Operating Instructions
COOKER AND OVEN
GB
English,1
CX65SM2 AUS
CX65SM2 X AUS
Contents
GB
Installation, 2-6
Positioning and levelling
Mounting a Power Supply Cable
Electrical connection
Gas connection
Adapting to different types of gas
Table of burner and nozzle specifications
Table of characteristics
Description of the appliance, 7
Overall view
Control panel
Start-up and use, 8-10
Using the hob
Using the oven
Using the cooking timer
Cooking modes
Oven cooking advice table
Precautions and tips, 11
General safety
Disposal
Respecting and conserving the environment
Care and maintenance, 12
Switching the appliance off
Cleaning the appliance
Replacing the oven light bulb
Gas tap maintenance
Assistance
Page 2
Installation
GB
Before operating your new appliance please read
this instruction booklet carefully. It contains
important information concerning the safe installation
and operation of the appliance.
Please keep these operating instructions for future
reference. Make sure that the instructions are kept
with the appliance if it is sold, given away or moved.
The appliance must be installed by a qualified
professional according to the instructions provided.
Any necessary adjustment or maintenance must be
performed after the cooker has been disconnected
from the electricity supply.
Room ventilation
The appliance may only be installed in permanentlyventilated rooms, in accordance with current national
legislation. The room in which the appliance is
installed must be ventilated adequately so as to
provide as much air as is needed by the normal gas
combustion process (the flow of air must not be
lower than 2 m
The air inlets, protected by grilles, should have a
duct with an inner cross section of at least 100 cm
and should be positioned so that they are not liable
to even partial obstruction (see figure A).
These inlets should be enlarged by 100% - with a
minimum of 200 cm
hob is not equipped with a flame failure safety
device. When the flow of air is provided in an
indirect manner from adjacent rooms (see figure B),
provided that these are not communal parts of a
building, areas with increased fire hazards or
bedrooms, the inlets should be fitted with a
ventilation duct leading outside as described above.
AB
3
/h per kW of installed power).
2
- whenever the surface of the
Adjacent room Room requiring ventilation
2
Disposing of combustion fumes
The disposal of combustion fumes should be
guaranteed using a hood connected to a safe and
efficient natural suction chimney, or using an electric
fan that begins to operate automatically every time
the appliance is switched on (see figure).
Fumes channelled Fumes channelled through
straight outside a chimney or a branched
flue system (reserved for
cooking appliances)
The liquefied petroleum gases are heavier than air
and collect by the floor, therefore all rooms containing
LPG cylinders must have openings leading outside
so that any leaked gas can escape easily.
LPG cylinders, therefore, whether partially or
completely full, must not be installed or stored in
rooms or storage areas that are below ground level
(cellars, etc.). Only the cylinder being used should
be stored in the room; this should also be kept well
away from sources of heat (ovens, chimneys,
stoves) that may cause the temperature of the
cylinder to rise above 50°C.
Positioning and levelling
It is possible to install the appliance alongside
cupboards whose height does not exceed that of the
hob surface.
Make sure that the wall in contact with the back of
the appliance is made from a non-flammable, heatresistant material (T 90°C).
A
Ventilation opening Increase in the gap between
for comburent air the door and the flooring
After prolonged use of the appliance, it is
advisable to open a window or increase the speed of
any fans used.
2
To install the appliance correctly:
Place it in the kitchen, the dining room or the bed-
sit (not in the bathroom).
If the top of the hob is higher than the cupboards,
the appliance must be installed at least 600 mm
away from them.
Page 3
If the cooker is
installed underneath a
wall cabinet, there must
be a minimum distance
of 420 mm between
this cabinet and the top
700 mm. without hood
of the hob.
min. 650 mm. with hood
min.
mm.
420
Min.
HOOD
Min. mm.
600
420
Min. mm.
This distance should
be increased to 700
mm if the wall cabinets
are flammable (see figure).
Do not position blinds behind the cooker or less
than 200 mm away from its sides.
Any hoods must be installed according to the
instructions listed in the relevant operating
manual.
The cooker is fitted
with a safety chain that
must be attached to a
hook, secured to the
wall behind the
appliance.
GB
NL
To install the cable, proceed as follows:
_ Remove the wire clamp screw and the three
contact screws L-N-
Fasten the wires beneath the heads of the screws
using the following color scheme : Blue (N)
Brown (L) Yellow-Green
Fasten the supply cable in place with the clamp
and close the cover of the terminal board.
Electrical connection
Ovens with a three-pole power supply cable are
designed to operate with alternated current at the
supply frequency and voltage indicated on the data
plate (at the bottom of the oven dashboard). The
earthing conductor of the cable is the yellow-green
conductor.
Levelling
If it is necessary to level the
appliance, screw the
adjustable feet into the places
provided on each corner of the
base of the cooker (see
figure).
The legs* fit into the slots on
the underside of the base of
the cooker.
Mounting a Power Supply Cable
Opening the terminal board:
_ Using a screwdriver, prise on the side tabs of the
terminal board cover;
_ Pull open the cover of the terminal board.
Connecting the power supply cable to the mains.
Fit a normalized plug to the cable, which
corresponds to the load indicated on the data plate;
if the cooker is connected directly to the mains, an
omnipolar circuit-breaker with a minimum opening of
3 mm between the contacts, suitable for the load
indicated and complying with current directives,
must be installed between the appliance and the
mains (the earthing wire must not be interrupted by
the circuit-breaker). The power supply cable must be
positioned so that it does not exceed room
temperature by 50°C at any point of its length.
Before making the connection check that:
the limiter valve and the home system can
support appliance load (seedata plate);
the power supply system has an efficient earthing
connection which complies with the provisions of
current regulations and the law;
there is easy access to the socket or the
omnipolar circuit-breaker once the cooker has
been installed.
Do not use reducers, adapters or shunts as these
could cause heating or burning.
3
Page 4
GB
L
G
R
How to connect an alternative plug
The wires in this mains
GREEN &
YELLOW
BROWN
BLUE
13 amp fuse
CROSS-BAR
CORD GRIP
lead are coloured in
accordance with the
following code:
BLUE NEUTRAL (N)
BROWN LIVE (L)
GREEN AND YELLOW
EARTH (E)
Once the appliance has been installed, the power
supply cable and the electrical socket must be
easily accessible.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced
by authorised technicians only.
The manufacturer declines any liability should
these safety measures not be observed.
Gas connection using a flexible rubber hose
Make the connection using a gas hose that complies
with requirements set forth by the current National
Regulations. The appliance is factory set for
connection to a natural gas supply. A fitting "R" with
a conical thread ISO7-1
(1/2 gas) and a seal "G"
is fitted at the end "L"
of the pipe to be
connected to the gas
mains. This fitting
should not be removed.
When the connection
pipe (flexible or rigid) is
dismounted, the fitting
"R" should be locked in
place using a spanner
before unscrewing the metal pipe bolt. This is to
prevent the fitting "R" from slipping and so as not to
cause any leaks from sleeve "L". If the appliance is
designed for left and right gas connection, the cap
should be inverted and the seal supplied with the
appliance should be replaced when changing the
connection.
Gas connection
Connection to the gas network or to the gas cylinder
may be carried out using a flexible rubber or steel
hose, in accordance with current national legislation
and after making sure that the appliance is suited to
the type of gas with which it will be supplied (see the
rating sticker on the cover: if this is not the case see
below). When using liquid gas from a cylinder, install a
pressure regulator which complies with current national
regulations. To make connection easier, the gas
supply may be turned sideways*: reverse the position
of the hose holder with that of the cap and replace the
gasket that is supplied with the appliance.
Check that the pressure of the gas supply is
consistent with the values indicated in the Table of
burner and nozzle specifications (see below). This
will ensure the safe operation and durability of your
appliance while maintaining efficient energy
consumption.
Once the connection has been performed, make
sure that the hose:
Does not come into contact with any parts that
reach temperatures of over 50°C.
Is not subject to any pulling or twisting forces and
that it is not kinked or bent.
Does not come into contact with blades, sharp
corners or moving parts and that it is not
compressed.
Is easy to inspect along its whole length so that
its condition may be checked.
Is shorter than 1500 mm.
Fits firmly into place at both ends, where it will be
fixed using clamps that comply with current
regulations.
If one or more of these conditions is not fulfilled or
if the cooker must be installed according to the
conditions listed for class 2 - subclass 1 appliances
(installed between two cupboards), the flexible steel
hose must be used instead (see below).
4
Page 5
Connecting a flexible jointless stainless steel
pipe to a threaded attachment
Make sure that the hose and gaskets comply with
current national legislation.
To begin using the hose, remove the hose holder on
the appliance (the gas supply inlet on the appliance
is a cylindrical threaded 1/2 gas male attachment).
Perform the connection in such a way that the hose
length does not exceed a maximum of 2 metres,
making sure that the hose is not compressed and
does not come into contact with moving parts.
Checking the tightness of the connection
Adjusting the hob burners minimum setting:
1. Turn the tap to the minimum position.
2. Remove the knob and adjust the regulatory
screw, which is positioned inside or next to the tap
pin, until the flame is small but steady.
If the appliance is connected to a liquid gas
supply, the regulatory screw must be fastened as
tightly as possible:
GB
When the installation process is complete, check
the hose fittings for leaks using a soapy solution.
Never use a flame.
Adapting to different types of gas
It is possible to adapt the appliance to a type of gas
other than the default type (this is indicated on the
rating label on the cover).
Adapting the hob
Replacing the nozzles for the hob burners:
1. Remove the hob grids and slide the burners off
their seats.
2. Unscrew the nozzles using a 7 mm socket
spanner (see figure), and
replace them with nozzles
suited to the new type of gas
(see Burner and nozzle
specifications table).
3. Replace all the components
by following the above
instructions in reverse.
3. While the burner is alight, quickly change the position
of the knob from minimum to maximum and vice versa
several times, checking that the flame is not
extinguished.
The hob burners do not require primary air adjustment.
After adjusting the appliance so it may be used with a
different type of gas, replace the old rating label with a
new one that corresponds to the new type of gas (these
labels are available from Authorised Technical Assistance
Centres).
Should the gas pressure used be different (or vary
slightly) from the recommended pressure, a suitable
pressure regulator must be fitted to the inlet hose in
accordance with current national regulations relating
to regulators for channelled gas.
5
Page 6
GB
g
g
Table of burner and nozzle specifications
Table 1 Propane Natural Gas
Burner Diameter
(mm)
Nominal Thermal
Power
Nozzle
1/100
Nominal Thermal
Power
Nozzle
1/100
(MJ/h)* (mm) (MJ/h)* (mm)
Auxiliary (A) 55 3.5 50 3.3 85
Tripl Crown (TC) 130 15.0 105 15.0 175
SemiRapid (S) 75 5.5 64 6.0 110
Rapid (R) 100 9.0 80 8.3 129
1.00
0.75
1.20
Supply pressures
* At 15°C and 101.3 kPa dry
Nominal (kPa)
Minimum (kP a)
Maximum (kPa)
as
2.75
2.00
3.50
Propane = 95.8 MJ/m³
Natural
as = 37.8 MJ/m³
Total Thermal Power (MJ/h)
Propane Natural Gas
CX65SM2 AUS
CX65SM2 X AUS
33.0 32.6
S
R
A
TC
CX65SM2 AUS
CX65SM2 X AUS
TECHNICAL DATA
Oven dimensions
(HxWxD)
Volume
Useful
measurements
relating to the oven
compartment
Burners
Voltage and
frequency
32x42x40 cm
54 l
width 42 cm
depth 44 cm
height 8.5 cm
may be adapted for use with any
type of gas shown on the data plate
see data plate
EC Directives: 2006/95/EEC dated
12/12/06 (Low Voltage) and
subsequent amendments 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent amendments 90/369/EEC dated 29/06/90 (Gas)
and subsequent amendments 93/68/EEC dated 22/07/93 and
subsequent amendments 2002/96/EC.
6
Page 7
Description
of the appliance
Overall view
DRIPPING PAN rack
Gas burner
Hob grid
Control panel
GRILL rack
Adjustable foot
GB
Containment surface
for spills
GUIDE RAILS
for the sliding racks
position 5
position 4
position 3
position 2
position 1
Adjustable foot
Control panel
OVEN
OPERATION
indicator light
SELECTOR knob
THERMOSTAT indicator light
THERMOSTAT knob
Hob BURNER
control knobs
COOKING TIMER knob
7
Page 8
Start-up and use
GB
Using the hob
Lighting the burners
For each BURNER knob there is a complete ring
showing the strength of the flame for the relevant burner.
To light one of the burners on the hob:
1. Bring a flame or gas lighter close to the burner.
2. Press the BURNER knob and turn it in an
anticlockwise direction so that it is pointing to the
maximum flame setting -.
3. Adjust the intensity of the flame to the desired level
by turning the BURNER knob in an anticlockwise
direction. This may be the minimum setting +, the
maximum setting - or any position in between the two.
If the appliance is fitted with
an electronic lighting device*
(see figure), press the
BURNER knob and turn it in
an anticlockwise direction,
towards the maximum flame
setting, until the burner is lit.
The burner may be
extinguished when the knob is released. If this
occurs, repeat the operation, holding the knob down
for a longer period of time.
For models equipped with a reducer grid, the latter
must be used only for the auxiliary burner, when
pans with a diameter of less than 12 cm are used.
Using the oven
The first time you use your appliance, heat the empty
oven with its door closed at its maximum temperature
for at least half an hour. Ensure that the room is well
ventilated before switching the oven off and opening
the oven door. The appliance may emit a slightly
unpleasant odour caused by protective substances
used during the manufacturing process burning away.
Never put objects directly on the bottom of the oven;
this will avoid the enamel coating being damaged.
1. Select the desired cooking mode by turning the
SELECTOR knob.
2. Select the recommended temperature for the
cooking mode or the desired temperature by turning
the THERMOSTAT knob.
A list detailing cooking modes and suggested
cooking temperatures can be found in the relevant
table (see Oven cooking advice table).
If the flame is accidentally extinguished, switch off
the burner and wait for at least 1 minute before
attempting to relight it.
If the appliance is equipped with a flame failure
safety device*, press and hold the BURNER knob
for approximately 2-3 seconds to keep the flame
alight and to activate the device.
To switch the burner off, turn the knob until it
reaches the stop position .
Practical advice on using the burners
For the burners to work in the most efficient way
possible and to save on the amount of gas
consumed, it is recommended that only pans that
have a lid and a flat base are used. They should
also be suited to the size of the burner:
Burner ø Cookware Diameter (cm)
Fast (R) 24 - 26
Semi Fast (S) 16 - 20
Auxiliary (A) 10 - 14
Triple Crown (TC) 24 - 26
To identify the type of burner, please refer to the
diagrams contained in the Burner and nozzle
specifications.
During cooking it is always possible to:
Change the cooking mode by turning the
SELECTOR knob.
Change the temperature by turning the
THERMOSTAT knob.
Stop cooking by turning the SELECTOR knob to
the 0 position.
Always place cookware on the rack(s) provided.
THERMOSTAT indicator light
When this is illuminated, the oven is generating
heat. It switches off when the inside of the oven
reaches the selected temperature. At this point the
light illuminates and switches off alternately,
indicating that the thermostat is working and is
maintaining the temperature at a constant level.
OPERATION indicator light
When this is illuminated, the oven is generating
heat.
Oven light
This is switched on by turning the SELECTOR knob
to any position other than 0. It remains lit as long
as the oven is operating. By selecting
knob, the light is switched on without any of the
heating elements being activated.
with the
&
8
Page 9
Using the cooking timer
1. To set the buzzer, turn the COOKING TIMER knob
clockwise almost one complete revolution.
2. Turn the knob anticlockwise to set the desired
time: align the minutes shown on the COOKING
TIMER knob with the indicator on the control panel.
3. When the selected time has elapsed, a buzzer
sounds and the oven turns off.
4. When the oven is off the cooking timer can be
used as a normal timer.
To use the oven manually, in other words when you
do not wish to use the end of cooking timer, turn the
COOKING TIMER knob until it reaches the '
symbol.
small dishes. Place the food in the centre of the
rack, as it will not be cooked properly if it is placed
in the corners.
GRILL mode
The central part of the top heating element is
switched on. The high and direct temperature of the
grill is recommended for food that requires a high
surface temperature (veal and beef steaks, fillet
steak and entrecôte). This cooking mode uses a
limited amount of energy and is ideal for grilling
small dishes. Place the food in the centre of the
rack, as it will not be cooked properly if it is placed
in the corners.
GB
Cooking modes
A temperature value can be set for all cooking
modes
between 60°C and Max, except for the following
modes
TOP OVEN and GRILL (recommended: set only to
MAX power level).
GRATIN (recommended: do not exceed 200°C).
TRADITIONAL OVEN mode
Both the top and bottom heating elements will come
on. When using this traditional cooking mode, it is
best to use one cooking rack only. If more than one
rack is used, the heat will be distributed in an
uneven manner.
MULTILEVEL mode
All the heating elements (top and bottom) switch on
and the fan begins to operate. Since the heat
remains constant throughout the oven, the air cooks
and browns food in a uniform manner. A maximum of
two racks may be used at the same time.
TOP OVEN mode
The central part of the top heating element is
switched on. The high and direct temperature of the
grill is recommended for food that requires a high
surface temperature (veal and beef steaks, fillet
steak and entrecôte). This cooking mode uses a
limited amount of energy and is ideal for grilling
GRATIN mode
The top heating element and the fan will begin to
operate. This combination of features increases the
effectiveness of the unidirectional thermal radiation
provided by the heating elements through forced
circulation of the air throughout the oven. This helps
prevent food from burning on the surface and allows
the heat to penetrate right into the food.
The TOP OVEN, GRILL and GRATIN cooking
modes must be performed with the oven door shut.
When using the TOP OVEN and GRILL cooking
modes, place the rack in position 5 and the dripping
pan in position 1 to collect cooking residues (fat
and/or grease). When using the GRATIN cooking
mode, place the rack in position 2 or 3 and the
dripping pan in position 1 to collect cooking
residues.
Cooking on several shelves simultaneously
If it is necessary to use two racks, use the
MULTILEVEL cooking mode, as this is the only
cooking mode suited to this type of cooking. We
also recommend that:
Positions 1 and 5 are not used. This is because
excessive direct heat can burn temperature
sensitive foods.
Positions 2 and 4 are used and that food that
requires more heat is placed on the rack in
position 2.
When cooking foods that require different cooking
times and temperatures, set a temperature that is
halfway between the two recommended
temperatures (see Oven cooking advice table)
9
Page 10
GB
and place the more delicate food on the rack in
position 4. Remove the food that requires a
shorter cooking time first.
When cooking pizzas on several racks with the
temperature set to 220°C, the oven is preheated
for 15 minutes. Generally speaking, cooking on
the rack in position 4 takes longer: we
recommend that the pizza cooked on the lowest
rack position is removed first, followed by the
pizza cooked in position 4 a few minutes later.
Place the dripping pan on the bottom and the rack
on top.
Oven cooking advice table
Cooking
modes
Traditional
Oven
Multilevel
Top oven
Grill
Gratin
Foods
Duck
Roast veal or beef
Roast pork
Biscuits (shortcrust pastry)
Pies / Tarts
Pizza (on 2 racks)
Lasagne
Lamb
Roast chicken + potatoes
Mackerel
Sponge cake made with yoghurt
Cream puffs (on 2 racks)
Biscuits (on 2 racks)
Sponge cake (on 1 rack)
Sponge cake (on 2 racks)
Savoury pies
Sole and cuttlefish
Squid and prawn kebabs
Cod fillet
Grilled vegetables
Sole and cuttlefish
Squid and prawn kebabs
Cuttlefish
Cod fillet
Grilled vegetables
Veal steak
Sausages
Hamburgers
Mackerel
Toasted sandwiches (or toast)
Grilled chicken
Cuttlefish
Weight
(in kg)
1
1
1
-
1
1
1
1
1+1
1
1
0.5
0.5
0.5
1
1.5
1
1
1
1
0.7
0.6
0.6
0.8
0.4
0.8
0.6
0.6
1
4 and 6
1.5
1.5
Rack
position
3
3
3
3
3
2 and 4
3
2
2 and 4
2
2
2 and 4
2 and 4
2
2 and 4
3
4
4
4
3/4
4
4
4
4
3 or 4
4
4
4
4
4
2
2
Preheating
time
(minutes)
15
15
15
15
15
15
10
10
15
10
10
10
10
10
10
15
5
5
5
5
-
-
-
-
-
-
-
-
-
-
10
10
Recommended
temperature
200
200
200
180
180
230
180
180
200
180
170
190
180
170
170
200
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
200
200
Cooking
duration
(minutes)
65-75
70-75
70-80
15-20
30-35
15-20
30-35
40-45
60-70
30-35
40-50
20-25
10-15
15-20
20-25
25-30
10-15
10-12
10-15
10-15
15-20
15-20
15-20
10-12
15-20
55-60
30-35
8-10
6-8
10
8-10
3-5
10
Page 11
Precautions and tips
This appliance has been designed and manufactured in
compliance with international safety standards.
The following warnings are provided for safety reasons and
must be read carefully.
General safety
The appliance was designed for domestic use inside the
home and is not intended for commercial or industrial use.
The appliance must not be installed outdoors, even in
covered areas. It is extremely dangerous to leave the
appliance exposed to rain and storms.
Do not touch the appliance with bare feet or with wet or
damp hands and feet.
The appliance must be used by adults only for the
preparation of food, in accordance with the instructions
provided in this booklet.
The instruction booklet accompanies a class 1 (insulated)
or class 2 - subclass 1 (recessed between 2 cupboards)
appliance.
Do no t touch th e he ating elements or ce r t a i n
parts of the ov en door when the appliance is
in us e; th e s e p
Keep children well away from th e appli a n ce .
Make sure that the power supply cables of other electrical
appliances do not come into contact with the hot parts of
the oven.
The openings used for the ventilation and dispersion of
heat must never be covered.
Always use oven gloves when placing cookware in the
oven or when removing it.
Do not use flammable liquids (alcohol, petrol, etc...) near
the appliance while it is in use.
Do not place flammable material in the lower storage
compartment or in the oven itself. if the appliance is
switched on accidentally, they could catch fire.
The internal surfaces of the compartment (where present)
may become hot.
Always make sure the knobs are in the
appliance is not in use.
arts become ext r e m ely hot.
position when the
If the appliance breaks down, under no circumstances
should you attempt to perform the repairs yourself. Repairs
carried out by inexperienced persons may cause injury or
further malfunctioning of the appliance. Contact
Assistance.
Do not rest heavy objects on the open oven door.
The appliance should not be operated by people (including
children) with reduced physical, sensory or mental
capacities, by inexperienced individuals or by anyone who
is not familiar with the product. These individuals should, at
the very least, be supervised by someone who assumes
responsibility for their safety or receive preliminary
instructions relating to the operation of the appliance.
Do not let children play with the appliance.
Disposal
When disposing of packaging material: observe local
legislation so that the packaging may be reused.
The European Directive 2002/96/EC relating to Waste
Electrical and Electronic Equipment (WEEE) states that
household appliances should not be disposed of using the
normal solid urban waste cycle. Exhausted appliances
should be collected separately in order to optimise the cost
of re-using and recycling the materials inside the machine,
while preventing potential damage to the atmosphere and
to public health. The crossed-out dustbin is marked on all
products to remind the owner of their obligations regarding
separated waste collection.
For further information relating to the correct disposal of
exhausted household appliances, owners may contact the
public service provided or their local dealer.
Respecting and conserving the
environment
You can help to reduce the peak load of the electricity
supply network companies by using the oven in the hours
between late afternoon and the early hours of the morning.
Always keep the oven door closed when using the TOP
OVEN, GRILL and GRATIN modes: This will achieve
improved results while saving energy (approximately 10%).
GB
When unplugging the appliance, always pull the plug from
the mains socket; do not pull on the cable.
Never perform any cleaning or maintenance work without
having disconnected the appliance from the electricity
mains.
Check the door seals regularly and wipe them clean to
ensure they are free of debris so that they adhere properly
to the door, thus avoiding heat dispersion.
11
Page 12
Care and maintenance
09/2008 - 195070641.00
XEROX BUSINESS SERVICES
GB
Switching the appliance off
Disconnect your appliance from the electricity
supply before carrying out any work on it.
Cleaning the appliance
Never use steam cleaners or pressure cleaners on
the appliance.
The stainless steel or enamel-coated external
parts and the rubber seals may be cleaned using
a sponge that has been soaked in lukewarm water
and neutral soap. Use specialised products for
the removal of stubborn stains. After cleaning,
rinse well and dry thoroughly. Do not use abrasive
powders or corrosive substances.
The hob grids, burner caps, flame spreader rings
and burners may be removed to make cleaning
easier; wash them in hot water and non-abrasive
detergent, making sure all burnt-on residue is
removed before drying them thoroughly.
Clean the terminal part of the flame failure safety
devices* frequently.
The inside of the oven should ideally be cleaned
after each use, while it is still lukewarm. Use hot
water and detergent, then rinse well and dry with
a soft cloth. Do not use abrasive products.
Clean the glass part of the oven door using a
sponge and a non-abrasive cleaning product,
then dry thoroughly with a soft cloth. Do not use
rough abrasive material or sharp metal scrapers
as these could scratch the surface and cause the
glass to crack.
Replacing the oven light bulb
1. After disconnecting the oven
from the electricity mains,
remove the glass lid covering
the lamp socket (see figure).
2. Remove the light bulb and
replace it with a similar one:
voltage 230 V, wattage 25 W,
cap E 14.
3. Replace the lid and reconnect the oven to the
electricity supply.
Gas tap maintenance
Over time, the taps may become jammed or difficult
to turn. If this occurs, the tap must be replaced.
This procedure must be performed by a
qualified technician authorised by the
manufacturer.
Assistance
Never use the services of an unauthorised
technician.
Please have the following information to hand:
The type of problem encountered.
The appliance model (Mod.).
The serial number (S/N).
The latter two pieces of information can be found on
the data plate located on the appliance.
The accessories can be washed like everyday
crockery, and are even dishwasher safe.
Inspecting the oven seals
Check the door seals around the oven regularly. If
the seals are damaged, please contact your nearest
Authorised After-sales Service Centre. We
recommend that the oven is not used until the seals
have been replaced.
12
Only available in certain models.
*
Loading...
