Behringer X-TOUCH EXTENDER Instruction Manual

Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
Universal X-TOUCH EXTENDER for
Studio and Live applications
Supports Mackie Control*,
HUI* and Standard MIDI Control protocol for seamless integration with every compatible music production software
Multiple X-TOUCH and EXTENDER
units can be combined to emulate a large-scale control surface
8 fully automated and touch-
sensitive 100 mm motorized faders
8 dynamic LCD Scribble Strips for
instant overview of track names and parameters
8 rotary controls with LED-collars
for on-the-y adjustments of your favorite parameters
Built-in USB MIDI interface for direct
connection to Mac* or PC computers
2-port powered multi-TT USB hub
for connecting additional controllers
Ethernet interface for RTP (Real-Time
Protocol) MIDI remote control
"Planet Earth" switching power
supply for maximum exibility (100 - 240 V~) and low power consumption for energy saving
3-Year Warranty Program*
Designed and engineered
in Germany
Love your X-TOUCH Universal
Control Surface, but want even more
control over your music production?
The amazing X-TOUCH EXTENDER is
the ideal and cost-eective way to
grow your current setup, and can even
be used as a standalone controller for
remote recording to your laptop.
From the 8 touch-sensitive, motorized
faders and the 8 dynamic LCD
scribble strips, to the 8 rotary encoders, 32 illuminated buttons, and
8-segment LED meters per channel, the X-TOUCH EXTENDER transforms
what’s on your DAW’s screen into one ultra-compatible, feature-packed
surface for precision control and a bird’s eye view of critical mix parameters.
Connectivity is simple using traditional USB connections, plus it also has an
Ethernet interface for use with DAWs that support RTP (Real-Time Protocol)
MIDI remote control.
Room to Grow
As your production needs grow, you can combine multiple X-TOUCH and EXTENDER units to emulate a large-scale control surface – all you need are a few standard USB cables.
*Mac is a trad emark of Apple Inc . All third-par ty trademark s are the proper ty of their respe ctive owners . Their use neith er constitutes a claim of the tr ademark nor ali ation of the trade mark owners with MUSIC Group. P roduct names are m entioned sole ly as a reference for compatibility, eects and/or components. Warranty details can be found at mu sic-group.com.
Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
Universally Yours
When it comes to integration, the X-TOUCH EXTENDER has you covered with the most widely used protocols in the industry. With included support for HUI* and Mackie Control*, you can be sure it will work seamlessly with all compatible music production software, allowing you to focus on what counts… the music.
Faders that Dance with Your Music
Your music is the embodiment of your imagination and creativity. Your controller should be equally inspired and dynamic in its response to your creation. That’s why the X-TOUCH EXTENDER features 8 fully automated and touch-sensitive 100 mm motorized faders. Every move or automation you write can be seen in the movements of each fader in real time, perfectly synced with your DAW.
LCD Scribble Strips - Instant Readout
LCD scribble strips grace the top of each channel fader, providing an instant visual readout of which track and parameter you are adjusting – totally eliminating old school tape-and-marker labelling.
2 of 6
Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
A Symphony of Lights
With 4 dedicated illuminated buttons, 8 rotary controls with LED collars and 8-segment LED meters per channel, the X-TOUCH EXTENDER is a feast for the eyes as well as the hands. At-a-glance you can see in brilliant color if a channel is muted or soloed and how hot the level is pumping as you make changes during recording or mixing. Arm multiple tracks or adjust panning at the same time and marvel at how you ever relied on a mouse to do a controller’s job.
The Feel
Navigation is a breeze with the abundant features on the X-TOUCH EXTENDER’s intuitive surface. Race between faders, push real illuminated buttons, turn actual knobs – X-TOUCH EXTENDER brings your on-screen DAW controls to life!
Connect, Control, Expand
With class-compliant USB functionality, the X-TOUCH EXTENDER is instantly recognizable by Mac and Windows PCs. Its USB MIDI port allows you to connect and communicate with an external device. The powered multi-TT USB hub provides connectivity for 2 more controllers so it can grow with your career. And the power and control can expand further via the integrated Ethernet interface for DAWs that support RTP MIDI. Isn’t that awesome?
3 of 6
Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
Compose. Record. Mix. Share.
Tracktion is one of the world’s fastest and easiest Digital Audio Workstations (DAW) for composing, recording, editing, mixing and sharing your music with the world. Featuring a single-screen interface, and pushing the envelope in design elegance, Tracktion brings together outstanding Pro DAW features, such as dynamic automation, unlimited track count, MIDI recording and support for VST and AU plug-ins. This powerful music production software gives you all the tools of an entire professional-grade recording studio. Learning a DAW has never been easier, thanks to their vast and readily available library of resources.
As our way of saying “Thank You”, when you register your X-TOUCH EXTENDER at behringer.com, we'll reward you with a complimentary download code for the full version of Tracktion. Recording and editing couldn’t be easier. To learn more, visit tracktion.com/support/videos.
Share the Love. Visit tracktion.com for more.
The Magic TOUCH
The X-TOUCH EXTENDER provides all the tools you need to expand your current music production control, so you always make the most of your recording and mixing sessions. Take full control of your DAW by adding more motorized faders, rotary encoders with LED collars and illuminated key function buttons.
See and feel the dierence the X-TOUCH EXTENDER can make in your workow at a BEHRINGER dealer today... or get yours online. Feel the music; feel the magic – X-TOUCH.
You Are Covered
We always strive to provide the best possible Customer Experience. Our products are made in our own MUSIC Group factory using state-of-the-art automation, enhanced production workows and quality assurance labs with the most sophisticated test equipment available in the world. As a result, we have one of the lowest product failure rates in the industry, and we condently back it up with a generous 3-Year Warranty program.
4 of 6
Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
5 of 6
Product Information Document
Desktop Controllers
X-TOUCH EXTENDER
X-TOUCH EXTENDER with 8 Touch-Sensitive Motor Faders, LCD Scribble Strips, USB Hub and Ethernet/USB Interfaces
