Bake Max BMMG003, BMMG004 Operation Manual

BMMG003/BMMG004

MEAT GRINDER

Operations Manual

Questions? OEM Parts, Contact Us:

Toll Free: 1-800-565-2253

Email: [e-mail]

www.BakeMax.com

Warranty Registration

www.BakeMax.com/Warranty-Registration

Warning & Safety

PLEASE READ AND FOLLOW INSTRUCTIONS BELOW TO PREVENT

INJURY OR DAMAGE TO THE PRODUCT

BakeMax® (a registered trademark of Titan Ventures International Inc or TVI) is

not responsible for any harm or injury caused due to any person’s improper or

negligent use of this equipment. The product shall only be operated by someone
over the age of 18, of sound mind, and not under the influence of any drugs or
alcohol, who has been trained in the correct operation of this machine, and is
wearing authorized, proper safety clothing. This machine is intended for
commercial use only. Any modification or miss use to the machine voids any
warranty and may cause harm to individuals using the machine or in the area of
the machine while in operation.

• When using the machine, please ensure that you have read all of the instructions within
this manual.

• Be aware of your surroundings when using this machine, ensure there are no children
or any other persons who are near the machine before operating.

• Do not put hand near moving parts.

• Remove all obstacles, which may interfere with machine functions.

• Keep work area clean and clear of clutter.

• Do not sit or stand on machine.

• Do not wear loose clothing or jewellery when operating machine as it may get caught in

moving parts and cause injury.

• Stop using the machine and have it checked by an authorized service personal if it is not
working properly.

• Disconnect from power source before performing and maintenance or cleaning on the
machine.

• When the machine is not in use, please clean and store properly,

• Do not place any electrical parts or plug / cord in water or liquid.

• If the supply cord is damaged it must be replaced by an authorized service agent in order

to avoid any electrical hazards.

• Keep power cord away from heat.

• Always ensure to follow local laws when operating your machine.

Cleaning

• This unit has been coated for shipping purposes, please clean before use.

• Do not use any liquid pressurized cleaning equipment on this machine.

• Disconnect power supply before cleaning.

• Only use food grade non abrasive cleaning agents.

• Follow any additional cleaning / maintenance listed below.

BMMG003 Features

Prepare freshly ground meat with ease using the BakeMax BMMG003 Meat Grinder. Capable of grinding up
to 264 lb of meat per hour with its 1 HP motor. This unit is great for Restaurants, Delis, and Meat Shops.

• 1 HP motor capable of grinding up to 264 lb / Hr

• #12 hub

• 2 plates included (6mm & 8mm)

• Constructed of anodized aluminum alloy and stainless steel for durability and ease of cleaning

• Resistant to rust, salt and acid

• Forward and reverse switch

• Waterproof and emergency shut off switch

• 120v / 850W / 60HZ / 1 Phase

• Nema 5-15P

• Net Weight: 49 lb

• Packaged Dimensions (WDH): 16” x 13” x 22”

• Packaged Weight: 53 lb

• 1 year limited warranty

BMMG004 Features

Prepare freshly ground meat with ease using the BakeMax BMMG004 Meat Grinder. Capable of grinding up to
660 lb of meat per hour with its 1.5 HP motor. This unit is great for Restaurants, Delis, and Meat Shops.

• 1.5 HP motor capable of grinding up to 660 lb / Hr

• #22 hub

• 2 plates included (5mm & 8mm)

• Constructed of anodized aluminum alloy and stainless steel for durability and ease of cleaning

• Resistant to rust, salt and acid

• Forward and reverse switch

• Waterproof and emergency shut off switch

• 120v / 1000W / 60HZ / 1 Phase

• Nema 5-15P

• Net Weight: 55 lb

• Packaged Dimensions (WDH): 18” x 11” x 24”

• Packaged Weight: 60 lb

• 1 year limited warranty

** Due to continuous product improvement, specifications are subject to change without notice.
