Product: KCONN PP Flat 24 1U
KeyConnect Patch Panel Flat 24 Port, 1U
Product Description
KeyConnect Patch Panel, 24-port, 1U, Empty
Technical Specifications
Product Overview
Environmental Space: Indoor
Suitable Applications: Compatible with a variety of modules that are suitable for use with Belden IBDN Systems 10GX, 4800, 2400 and 1200.
Physical Characteristics (Overall)
Height: 44.450 mm
Width: 482.600 mm
Depth: 33.020 mm
Port Count: 24 Port
Front Connection: Flush
Packaging: Individually packaged in a cardboard box.
Weight: 0.454 kg
Connectors
Materials
Description Material
Panel Steel
Construction and Dimensions
Max Capacity: 24 connectors
Temperature Range
Installation Temp Range: -10°C To +60°C
Storage Temp Range: -40°C To +70°C
Operating Temp Range: -10°C To +60°C
Mechanical Characteristics
Footprint/Type: KeyConnect
Applicable Environmental and Other Programs
EU Directive 2011/65/EU (ROHS
II):
Yes
MII Order #39 (China RoHS): EUP 50
Flammability, LS0H, Toxicity Testing
Safety Listing: ACA, Bi-national Standard Listed
Part Number
Related Parts: Compatible with 10GX, CAT6+ and CAT5E KeyConnect Modular Jacks as well as KeyConnect Multimedia Modules.
Variants
Item # Color UPC
AX103114 Black 611589033893
Product Notes
Included Parts:
4 Screws (10x32); 4 Screws (12x24); 1 Label Holder; 1 Printable LabelFlex Half-Sheet; 2 Velcro Straps; 2 Rear Cable Management Brackets, 1 Management Bar; 1
Installation Guide
Notes: For proper installation refer to Installation Guide PX104691 included with the product
History
Update and Revision: Revision Number: 0.45 Revision Date: 01-31-2020
