This installation, administration and user’s guide provides background information and procedures
for installing, configuring and maintaining the Cyclades
Power Distribution Unit (IPDU) family.
The Cyclades PM IPDU enables remote power control of servers and network gear. When used in
conjunction with DSR
capabilities and faster problem solving by integrating console/KVM access and power control into
one single interface.
The following sections describe general features common to all PM IPDU models and point out
specific features of certain units.
®
switches or console servers, the PM IPDU delivers easier management
Features and Benefits
Alarms and monitoring
The PM IPDU delivers accurate, real-time global current monitoring of all connected devices via
the user interface screen or locally through an LED digital display. Users have the ability to set a
current alarm threshold that, once exceeded, will cause the PM IPDU to sound an alarm or send a
notification message, or both.
Sequential power application
The PM IPDU incorporates a sequential power application feature that prevents all power outlet
receptacles from turning on at once, eliminating the potential of current surges that could render the
equipment inoperable. Together with the global current monitoring, the sequential power
application feature lets users safely install more equipment on existing power circuits without the
worry of current overloads.
®
Power Management (PM) Intelligent
Support for daisy chaining
The IPDU has a fixed number of power outlet receptacles, but with daisy chaining capabilities,
users may increase capacity by connecting the control interfaces of several PM IPDUs in a series.
Page 12
2 Cyclades PM IPDU Installer/Administrator/User Guide
1
2
3
4
5
6
Integration with Avocent management products
The PM IPDU can be combined with an ACS console server or DSR KVM switch to provide
enhanced functionality. Please refer to the appropriate product documentation for more information
on how to use the PM IPDU with your specific implementation.
Hardware Configuration Options
The PM IPDU may be used in one of three hardware configurations:
• Standalone – Managed independently of any other hardware device.
• Daisy chained - Multiple PM IPDUs connected to one another and managed by one main
PM IPDU.
• Integrated – Managed by a console server or a KVM switch.
Standalone configuration
In a standalone configuration, the PM IPDU operates independently of any other hardware. The
following graphic displays a PM IPDU with the console port connected to a computer running
terminal emulation.
Figure 1.1: Standalone Configuration
Table 1.1: Standalone Configuration Descriptions
Number Description Number Description
1 RJ-45 to DB-9F Adaptor (Optional) 4 Server
2 RJ-45 Cable 5 Switch
3 IN Port 6 Power Source
Page 13
NOTE: The installation example displays the PM IPDU being connected with the RJ-45 to DB-9F adaptor that is
shipped with the product. If the unit you are connected to does not have a DB-9M COM port, you may use a USB
serial adaptor and connect to a USB port when possible.
Daisy chained configuration
In a daisy chained configuration, multiple PM IPDUs are connected to one another and managed by
a single main PM IPDU. The PMs are linked together with RJ-45 cables connected through the PM
IPDU’s IN and OUT ports. The following example shows three PM IPDUs operating in a daisy
chained environment. PM IPDU #1 is connected to the local workstation and is the “main”
PM IPDU.
Chapter 1: Introduction 3
Figure 1.2: Daisy Chained PM IPDUs with an Avocent Management Device
Integrated configuration
In an integrated configuration, the PM IPDU is configured to work in conjunction with an Avocent
management product.
A user connects to the PM IPDU by accessing the appropriate console port of the Avocent
management product. In this scenario, software configuration on and monitoring of the PM IPDU
is done through the Avocent management product and not on the PM IPDU itself. Visit
www.avocent.com for more information.
Page 14
4 Cyclades PM IPDU Installer/Administrator/User Guide
Page 15
CHAPTER
Installation
2
Getting Started
Collect the following equipment prior to installing and configuring the PM IPDU in
standalone configuration:
• One or more RJ-45 to RJ-45 straight-through cables
• An RJ-45 to DB-9F straight-through adaptor
• A PC running a terminal emulation program
Supplied with the PM IPDU
5
Table 2.1: PM IPDU Shipping Box Contents and Description
Description Purpose
PM IPDU Quick Installation Guide (QIG) Basic installation guide in printed format.
RJ-45 to RJ-45 7ft. straight through
CAT5 cable
RJ-45 to DB-9F straight-through adaptor Along with an RJ-45 cable, used to connect a terminal or PC to a
RJ-45 loopback connector Used to gain temporary access to the PM IPDU.
PM IPDU to DSR switch cable adaptor Used to connect a PM IPDU to an Avocent switch’s SPC port.
Mounting brackets and screws (2 spares)
for PM10 IPDU and PM10i IPDU
Used for the following:
Along with an adaptor, to connect a terminal or PC to the IN port.
To connect to a Cyclades console or KVM management device.
To connect to another PM IPDU in a daisy chain.
PC’s COM port.
Use to mount the Cyclades PM10 IPDU and PM10i IPDU to a
rack or wall.
Modular input power cables for the PM IPDU
If your PM IPDU model does not have a fixed power input cable, it may ship with a modular cable.
Depending on your site’s location, the modular input power cables included in the box vary.
Page 16
6 Cyclades PM IPDU Installer/Administrator/User Guide
NOTE: The Cyclades PM 10i-32Au IPDU ships with an unterminated power cord. If necessary, contact Avocent
Technical Support for guidelines on approved power plug installation.
Optional outlet cable package
The following cable packages may be ordered separately for the IEC PM IPDU models:
• 8-outlet cables (C13 female to C14 male)
• 10-outlet cables (C13 female to C14 male)
Rack Mounting the PM IPDU
You may mount the PM IPDU on a rack or wall or place it on a desktop or other flat surface. Two
brackets are supplied with six Phillips screws for attaching the brackets to the PM8i IPDU, the
PM10 IPDU and the PM10i IPDU for mounting.
If you are mounting the PM IPDU, obtain a Phillips screwdriver and appropriate nuts and bolts
before mounting the PM IPDU.
NOTE: When mounting a PM IPDU zero U model to a wall stud, securely mount it by using a #10 (4.8 mm or
0.19 in or 3/16 in) or larger screw or use a drywall fastener rated min. 25 lb. (11.34 kg).
The following graphic depicts the orientation of the brackets for front rack mounting a PM IPDU.
Figure 2.1: Rack Mount Bracket Installation on a PM IPDU
Page 17
Installation environment
When installing the PM IPDU, ensure that the following environment specifications are met.
Table 2.2: PM IPDU Optimum Installation Environment
Environment Factor Recommendation
Temperature The manufacturer's maximum recommended ambient temperature for the
Chapter 2: Installation 7
PM IPDU is 122 ºF (50 ºC).
Elevated Operating Ambient
Temperature
Reduced Air Flow Installation of the equipment in a rack should be such that the amount of air
Mechanical Loading Mounting of the equipment in the rack should be such that a hazardous
Circuit Overloading Consideration should be given to the connection of the equipment to the
Reliable Grounding Reliable grounding of rack-mounted equipment should be maintained.
NOTE: Install a PM IPDU 0U model in a location where there is an adjacent and accessible socket outlet.
CAUTION: The plug on the power cord of the PM IPDU is used as the disconnect device.
If the PM IPDU is installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment may be greater
than room ambient temperature. Therefore, consideration should be given
to installing the equipment in an environment compatible with the
manufacturer’s maximum rated ambient temperature. See above.
flow required for safe operation of the equipment is not compromised.
condition is not created due to uneven mechanical loading.
supply circuit and the effect that overloading of circuits might have on
overcurrent protection and supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing
this concern.
Particular attention should be given to supply connections other than direct
connections to the branch circuit, such as power strips or extension cords.
To mount the PM10 IPDU or PM10i IPDU:
1. Using a Phillips screwdriver, attach the supplied brackets to the sides of the PM IPDU.
2. Use the mounting hardware recommended for your rack to mount the PM IPDU.
Page 18
8 Cyclades PM IPDU Installer/Administrator/User Guide
4
1
2
3
5
7
8
9
6
10
11
12
Figure 2.2: A Sample PM IPDU (PM42 Shown)
Table 2.3: Cyclades PM42 IPDU Callout Descriptions
Number/Letter Description
1 Outlet, IEC320-C13, 14 each for bank XY, YZ and XZ
2 RS-232 (IN) Port
3 MULTI (OUT) Port
4 Overload Reset Button
5 Three digit LED displays the current on Phase X, Y and Z in sequence, or the voltage
across Phases X and Y, Y and Z, and X and Z in sequence
6 SCROLL button - manually toggles display when the display command is set to Imanual
or Vmanual (see display on page 20)
7 LED indicates when Phase X current is displayed
8 LED indicates when Phase Y current is displayed
9 LED indicates when Phase Z current is displayed
10 Phase X
11 Phase Y
12 Phase Z
Daisy Chaining PM IPDUs
You may manage a maximum of 128 outlets by connecting multiple PM IPDUs to the main PM
IPDU device.
Page 19
To daisy chain a PM IPDU:
This procedure assumes that a main PM IPDU is already connected to a workstation or
management appliance.
1. Connect one end of an RJ-45 cable to the OUT port of the main PM IPDU, which is connected
to a workstation or management appliance.
2. Connect the other end of the RJ-45 cable to the IN port of the secondary Cyclades PM IPDU.
3. Repeat these steps until you have connected the desired number of PM IPDUs.
Accessing the Console
Users and administrators may access the PM IPDU either by making a direct console connection to
the PM IPDU’s IN port or by connecting the PM IPDU to an Avocent console or KVM switch
management device.
Direct console access
While using the PM IPDU device independently of other Avocent devices, local users may connect
directly to the system console port (the IN port) of the PM IPDU using the console cable with the
corresponding adaptor(s).
The system administrator must specify basic settings on the PM IPDU before users may connect to
and manage the unit and the connected devices. To perform necessary basic configuration, make a
direct connection to the PM IPDU by connecting a terminal or computer to the IN port.
Chapter 2: Installation 9
To access the console:
Perform the following steps to connect a computer to the console port of the PM IPDU. This
procedure assumes that you know how to use a terminal emulation program.
1. Connect an RJ-45 serial cable to the IN port on the PM IPDU.
2. Connect the RJ-45 serial cable to a computer with a terminal emulation program using the RJ-
45 to DB-9F straight-through adaptor or a USB serial adaptor.
3. Using a terminal emulation program, connect to the PM IPDU with the following settings:
ANSI emulation, 9600 bps, 8 bits, no parity, 1stop bit and no flow control.
When prompted, enter the username
If this is a first-time installation, see Initial configuration using the command prompt on page 10
for instructions on changing the default password, adding users and assigning outlets to users.
admin with the default password pm8.
Console access through a management device
By integrating the PM IPDU device with an Avocent console or KVM switch management device
such as DSView 3 software or Cyclades ACS, remote users may access the PM IPDU's console
port through a menu-driven interface. Using Telnet or SSH through the console server, type the
Page 20
10 Cyclades PM IPDU Installer/Administrator/User Guide
power management hotkey (Ctrl+P by default) to activate a power management menu. Please refer
to the appropriate product documentation for more information.
To connect a PM IPDU to an Avocent DSR switch:
Use the included RJ-45 cable adaptor to connect a PM IPDU to an Avocent DSR switch.
1. Plug the male end of the adaptor into the DSR switch’s SPC port.
2. Plug one end of a straightthrough CAT 5 cable into the female end of the adaptor.
3. Plug the other end of the CAT 5 cable into the PM IPDU’s IN port.
Configuring the PM IPDU
The PM IPDU may be configured by any one of two methods:
• Command Prompt - Full configuration capabilities
• Browser or text based menu - Available only when the PM IPDU is connected to a
management device
For information about integrated use with an Avocent management device visit www.avocent.com
or refer to the documentation relevant to that product family.
Default configuration parameters
The PM IPDU’s default configuration is as follows:
•User is admin.
• Admin user’s password is pm8.
• All outlets are un-named.
• All outlets are unassigned to user.
• All outlets are turned on.
• All outlets are unlocked.
Initial configuration using the command prompt
To change the default admin password (if pm8 is in use):
1. Log in to the PM IPDU using the default username
2. Enter the
3. Enter a new password when prompted.
To create users with the adduser command:
1. Log in to the PM IPDU.
2. Enter the
3. Enter the password when prompted.
passwd command.
adduser command followed by the new username.
admin and password pm8.
Page 21
To assign outlets to users with the assign command:
1. Log in to the PM IPDU.
2. Enter the
assign command followed by the outlet number(s) and username.
Example:
pm>assign 2 jane
Outlet 2 assigned to jane.
To name the outlets with the name command:
1. Log in to the PM IPDU.
2. Enter the
name command followed by the outlet number and desired name of the outlet.
Example:
pm>name 2 chispa
2: Outlet now named chispa
To save the configuration with the save command:
1. Log in to the PM IPDU.
2. Enter the
save command to save the configuration.
Chapter 2: Installation 11
Resetting the admin password
In the event the administrator wants to reset the password for the PM IPDU (for example, if the
administrator forgets the admin password), then the loopback connector that is shipped with the PM
IPDU may be used for temporary access to the PM IPDU.
To reset the admin password using the loopback connector:
1. If you are not logged out, log out by entering
to work.)
2. Connect the loopback connector shipped with the PM IPDU to the OUT port.
3. Check the display. If you are watching the PM IPDU's console output, your status will
be reported.
4. After one minute, you may remove the loopback connector. The password for the user admin is
reset to the default (pm8), and you should be able to log into the PM IPDU using the default
username/password. For maximum security, the admin password should be changed as soon
as possible.
Upgrading the PM IPDU firmware
The upgrade procedure described here is only valid for units that are curren tly runni ng firmware
versions 1.3.0 or greater. If your PM IPDU is running an older firmware version, please follow the
instructions in the manual that corresponds to the firmware currently installed on the PM IPDU.
exit. (You must be at the login prompt for this
Page 22
12 Cyclades PM IPDU Installer/Administrator/User Guide
To upgrade PM IPDU firmware:
1. Download the new PM IPDU firmware from the Avocent web site.
2. Using terminal emulation software, log into the PM IPDU as admin and type in the command:
pm>upgrade <IPDU#>
The <IPDU#> is the number of the IPDU to which you want to upgrade the firmware. If you
have only one PM IPDU, type
chain, type
NOTE: If you have a daisy chain and you want to upgrade all units, you should start from the last unit and work
your way towards the first.
upgrade 3 or upgrade 2 depending on which unit you want to upgrade.
upgrade 1. If you have, for instance, three units in a daisy
3. At the boot loader menu, select option 1 to upgrade the firmware.
The boot loader erases the firmware currently in the unit and asks you to upload the
new firmware.
4. Use your terminal emulator program to upload the PM IPDU firmware file to the PM IPDU
using the Xmodem protocol.
For information about using a different terminal emulator, please refer to the documentation
provided by the manufacturer on how to transfer files using the Xmodem protocol.
When the file transfer is complete, the PM IPDU console displays the login prompt. You may log
into the PM IPDU and perform actions as usual.
If the file transfer fails, an error message appears on the PM IPDU console, and the boot loader
menu is displayed again so you may redo the firmware upgrade process.
In this case, select option 1 from the menu and repeat the firmware upload procedure. If the
problem persists, contact Avocent Technical Support for assistance.
Page 23
CHAPTER
13
Accessing the PM IPDU via the
3
When using the PM IPDU independently of other Cyclades products, users and administrators may
access the PM IPDU command line interface through a terminal emulation program.
Command Line Interface
PM IPDU User Interface
You may access the PM IPDU user interface by following the instructions provided in Direct
console access on page 9. Depending on the PM IPDU’s boot status, either the Boot Menu or the
Login Prompt will appear.
On the Boot Menu, you may enter
Login Prompt.
Daisy chained PM IPDUs in the login prompt
Number of PM IPDUs
If no PM IPDUs are daisy chained, the [PM]: IPDU: line appears only once, and the value is 1.
If there are any PM IPDUs daisy chained to the first PM IPDU, the [PM]: IPDU: line appears once
for each PM IPDU in the chain. For each PM IPDU, the value is incremented by 1. The final
appearance of the [PM]: IPDU: line will show the total number of PM IPDUs in the daisy chain.
2 (or just wait approximately 12 seconds) to activate the
Number of PM IPDU outlets
If no PM IPDUs are daisy chained, the [PM]: OUT: line appears only once, and the value is equal
to the number of outlets on the PM IPDU.
If there are any PM IPDUs daisy chained to the first PM IPDU, the [PM]: OUT: line appears once
for each PM IPDU in the chain. For each PM IPDU, the value shows the cumulative total of outlets
until the total number of outlets for the entire chain is displayed.
Logging in to the PM IPDU
When prompted, enter your username and password.
NOTE: If there are daisy chained PM IPDUs, you will need to press Enter after the final [PM]: OUT: line appears.
Page 24
14 Cyclades PM IPDU Installer/Administrator/User Guide
After a successful login, the PM IPDU command prompt appears after which you may use any of
the commands described in this chapter.
Commands
NOTE: When a range of outlets is used in a command and the range spans more than one PM IPDU in a daisy
chain, the range of outlets must not be specified by name. The range of outlets may only be specified by number
in this situation.
adduser
The adduser command adds one username to the internal database. A maximum of eight characters
(not case sensitive) is allowed, and a maximum of eight individual users is allowed. This command
is available to the admin user only.
Syntax
adduser <user>
Arguments
<user> username
Examples
alarm
To add a user, enter:
pm>adduser popper
The alarm command sets and reads the current threshold. This command is available to the admin
user only.
Syntax
alarm | [<IPDU#>|<IPDU_ID>] | <threshold>
In the case of a PM42 IPDU:
alarm | <IPDU#> | <threshold> | <phase_letter>
Page 25
Chapter 3: Accessing the PM IPDU via the Command Line Interface 15
Arguments
<IPDU#> IPDU number in a daisy chain
Examples
To set the threshold on PM IPDU number one to 5.6A, enter:
To set the threshold on PM IPDU number two phase Y to 5.6A, enter:
pm>alarm 2 5.6 Y
To read the threshold, enter:
assign
The assign command assigns management of an outlet to a given user. This command is available
to the admin user only.
<IPDU_ID>
<threshold>
<phase_letter>
no argument
pm>alarm 1 5.6
pm>alarm
Identification string previously set by the id command
The current threshold is the maximum allowed current on the power strip
Specifies the threshold of a specific phase on the PM42 IPDU. When the
phase letter is not specified on the PM42 IPDU, the threshold will be set
to the same value for all three phases.
Displays alarm status of all PM IPDUs in the daisy chain
Syntax
assign <outlet_number> <user>
Arguments
<outlet_number>
Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
<user>
Desired username
Examples
To assign outlet 4, 6, 7 and 8 to user tess, enter:
pm>assign 4, 6-8 tess
Page 26
16 Cyclades PM IPDU Installer/Administrator/User Guide
buzzer
The buzzer command displays or changes the buzzer notification status. When set to “on”, a buzzer
sounds when the current exceeds the threshold. This command is available to the admin user only.
Syntax
buzzer <on|off|status>
Arguments
on
off
status
Examples
To get the current status of the buzzer notification, enter:
pm>buzzer status
To turn buzzer notification on or off, enter:
pm>buzzer on
pm>buzzer off
current
The current command displays the total current drawn by PM IPDUs and the maximum current the
unit has drawn (current peak). It may also be used to clear the saved peak current value.
Syntax
current [<IPDU#>|<IPDU_ID>]|reset
For PM42 IPDU:
current [<IPDU#>|<IPDU_ID> [<phase_letter>]]|reset
Enables buzzer
Disables buzzer
Displays buzzer status
Page 27
Chapter 3: Accessing the PM IPDU via the Command Line Interface 17
Arguments
<IPDU#> IPDU number in a daisy chain
<IPDU_ID>
reset
<phase_letter>
Examples
To get the current status for all units, enter:
pm>current
To get the current status for a specific unit, enter:
pm>current 2
To reset maximum current drawn, enter:
pm>current reset
currentprotection
The currentprotection command turns the over current protection feature on or off. The overcurrent
protection does not allow an outlet to be turned on if the current drawn by the unit is greater than
the current threshold configured with the command alarm. This command may also be used to
display the current protection status and is available to the admin user only.
Syntax
Identification string previously set by the id command
Clears the saved peak current value
Either phase X, Y or Z for the PM42 IPDU
currentprotection <on|off|status>
Arguments
on
off
status
Enables over current protection
Disables over current protection
Displays the current protection status
Examples
To display current protection status for all units, enter:
pm>
currentprotection status
Page 28
18 Cyclades PM IPDU Installer/Administrator/User Guide
To enable current protection status for all units, enter:
pm>currentprotection ON
To disable current protection status for all units, enter:
pm>currentprotection off
NOTE: Current protection commands affect all IPDUs in the daisy chain and all phases of the PM42 IPDU.
currseg
The currseg command lets you view the current for the lower or upper segment of outlets. This
command is only useful for IPDUs with dual current sensors. The lower segment (segment A)
would be outlets 1-5 on a PM10 series IPDU, and the upper segment (segment B) would be outlets
6-10 on a PM10 series IPDU.
Syntax
currseg A|B [reset]
Arguments
cycle
A|B
reset
Segment A or segment B
Clear the max recorded current for A and B
Example
To view the current load of segment A, enter:
pm>currseg A
To reset the maximum recorded current for A and B, enter:
pm>currseg reset
The cycle command power cycles an outlet or group of outlets. You may use the outlet number or
the outlet name (see command name for details).
Syntax
cycle all|<outlet_string>
Page 29
Chapter 3: Accessing the PM IPDU via the Command Line Interface 19
Arguments
all Cycles all outlets in the PM IPDU or PM IPDU daisy chain
<outlet_string>
Examples
To cycle outlet 3, enter:
pm>cycle 3
To cycle outlets 2, 3, 5, 6 and 7, enter:
pm>cycle 2, 3, 5-7
dbsync
The dbsync command synchronizes the user database for all PM IPDUs in the chain. This
command is available to the admin user only.
Syntax
dbsync
Arguments
none
Examples
To synchronize the user database for all PM IPDUs in the chain, enter:
Outlet number, such as “5”, outlet name such as “sunfire”, or group
of outlets such as “1, 3-5”
deluser
The deluser command deletes one username from the internal database. This command is available
to the admin user only.
Syntax
deluser <user>
Arguments
<user> Desired username
pm>dbsync
Page 30
20 Cyclades PM IPDU Installer/Administrator/User Guide
Examples
To delete the user “rog”, enter:
pm>deluser rog
display
The display command allows logical inversion of the 2-digit, 7-segment display. The purpose of
this command is to allow a PM IPDU to be mounted upside-down. This command is available to
the admin user only.
NOTE: The decimal point will be at the top of the display when the PM IPDU is mounted upside down.
On the PM42 IPDU, this command either allows you to manually step through the current level
views of each bank of outlets, or to set an interval for the current level views to automatically be
displayed.
NOTE: The display on the PM42 IPDU may be physically rotated.
Syntax
For single phase PM IPDUs:
display [<IPDU#>|<IPDU_ID> [0|180]]
For the PM42 IPDU:
display [<IPDU#>|<IPDU_ID> [Imanual|[Iauto <cycle_time>]]|[Vmanual|[Vauto
<cycle_time>]]]
-or-
display
Arguments
no argument
<IPDU#>
<IPDU_ID>
0
180
Show display status of all PM IPDUs in the daisy chain
Number of the PM IPDU in the chain
Identification string previously set by the id command
Normal mode (default)
Inverted display
Page 31
PM42 IPDU commands:
Chapter 3: Accessing the PM IPDU via the Command Line Interface 21
exit
Imanual
Push button toggles phase X, Y, Z and then the vector sum of the
three phases
Iauto <cycle_time>
Show current every <cycle_time> seconds of phase X, Y, Z and then
the vector sum of the three phases
Examples
To set the display of IPDU #2 to inverted mode, enter:
pm>display 2 180
To set the display of IPDU #1 to normal mode, enter:
pm>display 1 0
To set the display of IPDU #3 (PM42) to automatically show the current of each phase every two
seconds, enter:
pm>display 3 Iauto 2
To view the display status, enter:
pm>display
The exit command exits the session.
Syntax
exit
Arguments
none
Examples
To exit the current session, enter:
pm>exit
Page 32
22 Cyclades PM IPDU Installer/Administrator/User Guide
factory_defaults
The factory_defaults command resets the unit to its factory configuration. When used with a daisy
chain, and no argument is given, this command resets all units in the chain. This command is
available to the admin user only.
Syntax
factory_defaults [<IPDU#>|<IPDU_ID>]
Arguments
help
no argument
<IPDU#>
<IPDU_ID>
Resets all PM IPDUs in the daisy chain to factory default
Number of the PM IPDU in the chain
Identification string previously set by the id command
Examples
To reset the factory defaults, enter:
pm>factory_defaults 1
The help command displays the system help message for all commands or for a single command
when specified.
NOTE: When the admin user is logged in, the help command displays all commands. When a regular user is
logged in, the help command displays only the regular user commands.
Syntax
<command> help
Arguments
<command> Any available command
Examples
To view the system help message for a specific command, enter the command followed by
pm>syslog help
To view the system help message for all commands, enter:
pm>help
help.
Page 33
humidity
The humidity command displays the PM IPDU’s surrounding humidity and the maximum humidity
the IPDU has registered (humidity peak). It may also be used to clear the saved peak
humidity value.
Syntax
humidity [<IPDU#>|<IPDU_ID>]|reset
Arguments
Chapter 3: Accessing the PM IPDU via the Command Line Interface 23
Examples
To get the humidity for all units in a daisy chain, enter:
To get the humidity for specific unit, provide the unit number as an argument, enter:
To reset the maximum humidity registered, enter:
hwocp
The hwocp command checks the status of the hardware overcurrent protection. When overcurrent
protection is on, the power is shut off. When the overcurrent protection is off or reset, the power is
on and the PM IPDU is running in normal mode. If no string identifying the IPDU is given, all PM
IPDUs in the daisy chain are affected by this command. This command is available to the admin
user only.
<IPDU#>
<IPDU_ID>
reset
pm>humidity
pm>humidity 2
pm>humidity reset
IPDU number in a daisy chain
Identification string previously set by the id command
Resets the maximum humidity registered
Syntax
hwocp [<IPDU#>|<IPDU_ID> [reset]]
Page 34
24 Cyclades PM IPDU Installer/Administrator/User Guide
Arguments
id
<IPDU#>
<IPDU_ID>
reset
IPDU number in a daisy chain
Identification string previously set by the id command
Turns overcurrent protection off (normal operation)
Examples
To check the hardware overcurrent status of IPDU #1, enter:
pm>hwocp 1
To reset the hardware overcurrent protection, enter:
pm>hwocp 1 reset
The id command sets or displays the ID of a PM IPDU. A maximum of 16 characters (not case
sensitive) is allowed. Spaces, numbers and special characters are allowed. This command is
available to the administrator user only.
This command works in a daisy chain.
Syntax
id [<IPDU#>] [<IPDU_ID>]
-or-
id [<IPDU_ID>] [<IPDU_ID>]
-or-
id
Arguments
<IPDU#>
<IPDU_ID>
no argument
IPDU number in a daisy chain
Identification string previously set by the id command
Displays the IDs of all PM IPDUs in the daisy chain
If <IPDU_ID> follows <IPDU#>, or if the <IPDU_ID> parameter is typed twice, the latest entry
of the <IPDU_ID> parameter updates the ID string.
Page 35
Examples
To set the ID of PM IPDU 1 R&D, enter:
pm>id 1 R&D
To display the ID of PM IPDU 2, enter:
pm>id 2
To rename an ID to “sammy,” using an existing ID “QA,” enter:
pm>id QA sammy
To display the IDs of all PM IPDUs in the daisy chain, enter:
pm>id
interval
The interval command configures the time interval (in seconds) to turn on power for each outlet in
the system. This command is available to the admin user only.
Syntax
Chapter 3: Accessing the PM IPDU via the Command Line Interface 25
interval <outlet_number> <duration>
Arguments
<duration>
Sets the interval to turn on power to outlets. Valid intervals are
from 0 to 100. Default value is 0.5
NOTE: When this value is set to 0.0, there is still an interval of approximately 0.1 seconds between outlets to
receive power.
<outlet_number>
Outlet number, such as “5”, outlet name such as “sunfire”, or group
of outlets such as “1, 3-5”
Examples
To display the interval of outlet 1, enter:
pm>interval 1
To set the interval of outlets 2, 4, 5, and 6 to a value of 2.4, enter:
pm>interval 2,4-6 2.4
Page 36
26 Cyclades PM IPDU Installer/Administrator/User Guide
NOTE: The PM42 IPDU will not accept entries with decimal places.
list
For the admin user, the list command lists all users that have been created and the outlets assigned
to each of those users. For regular users, the list command lists only the outlets assigned to the user
currently logged in.
Syntax
list
Arguments
none
Examples
As admin, to list usernames and associated outlets in the internal database, enter:
pm>list
lock
The lock command locks an outlet or group of outlets in their current state. The response to this
command is a list of status lines, one per power port. This command works on all PM IPDUs in a
daisy chain.
name
Syntax
lock all|<outlet_string>
Arguments
<outlet_string> Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
Examples
To lock outlets 1, 2 and 6, enter:
pm>lock 1,2,6
The name command names an outlet. A maximum of 16 alphabetic and numeric characters (not
case sensitive) is allowed with these exceptions:
• The hyphen (-), percent (%), and comma (,) characters are not allowed.
• Numeric characters are not allowed as the first character of a name.
Page 37
Chapter 3: Accessing the PM IPDU via the Command Line Interface 27
This command is available to the administrator user only.
Syntax
name <outlet_number> <name>
Arguments
off
<outlet number>
<name>
Outlet number, such as “5”
Desired outlet name
Examples
To name outlet 4 as nowhere, enter:
pm>name 4 nowhere
The off command turns an outlet or group of outlets off. This command works on outlets in a PM
IPDU daisy chain.
Syntax
off all|<outlet_string>
Arguments
all
<outlet_string>
Turns off all outlets in the PM IPDU or PM IPDU daisy chain
Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
CAUTION: The “all” argument will turn off all outlets in a PM IPDU or PM IPDU daisy chain.
Examples
To turn all outlets off, enter:
pm>off all
To turn off outlets 2 through 7 (or all outlets except 1 and 10 in a single PM10 IPDU), enter
the following.
pm>off 2-9
Page 38
28 Cyclades PM IPDU Installer/Administrator/User Guide
on
The on command turns an outlet or a group of outlets on. If more than one outlet is selected there
will be an interval between outlets being powered on. The interval is defined by the interval
command. This command works on outlets in a PM IPDU daisy chain.
Syntax
on all|<outlet_string>
Arguments
all
<outlet_string>
Examples
To turn on outlets 1, 3, 4 and 5, type:
pm>on 1, 3-5
passwd
The passwd command sets a password. Regular users may change or set their own password only.
The Administrator may change his or her own password or any regular user’s password.
Syntax
passwd <user_name>
Arguments
<user_name>
no argument
Examples
To change the password for user alpha, when logged in as admin, enter:
Turns off all outlets in the PM IPDU or PM IPDU daisy chain
Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
Name of the user whose password is being changed
To change the current user’s password
reboot
pm>passwd alpha
Passwords may be set to null, which indicates that no password is needed.
The reboot command reboots a PM IPDU. You may reboot a specific unit by issuing the reboot
command followed by the unit’s logical number or the unit’s ID. Issuing the reboot command
Page 39
Chapter 3: Accessing the PM IPDU via the Command Line Interface 29
without a parameter reboots the first unit in a chain, not all the units in a chain. This command is
available to the admin user only.
Syntax
reboot [<IPDU#>|<IPDU_ID>]
Arguments
Examples
To reboot the first unit of the chain, or to reboot the unit in standalone mode, enter:
To reboot the a specific IPDU in the chain (IPDU 2 shown), enter:
restore
The restore command restores the configuration currently saved in Flash. This command is
available to the admin user only.
Syntax
restore
Arguments
N/A
Examples
<IPDU#>
<IPDU_ID>
pm>reboot
pm>reboot 2
IPDU number in a daisy chain
Identification string previously set by the id command
save
To restore the configuration currently saved in Flash, enter:
pm>restore
The save command saves the current configuration in the Flash device built in to all PM IPDU
units. This command saves the username/password database and the specific information
pertaining to each outlet such as outlet name, outlet assignments and outlet state. This command is
available to the admin user only.
Page 40
30 Cyclades PM IPDU Installer/Administrator/User Guide
If you save your configuration to Flash it will be restored after the next reboot. If you do not save
your configuration to Flash, you will lose it all after the next reboot.
Syntax
save
Arguments
none
Examples
To save the configuration to Flash, enter:
pm>save
status
The status command displays the status of selected outlets.
Syntax
status all|<outlet_string>
Arguments
Examples
To display the status of outlet 1, enter:
To display the status of all outlets, enter:
syslog
The syslog command displays or changes the syslog notification status. This command is available
to the admin user only.
Syntax
syslog on|off|status
<outlet_string>
all
pm>status 1
pm>status all
Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
Displays the status of all outlets in a PM IPDU or PM IPDU daisy chain
Page 41
Arguments
Chapter 3: Accessing the PM IPDU via the Command Line Interface 31
on
off
status
no argument
Examples
To get the current status of the syslog notification, enter:
pm>syslog
To turn on and off the syslog notification, enter as necessary:
pm>syslog on
pm>syslog off
temperature
The temperature command displays the PM IPDU’s surrounding temperature and the maximum
temperature the unit has registered (temperature peak). It may also be used to clear the saved peak
temperature value.
Syntax
Enables message to be displayed in the console when there is an over
current situation
Disables the message notification
Displays the current syslog status of all PM IPDUs on the daisy chain
Same as status
temperature [<IPDU#>|<IPDU_ID>]|reset
Arguments
<IPDU#>
<IPDU_ID>
reset
IPDU number in a daisy chain
Identification string previously set by the id command
Resets the maximum temperature registered
Examples
To get the temperature for all units in a daisy chain, enter:
pm>temperature
Page 42
32 Cyclades PM IPDU Installer/Administrator/User Guide
To get the temperature for specific unit, provide the unit number as an argument, enter
the following.
pm>temperature 2
To reset the maximum temperature registered and use reset as an argument, enter:
pm>temperature reset
unassign
The unassign command removes the assignment of an outlet or group of outlets from a given user.
This command is available to the admin user only.
Syntax
unassign <outlet_string> <user>
Arguments
Examples
To unassign outlet 2 and 4 from user diderot, enter:
unlock
The unlock command unlocks an outlet or group of outlets in the current state. The response to this
command is a list of status lines, one per power port.
Syntax
unlock all|<outlet_string>
<outlet_string>
<user>
pm>unassign 2,4 diderot
Outlet number, such as “5”, outlet name such as “sunfire”, or group
of outlets such as “1, 3-5”
Desired username
Page 43
Arguments
Chapter 3: Accessing the PM IPDU via the Command Line Interface 33
<outlet_string>
all
Examples
To unlock outlets 2, 3, 4 and 8, enter:
pm>unlock 2-4,8
upgrade
The upgrade command is available only to the administrator. You may either upgrade or boot
the firmware.
NOTE: For details on upgrading using the upgrade command or using the reboot command, see Upgrading the
PM IPDU firmware on page 11.
Syntax
upgrade <IPDU#>|<IPDU_ID>
Arguments
<IPDU#>
<IPDU_ID>
Outlet number, such as “5”, outlet name such as “sunfire”, or group of
outlets such as “1, 3-5”
Unlocks all outlets in the PM IPDU or PM IPDU daisy chain
IPDU number in a daisy chain
Identification string previously set by the id command
ver
If you wish to upgrade more than one IPDU, it is recommended that you upgrade the most remote
IPDU first.
Examples
To upgrade IPDU 1, type:
pm>upgrade 1
The ver command shows the current software version and hardware model information of the
selected PM IPDU.
Syntax
ver [<IPDU#>|<IPDU_ID>]
-or-
Page 44
34 Cyclades PM IPDU Installer/Administrator/User Guide
ver
Arguments
<IPDU#>
<IPDU_ID>
no argument
Examples
To view the current software version of all IPDUs in a daisy chain, enter:
pm>ver
NOTE: If an IPDU has an id assigned to it, the ver command displays the word “id” followed by the name of the
IPDU and the model number of the PM IPDU.
To get this information for a specific unit, provide the unit number as an argument.
pm>ver 2
voltage
The voltage command shows the true RMS voltage between two phases.
Syntax
voltage [<IPDU#>|<IPDU_ID> [AB|AC|BC]]
IPDU number in a daisy chain
Identification string previously set by the id command
Displays version information for the PM IPDU and for all PM IPDUs in a
daisy chain
Arguments
<IPDU#>
<IPDU_ID>
XY|YZ|XZ
no argument
IPDU number in a daisy chain
Identification string previously set by the id command
Phases to select
Displays the RMS voltage on all units if voltage sensors are available
Examples
To view the RMS voltage on a PM42 IPDU across phases X and Y, enter:
pm>voltage 1 XY
Page 45
whoami
The whoami command shows the username of the user currently logged in.
Syntax
whoami
Arguments
none
Examples
To view the current username, enter:
Chapter 3: Accessing the PM IPDU via the Command Line Interface 35
pm>whoami
Page 46
36 Cyclades PM IPDU Installer/Administrator/User Guide
Page 47
APPENDICES
Appendices
Appendix A: Specifications
Table A.1: PM IPDU Specifications
37
Unit
PM10-15A 100-125 VAC 15A (12A) 15A (12A) 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10-20A,
PM10-L20A
PM10-L30A 100-125 VAC 30A (24A) 15A (12A) 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10i-10A 100-240 VAC 10A 10A 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10i-15A 100-240 VAC 15A (12A) 10A (8A) 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10i-16A 100-240 VAC 16A 10A 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10i-20A 100-240 VAC 20A (16A) 10A (8A) 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
PM10i-32A,
PM10i-32Au
PM10i-L30A 100-240 VAC 30A (24A) 10A (8A) 0-50 ºC 5.45 kg 17 in 11.5 in 1.75 in
PM20-20A,
PM20-L20A
PM20-L30A 100-125 VAC 30A (24A) 15A (12A) 10-50 ºC 7.73 kg 1.8 in 2.2 in 66 in
PM20i-16A 100-240 VAC 16A 10A 0-50 ºC 7.73 kg 2 in 2.8 in 66 in
PM20i-20A,
PM20i-L20A
Input
Voltage
100-125 VAC 20A (16A) 15A (12A) 10-50 ºC 3.64 kg 17 in 8 in 1.75 in
100-240 VAC 32A 10A 0-50 ºC 5.45 kg 17 in 11.5 in 1.75 in
100-125 VAC 20A (16A) 15A (12A) 10-50 ºC 7.73 kg 1.8 in 2.2 in 66 in
100-240 VAC 20A (16A) 10A (8A) 0-50 ºC 7.73 kg 2 in 2.8 in 66 in
Max Output
Current
Max Output
Each Outlet
Operating
Temp Weight Width Depth Height
PM20i-L30A 100-240 VAC 30A (24A) 10A (8A) 0-50 ºC 7.73 kg 2 in 2.8 in 66 in
PM20i-32A 100-240 VAC 32A 10A 10-50 ºC 7.73 kg 2 in 2.8 in 66 in
Page 48
38 Cyclades PM IPDU Installer/Administrator/User Guide
Table A.2: PM42 IPDU Specifications
Characteristics
Electrical
Input Voltage Three phases, phase to phase 208 VAC
Max Input Current 24A
Max Output Current Total 16A on any single bank (XY, YZ or XZ)
Max Output Current Each Outlet 42 - IEC320-C13: 12A at 208 VAC (42 places)
Environmental
Operating Temperature 0-50ºC
Mechanical
Weight 10.89 kg
Physical Dimensions (W x D x H) 2.2 x 2.5 x 72.0 in
Interface Pinouts
Table A.3: Pinouts for IN and OUT RS-232 Serial Ports
Signal Name/Function I/O IN Pin OUT Pin
RTS Request to Send (O) 5 1
-or-
13.8A evenly distributed on each bank (XY, YZ or XZ)
NOTE: Maximum allowed current in any bank is limited to 16A
although the maximum of 24A input current per phase must not be
exceeded. If equal loads are provided to all banks then, in order to
have this maximum input current of 24A, the maximum allowed
current per bank will have to be decreased to 13.8A.
DTR Data Terminal Ready (O) 7 2
TxD Transmit Data (O) 6 3
Gnd Ground N/A 4 4
CTS Clear to Send (I) 1 5
RxD Receive Data (I) 3 6
DCD Data Carrier Detect (I) 2 7
Page 49
Appendix B: Safety Instructions
Follow the safety precautions in this document when installing and operating the PM IPDU.
Safety Instructions
Read all the following safety guidelines to protect yourself and your Cyclades PM.
DANGER! All outlets of the PM IPDU output high voltage. Necessary precautions should be taken.
DANGER! T o help prevent electric shock, plug the PM IPDU into a properly grounded power source. The power
cord is equipped with a three-prong plug to help ensure proper grounding. Do not use adaptor plugs or remove
the grounding prong from the cable. Do not use extension cords with the PM IPDU.
DANGER! Do not push any objects through the openings of the PM IPDU. Doing so may cause fire or electric
shock by shorting out interior components.
DANGER! There is a possibility of severe electrical shock from either the live or neutral side of any of the power
outlets or their wiring, even if one of the circuit breakers is disabled.
IMPORTANT: PM IPDU is intended for enterprise and indoor use only.
IMPORTANT: To help protect the PM IPDU from electrical power fluctuations, use a surge suppressor, line
conditioner, or uninterruptible power supply.
Appendices 39
IMPORTANT: Be sure that nothing rests on the cables of the PM IPDU and that they are not located where they
may be stepped on or tripped over.
IMPORTANT: Do not spill food or liquids on the PM IPDU. If it gets wet, disconnect the power immediately and
contact Avocent.
IMPORTANT: Keep your PM IPDU away from heat sources.
Sicherheitsanweisungen
Bitte lesen und befolgen Sie diese Sicherheitsrichtlinien um sich und Ihren PM IPDU vor Schäden
zu bewahren.
GEFAHR! Alle Ausgänge des PM IPDU führen Hochspannung. Bitte die erforderlichen Vorsichtsmaßnahmen
einhalten.
GEFAHR! Um elektrische S tromschläge zu vermeiden, verbinden Sie bitte das Eingangskabel des PM IPDU mit
einer ausreichend geerdeten Stromversorgung. Das Netzkabel ist mit drei Leitungen versehen um korrekte
Erdung zu ermöglichen. Bitte benutzen Sie keine Adapterstecker und entfernen Sie nicht die Erdungsleitung.
Bitte verwenden Sie keine Verlängerungskabel.
GEFAHR! Bitte führen Sie keine Gegenstände in die Öffnungen des PM IPDU ein. Dies könnte zu Bränden oder
elektrischen Schock durch Kurzschluss der internen Komponenten führen.
Page 50
40 Cyclades PM IPDU Installer/Administrator/User Guide
GEFAHR! Auch nach Öffnung einer der beiden Sicherungen kann das Gerät noch unter Spannung über die
Phasen- oder Nullleiterzufuhr stehen.
Wichtig: Der PM IPDU ist für den Unternehmenseinsatz und den Gebrauch innerhalb von abgeschlossenen
Gebäuden vorgesehen.
Wichtig: Um den PM IPDU vor elektrischen Spannungsschwankungen zu schützen empfehlen wir den Einsatz
von Überspannungsreglern, Spannungsglättern oder USVs.
Wichtig: Bitte stellen Sie sicher, daß keine Gegenstände auf den Kabeln des PM IPDU liegen und die Kabel so
geführt sind, daß niemand darauf treten oder darüber stolpern kann.
Wichtig: Bitte schütten Sie keine Nahrungsmittel oder Flüssigkeiten auf den PM IPDU. Falls das Gerät naß
werden sollte trennen Sie bitte sofort die Netzverbindung und kontaktieren Avocent.
Wichtig: Bitte halten Sie Ihren PM IPDU vor Hitzequellen entfernt.
Istruzioni di Sicurezza
Vi preghiamo di attenervi alle seguenti direttive per la vostra sicurezza e un sicuro utilizzo
dell'PM IPDU.
PERICOLO! Tutte le prese dell'PM IPDU sono sotto alta tensione. Occorre prendere precauzioni.
PERICOLO! Per evitare di prendere la scossa, inserire la spina dell'PM IPDU nell'appropriata presa a terra.
L'alimentatore è equipaggiato con una spina a tre poli per assicurare un corretto collegamento. Non utilizzare
adattatori e non rimuovere la spina a tre poli dal cavo. Non utilizzare prolunghe.
PERICOLO! Non inserire oggetti nelle aperture dell'PM IPDU. Farlo potrebbe causare un incendio o
danneggiare i componenti interni.
PERICOLO! C'è la possibilità che la fase o la terra rimanga sotto tensione anche se uno degli interruttori è
disattivato.
Importante: Le PM IPDU è certificato per uso aziendale e solamente in luogo chiuso.
Importante: Per proteggere le PM IPDU da fluttuazioni di corrente elettrica, utilizzare un limitatore di
sovracorrente, un condizionatore di linea, o un gruppo di alimentazione continua, UPS.
Importante: Assicurarsi che niente giaccia sui cavi dell'PM IPDU e che questi non causino intralcio al passaggio.
Importante: Non versare cibo o liquidi sull'PM IPDU. Nel caso l'apparecchiatura si bagnasse, togliere
immediatamente l'alimentazione e contattare Avocent.
Importante: Tenere lontano da fonti di calore.
Page 51
Instruções de Segurança
Leia e siga as diretrizes de segurança abaixo para sua proteção e de seu PM IPDU.
PERIGO! Alta voltagem está presente em todas as tomadas do PM IPDU. As devidas precauções devem ser
tomadas.
PERIGO! Para evitar choques elétricos, conecte o PM IPDU a uma tomada devidamente aterrada. O cabo de
força possui uma tomada com três pinos para ajudar a garantir que o devido aterramento seja feito. Não use
adaptadores nem remova o pino de aterramento da tomada. Não use extensões para conexão elétrica com o
PM IPDU.
PERIGO! Não introduza objetos pelas aberturas existentes no PM IPDU. O curto-circuito de componentes
internos pode fazer com que o produto pegue fogo e causar choques elétricos.
PERIGO! É possível que haja tensão presente nos circuitos de fase ou neutro mesmo que um dos dispositivos
de proteção contra sobrecorrente esteja atuando.
Importante: O PM IPDU é destinado exclusivamente ao uso comercial em ambientes fechados.
Importante: Para ajudar a proteger o PM IPDU contra conseqüências nocivas causadas por flutuações na rede
elétrica, use um estabilizador, filtro ou baterias que evitem eventual interrupção no fornecimento de energia.
Importante: Garanta que não haja nenhum objeto sobre os cabos do PM IPDU e que eles não estejam em
locais de transito de pessoas para que não sejam pisados e para que não causem quedas ou acidentes.
Appendices 41
Importante: Não derrame alimentos ou líquidos sobre o PM IPDU. Se o produto for molhado, disconete-o da
tomada imediatamente e entre em contato com a Avocent.
Importante: Mantenha o PM IPDU longe de fontes de calor.
Instrucciones de seguridad
Lea y siga estas pautas de seguridad para protegerse a usted y a su PM IPDU.
¡PELIGRO! Todos los enchufes de salida PM IPDU tienen alto voltaje. Se deben tomar las
precauciones necesarias.
¡PELIGRO! Para ayudar a prevenir descargas eléctricas, conecte el PM IPDU en una fuente de energía
correctamente puesta a tierra. El cable eléctrico está equipado de un enchufe del tres conectores para ayudar a
asegurar la puesta a tierra apropiadamente. No utilice adaptadores de enchufe, ni quite el conector de tierra. No
utilice extensores con el PM IPDU.
¡PELIGRO! No empuje ningun objeto en las aberturas del PM IPDU. El hacerlo puede causar fuego o descargas
eléctricas poniendo en cortocircuito los componentes interiores.
Page 52
42 Cyclades PM IPDU Installer/Administrator/User Guide
¡PELIGRO! Existe la posibilidad de tensión en cualquier conector del PM IPDU, incluso si uno de los
interruptores esta desabilitado.
Importante: El PM IPDU se piensa para la empresa y el uso de interior solamente.
Importante: Para ayudar a proteger el PM IPDU contra fluctuaciones de la corriente eléctrica, utilice un
supresor de fluctuaciones, acondicionador de línea, o fuente de alimentación ininterrumpida.
Importante: Asegurese que nada se apoya sobre los cables del PM IPDU y que no están localizados donde
puedan ser pisados cuando esten encendidos.
Importante: No derrame alimentos o líquidos en el PM IPDU. Si se hubiera mojado, desconecte la energía
inmediatamente y entre en contacto con Avocent.
Importante: Mantenga su PM IPDU lejos de fuentes de calor.
Instructions de sécurités
Lisez et suivez les instructions de sécurité pour votre protection et celle ce le PM IPDU.
DANGER! Toutes les prises de l'PM produisent une tension électrique élévée. Prenez les précautions d'usage.
DANGER! Pour aider à éviter tout choc électrique, branchez l'PM IPDU à une source électrique correctement
liée à la terre. Le cordon électrique est équipé d'une prise à 3 broches pour aider à assurer une connexion
correcte avec la terre. N'utilisez pas d'adaptateurs ou n'enlevez pas la broche de la terre du cable. N'utilisez pas
de rallonge électrique avec l'PM IPDU.
DANGER! Ne pas faire passer aucun objets à travers les ouvertures de l'PM IPDU. Le faire peut causer un feu
ou des chocs électriques en court-circuitant des composants interne.
DANGER! Il y a une possiblité de présence de courant pour la Phase et le Neutre même si l'un des relais
électrique est désactivé.
Important: L'PM IPDU est prévu pour les entreprises dans un usage à l'intérieur seulement.
Important: Pour aider à protéger l'PM IPDU des fluctuations d'alimentation électrique, utilisez un filtre de
surtension, un conditioneur de ligne ou une source d'alimentation qui ne peut pas être interrompue.
Important: Soyez sûr que rien ne repose sur les cables de l'PM IPDU, qu'ils ne sont pas sur un lieu de passage,
qu'ils ne peuvent pas être piétiné et que l'on ne peut pas trébucher dessus.
Important: Ne reversez pas de nourriture ou de liquides sur le PM IPDU. Si elle est humide, deconnectez
l'alimentation électrique immédiatement et contactez Avocent.
Important: Gardez l'PM IPDU à distance des sources de chaleur.
Page 53
Appendix C: Circuit Breakers
The PM IPDU circuit breakers are designed to turn the power off to some or all of the PM IPDU
outlets in case the rated current is exceeded. The circuit breaker mechanism for each PM IPDU
model is explained the in the following sections.
PM IPDU Units with One Circuit Breaker
Only one circuit breaker is used for the following units:
• PM10-15A IPDU
• PM10-20A IPDU
• PM10-L20 IPDU
• PM20-20A IPDU
• PM20-L20 IPDU
• PM20i-16A IPDU
• PM20i-20A IPDU
In the event of a current overload in any of these units, the entire unit shuts down, causing all
outlets to disconnect.
NOTE: The PM42 IPDU has two UL listed fuses on each phase bank that are not replaceable. There is also a
sensor circuit that acts as a backup by monitoring total current and resetting all receptacle relays in the event of
a current overage.
Appendices 43
PM10i IPDU
Some versions of the PM10i IPDU (10, 15, 16 and 20 amps) have two circuit breakers each. Both
circuit breakers are designed to protect different phases of the same circuit inside the unit. If either
one of the two circuit breakers trips, the entire unit will shut down.
PM10-L30A IPDU
The PM10-L30A IPDU has two 15-amp circuit breakers. The first circuit breaker controls outlets 1
through 5 and the power supply to the controller; the second circuit breaker controls outlets 6
through 10. If the total current flow to outlets 6 through 10 exceeds 15 amps due to equipment
connected to these outlets, then the second circuit breaker will trip causing outlets 6 through 10 to
shut down. This does not affect outlets 1 through 5, which are controlled by the first circuit breaker.
If, however, current overload causes the first circuit breaker to trip, then the entire power unit shuts
down because the power supply is also tied to the first circuit breaker.
Refer to Table C.5 to determine the time it takes for the circuit breaker to trip based on the amount
of current overload.
Page 54
44 Cyclades PM IPDU Installer/Administrator/User Guide
12345 678910
12
34
56
Figure C.1: PM10-L30A IPDU Circuit Breakers
Table C.1: PM10-L30A IPDU Circuit Breakers Descriptions
Number Description Number Description
1 Controller 4 15A to Outlets 6 - 10
2 Power Supply 5 First Circuit Breaker
3
15A to Outlets 1 - 5 and to the Controller
and Power Supply
PM10i-L30A IPDU
The PM10i-L30A IPDU has two 15-amp circuit breakers. The first circuit breaker controls outlets 6
through 10; the second controls outlets 1 through 5. In the event that the total current flow to outlets
6 through 10 exceeds 15 amps due to equipment connected to these outlets, the first circuit breaker
will trip causing outlets 6 through 10 to shutdown. This does not affect outlets 1 through 5, which
are controlled by the second circuit breaker.
The PM IPDU controller is installed so that tripping either or both breakers will not render
it inoperative.
When either circuit breaker trips, only the power outlets of that segment will be affected, and half
of the outlets remain operative.
6 Second Circuit Breaker
Page 55
Appendices 45
12345 678910
12
34
56
7
Figure C.2: PM10i-L30A IPDU Circuit Breakers
Table C.2: PM10i-L30A IPDU Circuit Breakers Descriptions
Number Description Number Description
1 Controller 5 First Circuit Breaker
2 Power Supply 6 Second Circuit Breaker
3 15A to Outlets 1 - 5 7 Independent Power to Controller
4 15A to Outlets 6 - 10
PM10i-32A IPDU and PM10i-32Au IPDU
The PM10i-32A has two 16-amp circuit breakers. The first circuit breaker controls outlets 6
through 10; the second controls outlets 1 through 5. In the event that the total current flow to outlets
6 through 10 exceeds 16 amps due to equipment connected to these outlets, the first circuit breaker
will trip causing outlets 6 through 10 to shutdown. This does not affect outlets 1 through 5, which
are controlled by the second circuit breaker.
The PM IPDU controller is installed so that tripping either or both breakers will not render
it inoperative.
When either circuit breaker trips, only the power outlets of that segment will be affected, and half
of the outlets remain operative.
PM20-L30A IPDU
The PM20-L30A IPDU has two 15-amp circuit breakers. The first circuit breaker controls outlets
11 through 20; the second controls outlets 1 through 10 as well as the power supply to the logic
board. In the event that the total current flow to outlets 11 through 20 exceeds 15 amps due to
equipment connected to these outlets, then the first circuit breaker will trip causing outlets 11
through 20 to shutdown. This does not affect outlets 1 through 10 which are controlled by the
second circuit breaker.
Page 56
46 Cyclades PM IPDU Installer/Administrator/User Guide
12
34
56
12345678910 11121314151617181920
If, however, current overload causes the second circuit breaker to trip, then the entire power unit
shuts down because the power supply is also tied to the second circuit breaker.
Refer to Table C.5 to determine the time it takes for the circuit breaker to trip based on the amount
of current overload.
Figure C.3: PM20-L30A IPDU Circuit Breakers
Table C.3: PM10i-L30A IPDU Circuit Breakers Descriptions
Number Description Number Description
1 Controller 4 15A to Outlets 11 - 20
2 Power Supply 5 First Circuit Breaker
3
PM20i-L30A IPDU
The PM20i-L30A IPDU has two 15-amp circuit breakers. The first circuit breaker controls outlets
11 through 20; the second controls outlets 1 through 10. In the event that the total current flow to
outlets 11 through 20 exceeds 15 amps due to equipment connected to these outlets, then the first
circuit breaker will trip causing outlets 11 through 20 to shutdown. This does not affect outlets 1
through 10 which are controlled by the second circuit breaker.
The PM IPDU controller is installed so that tripping either or both breakers will not render
it inoperative.
When either circuit breaker trips, only the power outlets of that segment will be affected, and half
of the outlets remain operative.
15A to Outlets 1 - 10 and to the Controller
and Power Supply
6 Second Circuit Breaker
Page 57
Appendices 47
12
34
56
7
12345678910 11121314151617181920
Figure C.4: PM20i-L30A IPDU, PM20i-32A IPDU and PM20i-32Au IPDU Circuit Breakers
Table C.4: PM10i-L30A IPDU Circuit Breakers Descriptions
Number Description Number Description
1 Controller 5 First Circuit Breaker
2 Power Supply 6 Second Circuit Breaker
3 15A to Outlets 1 - 10 7 Independent Power to Controller
4 15A to Outlets 11 - 20
PM20i-32A IPDU and PM20i-32Au IPDU
The PM20i-32A IPDU and the PM20i-32Au IPDU have two 16-amp circuit breakers. The first
circuit breaker controls outlets 11 through 20; the second controls outlets 1 through 10. In the event
that the total current flow to outlets 11 through 20 exceeds 16 amps due to equipment connected to
these outlets, the first circuit breaker will trip causing outlets 11 through 20 to shutdown. This does
not affect outlets 1 through 10 which are controlled by the second circuit breaker.
As the PM20i-32A IPDU and the PM20i-32Au IPDU have the controller powered from the line
side of one of the circuit breakers, the whole unit will become inoperative only when both circuit
breakers trip; however, the controller will remain functioning.
When either circuit breaker trips, only the power outlets of that segment will be affected, and half
of the outlets remain operative.
Page 58
48 Cyclades PM IPDU Installer/Administrator/User Guide
Circuit breaker trip time
Depending on the model, the PM IPDU uses either one 10 amp, one 20 amp, two 15 amp, or two 16
amp circuit breakers. Table C.5 shows the circuit breaker trip time for all PM IPDU mod els except
the PM42 IPDU.
Table C.5: Circuit Breaker Trip Time
Current Load Trip Time
200% 5-30 seconds
300% 1.8-10 seconds
400% 0.9-5 seconds
500% 0.5-3.3 seconds
600% 0.38-2.3 seconds
800% 0.2-1.3 seconds
1000% 0.15-0.9 seconds
Table C.6: PM42 IPDU Shutdown Time
Current Load Complete Shutdown Time
> 32A on any single phase 3.5 seconds
CAUTION: Do not pull a plug with a live electrical load from an outlet on the PM IPDU. This can cause damage
to your equipment. The off command provides a means to safely turn off the power to the selected outlet before
pulling the plug from the outlet.
Page 59
Appendix D: Technical Support
Our Technical Support staff is ready to assist you with any installation or operating issues you
encounter with your Avocent product. If an issue should develop, follow the steps below for the
fastest possible service.
To resolve an issue:
1. Check the pertinent section of this manual to see if the issue can be resolved by following the
procedures outlined.
2. Check our web site at www.avocent.com/support to search the knowledge base or use the
online service request.
3. Call the Avocent Technical Support location nearest you.
Appendices 49
Page 60
50 Cyclades PM IPDU Installer/Administrator/User Guide
Page 61
Page 62
For Technical Support:
www.avocent.com/support
Avocent Corporation
4991 Corporate Drive
Huntsville, Alabama 35805-6201 USA
Tel: +1 256 430 4000
Fax: +1 256 430 4031
Avocent Asia Pacific
Singapore Branch Office
100 Tras Street, #15-01
Amara Corporate Tower
Singapore 079027
Tel: +656 227 3773
Fax: +656 223 9155
Avocent Canada
20 Mural Street, Unit 5
Richmond Hill, Ontario
L4B 1K3 Canada
Tel: +1 877 992 9239
Fax: +1 877 524 2985
590-667-501B
Avocent International Ltd.
Avocent House, Shannon Free Zone
Shannon, County Clare, Ireland
Tel: +353 61 715 292
Fax: +353 61 471 871
Avocent Germany
Gottlieb-Daimler-Straße 2-4
D-33803 Steinhagen
Germany
Tel: +49 5204 9134 0
Fax: +49 5204 9134 99
Loading...
