Technical Specications
1002
Premium 10-Input 2-Bus Mixer with XENYX Mic Preamps,
British EQs and Multi-FX Processor
2 XENYX 1002FX Technical Specifications
XENYX 1002FX
Premium 10-Input 2-Bus Mixer with XENYX Mic Preamps,
British EQs and Multi-FX Processor
Premium ultra-low noise, high headroom analog mixer
2 state-of-the-ar t XENYX Mic Preamps comparable to stand-alone boutique preamps
Neo-classic “British” 3-band EQs f or warm and musical sound
Studio-grade stereo FX processor with 100 awesome presets including reverb, chorus, anger, delay, pitch shif ter and various multi-eect s
FX send control per channel for internal FX processor and/or as ex ternal send
Main mix outputs plus sep arate control room, phones and stereo CD/tape outputs
CD/tape input s assignable to main mix or control room/phone s outputs
Long-wearing 60-mm logarithmic-taper fader and sealed rotary controls
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
Mono Inputs
Microphone Inputs
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resis tance -132.7 dB / 137 dB A-weighted
@ 50 Ω source resis tance -130 dB / 133.9 dB A-weighted
@ 150 Ω source resistance -127.1 dB / 130.9 dB A-weighted
Frequency response <10 Hz - 200 kHz (-1 dB)
Gain range +10 to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx. 2.6 kΩ b alanced
Signal-to-noise ratio -107 dB / -111 dB A-weighte d
(0 dBu In @ +22 dB gain)
Distortion (THD + N) 0.005% / 0.003% A-weighted
Line Input
Type ¼" TRS connector,
electronically balanced
Frequency Response
Microphone Input to Main Out
<10 Hz - 80 kHz +0 dB / -1 dB
<10 Hz - 137 kHz +0 dB / -3 dB
Stereo Inputs
Type ¼" TRS connector,
electronically balanced
Impedance approx. 20 kΩ b al. / 10 kΩ unbal.
(+4 dBu operating level)
approx. 20 kΩ b al. / 5 kΩ unbal.
(-10 dBV )
Max. input level +22 dBu
EQ Mono Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Audio Outputs
FX Send
Impedance approx. 20 kΩ b alanced
approx. 10 kΩ unbalanced
Gain range -10 to +40 dB
Max. input level +20 dBu @ 0 dB Gain
Fade-Out Attenuation1 (Crosstalk Attenuation)
Main fader closed 85 dB
Channel fader closed 88 dB
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. outpu t level +22 dBu
Main Outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. outpu t level +22 dBu
3 XENYX 1002FX Technical Specifications
Control Room Outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. outpu t level +22 dBu
Headphones Output
Type ¼" TRS connector, unbalanced
Max. outpu t level +19 dBu / 150 Ω (+25 dBm)
Main Mix System Data
2
Noise
Main mix @ -∞, -105 dB / -108 dB A-weighted
Channel fader -∞
Main mix @ 0 dB, -94 dB / -97 dB A-weighted
Channel fader -∞
Main Mix @ 0 dB, -83 dB / -85 dB A-weighted
Channel fader @ 0 dB
FX Section
Converter 24-bit Sigma-D elta
Sampling rate 40 kHz
Mains Voltage
USA/Canada 120 V~, 60 Hz, MXUL6 adapter
U.K./Australia 240 V~, 50 Hz, MXUK6 adapter
Europe 230 V~, 50 Hz, MXEU6 adapter
China/Korea 220 V~, 50 Hz, MXCN6 adapter
Japan 100 V~, 60 Hz, MX JP6 adapter
Output 2 x 14.8 V~, 2 x 500 mA
Dimensions
Dimensions (H x W x D) approx. 1 ⁄" / 1 / x 7 / x 8 /"
approx. 47 mm / 37 x 189 x 220 mm
Weight (net) approx. 3.5 lbs / 1.6 kg
Measuring conditions:
1: 1 kHz rel. to 0 dB u; 20 Hz - 20 kHz; line i nput; main out put; unit y gain.
2: 20 Hz - 20 k Hz; measured a t main output . Channels 1 - 4 unit y gain; EQ flat ; all channels on ma in mix; channel s 1/3 as far
left a s possible, cha nnels 2/4 as far rig ht as possible. R eference = +6 dB u.
