Bio-Plex Pro Human Immunotherapy Panel
Quick Guide
For Use wi th Inst ruction Manu al #
Bio-Plex Pro Human Immunotherapy Assays 10000112563
This guide can be used to prepare and run a full 1 x 96-well assay plate. New
users can download the complete manual, which includes detailed instructions
and a list of kit components, at bio-rad.com/bio-plex.
Initial Preparation
1. Plan the plate layout.
2. Start up/warm up the Bio-Plex Multiplex Immunoassay System (30 min).
■
Bring diluents, including wash buffer, assay buffer, standard
diluent HB, detection antibody diluent HB, and sample diluent HB,
to room temperature (RT). Keep the other items on ice until needed
– Mix by inversion to ensure all salts are in solution
– Prepare 1x wash buffer: dilute 1 part 10x wash buffer (60 ml) with
9 parts distilled water (540 ml)
■
Begin to thaw the frozen samples
3. Prepare the sample dilution according to the guidelines provided in the
following table. It is important to centrifuge serum or plasma samples at
1,000 x g for 15 m in at 4°C to remove particulates from all samples prior to use.
Sample Type Recommended Sample Dilution Diluent
Serum and plasma 1:4 Sample diluent
Culture media and uids User dened Diluent + 0.5% bovine
Note: ICAM-1 and VCAM -1 require higher di lution for ser um and pl asma (re comm ended 100-fold ). Refer
to the Bio-Plex Pro Human Immunotherapy Assays Instruction Manual (#10000112563) for detailed sample
preparation recommendations.
serum albumin (BSA) (w/v)
4. Calibrate the Bio-Plex System within Bio-Plex Manager Software.
5. Reconstitute the standards and control by adding 250 µl of standard
diluent HB to each. Vortex at medium speed for 5 sec and incubate all
vials on ice for precisely 30 min.
Bio-Plex Pro Human Immunotherapy Panel Quick Guide
Standard Serial Dilution
6. Prepare a fourfold standard dilution series and blank as shown.
Vortex at medium speed for 5 sec between liquid transfers.
Note: Standards are at S1 concentration after reconsititution and the
controls are ready to use after reconstitution. Controls are included with
the xed panel only.
Transfer Volume, µl
Reconstituted
Standard
Standard Diluent, µl
50250 50 50 50 50 50 50
S1
S2 S3 S4 S5 S6 S7 S8 Blank
1500 150 150 150 150 150 150 150
7. Vortex the coupled beads at medium speed for 30 sec and dilute to 1x
in Bio-Plex Assay Buffer as shown. Protect from light.
Premixed Panels
Number of Wells 10x Beads, µl Assay Buffer, µl Total Volume, µl
96 570 5,1 3 0 5,700
Singleplex Assays
Singleplex #1
Number of Wells
96 285 285 5,13 0 5,700
Note: 20x sing lepl ex beads allow mu ltipl exing up to 20 analy tes.
20x Beads, µl
Singleplex #2
20x Beads, µl Assay Buffer, µl Total Volume, µl
Running the Assay
1. Vortex the diluted (1x) beads. Add 50 µl to each well of the assay plate.
2. Wash the plate two times with 100 µl Bio-Plex Wash Buffer.
3. Vortex the samples, standards, blank, and control. Add 50 µl to each well.
4. Cover the plate with sealing tape. Incubate on shaker at 850 ± 50 rpm at
RT for 30 min.
5. With 10 min left in the incubation, vortex the detection antibodies for 5 sec
and quick-spin to collect liquid. Dilute to 1x as shown.
Bio-Plex Pro Human Immunotherapy Panel Quick Guide
Premixed Panels
Number of Wells
96 300 2,700 3,000
Singleplex Assays
Number of Wells
96 150 150 2,700 3,000
Note: 20x sing lepl ex beads allow mu ltipl exing up to 20 analy tes.
10x Detection
Antibodies, µl
Singleplex #1
20x Detection
Antibodies, µl
Detection Antibody
Diluent HB, µl Total Volume, µl
Singleplex #2
20x Detection
Antibodies, µl
Detection
Antibody
Diluent HB, µl
Total
Volume, µl
6. Wash the plate three times with 10 0 µl was h b u f fe r.
7. Vortex the diluted (1x) detection antibodies. Add 25 µl to each well.
8. Cover the plate with sealing tape and incubate at 850 ± 50 rpm for
30 min at RT. Meanwhile, prepare the Bio-Plex Manager Software
protocol; enter standard S1 values and units provided in the assay kit.
9. With 10 min left in the incubation, vortex 100x streptavidin-phycoerythrin
(SA-PE) for 5 sec and quick-spin to collect liquid. Dilute to 1x as shown
and protect from light.
Number of Wells 100x SA-PE, µl Assay Buf fer, µl Total Volume, µl
96 60 5,940 6,000
10. Wash the plate three times with 100 µ l wash bu f fe r.
11. Vortex the diluted (1x) SA-PE. Add 50 µl to each well.
12.
Cover the plate with sealing tape and incubate at 850 ± 50 rpm for
10 min
at RT.
13. Wash the plate three times with 100 µl wash buf fe r.
14. Resuspend the beads in 125 µ l assay buffer. Cover and shake at
850 ± 50 rpm for 30 sec.
15. Remove the sealing tape and read plate using the following settings:
Instrument RP1 (PMT) DD Gates Bead Events
Bio-Plex 3D* Standard Select MagPlex Beads 50
Bio-Plex 100, 200* Low 5,000 (low); 25,000 (high) 50
Luminex MAGPIX N/A, use default
* Or simi lar Lum inex System.
instrument settings
10000112540 Ver A (12010951) US/EG
19-0219 0419 Sig 0119
Web site bio-rad.com USA 1 8 00 424 6723 Australia 61 2 9914 2800
Austria 43 01 877 89019 Belgium 32 03 710 53 00 Brazil 55 11 3065 7550
Canada 1 905 364 343 5 China 86 21 6169 8500 Czech Republic 36 01 459 6192
Denmar k 45 04 452 10 00 Finland 35 08 98 0 422 00 France 33 01 479 593 00
German y 49 089 3188 4393 H ong Kong 852 278 9 3300 Hungar y 36 01 459 6190
India 91 124 4029300
Israel 972 03 963 6050
Italy 39 02 494866 00 Japan 81 3 6361 7000
Korea 82 2 3473 4460 Mex ico 52 555 48 8 7670 The Netherlands 31 0 318 540 666
New Zealand 64 9 415 22 80 N orway 47 0 233 841 30 Poland 36 01 459 6191
Portugal 351 21 4727 717 Russia 7 495 721 14 04 Singapore 65 6 415 3188
South Africa 36 01 459 6193 Spain 3 4 091 49 06 580 S weden 46 0 8 555 127 00
Switzerland 41 0617 17 9555 Taiwan 886 2 2578 7189 Thailand 66 2 651 8311
United Arab Emirates 971 4 8187300 United Kingdom 44 01923 47 1301
Bio-Rad
Laboratories, Inc.
Life Science
Group
Bio-Plex Pro Human Immunotherapy Panel Quick Guide
The observed concentration ranges of the control apply only when standards
and controls are prepared using the provided Bio-Plex Standard Diluent HB.
ontrols
Assay Workow
Add 50 μl 1x beads to wells
Wash buffer: 2 x 200 μl
Add 50 μl standards, samples, controls; incubate on shaker at 850 rpm for 30 min at RT
Wash buffer: 3 x 100 μl
Add 25 μl 1x detection antibody; incubate on shaker at 850 rpm for 30 min at RT
Wash buffer: 3 x 100 μl
Add 50 μl 1x SA-PE; incubate on shaker at 850 rpm for 10 min at RT
Wash buffer: 3 x 100 μl
Resuspend in 125 μl assay buffer; shake at 850 rpm for 30 sec
Acquire data on Bio-Plex System
