AVerVision F70W
User Manual
Federal Communications Commission Statement(Class A)
NOTE- This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Class A ITE:
Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE limits. Such equipment should not be restricted in its sale but the following warning shall be included in the instructions for use:
Warning - This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
CE Class A (EMC)
This product is herewith confirmed to comply with the requirements set out in the Council Directives on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility Directive 2014/30/EU.
Warning - This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures to correct this interference.
DISCLAIMER
No warranty or representation, either expressed or implied, is made with respect to the contents of this documentation, its quality, performance, merchantability, or fitness for a particular purpose. Information presented in this documentation has been carefully checked for reliability; however, no responsibility is assumed for inaccuracies. The information contained in this documentation is subject to change without notice.
In no event will AVer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.
TRADEMARKS
“AVer” is a trademark owned by AVer Information Inc. Other trademarks used herein for description purpose only belong to each of their companies.
COPYRIGHT
©2015 AVer Information Inc. All rights reserved.
All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or specifications are subject to change without prior notice.
NOTICE
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. THE INFORMATION CONTAINED HEREIN IS TO BE CONSIDERED FOR REFERENCE ONLY.
WARNING
TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE . WARRANTY VOID FOR ANY UNAUTHORIZED PRODUCT MODIFICATION .
THE MARK OF CROSSED-OUT WHEELED BIN INDICATES THAT THIS PRODUCT MUST NOT BE DISPOSED OF WITH YOUR OTHER HOUSEHOLD WASTE. INSTEAD, YOU NEED TO DISPOSE OF THE WASTE EQUIPMENT BY HANDING IT OVER TO A DESIGNATED COLLECTION POINT FOR THE RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT. FOR MORE INFORMATION ABOUT WHERE TO DROP OFF YOUR WASTE EQUIPMENT FOR RECYCLING, PLEASE CONTACT YOUR HOUSEHOLD WASTE DISPOSAL SERVICE OR THE SHOP WHERE YOU PURCHASED THE PRODUCT.
Remote Control Battery Safety Information
-Store batteries in any cool & dry place.
-Do not dispose used batteries in domestic waste. Dispose batteries at special collection points or return to stores if applies.
-Remove the batteries if they are not in use for long period of time. Battery leakage and corrosion can damage the remote control, dispose batteries safely.
-Do not mix and use old and new batteries.
-Do not mix and use different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
-Do not dispose batteries in a fire.
-Do not attempt to short circuit the battery terminals.
Table of Contents |
|
Package Contents ........................................................................................................... |
1 |
Optional Accessories ..................................................................................................... |
1 |
Get Familiar with the AVerVision F70W......................................................................... |
2 |
Right Panel.............................................................................................................. |
3 |
Rear Panel .............................................................................................................. |
3 |
Left Panel ................................................................................................................ |
4 |
Control Panel........................................................................................................... |
5 |
Remote Control ....................................................................................................... |
7 |
Making the Connections ........................................................................................ |
10 |
Set the TV-RGB Switch Setting ............................................................................. |
10 |
Connect to a Monitor or LCD/DLP Projector with HDMI Output interface.............. |
10 |
Connect to a TV..................................................................................................... |
11 |
Connecting the Power ........................................................................................... |
11 |
Connect to a Computer via USB............................................................................ |
12 |
Connect to a Computer with HDMI Input interface ................................................ |
12 |
Connect an External Microphone .......................................................................... |
13 |
Connect an Amplified Speaker .............................................................................. |
13 |
Connect to a Microscope....................................................................................... |
14 |
Connect F70W to WLAN ............................................................................................... |
15 |
Toggling between WiFi mode and USB to PC Mode .................................................. |
17 |
Connect F70W with a Tablet Device ............................................................................ |
17 |
Setting Up AVerVision F70W ........................................................................................ |
19 |
Storing and Handling ............................................................................................. |
19 |
Shooting Area........................................................................................................ |
20 |
Overhead Light...................................................................................................... |
21 |
Infrared Sensor...................................................................................................... |
21 |
Mounting the F70W on a Flat Surface ................................................................... |
22 |
Anti-glare Sheet..................................................................................................... |
22 |
External Memory Storage ...................................................................................... |
23 |
Insert an SD Card............................................................................................. |
23 |
OSD MENU..................................................................................................................... |
24 |
Navigate the Menu and Submenu ......................................................................... |
25 |
Image .................................................................................................................... |
25 |
Brightness......................................................................................................... |
25 |
Contrast ............................................................................................................ |
25 |
Mode................................................................................................................. |
26 |
Effect................................................................................................................. |
26 |
Mirror ................................................................................................................ |
26 |
Advanced.......................................................................................................... |
26 |
Auto Image ....................................................................................................... |
26 |
Exposure .......................................................................................................... |
27 |
White Balance................................................................................................... |
27 |
Focus................................................................................................................ |
27 |
Presentation .......................................................................................................... |
28 |
Spotlight............................................................................................................ |
28 |
Visor.................................................................................................................. |
28 |
Split Screen ...................................................................................................... |
29 |
PIP.................................................................................................................... |
29 |
Timer................................................................................................................. |
30 |
Setting ................................................................................................................... |
30 |
Capture............................................................................................................. |
30 |
Resolution......................................................................................................... |
30 |
Quality .............................................................................................................. |
30 |
Type.................................................................................................................. |
31 |
Interval.............................................................................................................. |
31 |
Storage ............................................................................................................. |
31 |
73BFormat ........................................................................................................ |
31 |
USB to PC ........................................................................................................ |
31 |
Flicker ............................................................................................................... |
32 |
WiFi ....................................................................................................................... |
32 |
74BConnect ...................................................................................................... |
32 |
75BSelect AP.................................................................................................... |
32 |
77BEnter Password .......................................................................................... |
33 |
78BConnect AP ................................................................................................ |
33 |
Machine Name.................................................................................................. |
33 |
System .................................................................................................................. |
35 |
Language.......................................................................................................... |
35 |
Output Display .................................................................................................. |
35 |
Backup.............................................................................................................. |
35 |
Save Setting ..................................................................................................... |
35 |
Recall Setting.................................................................................................... |
35 |
Information........................................................................................................ |
36 |
Default .............................................................................................................. |
36 |
Playback................................................................................................................ |
37 |
Slide Show........................................................................................................ |
37 |
Interval.............................................................................................................. |
37 |
Slide Show Effect.............................................................................................. |
37 |
Current Storage ................................................................................................ |
37 |
Delete All .......................................................................................................... |
37 |
Transfer Captured Images/Videos to a computer .................................................. |
38 |
Technical Specifications............................................................................................... |
39 |
Image................................................................................................................ |
39 |
Optics ............................................................................................................... |
39 |
Compatibility ..................................................................................................... |
39 |
Power ............................................................................................................... |
39 |
Lighting ............................................................................................................. |
39 |
Input/Output ...................................................................................................... |
39 |
Dimension......................................................................................................... |
40 |
External Storage ............................................................................................... |
40 |
Using the RS-232 Interface........................................................................................... |
40 |
Connect to the Computer RS-232 ......................................................................... |
40 |
RS-232 Cable Specifications........................................................................................ |
40 |
RS-232 Transmission Specifications........................................................................... |
41 |
RS-232 Communication Format ............................................................................ |
41 |
RS-232 Send Command Table .............................................................................. |
42 |
RS-232 Get Command Table................................................................................. |
47 |
Troubleshooting............................................................................................................ |
48 |
Limited Warranty........................................................................................................... |
52 |
Package Contents
Make sure the following items are included in the package.
WiFi Dongle
USB Cable
|
Power Adapter (12V, 3A) |
|
* The power adapter will vary |
|
depending on the standard |
AVerVision F70W |
power outlet of the country |
where it is sold. |
Optional Accessories
Software & Manual CD
Remote Control (batteries included)
|
|
Microscope Adapter |
Carrying Bag |
Anti-glare Sheet |
(28mm & 34mm Rubber Coupler) |
1
Get Familiar with the AVerVision F70W
(1) |
|
|
(2) |
(4) |
|
(3) |
||
|
(5) |
(6) |
(7) |
(10) |
(8) |
(9) |
|
|
(fig. 1.1) |
Name |
Function |
||
(1) |
Camera head |
Contain the camera sensor. |
|
(2) |
Camera lens |
Focus the image in the camera. |
|
(3) |
LED light |
Provide light to enhance the lighting condition. |
|
(4) |
Flexible arm |
Provide adjustable viewing coverage. |
|
(5) |
Left panel |
Connections for RS-232, microphone, speaker, and reset button. |
|
(6) |
Control panel |
Easy access to various functions. |
|
(7) |
IR sensor |
Receive remote control commands. |
|
(8) |
Rear panel |
Connections for power, RCA external display device , WiFi dongle, |
|
HDMI input, HDMI output and USB to PC. |
|||
|
|
||
(9) |
Right panel |
Connections for the camera head holder, SD card, TV-RGB display |
|
output switch, and antitheft Kensington security lock compatible slot. |
|||
|
|
||
(10) |
Built-in MIC |
Record audio when recording video clip. The recorded sound will be |
|
|
|
in monophonic. |
|
2
Right Panel
(2)
(3)
(1) |
(4) |
(fig. 1.2)
Name |
Function |
||
(1) |
Camera Holder |
Hold the camera head for storage. |
|
(2) |
SD card slot |
Insert the SD card with the label facing up. |
|
(3) |
TV-RGB switch |
TV switch to output display video from RCA to HDMI OUT. |
|
(4) |
Antitheft Slot |
Attach a Kensington compatible security lock or antitheft device. |
|
Rear Panel
(1) |
|
|
(6) |
(2) |
(3) |
(4) |
(5) |
|
(fig. 1.3) |
||
|
|
|
|
Name |
Function |
|
|
(1) |
DC12V |
Connect the power adapter into this port. |
|
(2) |
WiFi Dongle port |
For WiFi dongle connection. |
|
(3) |
HDMI In port |
Connect an external HDMI source as an input via this port |
|
(4) |
HDMI Out port |
Output the video signal from the main system on an LCD monitor or |
|
LCD/DLP projector with HDMI interface using HDMI cable. |
|||
|
|
||
(5) |
TV Out port |
Connect the AVerVision F70W to any display device with TV output. |
Connect to a USB port of a computer with a USB cable and use
(6) Mini USB port AVerVision F70W as a USB camera or transfer the captured images from the memory source to computer.
3
Left Panel
(1)
(2)
(3)
(4) |
|
|
(fig. 1.4) |
|
Name |
Function |
||
(1) |
Reset |
Set system to standby mode. |
|
(2) |
MIC port |
Connect a 3.5mm plug microphone. The built-in mic will be disabled |
|
when an external MIC is connected to this port. |
|||
|
|
||
(3) |
Speaker port |
Connect to an amplified speaker to playback recorded audio & video |
|
clip. |
|||
|
|
||
(4) |
RS-232 port Reset |
The RS-232 jack is used to connect to computer serial port or to any |
|
control panel or for centralized control if desire. |
|||
|
|
||
4
Control Panel
(15) |
(16) |
(17) |
(18) |
(19) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(1) |
|
|
|
(7) |
|||
|
|
|
|
|||||
|
(2) |
|
|
|
(8) |
|||
|
(3) |
|
|
|
|
|
(9) |
|
|
|
|
|
|
||||
|
(4) |
|
|
|
(10) |
|||
|
(5) |
|
|
|
|
|
(11) |
|
|
|
|
|
|
||||
|
(6) |
|
|
|
(12) |
|||
|
|
|
|
|
|
(13) |
||
|
|
|
|
|||||
|
|
|
|
|
||||
|
|
|
|
|
(14) |
|||
|
|
|
|
|
|
|
|
(fig. 1.5) |
|
|
|
|
|
|
|
||
|
|
|
||||||
Name |
|
Function |
||||||
(1) |
POWER |
|
Turn the unit on/standby mode. |
|||||
(2) |
|
|
|
Switch between USB mode and WiFi mode. |
||||
|
|
|
|
|||||
(3) |
CAMERA / PC |
|
Switch the video signal between camera and computer from the |
|||||
|
|
|
|
HDMI IN port. |
||||
(4) |
|
|
|
Reduce the brightness of live view. |
||||
|
|
|
|
|||||
(5) |
LAMP |
|
Turn the overhead light on/off. |
|||||
(6) |
FREEZE/STOP |
|
- Pause or resume image display in Camera mode. |
|||||
|
|
|
- |
Stop audio & video playback in Playback mode. |
||||
(7) |
▲,▼,◄, & ► |
- |
Select options in OSD menu. |
|||||
-Use ▲&▼ to increase and decrease the video playback volume.
-Use ◄&► to play the video backward and forward.
-Move the Spotlight frame and Visor screen cover.
(8) |
MENU |
Open and exit the OSD menu. |
|
|
|
(9) |
RECORDING |
Start/Stop audio & video recording. Audio and video recording can be |
|||
|
|
saved on a SD card only. See ExternalUH |
Memory Storage.HU |
||
|
|
|
|
|
|
(10) |
|
- Adjust the focus automatically. |
|
|
|
|
|
- Make a selection in Playback mode and OSD menu. |
|||
|
|
- Start/Pause video playback. |
|
|
|
|
|
|
|
|
|
5
Name |
Function |
|||||
(11) |
CAP/DEL |
- Capture picture in Camera mode. In continuous capture mode, |
||||
|
|
|
|
|
press this button again to stop. |
|
|
|
|
|
- |
Delete the selected picture/video in Playback mode. |
|
(12) |
|
|
|
Increase the brightness of live view. |
||
|
|
|
||||
|
|
|
||||
(13) |
PLAYBACK |
View & playback captured still images and video files. |
||||
(14) |
|
|
|
Decrease the image magnification in camera and picture playback |
||
|
|
|
|
mode. |
||
(15) |
Power LED |
- Solid Red: Standby |
||||
|
indicator |
- Flashing Red: Power on |
||||
|
|
|
|
|||
|
|
|
|
- Solid Green: HDMI output |
||
|
|
|
|
- |
Solid Orange: TV output |
|
(16) |
|
|
(WiFi) |
- |
Flashing Orange: Search for Access Point |
|
|
|
|
|
- |
Solid Blue: Connected to Access Point |
|
|
|
|
|
- Flashing Blue: Camera can be accessed wirelessly now |
||
(17) |
|
|
|
Increase the image magnification in camera and picture playback |
||
|
|
|
|
mode. |
||
(18) |
|
|
(Battery) |
- |
Solid Green: Battery is over 40%. |
|
|
|
|
|
- |
Solid Orange: Battery is between 20~40%. |
|
|
|
|
|
- |
Solid Red: Battery is between 20 ~ 5%. |
|
|
|
|
|
- |
Flashing Red: Battery is lower than 5%. |
|
(19) |
|
|
(Charging) |
- |
Solid Red: Power plug is connected and battery is charging. |
|
|
|
|
|
- |
Solid Green: Battery is fully charged. |
|
|
|
|
|
- |
OFF: Power plug is not connected. |
|
6
.
Remote Control
The remote control requires two (2) “AAA” size batteries (supplied), make sure batteries are installed properly before use. You can access all the features of AVerVision F70W with the remote.
|
|
Name |
Function |
||
(1) |
|
(1) |
POWER |
Turn the unit on. |
|
(12) |
(2) |
CAMERA |
Camera mode displays the video signal |
||
(2) |
|||||
(13) |
|
|
from the built-in camera. |
||
(3) |
|
|
|||
(14) |
|
|
Start/Stop audio & video recording. |
||
(4) |
(3) |
RECORD |
|||
(15) |
|||||
(5) |
(16) |
|
|
Video recording can only be saved |
|
(6) |
(17) |
|
|
either in a SD memory card. |
|
|
|
Capture still image in Camera mode. In |
|||
(7) |
(18) |
(4) |
CAPTURE |
||
(8) |
(19) |
|
|
continuous capture mode, press this |
|
|
|
|
button again to stop. |
||
|
|
|
|
||
(9) |
|
(5) |
VISOR |
Call the Visor submenu. Visor covers |
|
|
(20) |
|
|
part of the presentation screen and allow |
|
(10) |
(21) |
|
|
presenter to reveal the material as |
|
|
|
desire. |
|||
|
|
|
|
||
(11) |
(22) |
|
|
In the Visor submenu, the following |
|
|
(23) |
|
|
options are available. |
|
(fig. 1.6)
|
|
ON/OFF – select to run/cancel the Visor. |
|||
|
|
Press |
to move to the next |
||
|
|
selection. |
|
|
|
|
|
Shade – set the opacity level of the |
|||
|
|
covered area. The shaded area will |
|||
|
|
completely turns black when it is set to |
|||
|
|
level 100. Press |
|
to move to the |
|
|
|
next selection. |
|
|
|
|
|
OK – press |
|
for the setting to take |
|
|
|
effect. If you select ON, upper part of |
|||
|
|
the presentation screen is slightly |
|||
|
|
exposed. Use the ▲,▼,◄, & ► buttons |
|||
|
|
to reveal more of the covered area; and |
|||
|
|
OFF will close the submenu. |
|||
|
|
To turn off Visor, press |
again. |
||
(6) |
ROTATE |
Rotate the image by 180° in Camera |
|||
|
|
mode and Playback mode. |
|||
(7) |
MENU |
Open and exit the OSD menu. |
|||
7
|
|
Name |
Function |
||
(1) |
|
(8) |
▲,▼,◄, & ► |
- |
Pan and zoom-in image (above digital |
|
(12) |
|
|
zoom level) in both live and playback |
|
(2) |
|
|
|
||
|
(13) |
|
|
mode. |
|
(3) |
|
|
|
||
|
(14) |
|
- |
Select options in OSD menu. |
|
(4) |
|
|
|||
(5) |
|
(15) |
|
- |
Use ▲&▼ to increase and decrease |
|
(16) |
|
|||
(6) |
|
(17) |
|
|
the video playback volume. |
|
|
- |
Use ◄&► to play the video |
||
(7) |
|
(18) |
|
||
(8) |
|
(19) |
|
|
backward and forward. |
|
|
|
- Move the Spotlight frame and Visor |
||
|
|
|
|
||
(9) |
|
(20) |
|
|
screen cover. |
|
|
AUTO FOCUS |
Adjust the focus automatically. |
||
(10) |
|
(9) |
|||
|
(21) |
ZOOM +/- |
Increase/decrease the image |
||
(11) |
|
(10) |
|||
|
(22) |
|
magnification in camera and picture |
||
|
|
(23) |
|
playback mode. |
|
|
|
(11) ZOOM RESET |
Reset zoom level to 100%. |
||
|
|
(12) |
PLAYBACK |
View the captured picture/video from |
|
|
|
|
|
the memory in 16-thumbnail images. |
|
|
(fig. 1.6) |
(13) |
PC 1/2 |
PC mode displays the video signal |
|
|
|
|
from the HDMI input port of F70W. |
||
|
|
|
|
||
(14) |
FREEZE / |
- |
Freeze live images. |
|
STOP |
- |
Stop video playback. |
(15) |
SPOTLIGHT |
Call the Spotlight submenu. Spotlight |
|
|
|
overlays a box frame on the |
|
presentation screen. You can adjust the box size and move it around.
In the Spotlight submenu, the following options are available.
ON/OFF – select to run/cancel the Spotlight. Press
to move to the
next selection.
Shade – set the opacity level of the area outside the box. The shaded area will completely turns black when it is set to
level 100. Press
to move to the next selection.
Color – select the Spotlight frame color. Press
to move to the next selection.
8
Name Function
(1) |
(12) |
|
(2) |
||
(13) |
||
(3) |
||
(14) |
||
(4) |
||
(15) |
||
(5) |
||
(16) |
||
(6) |
(17) |
|
(7) |
(18) |
|
(8) |
(19) |
|
|
||
(9) |
(20) |
|
|
||
(10) |
(21) |
|
(11) |
(22) |
|
|
(23) |
(15) |
SPOTLIGHT |
OK – press |
for the setting to take |
|
|
|
effect. If you select ON, the frame will |
||
|
|
appear and blink, use the ▲,▼,◄, & ► |
||
|
|
buttons to adjust the frame size and |
||
|
|
press |
to set the desired size; and |
|
|
|
OFF will close the submenu. |
|
|
|
|
To turn off Spotlight, press |
again. |
|
(16) |
SPLIT |
Divide the screen into two. One side |
||
|
SCREEN |
displays the live image from the built-in |
||
|
camera and the other side displays 8- |
|||
|
|
|||
|
|
thumbnail size picture/video from the |
||
|
|
memory. |
|
|
(17) MODE |
Select from 3 type of modes: |
|
||
|
|
Text - adjust the contrast along the |
||
|
|
edges making text appear more visible. |
||
|
|
Graphics - adjust the gradient of |
|
|
image. |
|
|
Microscope - automatically adjust |
(fig. 1.6) |
optical zoom for microscopic viewing. |
|
|
(18) TIMER |
Call the Timer submenu. Select to |
|
|
Start/Pause/Stop the timer countdown |
|
|
and set the timer duration. |
(19) |
|
- |
Make a selection in Playback mode |
|
|
|
and OSD menu. |
|
- |
Play/Pause video playback. |
|
(20) |
LAMP |
Turn the overhead light on/off. |
(21) |
BRIGHTNESS |
Adjust the brightness. |
|
+/- |
|
(22) |
DEFAULT |
Reset to factory default setting. |
(23) |
DEL |
Delete the selected picture/video in |
|
|
Playback mode. |
9
Making the Connections
Before making the connection, make sure the power of all devices are turned off. If you are not sure on where to connect, simply follow the illustrated connections below and also refer to the user manual of the device you are connecting the AVerVision F70W with.
Set the TV-RGB Switch Setting
The TV-RGB switch determines the display output selection. Switch it to RGB (right) to output signal using HDMI connection and TV (left) to output signal using RCA connection.
(see fig. 1.2 # 3) |
|
|
Switch |
AVerVision Port |
Display Device Port |
RGB |
|
|
|
HDMI OUTPUT |
HDMI INPUT |
TV |
|
To |
|
|
|
|
TV OUTPUT |
VIDEO IN |
Connect to a Monitor or LCD/DLP Projector with HDMI Output interface
Locate the HDMI input port of the display device and connect it to HDMI out port of AVerVision F70W.
Make sure the TV/RGB switch is set to RGB.
HDMI monitor
HDMI cable
LCD/DCP projector
10
Connect to a TV
Locate the Video input port of the TV or Video equipment (i.e., VCR) to record your presentation and connect it to RCA jack of RCA cable.
RCA cable (optional)
Projector |
|
|
I N P U T |
||
VIDEO
Television
VCR
Connecting the Power
Connect the power adapter (12V 2AMP) to a standard 100V~240V AC power outlet. The unit automatically goes into standby mode once the power is connected. Press
to turn on.
Power adapter |
Wall outlet |
|
11
Loading...
