Page 1
LED Keypads D720 Series
User’s Guide
D720W
D720B
D720
Page 2
Table of Contents
Fire Safety 3
The D720/D720W/D720B Keypad 4
Security System Basics 5
Turning the System On and Off 7
Silencing and Reporting Alarms 8
Keypad Tones 9
System Commands 10
Security System Glossary 30
Security System Limitations 31
2
Page 3
Fire Safety
Residential fire is a leading cause of accidental death. Most fire related deaths
occur at night when the occupants suffocate in their sleep from smoke and deadly
gases, rather than from burns. To help reduce this risk, implement the following
three-step program:
1. Minimize fire hazards around the home. Smoking in bed,
cleaning with flammable liquids such as gasoline, leaving
children home alone, and unsafe holiday decorations are some of
the more common causes of household fire.
2. Install a fire warning system. The primary purpose of this system
is to protect lives, not property, by giving the earliest possible
warning of the danger. In the event of a fire, the alarm system
generates a loud intermittent tone distinctly different than a
burglar alarm.
In homes with more than one sleeping area a smoke detector
(indicated by an inverted “s” in a circle) should be provided to
detect smoke in each area.
3. Plan and practice an escape plan. A fire alarm warning is wasted
unless the family has planned for a quick evacuation. Because
there is very little time between detection of a fire and the time it
becomes deadly, it is important that every member of the family
understand exactly what to do.
Possible escape routes through open windows marked with arrows.
Primary and alternate escape routes should be established. Since stairwells and
hallways can be blocked during a fire, exiting through a bedroom window at
night should be an essential part of the escape plan. If the sleeping area is above
the ground floor, provide a means of safe descent outside the building if one does
not already exist.
All family members should plan to meet at a predetermined location away from
the house (such as a neighbor’s), to verify that all are accounted for.
In Case of Fire
1. The primary purpose of a fire warning system is to protect lives.
In the event of a fire alarm, quickly leave the building and call
the fire department from a neighbor’s or public telephone.
2. If it is determined the alarm was accidentally tripped, the bell
should be silenced, the detectors reset, and your alarm company
notified immediately of the situation.
3
Page 4
Introduction
Your security system helps to secure life, property, and investments against fire,
theft, and bodily harm. The keypad is an arming station that offers a variety of
features. Function, versatility, and ease of operation make the keypad the ideal
system for the home or office.
With custom programming, the keypad is tailored to meet your individual needs.
The Command mode allows you to perform a variety of functions with maximum
simplicity - only the touch of two or three keys is required to control almost
every feature on the keypad. Three function keys allow common commands to be
performed with the touch of just one key.
The keypad puts the control of your security system right at your fingertips.
Maintenance and Service
The keypad requires very little maintenance; however, the system should be
tested weekly to detect serv ice needs early. A test schedule and maintenance
program is arr anged with your alarm company. If a change in operation is
noticed during normal use or testing, call for service as soon as possible. Do not
attempt to repair the control panel, arming stations, or detectors yourself.
Call _________________________________________ Before Testing
The security system is connected to this telephone number:
__________________________________________________________
The security control panel is connected to the phone jack located:
__________________________________________________________
AC Power Failure
If your keypad indicates AC power has failed, and you have power in the
remainder of your premises, there could be a problem with the electrical
transformer or circuit breaker supplying power to your security control panel.
First, check to be sure the transformer is securely plugged into the electrical
outlet. If it appears to be damaged in any way, do not attempt to repair it. Call
your security company for service.
Transformer location: _________________________________________
If the transformer is plugged in, check the circuit breaker supplying power to the
outlet. If the breaker is tripped, reset it. If it trips again, the overload condition must be
corrected.
Circuit breaker location: _______________________________________
The D720 Series Keypad
The keypad is an illuminated digital arming station that is the keypad for your
entire security system. The keypad does much more than just arm and disarm
your security system; it can initiate several system commands. A system status
display panel keeps you informed of security conditions, as well as storing alarm
information for future reference. It also indicates various security system
conditions such as your system’s armed status, protective point status, power
supply status, and Command mode status. A built-in sounder alerts you of
several different conditions, which requires action. The keypad also includes
three function keys that perform many system commands with the touch of one
key.
4
Page 5
Security System Basics
What is a Point?
A point is a detection device, or group of devices connected to your security
system. Each area of your property is assigned to a specific point w ith a number.
A point is a single door (like the entrance door) or an area of your property (like
the second floor). Each point is represented by its point number on the keypad
display panel. There are two basic types of points: Controlled and 24-hour.
Controlled Points
Controlled points respond to alarm conditions depending upon whether the
system is turned on (armed) or turned off (disarmed). Controlled points are
programmed to respond instantly to alarm conditions or provide a delay for you
to reach the keypad and disarm the system. There are two types of controlled
points: Perimeter and Interior.
1. Perimeter Points: All exterior doors and windows of the building,
forming the outside “wall of protection” around your building.
2. Interior Points: All interior forms of burglary protection such as
carpet mats, motion sensors, inside doors, etc..
24-Hour Points
24-hour points are always on, even when the burglary system is disarmed (turned off ).
There are two types of 24-hour points: Fire and Non-Fire.
1. Fire Points: Exclusively monitor fire detection devices. They are
always armed and cannot be disarmed. Fire alarms have a unique
audible warning signal.
2. Non-Fire Points: Always armed and cannot be disarmed.
Keypad Features
Armed Status Indicators
Three lights indicate the armed status of your security system. Each is explained
below. During an exit delay period, these lights flash on and off slowly.
Perimeter--When this red indicator is lit, your perimeter points are
armed. When this indicator is not lit, your system is not
armed.
Interior -- When this yellow indicator is lit, your interior points are
armed. When this indicator is not lit, your interior points
are not armed.
Instant-- This red indicator shows how your system is armed; either
instant or delayed. When this indicator is lit, your security
system is armed without entry/exit delay time. When the
system is armed with entry/exit delay, this indicator is not lit.
Point Status Indicators
Point status indicators on the keypad show the condition of your system’s
protective points. Each point has its own indicator that shows three different point
conditions (listed in order of priority).
Point Bypass -- When a point is bypassed (not armed with the rest of the system),
its indicator light flashes on and off slowly.
Faulted Point -- A faulted point is indicated by a steadily lit point status indicator.
Point Alarm Memory -- When a point is faulted into alarm, its indicator flashes
on and off rapidly.
The Point Status Indicators also show whether the system is ready to arm or not.
If the point status indicators are not lit, the system is armed by entering your
personal passcode or any of the arming commands available to your system. If
any of the point status indicators are lit, the system has a faulted point. Correcting
the faulted point usually means closing a door or window.
5
Page 6
Power Indicator
When the red PWR indicator LED lights steadily, your security system is
operating from AC voltage and the standby battery is fully charged. When the
PWR indicator is off, AC or battery power is not present. When flashing slowly, a
low battery power condition is indicated. When flashing quickly, battery power is
missing. If the indicator is off or continues to flash, contact your security
company.
Command Mode Indicator
When the [COMMAND] bar is pressed, the red Command mode indicator
(CMD) lights steadily to show the system is ready to accept a command. If the
command requires that a passcode be entered, the CMD indicator slowly blinks,
prompting you to enter your passcode. Once a passcode is entered, the
Command mode indicator lights steadily again and remains steadily lit while the
system is in the command mode. The indicator goes off when the command is
completed (or after 15 seconds of inactivity).
Note: If all of the keypad’s LEDs are blinking in unison, the system requires
service.
Exiting the Command Mode
If you decide to exit the Command mode before completing the chosen function,
you can exit the command mode at any time by pressing the [A] key. The CMD
light goes off, confirming that you have left the command mode.
The Keypad
The keypad has a lighted digital keypad used to enter passcodes and system
commands into the security system. As you touch the keys to enter a passcode,
the keypad emits a short beep tone to indicate that your entry is accepted.
COMMAND Bar
The [COMMAND] bar is used to perform one- or two-digit COMMAND
functions.
Note: Some systems require a security passcode to be entered after the function keys
or [COMMAND] bar are pressed. If a passcode is required, the CMD light
blinks. Enter your passcode when you see this light blinking.
Enter (ENT) Key
When the passcode is completed, press the [ENT] key to activate the passcode. If
you do not press the [ENT] key, the passcode is ignored by the security system.
When entering a passcode or command at the keypad, each key must be pressed
within 5 seconds of the last key entr y. After 5 seconds have expired from the last
key entry, the entire entry is cleared and the passcode must be started over.
6
Page 7
Function Keys
The keypad has three function keys (labeled A, B, and C). The function keys are
used to perform system commands w ith the touch of one key. Your alarm
technician programs the Function Keys.
Function Key Function Performed
[A] ______________________________
______________________________
[B] ______________________________
______________________________
[C] ______________________________
______________________________
Note: The [A], [B], and [C] keys can perform various functions. These functions
require a few seconds before they are completed, because the system is
completing several instructions at once. Therefore, please wait for 5 seconds
after using the [A], [B], or [C] keys to allo w the syst em to “catch up.”
Turning the System On (Arming)
Your security system is turned on (ar med) in many different ways, depending on
the arming command used. Arming commands turn the system on. The most
basic arming command is to arm the entire system. The simplest way to arm your
system is to enter your personal passcode and press [ENT] or to use COMMAND
1.
There are several other arming commands to turn the system on. For example:
arm only the perimeter or ar m only portions of the perimeter. These arming
functions and their respective commands are described later in this guide.
Turning the System Off (Disarming)
Your security system is tur ned off by entering your personal passcode and
pressing [ENT]. When your system is turned on, you must enter the premises
through a designated entry door to prevent an immediate instant alarm
condition. Open the door starts an entry delay time and the keypad emits a
pulsing beep tone to remind you to turn the system off. Enter your personal
passcode and press [ENT] before the delay time expires and the system turns off.
If you enter through a wrong door or fail to disarm before the entry delay
expires, causes an alarm. If this happens, silence the alarm (by entering your
personal passcode and pressing [ENT]) and call your security company to notify
them it is not an emergency situation.
7
Page 8
Silencing an Alarm
The audible alarm sounds for a specific period of time before it automatically
shuts off. If an alarm occurs and you want to silence the bell or siren before the
time expires, simply enter your personal passcode and press [ENT].
After silencing the alarm and returning points to normal, you can clear the alarm
memory lights by entering your passcode twice (arm and disarm). On some
systems the alarm memory lights are cleared by entering COMMAND 4.
To Silence an alarm:
Enter your personal passcode and press [ENT].
Note: Some security systems are programmed so bells or sirens cannot be silenced
until the point is restored to a normal (non-alarm) condition.
Reporting to the Central Station
My system reports to a Central Station.
My system does not report to a Central Station.
Your system is programmed to send a closing report to your security company
when arming.
My system sends a Closing Report.
My system does not send a Closing Report.
Your system is programmed to send an Opening Report to your secur ity
company when disarming.
My system sends an Opening Report.
My system does not send an Opening Report.
Your system is programmed to report Force Arming to your security company.
Force Arming is reported to my security company.
Force Arming is not reported to my security company.
Your security system automatically disconnects your telephone from its line when
transmitting reports to your securit y company. This prevents reports from being
interrupted during transmission. Once the report is completed, the telephone line
is restored to normal service.
Note: If damage occurs to the telephone line and your telephone service is
interrupted, reports are not transmitted to your security company unless an
alternate means of transmitting signals is installed in your system.
8
Page 9
Keypad Tones
Your keypad emits one of several distinc t tones to alert you to system events.
Additional bells or sirens can also be connected to your system. Bells or sirens
mounted on the exterior of your premises alert neighbors to emergencies and
provide an audible guide for police and fire fighters. Some of these tones are
optional, and are selected by your alarm technician.
1. Fire Alarms: Fire alarms are the highest priority events. When a
fire point activates, your keypad emits a fast, pulsating,
high-pitched tone. Evacuate all occupants and investigate for smoke
or fire. Ensure all occupants know the difference between the
burglary tone and the fire tone. The tone sounds for the time set by
your security company. The keypad point status LEDs show the
fire points in alarm.
Note: Some points, such as fire points, are programmed so the sounder cannot be
silenced until the point fault is corrected.
2. Burglary Alarms: Burglar y alarms are the second priority. When a
burglary point activates while your system is armed, your keypad
emits a pulsating burglary tone. The tone sounds for the time set
by your security company. The keypad point status LEDs show
the burglary points in alarm.
3. System Trouble Events: When a system component is not
functioning properly, your keypad is progr ammed to repeatedly
emit three warble tones, then a pause. If the problem is with a
point, the point status light indicates which point is faulted. To
silence the system trouble tone, enter COMMAND 4 or your
personal passcode followed by [ENT].
4. Entry Delay Tone: When you enter the premises through a point
programmed for entr y delay, the keypad emits a repeating tweedle
tone to remind you to turn off your system.
Exit Delay Tone: After you arm your system, the keypad emits a
repeating beep tone and counts down the exit delay time. If you
don’t exit before the delay time expires, and an exit delay door is
faulted, entry delay begins.
5. Keystroke Checking Tones: Pressing any key on the keypad
sounds a short beep tone. When you press an incorrect key, a flat buzz
tone sounds to indicate an invalid entry.
6. Faulted Point: When you enter an arming command, and a point is
faulted, the sounder is activated for 2 seconds. The point status
indicator associated with the faulted point is lit.
7. Watch Tone: When the Watch Mode is activated, the keypad
emits a brief tone to alert you when any watch point is faulted and the
point indicator lights to indicate which point is faulted. The tone
sounds only when the door or window is opened. It does not sound
again for that point until the door or window is closed and then
reopened.
Some system trouble events produce a trouble tone without producing any status light
indications. These trouble events fall into three categories:
1. Hardware, software, or wiring problems. For example: a keypad was
unplugged from the control panel or the printer was unplugged.
Call your security company.
2. Communication or phone failure. For example: you have phone
line trouble. Call your security company.
3. Late to close reminder tone. If your system is programmed to
send a Closing Report, your keypad sounds the trouble tone to
remind you that it is time to close. Arm your system to silence the
tone.
9
Page 10
Turn the Entire System On With Delays
I have this feature.
I do not have this feature.
This feature requires a passcode.
Command 1 is used to arm the entire system, both perimeter and interior points.
Once you enter Command1, the exit delay time starts. You now have a
predetermined amount of time to exit the p rotected area before the system arms.
During the exit period, you can move through motion detectors or any protected area
on your way to any exit without causing an alarm. To cancel Command 1, enter
your personal passcode and press [ENT].
Note: If you leave the building after the exit time expires, you can begin the entry
delay or initiate an alarm. It this happens, disarm your system by ent er ing
your personal passcode and press [ENT]. It your system reports to a central
station, call them if an alarm oc curs.
Application
Command1 is useful in applications where you want your cleaning or service
personnel, or anyone else to arm your system when they leave, but you do not
want them to have the passcode to disarm the system. Command 1 arms the
system, but does not disarm the system.
COMMAND 1
Arming with COMMAND 1:
1. Ensure all points are secure. All of the Point Status indicator
lights on the Keypad should be off. If not, refer to Force Arming
the System on page 29.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [1] key. The PERIMETER indicator and the INTERIOR
indicator lights begin to flash on and off, showing the system has
begun exit delay time.
4. To disarm your security system or cancel COMMAND 1, enter your
personal passcode and press [ENT] before the delay time expires.
10
Page 11
Turn the Entire System On Without Delays
I have this feature.
I do not have this feature.
This feature requires a passcode.
Use this function to turn on the entire system, both perimeter and interior
without delays. When entering Command 11, remember that the second [1] must
be pressed within 2 seconds of pressing the first [1].
COMMAND 1 1
Using Command 11:
1. Ensure all points are secure. All Point Status indicator lights on
the keypad should be off. If not, see the section describing Force
Arming the System (on page 29).
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [1] key. Now press the [1] key again.
4. The PERIMETER, INSTANT, and INTERIOR lights come on,
showing the perimeter, instant, and interior points are armed without
entry/exit delay time.
5. To disar m your security system, enter your personal passcode
and press [ENT].
11
Page 12
Turn On the Perimeter With No Delays
I have this feature.
I do not have this feature.
This feature requires a passcode.
Command 2 is used to arm only the perimeter of your building, leaving the
interior of the building disarmed. This command allows no exit or entry delay
time through the perimeter, including the designated delay door. Enter your
personal passcode, plus [ENT], to cancel Command 2. Remember, there are no
entry or exit delays when you use this function. You must disarm (turn off ) the
system to enter or exit the premises.
Application
This arming command is useful in residential systems at night when everyone is
home and ready to retire for the evening.
In commercial installations, this arming command is useful when you are
working late and you want the perimeter of the building armed until you are
ready to leave.
COMMAND 2
Arming with COMMAND 2:
1. Ensure all perimeter points are secure. Interior points are not
armed with this command, and can remain faulted while arming
with Command 2. Perimeter point status lights should be off. If
not, refer to Force Arming the System on page 29.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on
3. Press the [2] key. The PERIMETER and INSTANT indicator lights
come on, showing the perimeter points are armed without entr y/exit
delay time.
4. To disar m your security system or cancel Command 2, enter your
personal passcode and press [ENT] before the delay time expires.
12
Page 13
Turn On the Perimeter With Delays
I have this feature.
I do not have this feature.
This feature requires a passcode.
Command 3 is used to arm only the perimeter of your building, leaving the
interior disarmed. Once you enter Command 3, the exit delay time starts. You
now have a predetermined amount of time to leave before the perimeter arms.
Enter your personal passcode and press [ENT], to cancel Command 3.
Application
This arming command is useful in residential systems when you are leaving, but
members of your family, a baby-sitter, or a pet, are still inside the house.
In commercial installations, use this command to rearm your system when you
are on the premises, but not yet open for business.
COMMAND 3
Arming with Command 3:
1. Ensure all perimeter points are secure. Interior points are not
armed with this command and can remain faulted while arming
with Command 3. Perimeter point status lights should be off. If
not, refer to Force Arming the System on page 29.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [3] key. The PERIMETER indicator light flashes, showing
the system has begun exit delay time. When the delay time
expires, the light remains steady.
4. To disar m your security system or cancel Command 3, enter your
personal passcode and press [ENT] before the delay time expires.
13
Page 14
Silence the Trouble Sounder
I have this feature.
I do not have this feature.
This feature requires a passcode.
Use Command 4 to silence the trouble sounder during system trouble events.
COMMAND 4
To use Command 4:
1. Press the [COMMAND] bar. The Command mode indicator light
comes on.
2. Press the [4] key. The keypad trouble sounder is silenced, and
any flashing Point Status indicator lights are turned off if the point
is normal. If the point is not normal, its indicator light stays on
solidly, indicating the need for attention.
14
Page 15
Send Report
I have this feature as Command 41.
I have this feature as Command 42.
I do not have this feature.
This feature requires a passcode.
This function tests the communication link between your security system and
your security company. It is an important part of maintaining a high level of
security for your propert y.
Two types of Test Reports are sent. The first t ype (Command 41) simply tests the
communication of security messag es to your security company. The second type
is a Status Report (Command 42), which sends the current condition of your
system in addition to testing the communication link to your security company.
COMMAND 4 1 & 4 2
To use COMMAND 4 1 or COMMAND 4 2:
1. Always call your security company before sending a Test Report.
2. Ensure your security system is disarmed.
3. Press the [COMMAND] bar. The Command mode indicator light
comes on.
4. Press the [4] key, and then press the [1] key, or press the [4] key
and then the [2] key for COMMAND 42.
5. After the report is received at your security company, the keypad
emits a beep tone for 2 seconds to confirm the test signal was
properly transmitted and received.
15
Page 16
Enable Remote Account Management
I have this feature.
I do not have this feature.
This feature requires a passcode.
Your security system is manage d remotely from your security company without
having a service person on the protected premises. By using Command 43, you
can enable Remote Account Management (RAM). Remote Account Management
is done with the aid of a speciall y equipped computer at your security company.
Typical remote programming changes can include adding or deleting sy stem
commands and changing personal passcodes or entry/exit delay times.
COMMAND 4 3
To use COMMAND 4 3:
1. Your system is armed or disarmed to perform this function.
2. Call your security company using this phone number:
_________________________________________________________
This number is designated for the Remote Account Manager. You
must make the call using the telephone located:
_________________________________________________________
3. Identify yourself and your premises (account number, name,
address, etc.) and advise the operator of the programming
changes you want performed.
4. When the operator directs you, enter [COMMAND] [4] [3] at
your keypad:
Press the [COMMAND] bar. The Command mode indicator light
comes on.
5. Press the [4] key, and then press the [3] key. The telephone line the
call was made from is not active when Remote Account Management
is in progress. You can hang up the telephone.
6. When Remote Account Management is completed, your
telephone line automatically restores normal service.
16
Page 17
Walk Test
I have this feature.
I do not have this feature.
This feature requires a passcode.
Use this function to test keypads, detection devices, and sounders (both interior
and exterior) to be certain they function properly. You can review untested points
at your keypad to help pinpoint any problems.
You cannot arm your system while in the Walk Test Mode, and no Alarm Reports
are sent to your security company unless a 24-hour point is activated (such as fire
or panic).
Note: The AC is disabled for 4 minutes to test the system’s battery power. If the
battery cannot maintain the system for the 4 minutes period, the keypad
beomes unresponisive. If this happens, contact your securi ty company. At
the end of the 4 minutes period, AC is returns to the system and the control
panel restores.
To test indiv idual detection devices, simply activate sensors and open protected
doors and windows one at a time. As each detection device is faulted, the keypad
emits a brief tone and the display indicates the point is tested. This verifies that
each detection device is working properly.
COMMAND 4 4
To use Walk Test:
1. Ensure your security system is idle.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [4] key, and then the [4] key again. Audible devices (both
interior and exterior) sound the burglary bell.
4. After silencing the audible devices, you can test detection devices.
Open a door or window or activate a motion sensor. Each time a
detection device is tested, the keypad beeps for 2 seconds. The
keypad display panel indicates the point you faulted verifying that
the detection device is working properly.
5. To end the Walk Test, press any numeric key on the keypad. If no
activity occurs on the system for 20 minutes, the Walk Test ends
automatically.
17
Page 18
Reset Sensors
I have this feature.
I do not have this feature.
This feature requires a passcode.
Command 47 resets faulted detection devices. Devices can include smoke
detectors, shock sensors or a variety of other detection devices. Ask your alarm
technician which points you can reset from the keypad by entering Command
47.
COMMAND 4 7
To reset detectors:
1. Ensure your security system is disarmed.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [4] key, and then press the [7] key. The display flickers
momentarily and the keypad emits multiple pips during reset.
If you enter this function and the detector or sensor resets momentarily but then
returns to a faulted condition, the conditions causing the activation can still be
present or the detector is faulty. Check to be certain there is no smoke, fire, or
other danger present.
If you cannot reset the detector or sensor, contact your security company.
18
Page 19
Delete Passcodes
I have this feature.
I do not have this feature.
This feature requires a passcode.
Use Command 53 to delete a personal passcode from your system without
assistance from your security company. You need to know the user number fo r the
passcode you want to delete. The two-digit user numbers identify users in reports
transmitted from your system.
COMMAND 5 3
To delete passcodes:
1. Ensure your securit y system is idle.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [5] key, and then press the [3] key. Your security system is
now in the Passcode Delete Mode.
4. Enter the two-digit user number for the passcode you wish to
delete. Press [ENT]. The passcode is now deleted.
19
Page 20
Personal Passcode Change
I have this feature.
I do not have this feature.
This feature requires a passcode.
Your security system co nveniently allows you to change your personal passcode
whenever you need to without the services of your alarm technician. It is
recommended that you write down both your old and new passcodes before you
begin.
Before you begin:
• Care should be given when entering a passcode containing the same
digits in consecutive positions within the new passcode (s uch as “3”
in 33467). When entering this type of passcode, it is easy to make
mistakes.
• The passcode is from three to six digits in length.
• To avoid conflicting with other passcodes and duress codes, your
system does not let you change to passcodes that are within plus or
minus two of an existing passcode. For example, if 1234 were an
existing code, your system would not let you change your code to
1232, 1233,1235, or 1236.
COMMAND 5 5
To change your personal passcode:
1. Ensure your security system is idle.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [5] key and then the [5] key again. Your securit y system is
now in the Passcode Change Mode.
4. Enter the passcode you wish to change and press the [ENT] key.
5. Enter the new passcode and press the [ENT] key.
6. Enter the new passcode again and press the [ENT] key.
7. Test the new passcode by using it to arm and disarm the system.
Do not use any of the keypad arming commands to arm the
system until you are certain that the new passcode is working.
20
Page 21
Fire Test
I have this feature.
I do not have this feature.
This feature requires a passcode.
Use this function to test points and other 24-hour points to be certain they
function properly. You can review untested points at your keypad to help
pinpoint any problems.
When initiated, the Fire Test tests the fire bell pattern on the bell output and r ings
the keypad fire bell for 2 seconds. The AC is disabled for 4 minutes to test the
system’s battery power. If the battery cannot maintain the system for the 4-minute
period, the keypad appears to go dead. If this happens, contact your security
company. At the end of the 4-minute period, AC returns to the system and the
control panel restores. A message is be sent to your security company upon
initiation and completion of the Fire Test. During the Fire Test, no 24-hour alarms
are sent to your security company.
If there is no activity on the system for 20 minutes, the system automatically exits
from the Fire Te st.
COMMAND 5 8
To use Fire Test:
1. Ensure your security system is idle.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [5] key, and then the [8] key. Audible devices (both interior
and exterior) sound the fire bell.
4. One by one, activate the detection devices to fault ea ch point. The
audible fire devices sound momentarily and the keypad display
indicates the faulted point, verifying that the detection device is
working properly.
5. To end the Fire Test, press any numeric key on the keypad. If no
activity occurs on the system for 20 minutes, the fire test ends
automatically.
21
Page 22
Watch Mode
I have this feature.
I do not have this feature.
This feature requires a passcode.
With your system disarmed, use Watch Mode to monitor selected points. Each
time a watch point is faulted (door or window is opened) the keypad chimes
once.
Note: Contact your security company to find out which points are watch points
and whether or not your syste m automatical ly turns the Watch Mode on
whenever you disarm.
Application
This command is useful in a residential system when you want to monitor
entrances or exits in your home.
In commercial installations, Watch Mode is used as a door chime to alert you
when a customer or delivery person has entered your business.
COMMAND 6
To use COMMAND 6:
1. Ensure your security system is idle.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [6] key. The system is now in Perimeter Watch Mode.
4. To exit the Perimeter Watch Mode, press the [COMMAND] bar and
then the [6] key.
22
Page 23
Special Alert
I have this feature.
I do not have this feature.
This feature requires a passcode.
This command is a manually operated and initiated alarm command.
Command 7 is programmed to respond to numerous situations that can need
immediate attention. This command can also send a silent alarm to your security
company without sounding an alarm signal on the premises. Check with your
security company for the options they offer.
COMMAND 7
To engage COMMAND 7:
1. Press the [COMMAND] bar. The Command mode indicator light
comes on.
2. Press the [7] key. Your COMMAND 7 special alert is programmed to:
_____ notify your alarm company.
_____ ring a bell on your premises.
Description:
__________________________________________________________
__________________________________________________________
__________________________________________________________
__________________________________________________________
23
Page 24
Partially Turn On the Perimeter
I have this feature.
I do not have this feature.
This feature requires a passcode.
This function is used to turn on the perimeter of your building while selected
portions of the perimeter remain turned off. Perimeter points that are not secure
(faulted) when this function is entered are not included in the system. This
function does not turn on the interior of your building. Entry/exit delays are
provided with this arming command.
Application
Use this function in residential systems to turn on the front of your house while
the interior and the rear perimeter doors are turned off, giving you freedom of
movement between the house and patio.
In commercial systems, when you need access to the large overhead doors to
receive deliveries, this function allows you to keep the rest of the building
perimeter armed.
COMMAND 8
To arm with COMMAND 8:
1. Ensure the keypad is disarmed.
2. Decide which points are to be left disarmed. Fault the points
(doors and windows) by leaving them open. The point(s) must
remain open until after the exit delay time expires.
3. Press the [COMMAND] bar. The Command mode indicator light
comes on.
4. Press the [8] key. The PERIMETER indicator light begins to flash,
showing the system has begun exit delay time. When the exit delay
expires, the PERIMETER indicator is continuously lit.
5. When performing a COMMAND 8, and no points are faulted, or
the points return to normal before the exit delay time expires, the
system is armed as in COMMAND 3.
6. To disarm your security system or cancel COMMAND 8, enter
your personal passcode and press [ENT].
24
Page 25
Special Alert
I have this feature.
I do not have this feature.
This feature requires a passcode.
This command is a manually operated and initiated alarm command.
Command 9 is programmed to respond to several situations that can need
immediate attention. This command can also be used to send a silent alarm to
your security company without sounding an alarm signal on the premises. Check
with your security company for the available options.
COMMAND 9
To engage COMMAND 9:
1. Press the [COMMAND] bar. The Command mode indicator light
comes on.
2. Press the [9] key. Your COMMAND 9 special aler t is programmed
to:
_____ notify your alarm company.
_____ ring a bell on your premises.
Description:
__________________________________________________________
__________________________________________________________
__________________________________________________________
__________________________________________________________
25
Page 26
Bypass a Point
I have this feature.
I do not have this feature.
This feature requires a passcode.
The keypad makes it easy for you to have complete control of your security
system. With Command 0 you can bypass points you do not want included in the
system. You can bypass points when an area is disarmed. Bypassing a point
reduces the level of security and should be used with discretion. Points remain
bypassed until you unbypass them (refer to Unbypass a Point on page 27) or some
points can return when the area is disarmed.
COMMAND 0
To use Bypass a Point:
1. Ensure your security system is disarmed.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [0] key. The system is now in the Bypass mode. (Some
points are set by your alarm company so they cannot be
bypassed).
4. To bypass a point, press the key that corresponds with the
number of that point, and then press the [ENT] key. The point
status light corresponding to the bypassed point flashes,
indicating the point is bypassed.
26
Page 27
Unbypass a Point
I have this feature.
I do not have this feature.
This feature requires a passcode.
Unbypassing a point is a way to return a bypassed point to the security system so
it can respond to trouble and alarm conditions.
COMMAND 0 0
To Unbypass a Point:
1. Ensure your security system is disarmed.
2. Press the [COMMAND] bar. The Command mode indicator light
comes on.
3. Press the [0] key, then press the [0] key again. The system is now the
Unbypass mode.
4. To unbypass a point, press the number key that corresponds to the
number of the point that is flashing slowly, and then press the [ENT]
key. The point status light stops flashing, indicating the point is
unbypassed.
27
Page 28
Turning the System On With a Duress Passcode
I have this feature.
I do not have this feature.
This feature requires a passcode.
A duress passcode sends a silent alarm signal to your secur ity company. It arms
or disarms the security system just like your personal passcode; however, as the
system is armed or disarmed, an alarm signal is transmitted. Be sure your security
technician explains how this feature works in your system. There is no alarm tone
or visual indication at the premises that the report is sent.
Application
The duress passcode is used when someone threatens you and demands you
disarm (or arm) your security system. By disarming (or arming) with a duress
passcode, your security company is alerted of an alarm situation.
Passcode + 1, or + 2
The duress passcode is based on your personal passcode. By increasing the last
digit by one or two, the duress feature is activated. For example; If your personal
passcode is 1234, the duress passcode is 1235 (or 1236).
My system uses Passcode + 1 for duress.
My system uses Passcode + 2 for duress.
Note: If your system has a security passcode that unlocks the [COMMAND] bar,
increasing the last digit of that passcode sends a duress signal to your
security company.
Important! Be sure to press the [ENT] key after entering the duress passcode.
28
Page 29
Force Arming the System
I have this feature.
I do not have this feature.
If a protected door or window is open, you can have the option of force arming
with that point faulted. Faulted points (opened doors or windows) that are force
armed are not included in the system. The remaining points arm normally.
Your sy stem might not offer force arming or it is restricted to specific points.
Contact your security company for more information.
To arm with points faulted:
1. Enter your personal passcode and press the [ENT] key, or enter
an arming command (COMMANDs 1, 2, or 3). The keypad emits
a buzz tone indicating a point is faulted.
2. Press the [COMMAND] bar and then the [ENT] key. The system
now arms all points that are normal.
Note: If the fault is restored (returned to normal) while arming, the point is
armed. If the fault is restored after arming, how your system is programmed
determines whether or not the point is armed with the rest of the system.
A faulted point is armed with the rest of the system if restored.
A faulted point is not armed with the rest of the system if restored
and is not be armed until I disarm the security system and re-enter
an arming command.
I am allowed to have a maximum of ______ points faulted when force arming.
29
Page 30
Security System Glossary
Arm and Disarm - Rendering of an igniter from a safe (no energy) to a ready-tofire condition and vice versa.
Bypass - Deliberately not including certain points of protection when arming the
security system.
Central Station - Facility where trained personnel monitor your security system
24 hours a day. Your system can contact central station personnel to dispatch the
proper authorities.
Closing Report - Signal to your security company indicating the system is armed.
Commercial accounts can use this report to indicate the business is now closed.
Key pad - Displays system status, sounds warnings with a sounder, and can also
control many other functions of a security system including Arming and
Disarming.
Entry Delay - Predetermined amount of t ime provided by the security sy stem to enter
an armed building through a delay door. Once the delay door is opened, the entry
delay begins. If the security system is not disarmed befo re the delay time expires, the
system goes into alarm.
Exit Delay - Predetermined amount of time provided by the security system to
leave the armed building through a delay door. Once the system is armed, the
exit time begins. You must exit the building before the exit delay time expires.
Faulted Point - Point that is not normal (a door or window is open).
Force Arm - Turning on (arming) the securit y system even though one or more
points are faulted. Force arming bypasses the faulted points.
Master Arm - Turning on (ar ming) all detection systems, including interio r and
perimeter points.
Opening Report - Signal to your security company indicating the system just was
disarmed. Commercial accounts can use this report to indicate the business is
open.
Passcode - Used to arm or disarm the keypad.
Perimeter Arm - Arming command that arms only the perimeter of your building,
Point - Detection device, or group of devices, connected to your security system.
A point is a single door or an entire room or area of your building (like the
second floor). Most points are either perimeter, interior, or fire (24-hour) points.
Trouble - Service condition that needs to be corrected, such as a broken wire.
30
Page 31
Security System Limitations
Not even the most advanced security system can guarantee protection against
burglary, fire, or environmental threats. All security systems are subject to
possible compromise or failure-to-warn for a variety of reasons including, but
not limited to, the following:
• If sirens or horns are placed outside the hearing range of people in
remote areas of the building or in areas which are frequently closed off,
they do not provide the intended protection.
• If intruders g ain access through unprotected points of entr y, the system
does not detect their entrance.
• If intruders have the technical means of bypassing, jamming, or
disconnecting all or part of the system, they are not detected.
• If the AC power supply is off and the backup battery is missing or d ead,
sensors do not detect intrusion.
• Smoke detectors cannot detect smoke in chimneys, walls, roofs, or
smoke blocked by a closed door. They can not detect smoke or fire
on a level of the building different from the one on which they are
located. Smoke detecto rs can’t warn in time about fires started by
explosions, improper storage of flammables, overloaded electrical
circuits, or other types of hazardous conditions.
• If phone lines are out of service, reports from the security system to
the security company cannot be sent. Telephone lines are
vulnerable to compromise by several means.
Inadequate maintenance and failure to test are the most common causes of alarm
failure. It is strongly recommended that you test your system once a week to be
sure all system components are working properly.
Although having a security system can make you eligible for reduced insurance
premiums, the system is no substitute for insurance. Warning devices cannot
compensate you for loss of life or property.
31
Page 32
71-06898-000-D 08/04 © 2004 Bosch Security Systems D720 Series User’s Guide
Loading...
