Bosch PGH6B5B60, PGP6B5B60, PGH6B5B90, PGP6B2B90R, PGP6B5B85 Instructions for Use

...
3FHJTUFS
QHZGHYLFHRQ
0\%RVFKQRZDQG JHWIUHHEHQHILWV
CPTDIIPNFDPN
XFMDPNF
\RXU
PGC6B....., PGH6B....., PGP6B....., PGQ7B....., PGS7B.....
[en] Instruction manual Gas hob
3*&%
3*4%
2
3*+%
2
3*3%
1
1
3*6%
2
2
1
1
1
2
! Pan supports " Control knobs # Economy burner with an output of up to 1 kW
$ Standard-output burner with an output of up to 1.75 kW % High-output burner with an output of up to 3 kW & Mini wok burner up to 3.3 kW
2
Table of contents
[en]I n st r u ct i on manual Gas hob
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
en
8Intended use
( Important safety information . . . . . . . . . . . . . . . 4
* Getting to know your appliance . . . . . . . . . . . . . 5
Controls and burners . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ä Gas burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Switching on manually . . . . . . . . . . . . . . . . . . . . . . . . . 6
Automatic ignition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Switching off a burner . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cooking guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Å Cooking pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Suitable pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Instructions for use. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Cleaning and maintenance . . . . . . . . . . . . . . . . . 8
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . 8
I nt ended use
Read these instructions carefully. You will only be able to use your appliance safely and effectively when you have read them. These operating and installation instructions should be retained, and passed onto the buyer if the appliance is sold.
The manufacturer is exempt from all responsibility if the requirements of this manual are not complied with.
The images shown in these instructions are for guidance only.
Do not remove the appliance from its protective packaging until it is installed in the unit. Do not switch on the appliance if it is damaged in any way. Contact our Technical Assistance Service.
This appliance is class 3 type, according to the EN 30-1-1 regulation for gas appliances: built-in appliance.
Before installing your new hob, ensure that it is being installed according to the installation instructions.
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7 Environmental protection . . . . . . . . . . . . . . . . . . 9
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 9
Produktinfo
Additional information on products, accessories, replacement parts and services can be found at
www.bosch-home.com and in the online shop www.bosch-eshop.com
This appliance cannot be installed on yachts or in caravans.
This appliance must only be used in well ventilated places.
This appliance is not intended for operation with an external clock timer or a remote control.
All operations relating to installation, connection, regulation and conversion to other gas types must be performed by an authorised technician, respecting all applicable regulations, standards and the specifications of the local gas and electricity suppliers. Special attention shall be paid to ventilation regulations.
This appliance leaves the factory set to the gas type that is indicated on the specifications plate. If this needs to be changed, please consult the assembly instructions. It is recommended you contact the Technical Assistance Service to change to another gas type.
This appliance has been designed for home use only, not for commercial or professional use. This appliance is only intended for
3
en Important safety information
cooking purposes, not as a heating system. The warranty will only be valid if the appliance is used for the purpose for which it was designed.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
Do not use lids or hob guards for children which are not recommended by the hob manufacturer. They may cause accidents such as those due to the overheating, ignition or detachment of fragments of materials.
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsible for their safety how to use the appliance safely and have understood the associated hazards.
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 15 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
(Important safety
information
Impor t ant saf et y i nf or mati on
:Warning – Risk of deflagration!
Accumulation of unburned gas in an enclosed area carries a risk of deflagration. Do not subject the appliance to draughts. These might blow out the burners. Carefully read the instructions and warnings on the operation of gas burners.
:Warning – Risk of poisoning!
The kitchen will become hot and humid and combustion products produced when this gas appliance is used. Make sure the kitchen is well ventilated, particularly when the hob is in operation: either keep the natural ventilation apertures open, or install a ventilation system (extractor hood). Intense prolonged use of the appliance may require additional or more effective ventilation: open a window or increase the power of the ventilation system.
:Warning – Risk of burns!
The burners and their immediate vicinity get
very hot. Never touch the hot surfaces. Keep children under 8 years old well away from this appliance.
Risk of burns!
If the liquefied gas bottle is not upright,
liquefied propane/butane can enter the appliance. Intense darting flames may therefore escape from the burners. Components may become damaged and start to leak over time so that gas escapes uncontrollably. Both can cause burns. Always use liquefied gas bottles in an upright position.
:Warning – Risk of fire!
The cooking process must be supervised. A
short cooking process must be supervised without interruption.
Risk of fire!
The burners get very hot. Do not rest
inflammable objects on the hob. Do not store objects on the hob.
Risk of fire!
Do not store or use corrosive chemicals,
products which produce fumes, inflammable materials or non-food products below or near this domestic appliance.
Risk of fire!
Fat or oil which is overheated can catch fire
easily. Never leave fat or oil to heat up unattended. If oil or fats do catch fire, never use water to put the fire out. Put the fire out by covering the pan with a lid and switch off the hotplate.
4
