachments available on pages 22 and 274.
11387 3/4" Round Hex Demolition Hammer
ff Vario-Lock™ Positioning — Rotates and locks chisel into 12 different positions to optimize working angle
ff 360° Auxiliary Handle — Provides a wide range of movement along with operator comfort
ff Innovative Service Modules — Designed for quick brush and cord replacement by qualified technician
Includes:
Auxiliary Handle 1612025055
Carrying Case 3605438534
Optional dust collection attachments available on pages 22 and 274.
For more details visit
Boschtools.com
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
10.0 |
|
|
No Load RPM |
400 |
|
|
No Load BPM |
3,000 |
|
|
Impact Energy |
5.2 |
|
|
(ft.-lbs.) |
|
||
|
|
||
Maximum |
|
|
|
Capacities: |
1-9/16" |
|
|
Concrete |
|
|
|
Maximum |
|
|
|
Capacities: |
2-1/2" |
|
|
Concrete-Thru |
|
||
|
|
||
Hole Bit |
|
|
|
Maximum |
|
|
|
Capacities: |
4" |
|
|
Concrete-Core Bit |
|
|
|
Optimal Concrete |
1/2"–1-3/8" |
||
Capacity Range |
|||
|
|
||
Length |
17.25" |
|
|
Weight |
13.6 lbs. |
|
|
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
13.0 |
|
|
No Load RPM |
170–340 |
|
|
No Load BPM |
1,700–2,900 |
|
|
Impact Energy |
6.8/8.1 (turbo) |
||
(ft.-lbs.) |
|||
|
|
||
Maximum |
|
|
|
Capacities: |
1-5/8" |
|
|
Concrete |
|
|
|
Maximum |
|
|
|
Capacities: |
2-9/16" |
|
|
Concrete-Thru |
|
||
|
|
||
Hole Bit |
|
|
|
Maximum |
|
|
|
Capacities: |
4-1/8" |
|
|
Concrete-Core Bit |
|
|
|
Optimal Concrete |
1/2"–1-7/16" |
||
Capacity Range |
|||
|
|
||
Length |
19.25" |
|
|
Weight |
14.7 lbs. |
|
|
Specifications |
|
|
Rating |
120V |
|
Amperage |
10.0 |
|
No Load BPM |
2,800 |
|
Impact Energy |
5.9 |
|
(ft.-lbs.) |
||
|
||
Length |
17.5" |
|
Weight |
12.0 lbs. |
2012/2013 Power Tools & Accessories Catalog | 27
11317EVS 3/4" Round Hex Demolition Hammer
ff Constant Response™ Circuitry — Provides soft-start, maintains constant speed under load, provides overload protection
ff Variable Speed Dial — For controlled chipping applications
ff Service Minder™ Light — Indicates when preventative maintenance is required
Includes:
Auxiliary Handle 2602025079
Carrying Case 2605438297
Specifications |
|
|
|
Rating |
120V |
||
Amperage |
12.8 |
|
|
No Load BPM |
900–1,890 |
|
|
Impact Energy |
4.0–16.5 |
||
(ft.-lbs.) |
|||
|
|
||
Length |
22.0" |
|
|
Weight |
22.0 lbs. |
|
|
Spline Adapters
Spline Rotary Hammer Adapters |
|
|
|
Item # |
Description |
||
Use these Bosch adapters with a |
|
1618598151 |
Spline shank to SDS-max® adapter |
|
HA1020 |
Spline drive to SDS-plus® adapter |
|
Spline hammer to utilize B taper |
|
||
|
1601030009 |
Drift pin (for T1831) |
|
and SDS-plus® accessories. |
|
||
|
|
|
|
Spline Hammer Carbide and Round Hex Hammer Steel
Spline SpeedX™ Rotary Hammer Bits
Bosch spline rotary hammer bits are carbide tipped, fit Bosch and other Spline hammers.
Item # |
Diameter |
Usable Length |
Overall Length |
HC4501† |
3/8" |
8" |
13" |
HC4511† |
1/2" |
8" |
13" |
HC4512† |
1/2" |
16" |
21" |
HC4513† |
1/2" |
24" |
29" |
HC4516† |
9/16" |
16" |
21" |
HC4021 |
5/8" |
8" |
13" |
HC4022 |
5/8" |
16" |
21" |
HC4023 |
5/8" |
24" |
29" |
HC4024 |
5/8" |
31" |
36" |
HC4031 |
3/4" |
8" |
13" |
HC4032 |
3/4" |
16" |
21" |
HC4033 |
3/4" |
24" |
29" |
HC4034 |
3/4" |
31" |
36" |
HC4040 |
7/8" |
8" |
13" |
HC4041 |
7/8" |
16" |
21" |
HC4042 |
7/8" |
24" |
29" |
HC4043 |
7/8" |
31" |
36" |
HC4050 |
1" |
8" |
13" |
†Two cutter |
|
|
|
Item # |
Diameter |
Usable Length |
Overall Length |
HC4051 |
1" |
16" |
21" |
HC4052 |
1" |
24" |
29" |
HC4053 |
1" |
31" |
36" |
HC4060 |
1-1/8" |
8" |
13" |
HC4061 |
1-1/8" |
16" |
21" |
HC4062 |
1-1/8" |
24" |
29" |
HC4063 |
1-1/8" |
31" |
36" |
HC4070 |
1-1/4" |
8" |
13" |
HC4071 |
1-1/4" |
16" |
21" |
HC4072 |
1-1/4" |
24" |
29" |
HC4073 |
1-1/4" |
31" |
36" |
HC4081 |
1-3/8" |
16" |
21" |
HC4082 |
1-3/8" |
24" |
29" |
HC4083 |
1-3/8" |
31" |
36" |
HC4091 |
1-1/2" |
16" |
21" |
HC4092 |
1-1/2" |
24" |
29" |
HC4093 |
1-1/2" |
31" |
36" |
1 Accessoriesand HammersHex
Masonry/Concrete Drilling Spline/Round
Toll free: 877-BOSCH-99
1 AccessoriesHammer
DrillingMasonry/Concrete HexSpline/Round
28 | 2012/2013 Power Tools & Accessories Catalog
Spline Rotary Hammer Core Bits with Wave Design (1 pc)
|
|
Usable |
Overall |
Item # |
Diameter |
Length |
Length |
HC8001 |
1-3/4" |
7" |
12" |
HC8006 |
1-3/4" |
17" |
22" |
HC8010 |
2" |
7" |
12" |
HC8015 |
2" |
17" |
22" |
HC8016 |
2-1/4" |
7" |
12" |
HC8017 |
2-1/4" |
12" |
22" |
HC8021 |
2-5/8" |
7" |
12" |
HC8026 |
2-5/8" |
17" |
22" |
HC8031 |
3-1/4" |
7" |
12" |
HC8036 |
3-1/4" |
12" |
22" |
HC8040 |
3-9/16" |
7" |
12" |
HC8045 |
3-9/16" |
17" |
22" |
|
|
Usable |
Overall |
|
Item # |
Diameter |
Length |
Length |
|
HC8050 |
4" |
7" |
12" |
|
HC8055 |
4" |
17" |
22" |
|
HC8070 |
5" |
7" |
12" |
|
HC8075 |
5" |
17" |
22" |
|
HC8080 |
6" |
7" |
22" |
|
HC8085 |
6" |
17" |
22" |
|
HC88 |
— |
— |
5-5/16" |
|
centering bit |
||||
|
|
|
||
HCRR001 |
|
|
|
|
rubber ring |
— |
— |
— |
|
and pin |
|
|
|
Round Hex/Spline Hammer Steel
Bosch offers a full assortment of Round Hex / Spline hammer steel points and chisels.
Spline Core Bit
Extensions
Item # |
Diameter |
CAS008 |
8" |
CAS018 |
18" |
NOTE: For interchangable 2 pc core bits see page 24
Scaling Chisel |
Pointed Spade |
Tamper Plate Shank |
Seam Tool |
|
|
|
|
|
|
|
|
|
Tamper Plate |
|
|
Flat Chisel |
|
Bushing Head Shank |
Bull Point |
|
|
|
|
Scraping Chisel |
Slotting Tool |
Ground Rod Driver |
One Piece |
|
Bushing Head |
Carbide Bushing Tool |
|
|
|
|
|
|
|
|
|
Item # |
Description |
Size |
|
Qty. |
Bulk Item # |
Bulk Qty. |
|
HS1809 |
Bushing tool one piece |
16 tooth head, 1-3/4" square × 9-1/4" |
1 |
HS1809B10 |
10 |
||
HS1810 |
Scaling chisel |
3" × 12" |
|
1 |
HS1810B10 |
10 |
|
HS1811 |
Flat chisel |
1" × 12" |
|
1 |
HS1811B20 |
20 |
|
HS1812 |
Flat chisel |
1" × 18" |
|
1 |
HS1812B10 |
10 |
|
HS1813 |
Bull point |
12" |
|
1 |
HS1813B20 |
20 |
|
HS1814 |
Bull point |
18" |
|
1 |
HS1814B10 |
10 |
|
HS1815 |
Scraping chisel |
2" × 12" |
|
1 |
— |
|
— |
HS1816 |
Scaling chisel |
1-1/2" × 12" |
|
1 |
— |
|
— |
HS1817 |
Scaling chisel |
2" × 12" |
|
1 |
HS1817B10 |
10 |
|
HS1521 |
Bushing head |
16 tooth head, 1-3/4" square |
1 |
— |
|
— |
|
HS1818 |
Bushing head shank |
12" |
|
1 |
— |
|
— |
HS1820 |
Seam tool |
1-1/8" × 15" |
|
1 |
— |
|
— |
HS1821 |
Slotting tool |
1-1/8" × 15" |
|
1 |
— |
|
— |
HS1822 |
Clay spade |
4-1/2" × 16" |
|
1 |
HS1822B3 |
3 |
|
HS1824 |
Ground rod driver |
5/8" and 3/4" rods |
|
1 |
— |
|
— |
HS1826 |
Pointed spade |
4-1/2" × 16" |
|
1 |
— |
|
— |
HS1827 |
Tamper plate shank |
12" |
|
1 |
— |
|
— |
HS1828 |
Tamper plate |
5" × 5" |
|
1 |
— |
|
— |
HS1969 |
Carbide bushing tool |
25 tooth head (carbide), 2" × 2" square |
1 |
— |
|
— |
|
World of Concrete 2011
Editor’s Choice
For more details visit
Boschtools.com
Loading...
